A RECONFIGURATION ALGORITHM FOR DISTRIBUTED

COMPUTER NETWORKS

Chanan Glezer

Department of Information Systems Engineering, Ben Gurion University, Beer Sheva, Israel 84105

Moshe Zviran

Chair, Management of Technology and Information Systems Department

The Leon Recanati School of Business Administration,Tel Aviv University, Tel Aviv, Israel 69978

Keywords: computer networks, dependability, fault tolerance, load balancing

Abstract: This article presents an algorithmic reconfiguration model, combining mechan

isms of load balancing and

fault tolerance in order to increase utilization of computer resources in a distributed multi-server, multi-

tasking environment. The model has been empirically tested in a network of computers controlling

telecommunication hubs and is compared to previous efforts to address this challenge.

1 INTRODUCTION

Telecommunication systems as well as other

mission-critical systems such as utility, banking,

medical, military and transportation networks rely

heavily on state-of-the–art computing and

telecommunication technologies.

Fault tolerance i

n distributed computer networks

refers in most cases to a hot-standby approach

(Anderson and Lee, 1981), which is based on

duplication of computer resources using check-

pointing and message-logging techniques (Folliot

and Sens, 1994). Nevertheless, during periods of

normal operation the duplicated computer

resources are underutilized.

Load Balancing in a Distributed Computing

Syste

m (DCS) (Tiemeyer and Wong, 1988) refers

to dynamically allocating and independently

performing computation tasks across a

heterogeneous network of processors.

Several experiences have been reported on

com

bining load-balancing and fault-tolerance

mechanisms, (e.g., Remote Execution Manager

(Shoja et al., 1987), Paralex (Babaoglu et al.,

1992), Condor (Litzkow et al., 1988), and DAWGS

(Clark and McMillin, 1992), Coterie (Tiemeyer and

Wong, 1988)). Nevertheless, these systems exhibit

only limited fault tolerance capabilities. The most

comprehensive attempt to constructs a

reconfigurable, fault tolerant system was made in

GATOSTAR (Folliot and Sens, 1994).

The goal of this article is to develop, illustrate and

practically evaluate an algo

rithmic model that

combines load sharing and fault tolerance using the

prominent Hamilton method (Ibarkai and Katoh,

1988).

2 THE RECONFIGURATION

MODEL

The proposed model is based on combining the

mechanisms for fault tolerance and load balancing

in a multi-server and multi-tasking computer

network. Following are the assumptions underlying

the model:

1. Each computer connected to the network can

ocess several types of tasks concurrently based

on the unique requirements of each task.

2. The tasks are processed from queues by (expert)

serve

rs operating under the computers connected to

the network.

3. In case one of the servers

becomes inoperative,

the tasks in its incoming queue are routed to similar

servers running concurrently on different

computers.

491

Glezer C. and Zviran M. (2004).

A RECONFIGURATION ALGORITHM FOR DISTRIBUTED COMPUTER NETWORKS.

In Proceedings of the Sixth International Conference on Enterprise Information Systems, pages 491-494

DOI: 10.5220/0002592704910494

 SciTePress

4. Servers of a given type on different computers

may have a different processing capacity.

5. The prototype derived from the conceptual

model should accommodate safety mechanisms

that will enable it to handle both crash-type and

arbitrary (Byzantine) failures, resulting in a higher

failure mode coverage (Laprie, 1995)

The challenge in providing fault tolerance in the

scenario described above stems from the dynamic

and uncertain nature of the network. As a case in

point, computers can be installed or removed in

real time, unexpected software/hardware crashes

may occur. It is the need to provide end-users with

quality service at a minimum level of response time

that prompts the seeking and evaluation of

mechanisms that will detect faults as well as

rapidly adjust the performance of the network so

that the desired quality standards are maintained.

Effective synchronization and communication

protocols are a critical asset for the success of such

a system.

The proposed reconfiguration model is algorithmic

and comprises the following elements:

Network Status: A set of vectors and matrices that

capture the actual state of the network at any given

point in time (termed logical configuration). These

elements describe which servers and computers are

active and which tasks are processed on each server

at any point in time. It also includes operational

instructions on what to do with the tasks running on

a server in case the host computer becomes

inoperative.

Task-Reconfiguration Algorithm: An algorithmic

set of procedures that transform the network status

elements so that they capture and react to changes

in the state of the network (termed events) with

minimal delay.

Note that contrary to the logical configuration, the

physical configuration of the network refers to the

hardware profile (e.g., ratio of memory/CPU

power, number of I/O devices etc.). Changes in the

physical configuration are therefore less frequent

than changes in the logical configuration. The

former fall outside the focus of the model because

they cannot affect the behavior of the model unless

they are first reflected in the logical configuration

(e.g., register a newly acquired computer in an

appropriate status matrix).

The basic principle of the model is to dynamically

redistribute tasks between servers available on the

network in response to threatening events. When

such an event occurs in the network (e.g., a

computer crashes, or an arbitrary failure occurs),

the model reallocates active tasks on running the

stalled computer to other available computers

according to a proportional ratio determined by the

relative importance of the servers. The importance

(vote) of a server is based on the system manager's

perception of the relative processing capacity of all

servers of a given type (running on different

computers). In case there is a leftover task as a

result of the above event, then this task is allocated

to the computer that has the highest remainder,

using the Hamilton method (Ibarkai and Katoh,

1988). This approach can be applied to the event

of system initialization as well.

3 EVALUATION OF THE

MODEL

The proposed reconfiguration model was evaluated

on a large national digital telecommunications

network comprising approximately 200 hubs of the

following types: TX-1, TMX-10, and TMX-100

(manufactured by Northern Telecom) and System-

12 (manufactured by Alcatel). The above hubs

serve in the range of 1000 to 20,000 customers

each. As an example, the System-12 hub is a

complex hardware and software device running

several tens of modules concurrently. The modules

are responsible for various tasks (e.g., central

control, connection with customers, message

routing, connection bus with other hubs,

distribution control and more). The System-12 hub

uses approximately 100 types of status messages in

order to monitor and coordinate the operation of

the hub (e.g., detecting and handling malfunctions).

The model for controlling the network was

implemented using the C programming language.

The system operates over the VAX/OpenVMS

operating system running on two VAX 4000-5000

computers and using the Digital RMS software for

file management. The computers are connected in a

cluster using the Digital Small Systems

Interconnect (DSSI), which enables sharing of

disks among computers, synchronization of events

and transmission of data. Connection between the

servers on the computers and the hubs they are

serving is implemented using a X.25 packet

switching network. This network transmits

instructions from the servers to the hubs and events

from the hubs to the servers. The performance of

the network was measured and recorded using

Digital's Monitor software package over a period of

one month. Several measurements were performed

during the day and an arithmetic average was used

to summarize the results. The effect of the

workload created by MONITOR on the results is

ICEIS 2004 - DATABASES AND INFORMATION SYSTEMS INTEGRATION

492

negligible compared to the other tasks running on

the computers, and can therefore be ignored.

Table 1: Comparison of Cost/Utilization and Balance

Factors

The benefit from using the proposed model was

evaluated the theory of constraints (TOC), with or

without a manufacturing focus, and on the

cost/utilization model (Borovits and Ein-Dor,

1977) The idea underlying the method is to

generalize the application of TOC combined with

cost/utilization for performance analysis of a single

processor, into a scenario of a distributed network

composed of several processors. The method

exploits a simple graphic display of the processing

element (PE) components (e.g., CPU, Input/Output,

Memory, Communication links) in order to

pinpoint improper imbalances, fluctuations and

bottlenecks. The model uses the following two

main indicators for evaluating performance of a

distributed system. The values of F (cost utilization

factor) and B (balance) are between 0 and 1.

∑Pi * Ui (i=1….I)

B= Balance Factor = 2*√ ∑[( F-Ui)**2 *Pi]

Where I = Number of processing elements on a

single processor

Pi= Relative cost of PE i

Ui= Utilization percentage level of PE i

The closer F gets to 1 the better the utilization of

the network is in terms of the cost of its elements.

The closer B gets to the less balanced the network

becomes resulting in bigger variance in the

utilization of its elements. Since the percentage of

resource utilization in the original cost utilization

model is replaced by the maximal resource

utilization in the PE, it is better to have a system

that is balanced (a smaller B is better). If there is a

resource that is highly utilized in one of the PEs

compared to the other resources in that PE, a

moderate increase in the workload might cause a

crash or bottleneck in that PE. This could affect the

viability of the whole system.

The evaluation of the reconfiguration model was

performed by comparing the B and F measures in

two scenarios: hot standby, where a computer is

used as a mirror backup (without routinely sharing

the workload of the other computers); and a

scenario, where the backup computer processes

tasks and the load is balanced among all computers

linked to the network (reconfiguration).

Table 1 depicts the values calculated for B and F in

the two scenarios. In both cases the utilization of

the two computers is not good. The cost of

purchasing the backup computer is an imposed

operational constraint, and therefore there is no

option to alter the cost of the combined system.

The reconfiguration model seems to be the

preferred option because the system is more

balanced (0.433<0.653) and can therefore handle

peak processing volume with a better quality of

service. In other words, the model enables avoiding

bottlenecks which cause down time and impair

service to end-users. In the hot standby option, the

risk of a total malfunction, however, is higher

because the operations relies only on a single

computer which is more prone to crash.

Hot Standby Reconfiguration

Model

F 0.365 0.21

B 0.653 0.433

Table 2 contrasts the proposed model with the

GATOSTAR system (Folliot and Sens, 1994). The

main theme of the reconfiguration model presented

in this article is the application of the Hamilton

method (Ibarkai and Katoh, 1988) to the task

redistribution process. This article also analyses the

effectiveness of the proposed method in a very

large-scale industrial setting. A combination of the

two approaches is recommended for covering all

aspects of the dependability challenge

4 DISCUSSION

This study proposed and evaluated an algorithmic

model for combining hot standby and load

balancing in a network of computers where tasks

are processed concurrently and re-allocated by

servers running concurrently on different

computers.

The research found support for the claim that a

combination of fault tolerance and load balancing

mechanisms is more effective than software-based

fault tolerance alone. The combined approach is

also better than implementing a purely hardware-

based fault tolerant system, which is a much more

expensive solution because it requires the purchase

of specialized, synchronized, fault-tolerant

computers.

A RECONFIGURATION ALGORITHM FOR DISTRIBUTED COMPUTER NETWORKS

493

Table 2: Comparing the HS/LB model with the

GATOSTAR system

Criterion/

System

HS/LB

Reconfiguration

(Model and

Prototype)

GATO-STAR

Locus of

model

Specification of a

redistribution

mechanism to

increase utilization

Seamless

unification of

GATOS and

STAR

Impleme-

ntation

constructs

Network of

computers, each

with servers that

handle processes

Ring of hosts

composed

daemons

(LSM, FTM,

RM)

Algorithm Hamilton method

(Ibarkai and Katoh,

1988)

Overload,

migration,

reception

thresholds

Network

status

information

Matrices and

vectors

Local shared

memory

Prototype Hubs serving a

national

telecommunica-

tion network

Workstatio-ns

in a LAN of a

university

Evaluation

criteria

Balance (B) and

Utilization (U)

factors

Overhead of

process

allocation,

logging.

Conclusions Combining load

balancing with

fault tolerance

recommended for

increasing potential

of dependable

computer networks

Useful for

increasing

dependa-bility

of LANs).

Need to reduce

overhead

A major advantage of the model is its flexibility

and scalability. The model can operate on various

hardware platforms and has a great effect on both

real-time and Electronic Data Processing (EDP)

applications.

The model can be expanded in the future to include

an internal feedback system that changes the vote

(relative importance) of different servers

automatically to achieve an optimal balance in the

network. Such a system will invoke a quantitative

model, suggest a modification to the human

administrator, and enable “what-if” analysis

regarding the effects caused by various changes in

the logical configuration of the network.

REFERENCES

Anderson, T., and Lee, P.A., 1981. Fault Tolerance:

Principles and Practice, Prentice Hall International,

Englewood Cliffs, N.J.

Babaoglu, O., Alvisi, L., Amoroso, A., and Davoli, R.,

1992. Paralex: An environment for parallel

programming in distributed systems, Proc. of

International Conference on Supercomputing,

Washington D.C.

Borovits, I., and Ein-Dor, P., 1977. Cost/utilization: A

measure of system performance, Communications of

the ACM, 20 (3), pp. 185-191.

Clark, H., and McMillin, V., 1992. DAWGS – A

distributed computer server utilizing idle

workstations, Journal of Parallel Distributed

Computing, 14, pp. 175-186.

Folliot, B., and Sens, P., 1994. GATOSTAR: A fault

tolerant load sharing facility for parallel applications,

Proc. of the first European dependable computing

conference, Berlin.

Ibarkai, T. and Katoh, N., 1988. Resource Allocation

Problems: Algorithmic Approaches, MIT Press,

Foundations of Computer Series, Cambridge, MA,

(Chap. 6: The apportionment problem: the Hamilton

Method, pp. 106-126)

Laprie, J.C., 1995. Dependable computing: Concepts,

limits, challenges, invited paper FTCS-25, pp. 42-54.

Litzkow, M.J., Livny, M., and Mutka, M.W., 1988.

Condor - A hunter of idle workstations, Proc. of the

International Conference on Distributed

Computing Systems, San Jose, CA.

Shoja, C.G., Clarke, G., and Taylor, T., 1987. REM: A

distributed facility for utilizing idle processing power

of workstations, Proc. of the IFIP Conference on

Distributed Processing, Amsterdam.

Tiemeyer, M.P., Wong, J.S.K, 1998. A task migration

algorithm for heterogeneous distributed computing

systems, Journal of Systems and Software, 41 (3), pp.

175 – 188.

ICEIS 2004 - DATABASES AND INFORMATION SYSTEMS INTEGRATION

494
