MEASURING REQUIREMENT EVOLUTION

A Case Study in the E-commerce Domain

Päivi Ovaska

Lappeenranta University of Technology, P.O. BOX 20, FIN-53851, Lappeenranta , Finland

Keywords: Requirement evolution, requirements creep, s

ystems development prediction

Abstract: Although requirement evolution is a widely recognized phenomenon, there are only a few approaches for

measuring it. These existing approaches are based on the assumption that all the requirements exist and can

be seen in the requirement elicitation and analysis phases. They do not include provisions for the emergence

during systems development of new requirements, which cannot be anticipated in the requirement elicitation

and analysis phase. This paper shows how the concept of requirements creep is adopted for the

measurement of emergent requirement evolution. We use a case study in the E-commerce domain to

illustrate the use of this measure in the prediction of systems development. The findings of this study

suggest that requirement evolution can be measured in a practical software project, and the findings

demonstrate the strong influence of requirements creep on the systems development effort. The findings of

our study encourage us to undertake further studies involving other organizations and projects.

1 INTRODUCTION

Changing requirements and requirement evolution

are recognized as being a difficult and major source

of risks in the systems development projects.

Requirement evolution may lead to increasing costs,

schedule overruns as well as to system evolution in

software projects (Harker, Eason and Dobson, 1993;

van Lamsweerde, 2000). There are many reasons for

these changing requirements: stakeholders may

change their minds about the functionality of the

proposed system; new or modified requirements

may emerge during the design, implementation and

testing processes; analysts and designers may not

understand the requirement etc.

Although requirement evolution is a widely

recognized

phenom

enon, only a few approaches

have been developed to quantitatively measure it.

These approaches assume that all the requirements

are gathered and documented in the beginning of the

development of a systems and that the only changes

and additions to these initial requirements are made

during the systems development process. The

objective of this paper is to study how requirement

evolution can be measured in a situation, in which

requirements are not known in the requirement

specification stage but, rather, emerge during the

course of the development of the system. This

approach is based on the notion that the

requirements for system development do no exist a

priori but are, rather, socially constructed through

interactions among the participants in system

development (Davidson, 2002; Curtis, Krasner and

Iscoe, 1988; Ovaska, 2003).

This paper presents the early results of an

ngo

ing study into how requirement evolution

should be measured. This information can be used to

aid the prediction of system development in

organizations through the collection of history

information on completed projects. The collected

history information can then be used to support the

development of the prediction effort in future

projects. The aim of this paper is to present ways of

measuring requirement evolution using the concept

of requirements creep, to demonstrate the use and

importance of requirements creep in the case study

as well as to gain an insight into how to further

develop our approach.

The rest of the paper is structured as follows.

Sectio

2 presents previous research into

requirement evolution. Section 3 discusses a case

study and an example of the use of requirements

creep in the prediction of systems development.

Section 4 presents the conclusions and discusses the

research results along with topics for further studies.

669

Ovaska P. (2004).

MEASURING REQUIREMENT EVOLUTION - A Case Study in the E-commerce Domain.

In Proceedings of the Sixth International Conference on Enterprise Information Systems, pages 669-673

DOI: 10.5220/0002628806690673

 SciTePress

2 APPROACHES FOR

REQUIREMENT EVOLUTION

There are at least two different approaches to

managing requirement evolution. The requirement

engineering approach (Wiegers, 1999; Kotonya and

Sommerville, 1998; Jarke et. al, 1999) attempts to

manage requirement evolution using process-

oriented activities that try to eliminate the

phenomena. The other approach (Jarke et. al, 1999,

van Lamsweerde, 2000; Tomayko, 2002; Lehman,

1998; Lehman, Perry and Ramil, 1998) considers

requirement evolution as a natural and inevitable

feature of systems development instead of an issue

that has to be solved or eliminated. Software

lifecycle models and methodologies, such as

prototyping (Kotonya and Sommerville, 1998) and,

more recently, different kinds of agile methods

(Cockburn, 2001), are examples of the latter

approach to requirement evolution.

One way of understanding requirement evolution

is to measure it quantitatively, as in (IEEE Std

982.1, 1988; IEEE Std 982.2, 1988; Andersson and

Felici, 2002). These IEEE standards propose a

Requirement Maturity Index (RMI); the RMI metric

attempts to quantify the readiness of requirements.

In (Andersson and Felici, 2001), the metric is

extended by taking into account historical

information on change, as a result of which a

Historical Requirements Maturity Index (HRMI) is

proposed. The above-mentioned approaches measure

RMI or HRMI over all the software releases and

quantify the readiness of requirements over time.

These metrics are calculated on the basis of

requirement specification, which is performed as a

result of requirement elicitation and analysis.

A phenomenon called ‘requirements creep’

(Ryan et. al, 2001; Wiegers, 1999) takes into

account new emerging requirements which do not

necessarily exist in the requirement specification

document but have emerged during the course of the

development process. In (Wiegers, 1999),

requirements creep refers to the ”difference between

the requirements specification developed after the

requirements procedure and the requirements at the

time when the actual product is built”. In (Ryan et.

al, 2001), requirements creep is referred as

”significant additions or modifications to the

requirements of a software system throughout the

lifecycle, resulting in extensions to and alteration of

the software’s functionality and scope”.

3 CASE STUDY

3.1 Project Description

This study was carried out in the systems

development department of an international ICT

company. The project involved the development of

an E-commerce mobile service platform. The system

was intended to enable organizers or their sponsors

to promote their products in different kinds of

happenings, such as ice hockey and football games.

The system was composed of two subsystems, a

platform in which the services were running

(Subsystem A) and a toolbox, which permitted

addition, configuration and simulation services

(Subsystem B). This toolbox was intended to run on

a PC in the Windows environment and the platform

in the UNIX environment.

The project employed the object-oriented

approach for systems development and was

implemented in 2001.The project was divided into

the following phases on the basis of the company’s

process model: pre-study, feasibility study, project

execution and piloting and maintenance. The

requirements were collected and analyzed during the

pre-study and feasibility study phases. One of the

first activities in the project execution phase was to

design the software architecture, in which the system

was divided into the respective modules and their

interfaces. This was followed by the detailed design,

implementation and integration and system testing

phases. After the system testing showed the quality

of the software to be acceptable, the product went

onto the piloting and customer approval phases.

A process-oriented approach was taken to

managing requirement evolution in the project. A

requirement specification document was formulated,

and the requirements were ‘frozen’ in this document

upon completion of the requirement elicitation and

analysis phases. After requirement freezing,

requirements were managed through a strict

requirement changing procedure. This requirement

changing procedure was intended to be specified in

each development project, but the spirit of the

changing procedure was such that every single

change to the requirements had to be analyzed and

handled by the project steering group.

Unfortunately, in most of the projects this did not

work, as was the case in this E-commerce project.

This project, involved an entire subsystem,

Subsystem B, for which only four requirements were

specified in the requirement specification document.

Nevertheless, at the end of the development project,

Subsystem B was 60 % of the size of the whole

software application in terms of code size and the

required development effort. The new requirements

ICEIS 2004 - INFORMATION SYSTEMS ANALYSIS AND SPECIFICATION

670

for Subsystem B emerged iteratively during the

systems development through more than twenty

prototypes made for Subsystem B (Ovaska, 2003).

3.2 Requirements Creep

We used the notion of requirements creep (Ryan et.

al, 2001; Wiegers, 1999) and the conceptual

modelling technique widely used in the database

(Chen, 1976) and object-oriented approaches

(Rumbaugh, 1990; Jacobson, 1992; Booch, 1993) to

measure requirement evolution. In database

modelling, conceptual modelling is called entity-

relationships modelling and in the object-oriented

approach it is known as object modelling. This

conceptual modelling approach is a natural approach

for object-oriented systems as it is an essential part

of the object-oriented methodology.

We used two conceptual models of the system:

an analysis model that described the domain

concepts after requirement specification and an

implementation model that described domain

concepts after the implementation of the actual

system. Based on these models, the number of

different concepts between these models was

calculated (requirements creep) (Table 1).

The analysis model was extracted from the

project documentation and the implementation

model was re-engineered from the source code after

the completion of the project.

Table 1: The concepts found in the analysis and implementation models

Module Analysis model Implementation model

(Subsys-tem

Alarm, Logging,

Localisaction, Billing,

Message, User, Service

Alarm, Logging, Localisaction,

Billing, Message, User, Service

M2 (Subsys-

tem A)

Messaging, Counting,

Timing, Message, User

Messaging, Counting, Timing,

Message, User, Simulation

M3 (Subsys-

tem A)

Service control,

Localization, Message,

User, Service

Service control, Localization,

Message, User, Service,

Simulation

(Subsys-tem

UI, Message, User,

Service

UI, Message, User, Service

(Subsys-tem

Service, Simulation Service, Simulation,

Messaging, Authentication,

Localization, UI, Message,

User

3.3 Prediction Model

The aim of this prediction model is to analyze the

significance of the requirements creep (the

correlation between the requirements creep and

working hours) and demonstrate the use of the

requirements creep.

We used a simple linear prediction model for the

analysis, for which we required four other

measurements (system properties) to characterize

our system. We chose a widely used coupling (Xia,

1996), size (in LOC) (Henderson-Sellers, 1996),

cohesion (Henderson-Sellers, 1996) and

complexity/communication (Chidamber and

Kemerer, 1994). The values of these system

properties are shown in Table 2.

Table 2: The system properties for the case study

odule

Working hours 107 300 304 378 1767

1011 2176 1970 2843 12986

Complexity/

communication

88 91 160 99 607

Coupling 12 20 37 18 54

Cohesion 78 85 93 84 100

equirements creep 0 1 1 0 6

MEASURING REQUIREMENT EVOLUTION - A CASE STUDY IN THE E-COMMERCE DOMAIN

671

The model is based on the simple notion that the

development effort for a system can be expressed as

a linear function of the properties of each module

and coefficient values:

(

)

pnpnn

pnnnn

mamama

mmmC

,2,21,1

,2,1,

...

,...,,

+++

(1)

In the formula, m

n,q

corresponds to the value of

property q in module n and a

is the linear

coefficient that corresponds this property.

To analyze the correlation between the system

properties and development effort, the problem

turned out to be a function optimization problem,

more precisely a non-negative least-square problem

(Lawson and Hanson, 1995). The unknown factors

of this model were the values of the coefficients. We

used the MATLAB® Optimization Toolbox

function lsqnonneg.m (Matlab, 2003) to solve the

coefficient values.

3.4 Findings

Table 3 shows the values of the coefficients that

were of some significance (value>0) in the model.

The information in the table illustrates that

requirements creep was the most significant

measurement for the system (with the value 19).

Coupling and Lines of Codes (LOC) also had some

significance but much less than did requirements

creep (with values 0.9 and 0.1).

Table 3: The values of the coefficients of the software

assesment mode

The significance of LOC and coupling as cost

factors are line with the literature (Briand, Daly and

Wüst, 1999; Lionel et, al, 1998). Requirements creep

has such a strong impact on the development effort

that the other measurements are negligible.

4 DISCUSSION, CONCLUSIONS

AND FUTURE WORK

This study focused on using the concept of

requirements creep in measuring and introducing

requirement evolution in a case study in the E-

commerce domain. Requirements creep measures

new emerging requirements which do not exist at the

beginning of the development process but, rather,

emerge through interactions between the participants

in the development of the system.

The findings of this study suggest that

requirement evolution can be measured in a practical

software project and indicate the strong influence of

requirements creep on the systems development

effort.

It is not possible to generalize the results on the

basis of one case study. More studies must be

performed in other organizations and development

environments in order to obtain more evidence on

the applicability of our approach.

The main problem with measuring requirements

creep was that the concepts in the application

domain were slightly abstract and were not

necessarily at the same level. Measuring these

abstract concepts required a basic understanding of

the concepts in the application (application

knowledge) and definitions of these concepts during

the project.

In the analysis, we used a linear prediction

model that is too simple for real prediction purposes.

In our prediction model, we assumed that the system

development effort was a sum of the efforts of the

modules. It is well known that small changes in the

system size can have big effects on the development

effort. There are prediction methods and models,

such as case-based reasoning (Pedrycz, Peters and

Ramanna, 1999) and neural networks

(Venkatachalam, 1993), which take this non-linear

nature of systems development into account.

The results of this study have encouraged us to

analyse other industrial projects in order to collect

more evidence on the usefulness of measuring

requirements creep in other projects and domains.

We will develop our linear prediction model towards

a more non-linear approach in order for it to be

scalable for real-life prediction purposes.

LOC Coupling Requirements creep

0.1234 0.9164 19.2901

REFERENCES

Andersson, S., M. Felici, 2001. Requirements Evolution:

From Process to Product Oriented Management. In

3rd International Conference on Product Focused

Software Profess Improvement, Springer-Verlag.

Andersson, S. M. Felici, 2002. Quantitative Aspects of

Requirement Evolution. In 26th Annual International

Conference on Computer Software and Applications

Conference, Oxford, England, IEEE Computer

Society.

Booch, G., 1993. Object-Oriented Analysis and Design

with Applications, Addison Wesley Pub Co, 2 nd

editions.

ICEIS 2004 - INFORMATION SYSTEMS ANALYSIS AND SPECIFICATION

672

Briand, L.,C., J. W. Daly, J. K. Wüst, 1999. A Unified

Framework for Coupling Measurement in Object-

Oriented Systems. In IEEE Transactions on Software

Engineering, 25(1).

Chen, P., P., 1976. The entity-relationship model: toward a

unified view of data. In ACM Transactions on

Database Systems.

Chidamber, S.,R. and Chris F. Kemerer, 1994. A Metric

Suite for Object Oriented Design. In IEEE

Transactions on Software Engineering, Vol. 20, No. 6.

Cockburn, A., 2001. Agile Software Development.

Addison-Wesley.

Curtis, B., H. Krasner, and N. Iscoe, 1988. A Field Study

of the Software Design Process for Large Systems. In

Communications of the ACM 31.

Davidson, E.J., 2002. Technology Frames and Framing: A

Socio-Cognitive Investigation of Requirement

Determination. In MIS Quarterly, Vol. 26, Issue 4.

Harker, S., K.Eason, and J. Dobson, 1993. The change and

evolution of requirements as a challenge to the

practice of software engineering. In IEEE International

Symposium on Requirements Engineering, pages 266–

272, IEEE Computer Society Press.

Henderson-Sellers, B.,1996. Object-Oriented Metrics:

Measures of complexity, Prentice Hall, New Jersey.

IEEE Std 982.1, 1988. IEEE Standard Dictionary of

Measures to Produce Reliable Software.

IEEE Std 982.2 , 1988. IEEE Guide for the Use of IEEE

Standard Dictionary of Measures to Produce Reliable

Software.

Jacobson, I., 1992. Object-Oriented Software

Engineering. Addison Wesley Pub Co, 1 st edition.

Jarke, C. Rolland, A. Sutcliffe, R. Dömges, 1999. The

nature of Requirements Engineering. Aachen: Shaker

Verlag GmbH.

Kotonya, G., I.Sommerville, 1998. Requirement

Engineering, John Wiley & Sons, NY.

Lawson, C.L., R. J. Hanson, 1995. Solving Least Squares

Problems. Society for Industrial & Applied

Mathematics.

Lehman, M.,1998. Software’s future: Managing evolution,

In IEEE Software, Jan-Feb, pages 40–44.

Lehman, M., D. Perry, and J. Ramil, 1998. On evidence

supporting the feast hypothesis and the laws of

software evolution. In Metrics ‘98, Bethesda,

Maryland.

MATLAB® the Language of Technical Computing, 2003.

The MathWorks, Inc., [URL:

http://www.mathworks.com/, Referred 20 Sep 2003].

Ovaska, P., 2003. On the Organizational Factors in

Understanding of Information System Requirements.

In Scandinavian Conference on Information Systems

(IRIS26), Finland August 9-12.

Pedrycz, W., J.F. Peters, S. Ramanna, 1999. A Fuzzy Set

Approach to Cost Estimation of Software Project.

(Editor: Meng, M.), In IEEE Canadian Conference on

Electrical and Computer Engineering.

Rumbaugh, J., 1990. Object-Oriented Modeling and

Design. Prentice Hall.

Ryan A. R. Carter, I. Annie, I. Antón, A. Dagnino, L.

Williams, 2001. Evolving Beyond Requirement Creep:

A Risk-Based Evolutionary Prototyping.In IEEE 5th

International Symposium on Requirements

Engineering.

Tomayko, J.E, 2002.Engineering an unstable requirements

using agile methods. In International Workshop on

Time Constraint Requirement Engineering.

van Lamsweerde, A., 2000. Requirements engineering in

the year 00: A research perspective. In International

Conference on Software Engineering (ICSE’2000),

pages 5–19, Limerick, Ireland.

Venkatachalam, A., R., 1993. Software Cost Estimation

Using Artificial Neural Networks. In International

Joint Conference on Neural Networks, October 25-29,

Volume 1, Pages: 987 – 990.

Wiegers, K.E., 1999. Software Requirements, Microsoft

Press.

Xia, F.,1996. Module Coupling: A Design Metric.In Asia-

Pacific Conference on Software Engineering. Seoul,

South Korea, 4-7 Dec. Pages: 44 – 54.

MEASURING REQUIREMENT EVOLUTION - A CASE STUDY IN THE E-COMMERCE DOMAIN

673
