E-BUSINESS SECURITY DESIGN USING PROCESS SECURITY

REQUIREMENTS SEPTET

S. Nachtigal

Royal Holloway, University of London, Egham, Surrey TW20 0EX, UK

Keywords:

e-Business, perimeter security, business process–based security, information security requirements.

Abstract:

In the e-business environment, the traditional business models for information systems security are no longer

appropriate, and ﬁt neither the new organisational environment nor the new organisational security needs.

Existing security tools and mechanisms, developed upon the traditional perimeter security paradigm, and

based on hardware and software products, are not sufﬁcient since they do not relate to speciﬁc parameters that

characterise the business process. The modern business environment needs different security approach. Based

on such a new approach, which is e-process security design paradigm, a methodology to provide security for

an e-business organisation is presented here. The methodology makes use of the newly introduced security

requirements septet for e-business process.

1 INTRODUCTION

The business environment has adopted the IT (In-

formation Technology) advances since the very early

stages of computer developments. The advanced IT

solutions are widely used in business environment

both as an infrastructure, supporting the organisa-

tion’s business and operational activities, and as a

means of protecting the organiational assets, espe-

cially the information assets.

Although these technological changes have also

changed the business mode and the organisational

structures as well, the organisational information sys-

tems security approach in e-business organisations

has not changed since the 1980s, with the introduc-

tion of the communication networks into and be-

tween the organisations operations. Different types

of organisations require different access mode to their

information—the academic environment, for exam-

ple, needs a freely–accessed information environ-

ment, while the military environment is an example

of quite an opposite, access–blocked information.

This access–blocked solution has been achieved

by providing a hard-to-penetrate perimeter, which is

still in practice today (Bragg et al., 2004). Perime-

ter, which is a collection of tools, mechanisms and

techniques, is built to protect the organisational inter-

nal resources from the external access. The security

perimeter is applicable on the organisation’s bound-

aries, so it can protect the organiation from the exter-

nal world threats.

Tools and mechanisms (such as ﬁrewalls, IDSs

and IPSs), which are used in perimeter approach net-

work security, are designed to block all malicious

contents from entering into the organisational perime-

ter, but practically these safeguards do allow many

types of trafﬁc to pass and actually provide a false

sense of security (Andreu, 2006), (Bragg et al., 2004).

Also, the users themselves face problems while

using those technology–based solutions in a proper

way. Furnell (Furnell, 2005) argues that the

technology–based solutions are often used badly.

These include bad practice with passwords, poorly

maintained anti-virus protection, hardware/software–

based or applications-embedded security solutions, ir-

responsible users, lack of awareness and security mis-

understanding (Furnell, 2005).

In e-business mode of doing business all the pro-

cesses are considered to be e-processes, namely:

• performed electronically by means of information

technologies only/mainly;

408

Nachtigal S. (2007).

E-BUSINESS SECURITY DESIGN USING PROCESS SECURITY REQUIREMENTS SEPTET.

In Proceedings of the Second International Conference on Security and Cryptography, pages 408-413

DOI: 10.5220/0002128304080413

 SciTePress

• across the whole organisational environment;

• inside and outside organisation’s boundaries.

E-business organisation performs its business activ-

ities by means of e-processes, based on Internet in-

frastructure and technologies.

The uniqueness in running an e-business is in its

‘openness’ to the environment, which is achieved by

means of the various connections and communica-

tion channels with the external world. Although this

‘openness’ makes the e-business mode of doing busi-

ness much more dangerous than the traditional way,

it is essential. The whole business is dependent on

proper business processes execution, which are per-

formed mostly by technological means, with end-user

(customers, company’s employees, company’s sup-

pliers’ employees, etc.) involvement. Therefore, the

security issue becomes one of the most (if not the

most) important issues for e-business organisation.

The e-business security perception changes from

‘blocking’ and ‘preventing’ in the traditional busi-

ness to ‘opening’ and ‘enabling’ the modern e-

process. The e-business process–based security

paradigm (Nachtigal and Mitchell, 2006) provides a

possibility to secure the modern e-business organisa-

tions.

This paper presents a newly introduced set (septet)

of e-business security requirements, as a part of a

newly suggested process-based security paradigm,

which is an alternative for perimeter security ap-

proach. Also, the way of this security requirements

septet implementation is demonstrated in this paper.

The remainder of this paper is structured as fol-

lows: after the principles of the process-based secu-

rity paradigm are presented in the next section, the

seven e-business security criteria are described and

discussed in section three, followed by the descrip-

tion of their implementation in section four, related

works discussion (section ﬁve) and conclusions.

2 THE PRINCIPLES OF

E-BUSINESS PROCESS

SECURITY PARADIGM

The basis for that approach is the assumption that

for e-business to exist its processes must be secured.

Hence, the security safeguards design will be dif-

ferentiated between business processes according

to their speciﬁc characteristics. The process–based

security approach (Nachtigal and Mitchell, 2006)

includes the following key elements:

• the security is designed and provided for each sin-

gle e-process;

• e-process design is considered to be a result of two

different aspects elements:

– business logic deﬁnition;

– information ﬂows transportation and exchange

• the two aspects elements are analysed and security

mechanisms and tools are designed according to

their security requirements criteria.

2.1 e-Business Security Criteria

The three commonly accepted (Gollman, 2003),

(Harris, 2003), (Tettero, 2000), (Moffett et al., 2004)

generic security criteria, or security objectives, are:

• conﬁdentiality;

• integrity;

• availability.

These three security requirements, according to

Tettero (Tettero, 2000) and Harris (Harris, 2003),

come to ensure the following:

• conﬁdentiality—to obtain secrecy and to prevent

unauthorized disclosure of information and data

to unauthorised person;

• integrity is achieved when data and information

are correct and appropriate as meant by the pro-

cess designer (and can not be modiﬁed by unau-

thorised person), and accuracy and reliability of

information and systems are in place;

• availability comes to say that data, information

and other elements of information systems are

accessible and useable upon the demand of

authorised user.

Following the process–based security approach in

the e-business environment, these three security ob-

jectives are not sufﬁcient. The modern business en-

vironment is mostly characterised by its connectivity,

which was not the case for the traditional type organ-

isations. The security requirements triad described

above ﬁts the traditional business environment. In or-

der to provide the required security for an e-business

organisation, additional security requirements have to

be in place. According to this research perception, the

e-business security is associated with its e-process se-

curity. Hence, these additional security requirements

have to be considered and provided for e-processes,

namely—additional security requirements are needed

to ensure that business logic and information ﬂows

E-BUSINESS SECURITY DESIGN USING PROCESS SECURITY REQUIREMENTS SEPTET

409

will be secure. That conclusion, which is one of this

research statements, is based on a detailed analysis of

the e-business organisation nature and operations, and

its e-processes analysis and characteristics.

Based on that analysis, the following set of seven

security requirements is suggested to provide security

for the e-business information systems:

1. in order to ensure privacy and non-disclosure of

the contents (both of the companies and the cus-

tomers) the conﬁdentiality (C) objective has to be

achieved;

2. in order to ensure that data, information and

actions (performed by information technology,

namely—software) will not be modiﬁed by unau-

thorised users and/or means and/or technology,

the integrity (I) objective has to be achieved;

3. on order to ensure that the whole system (with all

relevant elements of technology managed accord-

ing to speciﬁc strategy and policy) will be accessi-

ble and capable to execute the process, the avail-

ability (A) objective has to be achieved;

4. a new security objective for business logic secu-

rity is suggested here—robustness (R)— for cor-

rect performing of the business logic;

5. an additional new security objective for business

logic security is suggested here—resistivity (R)—

to ensure that the business logic is checked against

possible logic-based abuse and it is designed in

such a way that it will resist the various possi-

ble abuse attempts that have a possibility to cause

harm to the e-business information systems;

6. a new security objective of compliance (C) is sug-

gested here to ensure that an e-process is able to

interact with other companies’ e-processes; the

security objective of compliance is needed also to

ensure that the process security design is compli-

ant with security regulations, standards and laws;

7. in order to make possible to manage the e-

business process security, to track actions, to keep

metrics for security planning and design an objec-

tive of accountability (A) is needed.

To conclude, the e-business process security objec-

tives suggested by this research are:

1. Conﬁdentiality (C);

2. Integrity (I);

3. Availability (A);

4. Robustness (R);

5. Resistivity (R);

6. Compliancy (C);

7. Accountability (A).

That seven security objectives set (septet)—

CIARRCA or I(RCA)

— makes possible to meet the

e-business process security requirements covering all

the relevant aspects, as described above.

In order to ensure that the security objectives septet

I(RCA)

will be indeed achieved, the development

and design of any e-process should be performed in

a systematic way—methodology—where all the rele-

vant security requirements issues will be considered,

following process-based approach and focusing on

security objectives.

3 SECURITY OBJECTIVES

ANALYSIS

The security requirements analysis is actually the

practical realisation of the business process–based

paradigm. This analysis needs to be performed sep-

arately for the business logic and for the information

ﬂows of the process.

3.1 Business Logic Security Objectives

Analysis

Here we have to check the business logic in regard

with the business logic security objectives, which are

Robustness, Resistivity and Compliance. These ob-

jectives come to ensure that the e-business logic is

correctly deﬁned in such a way that it is workable,

compliant with all the relevant standards and laws,

and does not make possible for users and processes—

both authorised and unauthorised—to abuse the logic

and to compromise the process and/or its outcomes

in any way. Here the business rules are analysed

in respect with the e-process interactions and inter-

faces with other processes, contacts between the par-

ticipants’ elements (users, customers, databases), ac-

cess rules and policies, possible conﬂicts, previously

reported business logic ﬂaws. Also, the compliance

with security standards and ability to comply with

other companies’ e-processes rules and policies are

analysed.

The business logic security (BizLogic security)

should be established, based on the security objec-

tives RRC analyses. Practically, that will start with

the threat-source modeling for each one of the Biz-

Logic security objectives (RRC) for each one of the

processes. The results of this threat-source analysis

(which can be presented as shown in table 1 for each

of the RRC objectives)) pave the way for the next

analysis steps.

SECRYPT 2007 - International Conference on Security and Cryptography

410

The ﬁnal purpose of the BizLogic analyses is to

establish a set of security means for the organisation’s

business logic by achieving the RRC (Robustness,

Resistivity, Compliance) business security objectives.

These will be based on ﬁndings of the threat-source

analysis and summarised separately for each objec-

tive, as presented by Table 2, for example.

Table 1: Process 1: Robustness/Resistivity/Compliance

analysis.

Threat analysis Threat-source

Possible attacks 1 .. N

Potential damage

Security design

Table 2: Process 1:

Business logic security—Robustness/Resistivity/Compliance

criteria summary.

Security measures Robustness (R)

Standards list of security mechanisms

Legal issues ”

Policies ”

Procedures ”

Unique requirements ”

As a result of these steps, performed for each sin-

gle e-process separately, the security tools and mech-

anisms of e-business logic will be established. On a

conceptual level, this set could be presented by Table

3 below.

Table 3: Single process Business Logic security means.

Security objectives Processes

Robustness 1 .. N

Resistivity

Compliance

Accountability

3.2 Information Flow Security Analysis

The process is decomposed into information ﬂows,

and the security analysis is performed separately for

each of these information ﬂows in regard with the rel-

evant security requirements.

Information Flows, as being an element of an e-

process, are presented by the following characteris-

tics:

• content—structured (speciﬁc sequence of data

ﬁelds) or unstructured (natural language);

• participants’ elements—classiﬁed as

– active—companies’ employees, private cus-

tomers;

– passive—databases, services providers (sys-

tems administrator, network manager, pro-

grammers, ISP’s employees);

• origin—one of the participants, either active or

passive;

• destination—one of the participants, either active

or passive;

• execution means—technology (software, hard-

ware, communication).

Actually, there is an interaction between partici-

pants, origin and destination: the ‘participant’ fea-

ture includes both the ‘origin’ and the ‘destination’

features—‘origin’/‘destination’ is usually a customer,

or employee, or another process. In case of another

process, the interaction between a speciﬁc informa-

tion ﬂow of the e-process under discussion and be-

tween another process (practically meaning an infor-

mation ﬂow of another process) is realised through a

database, which is, again, one of the participants in

this model. Hence, the information ﬂows features are

the following:

• content;

• participants;

• execution means.

According to this research approach, all these in-

formation ﬂow characteristics need to be identiﬁed

and discussed in regard with Information Flows se-

curity objectives—the CIA (Conﬁdentiality, Integrity,

Availability) objectives. Each of these security ob-

jectives should be ranked according to degree of its

criticality related to a speciﬁc Information Flow. The

ranks will be presented by Table 4 below.

Table 4: CIA Criticality Rank.

Item Conﬁdentiality

(C)

Integrity

(I)

Availability

(A)

Total score

InfoFlow 1 r1 r2 r3 sum of row

ranks

InfoFlow 2 r4 r5 r5 sum of row

ranks

...

InfoFlow n

Total security

objective rank

These ranks will be related to and expressed

in terms of threat modeling (such as suggested by

Swidersky and Snyder (Swiderski and Snyder, 2004))

and risk analysis. The results for each information

ﬂow will be presented by Table 5.

E-BUSINESS SECURITY DESIGN USING PROCESS SECURITY REQUIREMENTS SEPTET

411

Table 5: Information Flow security analysis.

Item Description Threat

modeling

Risk

analysis

Content data

ﬁelds/text

Employee

Customer

Database

Sys Admin

Net Man

Programmer

ISP

Practically, the threat modeling and analysis need

to be performed for each and every information ﬂow

separately.

Based on these analysis tables the following secu-

rity applications might be developed:

• security patterns for speciﬁc types of information

ﬂow in a speciﬁc given environment;

• access/performance rights rule as a function of a

speciﬁc information ﬂow, security threats, secu-

rity risks.

Again, the purpose of the analysis, presented

by Table 5, is to produce sufﬁcient information for

analysing the information ﬂows security objectives in

terms of CIAA. Hence, an additional table (Table 6,

see page 6) is suggested as a tool for analysing infor-

mation ﬂows security objectives.

3.3 The Septet Methodology

Application in a Case Study

The suggested e-business security requirements septet

has been tested by applying it in a real life situation.

For that purpose a big airline company was chosen

as one of this research case studies. The case study

company operates an e-business activity for purchas-

ing ﬂight tickets and vacations by their customers.

The septet has been applied as an alternative

method to design the company’s e-business informa-

tion systems security. The application analysis (which

is still in progress) includes also a comparative study

of the practicality and efﬁciency between the sug-

gested methodology and the traditional ways of in-

formation systems security design.

4 RELATED WORK

Not many research works on business security issues,

related to security requirements, are published, and

just few of them are related to e-business process

Table 6: Information Flow security analysis.

Item Conﬁdentiality

(C)

Integrity

(I)

Availability

(A)

Accountability

(A)

Content security

mechanisms

security

mecha-

nisms

security

mecha-

nisms

security

mechanisms

Employee

Customer

Database

Sys Admin

Net Man

Programmer

ISP

speciﬁcally. However, there is a range of suggested

approaches.

Herrmann and Pernul (Herrmann and Pernul,

1999) suggest a framework that supports business-

process re-engineering in order to improve security

and integrity. A three layered architecture is sug-

gested for business process speciﬁcation, while ‘se-

curity’ and ‘integrity’ are considered as two separated

requirements.

Jones et al. (Jones et al., 2000) consider e-business

important requirements in terms of trust and depend-

ability as related to business partners.

Bodin et al. (Bodin et al., 2005) suggest a method

for the optimal allocation of a budget for maintaining

and enhancing the security of an organizations infor-

mation system by using the ratings of the Conﬁden-

tiality, Data integrity and Availability criteria, while

the availability criterion is broken down into three

subcriteria: Authentication (of the right users), Non-

repudiation (a user cannot deny using the system, if

in fact he or she did actually use it), and Accessibility

or non-denial of service.

TROPOS methodology, which is a speciﬁcation

language for modelling early requirements for soft-

ware developers (Giorgini et al., 2005), (Susi et al.,

2005), is suggested also to be used for security re-

quirements models design (Massaccia et al., 2005),

(Susi et al., 2005). This methodology may be use-

ful in the advanced phases of security design and de-

velopment, namely the phase of applications/software

development for business tasks.

5 CONCLUSION

The newly suggested septet of e-business process

security requirements I(RCA)

(Conﬁdentiality, In-

tegrity, Availability, Robustness, Resistivity, Compli-

ance, Accountability) provides a practical way of de-

signing the e-business security safeguards in terms

of policies, standards, mechanisms and tools. Us-

ing this requirements septet on a single process ba-

sis, makes possible to provide the differentiated and

SECRYPT 2007 - International Conference on Security and Cryptography

412

realistic security design for separated functional do-

mains, while taking in account the real functional and

business needs.

REFERENCES

Andreu, A. (2006). Professional Pen testing for web appli-

cations. Wiley Publishing, Inc.

Bodin, L., Gordon, L., and Loeb, M. (2005). Evaluating in-

formation security investments using the analytic hier-

archy process. Communications of the ACM archive,

48:78 – 83.

Bragg, R., Phodes-Ousley, M., and Strassberg, K.

(2004). Network Security: The Complete Reference.

McGraw-Hill/Osborne.

Furnell, S. (2005)). Why users cannot use security. Com-

puters & Security, 24:274–279.

Giorgini, P., Mylopoulos, J., and Sebastiani, R. (2005).

Goal-oriented requirements analysis and reasoning in

the tropos methodology. Engineering Applications of

Artiﬁcial Intelligence, 18:159–171.

Gollman, D. (2003). Computer Security. John Wiley &

Sons.

Harris, S. (2003). CISSP All-In-One Exam Guide. McGraw-

Hill/Osborne Media, second edition.

Herrmann, G. and Pernul, G. (1999)). Viewing business-

process security from different perspectives. Interna-

tional Journal of Electronic Commerce, 3(3):89–103.

Jones, S., Wilikens, M., Morris, P., and Nasera, M. (2000)).

Trust requirements in e-business. COMMUNICA-

TIONS OF THE ACM, 43(12):81–87.

Massaccia, F., Prestb, M., and Zannone, N. (2005). Us-

ing a security requirements engineering methodology

in practice: The compliance with the italian data pro-

tection legislation. Computer Standards & Interfaces,

27:445–455.

Moffett, J. D., Halley, C. B., and Nuseibeh, B. (2004).

Core security rewuirements artefacts. ISSN 1744-

1986 2004/23, Departmenet of Computing, Faculty of

Mathematics and Computing, The Open University,

Walton Hall, Milton Keynes, MK7 6AA, UK.

Nachtigal, S. and Mitchell, C. (2006). Modelling e-business

security using business processes. In ICETE 2006

- International Joint Conference on E-Business and

Telecommunications, SECRYPT. INSTICC.

Susi, A., Perini, A., and Mylopoulos, J. (2005). The tropos

metamodel and its use. Informatica, 29:401–408.

Swiderski, F. and Snyder, W. (2004). Threat Modeling. Mi-

crosoft Press.

Tettero, O. (2000). Intrinsic Information Security. Embed-

ding Security Issues in the Design Process of Telem-

aticd Systems. Telematica Instituut Fundamental Re-

search Series, No. 006(TI/FRS/006).

E-BUSINESS SECURITY DESIGN USING PROCESS SECURITY REQUIREMENTS SEPTET

413
