Safety and Security in Networked Robotic Systems

Via Logical Consensus

Simone Martini

, Adriano Fagiolini

, Antonio Bicchi

and Gianluca Dini

Interdepartmental Research Center “E. Piaggio”, Faculty of Engineering

University of Pisa, Italy

Dipartimento dell’Informazione, Faculty of Engineering, University of Pisa, Italy

Abstract. The problem of allowing a set of autonomous mobile robots to plan

their motion by reaching consensus on logical observations of the environment

is studied in this paper. The particularity of the work is that the information on

which the consensus is sought is not represented by real numbers, but rather by

logical values such as the presence of an obstacle, of another robot, or of a person.

Previous work by the authors considered the problem of allowing a set of agents

to consent on the value of a logical vector function by communicating over a

network. In this paper, we present application of this result to the motion planning

decision problem and show its effectiveness through simulation.

1 Introduction

In the last decades, robotics has undergone a gradual yet constant migration of research

interests from monolithic systems with a unique robot to distributed multi–agents com-

posed of several semi–autonomous robots. Various motivations give reason for this

trend, among which is the possibility to achieve this desirable properties, such as scala-

bility, reconﬁgurability, robustness, etc. Recent years have indeed witnessed important

developmentsin the deﬁnition of decentralized and cooperativecontrol strategies for ap-

plications, such as intelligent transportation, surveillance, ﬂocking, formation control,

sensor coverage, patrolling, etc., all involving teams of robotic agents (see e.g. [1, 2]).

Most of these solutions require that agents consent on the value of a common quan-

tity of interest. This is achieved by means of consensus algorithms that are dynamical

systems, where every agent has a state that is updated through local measurement and

data received from its neighbors in a communication network [3–5]. A typical form of

consensus is described by the continuous–time linear system

˙x(t) = A x(t) + B u(t) , (1)

where A ∈ R

n×n

is a strongly connected doubly–stochastic matrix, B ∈ R

n×m

is the

input matrix, and u ∈ R

is a control law. The ﬂourishing literature on this topic have

studied continuous– and discrete–time, synchronous and asynchronous, and quantized

versions of such systems and has provided useful results on properties such as charac-

terization of equilibria, and convergence rate [6,7].

Proceedings of ICINCO 2009

6th International Conference on Informatics in Control, Automation and Robotics

Furthermore, the actual achievement of the system goal is theoretically guaranteed

only under the hypothesis that all agents harmoniously act and cooperate, whereas if

some of them do not follow speciﬁcation the whole system is at risk [8]. This motivates

the emerging interest toward techniques that make more robust existing multi–agent

systems by detecting the presence of intruders in various different settings (see [9]).

The EU, in the current Seventh Framework Programme, has suggested Security and

Safety in Automation and Robotics as one of the main aspects over which research

communities should place their efforts. Research on this ﬁeld focused on detection of

faults and anomalies in networked control systems, but the main theory and tools de-

veloped in the project are strongly based on the existence of one or more centralized

supervisors [10]. The challenge in these systems is to ﬁnd strategies to detect and isolate

possible intruders, without the use of any form of centralization. This requires under-

standing what level of intelligence must be embedded in the automation component to

provide satisfactory guarantees of performance, while remaining economically viable.

Another important fact that must be taken under consideration is that control and

automation systems are implemented on embedded devices, having resource and real–

time constraints that are much more severe than customary desktop and enterprise com-

puting [11]. Therefore, these constraints must be taken into account when designing and

building security solutions for any of such networked embedded system. In the Sixth

Framework Programme of the EU, the project RUNES pioneered some solutions guar-

anteeing security for resource constrained networked embedded systems [12,13].

In this context, we focus on the problem of coordinated motion for a set of mobile

semi–autonomous robots. The problem is studied also within the current EU project

CHAT [14] and the Network of Excellence CONET [15]. We propose a solution that

requires limited communication and computation complexities. The solution is based

on so–called logical consensus systems, that are algorithms allowing a set of agents to

consent on a number of decisions depending on logical inputs of the environment. The

proposed solution allows the agents to plan their motion by reaching consensus on logi-

cal values based on local observation of the environment. This endows every agent with

the capability to react to unexpected changes in the environment, such as the presence

of an obstacle or of an intruder. Indeed, during the execution of their plans, features

of the environment that were unknown at planning time, or that unexpectedly change,

can trigger changes in what the agents should do. Under suitable joint conditions on the

visibility of agents and their communication capability, we provide an algorithm gener-

ating logical linear consensus systems that are globally stable that allow each agent to

update its path according to the actual conﬁguration of the environment.

2 Problem Statement

We consider application scenarios requiring computation of a set of p decisions, y

, . . . ,

, that depend on m logical events, u

, . . . , u

. Such events may represent e.g. the

presence of an intruder or of a ﬁre within an indoor environment. More precisely, for

any given combination of input events, we consider a decision task that requires com-

putation of the following system of logical functions:







= f

, . . . , u

) ,

· · ·

= f

, . . . , u

) ,

(2)

where each f

: B

→ B consists of a logical condition on the inputs. Let us denote

with u = (u

, . . . , u

)

∈ B

the input event vector, and with y = (y

, . . . , y

)

∈

the output decision vector. Then, we will write y = f (u) as a compact form of Eq.

2, where f = (f

, . . . , f

)

, with f : B

→ B

, is a logical vector function. It is worth

noting that computation of f is centralized in the sense that it may require knowledge

of the entire input vector u to determine the output vector y.

Our approach to solve the decision task consists of employing a collection of n

agents, A

, . . . , A

, that are supposed to cooperate and possibly exchange locally avail-

able information. We assume that each agent is described by a triple A

= (S

, P

, C

where S

is a collection of sensors, P

is a processor that is able to perform elementary

logical operations such as {and, or, not}, and C

is a collection of communication de-

vices allowing transmission of only sequences of binary digits, 0 and 1, namely strings

of bits. Although we assume that every agent has the same processing capability, i.e.

= P for all i, we consider situations where agents may be heterogeneous in terms of

sensors and communication devices. Due to this diversity as well as the fact that agents

are placed at different locations, a generic agent i may or may not be able to measure

a given input event u

, for j ∈ 1, . . . , m. Therefore, we can conveniently introduce a

visibility matrix V ∈ B

n×m

such that we have V (i, j) = 1 if, and only if, agent A

able to measure input event u

, or, in other words, if the i–th agent is directly reachable

from the j–th input. Moreover, for similar reasons of diversity and for reducing battery

consumption,each agent is able to communicate only with a subset of other agents. This

fact is captured by introducing a communication matrix C ∈ B

n×n

, where C(i, k) = 1

if, and only if, agent A

is able to receive a data from agent A

. Hence, agents speciﬁed

by row C(i , :) will be referred to as C–neighbors of the i–th agent. The introduction of

visibility relations between inputs and agents immediately implies that, at any instant t,

only a subset of agents is able to measure the state of each input u

, for all j. Therefore,

to effectively accomplish the given decision task, we need that such an information

ﬂows from one agent to another, consistently with available communication paths. We

require all agents reach an agreement on the centralized decision y = f(u), so that any

agent can be polled and provide consistent complete information. In this perspective,

we pose the problem of reaching a consensus on logical values.

In this view, we can imagine that each agent A

has a local state vector, X

i,1

, . . . , X

i,q

) ∈ B

, that is a string of bits.

Then, let us denote with X(t) = (X

(t), . . . , X

(t))

∈ B

n×q

a matrix representing

the network state at a discrete time t. Hence, we assume that each agent A

is a dynamic

node that updates its local state X

through a distributed logical update function F that

depends on its state, on the state of its C–neighbors, and on the reachable inputs, i.e.

(t+1) = F

(X(t), u(t)). Moreover, we assume that each agent A

is able to produce

a logical output decision vector Y

= (y

i,1

, . . . , y

i,p

) ∈ B

througha suitable distributed

logical output function G depending on the local state X

and on the reachable inputs u,

i.e. Y

(t) = G

(t), u(t)). Let us denote with Y (t) = (Y

(t), . . . , Y

(t))

∈ B

p×q

a matrix representing the network output at a discrete time t. Therefore, the dynamic

evolution of the network can be modeled by the following distributed ﬁnite–state itera-

tive system:



X(t + 1) = F (X(t), u(t)) ,

Y (t) = G(X(t), u(t)) ,

(3)

where we have F = (F

, . . . , F

)

, with F

: B

× B

→ B

, and G = (G

, . . . , G

)

with G

: B

× B

→ B

In this perspective, we are interested in solving the following design problem:

Problem 1 (Globally Stable Synthesis). Given a decision system of the form of Eq. 2, a

visibility matrix V , and a communication matrix C, design a logical consensus system

of the form of Eq. 3, that is compliant with C and V , and such that, for all initial network

state X(0), and all inputs u, there exists a ﬁnite time

N such that the system reaches a

consensus on the centralized decision y

∗

= f(u), i.e. Y (t) = 1

∗

)

, for all t ≥

3 Distributed Map Synthesis for Logical Consensus

In this section a solution for Problem 1 is presented consisting of an algorithm that

generates an optimal distributed logical linear consensus system. More precisely, the

algorithm produces a (C, V )–compliant linear iteration map F minimizing the number

of messages to be exchanged, and the time needed to reach a consensus (a.k.a. rounds).

To achieve this we ﬁrst need to understand how the agent network can reach a

consensus on the value of the j–th subterm l

in the decision system of Eq. 2. Without

loss of generality, let us pose l

= u

and consider the j–th column V

of the visibility

matrix V that also describes the visibility of l

. Then, we need a procedure for ﬁnding to

which agents the value of input u

can be propagated. First note that vector V

contains

1 in all entries corresponding to agents that are able to “see” u

, or, in other words,

it speciﬁes which agents are directly reachable from u

. Then, it is useful to consider

vectors C

, for k = 0, 1, . . . , each containing 1 in all entries corresponding to agents

that are reachable from input u

after exactly k steps. The i–th element of C

is 1

if, and only if, there exists a path of length k from any agent directly reached by u

agent A

. Recall that, by deﬁnition of graph diameter, all agents that are reachable from

an initial set of agents are indeed reached in at most diam(G) steps, with diam(G) ≤

n − 1. Let us denote with κ the visibility diameter of the pair (C, V

) being the number

of steps after which the sequence {C

} does not reach new agents. Thus, given a pair

(C, V

), we can conveniently introduce the following reachability matrix R

, assigned

with input u



· · · C

n−1



, (4)

whose columns span a subgraph G

, E

) of G, where N

is a node set of all

agents that are eventually reachable from input u

, and E

is an unspeciﬁed edge set,

that will be considered during the design phase. Computing the span of R

is very

simple and efﬁcient, and indeed all reachable agents, that are nodes of N

, are speciﬁed

by non–null elements of the Boolean vector I

n−1

k=0

n−1

k=0

(:, i), that

is the logical sum of all columns in R

and that contains 1 for all agents for which there

exists at least one path originating from an agent that is able to measure u

. Then, we

can partition the agent network into N

= {i | I

(i) = 1}, and N

= N \ N

, where

N = {1, . . . , n}. In this perspective we can give the following:

Deﬁnition 1. A pair (C, V

) is (completely) reachable if, and only if, the corresponding

reachability matrix R

(C, V

) spans the entire graph, i.e. N

= N.

The design phase can obviously concern only the reachable subgraph G

, E

)

of G, and in particular will determine the edge set E

. Moreover, observe that a non–

empty unreachable subgraph G

in a consensus context is a symptom of the fact that

the design problem is not well–posed, and it would require changing sensors’ visibility

and locations in order to have a reachable (C, V

) pair.

Let us suppose that only agent A

is able to measure u

. Then, a straightforward

and yet optimal strategy to allow the information on u

ﬂowing through the network is

obtained if agent A

communicates its measurement to all its C–neighbors, which in

turn will communicate it to all their C–neighbors without overlapping, and so on. In

this way, we have that every agent A

receives u

from exactly one minimum–length

path originating from agent A

. The vector sequence {C

} can be exploited to this

aim. Indeed, it trivially holds that C

= C(C

k−1

), meaning that agents reached

after k steps have received the input value from agents that were reached after exactly

k − 1 steps. Then, any consecutive sequence of agents that is extracted from non–null

elements of vectors in {C

} are (C, V

)–compliant by construction. A consensus

strategy would minimize the number of rounds if, and only if, at the k–th step, all

agents speciﬁed by non–null elements of vector C

receives the value of u

from

the agents speciﬁed by non–null elements of vector C

k−1

. Nevertheless, to minimize

also the number of messages, only agents speciﬁed by non–null elements of vector

and that have not been reached yet must receive u

. If vector I

i=k

i=0

iteratively updated during the design phase, then the set of all agents that must receive

a message on u

are speciﬁed by non–null elements of vector C

∧ ¬I

. By doing

this, an optimal pair (C

∗

, V

∗

) allowing a consensus to be established over the reachable

subgraph is obtained.

Observe that is C

∗

= S C ≤ C, where S is a suitable selection matrix.

This procedure actually gives us only a suggestion on how to construct consensus

system that solves Problem 1. Indeed, we can prove in following Theorem 1 that a

simple logical linear consensus algorithm of the form

x(t + 1) = F

x(t) + B

(t) , (5)

where F

= C

∗

, B

= V

∗

, and x ∈ B

, allows a consensus to be reached through the

entire reachable subgraph. The state x must be interpreted as the network distributed

estimation of the value of the subterm l

or u

. It is indeed a vector and not a matrix,

since we are concerned here only with the j–th input.

In all cases where a unique generic agent A

is directly reachable from input u

, an

optimal communication matrix C

∗

for a linear consensus of the form of Eq. 5 can be

iteratively found as the incidence matrix of a input–propagating spanning tree having

as the root. Then, an optimal pair (C

∗

, V

∗

) can be written as C

∗

= P

(S C) P ,

and V

∗

= P

, where S is a selection matrix, and P is a permutation matrix. Fur-

thermore, C

∗

has the following lower–block triangular form:

∗







0 0 · · · 0 0

i,1

0 . . . 0 0

0 · · ·

i,κ

0 0

0 · · · 0 0 0







, (6)

and V

∗

= P

= (1, 0, . . . , 0)

. It is worth noting that the optimal pair (C

∗

, V

∗

)

preserves the reachability property of the original pair (C, V

). This can be shown by

direct computation of the reachability matrix R

∗

, but it is omitted for the sake of space.

We are now ready to consider the more general case with ν, 1 ≤ ν ≤ n agents

that are reachable from input u

, and let us denote with A = {i

, . . . , i

} the index set

of such agents. Then, the optimal strategy for propagating input u

consists of having

each of the other agents receive the input measurement through a path originating from

the nearest reachable agent in A. This naturally induces a network partition into ν dis-

joint subgraphs or spanning trees, each directly reached by the input through a different

agent. Let us extract ν independent vectors V

), . . . , V

) from vector V

having a

1 in position i

. Then, the sequences {C

)} are to be considered to compute the

optimal partition. Let us denote with κ

, for all i ∈ A the number k of steps for the

sequence {C

(i)} to become stationary. Therefore, we have that the visibility diam-

eter of the pair (C, V

) is vis-diam(C, V

) = max

{κ

}. Without loss of generality,

we can image that κ

≥ κ

≥ · · · ≥ κ

. Therefore, for the generic case, there exist a

permutation matrix P and a selection matrix S such that an optimal pair (C

∗

, V

∗

) can

be obtained as C

∗

= P

(S C) P , V

∗

= P

, where

∗

= diag(C

, . . . , C

) , V

∗

= (V

j,1

, . . . , V

j,ν

)

(7)

and where each C

and V

j,i

have the form of the Eq. 6. Finally, the actual optimal linear

consensus algorithm is obtained choosing F

= P C

∗

, and B

= P V

∗

Algorithm 1 allows computation of an optimal pair (C

∗

, V

∗

) as in Eq. 7. Its asymp-

totic computational complexity is in the very worst case O(n

), where n is the number

of agents, and its space complexity in terms of memory required for its execution is

Ω(n). However, its implementation can be very efﬁcient since it is based on Boolean

operations on bit strings. Finally, communication complexity of a run of the consensus

protocol in terms of the number of rounds is Θ(vis-diam(C, V

)).

To conclude, we need to prove that a so–built logical consensus system does indeed

solve Problem 1. Hence, for the general case with ν ≥ 1 agents that are reachable from

input u

, we can the state the following result (the proof is omitted for space limitation):

Theorem 1 (Global Stability of Linear Consensus). A logical linear consensus sys-

tem of the form x(t + 1) = C

∗

x(t) + V

∗

(t), where C

∗

and V

∗

are obtained as in

Eq. 7 from a reachable pair (C, V

), converges to a unique network agreement given by

in at most vis-diam(C, V

) rounds.

Algorithm 1 Optimal Linear Synthesis by Input–Propagation.

Inputs: C, V

Outputs: Minimal pair (C

∗

, V

∗

), permutation P .

1: Set A ← {i |V

(i) = 1} ⊳ nodes directly reachable from u

2: Set I(i) ← 1 for all i ∈ A ⊳ nodes reached from i ∈ A

3: Set N ← {1, . . . , n} \ I ⊳ nodes not yet reached

4: repeat

5: for all nodes i ∈ A do

6: Set Adj(i) ← C

(i) ∧ ¬I(i) ∧ N ⊳ new nodes

7: Set I(i) ← I(i) ∨ Adj(i)

8: Set N ← N ∧ ¬Adj(i)

9: Compute I ← {h : Adj(i)(h) = 1} ⊳ index list

10: for all new nodes h ∈ I do

11: Set

C(h, :) ← C(h, :) ∧ Adj(i)

⊳ every new node must communicate with one

reach at k − 1

12: end for

13: end for

14: until ∃ i ∈ A | Adj(i) 6= 0

15: Compute κ

← card(I(i)) for all i ∈ A

16: Find P | C

∗

← P

C P has κ

≥ · · · ≥ κ

⊳ re-order

17: Set V

∗

← P

4 Application to Intrusion Detection

Consider an indoor environmentwith n agents A

, · · · , A

whose task is to movepack-

ages between workspaces (WS). Suppose that agents have the capability to compute the

path associated with a task and to plan the sequence of tasks by ﬁnding an agreement

with other agents in order to avoid collisions and to avoid the use of the same segment

(W) in the same moment. We assume that each agent have also the capability to detect

and locate possible intruders or obstacles, such as lost packages or failed agents, in W.

The presence or the absence of an intruder in segment W

can be seen as an input u

the system of p = m logical decision y

(t) = u

(t) , i = 1, . . . , m, that each agent is

required to estimate. However, agents are able to detect the presence of intruders only

within their visibility areas, which is described by a visibility matrix V ∈ B

n×m

, with

i,j

= 1 if, and only if, an intruder in region W

can be seen by agent A

. Moreover,

let X ∈ B

n×m

denote the alarm state of the system: X

i,j

= 1 if agent A

reports an

alarm about the presence of an intruder in segment W

. The alarm can be set because

an intruder is actually detected by the agent itself, or because of communications with

neighboring observers. Indeed, agents have communication devices that allows them

to share alarm states with all other agents that are nearby. In this context, we aim at

designing a distributed update rule of the form X(t + 1) = F (X(t), u(t)), such that

agents can achieve the same state value (X

i,j

= X

k,j

∀i, k and ∀j). In other terms, at

consensus, each column of X should have either all zeros or all ones, depending on the

corresponding column of 1

f(u) = 1

Consider ﬁrst applying Algorithm 1 that produces a linear logical consensus of the

form X(t + 1) = F X(t) + B u(t), where each row basically expresses the rule that

(a) t = 0 (b) t = 1 (c) t = 2

(d) t = 3 (e)

Fig.1. (a)–(d) Run of the linear consensus system with 2 intruders (brown squares) in segment

and W

, respectively. The ﬁgure sequence shows that a correct agreement is reached (com-

ponents of the state X

of every agents are green or 0, when no intruder is detected in the

corresponding segment, red or 1 otherwise). (e) Considered communication graph C.

an observer alarm is set at time t + 1 if it sees an intruder (through u), or if one of its

C–neighbors was set at time t. The visibility diameter of this pair (C, V ) is 3, which

will correspond to the maximum number of steps before consensus is reached. Fig. 1

shows snapshots from a typical run of this linear consensus algorithm where every

agents converge to consensus after 3 steps. It is clear that using this method it is not

necessary that the system stops in the case that an intruder is detected in the area. By

sharing local information with other agents, each agent is able to execute its task by

excluding unavailable segments and by ﬁnding alternative paths to reach the goal.

5 Conclusions

In this work we considered the problem of the safety and security in the coordinated

motion of mobile robotics systems. The problem is studied through a novel consensus

mechanism where agents of a network are able to share logical values. We propose

an algorithm producing optimal logical consensus systems. By reaching consensus on

logical values based on local observation of the environment agents are able to update

its path according to the actual conﬁguration of the environment and to solve the motion

planning decision problem.

References

1. Olfati-Saber, R.: Flocking for multi-agent dynamic systems: algorithms and theory. IEEE

Trans. on Automatic Control 51 (2006) 401–420

2. Figueiredo, L., Jesus, I., Machado, J., Ferreira, J., Martins de Carvalho, J.: Towards the

development of intelligent transportation systems. Proc. IEEE Intelligent Transportation

Systems (2001) 1206–1211

3. Olfati-Saber, R., Fax, J.A., Murray, R.N.: Consensus and Cooperation in Networked Multi–

Agent Systems. Proc. of the IEEE (2007)

4. Ren, W., Beard, R., Atkins, E.: Information consensus in multivehicle cooperative control.

IEEE Cont. Syst. Mag. 27 (2007) 71–82

5. Blondel, V., Hendrickx, J., Olshevsky, A., Tsitsiklis, J.: Convergence in Multiagent Coor-

dination, Consensus, and Flocking. Proc. IEEE International Conference on Decision and

Control (2005) 2996–3000

6. Fang, L., Antsaklis, P., Tzimas, A.: Asynchronous Consensus Protocols: Preliminary Results,

Simulations and Open Questions. IEEE Int. Conf. on Decision and Control and Eur. Control

Conference (2005) 2194–2199

7. Bertsekas, D., Tsitsiklis, J.: Parallel and Distributed Computation: Numerical Methods.

(2003)

8. Baras, J.: Security and trust for wireless autonomic networks: Systems and control methods.

European Journal of Control 13 (2007) 105–133

9. Franceschelli, M., Egerstedt, M., Giua, A.: Motion Probes for Fault Detection and Recovery

in Networked Control Systems. American Control Conference, Seattle, WA, June (2008)

10. Necst - networked control systems tolerant to faults. (Sixth Framework Programme, Priority

2, Information Society Technologies, STREP, IST-004303)

11. Dzung, D., Naedele, M., von Hoff, T., Crevatin, M.: Security for industrial communication

systems. Proceedings of the IEEE 93 (2005) 1152–1177

12. Bicchi, A., Danesi, A., Dini, G., La Porta, S., Pallottino, L., Savino, I.M., Schiavi, R.: Hetero-

geneous wireless multirobot system. Robotics and Automation Magazine, IEEE 15 (2008)

62–70

13. Dini, G., Savino, I.: An efﬁcient key revocation protocol for wireless sensor networks. In:

Proc. IEEE International Symposium on World of Wireless, Mobile and Multimedia Net-

works, IEEE Computer Society Washington, DC, U.S.A (2006) 450–452

14. Chat - control of heterogeneous automation systems: Technologies for scalability, reconﬁg-

urability and security. (Seventh Framework Programme, IST-2008-224428)

15. Conet - the cooperating objects network of excellence. (Seventh Frame Programme, 2007-

2-224053)
