A Design Methodology for B2B Systems

Case of an e-Procurement System

Khoutir Bouchbout

, Jacky Akoka

and Zaia Alimazighi

Computer Science Department, USTHB University, Algiers, Algeria

ISID Research Team, CEDRIC-CNAM Laboratory, Paris, France

Keywords: B2B Systems, BPM, Inter-Organizational Business Process, Web Services, e-Procurement.

Abstract: As corporations rely more on collaboration with partners to enhance their position in the business world,

they transcend their traditional information system boundaries. They use IT-based inter-organizational

information systems (B2B systems - Business to Business) as a powerful strategic tool to link with their

partners in their supply chain. The B2B systems are critical for businesses in the current intensive and

competitive market. By considering the concepts of inter-organizational business process (IOBP), this paper

proposes an MDA-based methodology for B2B systems development which relies on the principles of BPM

(Business Process Management) and SOA (Service Oriented Architecture). Thus, our methodology

considers three levels in a top-down manner: collaborative business (organizational), business process

(conceptual) and process execution (technological). We have proposed an UML AD profile for IOBP

modelling. Then, the specific partner’s processes are derived based on MDA-based model transformations.

Finally, the B2B interactions are represented using Web services technology. In addition, we validate the

practicability of our methodology with the implementation of an e-procurement system.

1 INTRODUCTION

On the Internet, B2B (business-to-business) is the

exchange of products, services, or information

between businesses rather than between businesses

and consumers. In the new business era, B2B

systems are becoming a competitive necessity due to

globalization and the growing importance of

business alliances (networked organizations,

extended enterprises, etc.). They are the most

common form of technology to support data and

knowledge exchange between business partners like

in e-Procurement systems (Dorn et al., 2007). The

potential benefits of e-Procurement are transaction

cost savings and competitive sourcing opportunities.

It also increases the bargaining power of the buying

organization, which now has a better information

visibility of its business processes. Moreover, the

strategic value of B2B systems has been well

recognized for its real-time interaction, higher

transaction accuracy, more efficient and quicker

payments, rapid response, reduced search costs,

reduction in inventory and tighter links to customers

(Medjahed et al., 2003). These benefits enable all

parties to have high operational efficiency and

capability, and more and more corporations tend to

adopt B2B systems in order to gain competitive

advantages. IOBP are the enabler of such business

environments. Henceforth, there is a need for

supporting IOBP that interacts with the existing

business process of individual organizations.

Consequently, modelling such systems that span

multiple organizations involves new challenges,

mainly the ability to cope with autonomy, privacy,

distribution of components owned by business

partners to support the joint execution of

collaboration which requires the support for

coordination through mutual agreements (Bouchbout

et al., 2011). For this purpose, by considering

concepts of BPM and SOA, we present an MDA-

based design methodology for development of B2B

systems. It provides the capability to represent and

model IOBP independent of notation, standard or

technology.

The remainder of the paper is structured as

follows. In section 2, we cover the basic concepts of

IOBP. Section 3 highlights the related work for B2B

systems methodologies. Subsequently, the section 4

describes the aspects of the proposed methodology.

The section 5 assesses the capabilities of the

proposed methodology. Finally, the paper finishes

459

Bouchbout K., Akoka J. and Alimazighi Z..

A Design Methodology for B2B Systems - Case of an e-Procurement System.

DOI: 10.5220/0004439104590466

In Proceedings of the 15th International Conference on Enterprise Information Systems (ICEIS-2013), pages 459-466

ISBN: 978-989-8565-60-0

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

Receive

Request

for Quote

Send

Request

for quote

Send quote

information/

Rejection

Send

purchase

Order

Receive quote

information/

Rejection

Receive

Purchase

Order

Send order

Acceptation/

Rejection

Receive Order

Acceptation/

Rejection

Collaborative

Process

(global view)

Seller ‘s

Private

Process

Receive

Request

for Quote

Check

Product

availability

Prepare

Quote

Send quote

information/

Rejection

Receive

Purchase

Order

Check

Customer

Credibility

Send Order

Acceptation/

Rejection

Send

Request

for Quote

Send

Purchase

Order

Receive Quote

information/

Rejection

Receive order

Acceptation/

Rejection

Buyer’s

Private

Process

Purchase

Requisition

Evaluate

Quotation

Receive

Request

for Quote

Send Quote

information/

Rejection

Receive

Purchase

Order

Send order

Acceptation/

Rejection

Seller ‘s

Public

Process

Send

Request

for Quote

Send

Purchase

Order

Receive Quote

Information/

Rejection

Receive Order

Acceptation/

Rejection

Buyer ‘s

Public

Process

Figure 1: Basic scenario of e-Procurement: Collaborative, Public & Private processes.

giving a summary and an outlook to future work.

2 INTER-ORGANIZATIONAL

BUSINESS PROCESS

Recently, IOBP which depict the nature of business

interactions (information exchanges) between

organizations are turning to be an important issue of

contemporary BPM. To explain specifics of IOBP

modelling, we will discuss their requirements.

2.1 Characteristics of

Inter-Organizational Business

Process

While intra-organizational processes comprise

activities executed inside one organization only, the

activities comprised in an IOBP are executed by

different organizations that are working together to

reach a common objective. Moreover, compared to

intra-organizational business processes, IOBP is

based on multiple data-sets, owned and maintained

by the different involved stakeholders with the goal

to interweave the existing partner processes whilst

creating minimal impact on the existing processes

(Chebbi et al., 2006). Furthermore, IOBP usually do

not have a centralized control instance or process

owner (Bouchbout et al., 2010). It depicts the

different roles involved in the collaboration and their

specific responsibilities with regard to the

collaboration scenario. Hence, it needs close

coordination among networking partners which

requires an agreement on how to interact and

exchange information, business documents and

messages. Finally, the privacy and autonomy

requirements are at the top priority of participant’s

organizations.

Furthermore, in order to make IOBP work, each

involved organization has to implement not only its

internal processes (private processes), but also its

external behaviour (public process). So, adopting the

approaches used by (Bouchbout et al., 2010); (Chiu

et al., 2002); (Huemer et al., 2008); (Greiner et al.,

2006); (Legner et al., 2008), we consider a process

described either as a Private (orchestration, internal

or executable), Public (local choreography, abstract

or view), and Collaborative (global choreography,

cross-organizational or inter-organizational) in order

to better separate the information density of different

areas of concern. The Figure 1 illustrates these

process categories.

2.2 Inter-Organizational Business

Process Modelling Languages

To couple processes in the development of an IOBP

model is a complex task, as each business participant

has its own “private” set of established modelling

languages like UML2 Activity Diagrams (OMG,

2009), and BPMN (OMG, 2011). Important

contributions to handling the specific modelling

requirements of IOBP come from approaches for

distributed Workflow management, e.g. (Aalst et al.,

2001); (Chebbi et al., 2006); (Chiu et al., 2002),

current extensions of process modelling (Seal et al.,

2005); (Touzi et al., 2008), and B2B standards like

ebXML BPSS (Medjahed et al., 2003), but has been

limited to the process layer so far and they do not

fulfil the inter-organizational interactions issues.

This is so because they are incapable of representing

ICEIS2013-15thInternationalConferenceonEnterpriseInformationSystems

460

multiple actors participating in each collaborative

task while keeping consistency of the overall

processes. Moreover, one major requirement of

business/IT specialists in practice is the ability of

formal analysis and verification using Petri Nets

(Girault 2001); (Aalst et al., 2010) of BPM

languages like BPMN, EPC (Scheer, 1999) and

UML. Finally, the possibility of execution code

generation like BPEL and WS-CDL (Medjahed et

al., 2003). However, UML Activity Diagrams, EPC

and BPMN are more suitable to model public or

private processes from the viewpoint of one partner

instead of showing the peer-to-peer interactions

between the partners as a whole. Hence, most of the

languages provide insufficient support for modelling

IOBP and do not offer a collaborative and integrated

modelling framework comprising all levels of

abstraction.

Having these considerations in mind, our

approach provides an UML AD profile (Korherr and

List, 2007) ensuring more expressive power for

IOBP modelling, with the goal to develop a meta-

model that covers comprehensive aspects of B2B

business process theory including collaborations,

interaction flow, partner’s role, message exchanges,

public and private activities (at a high abstract level).

2.3 Methodical Approaches for IOBP

Modelling

In order to establish collaboration between business

partners one may start “bottom-up” from the private

processes or “top-down” from the IOBP (Bauer et

al., 2008); (Chebbi et al., 2006); (Greiner et al.,

2006) (Ziemann et al., 2007). In bottom-up

approach, the technology drives the business.

However, in top-down approach the business

requirements drive the technology. A bottom-up

approach bears the limitation that if each partner

develops its public process in isolation, it is rather

unlikely that their processes are complementary to

each other. Thus, it works only, if one partner

dominates the partnership and the other one adapts

his interfaces accordingly. In this case, discovering

potential business partners requires complex

comparisons of public processes. The bottom-up

approach implementations are based on Web

services compositions (Peltz, 2003). In cases where

private processes already exist, an organization

could simply expose application functionality as a

service and thereby realizes machine-to-machine

process integration with its business partners.

In general, a top-down approach describes a

decomposition approach where standards

organizations, industry consortia or market leaders

define an IOBP. Hence, a top-down approach

commences with a global view on the collaboration

efforts. The global view is described by an agreed

model of an IOBP, which should be followed by the

public processes of each partner. Each business

partner is then able to derive its public process and

to bind its private processes to the IOBP.

In this paper, we follow the top-down approach

which is more appropriate for an e-Procurement

system. This requires that the commonly agreed

IOBP was defined before.

Hence, our approach helps

to develop public processes that are compliant to

each other. This is guaranteed by the fact that each

partner derives its public process consistently to a

commonly agreed IOBP.

3 RELATED WORK

Before we present our B2B system design

methodology, we will briefly refer to some related

work in the following propositions done in the field

of inter-organizational Workflows or B2B

collaborations (Greiner et al., 2006); (Ziemann et al.,

2007); (Huemer et al., 2008); (Legner et al., 2008);

(Touzi et al., 2009), but it misses some research

clearly addressing the B2B systems methodology.

Legner et al., (2008) have presented a method for

modelling inter-organizational processes and

deriving business services in three steps. A

framework of conceptual inter-organizational

business modelling is then defined containing a

public process model which serves as reference for

the participating organizations (Step 1). Then, the

existing private processes have to be assigned and

eventually aligned to the agreed public process

model (Step 2). After that, the public process

interface is realized by business services leveraging

web service technology (Step 3). The business

process model is used to derive XML-based business

documents that are exchanged between business

services. In addition, private process modules are

transformed into workflows for business process

automation which later can be implemented using

the Business Process Execution Language (BPEL).

Huemer et al., (2008) have developed a

methodology dealing with collaborative processes

called UN/CEFACT Modelling Methodology

(UMM). UMM specifies collaborative business

processes involving information exchange in a

technology neutral, implementation-independent

manner. UMM is a UML modelling approach for

global choreographies of B2B scenarios. It is a top-

ADesignMethodologyforB2BSystems-Caseofane-ProcurementSystem

461

down approach that makes use of worksheets to

capture domain requirements. UMM do not provide

a complete development process to generate IOBP

executions. It only provides a development process

for modelling technology-independent IOBP.

The work of Touzi et al., (2009), has proposed a

model-driven approach to design a collaborative

information system (CIS) dedicated to deal with

exchanged data, shared services and collaborative

processes. The CIS design crosses the different

abstraction layers (business, logic and technological)

and exploits at each level the associated models to

build the models of the next level. The model of an

IOBP is BPMN-oriented and based on the SOA. Its

meta-model has been defined by referencing the

BPMN specifications as well as the IOBP aspects.

The framework proposed by Ziemann et al.,

(2007) presents a method for the creation of

collaborative process on a conceptual level. They

described how cross-organizational business

processes can be modelled and transformed to

technical process models in the form of Web Service

protocols. Their framework can be instantiated using

EPCs (design phase) and BPEL (implementation

phase) to describe models in different life cycle

phases and demonstrated the transitions between

these phases. However, a description of how

organizational roles can be communicated to

partners is missed.

Greiner et al.’s work (2006) describes the

designing and the implementing of cross-

organizational business processes including different

levels of technical detail: the business level, the

technical level and the execution level. They identify

how the mappings and the transformations are

needed among private process, view process and

IOBP among the different levels. The business level

models illustrate the organizational business aspects.

The technical model secures the technical realization

of the process integration and represents the bridge

to the process execution.

Summarizing the above review of related

literature, we observe that the issue of inter-

organizational systems modelling and development

has been extensively addressed. Yet, while the

proposed solutions strive to enable the operation of

an IOBP, no explicit consideration of generic

business requirements is made to relate to generic

inter-organizational scenarios. To achieve this we

propose a design methodology for B2B systems

development by combining MDA and SOA.

4 A DESIGN METHODOLOGY

FOR B2B SYSTEMS

To meet the aforementioned IOBP requirements, we

need a methodology that enables a process-based

B2B systems development at both business and

technological levels, based on a MDA (Model-

Driven Architecture) approach (OMG, 2003);

(Roser, 2006); (Hammoudi et al., 2010), shifting the

focus of software development from writing code to

building models. To define a valid separation

between business, software and technological

platforms in the information systems, MDA uses

different kind of models: (1) Computation

Independent Model (CIM); (2) Platform Independent

Model (PIM); (3) Platform Specific Model (PSM).

The MDA approach is characterized by a set of

vertical transformations/mappings across different

phases (PIM to PSM and PSM to Code) using model

transformation languages like ATL (Bézivin et al.,

2003). The vertical transformation in the downward

direction corresponds to process automation

approaches where conceptual process models (e.g.

BPMN) are transformed to executable processes

(e.g. BPEL).

Therefore, in the Figure 2 we depict the proposed

a MDA-based methodology which supports: the

design of IOBP independent of particular B2B

standard; and the automatic generation of each

partner’s side specifications based on a B2B

standard (BPEL) from conceptual IOBP models

(UML AD profile).

The main benefits of this methodology are:

increase of the abstraction level, since the focus is

on the design of technology-independent IOBP;

reduction of development costs and time and

guarantee of alignment of a business solution with a

technological solution, since process executions are

generated automatically from process models. The

development’s methodology is organized into three

levels from the abstract conceptual level to the

technical execution level: Collaborative business

requirements, Collaborative business process

definition, Public processes generation, Internal

Private processes generation, and code execution.

4.1 CIM Layer: Collaborative Business

Requirements Phase

The collaborative business requirements phase at

CIM level consists in analyzing the problem domain

and identifying the business requirements. This is

jointly carried out by the enterprises. Hence, it helps

the correspondent business analysts to understand

ICEIS2013-15thInternationalConferenceonEnterpriseInformationSystems

462

Enterprise A: Seller

Enterprise B: Buyer

Transformation

Rules

Generic CBP metamodel,

CBP model: UML2 Profile, Formal verification of CBP

1-BPMN public process:

public view, behaviour

2- BPMN private process:

private activities, internal

business logic

3- BPMN formal verification

1- SOA/WS-BPEL, WSDL:

internal techno. Standards

2- BPEL formal verification

3- Internal code execution,

4- Buyer web application

1- SOA/WS-BPEL, WSDL:

internal techno. Standards

2- BPEL formal verification

3- Internal code execution,

4- Seller web application

1-BPMN public process:

public view, behaviour

2- BPMN private process:

privateactivities, internal

business logic

3- BPMN formal verification

Message’s Exchange

Invocation of services

CSF for IOS adoption, B2B requirements

environnement, roles, common objectives,

interactions p rotocol, informations exchange

Derivation

Rules

Transformation

Rules

CIM: Collaborative

business layer

PIM: Collaborative

process layer

PIM: Public &

Private partner’s

processes layer

PSM: Partner’s

internal code

execution layer

Business

level

Process

level

Technology

level

Figure 2: MDA-based methodology for B2B systems development.

the problem. We should capture the process

stakeholders (description of various partners and

their roles they fulfil) and their communication

relationships.

We also define the collaborative agreement

parameters and the hierarchy of common business

goals to be fulfilled by partners. In this phase we

define also the critical success factors for B2B

system adoption and use. The collaboration partners

are determined by the shared goals of the

collaboration and the aspired win-win situation of all

partners. The joint aims of the collaboration have to

be defined as synthesis of the individual aims.

4.2 PIM Layer: Collaborative Process

Definition Phase

The main focus is on the definition of the IOBP,

which describe the common behaviour of the

interactions between partners from a global

viewpoint. The IOBP language was defined as a

UML AD Profile in order to provide well-known

graphical notations for modelling IOBP. So, the

IOBP modelled with UML AD profile instantiate the

generic IOBP meta-model proposed for this context.

The main contributions of our meta-model are

twofold: firstly, we introduce all the IOBP specific

concepts in order to model business collaboration;

secondly, contribution can be characterized by

taking into account explicitly both the four IOBP

requirements (autonomy and privacy,

decentralization, interaction flows, and technology

independence). The use of a UML profile allows us:

provide a vocabulary more suitable to model IOBP;

add semantics and constraints to the UML meta-

model from the modelling domain of IOBP; and

reuse existent UML case tools to model IOBP. In

addition, this language encourages a top-down

approach to model IOBP and provides the

conceptual elements to support the modelling of

IOBP main aspects:

- Definition of the participants (partners and their

collaboration roles) of an IOBP with their

communication relationships with description of

the hierarchy of common business goals that

partners agree on.

- Identification of IOBP required achieving the

agreed business goals using the definition of

collaborative processes as informal specifications

of a set of actions performed by partners.

- Representation of business documents to be

exchanged in IOBP with providing the concepts

to define the syntactic and semantics structure of

business documents.

- Description of the public interfaces of each

collaboration role performed by partners. A

public business process contains business

operations that support the asynchronous

message exchange of interactions between

partners.

Since IOBP models describe B2B collaboration, it is

essential to enable partners to make sure the

behaviour of IOBP is well-defined by verifying the

structural correctness of a business process. The

verification task is concerned to check the process

model is free of logical errors (Aalst et al., 2010).

ADesignMethodologyforB2BSystems-Caseofane-ProcurementSystem

463

This requires the use of formal verification

techniques, which should be applied to detect errors

in the integration process models, such as deadlocks,

livelocks, etc. With complex real life business

processes, ensuring the correctness of the model is a

very difficult task, even for a process modelling

expert. Therefore, tool support for this kind of

analysis would be very important. Hence, we carried

out a formal verification of IOBP models, using

Petri Nets, starting at an early stage in the

development, i.e. previous to the generation of the

IT architecture solution.

4.3 PIM Layer: Generation of Public

Process Phase

Although IOBP define how partners will coordinate

their actions, these processes are not executable.

IOBP require the definition of public and private

processes each enterprise has to implement for

executing collaborative process. A public process or

behavioural interface defines the public behaviour of

the role an enterprise performs in an IOBP at PIM

layer. It defines the public and externally visible

behaviour of a partner in terms of the activities that

support the receiving and sending of messages with

each other. The public process can be derived from

the IOBP. To carry out this derivation, we ensure

that the semantics of each IOBP element,

represented as an UML AD profile, is represented in

terms of the elements and semantics provided by

BPMN from one partner’s viewpoint (e.g. buyer).

4.4 PIM Layer: Definition of Private

Process Phase

An internal executable process or orchestration

processes is derived from a public process at each

partner’s side. It adds the private logic of the

enterprise required to support the role it perform in

an IOBP. The internal business logic includes the

activities for producing and processing the

exchanged information as well as data

transformations and invocations to internal systems.

Internal activities, which are required for generating

the information to be sent and processing the

information to be received from partners, have to be

added to the public process to define the

corresponding private process. It requires the

definition of activity patterns, which capture

recurrent business functions to process or generate

the information exchanged between partners. At this

end, in order to realize the BPMN-to-BPEL

transformation, we implement an algorithm inspired

from Ouyang et al., (2009), namely BPMN2BPEL.

It takes as input a BPD (BPMN Business Process

Diagram) represented in XML format and produces

the correspondent BPEL code. This step consists of

transforming BPMN model obtained from other

modelling tool to the corresponding BPMN2BPEL

XML input format to bridge this gap.

4.5 PSM Layer: Internal Process

and Code Execution Phase

This step deals with the user interface applications

development for the “seller” and the “buyer” roles.

These partners’ user interface applications support

the decentralized execution of the IOBP. Although

this phase is achieved in parallel for enterprises, they

must agree on the B2B standards to be used for

implementing the inter-enterprise specifications.

Furthermore, on the execution layer these internal

processes are used e. g. for the orchestration of Web

Services (Peltz, 2003). It consists on the generation

of the XML-based specifications of business

processes and the B2B systems’ interfaces of an

enterprise from its platform-specific IT model,

which contains the necessary information for the

code generation. To this aim, we have implemented

a direct connection with the computers and business

applications of the buyer organization

communicating directly with a seller's web

application to send and receive information. After

collaborating, both of the two partners’ applications

progress independently.

5 IMPLEMENTATION OF AN

e-PROCUREMENT SYSTEM

To master the complexity of the design and

implementation of B2B systems, a tool support is

essential. For this purpose, we use an Eclipse-based

IDE platform (Eclipse, 2012). By using the Eclipse

platform it is possible to guarantee the

interoperability of the different plug-ins, tools and

transformation languages. In addition, the Eclipse

platform enables us to provide an integrated tool that

supports the entire development process of the

model-driven development methodology for B2B

information systems (see Figure 3). Thus, we use the

following components:

- A set of Eclipse-based plug-ins, which supports

the definition of UML AD profile models as well

as BPMN, BPEL and WSDL process models.

Figure 3 illustrates the tools used using Eclipse

ICEIS2013-15thInternationalConferenceonEnterpriseInformationSystems

464



conforms‐to

model‐to‐model

transformation

edit

applies

Ecore

Eclipse UML2

Editor

Intalio BPMN

Editor

Eclipse UML2

Metamodel

UML2 Activity

Diagram Model

Eclipse UML2

Profile

UML2 Activity

Diagram Procurement 

Eclipse BPMN

Metamodel

ATL

Metamodel

UML2BPMN.atl

BPEL & WSDL

metamodels



Seller.bpmn

Buyer.bpmn

Ecore 

BPEL Model

WSDL Model

Buyer & Seller.bpel

Buyer & Seller.wsdl

BPEL & WSDL

Editor

BPMN2BPEL

Eclipse

BPMN Model

conforms‐to

applies

model‐to‐modeltransformation

edit

Figure 3: Process model transformations and tools used in the implementation.

UML plug-in.

- An Eclipse-based ATL (Atlas transformation

language) tool for model transformations which

supports the building of process model

transformations (from UML AD profile to

BPMN and from BPMN to BPEL). In this way,

the derivation of the intra-organizational process

“seller.bpmn” from the IOBP e-Procurement

process, by means of the “umlProfile2bpmn.atl”

file representing the application of the derivation

rules which should be defined before, is carried

out with the Eclipse ATL tool.

In addition, we have developed in parallel software

tool implementing formal verification techniques

which have to be applied to corresponding Petri Nets

representation (PNML) (Aalst et al., 2010) of

business process. This tool is applied at the three

levels (formal verification of UML AD, BPMN and

BPEL processes).

In this work, we have developed a prototype e-

Procurement system which implements the basic

scenario, depicted before by the Figure 1, where a

buyer (organization A: the University) makes an

online order (purchasing computers, printers,

laptops, etc.) to a seller (organization B: Supplier),

who processes and fulfils the order through

collaborative and internal business processes. Hence,

we have implemented an e-Procurement application

for each partner’s side (buyer and seller)

implementing the executable private business

processes as web services. Abstract processes

described with BPEL provide WSDL interfaces that

define the “static interface” of a private process. The

interaction that could occur between seller and buyer

(see Figure 4) is achieved as a part of the invocation

of a web services.

6 CONCLUSIONS

In the frame of this work, we have presented a top-

down methodology to build inter-organizational

information systems based on MDA approach and

rely on the principles of SOA paradigm. Thus, we

have proposed a three level methodology for

developing B2B systems (business, process and

technology). We have proposed an UML AD profile

for IOBP modelling. Then, the specific partner’s

processes are derived based on MDA-based model

transformations. Finally the B2B interactions are

represented using Web services technology.

FIREWALL

Intranet

To-be University’s e-Procurement application architecture

Solicitation

Automation

E-Procurement

University Procurement Sellers

Procurement

Agents

Requests

Responses

HTML

Campus

Agents

Internet

FIREWALL

Seller Organizations

Figure 4: Architecture of the University’s e-Procurement

application.

ADesignMethodologyforB2BSystems-Caseofane-ProcurementSystem

465

There are several open issues to address in the

future. Thus, we plan to evaluate our methodology

through several case studies in order to verify the

completeness of the proposed concepts and artefacts.

Another aspect that requires further research is to

investigate the explicit support of multi-party

interactions (e.g. buyer, seller, and shipper).

REFERENCES

Aalst Van der W.M.P. and Weske M. 2001. The P2P

approach to Interorganizational Workflows. In K.R.

Dittrich, A. Geppert, and M.C. Norrie, editors,

Proceedings of CAiSE'01, LNCS Vol. 2068, pp.140-

156. Springer-Verlag, Berlin, Germany.

Aalst van der W. M. P., Van Hee K., ter Hofstede A.,

Sidorova N., Verbeek H., 2010. Soundness of

Workflow Nets: classification, decidability, and

analysis. Formal Aspects of Computing, pp. 1-31.

Bauer B., Müller J.P., Roser S. 2008. Decentralized

business process modeling and enactment: ICT

architecture topologies and decision methods. Fifth

International Workshop (ProMAS'07), Honolulu,

USA, May 2008, LNAI 4908, pp. 1-26.

Bézivin, J., Dupé, G., Jouault, F. and Rougui, J. E., 2003.

First Experiments with the ATL Model

Transformation Language: Transforming XSLT into

XQuery, In the 2nd OOPSLA Workhop on Generative

Techniques in the context of Model Driven

Architecture.

Bouchbout K., Akoka J. Alimazighi Z. 2010. Proposition

of interorganizational business process metamodel, In

Proc. of EOMAS/CAISE Workshop, Hamamet,

Tunisia.

Bouchbout K., Akoka J. Alimazighi Z., 2011. Inter-

Organizational Business Process Modelling

Framework, In Proc. of ADBIS’2011, Vienna, Austria.

Chebbi Issam, Dustdar Schahram, Tata Samir, 2006. The

view-based approach to dynamic inter-organizational

workflow cooperation, Data & Knowledge

Engineering, Vol. 56, pp.139-173.

Chiu D. K. W., Karlapalem K., Li Q., and Kafeza E. 2002.

Workflow View Based E-Contracts in a Cross-

Organizational E-Services Environment, Distributed

and Parallel Databases, Vol. 12, pp. 193-216.

Dorn J., Grün C., Werthner H., and Zapletal M. 2007. A

Survey of B2B Methodologies and Technologies:

From Business Models towards Deployment Artifacts.

Proceedings of HICSS’07,

Eclipse Oranisation: Eclipse Platform, URL:

http://www.eclipse.org , accessed on June 2012.

Folmer E., and J. Bastiaans, 2008. Methods for Design of

Semantic Message-Based B2B Interactions Standards,

in Enterprise Interoperability III, Springer, pp.183-

194,

Girault, C., Valk, R. 2001. Petri Nets for System

Engineering: A Guide to Modeling, Verification, and

Applications, Springer-Verlag New York, Inc,

Greiner, U., Lippe, S., Kahl, T., Ziemann, J., Jäkel, F.W.

2006. Designing and implementing cross-

organizational business processes - description and

application of a modelling framework. In Proceedings

of I-ESA’2006.

Hammoudi S., Alouini W., Lopes D., Huchard M.

2010. Towards A Semi-Automatic Transformation

Process in MDA: Architecture, Methodology and First

Experiments. IJISMD, Vol.1 Issue 4, pp. 48-76.

Huemer C., Liegl P., Schuster R., Werthner H., and

Zapletal M. 2008. Inter-organizational Systems: From

Business Values over Business Processes to

Deployment. Proceedings of DEST’2008.

Korherr Birgit, List Beate, 2007. Extending the EPC and

the BPMN with Business Process Goals and

Performance Measures. 9th International Conference

on Enterprise Information Systems (ICEIS’07), ACM

Press,

Legner Christine, Vogel Tobias, Löhe Jan, Mayerl

Christian, 2008. Transforming Inter-Organizational

Business Processes into Service-Oriented

Architectures. Method and Application, Proceedings

of KiVS’2007, Switzerland,

Medjahed, B., Benatallah, B., Bouguettaya, A.,

Elmagarmid, A., 2003. Business-to-business

interactions issues. The VLDB Journ, Vol. 12, 59-85.

OMG Object Management Group, 2009. Unified

Modeling Language Specification, version .2.2.

http://www.omg.org/uml/

OMG: BPMN 2.0, 2011. available at:

http://www.omg.org/BPMN/.

OMG: Model Driven Architecture, 2003. available at:

http://www.omg.org/mda/.

Ouyang, C., Dumas, M., Van Der Aalst, W. M. P., Ter

Hofstede, A.H.M., 2009. “From business process

models to process-oriented software systems”, ACM

Trans. on Software Eng. Methodology, Vol. 19(1),

pp.1-37.

Peltz Chris, 2003. Web services Orchestration and

Choreography, IEEE Computer, 36(10), pp.45-52,

Roser S., Bauer B., Müller J. P. 2006. Model- and

Architecture-Driven Development in the Context of

Cross-Enterprise Business Process Engineering,

Proceedings of IEEE Intern. Conference SCC'06.

Scheer, A.-W. 1999. ARIS Business Process Modeling.

Springer Verlag.

Seel Christian, Vanderhaeghen Dominik, 2005. Meta-

Model based Extensions of the EPC for Inter-

Organisational Process Modelling, in Proceedings of

EPK’2005, Hamburg, Germany.

Touzi J., Bénaben F., Pingaud H., 2009. A Model-driven

approach for collaborative service-oriented

architecture design, International Journal of

Production Economics, Vol. 121 No 1, pp. 5-20.

Ziemann Jorg, Matheis Thomas, Freiheit Jorn, 2007.

Modelling of Cross-Organizational Business Processes

- Current Methods and Standards, Proceedings

EMISA’2007, LNI, Vol.119, pp.87-100.

ICEIS2013-15thInternationalConferenceonEnterpriseInformationSystems

466
