Checking Models for Activity Recognition

Martin Nyolt, Kristina Yordanova and Thomas Kirste

Institute of Computer Science, University of Rostock, Germany

Keywords:

Activity Recognition, Model Checking.

Abstract:

Model checking is well established in system design and business process modelling. Model checking ensures

and automatically proves safety and soundness of models used in day-to-day systems. However, the need for

model checking in activity recognition has not been realised. Models for activity recognition can be built by

prior knowledge. They can encode typical behaviour patterns and allow causal reasoning. As these models are

manually designed they suffer from modelling errors. To address the problem, we discuss different classes of

sensible properties and evaluate three different models for activity recognition. In all cases, modelling errors

and inconsistencies have been found.

1 INTRODUCTION

Activity recognition is an important yet challenging

task with applications in ubiquitous and pervasive

computing, smart environments, and ambient assisted

living. The key problem is to identify actions and ac-

tivities of agents (i.e. humans) as well as interactions

with the environment and other agents. For this pur-

pose, sensors are usually distributed throughout the

environment or the agents by means of dense sensing

(Chen et al., 2012), computer vision (Aggarwal and

Ryoo, 2011), or wearable sensing (Lara and Labrador,

2013). One approach is to build human behaviour

models based on prior knowledge about (causal) ac-

tivity structure, incorporating domain and application

speciﬁc knowledge (Hiatt et al., 2011; Krüger et al.,

2013). These generative models, when encoding the

behaviour of the environment and the agents, allow

reasoning about the current activity structure, and at

the same time enable assisting actions when used as

input to a classical planning algorithm.

These models have to be causally correct and rep-

resent all desired details. For instance, if a person has

taken a knife from a counter, the model should always

allow to put the knife down as long as the person is

at the counter or a table. On the one hand, sophis-

ticated models cover many causal dependencies be-

tween ﬁne-grained activities in a detailed state space.

Consider a system assisting an elderly in a kitchen. To

provide adequate assistance, the system must detect

and track activities involving many utensils at differ-

ent places, possibly guiding towards the location of

the utensil appropriate for the current situation. On

the other hand, a model that allows all unrelated phys-

ical interactions quickly becomes too complex, ren-

dering (probabilistic) inference infeasible due to large

state spaces. Therefore, techniques have been devel-

oped to reduce these models on a symbolic level (Yor-

danova et al., 2014), reducing the number of required

actions and states to distinguish. The result is a con-

ﬂict between creating complex models and reducing

and ﬁne-tuning the model. This tuning is error-prone

and increases chances for models to become incon-

sistent. Clearly the model should be free of errors,

otherwise it could lead to undesired or even harmful

actions of the system. Therefore, the need for check-

ing consistency of activity recognition models arises.

This paper presents ﬁrst results and experiences

on model checking for activity recognition. Model

checking is well established for verifying soundness

and correctness of models (Clarke et al., 1999). It has

been successfully applied in system design and busi-

ness process modelling, among others. To the best of

our knowledge, model checking has not been applied

to activity recognition models before.

In most previous publications activity recognition

models are assumed to exist. Only little work has

been done on the model development process for be-

haviour models for activity recognition (Yordanova

and Kirste, 2014). This paper raises awareness and

discusses the need for model checking. Three activ-

ity recognition models are evaluated, which all have

been designed to work in and have been applied to a

real smart environment (Krüger et al., 2012; Krüger

et al., 2013; Krüger et al., 2014). We present and dis-

cuss common modelling errors and sensible types of

497

Nyolt M., Yordanova K. and Kirste T..

Checking Models for Activity Recognition.

DOI: 10.5220/0005275204970502

In Proceedings of the International Conference on Agents and Artiﬁcial Intelligence (ICAART-2015), pages 497-502

ISBN: 978-989-758-074-1

 2015 SCITEPRESS (Science and Technology Publications, Lda.)

properties to detect them. Additionally, we discuss

the impact of model checking on activity recognition.

2 BACKGROUND

2.1 Related Work

Due to its wide success, model checking has found

application in AI and many researchers also discov-

ered model checking as a utility for activity recogni-

tion. Magherini et al. (Magherini et al., 2013) inves-

tigate the applicability of temporal logic and model

checking to the problem of plan recognition (assum-

ing actions observations). They present a linear tem-

poral logic reasoning about past events and real-time

constraints on actions. The application scenario is the

recognition of activities of daily living, tracking the

activities and calling assistance on potentially erro-

neous (e. g. dangerous) behaviour. Each activity is

represented as one formula in the temporal logic, and

at least one additional formula for erroneous execu-

tions of the actions. Inference works by ﬁnding that

activity (i. e. formula) that is satisﬁed by the observed

action sequence.

Cimatti et al. (Cimatti et al., 2003) design a plan-

ner in non-deterministic domain, i. e. domains with

actions that have non-deterministic effects. They ap-

ply techniques from symbolic model checking and

represent sets of states (possible outcomes of actions)

as propositional formulae. Based on this model-based

planner (MBP), Gromyko et al. (Gromyko et al.,

2006) synthesise a controller for non-deterministic

discrete event systems. Given required properties in

temporal logic and a system, they generate a con-

troller for this system such that it satisﬁes the prop-

erties.

In many cases applying model checking tech-

niques, the idea is to compactly represent states and

efﬁciently generate a search tree. This is often done

using efﬁcient data structure such as Binary Decision

Diagrams (BDDs). In contrast to Magherini et al.,

we do not recognise activities using model checking

techniques. We apply model checking in its origi-

nal sense: proving that the models (used for activity

recognition) fulﬁl all desired properties.

2.2 State Space Models for Activity

Recognition

This section introduces the types of models used for

activity recognition. In Sect. 3 we then describe how

to apply model checking.

( : a c tio n p r i n t

: pa r ame t ers (? j − job )

: p r ec on d i ti on ( and

( not ( p r in t ed ? j ) )

( not jammed )

( has paper p r i n te r ) )

: e f f e c t ( pr i n t ed ? j ) )

( : a c t io n r e p a ir

: p aram eter s ( ? a − a gent )

: pr ec o nd it i on ( and

( a t p r in te r ?a )

( hands− f r e e ?a )

( jammed ) )

: e f f e c t

( not jammed ) )

Listing 1: Simple PDDL domain deﬁnition for the ofﬁce

scenario (excerpt).

When reasoning about human behaviour, state

space models (Koller and Friedman, 2009) built from

prior knowledge are one option as a ﬂexible foun-

dation for reasoning about human behaviour. They

have recently been used for different activity and in-

tention recognition applications (Hiatt et al., 2011;

Krüger et al., 2013; Ramírez and Geffner, 2010) for

several reasons. First, learning (discriminativeor gen-

erative) probabilistic models requires a vast amount

of training data. Acquiring this data involves a lot

of human subjects and is therefore time-consuming

and costly. Second, human behaviour varies consid-

erably even for small domains like food preparation.

It is infeasible to record sufﬁcient training data for all

possible variations. Finally, generative models eas-

ily allow prediction, goal recognition (Ramírez and

Geffner, 2010), and support assistance (Hiatt et al.,

2011; Hoey et al., 2011).

In addition, this general framework allows to eas-

ily model long-term dependencies. For example in a

meeting scenario, a projector only can be turned off

after it has been turned on, no matter how many other

activities have been executed. This framework also

supports latently inﬁnite state spaces, like counting

how many objects are currently taken by some agent.

In our examples we use a syntax based on PDDL

(Fox and Long, 2003) for model speciﬁcation. PDDL

is used because it is widely adopted for planning (and

can thus be directly applied for assistance problems),

but also previous activity and goal recognition ap-

proaches are based on it (Krüger et al., 2013; Ramírez

and Geffner, 2010). Actions are deﬁned in terms of

preconditions and effects on state predicates. List-

ing 1 shows a simple excerpt from one of our models.

The model also comprises an initial world state and

a goal formula identifying goal states for a given ap-

plication domain. Additionally, the syntax is enriched

with a duration model and observation model. For

activity recognition, the model is then compiled to a

probabilistic model for Bayesian inference, i.e. com-

puting the most likely state given past observations.

Because we want to reason about detailed context and

activities, the model easily becomes complex.

ICAART2015-InternationalConferenceonAgentsandArtificialIntelligence

498

3 MODEL-CHECKING

APPROACH

We employ the PRISM tool as a state-of-the-art, off-

the-shelf model checker (Kwiatkowska et al., 2011).

We have chosen PRISM because it supports a vari-

ety of models, the property language covers many

features, it can produce counter-examples for certain

properties, and uses BDDs for efﬁciently storing large

state spaces. A compiler transforms the PDDL speci-

ﬁcation into PRISM’s syntax. The compiler instanti-

ates the actions to ground actions (removing any pa-

rameters) and resolves conditional effects (which are

not supported by PRISM) by generating different ac-

tions for each possible combinations of conditional

effects. Although our action models contain dura-

tions, the system itself evolves in discrete steps. Our

focus is only on qualitative aspects of the model, so

the duration models and the observation models can

be simply dropped.

The model checker can verify if a model (i. e. the

sequence of states generated by the model) satisﬁes

a boolean formula written in temporal logic. These

formulas are often called properties, as they describe

desired behaviour of the model. Any violation of the

properties is considered a modelling error. Temporal

formulae are deﬁned over sequences of states. A for-

mula φ references atomic state propositions and usu-

ally consist of one or more of the operators

φ (φ

must hold in the next state),

φ (φ must hold in at

least one state of the sequence),

φ (φ must hold in

all states of the sequence),

φ (φ must hold in at least

one possible path, e. g. due to non-determinism), or

φ (φ must hold in all possible paths), among others.

The formula in PRISM can refer to state variables

as well as labels, which are user-deﬁned formulas on

state variables. The compiler automatically generates

a “goal” label from the goal deﬁnition of the model,

making it easier to reference goal states. Properties

are usually of the form

φ, as all possible executions

of behaviour models should satisfy the property. An

example in PRISM syntax is

A [ F "goal" ]

, stat-

ing that it is always possible to reach a goal state.

Deﬁning properties is the most important step, as

this encodes all knowledge and intuition that should

hold in the domain. This is particularly important for

behavioural models as presented in Sect. 2.2. These

models are described on a symbolic level (in this case

using PDDL) in terms of the action’s preconditions

and effects. In contrast to, for example, functional

tests or unit tests in software engineering, the designer

should not focus on properties of single actions. One

might be tempted to compare properties with con-

tracts in programming by contract with imperative

implementations (Meyer, 1992), where functions also

have pre-conditions and post-conditions. Although

the concept is different in testing or veriﬁcation, from

a designer perspective formulating properties or con-

tracts seems to be a comparable task. Both ensure that

actions or functions are only called in certain contexts

and have a desired outcome.

However, symbolic action descriptions as in

PDDL are declarative, so the gain from impera-

tive functions to declarative properties is not exis-

tent when formulating properties for PDDL domains.

Even worse, the properties are likely to be deﬁned by

the model designer, who will simply re-state the ac-

tions’ preconditions and effects, possibly making the

same high-level conceptual errors. Therefore we ar-

gue it is most useful to describe properties that cover

long-term dependencies, and not simply assertions to

execute speciﬁc actions. We identiﬁed various types

of properties to be important, which can be grouped

into invariants and long-term causation.

Invariants. are properties that need to be satisﬁed

at all times. The two most salient properties are dead-

lock freeness and livelock freeness. Deadlocks are

states in which no action can be executed. Dead-

lock freeness can be checked using the formula

A [

G !"deadlock" ]

(PRISM automatically provides

a label “deadlock” for deadlock states). Deadlocks

should be avoided in behaviour models. Either dead-

lock states are impossible in the underlying domain,

in which case they should be unreachable, or they are

possible, in which case actions are probably miss-

ing and the inference process cannot recognise sub-

sequent activities. The underlying assumption is that

humans almost always ﬁnd a solution or continue act-

ing in any case, so that deadlocks do not occur in

the application (of course, domain-speciﬁc exceptions

may exist). Resolving the deadlock depends on the

model and the intended behaviour. Any reasonable

model checker can provide a counterexample path to

violated formulas of the form

A G

φ, thus giving a

sequence to a deadlock.

Livelocks, in our activity recognition case, are

states in which actions are possible, but no goal

state can be reached (checked with

A [ F "goal"

]

). They indicate a possible problem in the domain or

model, where the overall task is impossible to accom-

plish. Livelocks are more difﬁcult to track, as usually

no counter-examples can be given. One strategy is to

split the goal formula and verify that parts of the goal

can be reached.

Additionally, domain-speciﬁc invariants are can-

didates for properties, for example the property that

exactly one of a set of state variables is always true

CheckingModelsforActivityRecognition

499

(e.g. a user may hold only up to two objects in

his hands). Especially important are those invariants

which are related to multiple actions, where the in-

variants cannot be captured by preconditions and ef-

fects of a single action. An example might be multiple

actions where it is possible that the user holds an ad-

ditional object in hand (e.g. either by taking from a

surface or by disassembling one object). These for-

mulas are often of the form

A G

φ, thus any violation

can be proven with a counterexample.

Long-term Causations. between actions ensure

properties which can only be implicitly encoded

within multiple actions. This includes typical action

sequences such as turning devices on and off (e. g.

lamps or stoves) with intermediate actions, where turn

on is only allowed for devices previously turned off

and vice versa. Sometimes models include decisions

of users (e.g. where to sit, when to present) which do

not immediately inﬂuence the behaviour, but alter the

progress of the model when the decisions are realised

later. Here properties typically are of the scheme

[ G (

φ ⇒ F ψ

) ]

, meaning only when φ holds, the

model always behaves in a particular way according

to ψ. In real-world domains, repeatability of certain

actions are desired, like locomotion or basic inter-

actions with the environment. These properties of-

ten follow the scheme

A [ G (F

) ]

, stating that

it must always be possible to reach a state where φ

holds. On the other hand, some actions can only be

executed once in certain applications, for instance in-

gredients can only be cut once.

Some of these properties, when violated, may not

always indicate a modelling error. Instead, they can

provide useful insight to the problem domain and spot

unexpected effects that may or may not be desirable.

Other violations may point out possible chances for

reducing the model complexity and state space, such

as limiting the model behaviour to the particular ap-

plication domain. It must be noted that unsatisﬁed

properties, deadlocks, and livelocks not necessarily

inﬂuence recognition results negatively. If some be-

haviour not present in the datasets is not modelled,

recognition accuracy usually increases because less

behaviour must be discriminated. Therefore these “er-

rors” may sometimes be intended. Nonetheless, it

must be kept in mind that this hinders re-usability of

the models and can lead to unexpected problems, es-

pecially if they are not documented.

4 EVALUATION OF ACTIVITY

RECOGNITION MODELS

For the evaluation of our activity recognition tool, we

conducted several experiments in our smart environ-

ment and built various behaviour models. During de-

velopment, we identiﬁed a number of modelling er-

rors and inconsistencies in the models. Each section

brieﬂy presents the models and properties, and dis-

cusses the modelling errors found. Note that this is an

empirical review of actual modelling errors, none of

these errors has been artiﬁcially added to the model.

An overview of the number of actions and states is

shown in Table 1, giving an intuition of each model’s

complexity.

4.1 The Meeting Scenario

Three persons hold a presentation and discuss in a

meeting room. The model’s actions comprise walking

to different locations, sitting on a chair, as well as ac-

tually presenting and discussing. A presentation can

only start when the other persons are seated. To re-

strict the model, it was assumed uncommon to change

seats and walk to different locations, so a person was

only allowed to walk once before and between pre-

sentations.

We checked two domain-speciﬁc invariants and

one unrepeatable action property: (1) at most one

person is presenting, (2) when presenting, all oth-

ers are seated, and (3) a person never presents twice.

All properties were satisﬁed, no livelock was present,

but one deadlock could be found. The deadlock was

caused by the way walking (e.g. to seats) has been

implemented. When the people enter the room they

independently execute the action “walk to seat x”.

The deadlock happens if all persons execute the same

action and go to the same seat, which is possible as the

seat is still empty. When the persons arrive, only one

can sit down, and the others could not move because

walking was allowed only once.

Two options exist to remove the deadlock: reduce

behaviour that leads to the deadlock or add behaviour

to escape it. Reducing behaviour would require the

persons to negotiate where to seat, which seems rather

unnatural and complicates modelling even more. Al-

lowing additional walking ﬁxes the deadlock, but in-

creases the state space to 49,765 states, making it

rather costly.

4.2 The Ofﬁce Domain

A room contains a printer and a coffee machine that

people want to use concurrently. The model contains

ICAART2015-InternationalConferenceonAgentsandArtificialIntelligence

500

Table 1: Comparison of model complexity in terms of actions, boolean state variables, and state space size.

Model PDDL actions ground actions state variables states

meeting (3 persons) 10 150 104 31,372

ofﬁce (3 persons) 9 124 43 1,957,158

kitchen (1 person)

44 99 60 146,552,922

actions for entering and exiting the room and walk-

ing to different locations. Paper and ground coffee

are resources that can be taken (only one at a time if

the hands are free) from different locations and used

to reﬁll the printer or coffee machine. A paper jam

may occur, which must be repaired before printing is

possible.

We checked the following properties with respect

to a single agent: (1) no hands are free if and only if

some object is held, (2) when holding something it is

possible to get the hands free, and (3) it is always pos-

sible to leave the room. These properties are example

of an invariant (covering different state variables), an

intuitive assumption, and of ensuring repeatability of

an action.

The second property was violated, no additional

deadlocks or livelocks have been found. Here, the

agent could get some ground coffee for the coffee ma-

chine, reﬁll the coffee machine, and get some addi-

tional ground coffee. After getting additional ground

coffee, the coffee machine still has resources and the

agent is unable to release the ground coffee from his

hand, allowing him only to walk between different lo-

cations without making any additional progress. A

simple ﬁx is to add an additional “drop” action, al-

lowing to put resources back.

4.3 The Kitchen Task

A single person prepares and eats a carrots soup. This

model comprises detailed actions in the process of

preparing and eating a carrots soup as well as clean-

ing afterwards. The actions respect several causal re-

lations, such as an object can only be taken if at least

one hand is free, and cutting the carrot is only possi-

ble when a knife is in a hand and the carrot is on a

cutting board.

The properties we checked included an invariant

and two long-term causations: (1) there is exactly

one of the propositions true that zero, one, or two

hands are free, (2) when a person is not hungry he

has cooked, and (3) when eating, the person is seated

and at the table. While the ﬁrst two properties were

true, the last indeed turned out to be false. The model

allowed to eat without seating, it was sufﬁcient to just

stand at the table.

No deadlocks were present in the model, but a

livelock could be found. As a precondition for the

cook action, the spoon had to be in the hand. But in

case the spoon was in the pot before cooking, it was

impossible to remove the spoon, as the respective ac-

tions were too restrictive. In this case two ﬁxes are

possible. Either the actions could be relaxed to allow

the spoon to be removed from the pot. Or the action

could be restricted even more, preventing to put the

spoon in the pot before ﬁnishing cooking. While the

ﬁrst option does not change the size of the state space,

the second slightly decreases its size to 145 million

states.

5 CONCLUSION

Model-based approaches to activity recognition re-

quire sound models. Model checking helps ﬁnding

modelling errors and is therefore supposed to im-

prove recognition rates. Improper models can not

only have negativeimpact on recognition results, they

can possibly lead to wrong, possibly harmful, de-

cisions. We presented a short case study of mod-

elling errors found in activity recognition models. As

a guide for practitioners and model developers, we

identiﬁed and discussed important classes of sensible

properties to identify modelling inconsistencies and

errors, and how they may impact activity recognition.

Future work includes a detailed survey of impor-

tant property classes, making it easier to formulate

sensible properties. Currently, we employed an exter-

nal model checking tool. An integrated, continuous

tool support has to developed, which is presumed to

ease model development.

ACKNOWLEDGEMENTS

This research is supported by the German Research

Foundation (DFG) within the research training group

GRK 1424 MuSAMA (Multimodal Smart Appliance

Ensembles for Mobile Applications).

REFERENCES

Aggarwal, J. K. and Ryoo, M. S. (2011). Human activ-

ity analysis: A review. ACM Computing Surveys,

43(3):16:1–16:43.

CheckingModelsforActivityRecognition

501

Chen, L., Hoey, J., Nugent, C. D., Cook, D. J., and Yu, Z.

(2012). Sensor-based activity recognition. Systems,

Man, and Cybernetics, Part C: Applications and Re-

views, IEEE Transactions on, 42(6):790–808.

Cimatti, A., Pistore, M., Roveri, M., and Traverso, P.

(2003). Weak, strong, and strong cyclic planning

via symbolic model checking. Artiﬁcial Intelligence,

147(1-2):35–84.

Clarke, Jr., E. M., Grumberg, O., and Peled, D. A. (1999).

Model Checking. MIT Press.

Fox, M. and Long, D. (2003). PDDL2.1: Expressing tem-

poral planning domains. Journal of Artiﬁcial Intelli-

gence Research, 20:61–124.

Gromyko, A., Pistore, M., and Traverso, P. (2006). A tool

for controller synthesis via symbolic model check-

ing. In Discrete Event Systems, 2006 8th International

Workshop on, pages 475–476.

Hiatt, L. M., Harrison, A. M., and Trafton, J. G. (2011).

Accommodating human variability in human-robot

teams through theory of mind. In Proc. of the Int. Joint

Conference on Artiﬁcial Intelligence, pages 2066–

2071.

Hoey, J., Plötz, T., Jackson, D., Monk, A., Pham, C.,

and Olivier, P. (2011). Rapid speciﬁcation and auto-

mated generation of prompting systems to assist peo-

ple with dementia. Pervasive and Mobile Computing,

7(3):299–318.

Koller, D. and Friedman, N. (2009). Probabilistic Graphi-

cal Models. MIT Press.

Krüger, F., Nyolt, M., Yordanova, K., Hein, A., and Kirste,

T. (2014). Computational state space models for activ-

ity and intention recognition. A feasibility study. PLoS

One.

Krüger, F., Steiniger, A., Bader, S., and Kirste, T. (2012).

Evaluating the robustness of activity recognition using

computational causal behavior models. In Proc. ACM

Conference on Ubiquitous Computing, pages 1066–

1074.

Krüger, F., Yordanova, K., Hein, A., and Kirste, T. (2013).

Plan synthesis for probabilistic activity recognition. In

Proc. 5th ICAART, pages 283 – 288.

Kwiatkowska, M., Norman, G., and Parker, D. (2011).

PRISM 4.0: Veriﬁcation of probabilistic real-time sys-

tems. In Proc. 23rd Int. Conference on Computer

Aided Veriﬁcation, volume 6806, pages 585–591.

Lara, Ó. D. and Labrador, M. A. (2013). A survey on human

activity recognition using wearable sensors. Commu-

nications Surveys Tutorials, IEEE, 15(3):1192–1209.

Magherini, T., Fantechi, A., Nugent, C. D., and Vicario,

E. (2013). Using temporal logic and model check-

ing in automated recognition of human activities for

ambient-assisted living. Human-Machine Systems,

IEEE Transactions on, 43(6):509–521.

Meyer, B. (1992). Applying “design by contract”. Com-

puter, 25(10):40–51.

Ramírez, M. and Geffner, H. (2010). Probabilistic plan

recognition using off-the-shelf classical planners. In

Proc. AAAI-10, 24th Conf. Artiﬁcial Intelligence.

Yordanova, K. and Kirste, T. (2014). Towards systematic

development of symbolic models for activity recogni-

tion in intelligent environments. In Proc. 3rd Work-

shop on AI Problems and Approaches for Intelligent

Environments, held at ECAI 2014.

Yordanova, K., Nyolt, M., and Kirste, T. (2014). Strate-

gies for reducing the complexity of symbolic models

for activity recognition. In 16th International Confer-

ence on Artiﬁcial Intelligence: Methodology, Systems,

Applications.

ICAART2015-InternationalConferenceonAgentsandArtificialIntelligence

502
