Adaptive Buffer Resizing for Efﬁcient Anonymization of Streaming Data

with Minimal Information Loss

Aderonke Busayo Sakpere and Anne V. D. M. Kayem

Department of Computer Science, University of Cape Town, Cape Town, South Africa

Keywords:

Data Anonymity, Streaming Data, Crime Reporting, Privacy Enhancing Model, k-Anonymity, Information

Loss.

Abstract:

Mobile crime reporting systems have emerged as an effective and efﬁcient approach to crime data collection

in developing countries. The collection of this data has raised the need to analyse or mine the data to deduce

patterns that are helpful in addressing crime. Since data analytic expertises are limited in developing nations,

outsourcing the data to a third-party service provider is a cost effective management strategy. However, crime

data is inherently privacy sensitive and must be protected from “honest-but-curious” service providers. In or-

der to speed up real time analysis of the data, streaming data can be used instead of static data. Streaming data

anonymity schemes based on k-anonymity offer fast privacy preservation and query processing but are reliant

on buffering schemes that incur high information loss rates on intermittent data streams. In this paper, we pro-

pose a scheme for adjusting the size of the buffer based on data arrival rates and use k-anonymity to enforce

data privacy. Furthermore, in order to handle buffered records that are unanonymizable, we use a heuristic that

works by either delaying the unanonymized record(s) to the next buffering cycle or incorporating the record(s)

into a cluster of anonymized records with similar privacy constraints. The advantage of this approach to

streaming-data anonymization is two-fold. First, we ensure privacy of the data through k-anonymization, and

second, we ensure minimal information loss from the unanonymized records thereby, offering the opportunity

for high query result accuracy on the anonymized data. Results from our prototype implementation demon-

strate that our proposed scheme enhances privacy for data analytics. With varied data privacy requirement

levels, we incur an average information loss in delay of 1.95% compared to other solutions that average a loss

of 12.7%.

1 INTRODUCTION

Streaming data are real-time and continuous data

ﬂows that are ordered implicitly by arrival time or

explicitly by timestamps. Examples include phone-

calls and network monitoring. Mining continuous

data streams is useful because it enables data hold-

ers or organizations to learn hidden knowledge and

patterns through analyzing the data. For instance, in

newly industrialized countries law enforcement agen-

cies are encouraging users to report crime covertly

via electronic crime reporting systems based on mo-

bile phone technology (Mark-John and Kayem, 2014;

Jensen et al., 2012; CryHelp-App, 2014). Real-time

data analysis is important in enabling these agen-

cies address reported crime more effectively and ef-

ﬁciently. However, often times these law enforce-

ment agencies are not equipped with the on-site ex-

pertise required to analyze the data efﬁciently in real-

time. It is therefore a cost-effective strategy to transfer

streaming crime data to a third party service provider

(Qiu et al., 2008).

Since crime data is inherently privacy sensitive,

it makes sense to ensure that the outsourced data

is protected from all unauthorized access including

that of an “honest-but-curious” data mining service

provider. Cryptographic techniques have been stud-

ied for protecting outsourced data from unauthorized

access but have been shown to create a high over-

head in terms of querying and updates, making an-

alyzing large volumes of data in real-time is a time

consuming process (Vimercati et al., 2010; Kayem

et al., 2011). Other privacy preserving techniques for

big data include those based on differential privacy.

However, differential privacy techniques are better

suited to static repositories as opposed to smaller sizes

of streaming data (Dwork, 2006). Anonmyization

schemes are a better alternative than cryptographic

and differential privacy approaches to protecting the

privacy of streaming data because of the time sensi-

tivity of the data (Guo and Zhang, 2013). Most exist-

ing streaming data anonymization schemes are based

191

Busayo Sakpere A. and V. D. M. Kayem A..

Adaptive Buffer Resizing for Efﬁcient Anonymization of Streaming Data with Minimal Information Loss.

DOI: 10.5220/0005288901910201

In Proceedings of the 1st International Conference on Information Systems Security and Privacy (ICISSP-2015), pages 191-201

ISBN: 978-989-758-081-9

 2015 SCITEPRESS (Science and Technology Publications, Lda.)

on the k-anonymity technique for privacy preserva-

tion. This is because k-anonymity techniques offer a

simple and effective approach to producing data with

integrity (Bayardo and Agrawal, 2002). K-anonymity

achieves privacy preservation by using generalization

and suppression to ensure record indistinguishability

(Sweeney, 2002).

As a result of rapid change in streaming data, there

is a need for anonymization to happen fast with mini-

mal delay. Failure to keep up with the changes in data

stream during anonymization may lead into informa-

tion loss (Guo and Zhang, 2013).

1.1 Motivation and Problem Statement

Streaming data anonymization algorithms rely on

buffering mechanisms to hold the data temporar-

ily while it is anonymized (Guo and Zhang, 2013;

Cao et al., 2008; Zhang et al., 2010). Typically,

anonymization of data streams require an optimal

buffer size in order to enhance privacy preservation.

However, intermittent data streams make determin-

ing an adequate buffer size to guarantee effective

anonymization a challenge.

To determine the buffer size for effective

anonymization, existing k-anonymization schemes

arbitrarily choose an integer number to represent the

number of records needed for effective anonymiza-

tion. For instance, if the buffer size is set to 20

records, this implies that anonymization will only be-

gin when there are 20 records in the buffer. This

approach delays anonymization and so results in a

high degree of information loss in scenarios involv-

ing delay-sensitive data especially if the data stream

is slow as may be the case in crime-reporting.

Zakerzadeh and Osborn, 2013 have shown that

count-based buffering approaches (like the one we

have just described) can incur record expiry rates

of as high as 61.3%. This is not desirable for de-

lay sensitive scenarios where both the privacy of the

anonymized data as well as accuracy in query results

are important. Furthermore, in crime reporting sce-

narios, the time-sensitivity of the records requires that

the data analytics service provider is provided with

a comprehensive privacy preserving dataset that can

be analysed efﬁciently in real-time in order to ensure

query result accuracy.

The problem we seek to address therefore, is that

of coming up with an approach to resizing the buffer

to ensure efﬁcient streaming data anonymization (for

privacy preservation) with minimal information loss

(for query accuracy) in a delay or time-sensitive con-

text such as one involving reported crime data. In the

next sub-section, we brieﬂy present our approach to

addressing this problem.

1.2 Contribution

We propose an adaptive buffer resizing scheme to

minimize record suppression and information loss

due to delay during anonymization of intermittent

streaming data.

Firstly, we model our buffering mechanism as a

time-based tumbling sliding window because of the

time-sensitivity of crime data. The buffer size and rate

of arrival of the streaming crime data affect the rate of

information loss and the levels of privacy offered by

the anonymization scheme.

Secondly, we develop a solution to adaptively re-

adjust the size of the sliding window based on the ar-

rival rate of data that follows a Poisson process.

As a further step, we employ a time-based met-

ric in evaluating the data records to prioritize process-

ing (anonymizing) records that are nearing expiry. We

handle this by either including the selected record(s)

in a subsequent sliding window (buffer) or including

the record(s) into a reusable anonymity cluster.

Results from our prototype implementation

demonstrate that in addition to enhancing privacy of

the data, our proposed scheme outperforms previous

schemes with an average information loss of 1.95%.

1.3 Outline

The rest of the paper is structured as follows. In

Section 2, we present related work highlighting the

weaknesses of existing data stream anonymization

schemes. Section 3, presents our proposed dynamic

buffer sizing solution using the Poisson probability

distribution and the time-based tumbling sliding win-

dow. The arrival rate of data that follows a Poisson

process inﬂuences the the size of the the time-based

tumbling sliding window. In Section 4, we present

results from our implementation and conclude in Sec-

tion 5.

Other domain where the application of our Pois-

son Model concept to k-anonymity can be applied

include stock companies and hospitals. For exam-

ple, a stock company needs to investigate its sales

daily in order to adjust stock or marketing strategy

promptly and a hospital needs to release its daily med-

ical records for research purpose.

2 RELATED WORK

Proposed k-anonymity schemes for handling stream-

ing data use the concept of a sliding window or buffer

ICISSP2015-1stInternationalConferenceonInformationSystemsSecurityandPrivacy

192

to temporarily store data based on a pre-deﬁned pro-

cessing delay constraints such as time or record-count

(Patroumpas and Sellis, 2006; Li et al., 2008; Guo

and Zhang, 2013; Zhang et al., 2010; Zakerzadeh

and Osborn, 2011; Zakerzadeh and Osborn, 2013;

Cao et al., 2008). Processing delay constraints en-

sure that information loss (delay) is minimized while

the buffer holds the portion of the streaming data to

be anonymized.

The ﬁrst reported algorithm that considers k-

anonymity on streaming data for privacy protection

is Stream K-anonYmity (SKY) (Li et al., 2008). The

algorithm searches the specialisation tree to ﬁnd the

most speciﬁc node that generalises a new record.

SKY needs a specialization tree even for anonymizing

numerical values which makes anonymization pro-

cess more tedious because of the difﬁculty in ﬁnding

a suitable hierarchy on the tree (Zakerzadeh and Os-

born, 2013).

Continuously Anonymizing STreaming data via

adaptive cLustEring (CASTLE) solves the aforemen-

tioned deﬁciency of SKY which emerges as a re-

sult of using specialization tree for its anonymization

through the use of a clustering process. CASTLE re-

lies on the count-based delay constraint for impos-

ing constraints on the size of the buffer (Cao et al.,

2008). However, one of the key challenges that CAS-

TLE faces is that of determining an optimal bound on

the number of records to which the buffer needs to

be constrained. Furthermore, since the buffer size is

ﬁxed at runtime, CASTLE fails to handle changing

speeds of streaming data ﬂows effectively.

Other data stream anonymization tech-

niques/algorithms that use a similar delay-

constraint approach to that of CASTLE include

K-anonymIzation Data Stream based on sliding

window (KIDS) (Zhang et al., 2010), Fast clustering-

based k-Anonymization approach for Data Streams

(FADS) (Guo and Zhang, 2013) and B-CASTLE

(Wang et al., 2010).

The Fast Anonymizing Algorithm for Numerical

STreaming data (FAANST) addresses the challenge

inherent in CASTLE inspired approaches by delay-

ing the start of the anonymization process until the

buffer is full (Zakerzadeh and Osborn, 2011). This

allows for batching in terms of outputing results and

recycling of records that the scheme was unable to

anonymize during a given batch of data. A major

drawback of FAANST is that time-sensitive records

that are withheld and recycled may expire. The con-

sequence of this is that such expired records lead to

high information loss.

The delay-sensitive FAANST scheme addresses

the issue in FAANST with a user-deﬁned soft dead-

line for processing each record in the buffer (Zak-

erzadeh & Osborn, 2013). A major drawback of

the delay-sensitive FAANST scheme is that there is

no way of deciding whether or not unanonymizable

records would be anonymizable during the next slid-

ing window. So a record can get repeatedly recy-

cled until it actually expires. Another drawback of

the delay-sensitive FAANST is that the veriﬁcation

of record expiration generates additional performance

overhead (Zakerzadeh & Osborn, 2013).

A detailed survey of existing data stream

anonymization algorithms in relation to reported

crime streaming data is given in (Sakpere and Kayem,

2014). It is clear from current literature in data stream

anonymization that the issue of adaptive buffer resiz-

ing in order to minimize information loss in terms of

delay and to avoid expiration of records still needs to

be addressed. Minimizing information loss in terms

of delay is important in generating anonymized re-

ported crime data that is shared with third party ser-

vice providers. It is important to anonymize data be-

cause it protects users’ data (Sweeney, 2002). The

next section describes our proposed solution.

3 ADAPTIVE BUFFER RE-SIZING

SCHEME

In this section, we present our proposed adaptive

buffer re-sizing approach. The buffer size and rate

of arrival of the streaming data affect the rate of in-

formation loss and the levels of privacy offered by

the anonymization scheme. In order to minimize in-

formation loss we use a time-based tumbling sliding

window to adjust the size of the buffer with respect to

the arrival rate of the data.

3.1 Buffer Streaming Data

This section explains the concept of sliding window

as illustrated in Figure 1.

A Data Streams, DS, is deﬁned as a real-time

and continuous data ﬂow ordered implicitly by arrival

time or explicitly by timestamps.

Deﬁnition 1: A sliding window, say sw

, is a sub-

set of the data stream, DS where DS = {sw

, sw

,..., sw

} implies that DS consists of a set of m

sliding windows.

The sliding windows obey a total ordering such

that for every i < j, sw

precedes sw

. Each slid-

ing window, sw

, only exists for a speciﬁc period of

time T and consists of a ﬁnite and varying number of

records, n, such that sw

= R

, ..., R

n−1

AdaptiveBufferResizingforEfficientAnonymizationofStreamingDatawithMinimalInformationLoss

193

Crime data reported by a rst or third party,

electronically to a law enforcement agency

Third Party Data Analytics

Service Provider

Figure 1: Overview of Buffer Resizing Process.

We use Poisson probability model to predict the

rate of data ﬂow in the next sliding window, sw

i+1

based on the rate of ﬂow in a previous sliding window,

. We opted to use a Poisson model because the

Poisson distribution is concerned with the number of

success that an event occurs in a given unit of time.

This property of the Poisson model makes viewing

the arrival rate of the reported crime data as a series

of events occurring within a ﬁxed time interval at an

average rate that is independent of occurrence of the

time of the last event (Li, 2006). Only one parameter

needs to be known: the rate at which the events occur,

which in our case is the rate at which crime reporting

occurs.

3.2 Preliminaries

In this section, we present our proposed approach to

addressing the adaptive buffer re-sizing problem. The

buffer size and rate of arrival of the streaming crime

data affect the rate of information loss and the levels

of privacy offered by the anonymization scheme.

To better understand how our scheme works, we

divide our adaptive buffer sizing scheme into six

phases namely: Initial Buffer Size, Reduction of In-

formation Loss, Inclusion of Suppressed Records into

the Next Sliding Window, Determination of Arrival

Rate, Possible Optimal Sizes for the Next Sliding

Window using Poisson Probability Distribution and

Final Decision on the Size of the Next Sliding Win-

dow.

3.2.1 Phase 1: Initial Buffer Size

Let T be the time for which a sliding window, sw

exists, where T is a time value that is bounded by a

lower bound value, t

, and an upper bound value, t

then:

1 k-anonymization algorithm is applied to the data

that was collected in the sliding window, sw

, dur-

ing the period T

2 Essentially sw

= T

3 All records that are not anonymizable from the

data collected in sw

are suppressed or excluded

from the dataset released for publication

We begin by setting the size of the buffer to

some initial threshold value, T. For example, in

previous work (Zakerzadeh and Osborn, 2013),

values between 2000ms and 5000ms have been used

as the time interval in which a record can stay in the

buffer. In line with our threshold value, t

= 2000ms

and t

= 5000ms.

Example 1: Consider the dataset provided in Table 1

that has a time deﬁned size of 5000ms for a sliding

window, sw

. This implies that the k-anonymization

algorithm is applied to the data that was collected

in the sliding window, sw

, during the period T =

5000ms. The anonymization process was handled

with a k-anonymity scheme in which we used k = 3 as

the anonymization metric. We chose k = 3 because of

the small data set which consists of only 10 records.

A higher value of k will lead to higher information

loss. All records that are not anonymizable from the

data collected in sw

are suppressed (excluded) from

the dataset released for publication.

To achieve anonymization on Table 1 we used the

crime taxonomy tree in Figure 2 by clustering records

that belong to the same parent node and this results in

Table 2.

Figure 2: Crime Taxonomy Tree.

3.2.2 Phase 2: Reduction of Information Loss

Let C be a set of anonymized clusters where C = {c

, c

,..., c

}. A cluster is anonymized if it satisﬁes

the k-anonymity requirements. k-anonymization al-

gorithm requires that records be classiﬁed into clus-

ICISSP2015-1stInternationalConferenceonInformationSystemsSecurityandPrivacy

194

Table 1: Data for Sliding Window, T = sw

= 5000ms; T

80ms.

Record

Reported

Crime

Age WaitingTime

= T

1 Vandalism 60 4782

2 Murder 20 4017

3 Theft 50 3361

4 Corruption 60 2566

5 Rape 30 2118

6 Burglary 70 2069

7 Forgery 35 1492

8 Arson 40 1214

9 Drunken

Driving

50 417

10 Robbery 40 100

Table 2: Results for k-anonymization of sw

, k = 3 and T =

5000ms.

Cluster 1 Cluster 2 Cluster 3

(Violent

Crime, 20-40)

(Misdemeanors,

35 - 50)

(Property

Crime, 40-70)

2 7 1

5 9 3

10 4

ters of at least size k, such that each record in the

cluster is indistinguishable from at least k-1 records.

A record, R

, is unanonymizable or suppressible if it

does not ﬁt into any of the cluster in set C.

This second phase attempts to reduce infor-

mation loss that is likely to occur as a result of

suppressed/unanonymizable records in Phase 1. In

order to minimize the rate of information loss due

to the unanonymizable records, we either include

these unanoymizable records in a subsequent sliding

window, say sw

i+1

, or incorporate them into already

anonymized clusters (reusable cluster) of data that

are similar in terms of content. We describe a

reusable anonymity cluster as one that has success-

fully published a set of anonymized records whose

privacy and information loss levels are not negatively

impacted by the inclusion of the suppressed record(s).

Example 2: Searching the output of the k-

anonymization process in phase 1 i.e. Table 2

for unanonymizable/suppressed records, we note that

records with ID 7 & 9, i.e. R

and R

are not

anonymizable with the dataset in the current sliding

window sw

because the group of records they are

categorized into does not contain sufﬁcient records to

meet the k-anonymity requirement of k = 3. There-

fore, we need to decide whether to process the records

and R

in the next sliding window sw

or whether

to ﬁnd an appropriate reusable cluster into which to

incorporate the records instead.

3.2.3 Phase 3: Inclusion of Suppressed Records

into the Next Sliding Window

Let sw

be the time-size of the previous sliding win-

dow, let T

be the time for which a suppressed Record,

was stored in a previous sliding window, sw

, and

is the time it took to carry out anonymization in

the previous window, sw

. We therefore compute the

expiry time of R

as follows:

= sw

− T

...(1)

In order to determine whether or not a suppressed

record can be included in a subsequent sliding

window, say sw

i+1

, we compute its expiry time T

using equation 1 and compare the value of T

the bounds for acceptable sliding window sizes [t

Example 3: From Table 2, records R

and R

are

unaonymizable. In order to determine whether or

not to include these records into the next sliding win-

dow, sw

, we compute the remaining time T

) of

both records and compare both values to the bounds

for acceptable sliding window sizes. From Table

1, T

= 5000 and T

= 80. We therefore compute

) using equation 1 by subtracting T

and T

from

= T which in this case gives T

) = sw

−

−T

= 5000 −1492−80 = 3428ms and T

) =

− T

= 5000 − 417 − 80 = 4503ms. Given

that t

= 2000ms and t

= 5000ms, it follows that

≤ T (R

), T (R

) ≤ t

and we can conclude that it

makes sense to incorporate R

and R

into sliding

window sw

3.2.4 Phase 4: Determination of Arrival Rate

Let U be a set of unanonymized clusters of an

anonymization process where U = {u

, u

,..., u

A cluster is unanonymized if it does not satisfy k-

anonymity requirement.

Starting with the unanonymizable cluster that

has the suppressed record, R

, with the lowest T

and whose value falls within the acceptable slid-

ing window bound, [t

], the algorithm checks for

other suppressed records that belong to the same

unanonymized cluster, u

, as R

. We then proceed to

ﬁnd the rate of arrival, λ, of data in that unanonymized

cluster u

, within the time interval, sw

and com-

pute the expected arrival rate of records required to

AdaptiveBufferResizingforEfficientAnonymizationofStreamingDatawithMinimalInformationLoss

195

anonymize R

within its expiry time, T

using equa-

tion 2.

λ =

+|u

× T

...(2)

Example 4: In order to decide on what the optimum

size of sw

should be set to, we consider the expiry

time, T

, of the suppressed records in sw

. Since T

3428ms for R

and 4508ms for R

, sw

= 5000ms

and k = 3 is being used as the k-anonymization met-

ric and both records (R

and R

) fall under the gener-

alization attributes of (Crime = “misdemeanors”) and

(Age = “35 - 50”), therefore we require that at least

1 similar record arrive during sw

in order to ensure

that anonymization succeeds and thereby avoiding in-

formation loss from record expiry due to failure to

anonymize the records. Starting with the least T

3428, we compute λ

i+1

= λ

for R

as follows:

Number of Records

× T

5000

× 3428

gives λ

= 1.37 .

3.2.5 Phase 5: Optimal Size for the Next Sliding

Window using Poisson Probability

Let λ be the expected arrival rate of data in an

unanonymized cluster, u

, in a sliding window, sw

and n is the number of records u

required to undergo

proper anonymization. Then, the probability that an

unanonymizable/suppressed record R

in u

would be

anonymized in the next sliding window, sw

i+1

, can be

calculated using equation 3

f (sw

i+1

, λ) = Pr (i = 0 .... n) =

−λ

...(3)

where λ is the expected data arrival rate, e is the base

of the natural logarithm (i.e. e = 2.71828), n is the

total number of observation and i is the number of

records under observations. Therefore the probabil-

ity of having n or greater than n records arrive in the

stream within time T

1 −

n−1

∑

i=0

Pr ...(4)

where Pr is the probability outcome of equation 3.

The expected arrival rate, λ, from phase 4 is then

used to determine the probability of arrival of the

minimal number of records, n, we require in order

to guarantee that delaying the anonymization of the

suppressed record, R

, to the sliding window sw

i+1

will not adversely increase information loss. We

achieve this by ﬁnding the probability that n records

will actually arrive in the data stream within time,

, in order to anonymize the suppressed record, R

We use the expression in equation 3 to compute the

probability of having i = 0...n records arrive in the

stream within the period T

and equation 4 to ﬁnd

out the probability that n or more than n records will

arrive in the stream within T

Example 5: From example 4, the number of

unanonymizable records in the unaonymizable cluster

(“misdemeanors”, “35 - 50”) is 2 i.e. R

and R

. Sub-

stituting λ

= 1.37 into equation 3 and subsequently

into equation 4, we ﬁnd the probability Pr (≥ 1 record

belonging to group 2 arrive in the next 3428 seconds)

= 1 - Pr (0) = 1 - 0.25 = 0.75.

3.2.6 Phase 6: Final Decision on the Size of the

Next Sliding Window

Let δ be a pre-set probability threshold and Pr be the

result of equation 4. If Pr ≥ δ then the size of the next

sliding window, sw

i+1

, is set to the expiry time of the

suppressed record under consideration in equation 4.

If the result of equation 4 from phase 5 is greater

than a pre-set probability threshold, δ, we set the size

of the subsequent sliding window, sw

i+1

, to the expiry

time of the suppressed record under consideration.

We then mark the suppressed record for inclusion

in sw

i+1

along with other suppressed records that

have their T

within bounds for acceptable sliding

window sizes [t

]. If the probability is less than

the pre-set probability threshold, δ, we anonymize

the suppressed records using a reusable cluster and

calculate the size of sw

i+1

using the next suppressed

record whose T

lies within the bounds [t

]. In the

event that the probability of all suppressed records

is less than δ, we set the size of sw

i+1

to a random

number or some initial threshold value within the

time bound, [t

]. Finally, in order to decide into

which reusable data cluster to include a suppressed

record, R

, our model searches for the cluster that

covers the record and has the least information loss.

Example 6: The output of example 5 is 0.75. This

implies that there is a high likelihood of having one or

more records belonging to group 2 (where records R

and R

belong) arrive within the next 3428ms. There-

fore the existence time (size) of the next sliding win-

dow, sw

= 3428ms.

ICISSP2015-1stInternationalConferenceonInformationSystemsSecurityandPrivacy

196

Algorithm 1: SWET (i,K).

1: for each sliding window sw

, i:1 ...m do

2: if ((sw

== 1)||(SuppRec == φ)) then

3: sw

iExistTime

← T

4: else

5: sw

iExistTime

← RSWET (T

, T

, i, SuppRec)

6: end if

7: T

← Anonymization Processing Time

8: SuppRec ← Suppressed Records

9: T

← Remaining Time of Suppressed Records

10: Update Reusable Cluster (RC)

11: end for

Algorithm 2: RSWET(T

, T

, i, SuppRec).

1: Sort: Sort T

in ascending order and group by

unanonymizable cluster

2: for j:1 ...|SuppRec| do

3: if T

- T

< T

then

4: Anonymize SuppRec

using RC

5: Delete SuppRec

6: else

7: Calculate arrival rate, λ, of SuppRec

in the

sliding window, sw

8: Find the Probability, P, of successful

anonymization in sw

9: end if

10: if P or λ > δ then

11: ExistTime

← T

− T

12: Add SuppRec to sw

13: break

14: else

15: anonymize SuppRec

using RC

16: delete SuppRec

from SuppRec

17: end if

18: end for

19: if P or λ for all suppressed records < δ then

20: ExistTime

← T

21: end if

22: return ExistTime

3.3 Buffer Resizing: Algorithm

From the discussions in subsection 3.2, our frame-

work for the Buffer Re-sizing anonymization of data

streams can be summarized as follows:

Procedure Sliding Window Existence Time

(SWET) has two parameters: i which is the ith sliding

window under consideration and k is the k-anonymity

requirement. Step 3 determines when to launch the

ﬁrst sliding window, sw

, by randomly selecting its

existence time, T, within the time bound [t

] i.e.

≤ T ≤ t

. Apply k-anonymization algorithm to the

data collected in the sliding window during the period

T . Step 5 call on procedure RSWET to determine

when to launch a sliding window, sw

, where i ≥

2. Step 7 computes the processing time used for

carrying out k-anonymization. Step 8 search for

unanonymizable/suppressed records sorted by their

remaining time, T

, and group by their unaonymized

cluster. If no suppressed records exist, then randomly

select existence time, T, for the next sliding window

from [t

Procedure Reset Sliding Window Existence Time

(RSWET) has four parameters: T

which is a set that

contains Remaining Time of all Suppressed Records,

is the time required to carry out anonymization

process, i is the ith sliding window under consider-

ation and SuppRec is a set that contains Suppressed

Records. RSWET starts by sorting T

of each sup-

pressed records in ascending order. If there exists

suppressed records/an unanonymized cluster whose

− T

≤ T

, then the reusable cluster will be used

for its anonymization. Reusable cluster is a data struc-

ture of anonymized records whose privacy and infor-

mation loss levels are not negatively impacted by the

inclusion of the suppressed record. Otherwise, start

with the suppressed record/group that has the least

. Then ﬁnd the probability, P, that if such record(s)

is/are included in the sliding window, sw

, under con-

sideration, it will be successfully anonymized before

it expires.

If the λ or P result is greater than a threshold, δ,

the sliding window size will be set to T

− T

where

is the remaining time of the suppressed record un-

der consideration. Otherwise, the algorithm fetches

the next suppressed records. In the event that the

value of λ or P for all suppressed records under con-

sideration is less than the threshold, δ, the algorithm

randomly select its existence time, T, within the time

bound [t

] i.e. t

≤ T ≤ t

4 IMPLEMENTATION AND

RESULTS

The proposed framework was implemented on an In-

tel Core i5-3210 2.50 GHz machine with 4GB of

random access memory (RAM). The operating sys-

tem used was Ubuntu 12.10 and the CSE 467 k-

anonymization implementation

was integrated into

our adaptive buffering scheme using JAVA NetBeans

IDE 7.0.1.

In order to simulate streaming data, we used the

http://code.google.com/p/cse467phase3/source%20/

browse/trunk/src/Samarati.java?r=64

AdaptiveBufferResizingforEfficientAnonymizationofStreamingDatawithMinimalInformationLoss

197

ﬁle input stream functions in java that enabled data

to be read in real-time from an external source data

ﬁle into sliding window at random time interval of

between 1 and 800 milliseconds. We randomized the

time between 1 and 800ms in order to simulate a real-

istic crime report data stream with varying ﬂow rates

noting that this implies some slower report arrival

rates (to mimic peaceful days when crime reports are

few) and faster report arrival rates (to mimic disaster

scenarios when reporting trafﬁc is more bursty). A

MySQL database was used as storage for the sliding

window (buffer) and we assumed that data is read se-

quentially from the external ﬁle into the buffer.

Due to the large data set of crime data needed for

this experiment, we synthetically generated a realistic

crime data set that follows the structure of the Cry-

Help App using a random generator software

. The

CryHelp App is a simple crime reporting application

developed for mobile phones running the Android

Operating System (CryHelp-App, 2014). Figure 3

shows some screenshots from the CryHelp App. The

app was developed in conjunction with the University

of Cape Town Campus Protection Service (CPS). The

app enables users to send crime reports

. The synthet-

ically generated crime dataset contains 1000 records

and nine attributes that deﬁne the reporter’s or vic-

tim’s identity and the reported crime. The attributes

of the dataset are divided into explicit, quasi and sen-

sitive identiﬁers. In order to decide, if a tuple has ex-

ceeded its time-delay constraint, additional attributes

such as arrival time, expected waiting time and entry

time were included in the sliding window.

Figure 3: Screenshots from CryHelp App.

As a baseline case, for evaluating our pro-

posed adaptive buffering scheme we implemented

http://www.mockaroo.com

Further details about the app can be found in

http://cryhelp.cs.uct.ac.za/download

the proactive-FAANST and passive-FAANST. These

algorithms are a good comparison benchmark be-

cause they are the current state-of-the-art stream-

ing data anonymization that reduce information loss

with minimum delay (Zakerzadeh and Osborn, 2013).

The proactive-FAANST decides if an unanonymiz-

able record will expire if included in the next slid-

ing window while passive-FAANST searches for

unanonymizable records that have expired. A major

drawback of these two variants is that there is no way

of deciding whether or not unanonymizable records

would be anonymizable during the next sliding win-

dow. In our experiment, the proactive-FAANST and

passive-FAANST solutions also use the reusable clus-

ter concept as well but do not allow for overlapping of

sliding windows, which our implementation does, nor

do they model the ﬂow rate of reported crime data as

a Poisson process.

Our experiments were conducted to measure the

following: information loss in terms of delay, in-

formation loss in terms of records, gains obtained

from modelling the ﬂow rate of the data as a Poisson

process and using reusable anonymization clusters

to reduce the number of unanonymizable/suppressed

records. We ran the experiment ten different times

and took the average of the results. The entire dataset

size that was used included 1000 tuples with varying

sliding window sizes.

4.1 Effect of Privacy Levels

(k-anonymity Value) on Information

Loss (Delay)

Figure 4 shows the effect of k-anonymity level on in-

formation loss with respect to delay (the number of

expired records). For our experiment, the value of k-

anonymity was varied from the values of 2 to 4. Our

rationale for the choice of these k-values is that Za-

karzadeh and Osborn (2013) use a k-value of 100 for

2000 records, so by analogy in a sliding window of

20 records a minimum k-value of 2 would sufﬁce. We

also ensured that no more than 5 records were sup-

pressed per sliding window in order to achieve privacy

preserving k-anonymization.

As a heuristic, the choice of t

= 2000ms and t

5000ms, is guided by values of delay that are used

in published experimentation results (Zakerzadeh and

Osborn, 2013). The sliding window size for our Pois-

son solution varies between t

and t

. The window size

for passive and proactive solution in our experiment

was chosen to be 8 records. The choice of this value

was based on the number of records that arrive in our

slow data stream within 5000ms. Within 5000ms, as

low as 6-8 records and as high as 20 records were ob-

ICISSP2015-1stInternationalConferenceonInformationSystemsSecurityandPrivacy

198

●

0 50 100 150

Information loss delay against K−value

K=value

Expired tuples (Information loss delay)

2 3 4

●

Poisson Solution

Proactive Solution

Passive Solution

●

Figure 4: Performance comparison: Information loss with

respect to Privacy Levels (expressed by the K-value).

served. We therefore, chose 8 records to minimize

expired tuples.

In general, our approach shows that there are

fewer expired tuples when compared to passive-

FAANST and proactive-FAANST solutions. This is

because before our Poisson prediction transfers sup-

pressed records to another sliding window, it checks

for possibility of its anonymization. In other solu-

tions, there is no mechanism in place to check the

likelihood of the anonymizability of a suppressed

record before allowing it to go to the next sliding win-

dow/round. As a result, such tuples get sent to the

next sliding window and have high tendency to even-

tually expire.

Our solution also shows that the lower a k-value,

the higher the number of expired tuples. This is

because the outcome of Poisson prediction is lower

for higher k-values. As a result, there are fewer

changes of sliding windows as k-value increases and

this means there are fewer possibility of expired tu-

ples.

The main goal of our solution is to reduce infor-

mation loss in delay (i.e. to lower the number of ex-

pired tuples). Figure 4 depicts that our solution is suc-

cessful in achieving its main goal, and the information

loss (delay) in our solution is lower than passive and

proactive solutions. In order to determine the total

number of records that expired, a simple query was

executed to retrieve all records that have stayed in the

buffer longer than the upper limit threshold, t

. To get

the average expired records, we sum up the expired

records in all the experiments and divide by the total

number of experiments.

4.2 Information Loss (Records)

In order to measure the effect of the anonymity degree

and Time-Based Sliding Window on information loss,

we have set k-value to values between 2 and 4, δ i.e.

the Poisson probability threshold to 0.4, and Time-

Based Sliding Window to values between 2000ms and

5000ms. The choice of t

= 2000ms and t

= 5000ms,

is guided by values of delay that are used in pub-

lished experimentation results (Zakerzadeh and Os-

born, 2013). The choice of δ = 0.4 is based on the

various experiments we ran. We varied our δ from

0.4 to 0.6 and had the best output at 0.4.

To calculate information loss with respect to the

number of records i.e. deviation of anonymized data

from its initial form, we used the formula in equa-

tion 5 as it is in (Iyengar, 2002). We adopted this

metric because it is a benchmark in many data stream

anonymization schemes (Cao et al., 2008; Guo and

Zhang, 2013; Zakerzadeh and Osborn, 2013).

InfoLoss =

− 1

M - 1

...(5)

is number of leaf nodes in the subtree at node

P and M is the total number of leaf nodes in the gen-

eralization tree. We calculate the information loss of

a Sliding Window, SW

= {R

, R

,..., R

} as fol-

lows:

∑

i=1

InfoLoss(R

)...(6)

The total information loss of a data stream is sim-

ply calculated by averaging the information loss of all

sliding windows in it.

0.25 0.30 0.35 0.40 0.45

Information Loss Against Time Based Sliding Window

Buffer Existence Time (ms)

Average Information Loss

2000−2999 3000−3999 4000−4999 5000

●

K = 2

K = 3

K = 4

Figure 5: Effect of Sliding Window Size and Privacy Level

Variation (expressed in terms of k-value) on Information

Loss.

AdaptiveBufferResizingforEfficientAnonymizationofStreamingDatawithMinimalInformationLoss

199

Figure 5 shows the effect of applying the time-

based sliding window buffering mechanism and Pois-

son Probability distribution model on information

loss. Here we observe that for smaller sliding win-

dow sizes information loss is lower in comparison to

larger window sizes. One of the reasons for this is be-

cause the Poisson distribution considers unanonymiz-

able records in a sliding window with higher size for

consideration in a sliding window with lower size and

the reusable cluster is more active at the lower sliding

windows. This helps to reduce information loss.

We also observe that as the anonymity degree in-

creases, privacy is enhanced and anonymization qual-

ity or output drops. It therefore implies that an in-

crease in privacy level, k, also leads to increase in in-

formation loss.

4.3 Record Suppression

One of the goals of a good anonymization scheme is

to ensure that information loss is minimal. Records

suppression usually leads to a high information loss.

The combination of the reusable cluster and the Pois-

son distribution helped to minimize the total number

of suppressed records and as a result reduced informa-

tion loss. However, our approach was unable to effec-

tively recover some of the suppressed records because

their deadlines were already exceeded or the sliding

window size prediction for recovering those records

was low and a suitable reusable cluster could not be

constructed before the record expired.

As shown in Figure 6, a higher privacy level of

k-value leads to the recovery of more suppressed

records by the reusable cluster. This is because as the

privacy level (i.e. k-value) increases, it becomes more

difﬁcult to achieve k-anonymization which leads to

increase in suppressed records.

5 CONCLUSIONS

In this paper, we used an adaptive buffer resiz-

ing solution to aid in supporting a privacy preserv-

ing streaming data k-anonymity algorithm by mini-

mizing the rate of information loss from delay and

unanonymized crime data reports. We began with an

overview of the problem scenario which emerges in

developing nations where the lack of data analytics

expertise within a law enforcement agency makes the

need to have a third party data analytics provider in-

tervene to aid in fast crime report analysis. In addi-

tion, we highlighted the fact that the growing need to

make the processed information available to ﬁeld of-

ﬁcers requires a mechanism for capturing crime re-

Effect of K on Reusable Cluster

K−value

Number of Records

0 50 100 150 200

2 3 4

Figure 6: Impact of the Reusable Cluster on Minimizing

Number of Suppressed Records.

ports in real-time and transferring these reports to

the third-party service provider. While solutions in

the literature that are hinged on cryptography have

been shown to be successful in protecting data in out-

sourced scenarios from unauthorized access includ-

ing that of “honest-but-curious” service providers, we

note that querying encrypted streaming data is a time

consuming process and that anonymization is a more

practical approach to data privacy preservation in this

case.

Anonymizing streaming data in a crime report-

ing context however, can have strong real-time re-

quirements and therefore information loss can lead to

faulty or misguided conclusions on the part of the data

analytics service provider. Therefore, streaming data

anonymization algorithms (schemes) need to be sup-

ported by good buffering mechanisms.

Our proposed approach uses the concept of mod-

elling the ﬂow rate of reported crime streaming data

as a Poisson process that guides the sizing of a time-

based sliding window buffer. The data collected in

the buffer is subjected to k-anonymization to ensure

privacy of the data. Results from our prototype im-

plementation demonstrate that in addition to ensuring

privacy of the data, our proposed scheme outperforms

other with an information loss rate of 1.95% in com-

parison to 12.7% on varying the privacy level of crime

report data records.

As future work, we will be extending this work

to design an anonymization algorithm, which is efﬁ-

cient for processing reported crime data or streaming

data that is highly categorical in nature. As well, in

our adaptive buffering algorithm, we did not consider

cases when anonymization might not be possible as

a result of no records or few records in the stream as

may often be the case in a crime data stream, we could

ICISSP2015-1stInternationalConferenceonInformationSystemsSecurityandPrivacy

200

look at applying a perturbative method to anonymiz-

ing the data in this case (Aggarwal and Philip, 2008).

In our experiment, the choice of the threshold for the

probability of having enough requests within a spec-

iﬁed time frame is set to an extrema of the presented

benchmark (Zakerzadeh and Osborn, 2013). For fu-

ture work, further benchmark could be considered in

order to determine if a lower threshold performs bet-

ter. In the future we will also make some inclusion for

plans to work on real datasets. We can achieve this by

carrying out some usability study to collect real data

with the CRY-HELP App.

REFERENCES

Aggarwal, C. and Philip, S. (2008). A general survey

of privacy-preserving data mining models and algo-

rithms.

Bayardo, R. J. and Agrawal, R. (2002). Data privacy

through optimal k-anonymization. In Data Engineer-

ing, 2005. ICDE 2005. Proceedings. 21st Interna-

tional Conference on (pp. 217-228).

Cao, J., Carminati, B., Ferrari, E., and Tan, K. L. (2008).

Castle: Continuously Anonymizing Data Streams.

Dependable and Secure Computing, IEEE Transac-

tions on, 8(3), 337-352.

CryHelp-App (2014). http://people.cs.uct.ac.za/ tndlovu

/(accessed, may 2014).

Dwork, C. (2006). Differential privacy. In Automata, lan-

guages and programming (pp. 1-12).

Guo, K. and Zhang, Q. (2013). Fast clustering-based

anonymization approaches with time constraints for

data streams. Knowledge-Based Systems, Elsevier.

Iyengar, V. S. (2002). Transforming data to satisfy pri-

vacy constraints. In Proceedings of the eighth ACM

SIGKDD international conference on Knowledge dis-

covery and data mining (pp. 279-288).

Jensen, K. L., Iipito, H. N., Onwordi, M. U., and

Mukumbira, S. (2012). Toward an mpolicing solu-

tion for namibia: leveraging emerging mobile plat-

forms and crime mapping. In Proceedings of the South

African Institute for Computer Scientists and Informa-

tion Technologists Conference (pp. 196-205).

Kayem, A. V. D. M., Martin, P., and Akl, S. G. (2011). Ef-

fective cryptographic key management for outsourced

dynamic data sharing environments. In Proc. of the

10th Annual Information Security Conference (ISSA

2011), Johannesburg, South Africa, pp.1-8.

Li, J., Ooi, B. C., and Wang, W. (2008). Anonymizing

streaming data for privacy protection. In Data En-

gineering, 2008. ICDE 2008. IEEE 24th International

Conference on (pp. 1367-1369).

Li, S. (2006). Poisson process with fuzzy rates. In Fuzzy

Optimization and Decision Making, 9(3), pp. 289-305.

Mark-John, B. and Kayem, A. V. D. M. (2014). K-

anonymity for privacy preserving crime data publish-

ing in resource constrained environments. In the

8th International Symposium on Security and Multi-

nodality in Pervasive Environments, (SMPE 2014),

Victoria, Canada - May 13-16, 2014.

Patroumpas, K. and Sellis, T. (2006). Window speciﬁca-

tion over data streams. In Current Trends in Database

TechnologyEDBT 2006 (pp. 445-464).

Qiu, L., Li, Y., and Wu, X. (2008). Protecting business intel-

ligence and customer privacy while outsourcing data

mining tasks. In TEMPLATE’06, 1st International

Conference on Template Production. Knowledge and

information systems, 17(1), pp. 99-120.

Sakpere, A. B. and Kayem, A. V. D. M. (2014). A state of

the art review of data stream anonymisation schemes.

Information Security in Diverse Computing Enviro-

ments, 24. IGI Global, PA, USA., USA.

Sweeney, L. (2002). k-anonymity: A model for protecting

privacy. International Journal of Uncertainty, Fuzzi-

ness and Knowledge-Based Systems, 10 (05), 557-

570.

Vimercati, S. D. C. D., Foresti, S., Jajodia, S., Paraboschi,

S., and Samarati, P. (2010). Encryption policies for

regulating access to outsourced data. ACM Trans.

Database Syst., 35(2), pp. 12:1-12:46.

Wang, P., Lu, J., Zhao, L., and Yang, J. (2010). B-castle: an

efﬁcient publishing algorithm for k-anonymizing data

streams. Proceedings of the 2010 Second WRI Global

Congress on Intelligent Systems, Wuhan, China, 2010,

pp. 132136.

Zakerzadeh, H. and Osborn, S. L. . (2011). Faanst: Fast

anonymizing algorithm for numerical streaming data.

In Data Privacy Management and Autonomous Spon-

taneous Security (pp. 36-50).

Zakerzadeh, H. and Osborn, S. L. (2013). Delay-sensitive

approaches for anonymizing numerical streaming

data. International Journal of Information Security,

1-15.

Zhang, J., Yang, J., Zhang, J., and Yuan, Y. (2010). KIDS:

K-anonymization data stream base on sliding window.

In Future Computer and Communication (ICFCC),

2010 2nd International Conference on (Vol. 2, pp. V2-

311).

AdaptiveBufferResizingforEfficientAnonymizationofStreamingDatawithMinimalInformationLoss

201
