Analysis of Data Quality Problem Taxonomies

Arturs Zogla

, Inga Meirane

and Edgars Salna

National Library of Latvia, Mukusalas 3, Riga, Latvia

Datorzinibu centrs JSC, Lacplesa str. 41, Riga, Latvia

Keywords: Data Quality, Data Anomalies.

Abstract: There are many reasons to maintain high quality data in databases and other structured data sources. High

quality data ensures better discovery, automated data analysis, data mining, migration and re-use. However,

due to human errors or faults in data systems themselves data can become corrupted. In this paper existing

data quality problem taxonomies for structured textual data and several improvements are analysed. A new

classification of data quality problems and a framework for detecting data errors both with and without data

operator assistance is proposed.

1 INTRODUCTION

Errors in data occur for various reasons and are

caused both by human data operators and by mistakes

in information systems themselves. Low quality data

in turn limits the ways it can be searched, analysed,

and re-used. In a wider sense some data quality

problems are not errors. If a database for some

products lists prices in US dollars and for other – in

Euros, this might be considered a data quality issue,

but not necessarily an error.

A lot of research has been done on detecting and

resolving data quality problems. Most of this

research, however, has been on data quality problems

in non-structured or semi-structured data: images,

audio signals, network packets, etc (Chandola V. et.

al., 2009).

These data quality problems are usually referred

to as data anomalies. It has been suggested to group

all data anomalies into three classes (Chandola V. et.

al., 2009):

 point anomalies for individual objects that can be

considered as anomalous relative to other objects;

 context-sensitive anomalies for data that is

anomalous only in certain conditions (freezing

temperatures in summer);

 collective anomalies for several objects that are

anomalous only when viewed together (two

passengers having tickets for the same seat in an

airplane).

This paper focuses on data quality (DQ) problems

in structured textual data like relational databases,

CSV and XML documents. Several attempts have

been made to provide extensive taxonomies of data

quality problems in structured textual data. One such

taxonomy groups data quality problems into a

hierarchy of 33 classes (Kim W., et. al., 2003).

Another taxonomy contains 35 data quality

problem classes grouped by context in which a

particular data quality problem appears (Oliveira P.,

et. al., 2005). The existing research on DQ problems

in structured data, however, has been mostly

theoretical or has been applied for a particular

purpose – as part of data migration, data mining, data

transofrmation, etc.

Therefore, the goal of the research is to apply

existing, theoretically proposed DQ problem

taxonomies to real life data and provide necessary

improvements to DQ problem taxonmy based on real

data errors.

In the research one of the existing DQ problem

taxonomies was chosen and validated against several

databases used at National Library of Latvia. In the

process new error classes were identified.It is also

suggested that some DQ problem classes might be

merged, because of almost identical DQ problem

instances.

445

Zogla A., Meirane I. and Salna E..

Analysis of Data Quality Problem Taxonomies.

DOI: 10.5220/0005462604450450

In Proceedings of the 17th International Conference on Enterprise Information Systems (ICEIS-2015), pages 445-450

ISBN: 978-989-758-097-0

 2015 SCITEPRESS (Science and Technology Publications, Lda.)

2 TAXONOMY OF DATA

QUALITY PROBLEMS IN

STRUCTURED DATA

By analysing different publications of DQ problem

taxonomies (Kim W., et. al., 2003), (Li L., 2011),

(Hernandez M. A., Stolfo S. J., 1998) and (Rahm E.,

Hai Do H., 2000) one was selected as being the most

appropriate for structured textual data (Oliveira P., et.

al., 2005). It provides the most detailed structure with

35 DQ problem classes. It also has a clear and

accessible structure that makes it easy for data

operators to classify individual instances of data

errors.

This taxonomy groups all DQ problems into 6

subgroups by the context in which a particular DQ

problem occurs:

 An attribute value of a single tuple;

 The values of a single attribute;

 The attribute values of a single tuple;

 The attribute values of several tuples;

 Multiple relations;

 Multiple data sources;

For example, a typical DQ problem in “The values

of a single attribute” group was a Synonyms existence

problem, which occurs when several objects contain

different values to express the same concept in a

particular attribute (using both “F” and “Female” as a

value for Gender attribute).

2.1 Validation of Data Quality Problem

Taxonomy

To validate the data quality taxonomy several

databases of National Library of Latvia were chosen.

These databases are considered to be particularly

suitable for collecting DQ problem instances for

following reasons:

 Some of the databases have been around for

more than 20 years;

 Data has been input by many data operators

with different approaches towards how detailed

objects should be described;

 Methodology of describing the same type of

objects has changed many times over the years;

 In some databases little to no data validation

has been enforced;

 Data has been migrated between different

systems and different versions of the same

system.

All of these can be considered as prerequisites for

DQ problems to occur.

2.1.1 Validation Methods

Following databases were selected for testing

purposes (see Table 1).

Table 1: Databases used for validating DQ problem

taxonomies.

Database Number of data

objects

Library’s electronic catalogue 4 100 000

Authority data 205 000

Digital object management system 58 000

Digital collection “Lost Latvia” 30 000

It is worth noting that Library’s electronic catalogue

is integrated with the Digital object management

system. First one describes physical collection of

NLL while the other one – digitized versions of these

objects. This means that multiple data source DQ

problems could also be validated.

Two approaches were used to validate DQ

problem taxonomy: qualitative and quantitative

methods. Qualitative method is used to refer to a

process of identifying as many different DQ problem

class instances as possible. In the best case scenario

this would mean providing at least one example for

each DQ problem class.

To achieve this goal, it was decided to choose the

most likely people to identify different DQ problems

– the most experienced data operators for each of the

selected databases. It was clear that for some DQ

problem classes it will be hard or impossible to find

instances in real data. Mostly, because DQ problems,

if detected, are almost always immediately corrected.

So two kinds of DQ problem instances were allowed:

 Real DQ problems, where data operator could

provide an existing object with a particular DQ

problem;

 Hypothetical DQ problem, where data operator

could only describe or recall an instance of a DQ

problem or suggest a possible scenario of a DQ

problem occurring.

Quantitative method refers to a process of

analysing data and looking for accidental errors and

collecting as many DQ problems as possible. The

reason for doing this kind of analysis was to identify

most prominent and most frequently occurring DQ

problems. Unlike for qualitative method, quantitative

analysis is best performed by data operators relatively

unfamiliar with data sources as they might notice DQ

problems, which an experienced data operators might

overlook. Another reason for doing quantitative

analysis was to possibly identify new DQ problem

classes that didn’t exist in the selected DQ problem

ICEIS2015-17thInternationalConferenceonEnterpriseInformationSystems

446

taxonomy.

2.1.2 National Library of Latvia’s Most

Important Data Quality Problems

By performing qualitative analysis data operators

collected a total of about 200 instances of DQ

problems. Real or hypothetical data errors were found

for almost every DQ problem class from the selected

DQ problem taxonomy with an exception of Different

measurement unit error in a case of multiple data

sources. This data error may occur, for example,

when in case of two related data sources, one uses the

metric system, but the other – imperial measurement

system. Because all data sources at National Library

of Latvia use the same measurement systems no data

errors of this kind were found or even suggested.

However, it is obvious that this error may exist in

other cases and therefor this DQ problem class should

be kept.

One task of qualitative analysis was to determine

how well-founded are each of the DQ problems from

the original taxonomy. It was determined that data

operators often confused several DQ problem classes

and required detailed explanations of the meanings of

these classes. The most frequently confused DQ

problem class pairs were:

 Syntax violation and Misspelled error classes;

 Set violation and Interval violation classes;

 Outdated value and Value items beyond the

attribute context classes.

This suggests that several DQ problem classes

from the original taxonomy might be merged to avoid

misunderstandings in classifying particular instances

of DQ problems.

Quantitative analysis was performed by a

third-party relative to the ownership of data sources.

Their task was to identify DQ problems that stood out

for a person relatively unfamiliar with the data source.

One obvious type of DQ problem that can be

identified this way is the Set violation error, when a

data field contains a value outside of a pre-defined set

of values. In a data field with a limited set of data

values those that occur relatively rare compared to

others can be suspected for being incorrect.

Table 2 provides values of a Document Type data

field and number of times each was used in one of the

tested data sources. In several cases this data field

also contained the dimensions of the object, although

a separate data field was available for this

information.

Even without knowing the content requirements

of the particular data field, it is obvious that the data

value that appeared 393 times is probably the

Table 2: Values in a Document Type data field in digital

collection “Lost Latvia”.

DQ problem Value Used

number of

times

Syntax error 1 postcard 1

Misspelled error 1 potstcard 1

None 1 postcard 393

Value items

beyond the

attribute context

1 postcard, 8,5 x

13,5 cm

Value items

beyond the

attribute context

1 postcard, 8,5 x

13,5 cm

Value items

beyond the

attribute context

1 postcard, 8,7 x

13,6 cm

Value items

beyond the

attribute context

1 postcard, 8,7 x

13,7 cm

Value items

beyond the

attribute context

1 postcard, 8,8 x

13,5 cm

Value items

beyond the

attribute context

1 postcard, 8,8 x

13,8 cm

Value items

beyond the

attribute context

1 postcard, 9 x 14

Syntax error 1. postcard 1

“normal” one, while others should be considered at

least suspicious and should be provided for manual

review. In fact, when provided with this table of

values, data operators at the National Library of

Latvia indeed admitted that the most frequently used

value is the correct one, while others are results of

human errors.

Finally, an empirical study was performed where

data operators were asked to name what they consider

3 most important DQ problems each in their

particular data sources. For data sources used in this

research following DQ problems were named by at

least two data operators as important for their data

source:

 Value syntax error;

 Set violation error;

 Outdated values;

 Duplicate objects.

Note that these are not necessarily the most

frequently occurring data errors, but the DQ problems

that data operators consider have the most overall

impact on the operation of data source. For example,

Set violation error and Outdated values error cause

deterioration of data search and retrieval

performance.

AnalysisofDataQualityProblemTaxonomies

447

2.2 Proposed Improvements to Data

Quality Problem Taxonomy

While performing validation of the existing DQ

problem taxonomy (Oliveira P., et. al., 2005), it is

noticed that some improvements to the taxonomy are

necessary.

2.2.1 Identification and Correction of Data

Quality Problems

First of all, for future development, it is important to

understand, instances of which DQ problem classes

can be identified and corrected automatically and

which will require a partial or full manual assistance

from data operators.

Table 3 summarizes our initial estimates of how

many DQ problem classes can be processed

automatically and how many would require partial or

complete manual assistance.

Table 3: Detection and correction of DQ problem class

instances.

Detection and

correction

method

Number of DQ

problem classes

that can be

detected

Number of DQ

problem classes

that can be

corrected

Completely

automatically

19 7

Partially

manually (with

data operator

assistance)

4 8

Only manually 12 20

Total 35 35

As expected detecting a DQ problem in general is

much easier than correcting that error. For example,

it is easy to check whether all mandatory data fields

have values, but if a particular one does not, in most

cases without data operator assistance, it is

impossible to guess the missing value.

Only one DQ problem class is identified where

correcting error is considerably easier than

identifying it. It might be very hard just by looking at

data to detect that two data sources use different

measurement units. However, once established that

data source X uses one measurement unit and data

source Y another one, values can be easily

transformed using simple arithmetic. For example, a

comparatively simple correspondence exists between

metric and imperial measurement systems, where

conversion between those systems is done by simple

multiplication.

2.2.2 Modification of the DQ Problem Class

Structure

By analysing how well data operators could separate

between different DQ problem classes from the

original taxonomy (Oliveira P., et. al., 2005), we

identified following DQ problem classes where no

meaningful data error example could be provided to

separate the two: Inadequate value to the attribute

context and Value items beyond the attribute context.

So merging of these two DQ problem classes can be

suggested.

The first error describes cases where a value is

input into a wrong data field, while the second error

describes cases where data field contains a complex

value where parts of it would most appropriately have

been input in other data fields. These two errors

represent just a slightly more general case of

Redundancy errors.

A new DQ problem class can be proposed that

does not appear in the original taxonomy – Factual

errors. Such errors may appear in data fields that

contain natural language data values and

consequently may contain factual information. An

example of this DQ problem would be a data field

containing value: “The painting is located in the

capital of France – London,” where the statement that

London is capital of France is clearly a factual error.

Original DQ problem taxonomy considered

situations where only individual errors occur.

However, in real life scenarios a combination of two

or several different DQ problems might be

simultaneously present even in a single data field.

In fact, Misspelling error can cause almost every

other kind of DQ problem as well. For example, if a

person’s birth year is misspelled as “19743” instead

of “1974”, this will be both a Misspelling error and

an Interval violation error. Other DQ problem

combinations may exist, like: Syntax error/Set

violation, Set violation/Outdated value, etc.

The fact that DQ problem combinations may exist

requires establishing a certain order in which DQ

problems are identified in order to minimize the

number of suspected data errors. For example,

typically correcting misspelling errors first will also

automatically correct other suspected DQ problems

as well.

Following order can be proposed in which DQ

problems from a category “an attribute value of a

single tuple” should be processed:

 Missing value;

 Misspelling error;

 Syntax error;

 Interval violation;

ICEIS2015-17thInternationalConferenceonEnterpriseInformationSystems

448

 Outdated value;

 Set violation;

 Redundant value;

 Meaningless value;

 Factual error.

This, for example, means that factual errors

should only be checked after all other kinds of DQ

problems have been resolved.

Here the processing order of “an attribute value of

a single tuple” DQ problems is presented as they are

the most widely encountered, but such order

obviously can be established for other groups of DQ

problems as well.

While validating the original DQ problem

taxonomy, we identified several DQ problems that

can only be detected if sufficient external information

is provided. For example, to detect a Set violation

problem the set of all possible values must be

provided.

3 FRAMEWORK FOR

DETECTING DATA QUALITY

PROBLEMS

Section 2 of this paper describes the evaluation of an

existing DQ problem taxonomy with suggested

improvements. While granularity of this taxonomy

can be considered as optimal for classification of

individual instances of DQ problems, it is too detailed

when defining criteria for automatic identification of

data errors.

Although DQ problems like Set violation,

Outdated value and Syntax error all might have very

different causes, the algorithms used to identify these

DQ problems are almost identical. It can be

considered that these DQ problems are examples of a

more general type of data error: Incorrect value.

The detailed version of DQ problem taxonomy is

valuable for analysing reasons that certain errors

appear more frequently than others, however, DQ

problems for identification purposes can be grouped

in more general classes.

A new approach of grouping all DQ problems into

8 classes can be proposed, where each class of DQ

problems is identified with a particular type of

algorithms:

 Empty data field (for mandatory and semi-

mandatory data fields);

 Incorrectly formatted value;

 Incorrect use of special characters;

 Contradicting values in linked data fields;

 Outdated values;

 Set violation;

 Spelling/grammar errors;

 Object duplicates.

Furthermore, for each of these DQ problem

classes two types of algorithms can be provided:

 Assisted algorithm. If additional information is

available;

 Autonomous algorithm. If no additional

information is available and the algorithm

essentially must “guess” that a particular DQ

problem exists.

For example, an assisted algorithm for an

Incorrectly formatted value DQ problem class would

receive as an input list of data fields that have

specifically formatted values and a regular expression

that describes the expected format of values. An

autonomous algorithm on the other hand for the same

DQ problem class would “guess” both which data

fields contain specifically formatted values and the

corresponding regular expressions for value formats.

Although autonomous algorithms in general are

more complex than assisted algorithms, prototypes

for these algorithms have been developed for each of

the DQ problem classes, except for

Spelling/Grammar error class, where at least an

external vocabulary is required to perform a

meaningful detection of this kind of DQ problem.

4 CONCLUSIONS

This paper reflects a research in progress on finding

and correcting data quality problems in structured

textual data. Existing DQ problem taxonomies were

evaluated for structured data and one that was most

detailed and easy to use was adopted.

This taxonomy was then tested on real data from

several data sources of National Library of Latvia.

Some suggestions on how to improve the original

taxonomy are given in Section 2.2 of this paper.

Finally, a new regrouping of DQ problems is

proposed based on what algorithms can be used to

detect individual DQ problems. A new DQ problem

classification consisting of 8 groups of DQ problems

is proposed which can then be detected using two

types of algorithms: assisted and autonomous.

Like in the case of detecting DQ problems,

algorithms and methods for correcting DQ problems

will be developed. In general not always this will be

possible without additional input from data operators

(see Table 3). However, with sufficient external

information many DQ problem classes can be

corrected.

AnalysisofDataQualityProblemTaxonomies

449

A new universal tool will be developed that will

take any kind of structured data as input and will

detect and, where possible, correct DQ problems

based on criteria provided by data operators. This tool

will be validated by detecting and correcting DQ

problems in databases of National Library of Latvia.

ACKNOWLEDGEMENTS

This research is part of the project "Competence

Centre of Information and Communication

Technologies" run by IT Competence Centre,

contract No. L-KC-11-0003, co-financed by

European Regional Development Fund, Research No.

1.18 “Data array quality analysis and enhancement

technologies”. More information at

http://www.itkc.lv/.

REFERENCES

Chandola, V., Banerjee, A., Kumar, V., 2009. Anomaly

Detection: A Survey. ACM Computing Surveys

(CSUR), 41 (3). ACM New York, NY, USA. pp. 1-72.

Li, L., Peng, T., Kennedy, J., 2011. A Rule Based

Taxonomy of Dirty Data. GSTF International Journal

on Computing, 1 (2). Singapore. pp. 140-148.

Oliveira, P., Rodrigues, F., Henriques P., Galhardas H.,

2005. A Taxonomy of Data Quality Problems. In 2nd

Int. Workshop on Data and Information Quality (in

conjunction with CAiSE 2005), Porto, Portugal, June

14, 2005.

Kim W., et. al., 2003. A Taxonomy of Dirty Data. Data

Mining and Knowledge Discovery, 7. Kluwer

Academic Publishers, 2003. Manufactured in The

Netherlands. pp. 81–99.

Rahm, E., Hai Do, H., 2000. Data Cleaning: Problems and

Current Approaches. Bulletin of the Technical

Committee on Data Engineering, 23 (4).

Hernandez, M. A., Stolfo, S. J., 1998. Real-world Data is

Dirty: Data Cleansing and The Merge/Purge Problem.

Data Mining and Knowledge Discovery, 2. Kluwer

Academic Publishers, 1998. pp. 9–37.

ICEIS2015-17thInternationalConferenceonEnterpriseInformationSystems

450
