Analysis of Intrusion Detection Systems in Industrial Ecosystems

Juan Enrique Rubio, Cristina Alcaraz, Rodrigo Roman and Javier Lopez

Lenguajes y Ciencias de la Computaci

on, University of M

alaga, Spain

Keywords:

SCADA, Industrial Control, Intrusion Detection, Industry 4.0.

Abstract:

For an effective protection of all the elements of an industrial ecosystem against threats, it is necessary to

understand the true scope of existing mechanisms capable of detecting potential anomalies and intrusions. It

is the aim of this article to review the threats that affect existing and novel elements of this ecosystem; and to

analyze the state, evolution and applicability of both academic and industrial intrusion detection mechanisms

in this ﬁeld.

1 INTRODUCTION

Control of industrial environments through systems

such as SCADA (Supervisory Control and Data Ac-

quisition) is now present in most critical infrastruc-

tures (e.g. power grids, nuclear plants or transport

systems). These control systems allow remote and

real-time access to devices that govern the production

cycle, whether they are controllers such as PLC (Field

Programmable Logic Controllers), or RTU (Remote

Terminal Units). Traditionally, SCADA systems and

industrial networks had to be isolated from other en-

vironments. However, at present, we are dealing with

the interconnection of SCADA systems for the stor-

age of data or the outsourcing of services, as well as

a standardization of the software and hardware used

in control systems. Consequently, there has been a

substantial increase in security risks (Xu et al., 2014)

based on new speciﬁc threats operating under differ-

ent threat modes (Cazorla et al., 2016).

A solution to mitigate these effects is the provi-

sion of awareness-based approaches (e.g. situational-

awareness (Alcaraz and Lopez, 2013)), which help

to provide the necessary tools to favor the detection

and response to attacks and/or anomalies (Xu et al.,

2014). Many of these anomalies arise from conﬂicts

or security breaches due to interoperability issues,

probably caused by multiple communication and con-

trol protocols (Alcaraz and Zeadally, 2013). For ex-

ample, in the literature it is possible to ﬁnd proto-

cols working in Ethernet and TCP/IP, such as Ether-

net/IP, Ethernet POWERLINK, from ﬁeldbus proto-

cols (eg HART, wirelessHART, etherCAP, IO-Link)

CANopen, PROFINET, Modbus / TCP or HART / IP.

In addition to these, there are others designed for the

management and control of all industrial equipment,

such as the CIP, OPC UA, and MTConnect protocols,

without forgetting existing, open source alternatives

such as Woopsa or REST-PCA. This complexity is

further compounded by new communication infras-

tructures (e.g. IoT or cloud computing) along with

their speciﬁc digitization services for managing mul-

tiple types of data, as well as the integration of new

resources and services within the so-called Industry

4.0 (Khan and Turowski, 2016). As a result, a system

can become complex and critical, besieged by multi-

ple threats.

For these reasons, this paper explores the exist-

ing techniques and mechanisms that try to detect spe-

ciﬁc threat vectors within an industrial context, with-

out losing sight of the future industrial paradigm that

has started to be applied gradually. This is organized

as follows: Section 2 highlights the threats to which

the control is exposed today. Taking into account this

landscape, Section 3 addresses the search, by the in-

dustry and academia, for defense techniques suitable

for intrusion detection systems in these critical envi-

ronments, as explained in Sections 4 and 5, respec-

tively. Finally, Section 6 discusses the application

of these mechanisms in practice, and the conclusions

drawn are presented in Section 7.

2 CYBERSECURITY THREATS

2.1 Traditional Threats in IS and ICS

The threat model that can be applied to the elements

of traditional industrial control elements (PLCs, in-

116

Rubio, J., Alcaraz, C., Roman, R. and Lopez, J.

Analysis of Intrusion Detection Systems in Industrial Ecosystems.

DOI: 10.5220/0006426301160128

In Proceedings of the 14th International Joint Conference on e-Business and Telecommunications (ICETE 2017) - Volume 4: SECRYPT, pages 116-128

ISBN: 978-989-758-259-2

dustrial communication protocols, IT elements) is

highly diverse (Federal Ofﬁce for information Secu-

rity, 2016)(ICS-CERT, 2016). For the purposes of our

analysis, the attack vectors that affect these elements

can be classiﬁed following the taxonomy given by

the IETF standard-7416 (Tsao et al., 2015), in which

the threats are grouped according to the attack goals

against the minimum security services (Alcaraz and

Lopez, 2010) such as availability, integrity, conﬁden-

tiality and authentication.

Availability Threats. apart from the typical sub-

traction of devices (e.g. PLC and RTU) or com-

munication infrastructures, it is essential to highlight

the threats related to (distributed) denial of services

((D)DoS) attacks, the techniques of which mainly fo-

cus on the routing (e.g. relay attacks, selective for-

warding, grey hole, black hole or botnets).

Integrity Threats. Includes from the typical sabo-

tage of the industrial equipment to the injection of

malware (Moser et al., 2007) to slow down the op-

erational performance, obtain sensitive information,

modify the operation of the devices, etc. These

threats are also related to the alteration of the indus-

trial communication protocols and/or the real trafﬁc

values produced by ﬁeld devices, controllers or cor-

porate network equipment. Impersonation of nodes

and spooﬁng are also be applicable to an industrial

context, due in part to the susceptibility to Man-in-

the-Middle attacks and the existing weaknesses of the

industrial communication protocols.

Conﬁdentiality Threats. Within this category the il-

licit disclose techniques through passive trafﬁc analy-

sis (regarding topologies and routes) and theft of sen-

sitive data (related to industrial process, customers,

administration) or conﬁgurations should be high-

lighted. An example of information theft is that

achieved by injecting code in the operational appli-

cations (often webs through cross-site scripting (XSS)

or SQL Injection) so as to obtain or corrupt the control

measurements/actions, the company and/or end-users

privacy, or the security credentials.

Authentication/Authorization Threats. The au-

thentication in this point includes those attackers that

generally try to escalate privileges by taking advan-

tage of a design ﬂaw or vulnerability in the software

in order to gain unauthorized access to protected re-

sources. In order to carry out these attacks, attack-

ers need to apply speciﬁc social engineering tech-

niques (e.g. phishing attacks, chain of spam letters) to

collect strategic information from the system. Apart

from this, the easy mobility of in-plant operators and

their interactions through the use of hand-held inter-

faces (smart-phones, tablets, laptops) also lead to nu-

merous security problems, probably caused by mis-

conﬁgurations or unsuitable access control, both at

the logical (use of simple passwords) and physical

(access to equipment) level.

The exploitation of many of these threats may also

arise in some of the states of an advanced persistent

threat as discussed in (Singh et al., 2016; Chen et al.,

2014): (i) recognition (R) and communication (C)

through social engineering or compromising a third

party such as a provider; (ii) tracking (T) of zero-

day vulnerabilities and execution (E) of remote ac-

tions by previously launching malware and installing

backdoors; and (iv) propagation (P) and information

ﬁltration (F). Stuxnet was the ﬁrst APT recognized by

the industry in 2010 (Langner, 2011), but later others

appeared such as DuQu, Dragon Night, Flame, Au-

rora, Shamoon or the Mask (Blumbergs, 2014).

2.2 Present and Future Landscape of

Threats in IS and ICS

Besides addressing the aforementioned security is-

sues, it is necessary to envision a set of future security

threats that might appear, especially pertinent when

integrating new trending technologies such as IoT or

Cloud computing infrastructures.

2.2.1 Industrial Internet of Things Threats

IoT interconnects sensors and all kinds of devices

with Internet networks, to gather information about

physical measures, location, images, etc. The Indus-

trial IoT (IIoT) speciﬁcally pursues a vertical integra-

tion among all the components that belong to the in-

dustrial architecture, ranging from machines to oper-

ators or the product itself. With respect to security,

the situation is further complicated when we take into

consideration the scarce autonomy and computational

resources that these devices have. Continuing with

the IETF standard 7416 (Tsao et al., 2015), we can

distinguish the following range of threats:

Availability Threats. Comprises the disruption of

communication and processing resources: ﬁrstly,

against the routing protocol (Wallgren et al., 2013),

inﬂuencing its mode of operation (creating loops,

modifying routes, generating errors, modifying mes-

sage delays, etc.) through different attacks, which can

be directly committed at the physical level through

jamming or interferences. Secondly, against the

equipment itself, including the exhaustion of re-

sources (processing, memory or battery) exploita-

tion of vulnerabilities in the software (as well as re-

verse engineering) that govern control devices such as

PLCs, in addition to running malicious code or mal-

ware: viruses, Trojans, etc. (Sadeghi et al., 2015).

Analysis of Intrusion Detection Systems in Industrial Ecosystems

117

Thirdly, we have to stress the data trafﬁc disruption,

undermining the functionality of the routers in the

network, causing a lack of availability of certain ser-

vices. It is caused by vectors such as selective for-

warding, wormhole or sinkhole attacks.

Integrity Threats. It means the manipulation of rout-

ing information to inﬂuence the trafﬁc and fragment

the network, like a Sybil attack (Zhang et al., 2014).

This becomes the gateway to other attacks such as

black hole or denial of service, causing the routes to

pass through the more congested nodes. The form of

attack includes falsiﬁcation of information (the node

advertises anomalous routes), routing information re-

play, physical compromise of the device or attacks

on the DNS protocol (L

evy-Bencheton et al., 2015).

Node identity misappropriation can also be taken into

account, opening the door to other attacks that result

in the modiﬁcation of data of all types.

Conﬁdentiality Threats. Includes the exposure of

information of multiple kinds: ﬁrstly, the one related

the state of the nodes and their resources (available

memory, battery, etc.). One way is the so-called side

channel attacks (Zhao and Ge, 2013), where the elec-

tromagnetic emanations of devices leak information

about the execution of certain operations. Secondly, it

also includes the exposure of routing information and

the topology, which constitutes rich information for

the attackers as it enables them to identify vulnerable

equipment. Since this information resides locally in

the devices, attacks against the conﬁdentiality of this

information will be directed at the device, either phys-

ically compromising it or via remote access. Lastly, it

is also possible to have the exposure of private data,

usually collected by wearable devices belonging to

operators within the organization, which can reveal

information about their performance at work or their

location. One attack vector could be the use of social

engineering or phishing.

Authentication Threats. We can highlight the imper-

sonation and introduction of dummy/fake nodes, ca-

pable of executing code or injecting illegitimate traf-

ﬁc to potentially control large areas of the network or

perform eavesdropping. An attack vector consists of

the forwarding of digital certiﬁcates used in authenti-

cation protocols or physical or network address spoof-

ing. Escalation of privileges can also be faced as a

consequence of a non-existent or poor access control,

when the attacker can take advantage of design ﬂaws

or vulnerabilities in IoT devices to access protected

resources without authorization.

2.2.2 Cloud Computing Threats

In recent years cloud computing has changed the way

in which information technology (IT) is managed,

through an environment that provides on-demand re-

sources over the Internet with a low cost of investment

and easy deployment. For our work, cloud comput-

ing acquires dual importance. On the one hand, many

organizations use the cloud to provide IoT services,

acquiring sensor data and sending commands to actu-

ators. On the other hand, it is also necessary to take

into account the delegation of certain analysis and

production processes to the cloud, in what is known

as cloud-based manufacturing (Wu et al., 2015). The

ultimate goal of this model is to enable customers to

design, conﬁgure and manufacture a product through

a shared network of suppliers throughout its life cy-

cle, enhancing the efﬁciency and reducing costs. In

summary, these factors make it necessary to analyse

the full range of threats that cloud computing faces

(Sen, 2013)(Sun et al., 2014):

Availability Threats. This category includes the so-

called service theft attack, which takes advantage of

the vulnerabilities and inaccuracies that exist in the

scheduler component of some hypervisors, where the

service is charged considering the time spent running

virtual machines – instead of based on the CPU time

in use. This can be exploited by attackers in order to

use services at the expense of other clients, making

sure that the processes of interest are not executed at

each tick of the scheduler. We also contemplate denial

of service attacks: the attacker causes the service to

become inaccessible for its legitimate users. This is

the most serious type of attack on cloud computing,

because of the ease with which it can be carried out

and the difﬁculties in preventing them.

Integrity Threats. The most important one comes

with a malware injection attack, where the attacker

replicates the service instance that is provided to a

client (a virtual machine, for example) and replaces

it with a manipulated one that is hosted again in the

cloud. This means that requests sent by the legitimate

user are processed in the malicious service, and the at-

tacker can access the exchanged data. To do this, the

most common way is to appropriate access privileges

or introduce malware into multiple format ﬁles, jeop-

ardizing the conﬁdentiality and privacy of the data.

Conﬁdentiality Threats. Firstly, side-channel at-

tacks with virtual machines must be stressed, in which

the attacker, from his virtual machine, attacks oth-

ers that are running on the same physical hardware.

This allows them to access their resources by studying

the electromagnetic emanations, the processor cache,

etc. This information can be useful in choosing the

most attractive targets to attack. This category also in-

cludes attacks on shared memory systems: they work

as a gateway to other types of attacks such as mal-

ware or side-channel attacks, and consist in analyz-

SECRYPT 2017 - 14th International Conference on Security and Cryptography

118

Table 1: Overview of threats that affect industrial systems.

Threats Traditional IIoT Cloud Comp. APT-states Impact on

Control

in-plant

Corp. Net. End-users

Availability Subtraction of devices X X E X

DDoS attacks X X X C, E, P X X

Attacks on-path X X C, E, T, F, P X X

Exhaustion of node resources X X C, E X X

Service theft X C, E X X

Integrity Incorrect conﬁguration X X X C, E X X

Reverse engineering

and/or malware injection

X X X R, C, P, E, T, F X X

False data injection X X C, E, P X

Spooﬁng X X C, E X X X

Manipulation of routing information X X C, E, P X

Conﬁdentiality Sensitive information theft X X X C, E, F X X X

Nodes status exposure

(side-channel attacks)

X X R, C, E, F X

Passive trafﬁc analysis X X R, C, E, T, F, P X X

Infrastructure information exposure

(shared memory systems attacks)

X C, E, T, F, P X X X

AAA Privilege escalation X X X C, E, P X X X

Social engineering X X R, C, E X X X

Deﬁcient control access X X X C, E X X X

Impersonation of nodes

(fake/dummy nodes)

X X C, E X

ing the shared memory (cache or main memory) used

by virtual and physical machines to obtain technical

information about the infrastructure, such as the pro-

cesses that are running, the number of users, or even

the memory dump of virtual machines.

Authentication Threats. The attacker tries to obtain

information from the clients of different applications

or trusted companies by posing as themselves. This

is done through malicious services with the same ap-

pearance as those are normally offered through a link

sent by email. Thus, the attacker can obtain sensi-

tive information from his/her victims by entering their

data, such as passwords or bank cards. This way, the

attacker can illicitly host services in the cloud and ac-

cess accounts of certain services.

A complete overview of the present and future

threats faced by an Industrial System is summarized

in Table 1. Even though most of these are in gen-

eral inherited by IoT and cloud technologies, they also

pose new hazards to be addressed. Firstly, because the

technical constraints that the new devices and com-

munication protocols feature create new vulnerabil-

ities and attack vectors. Secondly, due to the impact

they cause in the assets within the organization, which

comprise control and corporative resources as well as

end-users (e.g., clients or operators). Altogether, this

makes it necessary to ﬁnd new defense solutions and

tailor the current detection mechanisms, as discussed

in the following.

3 DEFENSE TECHNIQUES

Intrusion Detection Systems (IDS) are a ﬁrst defense

solution to the wide range of cybersecurity threats de-

scribed in section 2. The objective is to detect unau-

thorized access to the network or one of its systems,

monitoring its resources and the trafﬁc generated in

search of behaviors that violate the security policy es-

tablished in the production process.

There are many methods for performing intru-

sion detection. One possibility is the signature-based

IDS, which tries to ﬁnd speciﬁc patterns in the frames

transmitted by the network. However it is precisely

for that reason that it is impossible for them to de-

tect new types of attacks whose pattern is unknown

(Patcha and Park, 2007).

Another possibility is the anomaly-based IDS,

which compare the current state of the system and its

generated data with the normal behavior of the sys-

tem, to identify deviations present when an intrusion

occurs. However, in the context of control systems,

restrictions such as the heterogeneity of the data col-

lected in an industrial environment, the noise present

Analysis of Intrusion Detection Systems in Industrial Ecosystems

119

in the measurements, and the nature of the anomalies

(attacks vs. faults) must be taken into consideration.

For this reason, numerous detection techniques

have been based on areas such as statistics or artiﬁcial

intelligence (Bhuyan et al., 2014), each with a differ-

ent level of adaptation depending on the scenario of

the application to be protected (Gyanchandani et al.,

2012):

Data Mining-based Detection. Based on the anal-

ysis of an enormous amount of information in search

of characteristics that enable distinguishing if the data

is anomalous. In this category we ﬁnd: Classiﬁca-

tion techniques: creation of a mathematical model

that classiﬁes data instances into two classes: “nor-

mal” or “anomalous”. This model is trained with al-

ready classiﬁed example data. Clustering-based tech-

niques: like the previous category, they seek to clas-

sify instances of data but in different groups or clus-

ters, according to their similarity. This is mathemati-

cally represented by the distance in the space between

the points associated with that information. Associa-

tion rule learning-based techniques: they process the

data set to identify relationships between variables, in

order to predict the occurrence of anomalies based on

the presence of certain data.

Statistical Anomaly Detection. In this approach, in-

ference tests are applied to verify whether a piece of

data conforms or not to a given statistical model, in

order to conﬁrm the existence of intrusions: Paramet-

ric and nonparametric-based methods: while the for-

mer are those that assume the presence of a probabil-

ity distribution that ﬁts the input data to estimate the

associated parameters (which does not have to con-

form to reality), the second tries to look for the under-

lying distribution. In general, both are accurate and

noise-tolerant models of missing data, which allow us

to ﬁnd conﬁdence intervals to probabilistically deter-

mine when an anomaly occurs. Time series analysis:

they predict the behavior of the system by represent-

ing the information it generates in the form of a se-

ries of points measured at regular intervals of time.

Although they are able to detect slight disturbances

in the short term, they are less accurate in predict-

ing drastic changes. Markov chains: they consist of

mathematical representations to predict the future be-

havior of the system according to its current state. For

this purpose, state machines are used with a prob-

ability associated with transitions. Its accuracy in-

creases when using complex multi-dimensional mod-

els. Information based techniques: they involve the

observation of the information generated (for exam-

ple, the capture of the trafﬁc) and its intrinsic char-

acteristics in search of irregularities associated with

threats- packages for denial of service, messages to

cause attacks by buffer overﬂow, etc. They are gener-

ally efﬁcient systems tolerant to changes and redun-

dancy in the information. Spectral theory-based tech-

niques: these techniques use approximations of the

data to other dimensional sub-spaces where the differ-

ences between the normal and the anomalous values

are evidenced. They are usually complex and are used

to detect stealth attacks, those which are specially de-

signed to circumvent detection techniques.

Knowledge-based Detection. In this case, the

knowledge about speciﬁc attacks or vulnerabilities is

acquired progressively, ensuring a low rate of false

positives, thereby resulting in a system that is resis-

tant to long-term threats. However, the security de-

pends on how often the knowledge base is updated,

and the granularity with which information about new

threats is speciﬁed. Examples of these techniques in-

clude state transition-based techniques, Petri nets or

expert systems.

Machine Learning-based Detection. This type of

technique bases the detection on the creation of a

mathematical model that learns and improves its ac-

curacy over time, as it acquires information about the

system to be protected. In this category we ﬁnd tech-

niques of artiﬁcial intelligence whose foundations are

also closely linked to statistics and data mining: Arti-

ﬁcial neural networks: they are inspired by the human

brain and are able to detect anomalies when dealing

with a large data set with interdependencies. It allows

the data to be classiﬁed as normal or anomalous with

great precision and speed, although they need a long

time to create the model, which prevents them from

being applied in real time systems. Bayesian net-

works: events are represented in a probabilistic way

through directed acyclic graphs where the nodes rep-

resent states and the edges deﬁne the conditional de-

pendencies between them. The purpose is to calcu-

late the probability of an intrusion from the data col-

lected. Support vector machines: this is a technique

that classiﬁes the data according to a hyperplane that

separates both classes (habitual and anomalous infor-

mation). Since it works with a linear combination of

points in space (given by the input data), its complex-

ity is not high and its quality of precision is accept-

able. However, it does not behave accurately in pres-

ence of similar data, for which there is no hyperplane

that divides them correctly. Fuzzy logic: rule-based

structures are used to deﬁne a reasoning with inaccu-

rately expressed information, like humans do in ev-

eryday language (being able to differentiate when a

person is “tall” or “short” or something is “slightly

cold”). Therefore it models the behavior of complex

systems without excessive accuracy (leading to speed

and ﬂexibility), but obviously it means the accuracy

SECRYPT 2017 - 14th International Conference on Security and Cryptography

120

of the anomaly detection is not high either. Genetic

algorithms: they simulate the phenomenon of natural

selection to solve a complex problem for which there

is no clear solution. In the ﬁrst phase, a set of indi-

viduals of a population is randomly generated (repre-

senting the possible solutions to that problem). From

there, numerous iterations are carried out where suc-

cessive operations of selection, replacement, mutation

and crossing are applied to ultimately ﬁnd an optimal

solution. Although it is moderately applicable to the

detection of anomalies, it has been shown that it is

unable to detect unknown attacks.

On the other hand, there are also speciﬁcation-

based IDS (Sekar et al., 2002). The principle behind

them is similar to systems based on anomalies, in the

sense that the current state of the system is compared

to an existing model. However, in this case the spec-

iﬁcations are deﬁned by experts, which reduces the

number of false positives to the extent that they are

deﬁned in detail. State diagrams, ﬁnite automata, for-

mal methods, etc. are often used. They are often com-

bined with signature-based and anomaly-based IDS.

4 INDUSTRIAL IDS PRODUCTS

At present, there are several types of IDS systems

available on the market. They correspond to the

strategies described in section 3: from more tra-

ditional signature detection systems to more novel

anomaly detection systems and “honeypot” systems.

Most of these solutions are passive (i.e. do not affect

the operation of the system), transparent (i.e. almost

invisible to the existing control systems), and easy to

deploy.

Table 2 provides an enumeration of the leading

companies in the market that provide IDS services

and appliances. In addition, a short summary of the

main solutions available in the market as of Q1 2017

is provided in the next sections.

4.1 Signature-based Solutions

These products consist mainly of devices that pas-

sively connect to the control network, accessing the

information ﬂow. One of the pioneers in this ﬁeld is

Cisco Systems, which has a large database of attack

signatures on industrial environments (CISCO Sys-

tems, 2017). Such attack signatures include not only

generic attacks on elements of the industrial network

(e.g. denial of service in HMIs, buffer overﬂows in

PLCs), but also speciﬁc vulnerabilities in industrial

protocols (e.g. CIP Or Modbus). This database is eas-

ily upgradeable, and can be integrated into all Cisco

intrusion detection systems.

There are also other products on the market that,

beyond the detection of attack signatures, provide

several value-added services. An example of this is

the monitoring system of Cyberbit (Cyberbit, 2017).

This system monitors the trafﬁc of the network in or-

der to map existing devices, giving the operator a real-

time view of the elements of a system. In addition, it

is possible to take advantage of information acquired

from the device to identify elements that have known

vulnerabilities.

4.2 Context-based Solutions

One drawback of most products based on the de-

tection of attack signatures and patterns is the lack

of correlation between the detected events, which

could provide valuable information regarding the ac-

tual scope of the attack behind those events. Another

drawback is the absence of an in-depth analysis based

on the context of the system: the parameters of a com-

mand can be valid in a given context, but harmful in

another. As a consequence, there are several prod-

ucts that perform correlation and/or in-depth analysis

tasks which take into account the general context of

the system.

One example of these correlation systems is the

Sentry Cyber SCADA software from AlertEnter-

prise (AlertEnterprise, 2017). It combines and cor-

relates events and alerts from various domains (phys-

ical, IT and OT networks) and sources, with the aim

of providing a complete security monitoring tool for

industrial systems. To achieve this objective, this tool

allows integration with other security tools, such as

vulnerability scanners, SIEM (Security Information

and Event Management) systems, IDS/IPS systems or

security conﬁguration tools.

Another example of in-depth analysis solutions is

Wurldtech’s OPShield (WurldTech (GE), 2017) sys-

tem. OPShield performs an in-depth analysis of the

network trafﬁc, including the syntactic and grammat-

ical structure of the protocols. Through these analy-

ses, OPShield can inspect the commands and param-

eters sent to the different components of the indus-

trial system, and even block those commands if the

administrator has authorized OPShield to do so. Note

that the blocking or not of these commands is deter-

mined based on the context in which they have been

sent. Thus, it is possible to protect the system against

seemingly valid and/or legitimate commands that are

potentially dangerous for the correct operation of the

system if they are sent outside the context for which

they were deﬁned.

Analysis of Intrusion Detection Systems in Industrial Ecosystems

121

Table 2: Leading companies in the market.

Detection Strategies Leading Companies

Signature-based Cisco, Cyberark, Cyberbit, Digital Bond, ECI, FireEye

Context-based AlertEnterprise, WurldTech (GE)

Honeypot-based Attivo Networks

Anomaly-based

Control-See, CritiFence, CyberX, Darktrace, HALO Analytics, HeSec, ICS2, Indegy, Leidos

Nation-E, Nozomi, PFP Cybersecurity, RadiFlow, SCADAfence, SecureNok, Sentryo, SIGA, ThetaRay

4.3 Honeypot-based Solutions

Existing solutions based on honeypot systems usually

create a distributed system, through which they col-

lect and analyze information related to the threat or

attack. Thanks to the analysis and correlation of the

collected information, this type of IDS / IPS systems

can be able to identify the type of attack launched,

the (malicious) activities carried out on the system, as

well as the existence of infected devices.

Within the current marketplace, one of the ma-

jor existing honeypot-based detection platforms is

ThreatMatrix from Attica Networks, which is able to

detect real-time intrusions in public and private net-

works, ICS/SCADA systems, and even IoT environ-

ments. Its ﬂagship product is called BOTsink (Attivo

Networks, 2017), and is able to detect advanced per-

sistent threats (APTs) effectively, without being de-

tected by the attackers. The client also can customize

the software images that simulate SCADA devices.

Such customization allows the integration of both the

software and the protocols that are used in the pro-

duction environment. As a result, fake SCADA de-

vices can be made almost indistinguishable from real

SCADA devices.

4.4 Anomaly-based Solutions

As of Q1 2017, there are a wide range of products

that make use of deep packet inspection and/or ma-

chine learning technologies to detect unusual behav-

iors or hidden attacks, of which there is no already

identiﬁed pattern. Regarding the deployment location

of these commercial products, most of them operate

on the operational network, accessing the informa-

tion ﬂow through the SPAN ports of existing network

devices. Other deployment strategies exist, though.

Some products, such as UCME-OPC from Control-

See (Control-See, 2017), retrieve system information

directly from the industrial process management lay-

ers. Other products, such as the Smart Agent services

by HeSec (HeSec, 2017), make use of agents that are

distributed throughout all the elements – devices and

networks – of the industrial system. Finally, there are

products in charge of monitoring the interactions with

ﬁeld devices, such as those offered by SIGA

(SIGA, 2017); or even systems embedded within the

ﬁeld devices themselves, such as those offered by

MSi (Mission Secure, 2017), which are responsible

for examining and validating the behavior of ﬁeld de-

vices.

As for the speciﬁc techniques of anomaly mod-

eling and detection, each commercial product makes

use of one or several of them. Some products, such as

UCME-OPC from Control-See (Control-See, 2017),

create a model of the system based on certain con-

ditions/rules. Whenever those rules are not fulﬁlled

by the system parameters and values, a warning will

be launched. Other products, such as XSense from

CyberX (CyberX, 2017), base their operation on the

classiﬁcation of system states: if a monitored system

transitions to a previously unknown state, such state is

classiﬁed as normal or malicious depending on mul-

tiple signals and indicators. There are also products,

such as HALO Vision from HALO Analytics (Halo

Analytics, 2017), which make use of statistical analy-

sis.

Other products consider industrial control systems

from a holistic point of view, and include the be-

havior of various actors, including human operators,

into their own detection systems. For example, Dark-

trace’s Enterprise Immune System (DarkTrace, 2017)

makes use of a variety of mathematical engines, in-

cluding Bayesian estimates, to generate behavioral

models of people, devices, and even the business as a

whole. There are also other products, such as Wisdom

ITI from Leidos (Leidos, 2016), which offer a pro-

active and real-time platform for internal threat detec-

tion. This platform not only monitors system activity

indicators, but also the behavior of human employees.

Finally, it is necessary to point out that the major-

ity of these products start with no knowledge about

the environment or industrial system that they aim to

protect. As such, they need to be trained, acquiring

the knowledge they need mostly by monitoring the

network trafﬁc. Even so, there are some products, like

the suites marketed by ICS2 (ICS2, 2017), that can ac-

quire such behavior ofﬂine by loading and processing

a ﬁle. The aim of this is to reduce the time required

for the deployment and commissioning of these prod-

ucts.

SECRYPT 2017 - 14th International Conference on Security and Cryptography

122

Table 3: Evolution according to detection coverage.

Coverage 2013 2014 2015 2016

Field devices 2 - 3 15

Control networks – PLCs 4 8 9 5

Control networks 1 3 3 9

Complete system - 1 - 5

Table 4: Evolution according to protocol analyzed

Protocol 2013 2014 2015 2016

Fieldbus protocols 2 1 2 3

Communication protocols 2 3 10 14

Control & management protocols 1 - 1 1

Table 5: Evolution according to detection mechanism.

Mechanism 2013 2014 2015 2016

Signature-based detection - 3 - 4

Data mining mechanisms 2 2 4 5

Statistical anomaly detection - - 4 5

Knowledge based detection 1 1 2 1

Machine learning based detection 3 3 2 8

Speciﬁcation-based detection 1 3 2 8

Other mechanisms - - 3 5

5 ACADEMIC RESEARCH

Due to the importance of protecting industrial con-

trol infrastructures before, during and after an attack,

the academia has also been paying special attention

to the development of intrusion detection systems for

this particular context. In these systems, all the de-

fense mechanisms described in section 3 have been

integrated to some extent, trying to cover all the ele-

ments of an industrial control network: ﬁeld devices,

the interactions between the control network and ﬁeld

controllers such as PLCs, the control network itself,

and even the complete system in a holistic way.

Tables 3, 4 and 5 provide a classiﬁcation by cate-

gories (according to detection coverage, protocol an-

alyzed, and detection mechanism, respectively) of

the number of articles published in the ﬁeld between

years 2013 and 2016. Within this classiﬁcation, we

have included the most relevant articles that appeared

in international journals and/or conferences. This rel-

evance has been measured by factors such as the rele-

vance of the corresponding journal or conference, and

the number of references per article. Due to space

constraints, this section will only provide citations to

those articles that are explicitly mentioned.

5.1 Analysis: Detection Mechanisms

In recent years, all detection mechanisms described

in section 3 have been taken into account. We can

observe in table 5 that research in the ﬁeld has been

growing over time. We can also observe that the

academia has paid special attention to machine learn-

ing and speciﬁcation-based mechanisms. One possi-

ble reason is that the elements of the control networks

can behave in a more or less predictable way (Krotoﬁl

and Gollmann, 2013). As such, these elements can be

modeled through various set of rules. It should also be

mentioned that signature-based detection and statisti-

cal techniques are becoming increasingly important –

and successfully applied – in the interactions between

the corporate network and the control network.

Still, there are certain detection strategies, which

will be highlighted here, that are still being studied

only within the academia. For example, several au-

thors are using parameters that have not previously

been taken into account in this context, such as net-

work telemetry. Through indirect or direct analysis

(e.g. via ICMP messages) of the telemetry, it is pos-

sible to detect fake control devices (Ponomarev and

Atkison, 2016), and even discover covert manipula-

tions of the controller device code (Lontorfos et al.,

2015). There are also researchers who have consid-

ered other less traditional parameters within the con-

text of anomaly and intrusion detection, such as the

radio-frequency emissions emitted by the control de-

vices (Stone et al., 2015).

There are also other researchers that incorporate

concepts such as the physical simulation of the mon-

itored system (McParland et al., 2014). This sim-

ulation allows not only to predict the malicious in-

tent of a command, but also to predict an imminent

system failure. In addition, within the context of

speciﬁcation-based research, there are a large number

of papers that seek to generate the system behavior

rules in an automatic or semi-automatic way, mainly

by analyzing the conﬁguration and system description

ﬁles (Caselli et al., 2016).

Besides, there are also other strategies whose goal

is to identify and analyze the most critical elements

of a control network. An example of this is the sys-

tem developed by Cheminod et al. (Cheminod et al.,

2016), which can identify the sequence of vulnerabil-

ities that could affect an existing system by (i) ana-

Analysis of Intrusion Detection Systems in Industrial Ecosystems

123

lyzing the elements of that system and (ii) analyzing

vulnerability databases such as CVE (Mitre, 2017).

Other research lines provide a support to the afore-

mentioned IDS/IPS technologies from a theoretical

perspective, adopting a reactive policy by means of

recovery mechanisms when topological changes are

detected. Their target is to ensure the structural con-

trollability of the network and achieve resilience (Lin,

1974), this is, the continuity of the industrial pro-

cess and the connectivity between nodes in presence

of attacks (Rahimian and Aghdam, 2013). For such

goal, graph theory concepts are leveraged. Finally,

it should be mentioned that the vast majority of new

signature-based detection systems use, in addition to

the SNORT tool, the BRO (Vern Paxson et al., 2017)

tool to perform their analyses. This tool provides

a modular and extensible framework that allows the

generation and analysis of events through a Turing-

complete language.

5.2 Analysis: Detection Coverage

Regarding the evolution of the coverage of detection

systems developed in the academia, it is worth com-

menting that in 2016 the mechanisms in charge of

protecting the ﬁeld devices have increased exponen-

tially. The reason is simple: these mechanisms can

detect attacks against the ﬁeld devices at the very mo-

ment they occur. Direct monitoring is usually done

by extracting the data directly from the sensors and

actuators, either through the machine’s own inter-

faces (Junejo and Goh, 2016), or through a “capillary

network” that monitors the operation of the machin-

ery through several types of external sensors (Jardine

et al., 2016). On the other hand, there are also mech-

anisms that integrate a hypervisor within the control

devices themselves (e.g. PLCs (Garcia et al., 2016)).

This hypervisor is then responsible for reviewing the

behavior of all control programs executed within the

device.

Moreover, in 2016 various researchers have de-

signed novel theoretical architectures whose objective

is to protect all the elements of an industrial produc-

tion system in a holistic way. This is achieved by de-

ploying various detection components, both hardware

and software, which obtain information and process

it at a local level. This information will then be sent

to a central system, which can more efﬁciently detect

threats that affect several elements of the system in

a covert way. These architectures represent an evo-

lution of the industrial correlation systems deﬁned in

section 4.2 in various ways. For example, certain ar-

chitectures allow ﬁeld devices to be fully monitored

alongside all other elements of the control system

(Jardine et al., 2016), while other architectures im-

prove the detection of anomalies whose impact is dis-

tributed to all elements of the system (Ghaeini and

Tippenhauer, 2016).

5.3 Analysis: Protocols Analyzed

Currently there are a large number of scientiﬁc ar-

ticles that have developed speciﬁc detection mech-

anisms for communications protocols such as Mod-

bus/TCP (Goldenberg and Wool, 2013). These works

focus mostly on two strategies: i) deﬁning and detect-

ing attack signatures, and ii) analyzing the behavior

of these communication protocols with the detection

mechanisms described in section 3. However, there

are very few works that have studied the security of

control & management protocols such as OPC UA. It

is extremely important to analyze and protect these

speciﬁc protocols in the near future: not only they

are considered as one of the cornerstones of Indus-

try 4.0 (H. et al., 2013), but there are already various

commercial products that currently use these proto-

cols in production environments (Siemens, 2017).

Finally, it should be mentioned that the vast ma-

jority of detection mechanisms that analyze the in-

tegrity of ﬁeldbus protocols are focused on the analy-

sis of wireless industrial IoT protocols such as Wire-

lessHART (Bayou et al., 2016). This is mainly be-

cause an attacker can more easily manipulate a wire-

less network if he has the necessary information: he

can not only inject information from anywhere within

the range of the network, but he can also deploy a ma-

licious element in a covert way.

6 DISCUSSIONS

6.1 Intrusion Detection and Existing

Threats

In an industrial control ecosystem, and due to the di-

versity of devices and protocols, there is no single

‘silver bullet’ that can address all potential threats de-

scribed in section 2. Yet it might be possible to com-

bine various solutions to provide an adequate level of

protection. The state of the art described in previous

sections has shown that it is possible to detect threats

against the availability of the system by detecting ma-

licious network trafﬁc and by mapping the behavior

and location of existing devices. There are other de-

tection mechanisms that are specialized in the detec-

tion of integrity threats: either directly, by detecting

the presence of malicious entities, or indirectly, by un-

SECRYPT 2017 - 14th International Conference on Security and Cryptography

124

covering the attacks and side effects caused by such

entities. Finally, various techniques, such as in-depth

trafﬁc analysis, anomaly-based detection, and user

monitoring can help in the detection of malicious in-

siders that bypassed the AAA infrastructure.

There are still certain aspects that require of more

research and validation. For example, any attack that

aims to passively extract information from the system

(i.e. data exﬁltration) can create anomalous trafﬁc that

might be ﬂagged by anomaly detection systems (Liu

et al., 2009). However, most industrial-oriented de-

tection systems have been more focused on detecting

other kind of anomalous trafﬁc, such as DoS attacks

and malware patterns. Another open issue is the iden-

tiﬁcation of misconﬁgured services and other proac-

tive defense mechanisms, whose designs are limited

due to the critical nature of the monitored system.

Moreover, other aspects related to the integration

of technologies such as IIoT and cloud computing

must be carefully considered. Regarding IIoT threats,

while there are various detection systems that are spe-

cialized in analyzing IIoT protocols such as Wire-

lessHART, it is still necessary to expand this cover-

age to other potential IIoT protocols such as CoAP,

MQTT and oneM2M (Joshi et al., 2017). Besides,

as IIoT attacks can be extremely localized (i.e. at-

tacks using the wireless channel), it is essential to as-

sure that all elements and evidence are properly moni-

tored; making use, if possible, of lightweight account-

ability mechanisms based on granular information in

which it is required to identify what, who and how

these events were launched.

As for the threats that cloud computing faces, if

the industrial system makes use of an external cloud

computing infrastructure, it is mandatory to integrate

various attestation and accountability mechanisms in

order to check that all outsourced processes are being

correctly managed. Even if the cloud infrastructure is

local, it is still necessary to monitor the cloud infras-

tructure itself in order to detect if the cloud resources

are being misused or not. On the other hand, these

resources can also be used by constrained devices

and systems as a means of executing time-consuming

complex detection algorithms.

6.2 Intrusion Detection and the

Industry of the Future

Within the context of the so-called Industry 4.0, the

integration of cutting-edge technologies within in-

dustrial environments is being planned. This will

generate new scenarios and services such as ﬂexi-

ble production lines or predictive maintenance sys-

tems (Khan and Turowski, 2016). However, such in-

tegration will bring new challenges that need to be un-

derstood and overcome when developing threat pro-

tection and detection mechanisms. One of these as-

pects, already mentioned in section 5.3, is the de-

tection of those anomalies that will affect control &

management protocols such as OPC-UA. Another as-

pect to consider is the integration of physical and

virtual processes within the industry, giving birth to

novel services such as the “digital twins”. This opens

up both new opportunities (detection of anomalies

through analysis of simulations) and challenges (con-

trol of virtualized environments).

Another aspect to consider is the assumption that,

in the near future, most Industry 4.0 elements will be

interoperable with each other. As a result, those ele-

ments will become semi-autonomous, able to make

collaborative decisions that could improve various

businesses and industrial processes (e.g. automatic

production line planning). This will make necessary

the development of new detection mechanisms, fo-

cused on analyzing both the behavior of these semi-

autonomous systems and their interactions. Yet these

interoperability mechanisms and principles can also

be used to improve the integration of all devices with

existing correlation systems and other holistic detec-

tion architectures. Finally, the various organizations

that will make up the industry of the future will be

part of a common space, in which producers, suppli-

ers and users will be able to share information. This

implies the need to create safe collaborative spaces in

which to share safety information regarding anoma-

lies that may affect other members of the ecosystem.

7 CONCLUSIONS

There have been signiﬁcant progress in the develop-

ment of intrusion detection techniques for industrial

ecosystems in the last years. Not only there are com-

mercially available products that integrate advanced

solutions such as honeypot systems and information

correlation systems, but also there are novel detec-

tion mechanisms and architectures developed in the

academia. Even so, it is necessary to move forward in

various aspects in order to completely cover the full

spectrum of potential threats, such as the integration

of mechanisms oriented to protect IIoT and cloud in-

frastructures, the deployment of novel research mech-

anisms in real scenarios, the analysis of certain com-

mand & control protocols, and various challenges re-

lated to the industry of the future.

Analysis of Intrusion Detection Systems in Industrial Ecosystems

125

ACKNOWLEDGEMENTS

This work has been funded by the Spanish Min-

istry of Economy, Industry and Competitiveness

through the SADCIP (RTC-2016-4847-8) and PER-

SIST (TIN2013-41739-R) projects. The work of the

ﬁrst author han been partially ﬁnanced by the Span-

ish Ministry of Education under the FPU program

(FPU15/03213).

REFERENCES

Alcaraz, C. and Lopez, J. (2010). A security analysis

for wireless sensor mesh networks in highly criti-

cal systems. IEEE Transactions on Systems, Man,

and Cybernetics, Part C: Applications and Reviews,

40(4):419–428.

Alcaraz, C. and Lopez, J. (2013). Wide-area situational

awareness for critical infrastructure protection. IEEE

Computer, 46(4):30–37.

Alcaraz, C. and Zeadally, S. (2013). Critical control system

protection in the 21st century: Threats and solutions.

IEEE Computer, 46(10):74 – 83.

AlertEnterprise (2017). Sentry CyberSCADA.

http://www.alertenterprise.com/products-

EnterpriseSentryCybersecuritySCADA.php. [Online;

Accessed March 2017].

Attivo Networks (2017). BOTsink.

https://attivonetworks.com/product/attivo-botsink/.

[Online; Accessed March 2017].

Bayou, L., Cuppens-Boulahia, N., Esp

es, D., and Cuppen,

F. (2016). Towards a cds-based intrusion detection de-

ployment scheme for securing industrial wireless sen-

sor networks. In 2016 11th International Conference

on Availability, Reliability and Security (ARES), pages

157–166.

Bhuyan, M. H., Bhattacharyya, D. K., and Kalita, J. K.

(2014). Network anomaly detection: methods, sys-

tems and tools. Ieee communications surveys & tuto-

rials, 16(1):303–336.

Blumbergs, B. (2014). Technical analysis of advanced

threat tactics targeting critical information infrastruc-

ture. Technical report.

Caselli, M., Zambon, E., Amann, J., Sommer, R., and

Kargl, F. (2016). Speciﬁcation mining for intru-

sion detection in networked control systems. In

25th USENIX Security Symposium, pages 791–806.

USENIX Association.

Cazorla, L., Alcaraz, C., and Lopez, J. (2016). Cyber stealth

attacks in critical information infrastructures. IEEE

Systems Journal, pages 1–15.

Cheminod, M., Durante, L., Seno, L., and Valenzano, A.

(2016). Detection of attacks based on known vulner-

abilities in industrial networked systems. Journal of

Information Security and Applications. In Press.

Chen, P., Desmet, L., and Huygens, C. (2014). A study

on advanced persistent threats. In IFIP International

Conference on Communications and Multimedia Se-

curity, pages 63–72. Springer.

CISCO Systems (2017). CISCO: Protect-

ing ICS with Industrial Signatures.

http://www.cisco.com/c/en/us/about/security-

center/protecting-industrial-control-systems-

networks-ips.html. [Online; Accessed March

2017].

Control-See (2017). UCME-OPC.

http://www.controlsee.com/u-c-me-opc/. [Online;

Accessed March 2017].

Cyberbit (2017). SCADAShield.

https://www.cyberbit.net/solutions/ics-scada-

security-continuity/. [Online; Accessed March

2017].

CyberX (2017). XSense. https://cyberx-

labs.com/en/xsense/. [Online; Accessed March

2017].

DarkTrace (2017). Enterprise Immune System.

https://www.darktrace.com/technology/#enterprise-

immune-system. [Online; Accessed March 2017].

Federal Ofﬁce for information Security (2016). Indus-

trial Control System Security: Top 10 Threats and

Countermeasures 2016. https://www.allianz-fuer-

cybersicherheit.de. [Online; Accessed March 2017].

Garcia, L., Zonouz, S., Wei, D., and de Aguiar, L. P. (2016).

Detecting plc control corruption via on-device run-

time veriﬁcation. In 2016 Resilience Week (RWS),

pages 67–72.

Ghaeini, H. R. and Tippenhauer, N. O. (2016). Hamids: Hi-

erarchical monitoring intrusion detection system for

industrial control systems. In Proceedings of the

2Nd ACM Workshop on Cyber-Physical Systems Secu-

rity and Privacy (CPS-SPC’16), pages 103–111, New

York, NY, USA. ACM.

Goldenberg, N. and Wool, A. (2013). Accurate modeling of

modbus/tcp for intrusion detection in {SCADA} sys-

tems. International Journal of Critical Infrastructure

Protection, 6(2):63 – 75.

Gyanchandani, M., Rana, J., and Yadav, R. (2012). Tax-

onomy of anomaly based intrusion detection system:

a review. International Journal of Scientiﬁc and Re-

search Publications, 2(12):1–13.

H., K., J., H., A., H., and Wahlster, W. (2013). Recommen-

dations for implementing the strategic initiative indus-

trie 4.0: Securing the future of german manufactur-

ing industry. ﬁnal report of the industrie 4.0 working

group.

Halo Analytics (2017). Halo Vision. https://www.halo-

analytics.com/. [Online; Accessed March 2017].

HeSec (2017). HeSec Smart Agents. http://he-

sec.com/products/. [Online; Accessed March 2017].

ICS-CERT (2016). Overview of Cyber Vulnerabil-

ities. http://ics-cert.us-cert.gov/content/overview-

cyber-vulnerabilities. [Online; Accessed March

2017].

ICS2 (2017). ICS2 On-Guard. http://ics2.com/product-

solution/. [Online; Accessed March 2017].

Jardine, W., Frey, S., Green, B., and Rashid, A. (2016).

Senami: Selective non-invasive active monitoring for

SECRYPT 2017 - 14th International Conference on Security and Cryptography

126

ics intrusion detection. In Proceedings of the 2Nd

ACM Workshop on Cyber-Physical Systems Security

and Privacy (CPS-SPC’16), pages 23–34, New York,

NY, USA. ACM.

Joshi, R., Didier, P., Jimenez, J., and Carey, T. (2017). The

Industrial Internet of Things Volume G5: Connectiv-

ity Framework. Industrial Internet Consortium Re-

port.

Junejo, K. N. and Goh, J. (2016). Behaviour-based attack

detection and classiﬁcation in cyber physical systems

using machine learning. In Proceedings of the 2Nd

ACM International Workshop on Cyber-Physical Sys-

tem Security (CPSS’16), pages 34–43, New York, NY,

USA. ACM.

Khan, A. and Turowski, K. (2016). A survey of current

challenges in manufacturing industry and preparation

for industry 4.0. In In Proceedings of the First Inter-

national Scientiﬁc Conference “Intelligent Informa-

tion Technologies for Industry” (IITI’16), pages 15–

26. Springer International Publishing.

Krotoﬁl, M. and Gollmann, D. (2013). Industrial con-

trol systems security: What is happening? In 11th

IEEE International Conference on Industrial Infor-

matics (INDIN’13), pages 670–675.

Langner, R. (2011). Stuxnet: Dissecting a cyberwarfare

weapon. IEEE Security & Privacy, 9(3):49–51.

Leidos (2016). Insider Threat Detection Platform - Wisdom

ITI. https://cyber.leidos.com/products/insider-threat-

detection. [Online; Accessed March 2017].

evy-Bencheton, C., Marinos, L., Mattioli, R., King, T.,

Dietzel, C., Jan, S., et al. (2015). Threat landscape and

good practice guide for internet infrastructure. Report,

European Union Agency for Network and Information

Security (ENISA).

Lin, C.-T. (1974). Structural controllability. IEEE Transac-

tions on Automatic Control, 19(3):201–208.

Liu, Y., Corbett, C., Chiang, K., Archibald, R., Mukherjee,

B., and Ghosal, D. (2009). Sidd: A framework for de-

tecting sensitive data exﬁltration by an insider attack.

In 42nd Hawaii International Conference on System

Sciences, pages 1–10.

Lontorfos, G., Fairbanks, K. D., Watkins, L., and Robin-

son, W. H. (2015). Remotely inferring device manip-

ulation of industrial control systems via network be-

havior. In IEEE 40th Local Computer Networks Con-

ference Workshops (LCN Workshops’15), pages 603–

610.

McParland, C., Peisert, S., and Scaglione, A. (2014). Mon-

itoring security of networked control systems: It’s the

physics. IEEE Security Privacy, 12(6):32–39.

Mission Secure (2017). MSi Secure Sentinel Platform.

http://www.missionsecure.com/solutions/. [Online;

Accessed March 2017].

Mitre (2017). Common Vulnerabilities and Exposures.

https://cve.mitre.org/. [Online; Accessed March

2017].

Moser, A., Kruegel, C., and Kirda, E. (2007). Exploring

multiple execution paths for malware analysis. In Se-

curity and Privacy, 2007. SP’07. IEEE Symposium on,

pages 231–245. IEEE.

Patcha, A. and Park, J.-M. (2007). An overview of

anomaly detection techniques: Existing solutions

and latest technological trends. Computer networks,

51(12):3448–3470.

Ponomarev, S. and Atkison, T. (2016). Industrial control

system network intrusion detection by telemetry anal-

ysis. IEEE Transactions on Dependable and Secure

Computing, 13(2):252–260.

Rahimian, M. A. and Aghdam, A. G. (2013). Struc-

tural controllability of multi-agent networks: Ro-

bustness against simultaneous failures. Automatica,

49(11):3149–3157.

Sadeghi, A.-R., Wachsmann, C., and Waidner, M. (2015).

Security and privacy challenges in industrial internet

of things. In Proceedings of the 52Nd Annual Design

Automation Conference, DAC ’15, pages 54:1–54:6,

New York, NY, USA. ACM.

Sekar, R., Gupta, A., Frullo, J., Shanbhag, T., Tiwari, A.,

Yang, H., and Zhou, S. (2002). Speciﬁcation-based

anomaly detection: a new approach for detecting net-

work intrusions. In Proceedings of the 9th ACM con-

ference on Computer and communications security,

pages 265–274. ACM.

Sen, J. (2013). Security and privacy issues in cloud com-

puting. Architectures and Protocols for Secure Infor-

mation Technology Infrastructures, pages 1–45.

Siemens (2017). SIMATIC OPC UA.

http://www.industry.siemens.com/topics/global/en/tia-

portal/software/details/pages/opc-ua.aspx. [Online;

Accessed March 2017].

SIGA (2017). SIGA Guard. http://www.sigasec.com. [On-

line; Accessed March 2017].

Singh, S., Sharma, P. K., Moon, S. Y., Moon, D., and Park,

J. H. (2016). A comprehensive study on apt attacks

and countermeasures for future networks and commu-

nications: challenges and solutions. The Journal of

Supercomputing, pages 1–32.

Stone, S. J., Temple, M. A., and Baldwin, R. O. (2015).

Detecting anomalous programmable logic controller

behavior using rf-based hilbert transform features and

a correlation-based veriﬁcation process. International

Journal of Critical Infrastructure Protection, 9:41 –

51.

Sun, Y., Zhang, J., Xiong, Y., and Zhu, G. (2014). Data se-

curity and privacy in cloud computing. International

Journal of Distributed Sensor Networks.

Tsao, T., Alexander, R., Dohler, M., Daza, V., Lozano, A.,

and Richardson, M. (2015). A security threat analy-

sis for the routing protocol for low-power and lossy

networks (rpls). Technical report.

Vern Paxson et al. (2017). The Bro Network Security Mon-

itor. https://www.bro.org/. [Online; Accessed March

2017].

Wallgren, L., Raza, S., and Voigt, T. (2013). Routing at-

tacks and countermeasures in the rpl-based internet of

things. International Journal of Distributed Sensor

Networks.

Wu, D., Rosen, D. W., Wang, L., and Schaefer, D.

(2015). Cloud-based design and manufacturing: A

Analysis of Intrusion Detection Systems in Industrial Ecosystems

127

new paradigm in digital manufacturing and design in-

novation. Computer-Aided Design, 59:1–14.

WurldTech (GE) (2017). OPShield.

https://www.wurldtech.com/products/opshield.

[Online; Accessed March 2017].

Xu, L. D., He, W., and Li, S. (2014). Internet of things in

industries: A survey. IEEE Transactions on Industrial

Informatics, 10(4):2233–2243.

Zhang, K., Liang, X., Lu, R., and Shen, X. (2014). Sybil at-

tacks and their defenses in the internet of things. IEEE

Internet of Things Journal, 1(5):372–383.

Zhao, K. and Ge, L. (2013). A survey on the internet of

things security. In Computational Intelligence and Se-

curity (CIS), 2013 9th International Conference on,

pages 663–667. IEEE.

SECRYPT 2017 - 14th International Conference on Security and Cryptography

128
