Evaluating Impact of Cross-platform Frameworks in Energy

Consumption of Mobile Applications

Matteo Ciman and Ombretta Gaggi

Department of Mathematics, University of Padua, Via Trieste 63, 35121 Padua, Italy

Keywords:

Mobile Applications Development, Cross-platform Frameworks, Energy Consumption.

Abstract:

In this paper we analyze energy consumption of mobile applications using different smartphones sensors, e.g.,

GPS, accelerometer, etc., and features, e.g., acquiring video or audio from the environment. In particular, we

have studied how the use of frameworks for mobile cross-platform development may inﬂuence the amount of

required energy for the same operation. We use an hardware and software tool to measure energy consumption

of the same application, using different sensors, when developed natively or using two frameworks, Titanium

and PhoneGap. Our experiments have shown that frameworks have a signiﬁcant impact on energy consump-

tion which greatly increases compared to an equal native application. Moreover, the amount of consumed

energy is not the same for all frameworks.

1 INTRODUCTION

With the advance of mobile technologies, modern

mobile devices are equipped with an ample set of

sensors, like GPS, accelerometer, light sensor, etc.

The presence of these sensors allows the implementa-

tion of more and more attractive applications, which

can analyze the surrounding environment to better an-

swer to the user’s need. As an example, applications

can use GPS to provide information about interesting

places near the user, the accelerometer to understand

the current user activity (e. g., if he/she is walking,

riding a bike or using a car), and the light sensor to

adapt the screen brightness.

Acquiring data from all these sensors have a cost

in terms of energy. The software implementing the

acquisition of data from sensors and the adaptation

process must conserve battery power since energy is a

vital resource for mobile computing and smartphones

may operate for days without being recharged.

Battery life is, in fact, a critical performance and

user experience metric on mobile devices. As stated

by Bloom et al. (Bloom et al., 2004), battery life is

one of the most important aspects considered by users

when dealing with mobile devices, and most of the

time users request a longer battery life. For this rea-

son, energy consumption is an extremely important

factor to consider when developing applications for

smartphones. Unfortunately, it is difﬁcult for devel-

opers to measure the energy used by their apps both

before and after its implementation.

In this paper, we analyze energy consumption of

mobile applications which acquire data using differ-

ent smartphones sensors, e.g., GPS, accelerometer,

etc., and features, e.g., acquiring video or audio from

the environment. We compare the request in terms of

power consumption of different sensors, with differ-

ent samples frequency. We use the Monsoon Power

Monitor (Monsoon Solutions Inc., 2013) during our

experiments to reduce the impact of external events.

We must note here that this tool requires to have direct

access to the battery, therefore cannot be used with

iOS devices without opening them.

Moreover, we have studied how the use of frame-

works for cross-platform development may inﬂuence

the amount of required energy for the same opera-

tions. Our experiments have shown that frameworks

have a signiﬁcant impact on the total amount of con-

sumed energy, since an application developed using

a cross-platform framework for mobile development

can consume up to 60% more energy than an equal

native application, which means, a strong reduction

in terms of battery life. Moreover, the amount of con-

sumed energy is not the same for all frameworks. This

means that power consumption can be one of the fac-

tors to be considered in the choice between native im-

plementation and using a framework, or in the choice

between two different frameworks.

The paper is organized as follows: related works

are discussed in Section 2. Section 3 describes the

423

Ciman M. and Gaggi O..

Evaluating Impact of Cross-platform Frameworks in Energy Consumption of Mobile Applications.

DOI: 10.5220/0004857604230431

In Proceedings of the 10th International Conference on Web Information Systems and Technologies (WEBIST-2014), pages 423-431

ISBN: 978-989-758-023-9

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

frameworks for cross-platform mobile development

already present in literature. The experiments made

are presented in Section 4. We conclude in Section 5.

2 RELATED WORKS

Other works in literature analyze power consumption

of mobile applications but they usually do not cover

all sensors/features available on smartphones, and do

not consider the use of cross-platform framework for

development of mobile applications.

(Balasubramanian et al., 2009) measure energy

consumption of mobile networking technologies, in

particular 3G, GSM and WiFi. They ﬁnd out that 3G

and GSM incur in tail energy overhead since they re-

main in high power states also when the transfer is

complete. They developed a model for energy con-

sumed by networking activity and an efﬁcient proto-

col that reduces energy consumption of common mo-

bile applications.

(Thompson et al., 2011) propose a model-driven

methodology to emulate the power consumption of

smartphone application architectures. They develop

SPOT, System Power Optimization Tool, a tool that

automates code generation for power consumption

emulation and simpliﬁes analysis. The tool is very

useful since it allows to estimate energy consumption

of potential mobile architecture, therefore before its

implementation. This is very important since changes

after the development can be very expensive. More-

over the tool is able to identify which hardware com-

ponents draw signiﬁcantly more power than others

(e.g, GPS).

(Mittal et al., 2012) propose an energy emulation

tool that allows to estimate the energy use for mo-

bile applications without deploying the application on

a smartphone. The tool considers the network char-

acteristics and the processing speed. They deﬁne a

power model describing different hardware compo-

nents and evaluate the tool through comparison with

real device energy measurements.

PowerScope (Flinn and Satyanarayanan, 1999a;

Flinn and Satyanarayanan, 1999b) is a tool to mea-

sure energy consumption of mobile applications. The

tool calculates energy consumption for each program-

ming structure. The approach combines hardware in-

strumentation to measure current level with software

to calculate statistical sampling of system activities.

The authors show how applications can modify their

behavior to preserve energy: when energy is plenty,

the application allows a good user experience, other-

wise it is biased toward energy conservation.

AppScope (Yoon et al., 2012) is an Android-based

energy metering system which estimates, in real-time,

the usage of hardware components at a microscopic

level. AppScope is implemented as a kernel module

and provides an high accuracy, generating a low over-

head. For this reason, the authors also deﬁne a power

model and measure energy consumption with external

tools to estimate the introduced error, which is, in the

worst case of about 5.9%.

Eprof (Pathak et al., 2012a), is a ﬁne-grained

energy proﬁler for mobile apps, which accurately

captures complicated power behavior of smartphone

components in a system-call-driven Finite State Ma-

chine (FSM). Eprof tries to map the power drawn and

energy consumption back to program entities. The

authors analyzed the energy consumption of 21 apps

from Android Market including AngryBirds, Android

Browser, and Facebook, and they found that third

party advertisement modules in free apps could con-

sume up to 65-75% of the total app energy, and track-

ing user data (e.g., location, phone stats) consumes up

to 20-30% of the total energy. Moreover, smartphone

apps spend a major portion of energy in I/O compo-

nents such as 3G, WiFi, and GPS.

Pathak et al. (Pathak et al., 2012b) study the

problem of no-sleep energy bugs, i. e., errors in en-

ergy management resulting in the smartphone com-

ponents staying on for an unnecessarily long period

of time. They develop a static analysis tool to detect,

at compile-time no-sleep bug in Android apps.

In other papers, the authors compare different

framework for cross-platform mobile development

according to a set of features. (Heitk

otter et al.,

2013) compare jQuery Mobile (Firtman, 2012), Sen-

cha Touch (Sencha Inc., 2013), The-M-Project (Pana-

coda GmbH., 2013) and Google Web Toolkit com-

bined with mgwt (Kurka, 2013) according to a partic-

ular set of criteria, which includes license and costs,

documentation and support, learning success, user in-

terface elements, etc. They conclude that jQuery Mo-

bile is a good solution for simple applications or as

ﬁrst attempt in developing mobile apps, while Sencha

Touch is suited for more complex applications.

(Palmieri et al., 2012) evaluate Rhodes (Motorola

Solutions, Inc, 2013), PhoneGap (Apache Software

Foundation, 2013), dragonRAD (Seregon Solutions

Inc., 2013) and MoSync (MoSync Inc., 2013) with

particular attention to the programming environment

and the APIs they provide. The authors provide an

analysis of the architecture of each framework and

they conclude highlighting Rhodes over other frame-

works, since this is the only one which supports both

MVC framework and web-based services.

(Ciman et al., 2014) evaluate different cross-

platform frameworks, i.e. Phonegap, Titanium,

WEBIST2014-InternationalConferenceonWebInformationSystemsandTechnologies

424

jQuery Mobile and MoSync, with the focus on ap-

plications with animations, i.e. games. Besides the

standard evaluation parameters like IDE, debug tools,

programming complexity, etc., they evaluate more

mobile and games-related aspects like APIs for ani-

mations, mobile devices supported, support for Na-

tive User Interface, performances etc. They conclude

that, according to the actual state of art of the frame-

works, Titanium is the best framework, since it sup-

ports animations and transitions, and its performances

are good even in case of complex applications.

Issues about performances are discussed in (Char-

land and Leroux, 2011). They stated frameworks

based on web technologies experience a decrease in

performances when the applications implement tran-

sition effects, effects during scrolling, animations,

etc., but this problem affects essentially games, while

the loss in performances are unnoticeable in business

application, i. e., applications which support business

tasks.

All the addressed works make a critical analysis

of the chosen frameworks according to criteria which

never include power consumption. In some case they

include performances which are considered in terms

of user experience. In this paper we want to study

how the use of a cross-platform framework for mobile

device may affect the energy consumption of the ﬁnal

application with respect to native development.

3 FRAMEWORKS FOR

CROSS-PLATFORM MOBILE

DEVELOPMENT

According to Raj and Tolety (Raj and Tolety, 2012),

frameworks for cross-platform development can be

divided into four approaches: web, hybrid, inter-

preted and cross compiled. They highlight strength

and weakness of each approach, concluding that a

preferred solution for each kind of application does

not exist, but the decision about which framework to

use should be made considering the features of the

application to be developed. To help the developers

in this decision, they provide a matrix which shows

which are the best choices to develop a speciﬁc fea-

ture. This classiﬁcation can help to correctly interpret

the results of our tests.

The Web Approach (WA) allows the program-

mer to develop a web application using HTML, CSS

and Javascript. Given the new emerging features of

HTML5 and CSS3, these technologies allow the cre-

ation of rich and complex applications, therefore their

use cannot be considered a limitation. The applica-

Figure 1: Architecture of an application using the WA.

tion can be accessed through a mobile device using

only its integrated browser, connecting to the right

public internet address. Figure 1 shows this approach.

In this way, a full devices support is guaranteed (lim-

ited only by the maturity of the native browser respect

to the standard technologies speciﬁcations), but the

problems arise when the application needs to access

to the smartphone’s sensors, because this feature is

not provided for web applications. Moreover, the user

does not interact with a mobile application, but he/she

must run the browser to access a web page containing

the web application. An example of framework using

the WA is jQuery Mobile (Firtman, 2013).

The Hybrid Approach (HA) is a middle way be-

tween native and web approach. In this case, the ap-

plication operates in two different ways. It uses the

webkit rendering engine to display controls, buttons

and animations. The webkit engine is therefore re-

sponsible to draw and manage user interface objects.

On the other site, the framework and its APIs provide

access to device features and use them to increase

the user experience. In this case, the application will

be distributed and installed and appears on the user

device as native mobile applications, but the perfor-

mances are often lower than native applications be-

cause its execution requires to run the browser render-

ing engine. An example of this kind of frameworks is

PhoneGap, also known as Apache Cordova (Apache

Software Foundation, 2013), and the architecture of

the ﬁnal application is shown in Figure 2.

With the Interpreted Approach (InA), the devel-

oper has the possibility to write the code of the ap-

plication using a language which is different from

languages natively supported by the different plat-

forms. An example can be Javascript: developers who

already knows this language are simply required to

learn how to use the APIs provided by the framework.

When the application is installed on the device, the ﬁ-

nal code contains also a dedicated interpreter which is

used to execute the non-native code. Even in this case,

the developer has access to the device features (how

EvaluatingImpactofCross-platformFrameworksinEnergyConsumptionofMobileApplications

425

Figure 2: Hybrid approach application architecture.

many and which features depend on the chosen frame-

work) through an abstraction layer. This approach al-

lows the developer to design a ﬁnal user interface that

is identical to the native user interface without any

additional line of code. This approach can reach an

high level of reusable code, but can reduce a little the

performances due to the interpretation step. Titanium

(Appcelerator Inc., 2013a) is an example of this kind

of framework and Figure 3 shows the architecture of

the framework.

Figure 3: Interpreted Approach architecture.

The last approach, the Cross Compiled Approach

(CCA), lets the developer write only one application

using a common programming language, e. g. C#.

Frameworks which follow this approach generate, af-

ter compilation, different native applications for dif-

ferent mobile platforms. The ﬁnal application uses

native language, therefore can be considered a native

mobile application to all intents and purposes. There-

fore, this approach lets the programmer have full ac-

cess to all the features provided by smartphones and

the performances can be considered similar (even if

not equal) to the native approach for simple applica-

tion. In fact some tests have shown that for complex

applications the native solution is better since the gen-

erated code gives worst performances of the resulting

application, compared to code written by a developer.

An example of this framework is Mono (Monologue

Inc., 2013).

4 EXPERIMENTS

Our goal is to provide objective information about en-

ergy consumption of the most common sensors with

which smartphones are usually equipped. To per-

form the best measure of energy consumption, it is

important to avoid inﬂuences from external factors.

A simple possibility is to run a background appli-

cation that measures battery power at ﬁxed intervals

of time. This solution is adopted by some of the re-

lated works discussed in Section 2, but clearly intro-

duces an overhead and must consider the possibility

that other external events like call, messages, network

problems and connectivity may inﬂuence energy con-

sumption. Moreover these external events are almost

unpredictable and unlikely reproducible, thus leading

to unequal test sets.

4.1 Study Setup

For the reason mentioned before, during our experi-

ments we use the Monsoon Power Monitor (Monsoon

Solutions Inc., 2013). The hardware device comes

with a software tool, the Power Tool, which gives the

possibility to analyze data of energy consumption of

any device that uses a single lithium battery. The in-

formation retrieved are energy consumption, average

power and current, expected battery life, etc. These

data are extremely important because can help the de-

veloper to understand which tasks use most of the en-

ergy of the battery, for how much time, etc. Moreover,

it helps to analyze and improve the application code

according to its power consumption. Using data ac-

quired by Power Monitor, it is possible to understand

if and where some energy can be saved increasing bat-

tery life, an extremely important aspect when working

with mobile devices. Figure 4 shows the hardware

setup of the system.

Our goal is to compare energy consumption of

applications developed in a native way or using a

Figure 4: Hardware setup of the system.

WEBIST2014-InternationalConferenceonWebInformationSystemsandTechnologies

426

cross-platform framework, and to compare perfor-

mances, in terms of energy consumption, among dif-

ferent frameworks. The application used for our anal-

ysis allows to choose between several sensors and the

frequency with which they retrieve data and update

the user interface showing the retrieved data. This

application can be considered a sort of lower bound

for applications behavior in terms of energy consump-

tion, because usually applications that collect data

from sensors, perform several computation before up-

dating the user interface.

As explained before, to use the Power Monitor

tool it is necessary to have direct access to the bat-

tery of the smartphone, in order to be able to connect

the entire system and to measure the consumed en-

ergy. For this reason, we made our comparison using

an Android device with removable battery, because

the iOS devices do not allow to have direct access to

the battery in a safe way.

To compare energy consumption of mobile cross-

platform frameworks, we select Titanium and Phone-

Gap. As already explained in Section 3, these two

frameworks belong to two different categories. Ti-

tanium belongs to the interpreted frameworks, while

PhoneGap follows an hybrid approach. In this way,

ﬁrst of all we can compare the native approach and its

consumption with two different cross-platform frame-

works. Then, we can even compare two different

frameworks, getting information about the less expen-

sive, in terms of power consumption, information that

can inﬂuence the framework choice when considering

mobile application development.

Our test smartphone is a Samsung Galaxy i9250.

The (theoretical) capacity of the battery is 1750mAh.

Even if this smartphone is not an up-to-date device,

what is important for us is if the usage of a cross-

platform framework has negative effects on energy

consumption, and in which measure, for applications

that use smartphone’s sensors. With this question in

mind, is easy to see that what we want to know, af-

ter our experiments, is how much (in percentage) the

energy consumption increases. Even if characteris-

tics and performances of sensors may vary between

different smartphones, our tests are performed on the

same device and comparisons are made on the per-

centage increase of energy consumption, to limit the

inﬂuence of the chosen device on our ﬁnal results. We

must note here, that many devices, although different

in terms of brand and model, share the same hardware

components for sensors.

To make our tests, we used three different appli-

cations: a native mobile application, one built with

PhoneGap and another one used to test the Titanium

framework. We developed from scratch the applica-

tion used to test the native solution and the Phonegap

framework. These applications let the user chooses

the sensor to test and the sampling frequency. In-

stead, we tested the Titanium framework using the

Kitchen Sink app provided by Appcelerator (Appcel-

erator Inc., 2013b), a sample application built to show

the different APIs and features provided by the frame-

work.

All the applications retrieve data from the ac-

celerometer, the compass and the GPS tests and dis-

play this information simply as a numerical value with

a label. To test the microphone API, we record audio

from the microphone and save it on the device as a

3GPP ﬁle. To test energy consumption due to the use

for the camera, all the developed applications show

the images captured from the camera for a predeﬁned

time interval, and take a picture at its end. Each test

lasted two minutes. Previous experiments show that,

after an initial interval, the duration of a test does not

inﬂuence the ﬁnal value of the expected battery life,

and we chose this amount of time to get a stable ﬁnal

value from the system. The version of the Android

API was 4.2.2, PhoneGap was version 3.0.0 while Ti-

tanium SDK was version 3.2.

4.2 Results

In this section we report the ﬁnal results of our anal-

ysis. We analyze the most common sensors which

can be used through the APIs provided by at least

one the two analyzed frameworks. For each sensor,

our application (either native or developed using a

cross-platform framework) starts to acquire data com-

ing from the selected sensor and display them on the

user screen.

We made our experiments keeping the screen on,

since this situation is much more adherent to reality

where it’s very difﬁcult that an user interact with an

application keeping the screen off: consider, as an ex-

ample, Google Maps, which uses the GPS sensor to

capture the position of the user and to give the correct

directions.

Measures are repeated several times, in order to

get a mean ﬁnal value of each test. The main value

we are interested in is the consumed energy, which

shows how much energy is used by that particular

task during this two minutes test. The smartphone

was in ﬂight mode (thus unable to receive any phone

call or message that could arbitrarily increase energy

consumption) and with WiFi and Bluetooth connec-

tivity are turned off.

To get an idea about energy consumption of an ap-

plication, we need a base value to compare with. For

our purpose, we decided to measure the consumed

EvaluatingImpactofCross-platformFrameworksinEnergyConsumptionofMobileApplications

427

energy when the smartphone is turned on, with the

screen on and without any running applications. This

is the base value for our analysis. Clearly, it is quite

impossible to measure the same value from another

smartphone, but, since our discussion does not deal

with absolute values of energy consumption, but with

the increment in energy consumption in term of per-

centage, this initial value is important for our com-

putation. Using the test smartphone, the consumed

energy in two minutes is 6047,31 µAh. Moreover, the

analysis of the increment in energy consumption re-

ported in percentage helps to give results which are

not tightly related to the chosen hardware.

Table 1 shows the results of our experiments, i.

e., it compares how the consumed energy increases

when the smartphone uses its sensors with a native

application, or with applications developed using the

two frameworks, PhoneGap and Titanium. We must

note here that native development provides full access

to all the available sensors of the device, while the

number and type of supported sensors may vary be-

tween different cross-platform frameworks, depend-

ing on the state of the art of the frameworks them-

selves. For example, Titanium provides access to the

microphone and record audio data only for iOS de-

vices and not for Android devices, while PhoneGap

supports this features for iOS, Android and Windows

Phone.

The columns ∆ of Table 1 show how the con-

sumed energy increases compared to the consumed

energy of our base value, i.e. the smartphone with the

screen on, without running applications. This value

gives an idea of how much more expensive is to per-

form a particular task among our initial idle state.

As it is easy to see, the differences between power

consumed by the native app and the solutions devel-

oped with a framework for cross-platform develop-

ment is very high.

Let us begin the analysis with the comparison

between applications which do not capture any data

from sensors. The purpose of this test is essentially to

investigate if the adoption of a cross-platform frame-

work instead of a native development requires more

energy consumption simply to “show” the applica-

tion without any computation behind. The results are

shown in the ﬁrst row of Table 1 denoted with the

label “Only App”. As we can see, the energy con-

sumption increases of about 7% for PhoneGap and

slight more than 2% for Titanium, i. e., the adoption

of a cross-platform framework produces, basically, a

little more expensive applications in terms of power

consumption, and this increment is not equal for all

frameworks.

Considering applications that use smartphones

sensors to retrieve data, we can measure differences

only for sensors that are supported at least from one of

the two frameworks. The measurements made show

that the usage of the accelerometer requires about

60% more energy using the PhoneGap application in-

stead of the native one. This is an extremely high

value, which means that the usage of this sensor in a

cross-platform application is really a battery consum-

ing task that can decrease user experience. Therefore,

if the application needs to retrieve data from the ac-

celerometer it is necessary to consider if it would be

better to develop different, more performing, native

applications for each platform.

The result reported for the Titanium framework

needs a particular attention. Data reported on the ta-

ble could lead to the wrong conclusion that it cost less

energy to retrieve data with the Titanium framework

in respect to the PhoneGap solution. The reason for

this lower consumption is that the update frequency

for the native (and the PhoneGap) application is about

a sample every 64ms, while the Titanium frequency is

about a sample every 600ms. To read data and update

the user interface with a lower frequency (about 10

times lower) clearly reduces the amount of required

energy. To be able to compare the performances of the

Titanium framework, we used the PhoneGap applica-

tion to acquire data at the right frequency (600ms) and

we compared the ﬁnal results (see Table 2). What we

got is that, with the same update frequency, the delta

of PhoneGap is about +40%, while for Titanium is

about +98%. This means that, if compared together,

the PhoneGap framework works better than the Tita-

nium framework (about 60%).

All the cross-platform frameworks perform worst

than the native solution also for data acquisition from

compass and GPS: about 45% more power for acqui-

sition from compass and about 10% more power for

acquisition from the GPS using the PhoneGap frame-

work; a little less than 5% more power for acquisition

of data from GPS using Titanium, compass is not sup-

ported by Titanium yet.

The only sensor for which the difference in power

consumption is very low is the use of camera to take

pictures. In this case, the amount for energy con-

sumed with a native application and with an applica-

tion developed with a cross-platform framework dif-

fers of 8% - 12%, which is very low if we consider the

total amount of energy required to use the camera (see

the “Camera” row of Table 1). This behavior can be

explained because in this case the cross-platform ap-

plication makes only one call to the system API, and

waits from the system the result (an image) and so the

difference between the native and the cross-platform

solution is really low.

WEBIST2014-InternationalConferenceonWebInformationSystemsandTechnologies

428

Table 1: Energy consumption comparison between native applications and apps developed with a framework for cross-

platform development. Note that data marked with (

∗

) use a different updating frequency.

Native PhoneGap Titanium

Sensor Consumed ∆ (%) Consumed ∆ (%) Consumed ∆ (%)

Energy (µAh) Energy (µAh) Energy (µAh)

Only App 7705,54 +27,42% 8130,85 +34,45% 7860,97 +29,99%

Accelerometer 9179,99 +51,80% 12849,82 +112,49% 11972,16

∗

+97,97%

∗

Compass 9489,85 +56,93% 12124,6 +100,50% - -

Microphone (Rec) 8120,92 +34,29% 8404,71 +38,98% - -

GPS 9301,48 +53,81% 9947,60 +64,50% 9577,27 +58,37%

Camera 21857,38 +261,44% 22347,52 +269,54% 22576,45 +273,33%

A similar situation takes place for data acquired

from the microphone (although test data are not avail-

able for the Titanium framework) and from the GPS.

In the last case the difference, in terms of energy con-

sumption, ranges between 5 and 11%.

Comparing the frameworks PhoneGap and Tita-

nium, the overhead of energy consumed introduced

by the two frameworks is particularly different when

the user interface has to be updated frequently. This

difference comes from the nature of the two frame-

works. As already mentioned in Section 3, PhoneGap

belongs to the hybrid family, while Titanium to the

interpreted frameworks. This means that if we com-

pare the two different platforms in terms of perfor-

mances and energy consumption, the hybrid applica-

tion is better, since the consumed energy by this appli-

cation is lower, meaning that the overhead introduced

is lower.

Another possibility to compare different develop-

ment frameworks, and in particular how sensors us-

age affects application performances and energy con-

sumption, would be to test these applications without

updating the values of the retrieved information on

the screen or turning off the screen while perform-

ing operations. In this case, the differences between

the native solution and the cross-platform solutions

when acquiring data from accelerometer or compass

are much more lower, about 20%. Unfortunately, this

is only a theoretical result. In fact, every application

that retrieves data from sensors does not use this raw

data immediately, but it usually elaborates the data

and updates the user interface accordingly. Therefore,

to use this theoretical results to promote the use of

cross-platform framework would not adhere to the re-

ality because we would not consider two extremely

important parts of the applications, i. e., data elabora-

tion and user interface management.

If we compare together the same cross-platform

application, what we can note is that the difference in

terms of consumed energy to show or not to show data

from sensors is about 80% for both the framework.

This essentially means that, without concern on the

chosen cross-platform framework, the most expensive

task for it is to update the User Interface.

Unlike Titanium, PhoneGap allows the developer

to decide the frequency to retrieve data from sensors.

This is an extremely important option, because lets

the developer to deﬁne the right update frequency de-

pending on the target application and the needs of

data. This possibility is available for both the ac-

celerometer and the compass sensor. In this cases,

we made several test at predeﬁned update frequen-

cies (60ms, 150ms, 300ms, 600ms) to see how, and

in which measure, changing the update frequency af-

fects energy consumption. The results are shown in

Table 2. As it is easy to see, if the update frequency

decreases, the consumed energy decreases, with a dif-

ference that can reach 70% between 60ms and 600ms

update frequency. This means that the developer has

to pay extremely attention when developing a cross-

platform application, because if the user experience

do not requires an extremely fast update, it is useful

to reduce the update frequency of sensor data in order

to save energy, and so battery life.

5 CONCLUSION

Due to the diffusion of different smartphones and

tablet devices from different vendors, the cross-

platform development approach, i. e., to develop only

one single application and distribute it to different de-

vices and mobile platforms, is growing and becom-

ing extremely important. This cross-platform devel-

opment incorporates several approaches, i. e., web,

hybrid, interpreted or cross compiled. All these ap-

proaches have several positive and negative aspects,

either from a developer or a user point of view.

Many papers address the problem of how to

choose the best framework for the development of a

particular application, but, to the best of our knowl-

edge, no one considers the power consumption as one

of the key issue to make a correct choice.

In this paper we analyze the inﬂuence of the dif-

ferent approaches on energy consumption of mobile

EvaluatingImpactofCross-platformFrameworksinEnergyConsumptionofMobileApplications

429

Table 2: Consumed energy using different sampling frequencies to capture data with PhoneGap.

Consumed Energy increase (%)

Sensor 60ms 150ms 300ms 600ms

Accelerometer +112,49% +70,06% +49,84% +40,25%

Compass +100,50% +75,31% +52,92% +46,62%

devices, in particular for the Hybrid (PhoneGap) and

the Interpreted (Titanium) approach. We compared

the performances of a simple application, built with

a particular framework, that retrieves data from sen-

sors and updates the user interface, to a native appli-

cation with the same behavior, to measure differences

in terms of power consumption. Despite other pre-

vious analysis, we do not use a software to measure

energy consumption since it introduces a not valu-

able overhead; for this reason we used the Monsoon

Power Tool which allows to measure, through hard-

ware links, consumed energy and to understand how

this consumption increases with the two frameworks.

Our comparison shows that, visualization of data

(business applications) perform better on the inter-

preted approach (Titanium), that can be a good so-

lution for simple applications that do not retrieve data

from sensors, e. g., on-line shopping, home banking,

games which do not use accelerometer, etc. More-

over, the two analyzed frameworks, PhoneGap and

Titanium, have very similar performances for Camera

and GPS.

A particular sensor needs speciﬁc discussion.

Even if Titanium seems to be the right choice if en-

ergy consumption is a key issue, our experiments

have shown that it fails in case of retrieval of data

from accelerometer for two reasons: the available API

does not allow to impose an update frequency, and

compared to other framework with the same update

frequency it consumes about 60% more energy than

PhoneGap. This result derives from the Interpreted

approach: the necessary interpretation step can be ex-

tremely expensive and lead to more energy consump-

tion. We must note here that this sensor consume a lot

of energy, therefore if the application make a strong

use of the accelerometer, the developer has to con-

sider also the native solution.

The results that we got show that a cross-platform

approach involves an increase in terms of energy con-

sumption that is extremely high, in particular in pres-

ence of an high usage of sensors data and user inter-

face updates. This increase can vary even in order

of about 60%, meaning that it is important to choose

the right framework to preserve the battery duration

and to avoid negatively affecting user experience with

usage of a cross-platform framework during develop-

ment. In fact, several research studies have shown that

energy consumption and battery life are the most im-

portant aspects considered by mobile devices users.

The results provided are clearly related to the state

of art of the framework under examination at the time

of writing. This means that, they can change in the

future according to the improvements of the frame-

works.

As future works, we plan to increase the total

number of analyzed frameworks and to add HTML5

applications in our comparisons, trying to cover all

the different approaches. Moreover, we will try to

follow the development of the different frameworks

in order to reach a complete analysis of the different

sensors provided by the smartphones and their con-

sumption in user applications.

REFERENCES

Apache Software Foundation (2013). Phonegap, http://

phonegap.com/.

Appcelerator Inc. (2013a). Titanium, http://

www.appcelerator.com/platform/titanium-platform/.

Appcelerator Inc. (2013b). Titanium Mobile Kitchen Sink

Demo, https://github.com/appcelerator/KitchenSink.

Balasubramanian, N., Balasubramanian, A., and Venkatara-

mani, A. (2009). Energy consumption in mobile

phones: a measurement study and implications for

network applications. In Proceedings of the 9th ACM

SIGCOMM conference on Internet Measurement Con-

ference, IMC ’09, pages 280–293.

Bloom, L., Eardley, R., Geelhoed, E., Manahan, M., and

Ranganathan, P. (2004). Investigating the relationship

between battery life and user acceptance of dynamic,

energy-aware interfaces on handhelds. In Proceedings

of the International Conference Human Computer In-

teraction with Mobile Devices & Services, pages 13–

24.

Charland, A. and Leroux, B. (2011). Mobile application de-

velopment: web vs. native. Communications of ACM,

54(5):49–53.

Ciman, M., Gaggi, O., and Gonzo, N. (2014). Cross-

platform mobile development: A study on apps with

animations. In Proceedings of the 29th Annual ACM

Symposium on Applied Computing, SAC’14.

Firtman, M. (2012). jQuery Mobile: Up and Running -

Using HTML5 to Design Web Apps for Tablets and

Smartphones. O’Reilly Media.

Firtman, M. (2013). jquery mobile,

http://jquerymobile.com/.

Flinn, J. and Satyanarayanan, M. (1999a). Energy-aware

adaptation for mobile applications. In Proceedings of

WEBIST2014-InternationalConferenceonWebInformationSystemsandTechnologies

430

the seventeenth ACM Symposium on Operating Sys-

tems Principles, SOSP ’99, pages 48–63.

Flinn, J. and Satyanarayanan, M. (1999b). Powerscope: A

tool for proﬁling the energy usage of mobile applica-

tions. In Proceedings of the Second IEEE Workshop

on Mobile Computer Systems and Applications, WM-

CSA ’99, Washington, DC, USA. IEEE Computer So-

ciety.

Heitk

otter, H., Hanschke, S., and Majchrzak, T. (2013).

Evaluating cross-platform development approaches

for mobile applications. In Cordeiro, J. and Krempels,

K.-H., editors, Web Information Systems and Tech-

nologies, volume 140 of Lecture Notes in Business

Information Processing, pages 120–138. Springer

Berlin Heidelberg.

Kurka, D. (2013). mgwt - Making gwt Work with Mobile.

http://www.m-gwt.com/.

Mittal, R., Kansal, A., and Chandra, R. (2012). Empow-

ering developers to estimate app energy consumption.

In Proceedings of the 18th annual International Con-

ference on Mobile Computing and Networking, Mobi-

Com ’12, pages 317–328.

Monologue Inc. (2013). Mono framework, http://www.

mono-project.com/.

Monsoon Solutions Inc. (2013). http://www.msoon.com/

LabEquipment/PowerMonitor/.

MoSync Inc. (2013). MoSync http://www.mosync.com.

Motorola Solutions, Inc (2013). Rhodes

http://www.motorolasolutions.com/us-en/rhomobile+

suite/rhodes.

Palmieri, M., Singh, I., and Cicchetti, A. (2012). Compar-

ison of cross-platform mobile development tools. In

16th International Conference on Intelligence in Next

Generation Networks, ICIN ’12, pages 179–186.

Panacoda GmbH. (2013). The-m-project http://www.the-

m-project.org/.

Pathak, A., Hu, Y. C., and Zhang, M. (2012a). Where is the

energy spent inside my app?: Fine grained energy ac-

counting on smartphones with eprof. In Proceedings

of the 7th ACM European Conference on Computer

Systems, EuroSys ’12, pages 29–42.

Pathak, A., Jindal, A., Hu, Y. C., and Midkiff, S. P. (2012b).

What is keeping my phone awake?: Characterizing

and detecting no-sleep energy bugs in smartphone

apps. In Proceedings of the 10th International Confer-

ence on Mobile Systems, Applications, and Services,

MobiSys ’12, pages 267–280.

Raj, R. and Tolety, S. (2012). A study on approaches to

build cross-platform mobile applications and criteria

to select appropriate approach. In Annual IEEE India

Conference, INDICON ’12, pages 625–629.

Sencha Inc. (2013). Sencha touch, http://www.sencha.

com/products/touch.

Seregon Solutions Inc. (2013). dragonrad http://dragonrad.

com/.

Thompson, C., Schmidt, D. C., Turner, H. A., and White,

J. (2011). Analyzing mobile application software

power consumption via model-driven engineering. In

Benavente-Peces, C. and Filipe, J., editors, PECCS,

pages 101–113. SciTePress.

Yoon, C., Kim, D., Jung, W., Kang, C., and Cha, H. (2012).

Appscope: Application energy metering framework

for android smartphones using kernel activity mon-

itoring. In Proceedings of the 2012 USENIX Con-

ference on Annual Technical Conference, USENIX

ATC’12, pages 36–36, Berkeley, CA, USA. USENIX

Association.

EvaluatingImpactofCross-platformFrameworksinEnergyConsumptionofMobileApplications

431
