Hadoop-based Framework for Information Extraction from Social Text

Ferdaous Jenhani, Mohamed Salah Gouider and Lamjed Bensaid

Department of Computing, SMART Laboratory,

Institut Superieur de Gestion de Tunis, Universite de Tunis, Rue de la Liberte, Le Bardo, Tunisia

Keywords:

Hadoop, Social Data, Twitter, Information Extraction, Drug Abuse.

Abstract:

Social data analysis becomes a real business requirement regarding the frequent use of social media as a new

business strategy. However, their volume, velocity and variety are challenging their storage and processing. In

a previous contribution (Jenhani et al., 2016a, 2016b), we proposed an events extraction system in which we

focused only on data variety and we did not handle volume and velocity dimensions. So, our solution cannot

be considered a big data system.

In this work, we port previously proposed system to a parallel and distributed framework in order to reduce

the complexity of task and scale up to larger volumes of data continuously growing. We propose two loosely

coupled Hadoop clusters for entity recognition and events extraction. In experiments, we carried time test and

accuracy test to check the performance of the system on extracting drug abuse behavioral events from 1000000

tweets. Hadoop-based system achieves better performance compared to old system.

1 INTRODUCTION

Nowadays, social media are becoming used for busi-

ness purposes which created a new source of informa-

tion rich with knowledge useful to make better deci-

sions in competitive environments. In the last recent

years their analysis becomes the interest of research

community, data scientists and industrials in order to

extract structured information mainly entities, rela-

tions and events from user-generated content. In (Jen-

hani et al., 2016a, 2016b), we combined natural lan-

guage processing, linguistic rules and machine learn-

ing techniques to extract meaningful, structured and

coherent information. However, we did not handle

data volume and velocity which are main challenges

of building big data solution. In fact, used technolo-

gies fail to store and process continuously growing

volumes of data, on one hand. On the other hand,

the proposed solution is complicated since it com-

bines many technologies so that cannot be straightfor-

ward applied to data generated in very high frequency

and bring real time results. In fact, rapidly ingest-

ing, storing, and processing big data requires a cost-

effective infrastructure that can scale with the amount

of data and the scope of analysis. Therefore, we port

the system to parallel programming model namely

Hadoop. Hadoop is the most pragmatic solution for

managing huge volume of data generated in high fre-

quency thanks to its parallel programming model and

distributed storage. Indeed, we propose a parallel and

distributed framework to implement information ex-

traction process and reduce the complexity of the task

thanks to Map Reduce paradigm and HDFS storage

in distributed clusters. We focus mainly on two in-

formation extraction tasks; named entity recognition

and events extraction. Regarding the complexity of

the handled tasks, we propose two loosely coupled

clusters; one for each. In order to check the perfor-

mance of the system, we carried out run time test by

comparing running time of the solution implemented

as standard java application and when implemented

in Hadoop framework. Data crawling and HDFS load

time test and accuracy test by measuring precision,

recall and F-measure. Running time and HDFS load

linearity face to data volume is not strange in a par-

allel and distributed system. However, how this af-

fects the accuracy is very important. The system is

tested on twitter data for extracting drug abuse behav-

ioral events and have shown improvement of accuracy

when the volume of data increases.

The paper is organized as follows; in section two

we investigate the various big data solutions for infor-

mation extraction from social media data. Hadoop,

the most famous and reputed big data technology used

in our system is presented in section three. The pro-

posed system is composed of two clusters namely the

named entity recognition cluster (NER-Hadoop Clus-

ter) and events extraction cluster (EE-Hadoop Clus-

Jenhani F., Salah Gouider M. and Bensaid L.

Hadoop-based Framework for Information Extraction from Social Text.

DOI: 10.5220/0006501402330237

In Proceedings of the 9th International Joint Conference on Knowledge Discovery, Knowledge Engineering and Knowledge Management (KDIR 2017), pages 233-237

ISBN: 978-989-758-271-4

ter) presented in section four. Implementation and test

details are discussed in section ﬁve. Finally, we con-

clude in section six.

2 STATE OF THE ART

Social data are the most important big data type han-

dled and analyzed by data scientists regarding the rich

information they embed. However, they are complex

since they are unstructured, informal, conversational,

voluminous and generated in a very high frequency.

In fact, by the increase of data volumes, data scientists

and researchers are convinced that natural language

processing is no longer possible on a single com-

puter whatever its memory size or processing speed.

Therefore, the use of big data technologies based on

distributed storage and parallel computing model is

the solution to reduce the complexity of the task and

achieve analysis goals. Hadoop is the most popular

distributed framework and commonly used big data

technology by scientists and industrials. It is used

in Trendminer system (Preotiuc-Pietro et al., 2012)

which is a real time system for social media text anal-

ysis based on Hadoop Map Reduce framework in or-

der to decrease the complexity of analyzing terabytes

of tweets, improve the performance of pre-processing

and extract structured information like named entities.

Trendminer without Hadoop processes only 0.51 mil-

lions of Tweets in one hour. However, with Hadoop,

it processes 7.6 million Tweets for the same period.

GeLo (Nesi et al., 2014) is a hybrid system for geo-

graphic information extraction from web pages com-

posed of web crawler, geographic information ex-

traction part and a geo-coding module. The crawler

of the system is based on Hadoop. Authors relied

on the use of distributed and parallel framework for

web information retrieval. Unlike KOSHIK frame-

work (Exner et al., 2014) which used Avro for web

documents serialization from web sources to HDFS.

Hadoop MapReduce engine is used to parallelize nat-

ural language processing, annotation and querying of

annotated data. NLP tasks including tokenization, pos

tagging and parsing are implemented in map reduce

jobs. Querying is achieved thanks to Hive and Pig ca-

pabilities. In (Prabhakar Benny et al., 2016), authors

proposed a system for entity resolution which heart is

map reduce functions. Connected to data stream col-

lector and after preprocessing, data is matched to a set

of existing rules. If entities match existing rules, the

rules are updated and new entities are stored in a data

base. If not, sets of blocks of entities are generated

and promoted to the map phase for similarity com-

putation and an average similarity is generated which

is the input of the reduce function in order to com-

pute a threshold value and make comparison. Tested

on Google and Amazon product bench mark data, the

system achieved 70% average accuracy. An emerging

research is about opinion mining and sentiment anal-

ysis in social data especially Twitter. In (Ramesh et

al., 2015, Ha et al., 2015) authors used Hadoop data

ﬁle system for social data storage. Sentiment com-

putation algorithms are divided between map reduce

functions to improve processing time and process the

large volume of social data thanks to parallel and dis-

tributed computing logic. In (Ha et al., 2015), authors

used four nodes for Hadoop cluster implementation.

Experiments showed a stable memory usage regard-

less the data size which is a maximum 2.5% and a

minimum 0.10%. As well as a stable CPU load espe-

cially for master node. The time processing for sen-

timent analysis increased linearly from 26s to 68s in

accordance with the scale of the data sets. Concern-

ing accuracy, sentiment analysis results using Hadoop

are close to results obtained with a manual process. In

(Sunil et al., 2014), contributors implemented a set of

functions for sentiment analysis in Twitter based on a

sentiword dictionary. The proposed solution achieved

an interesting accuracy average of 72% and impor-

tant time efﬁciency thanks to distributed processing

which reduced access time and response time eventu-

ally. Sarcasm is a type of sentiment expressing neg-

ative feelings using positive words. It is hard to de-

tect in textual data. In (Bharti et al., 2016) authors

proposed hadoop-based framework for sarcastic con-

tent detection in tweets using map reduce program-

ming model. Then a tweet is either, actual positive,

actual negative, sarcastic or neutral. Hadoop clus-

ter composed of ﬁve nodes is implemented. The use

of hadoop showed an interesting decrease of prepro-

cessing and processing time. In (Dhamodaran et al.,

2015), Hadoop is used to build an automatic emer-

gency alert system by crawling tweets, storing them

in an HDFS and extracting disaster keywords as well

as location information using map reduce engine.

3 HADOOP TECHNOLOGY

Hadoop is an open source project managed by Apache

software foundation and adopted by many organiza-

tions such as Google, Yahoo, Facebook and Amazon.

It is the framework that allows distributed processing

of large data sets across clusters of computers using

simple programming models which allow big prob-

lems to be broken down into smaller tasks so that

analysis could be easily, quickly and cost effectively.

Its hardware architecture is designed to scale up from

single server to thousands of machines, each offering

local computation and storage, able to detect failures,

and self-adjust to continue to operate without inter-

ruption and without data loss thanks to data replica-

tion technique. Hadoop has two main components

(White, 2011):

• Hadoop Data File System-HDFS: It offers a dis-

tributed storage of data in ﬁles across clusters of

servers. It is a reliable, high-bandwidth, low-cost

data storage technique.

• Map Reduce engine: a programming model com-

posed of two user deﬁned functions for paral-

lel processing of data among a set of computers.

Hadoop performs its implementation in parallel

among distributed set of computers belonging to

the same cluster.

4 HADOOP-BASED

FRAMEWORK

In this work, we cover two heavy information ex-

traction tasks namely named entity recognition and

events extraction. Therefore, we develop two loosely

coupled Hadoop clusters; named entity recognition

cluster (NER-Cluster hereafter) and events extraction

cluster (EE-Cluster hereafter) where the output of the

ﬁrst is the input of the second as shown in ﬁgure 1 and

explained in subsequent sections:

Figure 1: Hadoop-based Information Extraction Frame-

work.

Data collection is performed by a keyword-based

crawler developed at the heart of the system in order

to collect social data streams from API platforms and

load them into HDFS for analysis based on domain

keywords.

4.1 NER-Hadoop Cluster

The NER cluster regroups data cleaning and named

entity extraction in its map and reduce functions. The

input data is load into HDFS and streamed to later

Figure 2: NER-Map Reduce Engine.

functions. In map function we implement data clean-

ing which includes removing redundancy, punctua-

tions, special characters, URLs and URIs in order to

get data ready for analysis. Linguistic processing is

implemented in the reduce function. We use Stanford

Core NLP (Manning et al., 2014), a natural language

processing tool for tokenization, Part of Speech-POS

tagging and common named entity recognition such

as date, location and person. However, to recognize

domain entities such as DRUGS, routes of intake-

ROI and effects-EFF, we extend NLP pipeline with a

new annotator based on domain dictionary (Jenhani

et al., 2016). Social text is plenty with colloquial

words, informal data and abbreviations. Therefore

we used fuzzy matching used to match words similar

for a given threshold to capture the maximum of cor-

rect named entities. In the implementation, we match

words which are 80% similar. In short, in the reduce

phase, the set of tweets are reduced to a set of enti-

ties (date, location, person, DRUG, ROI, PATIENT,

etc). The ﬁnal step consists on parsing data in order

to identify all syntactic and grammatical relationships

between named entities.

4.2 EE-Hadoop Cluster

Events extraction consists on extracting complete,

meaningful and coherent information. It represents

the n-ary semantic relationship between entities. In

order to extract meaningful events with high preci-

sion, we proposed a hybrid approach combining lin-

guistic rules with machine learning technique namely

classiﬁcation.

Figure 3: EE-Map Reduce Engine.

We implement this hybrid process in map reduce

engine which input is named entities extracted in the

ﬁrst layer. In the map phase we match the set of

output entities and semantic predicates with lexico-

syntactic patterns. In fact, we give as input to map

functions a set of patterns prepared based on linguistc

grammar. In our drug abuse case study, we consider

drug abuse patterns (DA pattern) and adverse drug

reaction patterns (ADR Pattern). To each set of in-

put entities could correspond more than one pattern.

Therefore, in the reduce phase, ﬁnal patterns will be

selected using a classiﬁcation technique thanks to dis-

criminative features. In the context of our applica-

tion, features are named entities and triggers (take,

play, purchase, need, cause, etc), semantic relation-

ships (Abuser, Substance, Dose, unit, etc) and event

tags (Adverse Drug Reaction-ADR, Drug Abuse-DA,

NONE). We consider also the sentence length be-

cause social media data suffer from short messages

syntactically poor but meaningful. Indeed, a given

event may be expressed with one keyword in a sen-

tence full of colloquial meaningless words like ”mar-

ijuana, oh, good experience”. We use also window

of words mainly the word before subject (WBS) and

word after subject or before trigger (WBT). To choose

the best classiﬁcation technique for this problem, we

compared a set of classiﬁcation techniques and the

best suited for this task is Support Vector Machine

(SVM). We refer the reader to (Jenhani et al., 2016)

for more details.

5 IMPLEMENTATION AND

EXPERIMENTS

In this section we present implementation details and

tests to check the performance of the proposed sys-

tem compared to previous implementation. The pro-

posed system consists of two parallel servers. In

each one we create 3 nodes using pseudo-distributed

paradigm. We use eclipse java development environ-

ment to which we import Hadoop library for map re-

duce job programming and HDFS construction. We

import also Twitter4j library to build a key-word

based crawler. In table 1 we summarize information

about social data collected from Twitter Streaming

API to run the proposed system:

Table 1: Data Sets Crawling Details.

Data Set NB Tweets Extraction period (days)

DS1 504000 30

DS2 300000 23

DS3 196000 12

TOTAL 1000000 65

For performance analysis, we carry out run time test,

data crawling and HDFS loading time test and accu-

racy test on the three data sets having different sizes

to see system performance on different data volumes.

5.1 Run Time Test

We compare run time of the system implemented as

a standard java program (SJP hereafter) with Hadoop

map reduce solution (HDP hereafter) as depicted in

table 2.

Table 2: Run Time Test (minutes).

NER Cluster EE Cluster All

SJP HDP SJP HDP SJP HDP

DS1 125 100 148 102 127 95

DS2 101 89 136 93 113 85

DS3 83 67 106 77 93 69

For named entity recognition, running time is

decreased by about 25% using Hadoop. However,

events extraction is decreased by 45% where we ob-

serve clearly the efﬁciency of distributed and paral-

lel solutions for complex problems. Events extrac-

tion takes much time which is explained by the com-

plexity of treatment for a standard java program. In

fact, events extraction combines two heavy process-

ing methods; linguistic pattern matching and classi-

ﬁcation which is costing process and hard using tra-

ditional technologies especially when data volume is

large. Nevertheless, using Hadoop map reduce, the

process is much more simpliﬁed and processing time

is improved considerably. The processing time, when

all the system is implemented using Hadoop and data

is smoothly promoted between layers, is improved

compared to results obtained from each layer sepa-

rately.

5.2 Data Crawling and HDFS Load

Time Test

Data crawling and loading time test is an important

test to check the performance of Hadoop-based so-

lution. Table 3 shows this test carried on each data

set. We observe linear data loading in HDFS while

data crawling time is increasing. Thus, whatever data

volume, data load in HDFS is stable regarding its big

capacity to store larger volumes of data.

Table 3: data crawling and HDFS load time (seconds).

Crawling Time HDFS Load Time

DS1 2187 18

DS2 1452 16

DS3 925 12

5.3 Accuracy Test

Table 4 summarizes performance test results carried

out on Hadoop-based system with three data sets us-

Table 4: Precision, Recall and F-measure for Accuracy Test.

DA Events ADR Events

P% R% F% P% R% F%

DS1 93.3 93.3 93.3 98.1 97.8 97.8

DS2 91 90.4 90.4 97.1 96.8 96.8

DS3 84.7 83.3 83.9 96.6 95.6 95.8

Avg 89.7 89 89.2 97.3 96.7 96.8

ing SVM classiﬁer to test accuracy of extracting drug

abuse events (DA) and adverse drug reactions (ADR).

We use three measures of accuracy; precision, re-

call and F-measure calculated based on the number of

positive instances, negative ones, false positives and

false negatives.

6 CONCLUSIONS

Social data generated in very high frequency require

real time analysis to make the quicker decision in

highly competitive environments. However, existing

technologies fail to process voluminous, unstructured

and dynamic data in real time and return required in-

formation for immediate decision making.

In this work, we adopt Hadoop, distributed frame-

work which offers a parallel programming model and

effective storage system in distributed clusters. Tested

on Twitter data for drug abuse events extraction,

Hadoop-based system achieved good performance re-

sults.

REFERENCES

Peotiuc-Pietro,D., Samangooei, S., Cohn, T., Gibbins, N.,

Niranjan, M. (2012). Trendminer: An Architecture

for Real Time Analysis of Social Media Text, Asso-

ciation for the Advancement of Artiﬁcial Intelligence

(www.aaai.org).

Nesi, P., Pantaleo, G., and Tenti, M. (2014).

Ge(o)Lo(cator): Geographic Information Extraction

from Unstructured Text Data and Web Documents.

DISIT - Distributed Systems and Internet Technol-

ogy Lab, Department of Information Engineering,

University of Florence, Italy.

Exner, P. and Nugues, P. (2014). KOSHIK- A Large-

scale Distributed Computing Framework for NLP,

ICPRAM2014-International Conference on Pattern

Recognition Applications and Methods

Ramesh, R., Divya, G., Divya, D., Kurian, M., Vish-

nuprabha, V. (2015). Big Data Sentiment Analysis us-

ing Hadoop, IJIRST International Journal for Innova-

tive Research in Science and Technology— Volume 1

— Issue 11 — April 2015, ISSN (online): 2349-6010

Ha, I., Back, B. and Ahn, B. (2015). MapReduce Functions

to Analyze Sentiment Information from Social Big

Data, Hindawi Publishing Corporation International

Journal of Distributed Sensor Networks Volume.

Dhamodaran, S., Sachin, K. R., and Kumar, R. (2015).

Big Data Implementation of Natural Disaster Mon-

itoring and Alerting System in Real Time Social

Network using Hadoop Technology, Indian Jour-

nal of Science and Technology, Vol 8(22), DOI:

10.17485/ijst/2015/v8i22/79102.

Sunil, B., Mane, B., Sawant, Y., Kazi, S., Shinde, V. (2014).

Real Time Sentiment Analysis of Twitter Data Us-

ing Hadoop International Journal of Computer Sci-

ence and Information Technologies, Vol. 5 (3) , 2014,

3098 3100

Prabhakar Benny, S., Vasavi, S., Anupriya, P. (2016).

Hadoop Framework For Entity Resolution Within

High Velocity Streams. International Conference on

Computational Modeling and Security (CMS 2016).

Procedia Computer Science 85(2016 )550 557.

Bharti, S. K., Vachha, B., Pradhan, R. K., Babu, K. S., Jena,

S. K. (2016). Sarcastic sentiment detection in tweets

streamed in real time: a big data approach. Digital

Communications and Networks 2, pp.108121

White, T., second edition, Hadoop: the deﬁnitive guide,

(2011) , Published by OReilly Media, Inc., 1005

Gravenstein Highway North, Sebastopol, CA 95472.

Jenhani F., Gouider M. S., Ben Said L. (2016) A Hybrid Ap-

proach for Drug Abuse Events Extraction from Twit-

ter In 20th International Conference on Knowledge-

Based and Intelligent Information and Engineering

Systems, (ICKIIES16) York, United Kingdom pp.

1032-1040.

Jenhani F., Gouider M. S., Ben Said L. (2016) Lexicon-

based System for Drug Abuse Entity Extraction from

Twitter In 12th International Conference, BDAS, Us-

tro, Poland, Beyond Databases, Architectures and

Structures. Advanced Technologies for Data Mining

and Knowledge Discovery, Volume 613 of the series.

Communications in Computer and Information Sci-

ence pp. 692-703.

Manning, D., Mihai, C., Bauer, S., Finkel, J., Bethard, J.,

McClosky, D. (2014). The Stanford CoreNLP Natural

Language Processing Toolkit.
