Low-power Machine Learning for Visitor Engagement in Museums

Marcus Winter

, Lauren Sweeney

, Katie Mason

and Phil Blume

School of Architecture, Technology and Engineering, University of Brighton, Brighton, BN2 4GJ, U.K.

The Regency Town House, Hove, BN3 1EH, U.K.

Keywords: Machine Learning, Human Pose Estimation, Embodied Interaction, Visitor Engagement, Museums.

Abstract: Low-power Machine Learning (ML) technologies that process data locally on consumer-level hardware are

well suited for interactive applications, however, their potential for audience engagement in museums is

largely unexplored. This paper presents a case study using lightweight ML models for human pose estimation

and gesture classification to enable visitors' engagement with interactive projections of interior designs. An

empirical evaluation found the application is highly engaging and motivates visitors to learn more about the

designs. Uncertainty in ML predictions, experienced as tracking inaccuracies, jitter, or gesture recognition

problems, have little impact on their positive user experience. The findings warrant future research to explore

the potential of low-power ML for visitor engagement in other use cases and heritage contexts.

1 INTRODUCTION

Machine Learning (ML) in cultural heritage is

typically concerned with enhancing collections or

supporting museum operations. Its potential for

audience engagement is largely unexplored, despite

the recent emergence of low-power ML technologies

(Goel et al., 2020) and open ML model repositories,

enabling low-budget development of interactive ML

applications that run on consumer-level hardware and

avoid privacy issues by processing data locally.

This paper describes a case study developing and

evaluating an interactive ML application using these

technologies in a heritage context to promote visitors'

engagement and learning. Its main contributions are:

 a prototype application for visitor engagement,

based on low-power ML technologies;

 an empirical evaluation focusing on visitors'

reaction to uncertainty in ML predictions; user

experience and visitor engagement.

The following sections contextualise the work,

present the prototype application, describe the

evaluation study and discuss its findings. The paper

concludes by considering limitations of the work and

setting out future research directions.

https://orcid.org/0000-0001-6603-325X

https://orcid.org/0000-0001-8312-1550

https://orcid.org/0000-0001-9532-9375

https://orcid.org/0000-0002-3211-3419

2 RELATED WORK

Museums have long been testbeds for novel

technologies, however, their uptake of ML is difficult

to assess. French and Villaespesa (2019:102) point

out that "the broad language used to describe AI

initiatives makes searching for use cases a daunting

task". Based on a survey of 61 AI initiatives in

museums, they focus their discussion on three

application areas: computer vision to enhance

collections data, ML for visitor data, and voice

assistants for visitor engagement.

Responses to the MAIA survey (Hughes-Noehrer,

Jay and Gilmore, 2022:Q8) allow for a similar

classification, with 30% describing applications for

collections, including enhancing metadata, image

tagging, text extraction and OCR; 17% describing

applications to support museum operations, including

resource planning, ticketing and programming based

on visitor data; and 20% describing applications that

can be related to visitor engagement such as

interactive or personalised experiences, or production

of exhibits (other answers mention technologies

rather than applications). Contrasting the current 20%

of AI initiatives focusing on visitor engagement, 76%

236

Winter, M., Sweeney, L., Mason, K. and Blume, P.

Low-power Machine Learning for Visitor Engagement in Museums.

DOI: 10.5220/0011585600003323

In Proceedings of the 6th International Conference on Computer-Human Interaction Research and Applications (CHIRA 2022), pages 236-243

ISBN: 978-989-758-609-5; ISSN: 2184-3244

of respondents think that AI can enhance the visitor

experience on-site, or will be able to in the future

(Hughes-Noehrer, Jay and Gilmore, 2022:Q15).

Clusters of past research using ML technologies

for visitor engagement include:

 Chatbots offering conversational interfaces to

explore collections (e.g., Boiano et al. 2003;

Mollica, 2017; Anne Frank House, 2017)

 Robots engaging visitors in the gallery space

(e.g., Burgard et al., 1999; Pitch et al. 2011; Del

Vacchio, Laddaga and Bifulco, 2020)

 Interfaces to explore ML-enhanced collections

(e.g., The Metropolitan Museum of Art, 2022;

Harvard Art Museums, 2022a)

 Novel exhibits that would not be possible with

conventional technologies (e.g., Tate, 2016;

Mihailova, 2021).

While these efforts show that ML already plays an

important role in museums, they also suggest a need

for research exploring the potential of emergent low-

power ML technologies for visitor engagement,

which so far have received little attention.

3 HERITAGE CONTEXT

The Regency Town House, built in the 1820s as part

of architect Charles Augustine Busby's Brunswick

Estate, is a museum and heritage centre with a focus

on the architecture and social history of Brighton &

Hove between the 1780s and 1840s. Among its

numerous collections it holds Busby's architectural

plans, manuscripts, and aquatints, including an

original copy of his 1834 publication, Collection of

Designs for Modern Embellishments.

While Busby is mainly known as a designer of

buildings, this book features his work on interior

designs, which has so far received little attention. To

celebrate his interior designs in an authentic setting,

the brief was to develop an accessible, immersive,

and engaging application that would enable visitors to

interact with Busby's colourful and elaborate wall

designs in a way that is both educational and fun.

4 PROTOTYPE APPLICATION

The developed prototype uses light-weight ML

models for human pose estimation and gesture

classification to support embodied interaction

(Dourish, 2001) with interactive projections, which

has been shown to facilitate meaningful experiences

(Tan and Chow, 2017) and lead to high levels of

engagement (Lindgren et al., 2016). To satisfy a

requirement for cross-platform support and enable

other heritage organisations to access the application,

the prototype is implemented as a web application. It

runs in standards-compliant web browsers and does

not require any specialist hardware.

Human pose estimation is used for embodied

interaction with designs, turning users' hands into

virtual paint brushes to successively reveal designs. A

representation of the user's body is shown on screen

to support coordination (Figure 1b). The prototype

uses the MoveNet pose detection model (Voter and

Li, 2021), which provides sufficient performance on

most mid-range computers available today.

Gesture recognition is used for control operations.

A single trigger gesture is used to start a session from

the initial information screen (Figure 1a); progress

from reveal action to showing the complete design;

and progress from beholding a complete design to

loading the next design to reveal. The prototype uses

a pre-trained classifier based on body pose data in the

COCO format (Lin et al., 2014) and a k-nearest

neighbours (k-NN) algorithm. The classifier issues

W3C standard Document Object Model (DOM)

events for detected gestures, which are listened to by

the web application to control the application state.

Figure 1: Interactive wall projection, including (a) initial

information screen first encountered by visitors, (b) partly

revealed design, with user's body representation and a hint

explaining the control gesture in the bottom right corner.

Low-power Machine Learning for Visitor Engagement in Museums

237

Both MoveNet and the gesture classifier use

Tensorflow.js (Smilkov et al., 2019), a JavaScript

implementation of the Tensorflow open-source

software library for ML (Abadi et al., 2016). The

prototype has no other dependencies but uses plain

HTML, CSS and JavaScript to ensure standards

compliance and minimal overhead.

An admin interface provides functionality to

control and customise the application. This includes

loading content images, information screens,

interaction hints and gesture classifier via URLs,

enabling heritage organisations to customise the

application for their specific use context and host

critical resources in their own web space.

5 EVALUATION

The prototype application was empirically evaluated

at the Town House over two days in June 2022,

focusing on (i) usability and user experience, (ii)

visitors' reaction to uncertainty in ML predictions,

and (iii) visitor engagement and learning. The study

design was scrutinised by the University of Brighton's

ethics board and received a favourable opinion.

5.1 Participants

Participants were recruited through the Town House

blog and social media channels to reach their regular

audiences. The age distribution in the sample (n=31)

is broadly comparable to the average age distribution

among heritage audiences in England (DCMS, 2020)

with the exception of 35-44 years (6.5%) and 45-54

years (32.3%), which are typically both around 16%

(ibid). Participants' frequency of visiting museums

and historic buildings (55% up to 5 times per year,

32% 6-15 times, 13% more than 15 times) is higher

than the average among heritage audiences in

England (ibid). Some participants (10%) say they

usually visit on their own, while most visit with

friends or family (42%), or say they do both (48%),

suggesting that many participants understand

museum visits as a social occasion.

5.2 Experimental Setup

The system was deployed in The Regency Town

House first floor front dining room (Figure 2), using

a notebook computer with Intel Core i7 processor,

16GB RAM and integrated webcam, and a projector

with 1920 x 1080 pixels resolution and 6,000 lumen

brightness.

Figure 2: Room layout with positions of (a) computer and

webcam, (b) visitor and approximate interaction space, (c)

projector and (d) interactive projection.

The projector was fitted with a wide-angle lens to

cover the whole sidewall, measuring 6.62m width x

3.72m height excluding bottom skirting, from a

distance of 5m. The spatial layout was determined by

practical constraints preventing the projector to be

mounted at sufficient height for the projection beam

to clear visitors interacting in the area in front of the

wall. Instead, the projector was mounted on a pedestal

at 0.5m height and visitors positioned themselves to

the side of it to get a good view of the projection. The

computer with integrated webcam was mounted on a

small table at 0.65m height facing the user. It was

positioned at maximum distance to the user while still

clearing the projector beam to not throw a shadow.

This resulted in an effective interaction space of

approximately 3.4m x 2.2m in which users could

operate and their full body was recognised.

5.3 Procedure and Data Collection

Visitors arriving at the Town House were welcomed

by a researcher and informed about the context and

purpose of the study, before ascending to the first

floor dining room. Here Town House staff introduced

them to the prototype application, providing

information about Busby's interior designs and their

relation to the Town House. Participants were also

given some initial instructions to get them started

with the embodied interaction. A researcher present

in the room observed visitors' interaction with the

prototype. After visitors were finished with their

interaction, they were invited by Town House staff to

take part in a short interview about their experience.

Interviews were carried out by a researcher in the

ground floor reception room. After the interview,

participants were asked to complete a short user

experience questionnaire.

Observations involved a researcher positioning

themselves at the far end of the room to observe

CHIRA 2022 - 6th International Conference on Computer-Human Interaction Research and Applications

238

visitors' interaction, which typically lasted 5-15

minutes, and take notes recording their initial

reactions, level of engagement, learnability and

usability issues, and any comments and feedback

directed at Town House staff present in the room.

Interviews were designed to last 3-5 minutes and

included a total of five questions, plus a section on

demographic information. Following guidance in

Valenzuela and Shrivastava (2008), the researchers

took care to make participants feel comfortable and

avoided or elucidated technical jargon during the

interview. Answers were recorded in a bespoke

coding sheet and notes were revised and clarified

immediately after the interview while memory was

still fresh.

The questionnaire was based on the short form of

the UEQ User Experience Questionnaire developed

by Schrepp, Hinderks and Thomaschewski (2017). It

was filled in by participants after the interview and

took 2-3 minutes to complete.

Observation notes, interview notes and completed

questionnaires were digitised after the evaluation

event to support the data analysis, while the original

paper copies were destroyed.

5.4 Data Analysis

Qualitative observation notes and interview notes

were transcribed and analysed independently by three

researchers using an emergent coding process

described in Miles and Huberman (1994). This

involved first a data reduction step and then a data

visualisation step to identify common themes.

Themes identified in the three separate analyses were

then discussed and synthesised by all three

researchers together, using affinity diagrams as

described in Courage and Baxter (2005). This

resulted in a set of consolidated themes from these

two datasets and allowed for triangulation between

observed interaction (observation notes) and self-

reported views about the experience (interview notes)

to informing the findings.

Quantitative demographic data, as well as two

quantitative sub-questions in the interview asking

interviewees to rate on a fixed scale the accuracy of

the pose estimation and the impact any inaccuracies

had on their overall experience, were simply

aggregated.

Quantitative data from the short version of the

UEQ were analysed using the UEQ Data Analysis

Tool developed by Schrepp (2017).

5.5 Findings

5.5.1 Usability and User Experiences

Observations show that most participants had little or

no problems interacting with the system. While some

were initially unsure how to start and asked staff for

instructions, they quickly picked up on how the

interaction works and confidently used both body

poses and the cross-arms gesture to interact with the

system. Overall, the observed behaviour suggests a

good degree of usability and learnability in the

current design, even though some aspects could be

further improved, in particular, the gesture

recognition (see discussion of uncertainty below).

This is supported by interview data, with almost all

respondents reporting that it was clear how the

interaction works, even though some qualified this by

attributing it to the brief introduction by staff, or

observing others before interacting themselves, or

saying it took them a while to work out what to do.

Some participants reported that they found it

difficult to reach the corners and lower areas of

designs, or remarked that the embodied interaction

was physically challenging, confirming similar

reports in the literature (Hincapié-Ramos et al., 2017;

Jang et al., 2017). A few participants linked this to

accessibility, pointing out that it was more difficult to

use for people at their age, and for others with

restricted mobility or dexterity. One suggestion to

address these issues was to not only using users' hands

as virtual paint brushes but also their feet. Alternative

interaction modes were also suggested, for example

offering people with mobility issues the opportunity

to reveal the projected designs via a touch screen.

Several interview responses suggested alternative

ways to provide initial instructions for situations

where staff cannot be present (e.g., in writing; short

animation). They also commented on the usefulness,

design, or timing of the on-screen hints reminding

users to cross their arms at certain points.

Observations suggest these hints where often

unnoticed or ignored by users, with some preferring

to continue revealing a design with their hands rather

than cutting short the process by crossing their arms.

Some responses also questioned the need for an on-

screen body representation or suggested alternative

representations. All of these comments, however,

were in the spirit of further improving the prototype

rather than suggesting any fundamental problems in

its interaction design.

Regarding their overall user experience, many

participants were observed to exhibit behaviour or

make comments indicating positive approval, using

Low-power Machine Learning for Visitor Engagement in Museums

239

terms like "amazing" or "extraordinary" or "really

cool". A similar picture emerges from interviews,

with many participants emphatic about the experience

being fun and engaging. Several interviewees

suggested that children would appreciate the

embodied interaction and some suggested gamifying

the experience to make it even more engaging.

Results from the UEQ further support these

findings, with particularly positive scores for scales

relating to ease of use and stimulation (Table 1).

Mean scores of 1.716 (SD=0.928) for pragmatic

quality, 1.500 (SD=1.397) for hedonic quality and

1.602 (SD=1.074) overall put the prototype in the top

10% of scores in the UEQ benchmark dataset of 468

studies involving 21,175 people (Schrepp, 2017),

which indicates an excellent user experience overall

(Figure 3).

Table 1: UEQ scores and confidence intervals (p=0.05).

Scale Mean Conf. Interval

obstructive supportive 1.21

0.74 1.69

complicated easy 2.14

1.73 2.55

inefficient efficient 1.31

0.89 1.74

confusing clear 2.17

1.79 2.55

boring exciting 1.14

0.56 1.73

not interesting interesting 1.76

1.22 2.30

conventional inventive 1.79

1.16 2.41

usual leading edge 1.46

0.89 2.04

Figure 3: UEQ mean scores against benchmark dataset.

5.5.2 Uncertainty in ML Predictions

Uncertainty in ML predictions manifests itself in the

prototype in various ways. In the context of human

pose estimation, low confidence scores can lead to

some body parts not being rendered on screen.

Inaccurate estimations lead to a mismatch between

on-screen representation and actual body pose,

whereas slight differences in estimations between

video frames lead to jitter in the on-screen body

representation. In the context of gesture

classification, uncertainty can lead to false positives

(i.e., a body pose is wrongly classified as a gesture)

and false negatives (i.e., a correctly performed

gesture is not recognised).

Observations show that the cross-arms gesture

was often triggered accidentally (false positives) and,

conversely, in some cases did not trigger as expected

(false negatives). The former was typically caused by

(a) visitors crossing their arms as part of their normal

body posture; (b) wrong classification of other body

poses involving crossing an arm over the torso; and

loose clothes or shoulder bags obscuring body parts.

The latter was typically triggered by visitors

performing the cross-arms gesture in a different

manner than the classifier was trained to recognise

(e.g., several visitors performed an "X" with lower

arms crossing diagonally, while the classifier was

trained mostly with lower arms crossed almost

horizontally). Observations also show tracking

inaccuracies and body parts not rendered on screen

due to low confidence scores, for example when

people performed extreme body poses to explore the

limitations of the system. Overall, these aspects had

little impact on visitors' engagement. While there

were some reactions expressing surprise or even

amusement, visitors generally worked through those

situations unperturbed and seemed to accept them as

part of the experience.

This is supported by interviews, which asked

visitors to rate both the application's tracking

accuracy and the impact of inaccuracies on their

experience, and to expand on their ratings with open

comments. Figure 4 shows that participants' ratings

tend towards more positive assessments of both

aspects. However, while more respondents rate the

tracking accuracy as good (52%) rather than perfect

(16%), this trend is reversed in how tracking

inaccuracies impacted on the experience, with more

respondents saying they had no impact (45%) rather

than little impact (13%), suggesting a certain level of

acceptance of the effects of uncertainty.

Figure 4: Visitors' ratings of how well the application

tracked their movements and how much any tracking

inaccuracies impacted on their experience.

CHIRA 2022 - 6th International Conference on Computer-Human Interaction Research and Applications

240

Open answers describe issues as experienced by

participants. While some of these relate to uncertainty

in ML predictions, others are caused by ML inference

latency, or are the result of interaction design decision

aimed at mitigating some of the challenges of

embodied interaction:

 Some participants remarked on the body

representation sometimes being inaccurate or

out of proportion or not at scale. This is only

partly caused by uncertainty in ML predictions,

as the prototype also makes purposeful

adjustments that enable all participants to reach

the top of the screen regardless of their body

height or distance from the camera.

 Some respondents remarked on jitters in their

on-screen body representation, which is caused

by slight variations in key point predictions

between video frames.

 Some respondents remarked on lag or delay,

which is caused by latency in ML inference,

and is invers proportional to the processing

power of the machine it runs on.

Overall, the data shows that several aspects of the

user experience are affected by ML uncertainty or

latency, however, it also suggests a high level of

acceptance and willingness to work around any

issues. Some interviewees even suggested that

glitches made the experience more interesting as they

added an element of unpredictability.

5.5.3 Visitor Engagement and Learning

Observations show how several visitors methodically

reveal designs, often over prolonged periods of time,

engaging with one design after an other, directing

enquiries about specific design features and colours

to staff during their interaction, and talking about

designs and the differences between them with staff

and other visitors after their interaction. While most

participants are clearly excited about the technology,

they also show their appreciation for the designs they

reveal, suggesting that the prototype overall manages

to "preserve the primacy of the object and aesthetic

encounter" (vom Lehn and Heath, 2003, p.3) and

raises visitors' interest in the designs, motivating them

to enquire and learn about them.

Interview data strongly supports this, with

overwhelmingly positive answers when asked

whether the prototype was an engaging way to learn

about Busby’s interior designs. Several participants

expressed their excitement at the vivid colours of the

designs and at seeing them projected at scale in an

authentic environment. While there were two

responses saying they would prefer static images or

written materials, most expressed their satisfaction at

the interactive and immersive nature of the prototype,

with some explicitly stating that it was more fun to

reveal the designs rather than just observing them.

Several participants pointed out the value of

additional narrative delivered by staff, either as part

of the introduction, or commenting about specific

designs, or answering questions by participants

during or after their interaction. This reinforces the

notion that the interaction awakens interest and

motivates visitors to learn about the designs by asking

staff for more information. It also indicates that the

prototype can be part of a wider engagement and

learning strategy in museums involving staff or other

experts who can provide additional information and

support a more conversational form of learning.

6 DISCUSSION

The empirical evaluation suggests good usability and

learnability of the developed prototype This was

supported by participants receiving initial

instructions by staff, the direct mapping between

users' body pose and on-screen representation, and

on-screen hints when to use the cross-arms gesture.

Feedback suggests a need to improve the gesture

recognition and explore the possibility of users

customising or hiding their body representation.

While the presence of staff clearly added value to

the experience, this might not always be feasible,

especially in smaller museums with resource

constraints. Future work should explore how the

prototype can be further developed for use cases with

no staff present. Feedback suggesting to gamify the

experience, and observations of visitors' persistence

in trying to reveal - or "complete" - all areas of a

design, indicate a natural challenge to build on.

Uncertainty in ML predictions, perceived as

tracking inaccuracies, jitter in the on-screen body

representation, and gesture recognition problems, had

little impact on participants' overall user experience,

who generally showed a high level of tolerance,

simply trying again when something did not work as

expected. As this behaviour is likely to be influenced

by staff readily providing hints and explanations,

future work should explore if this tolerance holds

without staff being present.

Despite these issues, the UEQ results suggest an

excellent overall user experience against benchmark

data (Schrepp, 2017; Schrepp, Hinderks and

Thomaschewski, 2017). The high score for pragmatic

quality supports findings indicating good usability,

while the high score for hedonic quality supports

Low-power Machine Learning for Visitor Engagement in Museums

241

findings that participants enjoyed the experience.

They add further support to literature on the engaging

qualities of gesture-based interfaces (van Beurden,

Ijsselsteijn and de Kort, 2012) and show that ML

uncertainty does not diminish their appeal.

From a museum perspective, key questions

include whether the application supports visitors'

engagement and learning, and whether its use of ML

is a feasible alternative to specialist hardware. The

results show that the application is highly engaging

and motivates visitors to ask questions about designs

and learn more about Busby's work. Participants had

no privacy concerns about being observed by a

camera, and while they noticed the effects of

uncertainty in ML predictions, these had little impact

on their positive experience.

The findings provide useful insights informing

future development and research. While not allowing

for extrapolation to other use cases or contexts, they

give an indication of the potential of low-power ML

as an enabling technology for visitor engagement and

provide a snapshot of related user experience issues.

7 LIMITATIONS

Aiming for high ecological validity, the evaluation

study took place in the intended target environment

and involved participants recruited via The Regency

Town House's social media channels. The sample size

and composition, choice of methods and rigorous data

analysis ensure high internal validity, however, the

bespoke nature of the prototype and the evaluation

environment make it problematic to generalise

findings to other applications and environments. As

such, no recommendations or design guidelines are

offered for low-power ML applications for visitor

engagement.

8 CONCLUSIONS

This paper describes a prototype application using

human pose estimation and gesture recognition for

visitor engagement with interior designs in a heritage

setting. Unlike other applications involving embodied

interaction, it does not require specialist hardware but

uses pre-trained ML models and runs on a mid-range

computer with a webcam, putting it into reach for

smaller museums with limited budgets and

development capabilities.

The prototype uses low-power ML technologies,

which are particularly well suited for interactive

applications as they process data locally rather than

transmitting to a server, reducing latency and

preserving visitors' privacy.

An empirical evaluation in the intended target

environment found it usable, learnable and offering

an excellent overall user experience. Besides

engaging visitors of all ages, it motivated them to ask

questions about the interior designs they revealed and

to learn more about them in informal conversations

with staff. Uncertainty in ML predictions, perceived

by visitors as tracking inaccuracies, jitter in their on-

screen representation and gesture recognition issues,

had little impact on their positive experience.

The findings indicate that low-power ML holds

great promise for visitor engagement in heritage

contexts and warrant future research to explore this

potential. This includes developing designs that can

run unsupervised in the gallery space, without staff

being present to provide information and assistance,

and exploring how other ML capabilities can support

visitor engagement and learning in museums.

ACKNOWLEDGEMENTS

This research was supported by the Ignite funding

scheme of the Community University Partnership

Programme (CUPP) at the University of Brighton.

We would like to thank visitors to The Regency Town

House for taking part in the evaluation and sharing

their valuable views and feedback.

REFERENCES

Abadi, M., Barham, P., Chen, J., Chen, Z., Davis, A., Dean,

J., Devin, M., Ghemawat, S., Irving, G., Isard, M.,

Kudlur, M., Levenberg, J., Monga, R., Moore, S.,

Murray, D.G., Steiner, B., Tucker, P., Vasudevan, V.,

Warden, P., Wicke, M., Yu, Y., and Zheng, X. (2016).

TensorFlow: A System for Large-Scale Machine

Learning. Proceedings of the 12th USENIX

Symposium on Operating Systems Design and

Implementation (OSDI ’16). arXiv:1605.08695.

Anne Frank House (2017). Anne Frank House launches bot

for Messenger. Available https://www.annefrank.org/

en/about-us/news-and-press/news/2017/3/21/anne-

frank-house-launches-bot-messenger/. Retrieved 6

August 2022.

Boiano S, Gaia G, Caldarini M (2003) Make your museum

talk: natural language interfaces for cultural

institutions. Museums and the Web 2003. Available

https://www.museumsandtheweb.com/mw2003/papers

/gaia/gaia.html. Retrieved 6 August 2022.

CHIRA 2022 - 6th International Conference on Computer-Human Interaction Research and Applications

242

Burgard, W., Cremers, A. B., Fox, D., Hähnel, D.,

Lakemeyer, G., Schulz, D., Steiner, W., and Thrun, S.

(1999). Experiences with an interactive museum tour-

guide robot. Artificial Intelligence, 114(1–2), 3–55

Courage, C. and Baxter, K., 2005. Understanding your

users: A practical guide to user requirements methods,

tools, and techniques. Gulf Professional Publishing.

DCMS (2020). Taking Part 2019/20: Cross-sectional

survey. Technical Report. Available https://assets.pub

lishing.service.gov.uk/government/uploads/system/upl

oads/attachment_data/file/916246/Taking_Part_Techni

cal_Report_2019_20.pdf. Retrieved 27 July 2022.

Del Vacchio, E., Laddaga, C., & Bifulco, F. (2020). Social

robots as a tool to involve student in museum

edutainment programs. In Proceedings of the 29th IEEE

International Conference on Robot and Human

Interactive Communication (RO-MAN), 476-481.

Dourish, P. (2001). Where the action is: the foundations of

embodied interaction. MIT Press, Cambridge, Mass.

French, A. and Villaespesa, E. (2019). AI, visitor

experience, and museum operations: a closer look at the

possible. In Humanizing the Digital: Un-proceedings of

the MCN 2018 Conference, 101-113.

Gaia, G., Boiano, S., and Borda, A. (2019). Engaging

museum visitors with AI: The case of chatbots.

Museums and digital culture, 309-329. Springer.

Goel, A., Tung, C., Lu, Y. H., and Thiruvathukal, G. K.

(2020). A survey of methods for low-power deep

learning and computer vision. In 6th World Forum on

Internet of Things (WF-IoT), 1-6. IEEE.

Harvard Art Museums (2022). AI Explorer: Explore how a

computer sees art. Available https://ai.harvardart

museums.org/about. Retrieved 11 August 2022.

Hincapié-Ramos, J. D., Guo, X., Moghadasian, P., and

Irani, P. (2014). Consumed endurance: a metric to

quantify arm fatigue of mid-air interactions. In

Proceedings of the SIGCHI Conference on Human

Factors in Computing Systems, 1063-1072. ACM.

Hughes-Noehrer, L., Jay, C. and Gilmore, A. (2022).

Museums and AI Applications (MAIA) Survey.

University of Manchester. Dataset.

https://doi.org/10.48420/19298588.v1

Jang, S., Stuerzlinger, W., Ambike, S., and Ramani, K.

(2017). Modeling cumulative arm fatigue in mid-air

interaction based on perceived exertion and kinetics of

arm motion. In Proceedings of the 2017 CHI

Conference on Human Factors in Computing Systems,

3328-3339. ACM.

Lee, L., Okerlund, J., Maher, M. L., & Farina, T. (2020,

July). Embodied interaction design to promote creative

social engagement for older adults. In International

Conference on Human-Computer Interaction, 164-183.

Springer, Cham.

Lin, T. Y., Maire, M., Belongie, S., Hays, J., Perona, P.,

Ramanan, D., Zitnick, C. L., and Dollár, P. (2014).

Microsoft COCO: Common objects in context. In

Proceedings of the European conference on computer

vision (ECCV), 740-755. Springer.

Lindgren, R., Tscholl, M., Wang, S., and Johnson, E.

(2016). Enhancing learning and engagement through

embodied interaction within a mixed reality simulation.

Computers & Education, 95, 174-187.

Mihailova, M. (2021). To dally with Dalí: Deepfake (Inter)

faces in the art museum. Convergence, 27(4), 882-898.

Miles, M.B., and Huberman, A.M. 1984. Qualitative Data

Analysis. Newbury Park, CA: Sage.

Mollica, J. (2017). Send Me SFMOMA. Available

https://www.sfmoma.org/read/send-me-sfmoma/.

Retrieved 6 August 2022.

Pitsch, K., Wrede, S., Seele, J. C., and Süssenbach, L.

(2011). Attitude of german museum visitors towards an

interactive art guide robot. In Proceedings of the 6th

international conference on Human-robot interaction,

227-228. ACM.

Schrepp (2017). UEQ Data Analysis Tool. Available

https://www.ueq-online.org/Material/Short_UEQ_

Data_Analysis_Tool.xlsx. Retrieved 26 July 2022.

Schrepp, M., Hinderks, A., and Thomaschewski, J. (2017):

Design and Evaluation of a Short Version of the User

Experience Questionnaire (UEQ-S). IJIMAI, 4 (6),

103–108.

Smilkov, D., Thorat, N., Assogba, Y., Nicholson, C.,

Kreeger, N., Yu, P., Cai, S., Nielsen, E., Soegel, D.,

Bileschi, S. and Terry, M. (2019). Tensorflow. js:

Machine learning for the web and beyond. Proc. of

Machine Learning and Systems, 1, 309-321.

Tan, L., and Chow, K. K. (2017). Facilitating meaningful

experience with ambient media: an embodied

engagement model. In Proceedings of the 5th

International Symposium of Chinese CHI, 36-46.

Tate (2016). Can a machine make us look afresh at great art

through the lens of today’s world? IK Prize 2016:

Recognition. Available https://www.tate.org.uk/whats-

on/tate-britain/exhibition/ik-prize-2016-recognition.

Retrieved 11 August 2022.

The Metropolitan Museum of Art (2022) The Met Art

Explorer. Available https://art-explorer.azureweb

sites.net/search. Retrieved 11 August 2022.

van Beurden, M.H., Ijsselsteijn, W.A., de Kort, Y.A.

(2012). User Experience of Gesture Based Interfaces: A

Comparison with Traditional Interaction Methods on

Pragmatic and Hedonic Qualities. LNCS, vol 7206, 36-

47. Springer, Berlin.

Voter, R. and Li, N. (2021). Next-Generation Pose

Detection with MoveNet and TensorFlow.js. Available

https://blog.tensorflow.org/2021/05/next-generation-

pose-detection-with-movenet-and-tensorflowjs.html.

Retrieved 26 July 2022.

Winter M., Jackson P. (2020) Flatpack ML: How to Support

Designers in Creating a New Generation of

Customizable Machine Learning Applications. LNCS

vol 12201, 175-193. Springer Nature.

Low-power Machine Learning for Visitor Engagement in Museums

243
