Security Tools’ API Recommendation Using Machine Learning

Zarrin Tasnim Sworna

2,3

, Anjitha Sreekumar

1,2

, Chadni Islam

1,2

and Muhammad Ali Babar

1,2,3

Centre for Research on Engineering Software Technologies (CREST), University of Adelaide, Australia

School of Computer Science, University of Adelaide, Australia

Cyber Security Cooperative Research Centre, Australia

Keywords:

Security Tools’ API, Security Orchestration, API Recommendation, Security Operation Center.

Abstract:

Security Operation Center (SOC) teams manually analyze numerous tools’ API documentation to ﬁnd appropri-

ate APIs to deﬁne, update and execute incident response plans for responding to security incidents. Manually

identifying security tools’ APIs is time consuming that can slow down security incident response. To mitigate

this manual process’s negative effects, automated API recommendation support is desired. The state-of-the-art

automated security tool API recommendation uses Deep Learning (DL) model. However, DL models are envi-

ronmentally unfriendly and prohibitively expensive requiring huge time and resources (denoted as “Red AI”).

Hence, “Green AI” considering both efﬁciency and effectiveness is encouraged. Given SOCs’ incident response

is hindered by cost, time and resource constraints, we assert that Machine Learning (ML) models are likely to

be more suitable for recommending suitable APIs with fewer resources. Hence, we investigate ML model’s

applicability for effective and efﬁcient security tools’ API recommendation. We used 7 real world security tools’

API documentation, 5 ML models, 5 feature representations and 19 augmentation techniques. Our Logistic

Regression model with word and character level features compared to the state-of-the-art DL-based approach

reduces 95.91% CPU core hours, 97.65% model size, 291.50% time and achieves 0.38% better accuracy, which

provides cost-cutting opportunities for industrial SOC adoption.

1 INTRODUCTION

The frequency of security incidents increased by 358%

from 2019 to 2020 (Instinct, 2021). Security Operation

Centers (SOCs) use Incident Response Plan (IRP) to

respond to the security incidents. IRP is a sequence of

tasks that are performed by orchestrating various secu-

rity tools in a Security Orchestration, Automation and

Response (SOAR) platform in response to a speciﬁc

security incident (PAN, 2019). Table 1 shows an ex-

ample IRP for malware investigation from the Cortex

SOAR platform (PAN, 2022). It presents some tasks

of an IRP and the required APIs from different security

tools for executing these tasks. An organization uses

76 security tools on average (Muncaster, 2021). Each

of these tools has a large number of APIs. For instance,

Splunk (Splunk, 2022) and Malware Information Shar-

ing Platform, MISP (MISP, 2022) have around 598 and

398 APIs, respectively. To deﬁne, update or execute an

IRP, SOAR developers and SOC teams need to manu-

ally search and select the APIs from diverse security

tools (Sworna et al., 2022). For example, the Phantom

SOAR platform requires around 1900 APIs for execut-

ing IRPs using diverse tools (Phantom, 2021). Hence,

a SOC team with time constraint (PAN, 2019) ﬁnds

manually reading documentation to ﬁnd APIs of these

numerous tools as hard to navigate, cumbersome and

time consuming (Robillard and DeLine, 2011). Such

manual efforts for incident response cause a signiﬁcant

human burden and contribute to fatigue in SOCs (Viel-

berth et al., 2020). To accelerate incident response

and reduce SOC teams’ burden, there is a dire need

for automated API recommendation support (Sworna

et al., 2022).

To support automated programming language-

speciﬁc (e.g., Java) API recommendation, several

Deep Learning (DL)-based approaches have been re-

ported in Software Engineering (SE) literature (Ling

et al., 2020), (Gu et al., 2016). Besides, a set of

SE studies (Cai et al., 2019), (Huang et al., 2018),

(Nguyen et al., 2017), (Ye et al., 2016) used similarity

score (SimScore) (Ye et al., 2016) on DL-based word

embedding for language-speciﬁc API recommenda-

tion. The state-of-the-art security tool API recommen-

dation called APIRO (Sworna et al., 2022) presents a

DL-based (i.e., Convolutional Neural Network (CNN))

Sworna, Z., Sreekumar, A., Islam, C. and Babar, M.

Security Tools’ API Recommendation Using Machine Learning.

DOI: 10.5220/0011708300003464

In Proceedings of the 18th Inter national Conference on Evaluation of Novel Approaches to Software Engineering (ENASE 2023), pages 27-38

ISBN: 978-989-758-647-7; ISSN: 2184-4895

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

approach, which outperformed Recurrent Neural Net-

work (RNN)-based DL approach.

Though DL models achieve high accuracy, they

are computationally quite expensive due to the require-

ment of complex hyper-parameter and architecture

tuning, millions and billions of weights and connec-

tions between units and powerful hardware resources

(LeCun et al., 2015). The demand for computing re-

sources to train DL models has increased 300,000-fold

from 2012 to 2019 (Strubell et al., 2019). Moreover,

DL has a black-box nature and running DL even using

powerful hardware and algorithmic parallelization still

requires hours to weeks of long training time (Fu and

Menzies, 2017). For example, Deep-API (Gu et al.,

2016) required 240 hours of GPU time for training

DL-based API usage recommendation.

Furthermore, DL models are environmentally un-

friendly and prohibitively expensive, which is denoted

as “Red AI” (Strubell et al., 2019). The necessary com-

putation power for training a single DL model emitted

626,000 tonnes

, which is ﬁve times more than

an average car emits throughout its lifetime (Strubell

et al., 2019). As organizations are adopting cloud

environments, the total ﬁnancial cost of using a DL

model in SOC can be expensive due to the highly mon-

etized cloud environments (Fu and Menzies, 2017).

Hence, “Green AI” (Strubell et al., 2019) is encour-

aged, which considers efﬁciency as the primary assess-

ment criterion along with effectiveness. However, the

existing DL-based SE studies (Choetkiertikul et al.,

2018), (Mou et al., 2016), (White et al., 2015) did not

focus on computation efﬁciency (i.e., resource usage).

An increasing number of organizations prefer

sustainability-based designs (i.e., use fewer resources

for acquiring outcome) in industrial SE solutions for

extensive cost-cutting opportunities (Calero and Piat-

tini, 2015). If two competing learning models produce

similar results, the preferred model is the simpler one

to understand and interpret (Fakhoury et al., 2018).

Given SOCs operate under critical cost, time and re-

source constraints (CSCRC, 2022), we assert that tra-

ditional ML-based, compared with DL-based, solution

can be more attractive for SOCs as traditional ML

models are usually simpler, which require less time, re-

source and cost (Fakhoury et al., 2018). However, the

performance of ML and DL varies based on various

contexts such as domain, downstream task and dataset.

For example, in the SE domain, DL outperformed ML

in opinion-based question-answer extraction (Chatter-

jee et al., 2021). In contrast, ML outperformed DL in

ﬁnding similar questions in Stack Overﬂow (Fu and

Menzies, 2017). To support a SOC team by providing

a time and resource efﬁcient and effective security tool

API recommender, there is a gap for an investigation

Table 1: An example IRP for malware investigation with

required security tools’ APIs for executing the IRP.

IRP Tasks Security Security Tool’s

Tool API

Send ﬁle to Cuckoo Cuckoo Post/tasks/create/ﬁle

Get task report Cuckoo Get/tasks/report/id/format

Delete malicious ﬁle Wazuh delete/manager/ﬁles

Block IP/URL IOCs Zeek NetControl::drop_address

Isolate endpoint Zeek

NetControl::

quarantine_host

of the applicability of ML over DL.

To address the above-mentioned gap, we empir-

ically investigate the applicability of traditional ML

models for recommending security tools’ API with

signiﬁcant cost-cutting opportunities. We use the API

documentation of 7 diverse real world security tools

and adopt 19 text augmentation techniques for seman-

tic variation enrichment. We compare and identify

the best performing ML model out of 5 popular ML

models (e.g., Logistic Regression (LR)). We explore 5

feature (e.g., word and character level) representations

techniques for each ML model. Later, we compare

the effectiveness and efﬁciency of the best performing

ML model with the baselines that are SimScore and

state-of-the-art DL-based APIRO.

Our experimental results show that our best per-

forming ML model for security tool API recommen-

dation is the LR model with word and character level

features as it outperformed the other ML models and

baselines both in effectiveness (e.g., accuracy) and

efﬁciency (e.g., resource). Our best performing ML

model reduces the required memory (i.e., GB) in terms

of 97.65% model size, 99.13% maximum disk write,

92.86% maximum disk read and reduces 95.91% CPU

core hours compared to APIRO. It also gains 0.38%

better accuracy with 291.50% less training time com-

pared to APIRO. Hence, our best performing ML

model recommends the correct APIs requiring less

time and resources that achieves sustainable design

goals compared to the DL-based approach for fast

incident response in real world SOCs.

The main contributions of this study are:

We empirically investigate various simple ML

models and features to choose the best performing

ML model for recommending security tool APIs.

We compare our best performing ML model’s ef-

fectiveness with SimScore and DL-based APIRO,

where our best performing ML model outper-

formed the baselines in terms of accuracy, mean

reciprocal rank and mean precision@K.

We highlight efﬁciency showing our best perform-

ing ML model reduces 95.91% and 97.65% of

CPU core hours and model size, respectively with

291.50% less training time compared to APIRO.

ENASE 2023 - 18th International Conference on Evaluation of Novel Approaches to Software Engineering

Table 2: Security tools’ diversity based on the type of tool,

API and API data source.

Tool

Name

Tool

Type

API

API Data

Source

Limacharlie

EDR

REST, Python,

CLI Commands

JSON, HTML

Cuckoo

Sandbox

REST HTML

MISP TIP REST, Python HTML

Zeek NIDS

Python, CLI

Commands

HTML

Snort NIDS CLI Commands HTML

Wazuh HIDS REST HTML

Splunk SIEM REST

YAML, HTML

This paper is structured as follows. Our study de-

sign and results are detailed in Sections 2 and 3, re-

spectively. Sections 4 and 5 present threats to validity

and implications. Section 6 summarises the related

work and Section 7 concludes our paper.

2 STUDY DESIGN

This section presents our Research Questions (RQ),

our security tool APIs’ corpus creation and pre-

processing methods, methods to answer RQs and the

used evaluation metrics.

2.1 Research Questions

The following RQs motivated our empirical study.

RQ1: To What Extent Are the Traditional ML

Models Viable Approaches to Recommend Security

Tools’ API? This RQ investigates to what extent tradi-

tional ML models can perform to recommend security

tools’ API. We also aim to identify the simple statisti-

cal feature representation that helps the ML model to

gain better performance. Thus, we seek to identify the

best performing traditional ML model and feature. An

answer to this RQ will help a SOC team to select the

best performing ML model with features in their SOC

to recommend security tools’ API.

RQ2: How Does Traditional ML Perform Com-

pared to the State-of-the-Art Baselines? In this RQ,

we compare our best performing traditional ML model

that we gained from RQ1 to the following baselines:

(i) APIRO which is the state-of-the-art security tool

API recommendation approach using a CNN-based DL

model (Sworna et al., 2022) and (ii) classical SimScore

approach using a similarity score method on DL-based

word embedding that is widely used for Java API rec-

ommendation (Cai et al., 2019), (Huang et al., 2018),

(Ye et al., 2016). An answer to this RQ will identify

whether the traditional ML model can gain similar,

worse or better performance than DL baselines. This

comparison will help the SOC team to select whether

to adopt the ML model over baselines.

RQ3: What Are the Required Time and Resource

Utilization for Models to Recommend Security

Tools’ API? Since time and resource constraints are

the signiﬁcant barriers to SOCs’ incident response

(CSCRC, 2022), time and resource utilization must be

evaluated to validate the usability of the API recom-

mendation support in the real world SOC environment.

Delay in API recommendation may cause a delay in

the IRP execution in SOC that may result in a sig-

niﬁcant loss for the organization due to the negative

impact of an attack (Vielberth et al., 2020). Besides,

to respond to the ever increasing and intricate threat

landscape, new security tools and new APIs of the

existing tools are constantly being added to the SOC

(Muncaster, 2021). To keep the security tool API rec-

ommender of SOC up-to-date, re-training the model

is a must. Hence, we analyze time (i.e., training, test-

ing) and resource utilization (e.g., model size, CPU

core hours) of the best performing ML model com-

pared to baselines to inspect the practical usability

for deployment in the real SOC setting. The result of

RQ3 will help the SOC team to choose a sustainable,

time and resource efﬁcient model for automated API

recommendation.

2.2 Security Tool APIs’ Corpus

Construction and Pre-Processing

In this section, we present the methodology for security

tool APIs’ corpus construction and pre-processing.

2.2.1 Security Tool APIs’ Corpus Construction

We created a corpus of APIs using 7 diverse pop-

ular real world security tools. This includes Li-

macharlie (Limacharlie, 2022), MISP (MISP, 2022),

Snort (Snort, 2020), Cuckoo (Cuckoo, 2019), Splunk

(Splunk, 2022), Zeek (Zeek, 2020) and Wazuh (Wazuh,

2022). These diverse types of security tools perform

varied functionalities to ensure security. These tools

also vary in other criteria (e.g., API type and API

data source) as reported in Table 2. The API data

of different tools help us to evaluate our models’ ef-

fectiveness for API recommendation in diverse data

settings. We selected these tools as a common use case

scenario in SOC is detecting endpoint and network

attacks using Endpoint Detection & Response (EDR)

tool (i.e., Limacharlie) and Network Intrusion Detec-

tion System (NIDS) (i.e., Zeek and Snort). Security

information and event management (SIEM) tool (i.e.,

Splunk) helps incident investigation and forensic anal-

ysis in SOC. Besides, SOC collects updated malware

Security Tools’ API Recommendation Using Machine Learning

Table 3: Statistics of API data collected from security tools.

Security

Tool

API

Num

Total

Num of

Words

Mean Word

Count in

Description

Lima-

Python 146

2395 8.81REST 84

charlie Sensor Commands 42

Cuckoo

REST API 23

685 18.47Distributed Cuckoo 12

Process 9

MISP

Automation & MISP 66

5424 14.05PyMISP Python Lib 20

PyMISP Python 312

Zeek

Python 63

1571 13.90NetControl 31

Command-Line 19

Snort Snort (Up-to 2.2) 145 1577 10.88

Wazuh REST 152 2387 15.70

Splunk REST 598 4065 6.81

Total 1722 17504 10.73

*API num means the number of APIs collected from the API document.

information from Threat Intelligence Platform (TIP)

(i.e., MISP) and analyses malware using sandbox tools

(i.e., Cuckoo). For threat detection and response of

a particular host, SOC uses Host Intrusion Detection

Systems (HIDS) (i.e., Wazuh).

Since different security tools provide their API doc-

umentation in different formats (e.g., JSON, HTML),

we built different scrapers using diverse libraries. We

utilized BeautifulSoup (Beautifulsoup, 2020) library

for parsing Splunk, Cuckoo and Zeek HTML pages,

Python built-in JSON package to parse Limacharlie

JSON data and Python YAML module to parse Wazuh

YAML pages. Lastly, we created a uniﬁed API corpus,

API

, of security tools by gathering the data collected

from these seven tools. As shown in Table 3, we col-

lected 1722 APIs and their respective descriptions,

parameters and return values. The total word count of

the API descriptions is 17k. For each API description,

the average word count is 10.73.

2.2.2 Security Tool API Corpus Pre-Processing

We pre-processed the APIs’ textual descriptions as data

pre-processing contributes to the success of the model

in the data science pipeline (Biswas et al., 2021).

Noise and Stop-Word Removal: To clean APIs’ tex-

tual description, we removed noises to retain the al-

phanumerical data along with underscore and minus

in the description. Underscore was retained to pre-

vent the formation of sub-terms from a single term

(e.g. attribute_identiﬁer). Minus was retained to keep

argument representations (e.g. -u). We removed stop-

words using the NLTK (Steven Bird and Loper, 2009)

English stop-word list.

Lowercasing: We performed lowercasing to represent

words of different cases (e.g., Cuckoo, cuckoo) to the

same lower-case form (e.g., cuckoo).

Lemmatization: We performed WordNet-based

lemmatization using NLTK (Steven Bird and Loper,

2009) to represent a word’s inﬂected forms (e.g., get-

ting, gets) to its dictionary-based root form (e.g., get).

API Clustering: We created clusters of APIs of a

tool, which differ based on class name, method name,

parameters or representations, but have identical API

description (Sworna et al., 2022). Clustering helps

to provide a comprehensive view of APIs of a tool

that performs the same intended task. We performed

automated API clustering by exact description match-

ing with a Python script. The clustering created a list

of 55 API clusters by merging 143 APIs. Our clus-

tering resulted in the API corpus of 1466 distinctive

descriptions with the corresponding APIs.

Text Augmentation: Since natural language queries

can have synonyms, para-phrases and spelling mis-

takes, we enrich the API corpus with diverse text

augmentation techniques for semantic variation en-

richment. We enriched the API descriptions of

API

corpus using various text augmentation techniques

(e.g., synonym substitute using Wordnet, synonym

substitute using PPDB) to improve the model’s perfor-

mance. Implementing text augmentation is challeng-

ing as substituting some words may change the context

and semantics. For instance, synonym substitute using

Wordnet substitutes the word ‘PID’ with ‘Pelvic in-

ﬂammatory disease’ that changes the context as ‘PID’

is a ﬁle of Snort tool (Snort, 2020). Hence, we need

to build an immutable word list, which will not be

changed during augmentation. The immutable words

refer to domain-speciﬁc words (e.g., malware, HIDS)

that are usually Nouns (Sworna et al., 2022). Firstly,

we created a list of words under the Noun tag from

API

using NLTK (Steven Bird and Loper, 2009) POS

tagger and Universal Part-of-Speech Tagset. Then, we

built the immutable word corpus by inspecting that list.

Two researchers performed immutable word selection

with Cohen’s Kappa (McHugh, 2012) of 0.78, which

indicates substantial agreement.

For text augmentation, 19 different suitable aug-

mentation techniques were used, which are reported

to improve the performance of security tools’ API rec-

ommendation (Sworna et al., 2022). We implemented

these augmentation techniques (listed in our online Ap-

pendix

) on the API corpus using NLPAug (Ma, 2019)

library. Hence, the augmented corpus

API

included

the original data and augmented data.

Processed API Corpus: To build the processed API

corpus, the augmented API descriptions of the corpus

were further processed by removing noises and stop-

words, lowercasing and lemmatizing.

https://tinyurl.com/2bjhp5x8

ENASE 2023 - 18th International Conference on Evaluation of Novel Approaches to Software Engineering

2.3 Research Methods to Answer RQs

This section presents the research methods used for

answering our RQs. We ran our experiments in a

computing cluster including 10 CPU cores with 10GB

RAM of Linux NeXtScale system (Intel X86-64). We

augmented data for each API adopting text augmen-

tation techniques from the labeled data of API docu-

mentation as API documentation provides API with

relevant description representing labeled data. Thus,

the augmented data mitigated the need of time and

effort consuming manual labeling of a large number of

data for validating the prediction model. We randomly

shufﬂed our corpus and performed stratiﬁed 80-20

train-test split, which is commonly used in the liter-

ature (Yenigalla et al., 2018), (Sworna et al., 2022).

We performed 10-fold cross-validation on that 80%

train dataset for hyper-parameter optimization, which

is the recommended practice for learning-based mod-

els (Scikit-learn, 2022b). We used the 20% test dataset

for the models’ evaluation. Since queries can have syn-

onyms, para-phrases and contextual similar words, our

generalized test query set represents a wider variety of

Natural Language (NL) queries as the augmented de-

scription ensures NL variation of the API descriptions

as queries (Sworna et al., 2022).

RQ1. Traditional ML Models’ Performance In-

vestigation: In this RQ, we explore ﬁve traditional

ML models for security tool API recommendation

such as (i) Naïve Bayes (NB); (ii) Support Vector Ma-

chine (SVM); (iii) Logistic Regression (LR); (iv) Ran-

dom Forrest (RF); and (v) eXtreme Gradient Boosting

(XGB). These models belong to different categories

such as Bayesian networks, Support vector machines,

Regression and Ensemble. We consider these mod-

els as they are representative of the most investigated

models and considered state-of-the-art in SE for docu-

mentation classiﬁcation (Fucci et al., 2019), security

text prediction (Le et al., 2020) and SE-speciﬁc text

prediction and classiﬁcation (Fu and Menzies, 2017).

Besides, the adoption of two to ﬁve representative ML

models is a usual practice in the literature (Fakhoury

et al., 2018), (Fucci et al., 2019).

Our goal is to study how well simple ML, with-

out complex feature engineering or Natural Language

Processing (NLP) techniques (e.g., NN-based embed-

dings), can recommend security tools’ API. Hence,

we consider simple statistical features that are easy to

compute and improve the performance of ML mod-

els (Haque et al., 2022). To obtain the relevant fea-

tures from the API corpus, we used different Term

Frequency-Inverse Document Frequency (TF-IDF)-

based feature representations. For each ML model,

we compared TF-IDF-based word level, word n-gram

Table 4: Hyper-parameters of ML models and baselines (for

best performing features of ML models).

Model Feature Tuned Hyper-parameter

NB Word+Char alpha: 0.06271, ﬁt_prior: False

LR Word+Char

C: 2.60, tolerance: 5.82e-05, ﬁt_intercept:

True, max_iter: 250, solver: lbfgs,

warm_start: True

SVM Char C: 8.68, linear kernel, gamma: 3.56

RF Word+Char

criterion: gini, max_depth: none,

max_features: auto, n_estimators: 100

XGB Word+Char

gamma: 0.16, learning_rate: 0.13,

max_depth: 10, min_child_weight: 1.0,

n_estimators: 27

SimScore

Word2Vec

window size: 5, min_count: 1, embedding

dim: 300, workers: 3, skip-gram(sg): 1, hi-

erarchical_softmax(hs): 1

APIRO FastText

For fastText:- word_ngrams: 1, window:

5, embedding dim: 300, workers: 3,

min_count: 1, skip-gram(sg): 1, hierarchi-

cal_softmax(hs): 1. For CNN:- embedding

dim: 300, batch: 64, dropout: 0.5, epoch

num: early stop with patience: 50, ﬁlter

size:(3, 4, & 5), num of hidden node: 100,

L2R: 0.0001, ﬁlter num: 100

level, character (char) level and the combination of

word and char level features along with NLP/text-

based features. We chose these ﬁve feature represen-

tations as they are commonly used and showed good

performance in the existing literature (Haque et al.,

2022), (Xia et al., 2014) of cyber security and SE do-

main. NLP/text-based features that we chose are the

count of word, character, noun, verb, adjective, adverb,

pronoun and word density. Other NLP features such

as punctuation (removed in pre-processing), and case

(lower-cased in pre-processing) were not applicable as

they were irrelevant to our corpus.

For char level features, we chose an n-gram range

of 2-4 characters as the vocabulary size did not in-

crease after the value 4. Similarly, for word n-gram

features, we chose the n-gram range of 2-4. We tuned

each model’s hyper-parameter based on Bayesian Opti-

misation (Feurer and Hutter, 2019) using the Hyperopt

library (Bergstra et al., 2013). To ﬁnd optimal values

for parameters, we used Bayesian Optimisation for its

robustness against the evaluation of noisy objective

function and because it outperforms the other hyperpa-

rameter optimization approaches (e.g., random search)

(Snoek et al., 2012). Each model for each feature rep-

resentation was tuned individually. For conciseness, in

Table 4 we report the tuned hyperparameter values of

each model for only the best performing feature rep-

resentation (detailed in Section 3.1). We used Scikit-

learn (Scikit-learn, 2022a) and Gensim (

Reh˚u

rek and

Sojka, 2010) to implement our ML models.

RQ2. Comparison with Baselines: To answer RQ2,

we compared the performance of the best perform-

ing traditional ML model that we identiﬁed in RQ1

with two baselines. Firstly, to implement the state-of-

the-art security tool API recommender called APIRO

(Sworna et al., 2022), we used their fastText embed-

Security Tools’ API Recommendation Using Machine Learning

90.85%

93.26% 93.22% 93.23%

91.20%

76.51%

76.73%

76.80%

93.72%

10.99%

92.64%

94.80%

94.65%

76.20%

92.53%

8.12%

14.20%

13.25%

16.74%

6.54%

93.16%

94.73%

94.86%

93.93%

92.75%

0.00%

20.00%

40.00%

60.00%

80.00%

100.00%

NB SVM LR RF XGB

Word Level Word N-Gram Level Char level Text/NLP Word+Char Level

Figure 1: Acc of ML models with different feature representations.

ding (Bojanowski et al., 2017) based CNN approach.

We ﬁrst built a security tool API-speciﬁc fastText em-

bedding on

API

corpus using Gensim (

Reh˚u

rek and

Sojka, 2010). We built the CNN model based on the

fastText embedding using Keras (Chollet et al., 2015)

library. We followed the same hyper-parameter tuning

process of APIRO (Sworna et al., 2022) and report our

best parameter setting in Table 4.

To implement another baseline, SimScore, we used

Word2Vec (Mikolov et al., 2013) and IDF-weighted

cosine similarity score approach that is commonly

adopted in the existing studies for Java API recom-

mendation (Cai et al., 2019), (Huang et al., 2018), (Ye

et al., 2016). Unlike the existing studies (Cai et al.,

2019), (Huang et al., 2018) we do not consider the

Stack Overﬂow (SO) data (i.e., we rely on API doc-

umentation), and our approach is not conﬁned to a

language-speciﬁc model as we consider diverse secu-

rity tool’s data for a uniﬁed solution. The parameter

values for SimScore are shown in Table 4.

RQ3. Efﬁciency Evaluation: To answer RQ3, we

evaluated the best performing ML model (identiﬁed in

RQ1) with baselines of RQ2 in terms of required time

(i.e., train, test) and resource utilization (e.g., model

size, core hours in terms of CPU-time elapsed).

2.4 Evaluation Metrics

To answer RQ1 and RQ2, we evaluated our ML models

and baselines using Accuracy (Acc), Mean Reciprocal

Rank (MRR) and Mean Precision@K (MP@K). These

metrics are widely used for API recommendation by

the relevant literature (Huang et al., 2018), (Rahman

et al., 2016), (Ye et al., 2016). To answer RQ2, we

used delta (Fakhoury et al., 2018), which denotes the

performance difference between two models. To an-

swer RQ3, we evaluated the required time (i.e., train,

test) and resource utilization (i.e., model size, maxi-

mum disk write, maximum disk read, core hours for

CPU-time elapsed, User compute CPU, System I/O

CPU and total CPU used) (Fakhoury et al., 2018).

Acc refers to the percentage of queries for which a

recommender can recommend the actual API.

Acc(Q) =

∑

q∈Q

Actual_API(q)

|Q|

% (1)

Here,

refers to the list of all test queries.

Actual_API(q)

provides 1 if the actual API is recom-

mended and 0 otherwise.

MRR denotes if the system returns the correct re-

sult at a high-ranked position. Reciprocal rank denotes

the multiplicative inverse of the rank of the actual

API in the top-K results returned by a recommender.

MRR is the average for all search queries in the test

data. Here,

Rank

is the actual API’s rank for an input

query.

MRR(Q) =

|Q|

∑

q∈Q

Rank

(2)

MP@K denotes the mean of precision@K for all

the test queries. A higher value of MP@K is expected

for a low value of K.

MP@K(Q) =

|Q|

T Pos@K

(T Pos@K) + (FPos@K)

(3)

Here,

T Pos@K

denotes True_Positives@K and

FPos@K denotes False_Positives@K.

3 RESULTS

The RQ evaluation results are presented in this section.

3.1 RQ1. Traditional ML Models’

Performance Investigation

Figure 1 shows the performance comparison of 5

ML models with 5 feature representations in terms

of Acc for recommending security tools’ API. Table

5 presents the performance comparison of the ML

models with diverse features in terms of MRR, MP@1,

MP@2 and MP@3. Our results show that LR using the

combination of word and char level TF-IDF features

outperforms all the other models by achieving 94.86%

Acc, which indicates its ability to recommend correct

APIs. Except for SVM, for all the other models, the

ENASE 2023 - 18th International Conference on Evaluation of Novel Approaches to Software Engineering

Table 5: Comparison of ML models using different features

in terms of MRR, MP@1, MP@2 and MP@3.

Model Feature MRR MP@1 MP@2 MP@3

Word 94.15 90.85 47.95 32.50

Word N-Gram 80.16 75.90 41.26 28.13

Char 95.17 92.64 48.27 32.54

Text/NLP 13.12 8.16 6.64 5.62

Word+Char 95.61 93.16 48.47 32.68

Word 96.01 93.17 48.82 32.91

Word N-Gram 79.99 75.58 41.23 28.18

Char 96.29 93.61 48.67 32.84

Text/NLP 22.92 16.99 11.97 9.73

Word+Char 96.29 94.03 48.76 32.87

SVM

Word 95.19 91.79 48.62 32.89

Word N-Gram 78.35 73.47 40.36 27.78

Char 96.77 94.58 49.02 33.01

Text/NLP 20.03 13.09 10.18 8.42

Word+Char 96.62 94.22 49.03 33.05

XGB

Word 94.35 91.20 47.99 32.48

Word N-Gram 5.30 4.96 2.68 1.87

Char 95.01 92.54 48.21 32.52

Text/NLP 10.89 6.58 5.25 4.65

Word+Char 95.20 92.76 48.26 32.57

Word 95.90 93.23 48.90 32.96

Word N-Gram 95.90 76.19 41.34 28.23

Char 96.79 94.65 49.03 32.98

Text/NLP 19.87 13.30 10.04 8.20

Word+Char 96.96 94.86 49.12 33.05

best performing feature representation was the combi-

nation of word and char level feature, while the char

level feature showed the best performance for SVM.

This indicates that the combination of word and char

level TF-IDF is the most beneﬁcial feature representa-

tion for API description as this combination use both

word and char for learning the semantics of the API

description to provide better results. NLP/text-based

features had the least Acc, MRR and MP@K.

The top 3 best performing ML models for security

tool APIs recommendation are LR, SVM and RF. LR’s

high performance is an indication of a high correla-

tion between the feature and target variable (Bailly

et al., 2022). LR and SVM perform well for text data

due to linear separation and the ability to generalize

high dimensional features typical for text data (Fucci

et al., 2019). Furthermore, SVM is capable of learning

independent of the feature space and regularization

allows it to resist over ﬁtting. Whilst RF and XGB are

both decision-tree-based ensemble models, RF outper-

formed XGB. One of the reasons can be the high num-

ber of APIs in our dataset. As for XGB, the number of

trees to be trained is [number of iterations]*[number

of APIs], whereas RF only requires [number of itera-

tions] trees. RF classiﬁer accumulates decisions from

each tree for the ﬁnal decision. Hence, RF has strong

generalization achieving high Acc without over-ﬁtting

compared to XGB (Misra and Li, 2020). Overall, our

results show that the LR model outperformed all the

other ML models including the ensemble ones (i.e.,

Table 6: Comparison of best performing ML model with the

baselines in terms of Acc, MP@K and MRR.

Model Acc MRR MP@1 MP@2 MP@3

Best performing ML 94.86 96.96 94.86 49.12 33.05

SimScore 80.01 83.98 80.01 42.91 29.28

APIRO 94.50 96.70 94.50 49.04 32.90

RF and XGB). LR using the combination of word and

char level features outperforms all the other models

and achieves 96.96 MRR, which indicates its ability to

recommend the correct API at a higher ranked position

in the recommended list of APIs.

From these ﬁndings, we do not recommend the

use of NLP/text-based features for recommending

security tool APIs. We chose LR with the combi-

nation of word and char level features as the best

performing ML model for recommending security

tool APIs, as it outperformed all the other ML mod-

els with various feature representations in terms of

all the evaluated effectiveness metrics.

14.85

12.98

14.85

6.2

3.77

0.36

0.26

0.36

0.08

0.15

0 2 4 6 8 10 12 14 16

Acc

MRR

MP@1

MP@2

MP@3

Delta Score of best performing ML (LR)

Metrics

Best performing ML (LR) vs APIRO

Best performing ML (LR) vs SimScore

Figure 2: Delta Score of our best performing ML model

with APIRO and SimScore baselines, where positive values

indicate better performance of our ML model.

3.2 RQ2. Comparison with Baselines

Table 6 presents the Acc, MP@K and MRR for our

best performing ML model (LR with the combination

of word and char level features as discussed in RQ1)

and the two baselines. Figure 2 shows the delta score

which denotes the performance difference of our best

performing ML model with SimScore and APIRO, re-

spectively for each metric. In Figure 2, any horizontal

bar above zero represents that our best performing

ML model performs better and the higher the value of

delta, the better our best performing ML model per-

forms. Any bar below zero indicates that the baseline

performs better. As shown in Figure 2, all the bars are

above zero representing that our best performing ML

model outperforms baselines in terms of Acc, MRR,

MP@1, MP@2 and MP@3.

Our experimental result shows that our best per-

forming ML model achieved deltas in the range of

delta

0.36. A prior study (Fakhoury et al., 2018)

Security Tools’ API Recommendation Using Machine Learning

Table 7: Comparison of our best performing ML model with the baselines in terms of resource utilization.

Approach

CPU time

elapsed

(core

hours)

Total CPU

used (core

hours)

User CPU

(Com-

pute):

(core

hours)

System

CPU

(I/O):

(core

hours)

Model

size (GB)

Max Disk

Write

(GB)

Max Disk

Read

(GB)

Best performing ML (LR) 6.27 0.74 0.63 0.11 0.12 0.11 0.03

SimScore 166.17 16.80 15.90 0.91 0.01 0.62 38.47

APIRO 24.14 18.11 17.89 0.22 5.10 12.63 0.42

Improve. SimScore 96.23% 95.60% 96.04% 87.91% -1100% 82.26% 99.92%

Improve. APIRO 74.03% 95.91% 96.48% 50.00% 97.65% 99.13% 92.86%

100

120

140

160

Best performing ML (LR) APIRO SimScore

Train (minute) Test (Sec/query)

Figure 3: Time comparison of our best performing ML

model and baselines for security tool API recommendation.

recommended the applicability of ML over DL in SE

by achieving deltas for their ML model in the range of

-0.1

delta

0.3 for linguistic smell detection. In line

with the resultant deltas (Fakhoury et al., 2018), our

achieved resultant deltas make the applicability suit-

able for using ML over DL (i.e., APIRO) for security

tool API recommendation. Besides, our best perform-

ing ML model signiﬁcantly outperformed SimScore

baseline by achieving 18.57% and 15.45% improve-

ment in terms of Acc and MRR. It indicates that our

best performing ML model can recommend correct

APIs at a higher ranked position in the recommended

list of APIs.

Our result shows that our best performing ML

model outperforms the SimScore and DL-based

APIRO baselines. Hence, our best performing ML

model is recommended for security tool API recom-

mendation.

3.3 RQ3. Efﬁciency Evaluation

Table 7 shows the comparison of the resource utiliza-

tion of our best performing ML model (LR with word

and char level features) with baselines (i.e., APIRO

and SimScore). The memory (in terms of GB) con-

sumption reduction percentages by our best perform-

ing ML model compared to APIRO are 97.65% model

size, 99.13% maximum disk write and 92.86% max-

imum disk read. Our best performing ML model

also signiﬁcantly reduces the required core hours com-

pared to APIRO in terms of 74.03% CPU time elapsed,

96.48% User compute CPU, 50.00% System I/O CPU

and 95.91% total CPU used. Hence, DL-based APIRO

is highly resource consuming as it consumes more re-

sources than our best performing ML model. Similarly,

another baseline SimScore also requires more mem-

ory than our best performing ML model in terms of

82.26% maximum disk write and 99.92% maximum

disk read, except for model size, where SimScore’s

model size is smaller than our best performing ML

model. However, the Acc of SimScore is 18.57% less

than our best performing ML model and SimScore

requires more core hours than our best performing ML

model with a percentage increase of 96.23% CPU time

elapsed, 96.04% User compute CPU, 87.91% System

I/O CPU and 95.60% total CPU used. Hence, the

drastically high resource utilization of the DL-based

approach strongly justiﬁes the use of our less resource

consuming ML approach.

The time for training and testing each model is

shown in Figure 3. For training, DL-based APIRO

requires 291.50% more time than our best performing

ML model. Though SimScore requires less training

time than our best performing ML model, the Acc of

SimScore is 18.57% lower than our best performing

ML model as mentioned earlier. Besides, SimScore

requires 3.40 seconds per query, whereas our best per-

forming ML model and APIRO both require less than a

second to answer a query in terms of testing time. Sim-

Score requires the maximum testing time compared to

the other models as it calculates the cosine similarity

score for the query with each API description of the

training corpus.

Our results show that DL-based APIRO re-

quires a signiﬁcantly large amount of resources

(e.g., memory, CPU time, Disk read and write) and

signiﬁcantly high training time compared to our

best performing ML model. Hence, considering

both the effectiveness (e.g., Acc, MRR) and the

efﬁciency (e.g., time and resources), our best per-

forming ML model performs signiﬁcantly better for

security tool API recommendation than baselines

and provides signiﬁcant cost-cutting opportunities

to be adopted in the real world SOCs.

ENASE 2023 - 18th International Conference on Evaluation of Novel Approaches to Software Engineering

4 THREATS TO VALIDITY

The representativeness of the experimental data to the

real world SOC environment is the primary threat to

validity. We address this threat by conducting exper-

iments on data collected from 7 real world security

tools that are widely used in SOCs.

Enriching the security tool API corpus by adding

more security tools’ data is a continuous process. Our

dataset may not cover each possible query. Besides,

answering queries having extreme rare terms can be

difﬁcult for our approach. However, our generalized

approach enables re-training of the model for deal-

ing with such queries, where additional augmented

text and new augmentation techniques can be used to

handle the extreme rare terms.

To ensure a fair and valid comparison, we imple-

mented our ML models and baselines in the same en-

vironment using the same pre-processing steps on the

same dataset. We ran each experiment ten times and

reported the average to mitigate the experimental ran-

domness of results, which is a common repeat scheme

for learning-based models (Wang et al., 2019). The

chosen optimal hyper-parameters for traditional ML

models may not ensure the best result to recommend

suitable APIs. To minimize this threat, we used 10-

fold cross-validation and the state-of-the-art Bayesian

Optimisation for choosing optimal hyper-parameters.

5 IMPLICATIONS

Our results generated implications for both practition-

ers and researchers based on our analysis.

5.1 Implication for Practitioners

Resource constraint is considered as one of the signiﬁ-

cant challenges for utilizing AI-based (e.g., ML, DL,

NLP) solutions (Fu and Menzies, 2017). We present

important and deep insights into the comparative anal-

ysis of ML, DL and similarity score-based approaches

for security tool API recommendation. The ﬁndings

can enable practitioners to understand the resource uti-

lization of the investigated approaches before choos-

ing a particular AI-based approach to automating the

security tool APIs recommendation. Instead of pre-

ferring DL-based solution, practitioners may also con-

sider the use of traditional ML models, speciﬁcally

Small to Medium-sized Enterprises (SMEs) with lim-

ited resource and time allocation for ensuring security

(CSCRC, 2022). Since the use of DL is expensive,

most SOC will desire to use a simple ML approach.

As LR achieved better performance than DL with rela-

tively less amount of time and resources, practitioners

may consider LR for automated security tool API rec-

ommendation. Besides, the adoption of new security

tools and APIs requires re-training of a model. As ML

showed signiﬁcantly lower training time compared to

the DL approach, ML is a viable option for practition-

ers to re-train a model to cope with the evolving threat

landscape with signiﬁcant cost-cutting opportunities

that helps achieve sustainable design.

5.2 Implication for Researchers

Our best performing ML model motivates sustainable

design presenting a cautionary tale to researchers to

keep resource constraints in mind for real world ap-

plicability, as cost, resource and time constraints may

present signiﬁcant barriers to the industrial adoption

of a proposed solution. This cautionary recommenda-

tion based on a completely different task (i.e., security

tool API recommendation) strengthens this suggestion

by the prior studies (Fakhoury et al., 2018), (Fu and

Menzies, 2017). In the future, researchers can focus

on automated execution of the recommended APIs for

executing an Incident Response Plan (IRP) in response

to a security incident. Our best performing ML model

can also be explored for query answer recommenda-

tions from other artifacts of security tools (e.g., user

guide and tutorial).

6 RELATED WORK

This section summarizes the related work on security

incident response and API recommendation.

6.1 Cyber Security Incident Response

Different SOAR platforms (e.g., Swimlane (Swimlane,

2022), D3 (D3, 2017) and ThreatConnect (ThreatCon-

nect, 2019)) leverage APIs for incident response. How-

ever, developers and users of these SOAR platforms

manually look for the required APIs from the docu-

mentation to create, update and execute IRPs (Sworna

et al., 2022). APIRO is a DL-based foundation frame-

work for security tool API recommendation to sup-

port incident response using a CNN approach (Sworna

et al., 2022). In contrast to our study, APIRO does not

focus on resource utilization to mitigate SOC’s cost

and resource constraints (CSCRC, 2022).

6.2 API Recommendation in SE

The existing studies on programming language speciﬁc

APIs recommendation are mostly code, Stack Over-

Security Tools’ API Recommendation Using Machine Learning

ﬂow (SO) or documentation based approaches. For

code based studies, a set of studies (He et al., 2021),

(Ling et al., 2020), (Ling et al., 2019), (Xu et al., 2018),

(Gu et al., 2016), (Raghothaman et al., 2016), (Chan

et al., 2012), (McMillan et al., 2011) used open source

GitHub code repositories for recommending API us-

ages and code snippets. These code based approaches

perform time consuming complex code analysis.

The SO based approach is used for API recom-

mendation (Wu et al., 2021), (Zhou et al., 2021), (Cai

et al., 2019), (Huang et al., 2018), (Rahman et al.,

2016). However, SO is slow at covering new APIs

(Parnin et al., 2012) and SO data is less reliable as it

may cause security ﬂaws in code due to considering

unreliable suggestions (Acar et al., 2016). To mitigate

these issues, we use the comprehensive security tool

APIs documentation.

The code based and SO based approaches can only

cover the frequently used and discussed APIs (Xie

et al., 2020). Hence, our approach uses API documen-

tation so that our approach is not unable to recommend

APIs that are less frequently used. Besides, a study

(Xie et al., 2020) consider API documentation to man-

ually identify, categorize verbs and manually generate

verb-phrase patterns for matching functionality verb-

phrases of API description and query. It is highly time

and labor-intensive to perform these huge manual anal-

ysis on each API documentation of the wide range of

security tools that a SOC can utilize. Thus, we avoid

these manual efforts and adopt automated data aug-

mentation and the ML-based approach to recommend

security tool API. Another study (Fucci et al., 2019)

used the ML-based approach to annotate knowledge

types (e.g., purpose, quality and environment) to API

documentation, in contrast, we recommend security

tool API from diverse API documentation.

7 CONCLUSION

SOCs face cost, time and resource constraints to re-

spond to numerous security incidents. Hence, our

study inspires Green-AI and sustainable design by pre-

senting a cautionary tale to keep resource constraints

in mind for real world applicability of security tools’

API recommendation. We performed an empirical

study comparing 5 simple ML models with various

feature representations compared to the complex DL

models aiming at both efﬁciency and effectiveness

for recommending security tools’ API. Using APIs

of seven widely used real world security tools, our

best performing ML model achieved an exemplary

reduction of resource and time with better Acc and

MRR compared to baselines including the state-of-the-

art DL-based approach. Our empirically derived best

performing ML model with its tremendous time and re-

source efﬁciency including better effectiveness makes

it a viable approach to be adopted in real world SOC

with signiﬁcant cost-cutting opportunities. Our future

research will focus on extending our best performing

ML model by using the recommended APIs for au-

tomated execution of the security incident response

plans in SOC.

ACKNOWLEDGEMENTS

The work has been supported by the Cyber Security

Research Centre Limited whose activities are partially

funded by the Australian Government’s Cooperative

Research Centres Programme. This work has also been

supported with super-computing resources provided by

the Phoenix HPC service at the University of Adelaide.

REFERENCES

Acar, Y., Backes, M., Fahl, S., Kim, D., Mazurek, M. L., and

Stransky, C. (2016). You get where you’re looking for:

The impact of information sources on code security. In

2016 IEEE Symposium on Security and Privacy (SP),

pages 289–305. IEEE.

Bailly, A., Blanc, C., Francis, É., Guillotin, T., Jamal, F.,

Wakim, B., and Roy, P. (2022). Effects of dataset size

and interactions on the prediction performance of lo-

gistic regression and deep learning models. Computer

Methods and Programs in Biomedicine, 213:106504.

Beautifulsoup (2020). Beautiful soup package.

https://tinyurl.com/yf27edhf. Accessed October

1, 2022.

Bergstra, J., Yamins, D., and Cox, D. (2013). Making a

science of model search: Hyperparameter optimization

in hundreds of dimensions for vision architectures. In

International conference on machine learning, pages

115–123. PMLR.

Biswas, S., Wardat, M., and Rajan, H. (2021). The art and

practice of data science pipelines: A comprehensive

study of data science pipelines in theory, in-the-small,

and in-the-large. arXiv preprint arXiv:2112.01590.

Bojanowski, P., Grave, E., Joulin, A., and Mikolov, T. (2017).

Enriching word vectors with subword information.

Transactions of the Association for Computational Lin-

guistics, 5:135–146.

Cai, L., Wang, H., Huang, Q., Xia, X., Xing, Z., and Lo,

D. (2019). Biker: a tool for bi-information source

based api method recommendation. In Proceedings

of the 2019 27th ACM Joint Meeting on European

Software Engineering Conference and Symposium on

the Foundations of Software Engineering, pages 1075–

1079.

ENASE 2023 - 18th International Conference on Evaluation of Novel Approaches to Software Engineering

Calero, C. and Piattini, M. (2015). Introduction to green in

software engineering. In Green in Software Engineer-

ing, pages 3–27. Springer.

Chan, W.-K., Cheng, H., and Lo, D. (2012). Searching con-

nected api subgraph via text phrases. In Proceedings of

the ACM SIGSOFT 20th International Symposium on

the Foundations of Software Engineering, pages 1–11.

Chatterjee, P., Damevski, K., and Pollock, L. (2021). Au-

tomatic extraction of opinion-based q&a from online

developer chats. In 2021 IEEE/ACM 43rd Interna-

tional Conference on Software Engineering (ICSE),

pages 1260–1272. IEEE.

Choetkiertikul, M., Dam, H. K., Tran, T., Pham, T., Ghose,

A., and Menzies, T. (2018). A deep learning model for

estimating story points. IEEE Transactions on Software

Engineering, 45(7):637–656.

Chollet, F. et al. (2015). Keras.

https://github.com/fchollet/keras. Accessed Oc-

tober 20, 2022.

CSCRC, CSIRO’s Data61, C. (2022). Small

but stronger: Lifting sme cyber security.

https://tinyurl.com/2juxjnk6. Accessed October

21, 2022.

Cuckoo (2019). Cuckoo: Automated malware analysis.

https://cuckoosandbox.org/. Accessed October 20,

2022.

D3 (2017). Enterprise incident & case management solu-

tion for security orchestration, automation & response.

https://tinyurl.com/5bcwkuk4. Accessed October 20,

2022.

Fakhoury, S., Arnaoudova, V., Noiseux, C., Khomh, F., and

Antoniol, G. (2018). Keep it simple: Is deep learning

good for linguistic smell detection? In 2018 IEEE 25th

International Conference on Software Analysis, Evolu-

tion and Reengineering (SANER), pages 602–611.

Feurer, M. and Hutter, F. (2019). Hyperparameter optimiza-

tion. In Automated Machine Learning, pages 3–33.

Springer, Cham.

Fu, W. and Menzies, T. (2017). Easy over hard: A case study

on deep learning. In Proceedings of the 2017 11th joint

meeting on foundations of software engineering, pages

49–60.

Fucci, D., Mollaalizadehbahnemiri, A., and Maalej, W.

(2019). On using machine learning to identify knowl-

edge in api reference documentation. In Proceedings

of the 2019 27th ACM Joint Meeting on European Soft-

ware Engineering Conference and Symposium on the

Foundations of Software Engineering, pages 109–119.

Gu, X., Zhang, H., Zhang, D., and Kim, S. (2016). Deep

api learning. In Proceedings of the 2016 24th ACM

SIGSOFT International Symposium on Foundations of

Software Engineering, pages 631–642.

Haque, M. U., Kholoosi, M. M., and Babar, M. A. (2022).

Kgsecconﬁg: A knowledge graph based approach for

secured container orchestrator conﬁguration. In 2022

IEEE 29th International Conference on Software Anal-

ysis, Evolution, and Reengineering (SANER). IEEE.

He, X., Xu, L., Zhang, X., Hao, R., Feng, Y., and Xu, B.

(2021). Pyart: Python api recommendation in real-time.

In 2021 IEEE/ACM 43rd International Conference on

Software Engineering (ICSE), pages 1634–1645. IEEE.

Huang, Q., Xia, X., Xing, Z., Lo, D., and Wang, X. (2018).

Api method recommendation without worrying about

the task-api knowledge gap. In 2018 33rd IEEE/ACM

International Conference on Automated Software En-

gineering (ASE), pages 293–304. IEEE.

Instinct, D. (2021). Research study by deep instinct.

https://www.helpnetsecurity.com/2021/02/17/malware-

2020/. Accessed February 10, 2022.

Le, T. H. M., Hin, D., Croft, R., and Babar, M. A. (2020).

Puminer: Mining security posts from developer ques-

tion and answer websites with pu learning. In Proceed-

ings of the 17th International Conference on Mining

Software Repositories, pages 350–361.

LeCun, Y., Bengio, Y., and Hinton, G. (2015). Deep learning.

nature, 521(7553):436–444.

Limacharlie (2022). Ofﬁcial limacharlie page.

https://www.limacharlie.io/. Accessed October

20, 2022.

Ling, C., Lin, Z., Zou, Y., and Xie, B. (2020). Adaptive deep

code search. In Proceedings of the 28th International

Conference on Program Comprehension, pages 48–59.

Ling, C.-Y., Zou, Y.-Z., Lin, Z.-Q., and Xie, B. (2019).

Graph embedding based api graph search and recom-

mendation. Journal of Computer Science and Technol-

ogy, 34(5):993–1006.

Ma, E. (2019). Nlp augmentation.

https://github.com/makcedward/nlpaug. Accessed

October 20, 2022.

McHugh, M. L. (2012). Interrater reliability: the kappa

statistic. Biochemia medica, 22(3):276–282.

McMillan, C., Grechanik, M., Poshyvanyk, D., Xie, Q., and

Fu, C. (2011). Portfolio: ﬁnding relevant functions and

their usage. In Proceedings of the 33rd International

Conference on Software Engineering, pages 111–120.

Mikolov, T., Sutskever, I., Chen, K., Corrado, G. S., and

Dean, J. (2013). Distributed representations of words

and phrases and their compositionality. In Advances

in neural information processing systems, pages 3111–

3119.

MISP (2022). Malware information sharing platform.

https://www.misp-project.org. Accessed October 20,

2022.

Misra, S. and Li, H. (2020). Chapter 9 - noninvasive fracture

characterization based on the classiﬁcation of sonic

wave travel times. In Misra, S., Li, H., and He, J.,

editors, Machine Learning for Subsurface Characteri-

zation, pages 243–287. Gulf Professional Publishing.

Mou, L., Li, G., Zhang, L., Wang, T., and Jin, Z. (2016).

Convolutional neural networks over tree structures for

programming language processing. In Thirtieth AAAI

conference on artiﬁcial intelligence.

Muncaster, P. (2021). Organizations now have 76

security tools to manage. https://www.infosecurity-

magazine.com/news/organizations-76-security-tools/.

Accessed October 20, 2022.

Nguyen, T. D., Nguyen, A. T., Phan, H. D., and Nguyen, T. N.

(2017). Exploring api embedding for api usages and

applications. In 2017 IEEE/ACM 39th International

Security Tools’ API Recommendation Using Machine Learning

Conference on Software Engineering (ICSE), pages

438–449. IEEE.

PAN (2019). Palo alto networks: The state of soar re-

port. https://start.paloaltonetworks.com/the-2019-state-

of-soar-report.html. Accessed October 21, 2020.

PAN (2022). Palo alto networks: Cortex xsoar.

https://xsoar.pan.dev. Accessed September 3, 2022.

Parnin, C., Treude, C., Grammel, L., and Storey, M.-A.

(2012). Crowd documentation: Exploring the coverage

and the dynamics of api discussions on stack overﬂow.

Georgia Institute of Technology, Tech. Rep, 11.

Phantom (2021). Splunk phantom: Harness the

full power of your security investments with

security orchestration, automation and response.

https://tinyurl.com/4493k5nk. Accessed September

3, 2022.

Raghothaman, M., Wei, Y., and Hamadi, Y. (2016). Swim:

Synthesizing what i mean-code search and idiomatic

snippet synthesis. In 2016 IEEE/ACM 38th Interna-

tional Conference on Software Engineering (ICSE),

pages 357–367. IEEE.

Rahman, M. M., Roy, C. K., and Lo, D. (2016). Rack: Auto-

matic api recommendation using crowdsourced knowl-

edge. In 2016 IEEE 23rd International Conference

on Software Analysis, Evolution, and Reengineering

(SANER), volume 1, pages 349–359. IEEE.

Reh˚u

rek, R. and Sojka, P. (2010). Software Framework

for Topic Modelling with Large Corpora. In Proceed-

ings of the LREC 2010 Workshop on New Challenges

for NLP Frameworks, pages 45–50, Valletta, Malta.

ELRA.

Robillard, M. P. and DeLine, R. (2011). A ﬁeld study of api

learning obstacles. Empirical Software Engineering,

16(6):703–732.

Scikit-learn (2022a). Api reference. https://scikit-

learn.org/stable/modules/classes.html#module-

sklearn.metrics. Accessed October 20, 2022.

Scikit-learn (2022b). Cross-validation: evaluating estimator

performance. https://tinyurl.com/4ue9k44b. Accessed

October 20, 2022.

Snoek, J., Larochelle, H., and Adams, R. P. (2012). Practical

bayesian optimization of machine learning algorithms.

Advances in neural information processing systems,

25.

Snort (2020). Snort users manual 2.9.16.

https://tinyurl.com/2p8ferjm. Accessed October

20, 2022.

Splunk (2022). Splunk: Siem, aiops, application manage-

ment. https://www.splunk.com/. Accessed October 20,

2022.

Steven Bird, E. K. and Loper, E. (2009). Natural Language

Processing with Python. O’Reilly Media Inc.

Strubell, E., Ganesh, A., and McCallum, A. (2019). En-

ergy and policy considerations for deep learning in nlp.

arXiv preprint arXiv:1906.02243.

Swimlane (2022). Security orchestration, au-

tomation and response (soar) capabilities.

https://tinyurl.com/2p82wjvu. Accessed October 20,

2022.

Sworna, Z. T., Islam, C., and Babar, M. A. (2022). Apiro:

A framework for automated security tools api recom-

mendation. ACM Trans. Softw. Eng. Methodol. Just

Accepted.

ThreatConnect (2019). Everything you need to know about

soar. https://tinyurl.com/yfhp7sfx. Accessed October

20, 2022.

Vielberth, M., Böhm, F., Fichtinger, I., and Pernul, G. (2020).

Security operations center: A systematic study and

open challenges. IEEE Access, 8:227756–227779.

Wang, S., Phan, N., Wang, Y., and Zhao, Y. (2019). Ex-

tracting api tips from developer question and answer

websites. In 2019 IEEE/ACM 16th International Con-

ference on Mining Software Repositories (MSR), pages

321–332. IEEE.

Wazuh (2022). Wazuh website. https://wazuh.com. Accessed

October 20, 2022.

White, M., Vendome, C., Linares-Vásquez, M., and Poshy-

vanyk, D. (2015). Toward deep learning software repos-

itories. In 2015 IEEE/ACM 12th Working Conference

on Mining Software Repositories, pages 334–345.

Wu, D., Jing, X.-Y., Zhang, H., Zhou, Y., and Xu, B. (2021).

Leveraging stack overﬂow to detect relevant tutorial

fragments of apis. In 2021 IEEE International Confer-

ence on Software Analysis, Evolution and Reengineer-

ing (SANER), pages 119–130.

Xia, X., Lo, D., Qiu, W., Wang, X., and Zhou, B. (2014).

Automated conﬁguration bug report prediction using

text mining. In 2014 IEEE 38th Annual Computer

Software and Applications Conference, pages 107–116.

Xie, W., Peng, X., Liu, M., Treude, C., Xing, Z., Zhang, X.,

and Zhao, W. (2020). Api method recommendation via

explicit matching of functionality verb phrases. In Pro-

ceedings of the 28th ACM Joint Meeting on European

Software Engineering Conference and Symposium on

the Foundations of Software Engineering, pages 1015–

1026.

Xu, C., Sun, X., Li, B., Lu, X., and Guo, H. (2018). Mulapi:

Improving api method recommendation with api usage

location. Journal of Systems and Software, 142:195–

205.

Ye, X., Shen, H., Ma, X., Bunescu, R., and Liu, C. (2016).

From word embeddings to document similarities for

improved information retrieval in software engineering.

In Proceedings of the 38th international conference on

software engineering, pages 404–415.

Yenigalla, P., Kar, S., Singh, C., Nagar, A., and Mathur, G.

(2018). Addressing unseen word problem in text clas-

siﬁcation. In International Conference on Applications

of Natural Language to Information Systems, pages

339–351. Springer.

Zeek (2020). Zeek: An open source network security mon-

itoring tool. https://zeek.org/. Accessed October 20,

2022.

Zhou, Y., Yang, X., Chen, T., Huang, Z., Ma, X., and Gall,

H. C. (2021). Boosting api recommendation with im-

plicit feedback. IEEE Transactions on Software Engi-

neering.

ENASE 2023 - 18th International Conference on Evaluation of Novel Approaches to Software Engineering
