Trace-Based Authentication Biometric for On-Line Education

Fatma Derbel Bouattour and Pierre-Antoine Champin

Universit

e de Lyon, CNRS Universit

e Lyon 1, LIRIS, UMR5205, F-69622, France

Keywords:

Authentication, Biometric, Keystroke Dynamics, Mouse Dynamics, m-Traces, e-Learning

Abstract:

In this paper, we present a continuous behavioral authentication system for Web applications and in particular

for on-line education applications. Our system implement two behavioral biometric modalities, keystroke

dynamics and mouse dynamics, with m-traces concepts. We describe our trace based authentication approach

as well as the experiments we have conducted.

1 INTRODUCTION

On-line educational engineering is facing numerous

challenges and issues linked to teaching courses and

knowledge transmission, this evolution is encounter-

ing much unwillingness when granting and recogniz-

ing diplomas or qualiﬁcations. In fact, many organi-

zations don’t give equivalent credits for qualiﬁcations

obtained on-line compared to those obtained in situ

in a school or a learning center. One of the main ar-

guments for this lack of trust in remote learning pro-

grams is the fact that users may share authentication

credentials in order to cheat and obtain the certiﬁca-

tion. So for organizations that use these platforms to

award qualiﬁcations, the question of the authentica-

tion’s reliability is crucial because it guarantees the

credibility of the delivered certiﬁcates.

This paper focuses on the issue of learners authen-

tication in Web-based e-learning platforms. Authen-

tication is the process of conﬁrming a user’s iden-

tity, usually before giving them access to resources

or services in a secure environment. Many user au-

thentication approaches have been proposed in the

literature, and they can be divided into three cate-

gories (O’Gorman, 2003): knowledge-based authen-

tication, object-based authentication and biometric

authentication.The biometrics authentication methods

are divided into two categories: physiological biomet-

rics (face, ﬁngerprint,..) and behavioral biometrics

(keystroke dynamics, mouse dynamics,..) (Matyas

and Riha, 2003).

Biometric authentication has several advantages

over knowledge-based and object-based authentica-

tion because biometrics cannot be forgotten, stolen,

or misplaced. Additionally, behavioral biometric au-

thentication methods are less obtrusive than other bio-

metric methods and do not require special hardware in

order to capture the necessary biometric data.

Authentication methods are also divided into

static and continuous methods. A static authentication

system authenticates the user only once, when they

open their session, so it can not detect any change of

identity during a session. On the other hand, a contin-

uous authentication system veriﬁes the user’s authen-

ticity during the whole session. There are many ways

to implement continuous authentication systems, but

behavioral biometrics seems a good choice due to

the unobtrusive data collection that it allows. While

keystroke dynamics (KD) and mouse dynamics (MD)

are commonly used for this purpose (see Section 2

for more details on these two modalities), we argue

that complementing them with other behavioral in-

dicators can help improve the robustness of continu-

ous authentication systems. Of course, this requires a

data model that is versatile enough to capture multiple

facets of the user’s activity, such as the m-trace meta-

model proposed by (Mille et al., 2013) (described in

more details in Section 3.1).

In this paper, we present a continuous authenti-

cation system based on behavioral data implemented

with m-trace, which we have designed for for the con-

text of e-learning Web applications. This paper de-

scribes the following contributions:

- We propose a general architecture of an authen-

tication system based on interaction traces.

- We describe how biometric behavior modalities

can be implemented in our authentication system and

integrated it in an e-learning platform in order to con-

tinuously and dynamically authenticate learners.

- We compare the proposed system with state-of-

154

Bouattour, F. and Champin, P.

Trace-Based Authentication Biometric for On-Line Education.

DOI: 10.5220/0011776200003470

In Proceedings of the 15th International Conference on Computer Supported Education (CSEDU 2023) - Volume 1, pages 154-161

ISBN: 978-989-758-641-5; ISSN: 2184-5026

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

the-art authentication approaches in the context of e-

learning platforms.

The remainder of this paper will be as follows.

In the next section, we present a state of the art of

authentication systems implementing KD and MD in

e-learning platform. In the Section 3, we describe

the methodology followed in our research. In Sec-

tion 4, we describe the operation of each component

of our authentication system for both the KD and

MD modalities. Experimental results are described

and analyzed in Section 5. Finally, we conclude and

present some further developments of this research.

2 RELATED WORKS

Continuous Behavioral Biometric Authentication

Systems Using KD and MD. In this section, we

present the state of the art in continuous behavioral

biometric authentication systems , more speciﬁcally

on those based on the KD and MD modalities.

The motivation behind the use of these behavioral

biometric data is that they do not require any addi-

tional hardware for data capture. In addition, they can

be collected without interrupting the user’s activity.

Most researches on this topic report performances

in terms of False Acceptance Rate (FAR), False

Recognition Rate (FRR), and sometimes Equal Er-

ror Rate (EER) (Ahmed and Traore, 2005; Pusara,

2007; Bailey et al., 2014). FAR and FRR are deﬁned

as percentages; FAR represents the chances that an

impostor is accepted by the system, while FRR rep-

resents the chances that a genuine user is rejected by

the system. The EER is the value where FAR and

FRR are equal. Other researches (Mondal and Bours,

2017) have used different indicators for measuring au-

thentication performance: they focus on the number

of actions that impostors and genuine users, respec-

tively, can perform before being rejected or terminat-

ing the session. The Average Number of Impostor

Actions (ANIA) should therefore be as low as possi-

ble, while the Average Number of Genuine Actions

(ANGA) should be as high as possible.

Researches on continuous authentication using

KD was started by (Shepherd, 1995). They authenti-

cate users by analyzing the way they type on a key-

board (Bergadano et al., 2002). Some approaches

require the user to type a ﬁxed text (Kolakowska,

2011) while others can work on free text (Kang and

Cho, 2015). Most existing researches on KD use the

time between two successive keys as features (Ara

ujo

et al., 2004), although some researches also con-

sider n-graph durations (Davoudi and Kabir, 2010).

For classifying users, many researches compare fea-

ture vectors using various distance measures (Bours,

2012), or other measures of how their order dif-

fer (Kolakowska, 2011). Others use machine learning

techniques, such as nearest neighbor classiﬁers (Kang

and Cho, 2015) and neural networks (Ahmed and

Traore, 2014). Another approach for continuous au-

thentication, based on a trust model, has been pro-

posed by (Bours and Mondal, 2015). The conﬁdence

in the user’s authenticity is represented by a trust

value, which is revised for each action by compar-

ing it to the user proﬁle, and applying a penalty-and-

reward function.

Despite a few works using MD for continuous au-

thentication (Shen et al., 2013), this kind of biomet-

ric data has not been used as much as KD. (Gamboa

and Fred, 2004) propose an authentication system that

collects mouse move actions from a Web interface.

Ahmed and Traore (Ahmed and Traore, 2007) use ar-

tiﬁcial neural networks to model the users’ behavioral

characteristics from the captured data.

Mondal and Bours (Mondal and Bours, 2013) use

the trust model presented above to propose a contin-

uous authentication system based on MD behavioral

data.

Several researches have used a combination of

KD and MD in a continuous authentication sys-

tem (Ahmed and Traore, 2005; Pusara, 2007; Bai-

ley et al., 2014). Indeed, since only one biometric

modality is often insufﬁcient to robustly verify the

user’s identity, a combination of multiple modalities

can increase the performance of the authentication

system (Ross and Jain, 2003).

Biometric Authentication System in e-Learning.

In this section, we present an overview of most rel-

evant published works on the usage of biometric au-

thentication in eLearning systems. Many of this au-

thentication methods can be applied in e-Learning

systems in order to prevent impostors from accessing

teaching resources (Belashenkova et al., 2015).

(Agulla et al., 2008) presents a biometric authen-

tication system based on face recognition in the form

of a web application. This application can be eas-

ily integrated into LMS, and allows the use of facial

recognition during access control, tracking and as-

sessment. (Fayyoumi and Zarrad, 2014) developed

also an authentication system for on-line exams using

face recognition. Facial authentication is generally a

reliable method for identiﬁcation, but the variation of

the qualities of web-cams in addition to the lighting

conditions in the learners’ environment do not always

allow an image of sufﬁcient quality to authenticate

them.

(Rabuzin et al., 2006) recommended the system of

Trace-Based Authentication Biometric for On-Line Education

155

multi-biometric methods. The authors argued that au-

thentication based on a single biometric method could

cause security risks. Another multi-biometric authen-

tication system for eLearning systems was introduced

by (Traor

e et al., 2017). (Asha and Chellappan, 2008)

suggested to combine MD and ﬁngerprint recogni-

tion using a mouse with an inbuilt ﬁngerprint sensor.

(Traor

e et al., 2017) proposed a framework combines

keystroke mouse and face biometric for continuous

authentication.

Further approaches for continuous multi-

biometric authentication in eLearning systems have

been presented in cite (Hernandez-Ortega et al.,

2019). Others researchers recommended a combina-

tion of biometric technologies analysing face, voice,

mouse and keystroke dynamics (Jagadamba et al.,

2020).

(Flior and Kowalski, 2010) suggested to employ

continuous authentication based on KD for written

exams. (Morales and Fierrez, 2015) employ KD to

authenticate learner during a real on-line exam, test-

ing their system with 64 subjects. (Ramu and Arivoli,

2013) propose an authentication system to improve

on-line examination by utilizing KD and knowledge

based authentication. In this system exam participant

are authenticated only statically at login time. (Pl-

eva et al., 2016) demonstrate that using keystroke and

mouse dynamics is one of the best choices for contin-

uously authentication in current e learning systems.

(Maas et al., 2014) present the Signature Track au-

thentication process used in the e-learning platform

Coursera. The process uses two biometric authentica-

tion approaches, face recognition and KD. the Cours-

era platform asks the learner to provide a photo with

web-cam of his or her face as well as a photo of a

government-issued ID document, and to establish a

keystroke biometric proﬁle by typing a short phrase.

But this method of authentication is not continuous

since it authenticates the learners at the end of a

course or exercise. In addition it is invasive since it

interrupts the learning activity to perform the authen-

tication process.

3 GENERIC MULTI-MODAL

AUTHENTICATION

3.1 The m-Trace Meta-Model

In order to take into account multiple behavior modal-

ities, we need a ﬂexible model to capture the interac-

tions of the user with the system. We propose to use

the meta-model deﬁned by (Mille et al., 2013), as it

provides the desired ﬂexibility.

The central notion of the meta model is that of

m-trace (short for ”modeled trace”), which is a se-

quence of records representing the actions performed

by a user of a system. Each such record is called an

obsel (short for ”observed element”), and is described

by a type, a set of attributes, and two timestamps (be-

gin and end, delimiting the time interval in which the

obsel occurred

). Each m-trace is associated with a

trace model which speciﬁes the obsel types that trace

may contain, as well as the attributes obsels of each

type can have. The trace model allows to elicit the

structure and the underlying semantics of the m-trace.

M-traces are stored and processed in a system called

a Trace-Base Management System (TBMS). TBMSs

contain two kinds of m-traces: primary traces con-

tain the obsels collected directly from the applica-

tions; transformed traces, on the other hand, are

computed by processing the obsels of one or several

source traces (which can be either primary or trans-

formed). Transformations are typically used to ”lift”

the description of the activity from a low-level trace

model (focusing on atomic interactions) to a higher-

level one (describing more abstract actions and tasks).

The system presented in this paper uses kTBS

a reference TBMS implementation providing a num-

ber of useful transformation operators, from simple

ﬁlters to more complex rewriting methods, based on

the SPARQL query language (Harris and Seaborne,

2013) or ﬁnite state automata (FSA).

3.2 System Architecture

We describe in this section the architecture of our bio-

metric authentication system based on m-traces.

Users’ interactions with the platform are collected

by the collection system Tracing You

, a simple

script that can be added to any Web application, and

conﬁgured to collect a wide range of events inside that

application. Those events are then sent as obsels to

kTBS, which stores them in a primary trace (Cordier

et al., 2015).

These events must then be processed by the Data

Analysis Module to calculate the biometric features

and measures for each modality. The data analy-

sis module converts the collected atomic events into

higher-level obsels describing user actions. This

module is divided in sub-modules, each one handling

a speciﬁc modality. For the moment, a sub-module for

KD and another one for MD are implemented (which

will be described in detail in Section 4). They use a set

It is still possible for an obsel to have the same begin

and end, when it represents an instantaneous event.

http://tbs-platform.org/ktbs/

http://tbs-platform.org/tbs/doku.php/tools:tracingyou

CSEDU 2023 - 15th International Conference on Computer Supported Education

156

of FSA, SPARQL and fusion transformations. FSA

transformations are used to detect sequences of obsels

matching a given pattern, and produce a new obsel

for each occurrence of that pattern. SPARQL trans-

formation use the SPARQL query language (Harris

and Seaborne, 2013) to detect more complex arrange-

ments of obsels, and compute new attributes. Fusion

transformations merge the content of several sources

into a single m-trace. The features computed by

the Data Analysis Module are stored in transformed

traces, which will then be used by the Behavior Trac-

ing Module to build the proﬁle trace, and by the Sig-

nature Creation Module to build the signature trace.

The proﬁle trace is a transformed trace that de-

scribe the learning behavior resulting from different

authentication methods (in this article biometric be-

havior). The signature trace is also a transformed

trace that contains unique features and statistics ex-

tracted from actions after enough occurrences of each

type of action have been observed (the threshold is

currently set to 5). Finally, the Identity Decision

Module will compare an proﬁle trace with the sig-

nature trace with the signature trace generated from

previous (trusted) actions, in order to authenticate the

user.

4 IMPLEMENTING KD AND MD

4.1 Data Collection Module

For KD, we use to capture each key press and key

release events captured by the Tracing You module.

We therefore deﬁne the following obsel types for the

primary trace:

- K Press (key press): this type of obsel describes

the press of a given key from the keyboard. It contains

the following attributes: the character corresponding

to the key pressed, if any (character), the numeric

code for that key (keycode) and the time of the event

in milliseconds (begin and end are equal, as obsels of

this type are always instantaneous).

-K Release (key release): this type of obsel de-

scribes the release of a given key from the keyboard.

It contains the same attributes as type K Press.

For MD, there are three types of events we need

to collect, captured by the following obsel types:

-M Move (mouse move): this obsel type describes

a point traversed by the mouse pointer while it is mov-

ing. It contains the following attributes: the screen

coordinates of the cursor (posX, posY), and the time

of the event (begin and end are equal).

-M BPress (mouse button press): this obsel type

describes the press of a mouse button. It contains

the following attributes: the name of the button be-

ing pressed (TypeButton), the position of the mouse

pointer (posX, posY), and the time of the event (begin

and end are equal).

-M BRelease (mouse button release): this obsel

type is similar to the previous one, but it describes

the release of a mouse button.

4.2 Data Analysis Module

The collected data must then be processed by the Data

Analysis Module to calculate the biometric features

for each modality KD and MD. This module is di-

vided in sub-modules, a sub-module for KD and an-

other one for MD. They use a set of ﬁnite state au-

tomate (FSA), SPARQL and fusion transformations.

FSA transformations are used to detect sequences of

obsels matching a given pattern, and produce a new

obsel for each occurrence of that pattern.

For KD, various features can be extracted from the

raw data. We use in this research the most commonly

used in the literature (Zhong et al., 2012): the hold

time of a key (PR), the time between the release of

a key and the press of the next one (RP), the elapsed

time between two consecutive key releases (RR), and

the elapsed time between two consecutive key presses

(PP). We apply an FSA transformation to calculate

these features from the obsels of the primary trace

described above. The result of this transformation is

a transformed trace that contains the following obsel

types:

-K-PR (key press-release): this obsel type has

the same attributes as K Press above, but its begin

timestamp corresponds to the key press, while its end

timestamp corresponds to its release.

- K-PP (keys press-press): this obsel type contains

the following attributes: the characters corresponding

to the ﬁrst key pressed (charSource) and the next one

(charDestination), the numeric key code of the ﬁrst

key pressed (keySource) and the second one (keyDes-

tination); its begin timestamp corresponds to the ﬁrst

key press, while its end timestamp corresponds to the

second one.

- K-RR (keys release-release) and K-RP (keys

release-press): these types of obsel are similar to the

previous one, but capture the release time of ﬁrst key

in begin and the release (resp. press) of the second

one in end.

For MD, we use four types of actions deﬁned in

the literature (Mondal and Bours, 2013): move, drag-

and-drop, single click and double click.

As with KD, we apply an FSA transformation to

calculate these features from the three kinds of obsels

in the primary trace. The result of this transformation

Trace-Based Authentication Biometric for On-Line Education

157

is a Transformed trace that contains the following ob-

sel types:

- M-BPR (mouse button press-release): this obsel

type describes a single click. Its obsels are produced

whenever a mouse button is pressed and released in

less than a given time (currently set to 2000ms). They

have the following attributes: the name of the button

being clicked (TypeButton), the position of the click

in the screen (xSource, ySource), its begin timestamp

corresponds to the button press, while its end times-

tamp corresponds to its release.

- M-BDC (mouse button double click): this obsel

type describes a double click. Its obsels are produced

whenever two clicks are separated by less than a given

time (currently set to 1000ms). The have the same

attributes as M-BPR above, but their begin timestamp

corresponds to the ﬁrst press, while its end timestamp

corresponds to the second release.

- M-MS (mouse move sequence): this obsel

type describes continuous movements of the mouse

pointer. Its obsels are produced by sequences of M-

Move obsels with less than 250ms between them.

A combination of four transformations (FSA and

SPARQL) is used to compute the following attributes:

the time when the movement began (begin) and ended

(end), the position where the cursor started (xSource,

ySource) and ﬁnished (xDestination, yDestination),

the straight-line distance between those two points

(traveledDistance), the length of the pointer move-

ment (curveLength), the average speed (curveSpeed),

and the overall direction of the movement between 8

possible directions (direction).

- M-DD (mouse drag and drop): this obsel type

represents a movement of the mouse pointer started

when pressing a button, and ended when the button is

released. It has the same attributes as both M-MS and

M-BPR.

4.3 Behavior Tracing Module

The result of the behavior tracing module is a trans-

formed trace called the proﬁle trace that contains ac-

tion information for each of the KD and MD modali-

ties. This trace allows to describe the behavior of the

user: their way of typing on the keyboard and their

way moving the mouse pointer. The proﬁle trace then

contains these types of obsels (K-PR, K-PP, K-RR, K-

RP, M-MS, M-DD, M-BPR, M-BDD).

4.4 Signature Creation Module

A signature in our authentication system is a trans-

formed trace that contains unique features extracted

from each user action after it enough times (the rep-

etition number is set to 5 in this study). Our authen-

tication system builds a signature trace for each au-

thentication modality.

The signature trace for KD is produced by a

SPARQL transformation computing aggregated infor-

mation from the proﬁle trace, resulting in the follow-

ing obsel types:

- K-SPR: an obsel of this type is created for each

key, aggregating a set of trusted K-PR obsels on that

key. It has the following attributes: the number of

repetitions of the action, and the mean and standard

deviation of their durations (end − begin).

- K-SRR: an obsel of this type is created for each

pair of successive keys, aggregating a set of trusted

K-RR obsels on that key pair. It has the following

attributes: the number of repetitions of the action, and

the mean and standard deviation of their durations.

- K-SPP, K-SRP: these obsel types are similar to

K-SRR above, but aggregating K-PP and K-RP, re-

spectively.

As for KD, the signature trace for MD is produced

by a SPARQL transformation computing aggregated

information from the proﬁle trace, resulting in the fol-

lowing obsel types:

- M-SBPR and M-SBDC: an obsel of each of these

types is created, aggregating a set of trusted M-BPR

and M-BDC obsels, respectively. It has the following

attributes: the number of repetitions of the action, and

the mean and standard deviation of their durations.

- M-SMS and M-SDD: an obsel of each of these

types is created for each direction, grouping a set of

trusted M-MS and M-DD obsels, respectively. It has

the following attributes: the number of repetitions

of the action, and the mean and standard deviation

of their durations, traveled distance, curved length,

speed and acceleration.

4.5 Identity Decision Module

As in other biometric systems, we need to determine

the distance between the signature trace and the new

input (each action in the proﬁle trace in our system).

We use in our system a scaled Manhattan distance.

For KD obsels (and click-related MD obsels), we

compare each action obsel to the signature obsel of

the corresponding type, and related to the same pair

of keys (or same button). The action obsel has a

duration (end − begin), and the signature obsel con-

tains the mean m and standard deviation sd of the time

in genuine actions. The distance of the action to the

user’s signature is therefore deﬁned as:

D =

|m − duration|

(1)

CSEDU 2023 - 15th International Conference on Computer Supported Education

158

For move-related MD obsels, action obsels contain a

number of attributes value

(acceleration, speed, trav-

eled distance), and signature obsels contain the mean

and standard deviation sd

for each of those at-

tributes. The distance between them is therefore de-

ﬁned as:

D =

∑

i=1

− value

(2)

Once the system has determined the distance D be-

tween the current action and the signature, then this

value must be used to update a trust value, in a way

that is freely inspired by the the trust model used

in (Mondal and Bours, 2017). The penalty and reward

function used to calculate the trust is the following:

Trust =











0, initially

Trust + D

threshold

− D if D ≤ D

noise

Trust if D > D

noise

(3)

The conﬁdence value starts at zero (no opinion

about the authenticity of the user). Then it will in-

crease (positive opinion) or decrease (negative opin-

ion) based on the distance of each action. More

precisely, a small distance (smaller than a threshold

threshold

) will reward the user by increasing the trust,

while a higher distance will penalize them, decreas-

ing the trust. Very high distances (higher than D

noise

)

are considered as irrelevant outliers, and therefore do

not impact the trust.

5 EXPERIMENTAL RESULT

In this section we describe the results of an experi-

ment we have conducted to assess the performances

of our system. The experiment was conducted with

23 ofﬁce colleagues. The participants were asked

to play a Web-based puzzle game, requiring them to

drag and drop images across a page, and to type a

given text. This application can collect a primary m-

trace complying with the trace models described in

Sections 4.1. The experiment was divided into two

phases. In the enrollment phase, the collected data

was used to build the user’s signature trace. In the au-

thentication phase, the users were asked to replay the

same game and the collected data was used to calcu-

late the trust value for each action. Then, to simulate

impostor behaviors, we re-used each user’s second

trace with each other user’s signature. This provided

us with 23 cases of genuine user, and 23 × 22 = 506

cases of impostor.

The evolution of trust for typical genuine user is

a quick increase of value during the ﬁrst action, after

Table 1: Inﬂuence of D

threshold

on FAR and FRR pour.

threshold

1 1.2 1.5

FAR 0% 0% 4.34%

FRR 100% 49.4% 0%

which the trust stays well above zero. On the other

hand, for most simulated impostors, the trust continu-

ously decreases, therefore remaining below zero.

We consider that a user is genuine if their ﬁnal

trust (after all actions) is positive, and that they are an

impostor if their ﬁnal trust is negative.

To evaluate our algorithm, we start by empirically

determining D

noise

and D

threshold

To determine the value of D

noise

, we studied the

distribution for each user of the distances of all ac-

tions to their respective signature. We noticed a sig-

niﬁcant similarity in the distributions, with values

varying between 0 and 54. We noticed then the value

17 represents the 90th percentile of our whole dataset.

We therefore decided to set D

noise

= 17.

To determine the value of D

threshold

, we computed

the trust of all genuine users and impostors with three

different D

threshold

(1, 1.2, 1.5), in order to compute

the FAR and FRR. The results are given in Table 1.

Our priority being to avoid rejecting genuine users

(low FRR), we focus on D

threshold

= 1.5. However, we

also used Table 1 to compute the EER of our method,

as some related works only provide the EER. The

ERR value of our authentication method is 4.016%.

With D

threshold

= 1.5, our system correctly rec-

ognized all 23 genuine users, giving a False Reject

Rate (FRR) of 0%. It wrongly considered as genuine

22 impostors out of 506, giving a False Acceptance

Rate (FAR) of 4.34% and a Equal Error Rate (ERR)

of 4.016%. These results are among the best results

comparing with other works combining KD and MD,

as can be seen in the table 2. We did not compute the

ANIA and ANGA indicators (described in Section 2)

because they do not apply to our context where pre-

sumed impostors are never blocked (as explained in

the previous section).

6 CONCLUSION AND

PERSPECTIVES

In this paper, we have presented a continuous behav-

ioral authentication system based on KD and MD. An

experiment conducted on 23 users showed that the

performances of our system are comparable to sim-

ilar works from the literature. We have answered

the research questions stated in our introduction by

demonstrating that: the keyboard and mouse events

collected by a Web browser are sufﬁcient to authen-

Trace-Based Authentication Biometric for On-Line Education

159

Table 2: Performances of authentication system mixing KD

and MD (N is the number of participants).

FAR (%)

FRR (%)

ERR (%)

(Ahmed and Traore, 2005) 0.65 1.31 22

(Pusara, 2007) 14.47 1.78 61

(Bailey et al., 2014) 2.24 2.10 31

(Pleva et al., 2016) 4.5 50

(Morales and Fierrez, 2015) 6.07 64

(Jagadamba et al., 2020)

Our approach 4.34 0.00 4.16 23

ticate users with reasonable performances (compared

to similar related works); and that the m-trace meta-

model (Mille et al., 2013) can be used to implement a

continuous behavioral authentication system.

This opens a number of interesting perspectives

for future works. First, the architecture of our sys-

tem is naturally extensible to other behavioral data,

thanks to the genericity of the m-trace meta-model.

In the domain of e-learning, speciﬁcations such as

SCORM (Bohl et al., 2002) and xAPI (ADL, 2013)

provide standard ways for learning activities to ex-

pose traces of the user’s activity. We are currently

considering using these traces as a source of high-

level behavioral data which could complement the

lower-level KD and MD data in the authentication

process. This is all the more important that KD and

MD data are probably very sensitive

to hardware

changes (such as people switching from an external

mouse to a touchpad), while higher-level behaviors

may be more robust.

Second, even without considering hardware

changes, we expect that the KD and MD of a given

user will evolve over time (as the user gets used to

a given keyboard, or simply improves their typing

skills, for example). In order to improve our sys-

tem into a truly dynamic authentication system, we

need to update the user’s signature with the most re-

cent trusted proﬁle traces. In the future, we will study

the design of such update mechanisms. The challenge

is, of course, to prevent an impostor’s proﬁle trace to

pollute the updated signature.

Finally, and related to the previous point, we

would like to reﬁne the decision criteria used to dis-

criminate genuine users from impostors. Although

the current approach (using the sign of the ﬁnal trust)

gives good results, observing in more detail how the

trust evolves over time raises interesting questions.

For example, Figure 1 represents the evolution of trust

To the best of our knowledge, there has been no work

in the literature studying this sensitivity. Some data in our

own experiment seem nonetheless to conﬁrm this intuition.

Figure 1: Evolution of trust for a genuine user against the

number of actions.

for a genuine user, which was eventually correctly

recognized as such. We can see that, should the ses-

sion have stopped earlier, this user may have been

wrongly considered an impostor. We are planning to

study other indicators, taking into account the whole

sequence of trust values rather than just the last one.

REFERENCES

ADL (2013). Experience API v1.0.3. Technical report,

Advance Distributed Learning (ADL) Initiative, De-

partment of Defense. https://github.com/adlnet/xAPI-

Spec.

Agulla, E. G., Rif

on, L. A., Castro, J. L. A., and Mateo,

C. G. (2008). Is my student at the other side? apply-

ing biometric web authentication to e-learning envi-

ronments. In Advanced Learning Technologies, 2008.

ICALT’08. Eighth IEEE International Conference on,

pages 551–553. IEEE.

Ahmed, A. A. and Traore, I. (2014). Biometric recognition

based on free-text keystroke dynamics. IEEE transac-

tions on cybernetics, 44(4):458–472.

Ahmed, A. A. E. and Traore, I. (2005). Anomaly intrusion

detection based on biometrics. In Information Assur-

ance Workshop, 2005. IAW’05. Proceedings from the

Sixth Annual IEEE SMC, pages 452–453. IEEE.

Ahmed, A. A. E. and Traore, I. (2007). A new biometric

technology based on mouse dynamics. IEEE Trans-

actions on dependable and secure computing, 4(3).

Ara

ujo, L., HR Sucupira, L., Liz

arraga, M., Ling, L., and

Yabu-uti, J. (2004). User authentication through typ-

ing biometrics features. Biometric Authentication,

pages 101–103.

Asha, S. and Chellappan, C. (2008). Authentication of e-

learners using multimodal biometric technology. In

2008 International Symposium on Biometrics and Se-

curity Technologies, pages 1–6. IEEE.

Bailey, K. O., Okolica, J. S., and Peterson, G. L. (2014).

User identiﬁcation and authentication using multi-

modal behavioral biometrics. Computers & Security,

43:77–89.

Belashenkova, N. N., Cherepovskaya, E. N., Lyamin, A. V.,

and Skshidlevsky, A. A. (2015). Protection meth-

ods of assessment procedures used in e-learning. In

CSEDU 2023 - 15th International Conference on Computer Supported Education

160

Emerging eLearning Technologies and Applications

(ICETA), 2015 13th International Conference on,

pages 1–6. IEEE.

Bergadano, F., Gunetti, D., and Picardi, C. (2002). User au-

thentication through keystroke dynamics. ACM Trans-

actions on Information and System Security (TISSEC),

5(4):367–397.

Bohl, O., Scheuhase, J., Sengler, R., and Winand, U. (2002).

The sharable content object reference model (scorm)-

a critical review. In Computers in education, 2002.

proceedings. international conference on, pages 950–

951. IEEE.

Bours, P. (2012). Continuous keystroke dynamics: A dif-

ferent perspective towards biometric evaluation. In-

formation Security Technical Report, 17(1):36–43.

Bours, P. and Mondal, S. (2015). Continuous authentication

with keystroke dynamics. Norwegian Information Se-

curity Laboratory NISlab, pages 41–58.

Cordier, A., Derbel, F., and Mille, A. (2015). Observing a

web based learning activity: a knowledge oriented ap-

proach. Research Report tweak am fd ac 01, LIRIS

UMR CNRS 5205.

Davoudi, H. and Kabir, E. (2010). Modiﬁcation of the rel-

ative distance for free text keystroke authentication.

In Telecommunications (IST), 2010 5th International

Symposium on, pages 547–551. IEEE.

Fayyoumi, A. and Zarrad, A. (2014). Novel solution based

on face recognition to address identity theft and cheat-

ing in online examination systems. Advances in Inter-

net of Things, 4(02):5.

Flior, E. and Kowalski, K. (2010). Continuous biomet-

ric user authentication in online examinations. In

2010 seventh International Conference on informa-

tion technology: new generations, pages 488–492.

IEEE.

Gamboa, H. and Fred, A. (2004). A behavioral biometric

system based on human-computer interaction. In Pro-

ceedings of SPIE, volume 5404, pages 381–392.

Harris, S. and Seaborne, A. (2013). SPARQL 1.1 Query

Language. W3c Recommendation, W3C.

Hernandez-Ortega, J., Daza, R., Morales, A., Fierrez, J.,

and Ortega-Garcia, J. (2019). edbb: Biometrics

and behavior for assessing remote education. arXiv

preprint arXiv:1912.04786.

Jagadamba, G., Sheeba, R., Brinda, K., Rohini, K., and

Pratik, S. (2020). Adaptive e-learning authentication

and monitoring. In 2020 2nd International Confer-

ence on Innovative Mechanisms for Industry Applica-

tions (ICIMIA), pages 277–283. IEEE.

Kang, P. and Cho, S. (2015). Keystroke dynamics-based

user authentication using long and free text strings

from various input devices. Information Sciences,

308(Supplement C):72 – 93.

Kolakowska, A. (2011). User authentication based on

keystroke dynamics analysis. Computer Recognition

Systems 4, pages 667–675.

Maas, A., Heather, C., Do, C. T., Brandman, R., Koller, D.,

and Ng, A. (2014). Offering veriﬁed credentials in

massive open online courses. Ubiquity, 2014(May):2.

Matyas, V. and Riha, Z. (2003). Toward reliable user au-

thentication through biometrics. IEEE Security & Pri-

vacy, 99(3):45–49.

Mille, A., Champin, P.-A., Cordier, A., Georgeon, O., and

Lefevre, M. (2013). Trace-Based Reasoning - Model-

ing interaction traces for reasoning on experiences. In

McCarthy, P., editor, The 26th International FLAIRS

Conference, pages 1–15, United States.

Mondal, S. and Bours, P. (2013). Continuous authentication

using mouse dynamics. In Biometrics Special Inter-

est Group (BIOSIG), 2013 International Conference

of the, pages 1–12. IEEE.

Mondal, S. and Bours, P. (2017). A study on continuous

authentication using a combination of keystroke and

mouse biometrics. Neurocomputing, 230:1–22.

Morales, A. and Fierrez, J. (2015). Keystroke biometrics

for student authentication: A case study. In Proceed-

ings of the 2015 ACM Conference on Innovation and

Technology in Computer Science Education, ITiCSE

’15, pages 337–337, New York, NY, USA. ACM.

O’Gorman, L. (2003). Comparing passwords, tokens, and

biometrics for user authentication. Proceedings of the

IEEE, 91(12):2021–2040.

Pleva, M., Bours, P., Hladek, D., and Juhar, J. (2016).

Using current biometrics technologies for authentica-

tion in e-learning assessment. In Emerging eLearning

Technologies and Applications (ICETA), 2016 Inter-

national Conference on, pages 269–274. IEEE.

Pusara, M. (2007). An examination of user behavior for user

re-authentication. PhD thesis, Purdue University.

Rabuzin, K., Baca, M., and Sajko, M. (2006). E-learning:

Biometrics as a security factor. In 2006 International

Multi-Conference on Computing in the Global Infor-

mation Technology-(ICCGI’06), pages 64–64. IEEE.

Ramu, T. and Arivoli, T. (2013). A framework of secure

biometric based online exam authentication: An alter-

native to traditional exam. Int J Sci Eng Res, 4(11):52–

60.

Ross, A. and Jain, A. (2003). Information fusion in biomet-

rics. Pattern recognition letters, 24(13):2115–2125.

Shen, C., Cai, Z., Guan, X., Du, Y., and Maxion, R. A.

(2013). User authentication through mouse dynam-

ics. IEEE Transactions on Information Forensics and

Security, 8(1):16–30.

Shepherd, S. (1995). Continuous authentication by analy-

sis of keyboard typing characteristics. In European

Convention on Security and Detection, 1995., pages

111–114. IET.

Traor

e, I., Nakkabi, Y., Saad, S., Sayed, B., Ardigo, J. D.,

and de Faria Quinan, P. M. (2017). Ensuring online

exam integrity through continuous biometric authen-

tication. In Information Security Practices, pages 73–

81. Springer.

Zhong, Y., Deng, Y., and Jain, A. K. (2012). Keystroke

dynamics for user authentication. In Computer Vision

and Pattern Recognition Workshops (CVPRW), 2012

IEEE Computer Society Conference on, pages 117–

123. IEEE.

Trace-Based Authentication Biometric for On-Line Education

161
