An Empirical Study on the Relationship Between the Co-Occurrence of

Design Smell and Refactoring Activities

Lerina Aversano

1 a

, Mario Luca Bernardi

1 b

, Marta Cimitile

2 c

Martina Iammarino

1 d

and Debora Montano

3 e

University of Sannio, Department of Engineering, Benevento, Italy

Unitelma Sapienza University, Rome, Italy

Universitas Mercatorum, Rome, Italy

Keywords:

Software Evolution, Software Quality, Refactoring, Design Smells, Statistical Analysis, Java Software.

Abstract:

Due to the continuous evolution of software systems, their architecture is subject to damage and the formation

of numerous design issues. This empirical study focuses on the co-occurrence of design smells in software

systems and refactoring activities. To this end, a detailed analysis is carried out of the data relating to the

presence of Design Smells, the use of refactoring, and the consequences of such use. Speciﬁcally, the evolution

of 17 different types of design odors in ﬁve open-source Java software projects has been examined. Overall,

the results indicate that the application of refactoring is not used by developers on design smells. This work

also offers new and interesting insights for future research methods in this ﬁeld.

1 INTRODUCTION

Delivering software changes within a very short time

frame exposes their architecture to deterioration and

often leads to design ﬂaws, which is a hotly debated

topic in software engineering. Several research papers

address design challenges and their inﬂuence on the

evolution of the software system. These studies un-

derline how these problems increase the development

costs of software systems over time until the software

system itself becomes economically unsustainable.

Design smells are intrinsically linked to the evo-

lution of the system as they relate to difﬁculties en-

countered during the design phase or the introduction

of new features within the system. Furthermore, de-

sign smells are often produced as a result of inefﬁcient

design and architecture decisions that affect internal

system attributes such as maintainability, extensibil-

ity, testability, understandability, and reusability (Le

and Medvidovic, 2016). Failure to manage design

smells could result in technical issues that can also

https://orcid.org/0000-0003-2436-6835

https://orcid.org/0000-0002-3223-7032

https://orcid.org/0000-0003-2403-8313

https://orcid.org/0000-0001-8025-733X

https://orcid.org/0000-0002-5598-0822

increase maintenance efforts and not just costs.

This empirical study examines the components of

the source code in over 7,000 commits belonging to

the evolutionary history of ﬁve open-source software

systems. Speciﬁcally, design smells are identiﬁed in

the source code of systems as they evolve and the

related refactoring actions. The objective of the in-

vestigation is to examine the potential inﬂuence of

refactoring on source code, focusing on 17 differ-

ent types of design smells classiﬁed into four pri-

mary categories identiﬁed in the literature: abstrac-

tion, encapsulation, modularization, and hierarchy,

(Fowler, 2002). The results show that elements of the

source code affected by design smells are more likely

to change, but developers rarely make these changes

through refactoring operations. This implies that the

absence of design smell is not related to the presence

of refactoring. Furthermore, the contribution of our

work is the new and innovative approach in the ﬁeld

of software, represented by the use of factor analysis

and in particular by Multiple Factor Analysis (MFA)

to support the results.

The paper is structured as follows: Section 2 re-

ports the research related to our study, Section 3 ex-

plains the data extraction process, the features model,

and the objectives. The results are reported in Section

742

Aversano, L., Bernardi, M., Cimitile, M., Iammarino, M. and Montano, D.

An Empirical Study on the Relationship Between the Co-Occurrence of Design Smell and Refactoring Activities.

DOI: 10.5220/0012006600003464

In Proceedings of the 18th International Conference on Evaluation of Novel Approaches to Software Engineering (ENASE 2023), pages 742-749

ISBN: 978-989-758-647-7; ISSN: 2184-4895

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

4 , while Section 5 lists the threats that could affect

them. Finally, Section 6 reports the most important

conclusions and suggestions for future work.

2 RELATED WORK

According to Fowler, refactoring is a discipline used

to redesign an existing body of code, updating its in-

ternal structure without altering its external (Fowler,

2018) behavior. Hence, the goal of this strategy is to

improve defects in the source code by modifying only

the lines of code and not the ﬁnal product. A col-

lection of hundreds of code improvement ideas was

also created, the goal of which is to help program-

mers use refactoring to eliminate code smells. In

this regard, the impact of refactoring on the elimina-

tion of code smells and the changes in quality met-

rics following its adoption has been the subject of in-

creasing research in recent years (Cedrim et al., 2016;

Chavez et al., 2017; Mkaouer et al., 2017). The ma-

jority of programmers, unfortunately, have a knowl-

edge of smells is purely theoretical. This is also be-

cause most defects do not occur as speciﬁed by the

theory, so developers can only detect them when the

smell occurs exactly as stated in its description. Fer-

nandes et al.found that refactoring is only used for

source code with at least one critical (Fernandes et al.,

2020) attribute. Furthermore, it has been shown that

the amount of smells increases if a change is intro-

duced in the source code and if the refactoring is ap-

plied (Aversano et al., 2020b; Aversano et al., 2020a).

Bibiano et al.show that batch refactoring techniques

in 51% of the situations introduce new smells and

in 38% of the occurrences it does not remove smells

from the code (Bibiano et al., 2019). Further research

investigated the usefulness of refactoring techniques

to reduce the severity of design smells, although even

in these circumstances this strategy proved ineffective

(Saika et al., 2016; Aversano et al., 2007). According

to much research, refactoring is more beneﬁcial for

improving software quality metrics than for removing

smells from source code. Among all forms of smells,

design smells in particular are typically indicative of

architectural ﬂaws in the code, and they are frequently

a sign of damaging software maintainability (Garcia

et al., 2009).

At this point in the literature, it is crucial to under-

stand the power of refactoring on design smells. So

most empirical studies show that refactoring, in gen-

eral, cannot remove smells(Sharma et al., 2020; Aver-

sano. et al., 2022).

The research proposed in this paper aims to fur-

ther investigate the relationships among refactoring

actions and design smells at a ﬁne grained level by

using factor analysis, statistical indices, and tests, a

fresh and cutting-edge method in the software re-

search.

3 APPROACH

This section outline the main phases of the conducted

empirical study, that are:

• deﬁnition of the study’s research questions;

• data extraction and data collection;

• identiﬁcation of the features to analyze.

Each phase is better explained in the following sub-

sections.

3.1 Research Questions

This study aims to investigate the co-occurrence be-

tween design smells and refactoring activities, to

understand whether smelly code is more prone to

changes due to refactoring.

Overall, the following research questions have been

identiﬁed:

: Do programmers refactor when Design

Smells occur?

This ﬁrst research question aims to understand if there

is a correlation between the instances of design smells

with the use of refactoring by the developers,studying

their presence in the commit.

: To what extent the use of refactoring

change as the types of design smells to be

managed increases?

The second research question aims to better high-

light the co-occurrence of the two phenomena, we

have investigated whether the use of refactoring ac-

tivities is greater where there are more design smells

to manage.

: Is there any correlation between the

category of design smells and refactoring?

Different categories of design smells have been con-

sidered in the third research question to understand

how the are speciﬁcally related to refactoring.

3.2 Data Extraction

The data used in this research comes from ﬁve open-

source Java software projects. Table 1 shows the

names of the projects evaluated in the ﬁrst column, in

the second column the number of commits analyzed,

An Empirical Study on the Relationship Between the Co-Occurrence of Design Smell and Refactoring Activities

743

Table 1: Software Projects characteristics.

System #commit First and Last Commit Date

Atlas 1581 08/12/2014 - 05/07/2019

Guice 1176 16/11/2006 - 06/06/2019

JUnit4 1406 03/12/2000 - 20/06/2019

Log4j 2042 14/12/2000 - 11/02/2014

Zookeeper 1084 06/11/2007 - 17/07/2019

Total 7289 03/12/2000 - 17/07/2019

and in the last column the time interval to which they

belong. These projects have been chosen because

their repositories are publicly available on GitHub

vary in size, and cover different domains.

The data collection process involved several

stages. During the ﬁrst phase, the elements of the

source code to be analyzed have been extracted from

the commits of each system. Speciﬁcally, the ex-

tracted source code has been given as input to the

tools to detect the existence of smells and the pres-

ence of refactoring. Finally, each commit has been

examined by comparing it to the previous one to see

if the smell had been added or removed. More pre-

cisely, two different tools have been adopted: Desig-

nite

and RefactoringMiner

. The former was used

to detect smells and is able to assess the quality of

the design and thus recognize the existence of design

smells. Consequently, for the sake of completeness,

in Table 2 we provide the design smells detected by

this tool for this study, identifying the list of smells

in the ﬁrst column and the macro-categories of de-

sign smells in the second. The second tool detects

the existence of refactoring actions performed on the

source code. This

is particularly competent for rec-

ognizing 40 different types of refactoring for actions

on packages, classes, methods, features, arguments,

and attributes. Finally, the complete data-set includes

the history of all software systems described in Table

1, which consists of 7289 commits, 43009 different

modiﬁcations of the source code, and 19 features re-

lated to each type of design smell, the occurrence of

refactoring on the commit, and the speciﬁc class (the

java ﬁle) and the date of the commit.

3.3 Features Description

The following features have been analyzed to under-

stand the relationships between refactoring and de-

sign smells.

• Refactoring: a dichotomous feature that consid-

ers the value ”true” when refactoring techniques

https://github.com

https://www.designite-tools.com

https://github.com/tsantalis/refactoringMiner

At the time of writing, in version 2.1

Table 2: Type & Category of Design Smells Considered.

Type of smells Design smell Category

Imperative Abstraction

Multifaceted Abstraction

Unnecessary Abstraction

Unutilized Abstraction

ABSTRACTION

Deﬁcient Encapsulation

Unexploited Encapsulation

ENCAPSULATION

Broken Modularization

Cyclically Dependent Modularization

Insufﬁcient Modularization

Hub-Like Modularization

MODULARIZATION

Broke Hierarchy

Cyclic Hierarchy

Deep Hierarchy

Missing Hierarchy

Multipath Hierarchy

Rebellious Hierarchy

Wide Hierarchy

HIERARCHY

are employed for its reference commit, and the

value ”false” when they are not.

• Design Smells: 17 different types of design

smells have been detected. Each of these 17 char-

acteristics is named after the design smell it rep-

resents. All the design smells considered in this

paper are listed in Table 2. When a certain type

of smell is present in the commit, it is represented

with value ’1’, otherwise with value ’0’. Hence,

they are dichotomous characteristics.

• Date: the date on which the current commit was

made.

3.4 Data Analysis

In this study, different statistical techniques have been

used to analyze the various aspects of the research

questions. In particular, the following methods have

been used:

• Row proﬁles are widely used in statistical analysis

when we are interested in understanding whether

there is some conditioning relationship between

two features, that is when one of the certain char-

acter conditions occurs, the other assumes a cer-

tain behavior. There are two measures for cal-

culating this relationship: row and column pro-

ﬁles. In our study, we use row proﬁles because

the distribution is conditioned concerning a pre-

cise modality of the row variable. A row proﬁle

is obtained by relating the frequency of the con-

ditional distribution to the relative total (marginal

frequency):

• Spearman Rho non-parametric is a rank-based

correlation coefﬁcient. To evaluate whether the

determined coefﬁcient is signiﬁcant concerning

the ﬁxed alpha values, the obtained value is com-

pared with the critical values of the Rho Spear-

ENASE 2023 - 18th International Conference on Evaluation of Novel Approaches to Software Engineering

744

man table. In our case study, we have formu-

lated only one correlation hypothesis, which is

non-independence therefore our test is unidirec-

tional, for this reason, the rho value is signiﬁcant

if it exceeds the absolute value of the critical value

reported in the table for alpha / 2 = 0.025.

• Multiple Factor Analysis (MFA) is a multivari-

ate technique used to summarize and illustrate

complex data sets with naturally organized vari-

ables (quantitative and/or qualitative) (Escoﬁer

and Pag

es, 1994; Le Dien and Pag

es, 2003). It is

a combination of a Principal Component Analy-

sis (PCA) and a Multiple Correspondence Analy-

sis (MCA) (Ringn

er, 2008). During analysis, sets

of variables are analyzed simultaneously, which

requires balancing the effects of each set of vari-

ables. The number of variables in each group can

be different. Consequently, during the survey, the

variables of the same group are normalized using

the same weighting value, which can vary from

group to group. To be more precise, MFA at-

tributes to each variable of the j-th group a weight

equal to the inverse of the ﬁrst eigenvalue of the

analysis of the j group, an eigenvalue that is calcu-

lated with a PCA if the variable is quantitative or

with MCA if the variable is qualitative.Through

the eigenvalue, it is also possible to evaluate how

much an observation, a variable or an entire table

contributes to the inertia recovered by a compo-

nent to better understand the interactions between

components, observations, variables, and tables as

well as help in the interpretation of a component.

4 EMPIRICAL STUDY FINDINGS

This section reports the experimental results obtained

thanks to the use of the methodology and the model

of features previously described.

4.1 Do Programmers Refactor When

Design Smells Occur?

To examine how refactoring is used on smelly com-

mits, we looked at the commits where design smells

are found to see if there is a relationship to using

refactoring where there are smells. In particular, the

analyzes were conducted using the Row Proﬁles de-

scribed in Section 3.4. The analyzes were performed

on the total data-set, which contained instances of all

the software systems chosen and on each one sepa-

rately, to produce both an overview and a particular

vision linked to a single software system.

Table 3: Row proﬁles of commits affected by design smells

- ALL SOFTWARE.

TYPE OF DESIGN SMELL REFACTORING ACTIVITY

No Yes

Imperative Abstraction 90% 10%

Multifaced Abstraction 76% 24%

Unnecessary Abstraction 97% 3%

Unutilized Abstraction 79% 21%

Deﬁcient Encapsulation 72% 28%

Unexploited Encapsulation 70% 30%

Broken Modularization 78% 22%

Cyclic Dependent Modularization 68% 32%

Insufﬁcient Modularization 70% 30%

Hub like Modularizaton 61% 39%

Broken Hierarchy 75% 25%

Cyclic Hierarchy 86% 14%

Deep Hierarchy 100% 0%

Missing Hierarchy 70% 30%

Multipath Hierarchy 69% 31%

Rebellious Hierarchy 82% 18%

Wide Hierarchy 76% 24%

Table 3 shows the type of design smell in the ﬁrst

column, the row proﬁles that describe the percentage

of commit in which refactoring was used (second col-

umn) and in which no was used (third column). Re-

sults in bold show that refactoring is not used in at

least 60 % of commits affected by design smells. In

particular, with the smell of Deep Hierarchy, refactor-

ing is never used by developers while the type of smell

on which refactoring is more used than the other types

of design smell is Hub-like Modularization where in

40 % of commits affected, refactoring activities are

used. We have also looked at the row proﬁles on the

individual software systems to verify what we found

in the overall analysis of all systems together. The re-

sults are reported in Table 4 in which the ﬁrst column

shows the types of design smells, from the second on-

wards the columns are organized in pairs, and each

pair of columns shows the row proﬁles that character-

ize the proportion of commits where refactoring has

been applied (the ﬁrst column of the two) and where it

has not been applied (the second column of the two).

Table 4 shows that also on the single system, in

general, refactoring is not so practiced. In each soft-

ware project, there are some design smells where

the refactoring activities on dirty commits are higher

than in the general analysis. This condition is nor-

mal because the single software system has its pecu-

liar characteristics. In particular, the most refactored

design smells for Atlas are Multifaced Abstraction

(59%), Cyclic Hierarchy (64%), and broken Modular-

ization (79%); for Guice are Insufﬁcient Modulariza-

tion (62%), Broken Hierarchy (69%), Deﬁcient En-

capsulation (84%) and Broken Modularization (92%);

and for Log4j are Missing Hierarchy (56%) and Wide

Hierarchy (78%). JUnit4 and Zookeeper are the only

two software systems where the refactoring activities

An Empirical Study on the Relationship Between the Co-Occurrence of Design Smell and Refactoring Activities

745

are less used concerning the others systems.

All the analyzes conducted in this Section have

been statistically examined, in particular, we used

the non-parametric Spearman Rho, and all the results

have a p-value minor to 0.025 so we can say that the

analyzes demonstrate independence between the rows

proﬁles and their statistical signiﬁcance.

SUMMARY: Refactoring is less practiced

on commits affected by design smells, addi-

tionally, it is never used in the case of rare

smells like Deep Hierarchy.

4.2 To What Extent the Use of

Refactoring Change as the Types of

Design Smells to Be Managed

Increases?

To understand how the use of refactoring changes

based on the number of types of smells present in the

class, we report the results of the relative analysis in

Table 5 which presents in the ﬁrst column the num-

ber of different types of design smells present into the

class, in the second column the percentage of different

types of design smells present in the classes not refac-

tored, and in the third column the percentage for the

classes where refactoring activities are used. In the

analyzed classes we have found that there are at most

4 different types of smells, in particular, 59% of them

have only one type of design smells and in 29% of the

cases 2 types of different smells. Table 5 also high-

lights that 75% of the time refactoring is not applied

regardless of the number of different types of design

smells. Only 2% of the time refactoring is used to

manage design smells and, in particular, it is mostly

used to manage classes with 1(14%) or 2(8%) types

of different design smells.

The same analyzes conducted on the individual

software systems show the same empirical evidence

there are often at most 2 types of different design

smells in each class, and the cases in which more than

2 are present are very sporadic. Also, more than half

the time, regardless of how many design smells come

up, programmers don’t resort to refactoring. The At-

las software system represents the only case in which

the presence or absence of refactoring activities has

substantially the same behavior (47% vs 53%). Fur-

thermore, in this system, it is preferred to use refactor-

ing when there are too many designs smells to man-

age, in fact when 4 different types of smells occur

refactoring is used 8% of the time, instead only 1%

of the time when 4 different types of design smell ap-

pear developers prefer not to use refactoring. These

results are shown graphically in Figure 1 which shows

on the abscissa axis the number of different types of

design smells present in the classes and their percent-

age distribution on the ordinate axis. Therefore, the

blue bars represent the classes where refactoring is not

practiced, while the orange bars represent the classes

where refactoring is recognized. The graph for the to-

tal data-set is on the top left, followed by those for At-

las, Guice, JUnit4, Log4j, and ﬁnally Zookeeper. The

proposed analyzes were statistically validated through

the non-parametric Spearman Rho, a rank-based cor-

relation coefﬁcient, and with a correlation hypothesis,

which is non-independence. Consequently, having al-

ways obtained a p-value minor to 0.025, we can con-

clude that the analyzes illustrate their independence

and statistical signiﬁcance.

SUMMARY: In most instances, refactor-

ing is chosen when the source code contains

few design smells, in particular, at most 2.

4.3 Is There Any Correlation Between

Design Smells Categories and

Refactoring?

To understand the correlation between different smell

categories and refactoring activity, the possible pres-

ence of a common structure in the design smell cate-

gories, and the speciﬁcity of each, we have used Mul-

tiple Factor Analysis (MFA). The data-set contains

17 different characteristics for design smells, divided

into 4 different smell groups: Abstraction, Encapsula-

tion, Modularization, and Hierarchy. Therefore, MFA

has been performed on the four categories of design

smells and the presence of refactoring.

The graphs in Figure 2 illustrate the coordinates of

the groups which provide information on the correla-

tion between the groups. At the top left, we report the

overall graph of the data set, while the graphs for At-

las, Guice, JUnit4, Log4j, and Zookeeper are shown

respectively below. The coordinates of each group in

the Cartesian axis give information on the correlation

between the groups. In particular, if the coordinates of

the groups are arranged along the same axis, the cor-

relation between these groups is greater than that with

the other scattered groups in the graph. The results

show that the coordinates of the points that take into

account the refactoring are the Modularization and the

Abstraction which are the closest so they show that

the refactoring activities are more correlated and con-

nected with the presence of design smells belonging

to the Modularization and Abstraction.

ENASE 2023 - 18th International Conference on Evaluation of Novel Approaches to Software Engineering

746

Table 4: Row proﬁles of commits affected by design smells for SINGLE SOFTWARE.

ATLAS GUICE JUnit4 LOG4J ZOOKEEPER

REFACTORING ACTIVITY REFACTORING ACTIVITY REFACTORING ACTIVITY REFACTORING ACTIVITY REFACTORING ACTIVITY

TYPE OF DESIGN SMELL No Yes No Yes No Yes No Yes No Yes

Imperative Abstraction 58% 42% 0% 0% 0% 0% 82% 18% 85% 15%

Multifaced Abstraction

41% 59% 55% 45% 85% 15% 82% 18% 100% 0%

Unnecessary Abstraction 100% 0% 100% 0% 98% 2% 76% 24% 100% 0%

Unutilized Abstraction 63% 37% 41% 59% 76% 24% 79% 21% 83% 17%

Deﬁcient Encapsulation 54% 46% 16% 84% 76% 24% 69% 31% 70% 30%

Unexploited Encapsulation 63% 37% 49% 51% 65% 35% 100% 0% 60% 40%

Broken Modularization 21% 79% 8% 92% 0% 0% 79% 21% 100% 0%

Cyclic Dependent Modularization 51% 49% 60% 40% 70% 30% 62% 38% 66% 34%

Insufﬁcient Modularization 46% 54% 38% 62% 70% 30% 68% 32% 68% 32%

Hub like Modularizaton 48% 52% 97% 3% 0% 0% 0% 0% 0% 0%

Broken Hierarchy 64% 36% 31% 69% 68% 32% 63% 37% 75% 25%

Cyclic Hierarchy 36% 64% 95% 5% 100% 0% 0% 0% 0% 0%

Deep Hierarchy 100% 0% 0% 0% 0% 0% 0% 0% 0% 0%

Missing Hierarchy 58% 42% 0% 0% 86% 14% 44% 56% 66% 34%

Multipath Hierarchy 54% 46% 93% 7% 0% 0% 0% 0% 0% 0%

Rebellious Hierarchy 100% 0% 0% 0% 89% 11% 54% 46% 69% 31%

Wide Hierarchy 93% 7% 0% 0% 85% 0% 22% 78% 65% 35%

Figure 1: Distribution of Design Smells in the classes and Refactoring Activities - ALL DATA & SINGLE SYSTEM.

Table 5: Number of smells in the classes and refactoring

activities - ALL SYSTEM.

REFACTORING ACTIVITY Total

#smell in a class No Yes

1 45% 14% 59%

2 21% 8% 29%

3 6% 3% 9%

4 2% 1% 3%

5 or more 0% 0% 0%

SUMMARY: The categories of smells re-

lated to Modularization and Abstraction

are those whose design smells are most

closely associated with refactoring opera-

tions.

An Empirical Study on the Relationship Between the Co-Occurrence of Design Smell and Refactoring Activities

747

Figure 2: Multiple Factor Analysis (MFA) - ALL DATA & SINGLE SYSTEM.

5 THREATS TO VALIDITY

This section discusses the threats to the validity of the

study described.

Threats to validity construction concern the rela-

tionship between theory and observation, so we can

consider the potential inaccuracy of smell detection

systems and refactoring activities. To reduce the

threat, we used Designite, which has accuracy 96%

and recall 99% (Tushar Sharma and Spinellis, 2020),

and Refactoring Miner which has high accuracy 98%

and recall 87% (Tsantalis et al., 2018).

Threats to internal validity relate to aspects of our

study that could affect the results. We cannot assume

that the cause-and-effect link between Design Smells

refactoring and removal activities are always the same

as determined by our research in general. To mitigate

this vulnerability, we evaluated refactoring on a large

number of commits (7289) of ﬁve pieces of software

rather than just one. The potential lack of general-

izability of the data produced poses a danger to the

validity of the conclusions. To reduce this threat, we

have considered ﬁve different systems. We performed

analyzes on each system separately, taking into ac-

count its unique characteristics, as well as the combi-

nation of these, to obtain results for both the speciﬁc

subset and the complete enumeration. This point is

also an external threat, in fact, we only looked at ﬁve

software systems because this is the ﬁrst phase of our

research. The results can be conﬁrmed or refuted dur-

ing future research phases, taking into account multi-

ple commits and multiple software systems.

6 CONCLUSION AND FUTURE

WORK

This study suggests a different method for examining

how design smells and refactoring operations inter-

act. We have produced useful results for the scientiﬁc

community using simple analyzes such as statistical

techniques and factor analysis. The analyzes show

that refactoring techniques are still underused in the

ﬁeld of software development. Furthermore, tests on

single system software show that the frequency of us-

ing refactoring in smelly commits is signiﬁcantly re-

lated to the nature of the design smell.

Refactoring is most frequently associated with the

existence of design smells from the categories of

Modularization and Abstraction. This is an interest-

ing consideration that deserves to be explored across

multiple systems in targeted research.

Future research will also focus on predicting anal-

ysis that can anticipate refactoring behavior in terms

ENASE 2023 - 18th International Conference on Evaluation of Novel Approaches to Software Engineering

748

of adding or eliminating design smells. To conﬁrm

the methodologies and results obtained in this study,

it would be interesting to investigate how the use of

refactoring varies according to the different program-

ming languages of software projects.

REFERENCES

Aversano., L., Bernardi., M., Cimitile., M., Iammarino., M.,

and Montano., D. (2022). Is there any correlation be-

tween refactoring and design smell occurrence? In

Proceedings of the 17th International Conference on

Software Technologies - ICSOFT, pages 129–136. IN-

STICC, SciTePress.

Aversano, L., Bernardi, M. L., Cimitile, M., Iammarino, M.,

and Romanyuk, K. (2020a). Investigating on the rela-

tionships between design smells removals and refac-

torings. page 212 – 219.

Aversano, L., Carpenito, U., and Iammarino, M. (2020b).

An empirical study on the evolution of design smells.

Information (Switzerland), 11(11). Cited by: 4; All

Open Access, Gold Open Access, Green Open Ac-

cess.

Aversano, L., Cerulo, L., and Del Grosso, C. (2007). Learn-

ing from bug-introducing changes to prevent fault

prone code. page 19 – 26.

Bibiano, A. C., Fernandes, E., Oliveira, D., Garcia, A.,

Kalinowski, M., Fonseca, B., Oliveira, R., Oliveira,

A., and Cedrim, D. (2019). A quantitative study on

characteristics and effect of batch refactoring on code

smells. In 2019 ACM/IEEE International Symposium

on Empirical Software Engineering and Measurement

(ESEM), pages 1–11. IEEE.

Cedrim, D., Sousa, L., Garcia, A., and Gheyi, R. (2016).

Does refactoring improve software structural quality?

a longitudinal study of 25 projects. In Proceedings of

the 30th Brazilian Symposium on Software Engineer-

ing, pages 73–82.

Chavez, A., Ferreira, I., Fernandes, E., Cedrim, D., and Gar-

cia, A. (2017). How does refactoring affect internal

quality attributes? a multi-project study. In Proceed-

ings of the 31st Brazilian symposium on software en-

gineering, pages 74–83.

Escoﬁer, B. and Pag

es, J. (1994). Multiple factor analysis

(afmult package). Computational Statistics & Data

Analysis, 18(1):121–140.

Fernandes, E., Ch

avez, A., Garcia, A., Ferreira, I., Cedrim,

D., Sousa, L., and Oizumi, W. (2020). Refactoring

effect on internal quality attributes: What haven’t they

told you yet? Information and Software Technology,

126:106347.

Fowler, M. (2002). Tutorials-refactoring: Improving the

design of existing code. Lecture Notes in Computer

Science, 2418:256–256.

Fowler, M. (2018). Refactoring: improving the design of

existing code. Addison-Wesley Professional.

Garcia, J., Popescu, D., Edwards, G., and Medvidovic,

N. (2009). Toward a catalogue of architectural bad

smells. In International conference on the quality of

software architectures, pages 146–162. Springer.

Le, D. and Medvidovic, N. (2016). Architectural-based

speculative analysis to predict bugs in a software sys-

tem. In Proceedings of the 38th International Confer-

ence on Software Engineering Companion, ICSE ’16,

page 807–810, New York, NY, USA. Association for

Computing Machinery.

Le Dien, S. and Pag

es, J. (2003). Hierarchical multiple fac-

tor analysis: application to the comparison of sensory

proﬁles. Food Quality and Preference, 14(5):397–

403. The Sixth Sense - 6th Sensometrics Meeting.

Mkaouer, M. W., Kessentini, M., Cinn

eide, M.

O., Hayashi,

S., and Deb, K. (2017). A robust multi-objective ap-

proach to balance severity and importance of refactor-

ing opportunities. Empirical Software Engineering,

22(2):894–927.

Ringn

er, M. (2008). What is principal component analysis?

Nature biotechnology, 26(3):303–304.

Saika, T., Choi, E., Yoshida, N., Haruna, S., and In-

oue, K. (2016). Do developers focus on severe code

smells? In 2016 IEEE 23rd International Conference

on Software Analysis, Evolution, and Reengineering

(SANER), volume 4, pages 1–3. IEEE.

Sharma, T., Singh, P., and Spinellis, D. (2020). An empir-

ical investigation on the relationship between design

and architecture smells. Empirical Software Engineer-

ing, 25(5):4020–4068.

Tsantalis, N., Mansouri, M., Eshkevari, L., Mazinanian, D.,

and Dig, D. (2018). Accurate and efﬁcient refactor-

ing detection in commit history. In 2018 IEEE/ACM

40th International Conference on Software Engineer-

ing (ICSE), pages 483–494. IEEE.

Tushar Sharma, P. S. and Spinellis, D. (2020). An empirical

investigation on the relationship between design and

architecture smells. Empirical Software Engineering,

25:4020–4068.

An Empirical Study on the Relationship Between the Co-Occurrence of Design Smell and Refactoring Activities

749
