Towards a Low-Code Tool for Developing Data Quality Rules

Timon Sebastian Klann

, Marcel Altendeitering

2 a

and Falk Howar

1 b

TU Dortmund University, Dortmund, Germany

Fraunhofer ISST, Dortmund, Germany

Keywords:

Data Quality Rules, Data Validation, Data Management, Domain Speciﬁc Language, Visual Programming.

Abstract:

High-quality data sets are vital for organizations as they promote business innovation and the creation of data-

driven products and services. Data quality rules are a common approach to assess and enforce compliance

with business domain knowledge and ensure the correctness of data sets. These data sets are usually subject

to numerous data quality rules to allow for varying requirements and represent the needs of different stake-

holders. However, established data quality tools have a rather technical user interface and lack support for

inexperienced users, thus hindering them from specifying their data quality requirements. In this study, we

present a tool for the user-friendly and collaborative development of data quality rules. Conceptually, our tool

realizes a domain-speciﬁc language, which enables the graphical creation of rules using common data quality

constraints. For implementation, we relied on CINCO, a tool for creating domain-speciﬁc visual modeling

solutions, and Great Expectations, an open-source data validation framework. The evaluation of our prototype

was two-fold, comprising expert interviews and a focus group discussion. Overall, our solution was well-

received and can contribute to lowering the accessibility of data quality tools.

1 INTRODUCTION

A high level of Data Quality (DQ) is a critical suc-

cess factor for organizations but is often impaired

by missing, erroneous, or duplicate values (Kandel

et al., 2012). These DQ issues are usually difﬁcult to

ﬁnd and resolve and can interrupt business operations

(Redman, 2020; Amadori et al., 2020). Consequently,

poor DQ is considered one of the major tasks in mod-

ern data management (Gr

oger, 2021) and is responsi-

ble for ”$15 million per year in losses” (p.1) (Moore,

2018) for an average organization.

The speciﬁcation of DQ rules is a typical approach

to ensure accurate and high-quality data sets. These

rules deﬁne general or domain-speciﬁc data knowl-

edge and can be used for validating the compliance of

data (Altendeitering and Tomczyk, 2022). However,

deﬁning these rules is complicated by the ’ﬁtness for

use’ principle of DQ (Wang and Strong, 1996). Fit-

ness for use means that different stakeholders pose

different requirements on data and have varying qual-

ity deﬁnitions based on their tasks. As a result, a data

set is usually subject to numerous DQ rules (Wang

and He, 2019; Tebernum. et al., 2021). For example,

https://orcid.org/0000-0003-1827-5312

https://orcid.org/0000-0002-9524-4459

when analyzing a sales data set, a data scientist might

want the data to be accurate, while a business analyst

is more focused on the timeliness of data.

In the past, deﬁning DQ rules was a technical

task conducted by a centralized group of technically

skilled employees. However, this approach to DQ

does not scale in light of ubiquitous and big data,

leading to cumbersome and time-consuming DQ pro-

cesses (Altendeitering and Guggenberger, 2021). In

response to this lack of scalability, DQ is becom-

ing increasingly decentralized and conducted ”at the

source” (p.1) (Redman, 2020). It evolves from a cen-

tralized task to a cooperative effort involving stake-

holders across the organization (Gr

oger, 2021; De-

hghani, 2020). DQ tools must embrace these changes

and allow various stakeholders to specify their DQ

rules and validate data to their needs. Established DQ

tools often fail to address this need as they are limited

in supporting inexperienced users and lack collab-

orative functionalities (Altendeitering and Tomczyk,

2022).

We aim to address the need for accessible and

user-friendly solutions by developing a low-code ap-

plication that supports the design and development of

DQ rules. The following research question guided our

study:

Klann, T., Altendeitering, M. and Howar, F.

Towards a Low-Code Tool for Developing Data Quality Rules.

DOI: 10.5220/0012050400003541

In Proceedings of the 12th International Conference on Data Science, Technology and Applications (DATA 2023), pages 22-29

ISBN: 978-989-758-664-4; ISSN: 2184-285X

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

Research Question: What does a DQ tool for the

user-friendly and collaborative speciﬁcation of DQ

rules look like?

To answer the proposed research question, we de-

veloped and prototypically implemented ColDaQ, a

DQ tool for the graphical and collaborative speciﬁ-

cation of DQ rules. ColDaQ offers a data-ﬂow pro-

gramming environment for constructing DQ rules in

a user-friendly way. The low-code approach is well-

suited for supporting users from various backgrounds

to realize their DQ requirements (Altendeitering and

Schimmler, 2022). In this sense, our tool helps data

domain experts become self-reliant and empowers

them to integrate and operate DQ rules themselves.

As a result, we contribute to overcoming the typical

divide of DQ tasks between technical (e.g., data engi-

neers) and non-technical (e.g., domain experts) users

that complicates DQ management (Altendeitering and

Guggenberger, 2021).

For the prototypical implementation of ColDaQ,

we used Great Expectations (The Great Expectations

Team, 2020) and CINCO (Naujokat et al., 2018) as

technological bases. The qualitative evaluation of our

application was two-fold. In the ﬁrst round, we inter-

viewed three experts from the DQ and user experience

domains to gain in-depth feedback. Subsequently, we

completed a second round of evaluation using a fo-

cus group discussion with ten participants working in

data-intensive jobs. Overall, we found that our tool

can ease the manual speciﬁcation of DQ rules and in-

form the design of future DQ tools.

The remainder of this article is structured as fol-

lows. First, we describe the theoretical background

of our study regarding data management and quality,

DQ tools, and domain-speciﬁc languages in section

2. In section 3, we outline the conceptual approach of

our tool and describe its prototypical implementation.

We present and discuss the qualitative evaluation re-

sults for our tool in section 4. Finally, in section 5,

we describe the contributions of our study, highlight

limitations, and outline paths for future work.

2 BACKGROUND

2.1 Data Management & Data Quality

”You can’t do anything important in your company

without high-quality data” (p.1) (Redman, 2020).

(Redman, 2020) states that DQ forms an important

organizational success factor and is widely recog-

nized as an essential building block for organizational

agility and a driver of business innovation. For in-

stance, a high level of DQ has a positive inﬂuence on

the functioning of data-intensive applications (e.g., ar-

tiﬁcial intelligence) (Tebernum. et al., 2021; Gr

oger,

2021), allows seamless business processes (Amadori

et al., 2020), and builds trust among partners in a data

ecosystem (Guggenberger et al., 2020).

To be considered high-quality, data needs to ful-

ﬁll a ’ﬁtness for use’, which is context-dependent

and deﬁned by the data consumer (Wang and Strong,

1996). As a context-dependent and multi-dimensional

concept, a sufﬁcient level of DQ can be difﬁcult to

achieve. As a result, it has long been incorporated into

data management practices but is still considered a

signiﬁcant issue (Wang, 1998; Gr

oger, 2021). Several

frameworks, such as the Total Data Quality Manage-

ment (TDQM) framework, emerged to support and

ease DQ management. The TDQM framework out-

lines how to deﬁne, analyze, measure, and improve

DQ. For example, by specifying DQ rules and vali-

dating data against these rules (Altendeitering, 2021).

However, manual DQ management is complex, cum-

bersome, and error-prone and is often supported by

DQ tools (Altendeitering and Tomczyk, 2022; Al-

tendeitering and Guggenberger, 2021).

2.2 Data Quality Tools

A plurality of tools emerged from science and prac-

tice to support DQ management. We can distinguish

these tools in data preparation tools for correcting er-

roneous data, data measuring and monitoring tools for

data validation, and general-purpose tools, which of-

fer the most comprehensive set of DQ functionalities

(Ehrlinger and W

oß, 2022; Altendeitering and Tom-

czyk, 2022). Over time, DQ evolved from an algo-

rithmic, IT-centric task to a joint effort involving mul-

tiple stakeholders from across the organization (Al-

tendeitering and Tomczyk, 2022). These develop-

ments raised new requirements for modern DQ tools,

which must offer collaborative functionalities and ac-

cessible user interfaces (Altendeitering and Guggen-

berger, 2021; Swami et al., 2020). However, estab-

lished tools often cannot fulﬁll these requirements and

lack support for inexperienced users and collabora-

tive approaches to DQ (Altendeitering and Tomczyk,

2022).

In this study, we aim to address this lack of estab-

lished tools and develop a collaborative, user-friendly

solution for deﬁning DQ rules and validating data.

For this purpose, we extend the DQ tool Great Expec-

tations (GE) (The Great Expectations Team, 2020).

We decided to use GE as it is open-source, offers ex-

tensive documentation, and is well-established in the

ﬁeld of DQ. It also has an active community and was

Towards a Low-Code Tool for Developing Data Quality Rules

used by similar studies (e.g., (Swami et al., 2020)).

GE is a Python-based library for validating and

proﬁling data. By specifying ’Expectations’, users

can formulate their requirements on data in a declar-

ative language (The Great Expectations Team, 2020).

Along with metadata, several Expectations are com-

bined into a list inside an ’Expectation Suite’ in JSON

format. Besides deriving expectations manually or

automatically through proﬁling, the critical features

of GE are data validation and documentation. The

latter also offers a graphical and comprehensive pre-

sentation of the data and the validation results. GE

allows to validate Expectations individually or com-

bined in an Expectation Suite.

2.3 Domain Speciﬁc Languages

Domain-Speciﬁc Languages (DSLs) are used to de-

scribe the context of a speciﬁc problem domain efﬁ-

ciently with gains in productivity (Kosar et al., 2008).

In contrast to general-purpose languages, a textual

or graphical DSL is limited to the bounded con-

text of its domain and does not require general pro-

gramming knowledge. This means a DSL is more

accessible to domain experts and offers expressive

power through abstraction without explaining every-

thing in detail (Fall and Fall, 2001; Kosar et al., 2008;

Van Deursen and Klint, 2002). Potential advantages

of DSLs are high portability, efﬁciency, and reliabil-

ity (Deursen and Klint, 1998; Van Deursen and Klint,

2002; Van Deursen et al., 2000).

The CINCO meta tooling suite is a simplicity-

oriented DSL tool for developing domain-speciﬁc

graphical modeling tools (Naujokat et al., 2018).

Based on several frameworks, CINCO generates such

tools, also called CINCO Products (CP), from simple

high-level speciﬁcations (MGL: meta graph language,

MSL: meta styler language, and CPD: CINCO prod-

uct deﬁnition) automatically (Lybecait et al., 2018).

The key idea of CINCO is to hide the complexity of

its underlying frameworks and keep the development

of the CP as simple as possible (Naujokat, 2016).

Owing to the common meta-domain, every CP has

the same structure and basic functionality. Based on

structural speciﬁcations made in the MGL, users of

the CP can place nodes into a graphical editor (can-

vas) by drag & drop and connect them via edges.

The resulting graph will appear as speciﬁed in the

MSL (Naujokat, 2016). Users can deﬁne additional

functionality and semantic interpretations, such as

code generation or model validation, using meta plug-

ins (Naujokat et al., 2018). We decided to use CINCO

to develop our prototype as it supports creating cus-

tom domain-speciﬁc languages and reduces the de-

velopment time. It is thus well-suited for quickly

creating prototypical applications and retrieving feed-

back early on. CINCO was also used in several other

projects and CINCO Cloud, the web-based successor

of CINCO, is currently under development (Naujokat

et al., 2018).

3 PROTOTYPE

3.1 Conceptual Approach

With our prototypical DQ tool ColDaQ, we aim

to enable the user-friendly and collaborative spec-

iﬁcation and application of DQ rules. In contrast

to established solutions such as GE, users should

beneﬁt from a simple UI that is less code-centric.

ColDaQ should empower users from technical and

non-technical backgrounds to specify their individual

DQ needs without modifying codebases (Altendeit-

ering and Guggenberger, 2021; Altendeitering and

Tomczyk, 2022). We envision ColDaQ to be oper-

ated in a federated, self-serve data infrastructure as a

platform where different domains and user groups can

customize ColDaQ to their needs (Gr

oger, 2021). In

this architecture, a centralized DQ team could specify

DQ information models and offer universal DQ rules,

which domain experts can extend and customize (Al-

tendeitering and Tomczyk, 2022; Dehghani, 2020).

ColDaQ relies on CINCO and GE as its techno-

logical bases. The tool is speciﬁed as an MGL and

MSL and generated into a CP by CINCO. To enable

the validation of a given data set against user-deﬁned

DQ rules, ColDaQ offers a code export that converts

the DQ rules into an Expectation Suite suitable for

use in GE. For our prototype, we focused on validat-

ing CSV ﬁles for simplicity. Furthermore, ColDaQ

only considers single table data sources and is limited

to DQ conditions that can be validated as true or false.

In this sense, we assume that DQ rules in ColDaQ can

be treated as logical statements about the data.

As a starting point, ColDaQ offers a small set

of typical DQ constraints that users can use to de-

scribe speciﬁc requirements on data (see Table 1).

We based the pre-deﬁned set of DQ constraints on

two studies reviewing DQ tools and their function-

alities (Ehrlinger and W

oß, 2022; Altendeitering and

Tomczyk, 2022). Users can create custom DQ rules

by combining one or more of these constraints us-

ing edges and Or-Container nodes. The key idea of

edges and Or-Containers is to cover the basic logical

connectives (negation, conjunction, and disjunction)

to form a composition of (custom) DQ constraints.

The latter is supported by a graphical user interface

DATA 2023 - 12th International Conference on Data Science, Technology and Applications

Table 1: Set of DQ constraints available in ColDaQ.

Constraint Description

Not Null Exclude Null Values

All True Assert that all values are True

Values In Range Ensure that values are restricted to given bounds

Matches Regex Ensures values match a given regular expression

Uniqueness Exclude duplicate values

Numeric Assert that all values are numeric

Evenly Distributed Assert an even distribution with a given parameter for tolerance

Min Between Check if the minimum of the values is within a given interval

Max Between Check if the maximum of the values is within a given interval

Sum Between Check if the sum of the values is within a given interval

that allows users to model DQ rules in a low-code DQ

graph called ColDaQ Graph (CG). Following a data-

ﬂow programming approach, our concept lowers the

semantic and syntactic barriers to creating DQ rules

and improves the accessibility to DQ tools for inexpe-

rienced users (Altendeitering and Schimmler, 2022).

3.2 Prototypical Implementation

For the prototypical implementation of our concept,

we followed the guidelines by (Alavi, 1984) and con-

tinuously improved an initial version of our proto-

type. We initialized the implementation by specify-

ing the MGL and MSL more concretely. The MGL

describes all nodes and edges available in the graphi-

cal DSL. ColDaQ distinguishes three kinds of edges:

Success, No-Success, and Default edge. The latter is

a universal edge used in cases where no separation

between success and non-success is necessary. List-

ing 1 displays an example of how edges are speciﬁed

in CINCO.

Listing 1: Speciﬁcation of the success edge.

@style ( succes s )

edge Success {}

Regarding the provisioning of nodes, ColDaQ im-

plements each of the DQ constraints shown in Table

1 as a node. Listing 2 shows how a node is imple-

mented using the ’Matches Regex’ constraint as an

example. The abstract Constraint node (l. 1-6) spec-

iﬁes the general handling of edges. Nodes can have

outgoing edges depending on whether a constraint is

validated successfully. Every concrete node inherits

from this abstract node and speciﬁes further details

(l. 7-19). For instance, the Matches Regex constraint

has an attribute to transfer the display name to the

MSL and a column attribute annotated with possibl-

eValuesProvider annotation to choose a column from

the data table provided. Furthermore, a DQ node can

have additional attributes (l. 18).

Listing 2: Speciﬁcation of the Matches Regex node.

abst r a c t node Cons t r a i nt {

in c o m ingE d g e s ( * [1 , 1 ] )

ou t g o ingE d g e s ( Success [0 ,1] ,

NoS u c c e ss [0 ,1] ,

{ Su cces s , No Su c ce s s }[1 ,2])

}

.. .

@style ( rul e R e c t an g le 3 Ar g ,

"${ column }" ,"${ displ a y } " ,"${ regex }")

@pal e t t e (" De f R ul e s ")

nod e M a t ch es Re ge x ex t en d s C o ns tr a in t {

@p o ss ibl e V alu e s Pro v i der (" info . sc ce .

cinco . p r o du c t . c o l d a q . p r ov i d er .

P o s si bl e C olu m n Val u e Pr o v id er ")

att r E S t r i n g as co l um n

@p r o per t i esV i e wHi d d en

att r E S t r i n g as display :=

" match e s regex "

att r E S t r i n g as re g e x

}

In CINCO, annotations are an easy way to imple-

ment additional functionality. For example, the model

checking annotation can check whether all nodes ex-

cept the Data node are connected from the Start to the

End node. It can also automatically adjust the size of

Or-Container and Or-Lanes whenever the user adds

new elements. The MSL only implements the visual

concept declaratively illustrated in Figure 1, which

shows the user interface of ColDaQ in its ﬁnal ver-

sion. As an additional feature, users of ColDaQ can

reuse CGs with custom DQ rules as new nodes that

behave like a new, single node. For instance, the DQ

rule speciﬁed in the CG shown in Figure 1b is referred

to by a new node named ’Valid Identiﬁer’ in the CG

in Figure 1a.

For the validation of data against a DQ rule mod-

eled in ColDaQ, we implemented a code generator

that creates a Python script and an Expectation Suite.

The Expectation Suite summarizes the DQ conditions

and uses GE for validation. ColDaQ generates the

Python script in three steps. At ﬁrst, static code for

Towards a Low-Code Tool for Developing Data Quality Rules

(a)

(b)

Figure 1: Data Quality Rules modeled with the ColDaQ Prototype.

executing the atomic validation with GE is generated.

In the second step, the code generator analyzes every

path from the Start to the End node and builds a bi-

nary parse tree considering all concepts of DQ rules

treated as logical statements. At last, ColDaQ uses the

tree’s structure to generate a logical statement based

on the atomic validation results. When executing the

Python script, the evaluation of that logical statement

equals the overall validation of the modeled CG.

To realize the collaborative functionality of

DATA 2023 - 12th International Conference on Data Science, Technology and Applications

ColDaQ, we relied on Pyro (Zweihoff, 2022), a meta-

plugin to CINCO (Naujokat, 2016). Pyro can gen-

erate a full-featured web application that supports si-

multaneous work on DQ rules. However, technical re-

strictions and incompatibilities hindered us from fully

integrating Pyro. The collaborative aspect is thus cur-

rently limited to sharing DQ rules using the import

and export function of ColDaQ (see also section 5.2).

4 EVALUATION

Following the guidelines of (Kitchenham et al., 2004),

our evaluation aims to critically reﬂect on the valid-

ity, impact, and applicability of our prototype. To

achieve this goal, we conducted a two-fold evalu-

ation. In the ﬁrst step, we interviewed three DQ

and user experience experts. With these interviews,

we wanted to gain in-depth feedback on our concep-

tual approach and the functional scope of ColDaQ

(Meuser and Nagel, 2009). Subsequently, we con-

ducted a focus group discussion with ten participants

working in data-intensive roles. The focus group dis-

cussion was well-suited for obtaining additional in-

sights as they are high in external validity and can

spark discussions participants have in their daily lives

(Hollander, 2004). In the following subsections, we

describe each evaluation step more closely.

4.1 Step 1: Expert Interviews

The ﬁrst expert we interviewed is employed as a fron-

tend software developer. Interviewees 2 and 3 have a

background in DQ. We initiated each interview with a

demo of our tool, including creating a DQ rule and its

application to an exemplary data set. After the demo,

we asked the interviewees for feedback regarding in-

tuition and concept of the UI components, relevance,

and beneﬁt. We noted their responses, which form

the primary source for analysis (Meuser and Nagel,

2009). To systematically analyze the data, we used

content analysis (Vaismoradi and Snelgrove, 2019).

Overall, the expert feedback was mainly positive.

All interviewees liked the conceptual design of the

user interface. Interviewees 2 and 3 emphasized that

the concept of composing DQ rules graphically is in-

tuitive. As a potential improvement, interviewee 3

stated that the start and end nodes could feature ad-

ditional functionality, such as connecting with APIs

for direct data imports.

Regarding the conceptual approach for develop-

ing DQ rules, interviewees 1 and 2 critically noted

that ColDaQ only allows DQ constraints that can be

validated as true or false. In addition, they criticized

the limitation of the static set of DQ constraints in the

node palette and envisioned possibilities to include

additional nodes. Moreover, interviewee 3 suggested

including a node that uses external code for data vali-

dation. Interviewees 2 and 3 proposed more automa-

tion, for example, by conducting automated data pro-

ﬁling and offering a set of DQ constraints appropriate

for a data set.

4.2 Step 2: Focus Group Discussion

The focus group discussion included ten participants

working in data engineering. Similar to the expert in-

terviews, we initiated the discussion with a presenta-

tion of the tool and demonstrated its functionality us-

ing an exemplary data set. After the presentation, we

asked guiding questions on the tool’s functional com-

position and visual style to spark a discussion among

the participants (Hollander, 2004). The participants

positively noted the conceptual approach and the pos-

sibility of graphically designing DQ rules. It can help

users inexperienced with DQ to construct rules and

apply these to a data set.

On the negative side, the participants noted that

some nodes are difﬁcult to understand because they

did not recognize the difference between default

(atomic) and composed nodes. They suggested sim-

plifying the naming of nodes for better usability.

Users might furthermore beneﬁt from additional ex-

planations and usage examples for the individual

nodes to improve their comprehensibility. Addition-

ally, the participants stated limitations in the compo-

sition of DQ rules. They envisioned further nodes and

logical operators for combinations. Finally, the eval-

uation of DQ rules with GE can be improved. More

detailed results about which nodes failed and poten-

tial reasons could help users identify underlying data

errors and improve the quality of a data set.

5 CONCLUSION

5.1 Contributions

In response to our initial research question, we suc-

cessfully developed a DQ tool that allows the user-

friendly speciﬁcation of DQ rules using a low-code

user interface. With export functionalities, ColDaQ

allows the collaborative design of DQ rules and auto-

mated validation in GE. The two-step evaluation re-

vealed that ColDaQ was, overall, well-received and

can fulﬁll the goal of lowering the accessibility of DQ

tools. Speciﬁcally, the participants positively com-

mented on the intuitive user interface and the visual,

Towards a Low-Code Tool for Developing Data Quality Rules

low-code concept for constructing DQ rules. For fur-

ther development, the participants noted that the tool

should allow the design of more complex DQ rules

and improve the comprehensibility of nodes.

Our study offers both scientiﬁc and managerial

contributions. Scientiﬁcally, we conceptually de-

signed and prototypically implemented an artifact that

addresses the need for more intuitive, user-friendly,

and collaborative DQ tools raised in several studies

(Altendeitering and Tomczyk, 2022; Swami et al.,

2020; Ehrlinger and W

oß, 2022). Our ﬁndings can

furthermore contribute to realizing decentralized DQ

tools accessible to different stakeholders and inform

the design of future tools (Gr

oger, 2021). For man-

agers, we provide insights on building tools for the

manual speciﬁcation of DQ rules that take current

trends into account. This knowledge can support

make-or-buy decisions, inform custom implementa-

tions, and raise awareness for DQ and adequate tool-

ing.

5.2 Limitations & Future Work

Despite following a rigorous approach, our study is

subject to several limitations, which offer paths for

future work. Most importantly, we aimed to create an

application that supports collaborative work on DQ

rules. However, due to technical restrictions, the col-

laborative aspect is only partly realized and limited

to export/import functionalities. We plan to focus the

future development of our tool on this aspect and up-

grade to ’Cinco Cloud’, which was not yet available

at the time of writing. Cinco Cloud aims to realize

full-featured web applications that enable the collab-

orative, multi-user modeling of DQ rules.

Moreover, ColDaQ currently features a limited

set of pre-deﬁned DQ rules. In the future, ColDaQ

should allow more kinds of basic DQ rules from dif-

ferent sources and allow users to specify custom DQ

rules for validation. In this regard, it would also be

interesting to investigate the difference in DQ rules

between different user groups and derive which ones

are generally applicable.

To further increase its usability, ColDaQ should

offer additional support and automation. For exam-

ple, we can apply automated data proﬁling techniques

on a given data set and generate DQ rules automati-

cally (Abedjan et al., 2015).

Regarding our methodological approach, our eval-

uation results are based on qualitative feedback from

participants working in computer science and data-

related jobs. In future studies, we plan to evalu-

ate ColDaQ with a more extensive and diverse user

group to obtain more profound results. These stud-

ies should also include participants working in non-

technical jobs to assess if our tool can achieve the de-

sired level of accessibility.

ACKNOWLEDGEMENTS

This research was partly supported by the German

Federal Ministry of Education and Research (BMBF)

and the research project FAIR Data Spaces.

REFERENCES

Abedjan, Z., Golab, L., and Naumann, F. (2015). Proﬁling

relational data: a survey. The VLDB Journal, 24:557–

581.

Alavi, M. (1984). An assessment of the prototyping ap-

proach to information systems development. Commu-

nications of the ACM, 27(6):556–563.

Altendeitering, M. (2021). Mining data quality rules for

data migrations: a case study on material master data.

In International Symposium on Leveraging Applica-

tions of Formal Methods, pages 178–191. Springer.

Altendeitering, M. and Guggenberger, T. M. (2021). De-

signing data quality tools: Findings from an action

design research project at boehringer ingelheim. In

ECIS 2021 Proceedings.

Altendeitering, M. and Schimmler, S. (2022). End-user de-

velopment for smart spaces: A comparison of block

and data-ﬂow programming. In Proceedings of the

11th International Conference on Smart Cities and

Green ICT Systems, SMARTGREENS.

Altendeitering, M. and Tomczyk, M. (2022). A functional

taxonomy of data quality tools: Insights from science

and practice. Wirtschaftsinformatik 2022 Proceed-

ings.

Amadori, A., Altendeitering, M., and Otto, B. (2020). Chal-

lenges of data management in industry 4.0: a single

case study of the material retrieval process. In Interna-

tional Conference on Business Information Systems,

pages 379–390. Springer.

Dehghani, Z. (2020). Data mesh principles and logical ar-

chitecture. https://martinfowler.com/articles/data-m

esh-principles.html. Accessed: 17.01.2023.

Deursen, A. V. and Klint, P. (1998). Little languages: lit-

tle maintenance? Journal of Software Maintenance:

Research and Practice, 10(2):75–92.

Ehrlinger, L. and W

oß, W. (2022). A survey of data quality

measurement and monitoring tools. Frontiers in Big

Data, page 28.

Fall, A. and Fall, J. (2001). A domain-speciﬁc language for

models of landscape dynamics. Ecological modelling,

141(1-3):1–18.

oger, C. (2021). There is no ai without data. Communi-

cations of the ACM, 64(11):98–108.

Guggenberger, T. M., M

oller, F., Boualouch, K., and Otto,

B. (2020). Towards a unifying understanding of digital

DATA 2023 - 12th International Conference on Data Science, Technology and Applications

business models. In Proceedings of the Twenty-Third

Paciﬁc Asia Conference on Information Systems.

Hollander, J. A. (2004). The social contexts of focus groups.

Journal of contemporary ethnography, 33(5):602–

637.

Kandel, S., Parikh, R., Paepcke, A., Hellerstein, J. M., and

Heer, J. (2012). Proﬁler: Integrated statistical analysis

and visualization for data quality assessment. In Pro-

ceedings of the International Working Conference on

Advanced Visual Interfaces, pages 547–554.

Kitchenham, B. A., Dyba, T., and Jorgensen, M. (2004).

Evidence-based software engineering. In Proceed-

ings. 26th International Conference on Software En-

gineering, pages 273–281. IEEE.

Kosar, T., Martı, P. E., Barrientos, P. A., Mernik, M., et al.

(2008). A preliminary study on various implementa-

tion approaches of domain-speciﬁc language. Infor-

mation and software technology, 50(5):390–405.

Lybecait, M., Kopetzki, D., Zweihoff, P., Fuhge, A., Nau-

jokat, S., and Steffen, B. (2018). A tutorial in-

troduction to graphical modeling and metamodeling

with cinco. In International Symposium on Leverag-

ing Applications of Formal Methods, pages 519–538.

Springer.

Meuser, M. and Nagel, U. (2009). The expert interview

and changes in knowledge production. Interviewing

experts, pages 17–42.

Moore, S. (2018). How to create a business case for data

quality improvement. https://www.gartner.com/smar

terwithgartner/how-to-create-a-business-case-for-dat

a-quality\-improvement. Accessed: 24.01.2023.

Naujokat, S. (2016). Cinco user’s manual. https://cinco.sc

ce.info/. Accessed: 24.01.2023.

Naujokat, S., Lybecait, M., Kopetzki, D., and Steffen,

B. (2018). Cinco: a simplicity-driven approach to

full generation of domain-speciﬁc graphical model-

ing tools. International Journal on Software Tools for

Technology Transfer, 20(3):327–354.

Redman, T. C. (2020). To improve data quality, start at the

source. https://hbr.org/2020/02/to-improve-data-qua

lity-start-at-the-source. Accessed: 10.01.2023.

Swami, A., Vasudevan, S., and Huyn, J. (2020). Data sen-

tinel: A declarative production-scale data validation

platform. In 2020 IEEE 36th International Confer-

ence on Data Engineering (ICDE), pages 1579–1590.

IEEE.

Tebernum., D., Altendeitering., M., and Howar., F. (2021).

Derm: A reference model for data engineering. In

Proceedings of the 10th International Conference on

Data Science, Technology and Applications, pages

165–175. INSTICC.

The Great Expectations Team (2020). Welcome to great

expectations! https://greatexpectations.io/. Accessed:

24.01.2023.

Vaismoradi, M. and Snelgrove, S. (2019). Theme in qual-

itative content analysis and thematic analysis. Forum

Qualitative Sozialforschung/Forum: Qualitative So-

cial Research, 20(3).

Van Deursen, A. and Klint, P. (2002). Domain-speciﬁc lan-

guage design requires feature descriptions. Journal of

computing and information technology, 10(1):1–17.

Van Deursen, A., Klint, P., and Visser, J. (2000). Domain-

speciﬁc languages: An annotated bibliography. ACM

Sigplan Notices, 35(6):26–36.

Wang, P. and He, Y. (2019). Uni-detect: A uniﬁed approach

to automated error detection in tables. In Proceedings

of the 2019 International Conference on Management

of Data, pages 811–828.

Wang, R. Y. (1998). A product perspective on total data

quality management. Communications of the ACM,

41(2):58–65.

Wang, R. Y. and Strong, D. M. (1996). Beyond accuracy:

What data quality means to data consumers. Journal

of Management Information Systems, 12(4):5–33.

Zweihoff, P. (2022). Pyro - a collaborative, meta-model-

driven, web-based and graphical modeling environ-

ment. https://pyro.scce.info. Accessed: 17.02.2023.

Towards a Low-Code Tool for Developing Data Quality Rules
