A Note on a CBC-Type Mode of Operation

George Tes¸eleanu

1,2 a

Advanced Technologies Institute, 10 Dinu Vintil

a, Bucharest, Romania

Simion Stoilow Institute of Mathematics of the Romanian Academy, 21 Calea Grivitei, Bucharest, Romania

Keywords:

Mode of Operation, Cipher Block Chaining Mode, Block Cipher, Provable Security.

Abstract:

In this paper we formally introduce a novel mode of operation based on the cipher block chaining mode. The

main idea of this mode is to use a stateful block cipher instead of a stateless one. Afterwards, we show how to

implement our proposal and present a performance analysis of our mode. Next, we provide a concrete security

analysis by computing a tight bound on the success of adversaries based on their resources. The results of

our performance and security analyses are that this novel mode is more secure than the cipher block chaining

mode for large ﬁles, but the encryption/decryption time doubles/triples. Therefore, our novel mode is suitable

for encrypting large ﬁles, when higher security is required, but speed is not paramount. Note that the changes

required to transform the software implementations of the cipher block chaining mode into this new mode are

minimal, and therefore transitioning to this new mode is straightforward.

1 INTRODUCTION

One of the most popular classical mode of operation is

called Cipher Block Chaining (CBC) mode (Ehrsam

et al., 1978). The CBC mode is widespread and very

widely used, and therefore is standardised in (ISO,

2017; Dworkin, 2001; IEEE, 2018; IETF, 2003). Im-

plementations of CBC can be found in software li-

braries such as (Legion of the Bouncy Castle, 2023;

Trusted Firmware, 2023; Crypto++, 2022; OpenSSL

Technical Committee, 2023).

In this paper we introduce a novel CBC-based

mode of operation. More precisely, we use the CBC

mode with a stateful block cipher instead of a state-

less one. Speciﬁcally, rather of using the same key to

encrypt each block of data, we modify the key sched-

ule such that after generating the round keys neces-

sary for encryption it also generates an encryption

key

. Therefore, after encrypting the ﬁrst block of

data, we memorize the encryption key generated by

the key schedule. The memorized key is then used to

encrypt the second block of data and the process is

repeated for the remaining blocks. After ﬁnishing all

the blocks, the key is reset to the original value and

the block cipher is now ready to encrypt the next set

https://orcid.org/0000-0003-3953-2744

Formed by concatenating one or more additional gen-

erated round keys depending on the size of the round and

encryption keys

of data. Note that resetting the key before each new

set of plaintexts avoids synchronisation problems.

After formalizing our novel CBC-based mode,

we provide some implementations details. We start

with describing two possible approaches for trans-

forming a stateless block cipher into a stateful one.

Since the second one is more suitable for all three ci-

phers implemented in Mbed TLS (Trusted Firmware,

2023), namely AES (Daemen and Rijmen, 2002),

ARIA (NSRI, 2005) and Camellia (Aoki et al., 2001),

we made the necessary implementation modiﬁca-

tions needed to obtain a stateful cipher. To analyze

the performance of our mode, we also modiﬁed the

CBC implementation found in Mbed TLS (Trusted

Firmware, 2023). We observed that our mode’s en-

cryption/decryption time is two/three times slower

than that of classical CBC.

In the last part of the paper, we provide a tight

security bound. To achieve this we ﬁrst compute an

upper bound and then we devise an attack that has a

success probability close to this bound. Therefore,

there is no signiﬁcantly better bound than the one

given in this paper. Based on this security bound, we

conclude that this mode is more secure than CBC for

large ﬁles. Since modifying existing CBC implemen-

tations to use a stateful block cipher is straightfor-

ward, we recommend switching to this novel mode

for large ﬁles, when the additional processing time

does not lead to bottlenecks. An example of such a

TeÅ§eleanu, G.

A Note on a CBC-Type Mode of Operation.

DOI: 10.5220/0012059100003555

In Proceedings of the 20th International Conference on Security and Cryptography (SECRYPT 2023), pages 353-360

ISBN: 978-989-758-666-8; ISSN: 2184-7711

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

353

use case is the following: suppose you want to store

some sensitive data that is rarely accessed, such as

backup copies of surveillance footage. In this case,

the data is not accessed frequently, so the speed of ac-

cessing it is not crucial. However, security is essential

to ensure the conﬁdentiality of the data.

Full Version. The full version of the paper can be

found here (Tes¸eleanu, 2023).

Structure of the Paper. We introduce notations and

deﬁnitions used throughout the paper in Section 2. In

Section 3 we formalize the Running Key CBC mode

of operation. Implementation details and a security

analysis are provided in Sections 4 and 5. We con-

clude in Section 6.

2 PRELIMINARIES

Notations and Conventions. Throughout the paper

|b| will denote the bit size of b and ⊕ the bitwise xor

operation. By x∥y we understand the concatenation

of the strings x and y. Also, we deﬁne 0

and 1

as a

string of s zeros and ones, respectively. We use the no-

tation x

←−X when selecting a random element x from

a sample space X . We denote by x ←y the assignment

of the value y to the variable x. The probability that

event E happens is denoted by Pr[E]. Hexadecimal

strings are marked by the preﬁx 0x. The most ℓ sig-

niﬁcant bits of Q are denoted by MSB

ℓ

(Q).

For all complexity measures we work in the ran-

dom access model and all the adversaries are prob-

abilistic polynomial time machines (PPT). When we

talk about the running time of an opponent, we will in-

clude the actual running time plus the length of the ad-

versary’s description (i.e. the length of the random ac-

cess machine program that describes the adversary).

Also, queries are answered in one unity of time.

2.1 PRF/PRP

We start by deﬁning the security notions commonly

used to quantify the security of a block cipher (Rog-

away, 2011) and then we provide the link between the

two notions (Bellare and Rogaway, 2006).

Deﬁnition 2.1 (Pseudorandom Function - PRF, Pseu-

dorandom Permutation - PRP). A function F :

{0,1}

× {0, 1}

→ {0,1}

is a PRF or PRP if for

any PPT algorithm A which makes at most q oracle

queries, the following advantages

ADV

PRF

(A) =



Pr[A

(·)

= 1|K

←− {0,1}

]

−Pr[A

ρ(·)

= 1|ρ

←− F ]



ADV

PRP

(A) =



Pr[A

(·)

= 1|K

←− {0,1}

]

−Pr[A

π(·)

= 1|π

←− P ]



are negligible, where F

(X) = F(X, K), and F and P

denote the sets of all functions and permutations from

n-bit strings to n-bit strings.

Lemma 2.1 (PRP/PRF Switching Lemma). Let F :

{0,1}

×{0,1}

→ {0,1}

be a function. Also, let

A be an adversary that asks at most q oracle queries.

Then



Pr[A

ρ(·)

= 1|ρ

←− F ] −Pr[A

π(·)

= 1|π

←− P ]



≤

q(q −1)

n+1

As a consequence, we have that



ADV

PRF

(A) −ADV

PRP

(A)



≤

q(q −1)

n+1

2.2 Symmetric Key Encryption

We further deﬁne symmetric key encryption schemes

(Bellare and Rogaway, 2005) and provide one of the

security notions commonly used to model chosen-

plaintext attacks (Bellare and Rogaway, 2006; Rog-

away, 2011).

Deﬁnition 2.2 (Symmetric Key Encryption - SKE). A

symmetric key encryption (SKE) scheme usually con-

sists of three PPT algorithms: Setup, Encrypt and De-

crypt. The Setup algorithm takes as input a security

parameter and outputs the secret key. Encrypt takes

as input the secret key and a message and outputs

the corresponding ciphertext. The Decrypt algorithm

takes as input the secret key and a ciphertext and out-

puts either a valid message or an invalidity symbol (if

the decryption failed).

Deﬁnition 2.3 (Indistinguishability under Chosen

Plaintext Attacks - IND-CPA). The security model

against chosen plaintext attacks for a SKE scheme S E

is captured in the following game:

Setup(λ): The challenger C generates the secret key

←− {0, 1}

and a bit b

←− {0, 1}.

Queries: Adversary A sends C two messages

∈ {0, 1}

∗

of the same length. The chal-

lenger encrypts m

and obtains the ciphertext c

S E(m

,K). The value c

is sent to the adversary.

Guess: After making a polynomial number of

queries, the adversary outputs a guess b

′

∈ {0, 1}.

He wins the game, if b

′

= b.

SECRYPT 2023 - 20th International Conference on Security and Cryptography

354

The advantage of an adversary A which runs in time

t, makes at most q oracle queries, these totaling σ bits

and is attacking a SKE scheme is deﬁned as

ADV

IND-CPA

S E

(A) = |2Pr[b = b

′

] −1|

where the probability is computed over the random

bits used by C and A. A SKE scheme is IND-CPA

secure, if for any PPT adversary A the advantage

ADV

IND-CPA

S E

(A) is negligible.

We further present the CBC encryption algorithm

in Algorithm 1 and then we present its security mar-

gins as stated in (Rogaway, 2011; Bellare and Rog-

away, 2005). Let K be an k-bit random key, P a plain-

text and C a ciphertext.

Algorithm 1: CBC Mode of Operation.

1 Function Encrypt(P, K):

2 if |P| mod n ̸≡ 0 or |P| = 0 then return ⊥;

3 P

∥. ..∥P

← P where |P

| = n;

4 IV

←− {0,1}

and C

← IV ;

5 foreach i ∈[1,m] do C

← E

⊕C

i−1

) ;

6 C ←C

∥. ..∥C

;

7 Function Decrypt(IV , C, K):

8 if |C| mod n ̸≡0 or |C| = 0 then return ⊥;

9 C

∥. ..∥C

←C where |C

| = n;

10 C

← IV ;

11 foreach i ∈[1,m] do P

← E

−1

) ⊕C

i−1

;

12 P ←P

∥. ..∥P

;

Theorem 2.2 (Upper Bound on Security of CBC Mode

Using a Block Cipher). Let E : {0, 1}

×{0,1}

→

{0,1}

be a block cipher. Let A be a PPT adversary

against the IND-CPA security of CBC that runs at most

time t and queries at most σ n-bit blocks. Then there

exists an adversary B against the PRP security of E

such that

ADV

IND-CPA

CBC

(A) ≤ ADV

PRP

(B) +

2σ

and where B makes at most σ queries and runs in time

at most t + O(nσ).

Theorem 2.3 (Lower Bound on Security of CBC

Mode Using a Block Cipher). Let E : {0,1}

{0,1}

→ {0,1}

be a block cipher and let σ ∈

[1,

√

n+1

]. Then there exists an adversary A against

the IND-CPA security of CBC such that

ADV

IND-CPA

CBC

(A) ≥

0.15σ

and which asks one query consisting of σ n-bit blocks

and runs in time at most O(nσ logσ).

3 RUNNING KEY CBC SKE

Let E : {0,1}

× {0, 1}

→ {0,1}

be a block ci-

pher. Instantiating the running key CBC (denoted

RK-CBC) with E and with a random initialisation

vector (denoted IV ) leads to a stateless symmetric en-

cryption scheme. Let K

= {K

}

i>0

be a family of

distinct k-bit random keys, P a plaintext and C a ci-

phertext. We present in Algorithm 2 the exact detail

of RK-CBC.

Algorithm 2: Running Key CBC Mode of Opera-

tion.

1 Function Encrypt(P, K

2 if |P| mod n ̸≡ 0 or |P| = 0 then return ⊥;

3 P

∥. ..∥P

← P where |P

| = n;

4 IV

←− {0,1}

and C

← IV ;

5 foreach i ∈[1,m] do C

← E

⊕C

i−1

) ;

6 C ←C

∥. ..∥C

;

7 Function Decrypt(IV , C, K

8 if |C| mod n ̸≡0 or |C| = 0 then return ⊥;

9 C

∥. ..∥C

←C where |C

| = n;

10 C

← IV ;

11 foreach i ∈[1,m] do P

← E

−1

) ⊕C

i−1

;

12 P ←P

∥. ..∥P

;

4 IMPLEMENTATION DETAILS

When studying the security of iterated block ciphers

(Lai et al., 1991), it is assumed that the cipher’s round

sub-keys are independent. This assumption is reason-

able in practice (Biham and Shamir, 1991; Knudsen

and Mathiassen, 2004; Vaudenay, 2005). Using this

assumption, we can transform a stateless block cipher

into a stateful one using two methods.

In the ﬁrst method we simply memorize the initial

key into a buffer and then we continuously run the key

schedule algorithm until all data blocks are encrypted

(see Figure 1). More precisely, for an r round cipher

and an m block plaintext the key schedule algorithm

will generate (r + 1)m keys. Since we assumed that

the round sub-keys are independent, we obtain m in-

dependent instantiations of the iterated block cipher.

Therefore, we can use it to implement the RK-CBC

mode. Unfortunately, not all key schedules can be

easily modiﬁed to support continuous generation. For

example, the AES (Daemen and Rijmen, 2002) and

ARIA (NSRI, 2005) key schedules support this out of

the box, but for the Camellia (Aoki et al., 2001) key

schedule we could not devise a suitable modiﬁcation.

In the second method we modify the key schedule

to generate a few additional round keys after comput-

ing the round keys needed for encryption. Then we

concatenate the additional round keys to obtain a new

encryption key, that is used to encrypt the next block

of data. The process continues until all blocks are pro-

We consider that an r round cipher uses r+1 sub-keys.

A Note on a CBC-Type Mode of Operation

355

ENC

...

r+1

state

ENC

...

r+2

2r+1

state

ENC

...

2r+2

3r+1

Figure 1: The First Method for Implementing RK-CBC

when m = 3.

cessed. For example, if n = k we generate only one

additional round key k

r+2

and set K

= k

r+2

(see Fig-

ure 2).

If n = 2k we have to generate two additional

round keys k

r+2

r+3

and set K

= k

r+2

∥k

r+3

. Using

this method we managed to modify all three block ci-

phers implemented in Mbed TLS (Trusted Firmware,

2023). The technical details of the changes can be

found in (Tes¸eleanu, 2023).

ENC

...

r+1

r+2

ENC

...

r+1

r+2

ENC

...

r+1

Figure 2: The Second Method of Implementing RK-CBC

when m = 3 and n = k.

Taking into account the above discussions, we can

transform a CBC implementation into a RK-CBC one

by simply resetting the key before encrypting each

block of plaintexts and by using either stateful block

cipher described above. Note that, compared to CBC,

RK-CBC needs an extra buffer to memorize the initial

key.

Let t

be the time needed run the key schedule

once and t

enc

be the time needed to compute a block

cipher encryption without taking into account t

. In

terms of performance, the time required to encrypt an

m-block of data using CBC is O(m ·t

enc

On the

other hand, the time required by the RK-CBC is O(m ·

+ t

enc

)). Therefore, CBC is O((t

+ t

enc

)/t

enc

)

faster than RK-CBC.

To compute the exact slowdown for Mbed TLS

(Trusted Firmware, 2023), we implemented the RK-

CBC mode and run the Mbed TLS benchmark pro-

gram on a CPU Intel i7-4790 4.00 GHz. Note that to

compute the rate of kilobytes per second, Mbed TLS

ﬁrst sets an internal alarm to 1 second and then in-

crements a counter for each 1024 bytes block that is

Figures 1 and 2 are based on the TikZ found in

(Maimut¸, 2017).

Usually, the key schedule is run once at the beginning

and the round keys memorized for the duration of encryp-

tion, and thus t

can be ignored.

processed, until the alarm is set off. The counter rep-

resents the given rate. In the case of the cycle per

byte rate, the benchmark program computes the num-

ber of cycles needed to process 1024 blocks of size

1024 bytes. Then it divides the resulting number by

1024 ·1024 and outputs the rate. The results of our

experiments can be found in Figure 3 to 8. Compared

to RK-CBC encryption/decryption, classical CBC en-

cryption is 2x/3.5x faster for AES

, 2.3x/3.2x faster

for ARIA and 2.2x/2.5x faster for Camellia.

We also carried a series of experiments to test

the validity of our assumption (i.e. the generated

key bits are independent and identically distributed).

Therefore, we set K

as either 0

or 1

, where s =

128/192/256 and we generated K

... using the

second method. Then we applied the NIST test suite

(Turan et al., 2018; NIST, 2023) to check if the key

bits of K

... are independent and identically dis-

tributed. We obtained that the samples pass all the

statistical tests, and have an entropy of 0.99 per bit

and 7.9 per byte. Thus, based on the results of the

experiments we conducted, we can safely assume the

generated keys are random and mutually independent.

5 SECURITY ANALYSIS

Before starting our analysis, some notations are re-

quired. Therefore, A will denote a PPT algorithm

which makes at most q oracle queries, these totaling at

most σ n-bit blocks, unless mentioned otherwise. Let

′

= σ −q +1 and σ = αq + r, where r < q. For sim-

plicity, we denote by ρ

the oracle that responds to a

query of type (i,X) with ρ

(X), where {ρ

}

i∈[1,σ

′

]

is a

family of distinct random functions. Similarly, we de-

note by π

the oracle that responds with π

(X), where

{π

}

i∈[1,σ

′

]

is a family of distinct random permuta-

tions. Lastly, we denote by F

the oracle that responds

with F

), where {K

}

i∈[1,σ

′

]

is a family of distinct

random k-bit keys and F : {0,1}

×{0,1}

→{0,1}

is a function.

For simplicity, we further assume that adversary

A never asks a query that is not composed of n-bit

blocks. In our case, queries that do not satisfy this

restriction generate error messages, and thus they are

pointless for A.

Now, we start our security analysis (see

(Tes¸eleanu, 2023) for the proofs) by ﬁrst study-

ing the security of the RK-CBC mode instantiated

with random functions ρ

from F instead of E

. We

denote this version by RK-CBC(ρ

). Note that in

Note that we deactivated the AES-NI instructions for a

fair performance between the three block ciphers.

SECRYPT 2023 - 20th International Conference on Security and Cryptography

356

0 20 40

80 100 120

128

192

256

cycles/byte

key size

Enc CBC

Enc RK-CBC

Dec CBC

Dec RK-CBC

Figure 3: AES performance.

0 20 40

80 100 120

128

192

256

cycles/byte

key size

Enc CBC

Enc RK-CBC

Dec CBC

Dec RK-CBC

Figure 4: ARIA performance.

0 20 40

80 100 120

128

192

256

cycles/byte

key size

Enc CBC

Enc RK-CBC

Dec CBC

Dec RK-CBC

Figure 5: Camellia performance

this case, the decryption algorithm returns ⊥ with

probability 1 −2

−n

, since it does not have a correct

decryption property.

Lemma 5.1 (Upper Bound on Security of RK-CBC

Mode Using a Random Function). Let A be a PPT

adversary against the IND-CPA security of the RK-

CBC(ρ

) mode. Then

ADV

IND-CPA

RK-CBC(ρ

)

(A) ≤

αq

+ r

In order to make the switch from random function

to random permutation we need an equivalent of the

Switching Lemma (Lemma 2.1). We also introduce

an equivalent of Deﬁnition 2.1 that will be useful later.

0 1 2 3 4

·10

128

192

256

kilobytes/second

key size

Enc CBC

Enc RK-CBC

Dec CBC

Dec RK-CBC

Figure 6: AES performance.

0 1 2 3 4

·10

128

192

256

kilobytes/second

key size

Enc CBC

Enc RK-CBC

Dec CBC

Dec RK-CBC

Figure 7: ARIA performance.

0 1 2 3 4

·10

128

192

256

kilobytes/second

key size

Enc CBC

Enc RK-CBC

Dec CBC

Dec RK-CBC

Figure 8: Camellia performance.

Deﬁnition 5.1 (Family of Pseudorandom Functions

- F-PRF, Family of Pseudorandom Permutation -

F-PRP). A function F : {0,1}

×{0,1}

→ {0,1}

a F-PRF or F-PRP if for any PPT algorithm A which

makes at most q oracle queries of type (i,·), these to-

taling at most σ n-bit blocks, the following advantages

ADV

F-PRF

(A) =



Pr[A

(·)

= 1|K

←− {0,1}

]

−Pr[A

(·)

= 1|ρ

←− F ]



ADV

F-PRP

(A) =



Pr[A

(·)

= 1|K

←− {0,1}

]

−Pr[A

(·)

= 1|π

←− P ]



are negligible.

A Note on a CBC-Type Mode of Operation

357

Remark. Note that when q = σ the F-PRF/F-PRP se-

curity notions are identical to the PRF/PRP ones.

Lemma 5.2 (F-PRP/F-PRF Switching Lemma). Let A

be an adversary that asks at most q oracle queries,

these totaling at most σ n-bit blocks. Then

Pr[switch] =



Pr[A

(·)

= 1|ρ

←− F ] −Pr[A

(·)

= 1|π

←− P ]



≤

0.5(αq

+ r

)

As a consequence, we have that



ADV

F-PRF

(A) −ADV

F-PRP

(A)



≤

0.5(αq

+ r

)

We further apply Lemma 5.2 to see what happens

if we use random permutations instead random func-

tion when instantiating the RK-CBC mode. We de-

note this version by RK-CBC(π

Corollary 5.2.1 (Upper Bound on Security of

RK-CBC Mode Using a Random Permutation). Let

A be a PPT adversary against the IND-CPA security of

the RK-CBC(π

) mode. Then

ADV

IND-CPA

RK-CBC(π

)

(A) ≤

2(αq

+ r

)

Theorem 5.3 (Upper Bound on Security of RK-CBC

Mode Using a Block Cipher). Let E : {0,1}

{0,1}

→ {0,1}

be a block cipher. Let A be a PPT

adversary against the IND-CPA security of RK-CBC

that runs at most time t. Then there exists an adver-

sary B against the F-PRP security of E such that

ADV

IND-CPA

RK-CBC

(A) ≤ ADV

F-PRP

(B) +

2(αq

+ r

)

and where B makes at most q queries of type (i,·) and

runs in time at most t + O(nσ).

Corollary 5.3.1 (Simpliﬁed Upper Bound on Security

of RK-CBC Mode Using a Block Cipher). Let E :

{0,1}

×{0,1}

→ {0,1}

be a block cipher. Let A

be a PPT adversary against the IND-CPA security of

RK-CBC that runs at most time t. Then there exists

an adversary B against the F-PRP security of E such

that

ADV

IND-CPA

RK-CBC

(A) ≤ ADV

F-PRP

(B) +

2qσ

and where B makes at most q queries of type (i,·) and

runs in time at most t + O(nσ).

We further provide an attack that gives A an ad-

vantage of around (αq

+ r

)/2

to break the IND-

CPA security of RK-CBC. This implies that there is no

signiﬁcantly better bound than the one given in Theo-

rem 5.3 .

Theorem 5.4 (Lower Bound on Security of RK-CBC

Mode Using a Block Cipher). Let E : {0,1}

{0,1}

→ {0,1}

be a block cipher and let q ∈

[1,

√

n+1

]. Then there exists an adversary A against

the IND-CPA security of RK-CBC such that

ADV

IND-CPA

RK-CBC

(A) ≥

0.15(αq

+ r

)

and runs in time at most O(n(αq logq + r logr)).

Proof. Adversary A makes q queries of type (Z

where for i ∈ [1, r] we have Z

← 0

n(α+1)

and R

←−

{0,1}

n(α+1)

, and otherwise we have Z

← 0

nα

and

←− {0,1}

nα

. If there exists two distinct queries q

and q

such that blocks v received from the challenger,

denoted B

) and B

), are identical then A selects

lexicographically the ﬁrst such (q

,v) and output 1

if B

v+1

) ̸= B

v+1

). Note that the running time of

A is dominated by the running time needed to sort the

data received from each oracle, and thus we obtain a

running time of O(n(αq logq + r logr)).

When b = 0, adversary A queries identical blocks,

and thus if a collision of type B

) = B

) occurs

we always have B

v+1

) = B

v+1

). Therefore, we

always have

Pr[A

RK-CBC(·)

= 1|b ←0] = 0,

and hence

ADV

IND-CPA

RK-CBC

(A) = Pr[A

RK-CBC(·)

= 1|b ←1].

When b = 1, encrypting a random block of data

using RK-CBC results in another block of random

data, since the image of a uniformly selected value

under a permutation remains uniform. Therefore,

we can apply the birthday paradox to compute the

probability of obtaining B

) = B

). The para-

dox states that the probability of obtaining a colli-

sion when making Q ∈ {q, r} queries to oracle v ∈

[1,α + 1] is at least 0.3Q

, when Q ∈ [1,

√

n+1

Also, note that since B

v+1

) and B

v+1

) are ran-

dom, the probability of having B

v+1

) = B

v+1

) is

1/2

. Hence, we obtain that

Pr[A

RK-CBC(·)

= 1|b ←1] ≥



0.3q

0.3r



1 −



≥

0.15(αq

+ r

)

as desired.

5.0.1 CBC vs. RK-CBC

To better understand the security gap between the two

modes we further consider two scenarios. In the ﬁrst

SECRYPT 2023 - 20th International Conference on Security and Cryptography

358

0.5

·10

0.5

·10

c (bytes)

Figure 9: The curve q

= q

c/n when n = 16 bytes.

scenario we assume that we can only encrypt blocks

of data of a ﬁxed size c = d ·n, where d > 0. There-

fore, the data requirement for both modes is σ = q ·d.

According to Theorem 2.2 we obtain

ADV

IND-CPA

CBC

(A) ≤ ADV

PRP

(B) +

and to Theorem 5.3

ADV

IND-CPA

RK-CBC

(A) ≤ ADV

F-PRP

(B) +

Therefore, the free term for RK-CBC is d times better

than the one for CBC. Hence, to obtain the same se-

curity margin we have to set the number of RK-CBC

queries to q

= q

√

d (see Figure 9), where q

is the

number of CBC queries.

For example, if we consider TLS packages of

maximum record size 16 Kilobytes we obtain that

d = 1000, which means that we have to make 31x

more queries for RK-CBC. If restrict to encrypting

DVDs, we have that c = 4.37 Gibibytes and d ≃ 2

and thus we have to make 2

times more queries for

RK-CBC. Since RK-CBC is slower than CBC (see

Section 4) we consider that the security advantage be-

comes relevant only for large ﬁles (e.g. DVDs, Blu-

rays).

In the second scenario we consider that we can

encrypt ﬁles of any size. Let σ

and σ

be the

data requirements from Theorem 2.2 and Corol-

lary 5.3.1. Then the security margins presented in

Corollary 5.3.1 coincide with the ones from Theo-

rem 2.2 only if σ

= q

(see Figure 10). If we con-

sider that σ

= σ

= σ, then we obtain that q

= σ

. In this case, the only difference is that instead of

asking one query consisting of σ blocks (see Theo-

rem 2.2) we have to ask σ queries each consisting of

one block (see Corollary 5.3.1). One consequence of

this is that if we have an IND-CPA attacker for RK-

CBC that asks σ queries, then we can use this at-

tacker to break the IND-CPA security of CBC. More

precisely, we only send messages of one block to the

CBC oracle, forward the challenges to the RK-CBC

attacker and output the bit computed by the RK-CBC

attacker. The converse is not true. We can also con-

sider the other extreme case q

= 1. This leads to

= σ

. Therefore, if we want to make one query as

in the case of CBC, we need σ

times more data for

RK-CBC.

6 CONCLUSIONS

In this work we presented a novel CBC-based mode

of operation. Then we provided some implementa-

tion details and a performance analysis. Finally, we

proved its security by giving an upper bound to poly-

nomial adversaries and, moreover, we showed that

this bound is the best possible, by showing a matching

attack.

Let σ

be the data requirements from Theo-

rem 2.2, and let σ

and q

be the data and query

requirements from Corollary 5.3.1. From the security

analysis we can see that to match the IND-CPA upper

limit of CBC we need to have σ

= q

. Therefore,

an IND-CPA adversary against the RK-CBC mode re-

quires either more data or more queries. Since obtain-

ing legitimate ciphertexts is problematic in practice,

we obtain that the RK-CBC is more secure that CBC.

Therefore, because converting existing CBC imple-

mentations into RK-CBC ones is straightforward and

due to the speed penalty incurred by RK-CBC, we

recommend using this novel mode instead of CBC

for encrypting large ﬁles when processing time is not

paramount.

0.5

·10

0.5

·10

0.5

·10

Figure 10: The curve σ

√

A Note on a CBC-Type Mode of Operation

359

REFERENCES

Aoki, K., Ichikawa, T., Kanda, M., Matsui, M., Moriai,

S., Nakajima, J., and Tokita, T. (2001). Speciﬁca-

tion of Camellia - A 128-bit Block Cipher. Technical

report, Nippon Telegraph and Telephone Corporation

and Mitsubishi Electric Corporation.

Bellare, M. and Rogaway, P. (2005). Introduction to Mod-

ern Cryptography. UCSD CSE.

Bellare, M. and Rogaway, P. (2006). The Security of Triple

Encryption and a Framework for Code-Based Game-

Playing Proofs. In EUROCRYPT 2006, volume 4004

of Lecture Notes in Computer Science, pages 409–

426. Springer.

Biham, E. and Shamir, A. (1991). Differential Cryptanal-

ysis of DES-like Cryptosystems. In CRYPTO 1990,

volume 537 of Lecture Notes in Computer Science,

pages 2–21. Springer.

Crypto++ (2022). Crypto++ Library. https://www.cryptopp.

com/.

Daemen, J. and Rijmen, V. (2002). The Design of Rijndael.

Springer.

Dworkin, M. (2001). Recommendation for Block Cipher

Modes of Operation: Methods and Techniques. Tech-

nical report, NIST Special Publication 800-38A.

Ehrsam, W. F., Meyer, C. H., Smith, J. L., and Tuchman,

W. L. (1978). Message Veriﬁcation and Transmission

Error Detection by Block Chaining. US Patent No.

4,074,066.

IEEE (2018). IEEE Standard for Authenticated Encryption

with Length Expansion for Storage Devices. IEEE

Standard No. 1619.1.

IETF (2003). The AES-CBC Cipher Algorithm and Its Use

with IPsec. IETF Standard No. RFC3602.

ISO (2017). Information Technology - Security Tech-

niques - Modes of Operation for an n-bit Block Ci-

pher. ISO/IEC Standard No. 10116:2017.

Knudsen, L. R. and Mathiassen, J. E. (2004). On the Role of

Key Schedules in Attacks on Iterated Ciphers. In ES-

ORICS 2004, volume 3193 of Lecture Notes in Com-

puter Science, pages 322–334. Springer.

Lai, X., Massey, J. L., and Murphy, S. (1991). Markov Ci-

phers and Differential Cryptanalysis. In EUROCRYPT

1991, volume 547 of Lecture Notes in Computer Sci-

ence, pages 17–38. Springer.

Legion of the Bouncy Castle (2023). Bouncy Castle. https:

//www.bouncycastle.org/.

Maimut¸, D. (2017). TikZ for Cryptographers. https://www.

iacr.org/authors/tikz/.

NIST (2023). NIST SP 800-90B: Recommendation for

the Entropy Sources Used for Random Bit Gen-

eration. https://github.com/usnistgov/SP800-90B

EntropyAssessment.

NSRI (2005). Speciﬁcation of ARIA. Technical report,

National Security Research Institute.

OpenSSL Technical Committee (2023). OpenSSL. https:

//www.openssl.org/.

Rogaway, P. (2011). Evaluation of Some Blockcipher

Modes of Operation. Technical report, Cryptography

Research and Evaluation Committees (CRYPTREC)

for the Government of Japan.

Tes¸eleanu, G. (2023). A Note on a CBC-Type Mode of Op-

eration. IACR Cryptology ePrint Archive, 2023/599.

Trusted Firmware (2023). Mbed TLS. https://tls.mbed.org/.

Turan, M. S., Barker, E., Kelsey, J., McKay, K., Baish, M.,

and Boyle, M. (2018). NIST SP 800-90B: Recom-

mendation for the Entropy Sources Used for Random

Bit Generation. Technical report, National Institute of

Standards and Technology.

Vaudenay, S. (2005). A Classical Introduction to Cryp-

tography: Applications for Communications Security.

Springer Science & Business Media.

SECRYPT 2023 - 20th International Conference on Security and Cryptography

360
