Grifﬁn: Towards Mixed Multi-Key Homomorphic Encryption

Thomas Schneider

, Hossein Yalame

and Michael Yonli

ENCRYPTO Group, Technical University of Darmstadt, Darmstadt, Germany

Keywords:

Secure Computation, Multi-Key Homomorphic Encryption.

Abstract:

This paper presents Grifﬁn, an extension of the mixed-scheme single-key homomorphic encryption framework

Pegasus (Lu et al., IEEE S&P’21) to a Multi-Key Homomorphic Encryption (MKHE) scheme with applica-

tions to secure computation. MKHE is a generalized notion of Homomorphic Encryption (HE) that allows

for operations on ciphertexts encrypted under different keys. However, an efﬁcient approach to evaluate both

polynomial and non-polynomial functions on encrypted data in MKHE has not yet been developed, hindering

the deployment of HE to real-life applications. Grifﬁn addresses this challenge by introducing a method for

transforming between MKHE ciphertexts of different schemes. The practicality of Grifﬁn is demonstrated

through benchmarks with multiple applications, including the sorting of sixty four 45-bit ﬁxed point numbers

with a precision of 7 bits in 21 minutes, and evaluating arbitrary functions with a one-time setup communica-

tion of 1.4 GB per party and 2.34 MB per ciphertext. Moreover, Grifﬁn could compute the maximum of two

numbers in 3.2 seconds, a 2× improvement over existing MKHE approaches that rely on a single scheme.

1 INTRODUCTION

As data collection reaches unprecedented volumes

and consumer awareness and apprehension regard-

ing the usage of their personal information grow,

the implementation of efﬁcient privacy protection

measures gets more and more important. Secure

multi-party computation techniques (MPC) (Yao,

1986; Goldreich et al., 1987) allow to address this

problem efﬁciently in a variety of real-world applica-

tions, including privacy-preserving machine learning

(PPML) (Riazi et al., 2018; Boemer et al., 2020;

Patra et al., 2021a; Br

uggemann et al., 2023), cluster-

ing (Hegde et al., ; Keller et al., 2021), and federated

learning (Nguyen et al., 2022; Fereidooni et al., 2021;

Gehlhar et al., 2023). One promising approach is

Homomorphic Encryption (HE), which allows for

performing arbitrary computations over encrypted

data. HE has been used as a building block in various

applications such as PPML (Juvekar et al., 2018;

Boemer et al., 2020; Mishra et al., 2020). Compared

to traditional MPC methods, HE-based methods have

the advantage of lower communication and round

complexity (Chen et al., 2019b), but they come at the

cost of higher computational complexity and runtime.

Existing HE schemes can be broadly categorized

https://orcid.org/0000-0001-8090-1316

https://orcid.org/0000-0001-6438-534X

into two types: binary schemes such as FHEW (Ducas

and Micciancio, 2015) and TFHE (Chillotti et al.,

2020), and arithmetic schemes such as BFV (Fan

and Vercauteren, 2012), BGV (Brakerski et al.,

2014), and CKKS (Cheon et al., 2017). Arithmetic

schemes typically support Single Instruction Multiple

Data (SIMD) operations and are well-suited for eval-

uating functions which can be easily represented as

a polynomial. However, evaluating non-linear func-

tions, such as square roots or ﬁnding the minimum

of two elements, requires numerical approximations,

which can be very expensive to compute due to the

need for deep circuits to achieve accurate results. On

the other hand, binary schemes can easily evaluate

binary circuits and even support lookup table (LUT)

evaluation, making them more suitable for non-linear

functions. However, they are less efﬁcient for

addition and multiplication circuits, as demonstrated

in (Lou et al., 2020, Tab. 1). To overcome this lim-

itation, Pegasus (Lu et al., 2021) recently proposed

a framework that can switch between an arithmetic

CKKS ciphertext and corresponding binary FHEW

ciphertexts. This allows for the evaluation of arith-

metic functions using CKKS and LUTs using FHEW.

However, Pegasus only supports a single secret

key, making it unsuitable for secure computation

applications with multiple data providers, such as

federated learning (McMahan et al., 2017; Fereidooni

et al., 2021; Schneider et al., 2023).

Schneider, T., Yalame, H. and Yonli, M.

Grifﬁn: Towards Mixed Multi-Key Homomorphic Encryption.

DOI: 10.5220/0012090200003555

In Proceedings of the 20th International Conference on Security and Cryptography (SECRYPT 2023), pages 147-158

ISBN: 978-989-758-666-8; ISSN: 2184-7711

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

147

Table 1: Overview of existing homomorphic encryption protocols and compilers.

Name

Functions Conversion

MKHE

Arithmetic Boolean Arithmetic ←→ Boolean

Cingulata (Carpov et al., 2015) ✗ ✓ ✗ ✗

FHEW (Ducas and Micciancio, 2015) ✗ ✓ ✗ ✗

TFHE (Chillotti et al., 2020) ✗ ✓ ✗ ✗

Transpiler (Gorantala et al., 2021) ✗ ✓ ✗ ✗

Zama (Chillotti et al., 2021) ✗ ✓ ✗ ✗

HElib (Halevi and Shoup, 2014) ✓ ✗ ✗ ✗

HEAAN (Cheon et al., 2017) ✓ ✗ ✗ ✗

CHET (Dathathri et al., 2019) ✓ ✗ ✗ ✗

nGraph-HE (Boemer et al., 2019) ✓ ✗ ✗ ✗

EVA (Dathathri et al., 2020) ✓ ✗ ✗ ✗

SEAL (Microsoft Research, 2020) ✓ ✗ ✗ ✗

(Chielle et al., 2018) ✓ ✓ ✗ ✗

Lattigo (Mouchet et al., 2020) ✓ ✓ ✗ ✗

MKHE-CKKS (Chen et al., 2019b) ✓ ✗ ✗ ✓

MKHE-TFHE (Chen et al., 2019a) ✗ ✓ ✗ ✓

OpenFHE (Al Badawi et al., 2022) ✓ ✓ ✗ ✓

Chimera (Boura et al., 2020) ✓ ✓ ✓ ✗

Pegasus (Lu et al., 2021) ✓ ✓ ✓ ✗

Grifﬁn (This work) ✓ ✓ ✓ ✓

In an orthogonal line of research, Multi-Key

Homomorphic Encryption (MKHE) schemes have

been developed to support operations on ciphertexts

encrypted using different keys (L

opez-Alt et al.,

2012; Chen et al., 2019a; Chen et al., 2019b).

These schemes also provide on-the-ﬂy MPC, where

the circuit to be evaluated can be ﬁxed after the

data providers upload their encrypted data and the

evaluation is non-interactive. However, to the best of

our knowledge, no previous works can switch back

and forth between different MKHE schemes. We

introduce Grifﬁn, the ﬁrst hybrid MKHE framework

that supports SIMD-style arithmetic operations while

simultaneously supporting non-linear functions over

binary circuits.

1.1 Our Contributions

The contributions of this paper are as follows:

• We introduce Grifﬁn, the ﬁrst MKHE scheme that

can evaluate both arithmetic functions and LUTs

on ciphertexts (§4).

• Grifﬁn provides the on-the-ﬂy MPC property,

where the circuit to be evaluated can be ﬁxed after

the data providers upload their encrypted data.

• We introduce a new conversion similar to single-

key Pegasus (Lu et al., 2021) allowing for trans-

formation between MKHE ciphertexts of FHEW

and CKKS (Chen et al., 2019b). This allows

to compute the maximum of two numbers in

3.2 seconds, outperforming the existing solutions

of (Chen et al., 2019b) by ≈ 2× (§5).

• We implement Grifﬁn on top of OpenPEGASUS

which is based on Microsoft SEAL

, and bench-

mark it against other HE solutions, showing its

beneﬁts for different applications.

Tab. 1 provides a comparison of Grifﬁn with pre-

vious works in terms of the features supported.

2 BACKGROUND

We deﬁne our parameters and notation in §2.1 and

provide an overview of the FHE schemes used in

Grifﬁn in §2.2.

2.1 Parameters and Notation

[k] refers to the set containing all non-negative inte-

gers smaller than k, i.e., {i|i ∈ N

,i < k}. We use

to refer to Z/qZ. Let R := Z[X]/(X

+ 1). We

https://github.com/Alibaba-Gemini-Lab/

OpenPEGASUS

https://github.com/Microsoft/SEAL

SECRYPT 2023 - 20th International Conference on Security and Cryptography

148

use R

to refer to A[X]/(X

+ 1). If q is an inte-

ger, we deﬁne R

:= Z

[X]/(X

+ 1). B refers to the

subset of polynomials with binary coefﬁcients of R .

Similarly, B refers to the set {0, 1}. For a ∈ R we

use [a]

to refer to a mod q where coefﬁcients are re-

duced in (q/2, q/2]. We use ⟨·,·⟩ to denote the canon-

ical inner product. Vectors are typically bold such as

a ∈ B

. We refer to the j-th element of a vector with

. We use the notation ct ∈ SCHEME

(m) to ex-

press that ct is a ciphertext obtained by encrypting the

message m with key s in scheme SCHEME with pa-

rameters p. We omit s and p if the parameters and

the key are clear from the context. If χ is a distribu-

tion, then x ← χ expresses that x is sampled from χ.

If A is a set, then x ← A denotes that x is uniformly

randomly sampled from A. An extended RLWE ci-

phertext ct ∈

RLWE(m;g

g) of a message m is deﬁned

by (c

)

i∈[d]

with c

∈RLWE(g

g[i]·m) (Lu et al., 2021).

Ecd refers to the CKKS encoding function.

2.2 FHE Schemes

We differ between Arithmetic schemes, which ei-

ther perform arithmetic over a plaintext space such

as Z/pZ (Fan and Vercauteren, 2012) or ﬁxed point

complex vectors (Cheon et al., 2017), and Binary

schemes, which can evaluate binary gates such as

NAND on binary ciphertexts (Ducas and Miccian-

cio, 2015). Binary schemes are often based on the

Learning With Errors (LWE) assumption, whereas

Arithmetic schemes use the Ring Learning With Er-

rors (RLWE) assumption. LWE Assumption (Regev,

2005). Let n be the LWE dimension, q the cipher-

text modulus, and t ≥ 2 the plaintext modulus. A

key vector s

s ∈ Z

is sampled from a given key dis-

tribution. Let m ∈ Z

be the message that ought to

be encrypted. For each encryption, a vector a

a is uni-

formly randomly sampled from Z

, and a random

error e is sampled from Z

according to the error

distribution. A ciphertext consists of the elements

a,b), where b = ⟨a

a,s

s⟩+ e + ∆m, and ∆ is the scal-

ing factor that depends on the scheme. Commonly

∆ = ⌊

⌉ is used. The LWE assumption states that this

tuple is indistinguishable from a tuple where b is sam-

pled from Z

uniformly at random.

RLWE Assumption (Stehl

e et al., 2009; Lyuba-

shevsky et al., 2010). Let M be an integer based

on the ciphertext modulus and the security parame-

ter. Let R := Z[X]/(Φ

(X)), where Φ

is the M-

th cyclotomic polynomial. Again, let q be the ci-

phertext modulus and t the plaintext modulus. The

key s ∈ R

is generated according to the key distribu-

tion. We encrypt a message m ∈ R

by sampling an

element a ∈ R

uniformly at random and calculating

b = as + m + e.

CKKS (Cheon et al., 2017). The CKKS idea is that

each multiplication consumes a level, and the parame-

ters are generated for a ﬁxed level. So it is only possi-

ble to evaluate functions up to a given maximum mul-

tiplicative depth. A base p is ﬁxed, and a modulus q

is chosen for the plaintext. We deﬁne q

ℓ

= p

ℓ

·q

for

0 < ℓ ≤ L. A ciphertext of level ℓ is a vector in R

ℓ

for ﬁxed k. If binary operations are passed ciphertexts

of different levels, then a rescaling procedure is exe-

cuted to equalize the levels by lowering the level of

the higher ciphertext.

HWT(h) is the set of signed binary vectors in

{0,±1}

with Hamming weight h. DG(σ

) is a dis-

crete Gaussian distribution on Z

with standard de-

viation σ. ZO(p) is the distribution deﬁned over

{0,±1}

, where each element is -1 with probability

p/2, +1 with probability p/2, and 0 with probabil-

ity 1 − p. We sample s ← HWT(h), a ← R

and

e ← DG(σ

) for the key generation. The secret key

sk is set as sk = (1,s) while the public key pk is set

to an encryption of 0. We also generate an evaluation

key, which is the encryption of Ps

for an integer P

that depends on the security parameter and modulus.

In order to encrypt a message m ∈ R

, we sample

v ← ZO(0.5) and (e

) ← DG(σ

). Then output

ct = v ·pk + (m + e

) (mod q

). Decryption con-

sists of outputting b + a ·s mod q

ℓ

for a given cipher-

text (b,a).

FHEW (Ducas and Micciancio, 2015). In FHEW,

a ← Z

and s are chosen uniformly at random or as

short vectors. Instead of using a separate error term,

a randomized rounding function χ : R → Z is used.

Encryption is deﬁned as:

Enc

t/q

(m) = (a

a,χ(⟨a

a,s

s⟩+ mq/t) mod q) ∈ Z

n+1

Decryption is deﬁned as:

Dec

t/q

(ct) = ⌊t(b −⟨a

a,s

s⟩)/q⌉ mod t ∈ Z

= m

′

Another technique that FHEW can use is key switch-

ing. Here, the components of the old key are de-

composed along a basis, and each decomposed part is

encrypted under the new key: k

i, j,v

= Enc

q,q

(vz

)

for i ∈ [n], j ∈ [⌈log

q⌉] and v ∈ [B

]. A

key switch is then performed by ﬁrst calculating

i, j

such that a

∑

i, j

, and then calculating:

KeySwitch((a

a,b),K) = (0

0,b) −

∑

i, j

i, j,a

i, j

, where K

is the set of all k

i, j,v

3 RELATED WORK

In this section, we summarize existing MKHE

schemes and Pegasus (Lu et al., 2021), a conversion

Grifﬁn: Towards Mixed Multi-Key Homomorphic Encryption

149

between single-key FHEW (Ducas and Micciancio,

2015) and CKKS (Cheon et al., 2017).

3.1 MKHE

MKHE schemes allow to perform operations on en-

crypted data under different keys. Thus, each party

can encrypt their data with their key and publish

the ciphertext. An evaluator can perform the de-

sired operations on the ciphertexts, and ﬁnally, the

involved parties can decrypt the ciphertext (Chen

et al., 2019b). Many MKHE schemes have in com-

mon that they require the Common reference string

(CRS) assumption (Chen et al., 2019b; Chen et al.,

2019a). Traditional MPC approaches have commu-

nication that is proportional to the product of the

complexity of the function and the number of par-

ties (Chen et al., 2019b). In contrast, the commu-

nication in MKHE approaches is independent of the

evaluated function. Another advantage is that the par-

ties in Multi-Party Computation (MPC) need to stay

online during the entire protocol execution. More-

over, MKHE approaches are more suitable for out-

sourcing. Some MPC protocols have the data own-

ers secret-share their data with independent servers

who perform the MPC to obtain the result (Mohas-

sel and Zhang, 2017). However, they assume that the

servers do not collude. Bootstrapping and key switch-

ing are also possible in MKHE schemes without inter-

action (Chen et al., 2019b; Chen et al., 2019a).

Relinearization. (Chen et al., 2019b) introduces

two different relinearization techniques for MKHE-

CKKS and MKHE-BFV. The ﬁrst technique (Chen

et al., 2019b, Alg. 1) has higher noise levels but has a

faster scheme compared to the second variant (Chen

et al., 2019b, Alg. 2). The second variant has lower

noise levels and requires less storage. The relineariza-

tion techniques introduced in (Chen et al., 2019a)

for MKHE-TFHE are very similar. We focus on the

second variant since that variant offers higher accu-

racy and has been used for benchmarks in the litera-

ture (Chen et al., 2019b; Chen et al., 2019a).

Let a

a ←R

be the CRS for modulus q and decom-

position degree d. k refers to the number of parties.

The key generation of the public key is slightly mod-

iﬁed. Instead of outputting a single zero encryption,

we output d zero encryptions as the public key. Only

a single zero encryption is needed for normal encryp-

tion. However, the other encryptions are needed for

the relinearization.

KeyGen(p,s) := b

b = −s ·a

a + e

e (mod q) ∈ R

where e

e ← ϕ

for some error distribution ϕ and a

a ←

. The key s is drawn from the key distribution χ as

in the normal single key schemes (Cheon et al., 2017;

Fan and Vercauteren, 2012). This, in turn, allows to

deﬁne a new encryption method that will be used to

generate the new relinearization key:

UniEnc(µ;s) := d

d = [d

] ∈ R

d×3

1. r ← χ, e

← ϕ

and d

← R

2. d

= −s ·d

+ e

+ r ·g

g (mod q)

3. d

= r ·a

a + e

+ µ ·g

g (mod q)

where s is the secret key, q is the modulus and

g is the decomposition vector. The decomposi-

tion vector represents a basis analogously to decom-

position in BFV (Fan and Vercauteren, 2012) and

TFHE (Chillotti et al., 2020). The relinearization key

is then deﬁned as D

D ← UniEnc(s;s).

Arithmetic Operations. Generally, MKHE cipher-

texts store a tuple of the ids of the parties whose secret

key is required to decrypt the current ciphertext (Chen

et al., 2019b). If a binary operation combines two ci-

phertexts whose id tuples are distinct, then the cipher-

texts are expanded prior to the operation. Ciphertexts

will be of the form ct ∈ R

k+1

. Every id is associated

with an index i such that 1 ≤ i ≤ k and ct[i] is mul-

tiplied with the private key of the party with id

dur-

ing decryption. The expansion consists of padding a

ciphertext with zero polynomials at the indices cor-

responding to ids that are only present in the other

ciphertext. This results in a change of the id to index

mapping. An id might be associated with a new in-

dex afterward since both ciphertexts need to have the

same mapping. The addition does not require any spe-

cial treatment aside from a possible expansion. Multi-

plication also shares the ﬁrst phase with the single key

Fully Homomorphic Encryption (FHE) variant. How-

ever, the particular MKHE relinearization method is

applied afterward.

Permutations and Rotations. Permutations use Ga-

lois Automorphisms, just like the single key variant

of the schemes (Chen et al., 2019b, §5.1). However,

since applying a Galois element to a ciphertext also

changes the key of that ciphertext, a key switch to the

original key is performed. Let τ

: a(X ) 7→ (aX

) be a

Galois element. Then we deﬁne:

MKHE.GKGen( j; s) := gk = [h

] ∈ R

d×2

where h

← R

and h

= −s · h

+ e

′

+ τ

(s) · g

(mod q). To apply a Galois element, we then per-

form:

MKHE.EvalGal(ct; {gk

}

1≤i≤k

) := (c

′

,...,c

′

) , where

′

= τ

) +

∑

i=1

⟨g

−1

(τ

)),h

i,0

⟩ (mod q),

SECRYPT 2023 - 20th International Conference on Security and Cryptography

150

′

= ⟨g

−1

(τ

)),h

i,1

⟩ (mod q) for 1 ≤i ≤k.

Distributed Decryption. For decryption, each party

multiplies the index of the ciphertext associated with

their id with their private key and adds noise from a

distribution φ which has a larger variance than ϕ, re-

ducing it mod q and publishes the result (Chen et al.,

2019b). The result can then be obtained by adding all

these shares and by removing the scaling in the case

of BFV (Fan and Vercauteren, 2012).

3.2 Pegasus (Lu et al., 2021)

Different FHE schemes have different strengths and

advantages (Boura et al., 2020; Lu et al., 2021):

on the one hand, CKKS (Cheon et al., 2017) and

BFV (Fan and Vercauteren, 2012) excel at tasks

that involve addition or multiplication and can be

performed in a SIMD-like manner. On the other

hand,TFHE (Chillotti et al., 2020) and FHEW (Ducas

and Micciancio, 2015) might perform better when

parallelization is not possible, the functions involve

many non-linear operations, or when very deep cir-

cuits need to be evaluated. This motivated researchers

to create conversions between different FHE schemes

such as Pegasus (Lu et al., 2021) and Chimera (Boura

et al., 2020). Pegasus (Lu et al., 2021) outperforms

Chimera (Boura et al., 2020) with faster conversions

and smaller keys. Indeed, benchmarks in (Lu et al.,

2021) demonstrated a signiﬁcant speedup compared

to Chimera (Boura et al., 2020). This is the main

reason why we provide a MKHE variant of Pegasus

instead of Chimera in Grifﬁn. The full Pegasus proto-

col merely allows for evaluating a look-up table with

CKKS-ciphertexts. However, this is achieved by con-

verting from CKKS to FHEW, performing the look-

up, and then converting to CKKS. The functionality

of Pegasus can be summarised as follows:

1. Apply the slots to coefﬁcients transformation.

2. Extract all the slots of the ciphertext to obtain

LWE ciphertexts.

3. Evaluate the LUT T (x) on the LWE ciphertexts.

4. Repack the LWE ciphertexts into a RLWE cipher-

text and apply the proper encoding.

Removing the two last steps results in a conversion

from CKKS to FHEW, taking a tuple of LWE ci-

phertexts, and only applying the last step results in

a conversion from FHEW to CKKS. Repacking in-

volves homomorphically performing the partial LWE

decryption, represented as a linear transformation,

and then applying a modular reduction. The following

procedures play an important role for Pegasus and we

later translate them to the MKHE setting in Grifﬁn:

LWE Key Switching. The key switching procedure

allows changing the key of a given ciphertext. It is

possible to change the lattice dimensionality of the

LWE instance. Note that LWE ciphertexts are of the

form (b,a

a). Where b = m + e −⟨a

a,s

s⟩. To obtain a

new encryption, we use encryption of the old key s

under the new key s

′

and homomorphically multiply

it with a

a (Lu et al., 2021). This ciphertext can then be

added to b to obtain encryption of m under s

′

LUT Evaluation. The lookup table (LUT) func-

tion evenly samples a real function at n points in

a bounded interval given by [−q/4∆,q/4∆]. These

sampling points are used as the coefﬁcients of a poly-

nomial. The idea is to rotate the polynomial so that

the constant part of the polynomial corresponds to the

image of the function being evaluated under the given

input. This image is then recovered by performing a

slot extraction (Lu et al., 2021). This is achieved by

ﬁrst performing a modulus switch from q to 2n. Then

we perform an arithmetic operation such that AC

k,n

an encryption of

f ·X

∑

i∈[k]

˜a

f ·X

∆m

. This re-

sults in the desired value being in the constant part of

the polynomial.

Linear Transformation (LT) Evaluation. Tiling

transforms a rectangular matrix into a square matrix

by repeating the matrix itself (Lu et al., 2021). The LT

evaluation algorithm combines tiling with baby step

and giant step to perform matrix multiplication and

then adds the vector t to the result (Lu et al., 2021;

Halevi and Shoup, 2014).

Eval Sine. EvalSine is used to approximate the mod-

ular reduction by q

as part of the repacking process.

There is no need for a special MKHE variant. The

algorithm is taken from (Bossuat et al., 2021).

Slots to Coefﬁcients (S2C). The algorithm S2C takes

a ciphertext in the slot encoding and converts it to a ci-

phertext in the coefﬁcient encoding (Lu et al., 2021).

While doing so, it consumes 1 or 2 slots. No spe-

cial adjustment is needed to move this routine to the

MKHE setting.

Slot Extraction. Given a RLWE ciphertext in the co-

efﬁcient encoding, we can use this procedure to ex-

tract a given coefﬁcient into a LWE ciphertext (Lu

et al., 2021).

4 Grifﬁn

Grifﬁn is capable of switching between different

MKHE schemes and also performing MPC. In Grif-

ﬁn, the dimensions of the ciphertexts increase due to

the MKHE conversion and we require a switching,

evaluation, repacking and rotation key of every party.

We assume the CRS model and require the public

Grifﬁn: Towards Mixed Multi-Key Homomorphic Encryption

151

keys of every party. Additionally, correctness for the

prior multiplication method of the Pegasus LUT pro-

cedure does not hold with MKHE ciphertexts. As a

result, Grifﬁn uses a new multiplication method based

on (Chen et al., 2019a). Most of the Pegasus (Lu et al.,

2021) subroutines do not require any signiﬁcant mod-

iﬁcations to work with MKHE ciphertexts.

Grifﬁn, Full Protocol. Alg. 1 shows the full protocol

of Grifﬁn. It is an extension of the full Pegasus proto-

col (Lu et al., 2021, Fig. 6). The main modiﬁcations

are highlighted in gray.

Grifﬁn LWE Key Switching. Adjusting the Key

Switching (KS) routine from the single-key (Lu et al.,

2021, Fig. 9) to the MKHE setting is fairly straightfor-

ward as shown in Alg. 2. We can simply perform parts

of the routine for every party and sum the result. The

operator ⋄in Alg. 2 refers to a product between an ex-

tended RLWE ciphertext (the key switching key) and

an arbitrary ring element. The ring element is decom-

posed along the same basis as the RLWE ciphertext,

the two decomposed elements are then multiplied

component wise, and all components of the result are

then summed together: r ⋄ct :=

∑

d−1

i=0

−1

(r)[i] ·ct[i].

Grifﬁn LUT Evaluation. Our algorithm for LUT eval-

uation is shown in Alg. 3. This algorithm is an ex-

tension of the LUT evaluation in Pegasus (Lu et al.,

2021, Fig. 2), however it has a wider loop range in

line 5 and line 6 to obtain the correct evaluation key

in Grifﬁn.

Grifﬁn Slot Extraction. Moving the slot extraction

from the single key setting to the MKHE setting is

shown in Alg. 4. It consists of applying the routine

that is performed on a to all the a

Grifﬁn LT Evaluation. The LT algorithm of Grifﬁn

is given in Alg. 5 which is derived from the LT algo-

rithm in Pegasus (Lu et al., 2021, Fig. 5).

Correctness of Grifﬁn. In this section, we show

the correctness of Grifﬁn. Pegasus can be under-

stood as a transformation between the single-key

CKKS (Cheon et al., 2017) and FHEW (Ducas and

Micciancio, 2015) encryption methods. Grifﬁn al-

lows for evaluating a look-up table with MKHE-

FHEW. This is achieved by converting from MKHE-

CKKS to MKHE-FHEW, performing the look-up,

and then converting back to MKHE-CKKS. The func-

tionality of Grifﬁn is analogous to that of Pegasus (Lu

et al., 2021) and can be described as follows: (a)

Apply the slots to coefﬁcients transformation, (b) ex-

tract all slots of the ciphertext to obtain LWE cipher-

texts, (c) perform LUT evaluations on the LWE ci-

phertexts, and (d) repackage the LWE ciphertexts into

an RLWE ciphertext and apply encoding. Omitting

steps (c) and (d) results in a conversion from MKHE-

CKKS to MKHE-FHEW, whereas performing only

step (d) results in a conversion from MKHE-FHEW

to MKHE-CKKS. Repacking involves homomorphi-

cally decrypting the LWE ciphertext, applying a linear

transformation, and performing a modular reduction.

Algorithm 1: Grifﬁn, Full Protocol (modiﬁed from (Lu

et al., 2021, Fig. 6)).

Input: • Ciphertext moduli q

,...,q

L−1

, special mod-

ulus q

′

. Deﬁne Q

= Π

l∈[i]

for 1 ≤i ≤ L.

• CRS: a

• Public keys: {b

}

i∈[k]

• Digit decomposition gadget vector g

digit

[1,B

,...,B

] for some B

> 0 and B

≥ q

• RNS decomposition gadget vector g

rns

= [q

′

mod q

• Rescaling factors 0 < ∆, ∆

,∆

′

< q

• Switching keys SwK

→s

• LWE evaluation keys EK

i, j,0

∈ UniEnc

n,q

′

[ j])),

i, j,1

∈ UniEnc

n,q

′

−

[ j]))

for j ∈ [n], where I

(x) = 1{x ≥ 0} and I

−

(x) =

1{x ≤0} for i ∈ [k].

• Repacking keys RK

∈ RLWE

n,Q

(Ecd(s

,∆

)) for

i ∈[k].

• Rotation keys of the CKKS scheme RotK

for i ∈[k].

• A level-l RLWE ciphertext (l > 1) of an encoded

vector v

v ∈ R

ℓ

, i.e., ct

∈ RLWE

n,Q

i∈[k]

(Ecd(v

v,∆)) for

i ∈[k].

• A look-up table function T (x) : R 7→ R .

Output: A RLWE ciphertext ct

out

∈

RLWE

n,Q

′

}

i∈[k]

(Ecd(T (v

v),∆)), i.e., the evaluation

of T (x) on the elements of v

1: Slots to coefﬁcients and drop moduli: ct

′

= S2C(ct

)

2: Extract Coefﬁcients: ct

= Extract

(ct

′

) for each l ∈ [ℓ]

3: for l ∈ [ℓ] do

4: Switch from n to the smaller dimension

= GRIFFIN.KS(ct

,{SwK

→s

}

i∈[k]

)

5: Evaluate the look-up table.

= GRIFFIN.LUT(

,{EK

}

i∈[k]

,{b

}

i∈[k]

,T (x))

6: Switch from n to n.

...

= (b

l,0

,...,a

l,k−1

) =

GRIFFIN.KS(

,{SwK

→s

}

i∈[k]

)

7: end for

8: Deﬁne b

b = b

,...,b

ℓ−1

and A

∈ Z

ℓ×n

, s.t. the l-th row

of A

is a

l,i

9: for i ∈[k] do

10: Evaluate the linear transform

GRIFFIN.LT(RK

,RotK

,∆

′

11: end for

12:

ct = GRIFFIN.LT(RK

,RotK

,∆

′

b) +

∑

k−1

i=0

13: Evaluate the modulo q

ct via F

mod

and output the

result as ct

out

SECRYPT 2023 - 20th International Conference on Security and Cryptography

152

Algorithm 2: Grifﬁn LWE KS (modiﬁed from (Lu et al.,

2021, Fig. 9)).

Input: A LWE ciphertext (b,{a

}

i∈[k]

) ∈ LWE

n,q

}

i∈[k]

(m).

The LWE switching key of every party:

SwK

i, j

∈

RLWE

n,q

}

i∈[k]

∑

l∈[n]

[ jn +l]X

for j ∈ [n/n].

Output: A LWE ciphertext ct

out

∈ LWE

}

i∈[k]

(m).

1: Deﬁne a set of polynomials {ˆa

i, j

} where ˆa

i, j

= a

[ jn]−

∑

n−1

l=1

[ jn +l]X

n−l

for j ∈ [n/n].

2: Compute

∑

j∈[n/n]

ˆa

i, j

⋄SwK

i, j

∈ R

n,q

3: Output (b,0

0) +

∑

k−1

i=0

Extract

(

) as ct

out

Algorithm 3: Grifﬁn LUT evaluation (modiﬁed from (Lu

et al., 2021, Fig. 2)).

Input: (b,a

a) ∈ LWE

n,q

}

i∈[k]

(⌊∆m⌉) of a message m ∈ R

with a scaling factor ∆ such that |⌊∆m⌉| < q/4. Look-

up table function T (x) : R 7→ R . The evaluation keys

{EK

}

i∈[k]

are a set of Uni-encryptions of the respective

keys s

∈ {0, ±1}

. Public keys of the involved parties

}

i∈[k]

Output: A LWE ciphertext ct

out

∈ LWE

n,q

}

i∈[k]

(·).

1: Let η

= kq/(2n∆) ∈R for 1 ≤k ≤n/2. Deﬁne a poly-

nomial

f ∈ R

n,q

whose coefﬁcients are:











⌊∆T (0)⌉ if j = 0

⌊∆T (−η

)⌉ if 1 ≤ j ≤ n/2

⌊−∆T (η

n−j

)⌉ if n/2 < j < n

b = ⌊

b⌉ and

a = ⌊

a⌉.

3: Initialize AC

= (

f ·X

b mod n

,0) ∈ R

n,q

4: for j ∈ [kn] do

5: t

= ((X

a[ j] mod n

− 1) · AC

) ◦

(EK

⌊j/n⌋, j mod n,0

,{b

}

i∈[k]

) + AC

6: AC

j+1

= ((X

−

[ j] mod n

− 1) · t

) ◦

(EK

⌊j/n⌋, j mod n,1

,{b

}

i∈[k]

) + t

7: end for

8: Extract

(AC

) as ct

out

To show the correctness of Grifﬁn, we show the

correctness of each of its subprocedures. Addition-

ally, we present a lemma that applies to linear trans-

formations generally, rather than the algorithm used

in Pegasus only (Lu et al., 2021).

Lemma 1. Let c be a MKHE-CKKS ciphertext en-

crypting the polynomial m with noise level e and f be

a linear transformation. There exists an efﬁcient algo-

rithm, using only public information, that calculates

′

, a MKHE-CKKS ciphertext encrypting the polyno-

mial f (m) with noise level f (e) + e

, where e

is the

noise added by the evaluation of the linear transform.

Algorithm 4: Grifﬁn Slot Extraction.

Input: A MKHE-RLWE ciphertext that uses the coefﬁ-

cient encoding: ct ∈ RLWE

n,Q

(m). The coefﬁcient to

extract j.

Output: A MKHE-LWE ciphertext ct

′

∈ LWE

n,Q

1: Let ct = (

∑

n−1

l=0

∑

n−1

l=0

0,l

,...,

∑

n−1

l=0

k−1,l

2: return

′

= (b

0, j

0, j−1

,...,a

0,0

,−a

0,n−1

,...,−a

0, j+1

1, j

1, j−1

,...,a

1,0

,−a

1,n−1

,...,−a

1, j+1

,...

k−1, j

k−1, j−1

,...,a

k−1,0

,−a

k−1,n−1

,...,−a

k−1, j+1

Algorithm 5: Grifﬁn LT evaluation (modiﬁed from (Lu

et al., 2021, Fig. 5)).

Input: ct

∈ RLWE

n,q

}

i∈[k]

(Ecd(z

z,∆

)). Rotation keys

RotK

. A scaling factor ∆

′

> 0. A plain matrix M

M ∈

ℓ×n

such that ℓ,n < n. A vector t

t ∈ R

ℓ

Output: A RLWE ciphertext ct

out

∈ RLWE

n,q/∆

}

i∈[k]

(m).

1: Tiling and Diagonals. Let ¨n = max(ℓ,n) and ˜n =

min(ℓ,n). Deﬁne ˜n vectors { ˜m

}

˜n−1

j=0

by going through

the rows and columns of M

[r] = M

M[r mod ℓ,r + j mod n] for r ∈ [ ¨n].

2: Baby-Step. Let ˜g =



√

˜n



. For g ∈ [ ˜g], compute c

RotL

(ct

3: Giant-Step. Let

b =

⌈

˜n/ ˜g

⌉

. Compute

ct =

∑

b∈[

RotL

b ˜g



∑

g∈[ ˜g]

Ecd(

b ˜g+g

≫ b ˜g,∆

′

) ·c



4: if ℓ ≥ n then

5: Output Rescale(

ct,∆

) + Ecd(t

t,∆

′

) as ct

out

6: else

7: Let γ = log(n/ℓ) and ct

ct.

8: Update iteratively for 1 ≤ j ≤ γ

= RotL

ℓ2

(ct

j−1

) + ct

j−1

9: Output Rescale(ct

,∆

) + Ecd(t

t,∆

′

) as ct

out

10: end if

Proof. It has been established in previous research

that rotations can be homomorphically evaluated on

MKHE ciphertexts (Chen et al., 2019b). Additionally,

it has been shown that linear transformations can be

efﬁciently represented as a combination of rotations,

constant products, and additions, as outlined in (Han

et al., ). Given that all the basic operations required

to evaluate a linear transformation can also be applied

to an MKHE-ciphertext, it can be inferred that an al-

gorithm for homomorphically evaluating linear trans-

formations on MKHE-ciphertexts must exist.

Corollary 1. The single key variant of the Slot-

sToCoefﬁcients (S2C) transformation can be adapted

Grifﬁn: Towards Mixed Multi-Key Homomorphic Encryption

153

to a MKHE variant by replacing all the basic op-

erations with their MKHE equivalents. In other

words, the S2C transformation can be transformed

into a MKHE-variant by applying the corresponding

MKHE counterparts of the primitive operations used

in the single key variant.

From Lemma 1, we can deduce Corollary 1,

which states that the SlotsToCoefﬁcients (S2C) trans-

formation corresponds to a linear transformation, as

previously established in (Han et al., ). This is also

the approach used for the implementation of MKHE

variant of S2C. The single key variant of S2C was

modiﬁed by replacing each primitive operation with

its corresponding MKHE equivalent. As the effect of

these operations on the encrypted message is identi-

cal, it follows that the resulting ciphertext utilizes a

coefﬁcient encoding rather than a slots encoding.

Lemma 2. Let c be a MKHE-CKKS ciphertext en-

crypting N coefﬁcients, v

,...v

N−1

under the keys

,...s

). There exists an efﬁcient algorithm that

given an integer p ∈ [N − 1], produces a MKHE-

FHEW ciphertext that encrypts v

under the keys

′

,...,s

′

), where s

′

is the coefﬁcient vector corre-

sponding to the polynomial s

Proof. Alg. 4 is an example of such an algorithm.

Let c = ({a

}

i∈[k]

,b) be the input ciphertext and c

′

({a

′

}

i∈[k]

′

). First, we use the p-th coefﬁcient of the

polynomial b to obtain b

′

. Just as in (Chillotti et al.,

2020) we use antiperiodic indexes. Let N be the de-

gree of the polynomial. a

′

i, j

shall refer to the j-th co-

efﬁcient of a

′

. a

′

i, j

is set to the (p − j)-th coefﬁcient

of a

. Since we are using antiperiodic indexes, a neg-

ative index corresponds to the additive inverse of the

respective coefﬁcient. For example, −2 would corre-

spond to the additive inverse of the (N −2)-th coefﬁ-

cient. This is a consequence of the assumption that we

are using cyclotomic polynomials of the form X

+1.

Simple arithmetic shows that this method results in an

′

= (a

′

i,0

,...,a

′

i,n−1

) such that ⟨a

′

⟩ = (a

)

. That

is, the inner product corresponds to the p-th coefﬁ-

cient of the product of the two polynomials. It follows

that we obtain a correct MKHE-LWE encryption of v

without any additional noise.

Lemma 3. The MKHE variant of the LWE KS

(Alg. 2) is a correct key switching procedure. That

is, given a FHEW-MKHE ciphertext of dimension n,

c encrypted by the keys s

and a tuple of key switch

keys (SwK)

, the procedure outputs a FHEW-MKHE

ciphertext c

′

of dimension n

′

encrypted by the keys s

′

for i ∈ [k]. We assume

′

> 1 .

Proof. First, we observe that the key switch key of

party i is an extended RLWE encryption of the LWE

secret key s

. This RLWE instantiation uses a cy-

clotomic polynomial of degree n

′

. The elements of

the LWE secret key vector are interpreted as coefﬁ-

cients of a polynomial. A single polynomial will not

be able to contain all of the key elements, therefore

there are ⌈n/n

′

⌉-many. The LWE KS algorithm intro-

duced in (Lu et al., 2021) homomorphically computes

the inner product of a

and s

and adds the result to

b of the input. This corresponds to a homomorphic

partial decryption. A full decryption (i.e., bootstrap-

ping) would be followed by a modular reduction. Our

MKHE variant homomorphically computes this inner

product for every party and then adds the sum of these

ciphertexts to the b of the input. This again is a par-

tial decryption, which follows from the deﬁnition of

MKHE decryption.

A crucial algorithm in Grifﬁn is the LUT evalu-

ation. In the single key case, this algorithm utilizes

RGSW ciphertexts, which cannot be easily combined

with MKHE ciphertexts. A possible solution is to

replace the RGSW encryption of the evaluation key

with the Uni-encryption method outlined in (Chen

et al., 2019b). This allows for the use of one of

the multiplication algorithms previously introduced,

to evaluate the LUT table.

Lemma 4. Alg. 3 evaluates a LUT on a MKHE-LWE

ciphertext.

Proof. First, we observe that the idea behind the sin-

gle key LUT evaluation is to encode each possible

image of the LUT as a coefﬁcient in the polynomial

f . We then calculate X

b+ ˆas

≈ X

2nm/q

. The polyno-

mial coefﬁcients of

f are chosen such that the follow-

ing slot extraction extracts the correct coefﬁcient with

the correct value. The reasoning behind the MKHE

variant is similar. We calculate X

∑

i=1

ˆa

≈ X

2nm/q

This multiplication of a MKHE ciphertext with a uni-

encryption by a single party is identical to the usage

of the algorithm in (Chen et al., 2019a).

The correctness of the LT evaluation follows

straightforwardly from Lemma 1. The ﬁnal part is

the modular reduction.

Lemma 5. MKHE-F-Mod correctly evaluates the

modular reduction on a RLWE-MKHE ciphertext.

Proof. We obtain MKHE-F-Mod by replacing the

primitive operations of F-Mod in (Bossuat et al.,

2021) with their MKHE counterparts. Since the mod-

iﬁcations of the encoded message are identical it fol-

lows that the reduction is applied properly.

Theorem 4.1. Grifﬁn is a correct MKHE instantia-

tion of the Pegasus (Lu et al., 2021).

SECRYPT 2023 - 20th International Conference on Security and Cryptography

154

Proof. This follows from Corol-

lary 1, Lemma 1, Lemma 2, Lemma 3, Lemma 4 and

Lemma 5.

Security of Grifﬁn. The security of the Grifﬁn

scheme can be analyzed with relative ease due to the

fact that the evaluator does not have access to any pri-

vate information. The evaluator is only able to access

public information, which simpliﬁes the task of prov-

ing the security of the scheme to demonstrating that

this public information does not reveal any sensitive

information. To achieve this, we will demonstrate that

all public information is indistinguishable from ran-

domly generated data. Our scheme relies on the LWE,

RLWE, CRS and circular security assumptions.

We will divide the analysis into two distinct

phases:

• The setup phase, during which all keys and en-

crypted inputs are published.

• The decryption phase, during which ciphertexts

are decrypted.

The setup phase in particular, involves public mate-

rial from the MKHE-CKKS and the MKHE-FHEW

schemes, as well as new material from the Grifﬁn

keys. We will only prove the security of the new ma-

terial, as the security of the other material has already

been established in (Chen et al., 2019b) and (Chen

et al., 2019a). The decryption phase is equivalent

to the decryption phase of the MKHE schemes and

as such, does not require any special treatment. We

only focus on the RKWE swtiching keys, needed

for MKHE-LWE key switching, and repacking key,

needed for the MKHE-repacking operation, as the

rest are either present in MKHE-CKSS (Chen et al.,

2019b) or are variants of (Chen et al., 2019a) present

in MKHE-FHEW.

Lemma 6. The RLWE switching key is indistin-

guishable from a randomly generated ciphertext of the

same size under the RLWE assumption and the circu-

larity assumption.

Proof. We observe that the MKHE-RLWE switching

key of one party is identical to the switching key in

the single key instantiation. This in turn is a tuple of

RLWE encryptions of the LWE key. This is secure if

we combine the RLWE and circularity assumptions.

Lemma 7. The repacking key is indistinguishable

from a randomly generated ciphertext of the same size

under the RLWE assumption and the circularity as-

sumption.

Proof. The argument follows the same line of reason-

ing as in the previous Lemma 6. The repacking key

is the collection of the party’s single-key repacking

key, which is a RLWE encryption of the LWE key.

Combining the RLWE and the circularity assumption

again results in the proof.

Theorem 4.2. Grifﬁn is secure against semi-honest

adversaries under the LWE assumption.

Proof. This follows from combining the results of

(Chen et al., 2019b), (Chen et al., 2019a) with

Lemma 6 and Lemma 7.

5 EVALUATION

In this section, we present several applications of

Grifﬁn. We primarily compare the runtime of the ap-

plications with single-key Pegasus (Lu et al., 2021) to

show the overhead of our modiﬁcations.

Optimizations. Our implementation uses various op-

timisations, including the Residue Number System

(RNS) representation (Chen et al., 2019b), the special

modulus technique (Gentry et al., 2012), and seeded

ciphertexts (Joye, 2022).

Selecting Parameters. For the benchmarks we use

the same parameters as Pegasus (Lu et al., 2021). We

use binary keys rather than trinary keys because the

implementation only supports binary keys. Tab. 2

shows the parameters that are used in Pegasus (Lu

et al., 2021). We use these parametes for the mi-

crobenchmarking in Grifﬁn.

Table 2: Parameters used in Pegasus (Lu et al., 2021). n is

the lattice dimensions, q

′

the special modulus, q

∗

a modulus

prime used for the Residue Number System (RNS), σ

∗

the

standard deviation of the noise distribution, B

and d

are

parameters for the digit decomposition, Q is the modulus.

Encryption Parameters

RLWE

n,q

(·), level 0 n = 2

≈ 2

,σ

= 2

= 7

RGSW

n,q

′

(·), level 1 n = 2

′

≈ 2

,σ

lut

= 2

RLWE

n,∗

(·), level 2 n = 2

≈ 2

,σ

ckks

= 3.19,log Q = 795

Communication Cost. Grifﬁn requires communica-

tion only during the setup and the decryption phase.

Setup Phase: The per party communication for the

setup phase is independent of the number of parties.

It also merely depends on the number of levels of the

CKKS scheme and not on the depth of the circuit.

The repacking procedure resets the number of levels

and can thus be used to evaluate circuits whose multi-

plicative depth exceeds the number of levels. Gener-

ally, lower levels offer a better runtime for primitive

operations, but this might come at the cost of more

frequent repacking. Repacking itself also introduces

Grifﬁn: Towards Mixed Multi-Key Homomorphic Encryption

155

a minimum number of levels, since it consumes lev-

els. Our Grifﬁn implementation requires 9 levels for

repacking.

Decryption Phase: For decryption, each party re-

ceives part of the ciphertext from the evaluator. This

part has a size of n log

) bits per party. Note that

we are assuming that the ciphertext is at its lowest

level. Even if the computation did not consume all

levels, the evaluator can reduce the levels in order to

reduce communication. This part is also unaffected

by the seeded optimization. Afterwards, the party per-

forms its computation and sends a polynomial with

the same size back. The total communication per

party for the decryption phase is thus 2n log

) bits

per ciphertext.

Since the communication costs only depend on the

number of ciphertexts and the parameters, we can cal-

culate them without a speciﬁc application in mind.

Tab. 3 shows per party communication costs for Grif-

ﬁn and Pegasus considering Pegasus parameters (cf.

Tab. 2). As Tab. 3 shows, communication per party for

an application that requires each party to contribute a

ciphertext is 3.86 GB and 2.08 GB with the seeded ci-

phertexts optimization (Joye, 2022). If the evaluator

has downloaded the public material of the involved

parties in the past, then this communication can be

reduced to 12.42 MB or 6.21 MB with the seeded ci-

phertexts optimization. A single ciphertext can con-

tain 2

slots and thus the amortized ciphertext size

(i.e., ciphertext size divided by number of slots) with

the seeded ciphertexts optimization is 199 bytes. This

corresponds to 35 ciphertext bits per plaintext bit with

this optimization.

Microbenchmarks. Tab. 4 shows the comparison of

different operations of our MKHE framework Grifﬁn

with single-key Pegasus framework (Lu et al., 2021).

Note that Pegasus only supports a single party.

Sorting with Grifﬁn. Similar to Pegasus (Lu et al.,

2021), we use bitonic sorting (Batcher, 1968) which

is data independent and can be parallelized easily. In

order to implement this sorting, we approximate the

min and max functions with LUTs.

min(a,b) := 0.5(a + b) −0.5|a −b|,

max(a,b) := 0.5(a + b) + 0.5|a −b|.

Tab. 5 shows the performance results of Grifﬁn in

comparison with Pegasus (Lu et al., 2021).

Maximum of Two Numbers with Grifﬁn. A pure

MKHE-CKKS circuit that obtains the maximum of

two numbers has 27 levels to reach an accuracy com-

parable to the MKHE-FHEW implementation (Cheon

et al., 2019). The MKHE-CKKS approach to cal-

culating the maximum is similar to the approach

Table 3: Communication Costs for Pegasus Parameters

in Grifﬁn. SCO denotes seeded ciphertexts optimiza-

tion (Joye, 2022). PK

is the public key of level i, SwK

is a switching key, EK is the LUT evaluation key, RepackK

is the repacking key, RotK is the rotation key, RelinK is

the relinearization key of level 2, Input CT is the size of a

fresh ciphertext, and output CT is the communication for

decrypting one ciphertext. The column of seeded optimiza-

tion is marked with ✗ if the optimisation cannot be applied.

Key Size Size with SCO

105 MB ✗

105 KB ✗

SwK

s→s

4.92 MB 2.46 MB

SwK

s→s

315 KB 157.5 KB

EK 315 MB 210 MB

RepackK 12.42 MB 6.21 MB

RotK 3.11 GB 1.55 GB

RelinK 298.13 MB 198.75 MB

Input CT 12.42 MB 6.21 MB

Output CT 11.5 KB ✗

Total 3.86 GB 2.08 GB

Table 4: Runtime comparison of Grifﬁn with Pegasus (Lu

et al., 2021). LUT refers to a LUT evaluation and KS to a

keyswitch. S2C is the slots to coefﬁcients transformation,

LT the linear transformation routine, and Mod the modular

reduction.

Pegasus (Lu et al., 2021) Grifﬁn (Ours)

Operation 1 Party 1 Party 2 Parties 4 Parties

1 slot

KS(s →s) 20ms 18ms 37ms 76ms

KS(s →s) 1.5ms 1.3ms 2.5ms 4.9ms

LUT 0.93s 1.2s 2.96s 8.51s

256 slots

S2C 0.78s 0.41s 0.76s 1.48s

LT 16.76s 15.4s 30.94s 62.55s

Mod 7.06s 13.6s 35.41s 108.26s

1024 slots

S2C 1.28s 0.65s 1.21s 2.39s

LT 44.50s 42.9s 86.14s 174.00s

Mod 7.06s 13.35s 35.06s 107.72s

4096 slots

S2C 2.02s 0.97s 1.88s 3.67s

LT 44.65s 43.32s 87.09s 175.84s

Mod 7.06s 13.43s 35.03s 107.57s

outlined above, except that the LUT for calculating

0.5|x| is replaced by sqrt(x

). Most of the layers are

consumed by approximating the sqrt function. Grifﬁn

replaces the LUT for 0.5|x| with a plaintext multipli-

cation in CKKS. The algorithm halves the CKKS ci-

phertext, converts it to two FHEW ciphertext and then

proceeds to use a single LUT for |x|. The parameters

for the benchmark are slightly adjusted from Tab. 2.

Tab. 6 shows that Grifﬁn has the lowest runtime

compared to pure MKHE-CKKS (Chen et al., 2019b)

and MKHE-FHEW. All benchmarks involved two

parties. MKHE-CKKS uses (Cheon et al., 2019) with

SECRYPT 2023 - 20th International Conference on Security and Cryptography

156

Table 5: Runtimes for sorting (Batcher, 1968) with two par-

ties in Grifﬁn.

Elements Threads Pegasus (Lu et al., 2021) 1 party This work 2 parties

32 20 34s 187s

16 38s 186s

8 73s 293s

4 149s 476s

1 493s 1441s

64 20 84s 458s

16 104s 457s

8 200s 748s

4 409s 1277s

1 1381s 4062s

a total depth of 15. MKHE-FHEW uses Pegasus (Lu

et al., 2021) and Grifﬁn combines MKHE-CKKS op-

erations with MKHE-FHEW operations.

Table 6: Runtimes for calculating the maximum of two

numbers among two parties.

Scheme Time Avg. Err. [%] Max. Err. [%]

MKHE-CKKS (Chen et al., 2019b) 17.54s 2.00 4.28

MKHE-FHEW 5.91s 0.11 0.32

Grifﬁn (Ours) 3.21s 0.17 0.50

6 CONCLUSION AND FUTURE

WORK

We presented Grifﬁn, a new MKHE scheme that can

convert between different MKHE schemes depending

on the function that needs to be evaluated. Grifﬁn

satisﬁes the on-the-ﬂy property, i.e., it requires no

interaction for converting from one MKHE scheme

to another. To the best of our knowledge, this is the

ﬁrst time that a MKHE scheme with such properties

has been constructed. As future work, we intend to

expand the capabilities of Grifﬁn by incorporating

other MPC protocols like FLUTE (Br

uggemann

et al., 2023). Furthermore, we aim to explore the

potential beneﬁts of hardware acceleration (M

unch

et al., 2021) and synthesis tools (Patra et al., 2021b;

Heldmann et al., 2021) in the context of Grifﬁn.

ACKNOWLEDGEMENTS

This project received funding from the ERC under the

European Union’s Horizon 2020 research and innova-

tion program (grant agreement No. 850990 PSOTI).

It was co-funded by the DFG within SFB 1119

CROSSING/236615297 and GRK 2050 Privacy &

Trust/251805230.

REFERENCES

Al Badawi, A., Bates, J., Bergamaschi, F., Cousins, D. B.,

Erabelli, S., Genise, N., Halevi, S., Hunt, H., Kim,

A., and Lee, Y. (2022). OpenFHE: Open-source fully

homomorphic encryption library. In WAHC.

Batcher, K. E. (1968). Sorting Networks and Their Appli-

cations. In American Federation of Information Pro-

cessing Societies.

Boemer, F., Cammarota, R., Demmler, D., Schneider, T.,

and Yalame, H. (2020). MP2ML: A Mixed-Protocol

Machine Learning Framework for Private Inference.

In ARES.

Boemer, F., Lao, Y., Cammarota, R., and Wierzynski, C.

(2019). nGraph-HE: A Graph Compiler for Deep

Learning on Homomorphically Encrypted Data. In

ACM International Conference on Computing Fron-

tiers.

Bossuat, J.-P., Mouchet, C., Troncoso-Pastoriza, J., and

Hubaux, J.-P. (2021). Efﬁcient Bootstrapping for

Approximate Homomorphic Encryption with Non-

Sparse Keys. In EUROCRYPT.

Boura, C., Gama, N., Georgieva, M., and Jetchev, D.

(2020). Chimera: Combining Ring-LWE-based Fully

Homomorphic Encryption Schemes. Journal of Math-

ematical Cryptology.

Brakerski, Z., Gentry, C., and Vaikuntanathan, V. (2014).

(Leveled) Fully Homomorphic Encryption without

Bootstrapping. In ACM Transactions on Computation

Theory.

uggemann, A., Hundt, R., Schneider, T., Suresh, A., and

Yalame, H. (2023). FLUTE: Fast and Secure Lookup

Table Evaluations. In IEEE S&P.

Carpov, S., Dubrulle, P., and Sirdey, R. (2015). Armadillo:

A Compilation Chain for Privacy Preserving Applica-

tions. In International Workshop on Security in Cloud

Computing.

Chen, H., Chillotti, I., and Song, Y. (2019a). Multi-Key Ho-

momorphic Encryption from TFHE. In ASIACRYPT.

Chen, H., Dai, W., Kim, M., and Song, Y. (2019b). Efﬁcient

Multi-Key Homomorphic Encryption with Packed Ci-

phertexts with Application to Oblivious Neural Net-

work Inference. In CCS.

Cheon, J. H., Kim, A., Kim, M., and Song, Y. (2017).

Homomorphic Encryption for Arithmetic of Approxi-

mate Numbers. In ASIACRYPT.

Cheon, J. H., Kim, D., Kim, D., Lee, H. H., and Lee, K.

(2019). Numerical Method for Comparison on Ho-

momorphically Encrypted Numbers. In ASIACRYPT.

Chielle, E., Mazonka, O., Gamil, H., Tsoutsos, N. G., and

Maniatakos, M. (2018). E3: A Framework for Com-

piling C++ Programs with Encrypted Operands. Cryp-

tology ePrint Archive.

Chillotti, I., Gama, N., Georgieva, M., and Izabach

ene, M.

(2020). TFHE: Fast Fully Homomorphic Encryption

over The Torus. JoC.

Chillotti, I., Joye, M., and Paillier, P. (2021). Programmable

Bootstrapping Enables Efﬁcient Homomorphic Infer-

ence of Deep Neural Networks. In CSCML.

Grifﬁn: Towards Mixed Multi-Key Homomorphic Encryption

157

Dathathri, R., Kostova, B., Saarikivi, O., Dai, W., Laine, K.,

and Musuvathi, M. (2020). EVA: An Encrypted Vec-

tor Arithmetic Language and Compiler for Efﬁcient

Homomorphic Computation. In PLDI.

Dathathri, R., Saarikivi, O., Chen, H., Laine, K., Lauter,

K., Maleki, S., Musuvathi, M., and Mytkowicz, T.

(2019). CHET: An optimizing compiler for fully-

homomorphic neural-network inferencing. In PLDI.

Ducas, L. and Micciancio, D. (2015). FHEW: Bootstrap-

ping Homomorphic Encryption in Less than A Sec-

ond. In EUROCRYPT.

Fan, J. and Vercauteren, F. (2012). Somewhat Practical

Fully Homomorphic Encryption. Cryptology ePrint

Archive. https://eprint.iacr.org/2012/144.

Fereidooni, H., Marchal, S., Miettinen, M., Mirhoseini, A.,

ollering, H., Nguyen, T. D., Rieger, P., Sadeghi, A.-

R., Schneider, T., Yalame, H., and Zeitouni, S. (2021).

SAFELearn: Secure Aggregation for Private FEder-

ated Learning. In DLS@S&P.

Gehlhar, T., Marx, F., Schneider, T., Suresh, A., Wehrle,

T., and Yalame, H. (2023). SAFEFL: MPC-friendly

Framework for Private and Robust Federated Learn-

ing. In DLSP@S&P.

Gentry, C., Halevi, S., and Smart, N. P. (2012). Homomor-

phic Evaluation of the AES Circuit. In CRYPTO.

Goldreich, O., Micali, S., and Wigderson, A. (1987). How

to Play ANY Mental Game. In STOC.

Gorantala, S., Springer, R., Purser-Haskell, S., Lam, W.,

Wilson, R., Ali, A., Astor, E. P., Zukerman, I., Ruth,

S., Dibak, C., Schoppmann, P., Kulankhina, S., and

Forget, A. (2021). A General Purpose Transpiler for

Fully Homomorphic Encryption. Cryptology ePrint

Archive. https://eprint.iacr.org/2021/811.

Halevi, S. and Shoup, V. (2014). Algorithms in HElib. In

CRYPTO.

Han, K., Hhan, M., and Cheon, J. H. Improved Homomor-

phic Discrete Fourier Transforms and FHE Bootstrap-

ping. IEEE Access.

Hegde, A., M

ollering, H., Schneider, T., and Yalame, H.

SoK: Efﬁcient Privacy-preserving Clustering. PETS,

2021.

Heldmann, T., Schneider, T., Tkachenko, O., Weinert, C.,

and Yalame, H. (2021). LLVM-based Circuit Compi-

lation for Practical Secure Computation. In ACNS.

Joye, M. (2022). Guide to Fully Homomorphic Encryption

over the [Discretized] Torus. In TCHES.

Juvekar, C., Vaikuntanathan, V., and Chandrakasan, A.

(2018). GAZELLE: A Low Latency Framework for

Secure Neural Network Inference. In USENIX Secu-

rity.

Keller, H., M

ollering, H., Schneider, T., and Yalame, H.

(2021). Balancing Quality and Efﬁciency in Private

Clustering with Afﬁnity Propagation. In SECRYPT.

opez-Alt, A., Tromer, E., and Vaikuntanathan, V. (2012).

On-the-ﬂy Multiparty Computation on The Cloud via

Multi-Key Fully Homomorphic Encryption. In STOC.

Lou, Q., Feng, B., Fox, G. C., and Jiang, L. (2020). Glyph:

Fast and Accurately Training Deep Neural Networks

on Encrypted Data. In NeurIPS.

Lu, W.-j., Huang, Z., Hong, C., Ma, Y., and Qu, H. (2021).

Pegasus: Bridging Polynomial and Non-polynomial

Evaluations in Homomorphic Encryption. In IEEE

S&P.

Lyubashevsky, V., Peikert, C., and Regev, O. (2010). On

Ideal Lattices and Learning with Errors over Rings.

In EUROCRYPT.

McMahan, B., Moore, E., Ramage, D., Hampson, S., and

y Arcas, B. A. (2017). Communication-Efﬁcient

Learning of Deep Networks from Decentralized Data.

In AISTATS.

Microsoft Research (2020). Microsoft SEAL. https:

//github.com/Microsoft/SEAL. Microsoft Research,

Redmond, WA.

Mishra, P., Lehmkuhl, R., Srinivasan, A., Zheng, W., and

Popa, R. A. (2020). Delphi: A Cryptographic Infer-

ence Service for Neural Networks. In USENIX Secu-

rity.

Mohassel, P. and Zhang, Y. (2017). SecureML: A System

for Scalable Privacy-Preserving Machine Learning. In

IEEE S&P.

Mouchet, C., Bossuat, J.-P., Troncoso-Pastoriza, J., and

Hubaux, J.-P. (2020). Lattigo: A Multiparty Homo-

morphic Encryption Library in Go. In WAHC.

unch, J.-P., Schneider, T., and Yalame, H. (2021). VASA:

Vector AES Instructions for Security Applications. In

ACSAC.

Nguyen, T. D., Rieger, P., Chen, H., Yalame, H., M

ollering,

H., Fereidooni, H., Marchal, S., Miettinen, M., Mirho-

seini, A., Zeitouni, S., Koushanfar, F., Sadeghi, A.-

R., and Schneider, T. (2022). FLAME: Taming Back-

doors in Federated Learning. In USENIX Security.

Patra, A., Schneider, T., Suresh, A., and Yalame, H.

(2021a). ABY2.0: Improved Mixed-Protocol Secure

Two-Party Computation. In USENIX Security.

Patra, A., Schneider, T., Suresh, A., and Yalame, H.

(2021b). SynCirc: Efﬁcient Synthesis of Depth-

Optimized Circuits for Secure Computation. In IEEE

HOST.

Regev, O. (2005). On Lattices, Learning with Errors, Ran-

dom Linear Codes, and Cryptography. In STOC.

Riazi, M. S., Weinert, C., Tkachenko, O., Songhori, E. M.,

Schneider, T., and Koushanfar, F. (2018). Chameleon:

A Hybrid Secure Computation Framework for Ma-

chine Learning Applications. In AsiaCCS.

Schneider, T., Suresh, A., and Yalame, H. (2023). Com-

ments on “Privacy-Enhanced Federated Learning

Against Poisoning Adversaries. IEEE TIFS.

Stehl

e, D., Steinfeld, R., Tanaka, K., and Xagawa, K.

(2009). Efﬁcient Public Key Encryption Based on

Ideal Lattices. In ASIACRYPT.

Yao, A. C.-C. (1986). How to generate and exchange se-

crets. In FOCS.

SECRYPT 2023 - 20th International Conference on Security and Cryptography

158
