Using Untrusted and Unreliable Cloud Providers to Obtain Private Email

Nicolas Chiapputo

, Yvo Desmedt

and Kirill Morozov

Independent Researcher, U.S.A.

Department of Computer Science, The University of Texas at Dallas, U.S.A.

Department of Computer Science and Engineering, University of North Texas, U.S.A.

Keywords:

Cloud Security, Email Security, Secret Sharing, Perfectly Secure Message Transmission.

Abstract:

A recent trend for organizations is to shift to cloud services which typically include email. As a result, the

natural privacy concerns for users stem not only from outside attackers, but from insiders as well. Our solution

does not rely on unproven assumptions and does not need a PKI. To achieve this, we partially rely on concepts

from Private and Secure Message Transmission protocols, which are built on top of secret sharing. This

technology allows us to distribute trust over email providers. Hence, the system remains secure as long as

hackers are unable to penetrate a threshold number of providers, or this set of providers does not form a

coalition to attack their users. The prototype of our proposed system has been implemented as an add-on

for the Thunderbird email client, using Mozilla’s Web Crypto API and Rempe’s secret.js library. It currently

supports the following secret sharing schemes: the 2-out-2 additive scheme (set as a default), the k-out-n

threshold Shamir scheme, and the Rabin and Ben-Or robust scheme.

1 INTRODUCTION

Previously, public and private organizations, such as

universities and companies, used to maintain their

own email services. In recent years, we see a trend for

these organizations to shift their computer system op-

erations to the cloud. Private users have also utilized

web-based email services since the 1990s. All this

time, concerns for the user data privacy were growing,

and webmail-related data breaches kept resurfacing in

the recent years with alarming frequency.

For decades, email protection efforts were mainly

limited to prevailing forms of encryption provided

by the software such as PGP and its genus. How-

ever, these encryption techniques rely on unproven

assumptions, i.e., on hardness of the computational

aspects of some mathematical problems.

In this paper, we propose a different approach

to email security which partly relies on techniques

underlying Private and Secure Message Transmis-

sion (PSMT), namely the secret sharing technology.

Roughly speaking, this allows us to distribute trust

over several email providers.

Secret sharing is one of the cornerstones of theo-

retical cryptography. It uses shares such that a partic-

ular number of these, called the threshold, will be re-

quired to recover the message. At the same time, any

number of shares below the threshold will reveal no

information about the message, in the strongest sense

(called unconditional security). Known to mathemati-

cians as a mechanical problem (Liu, 1968), secret

sharing was realized in the digital world by Blakley

(Blakley, 1979) and Shamir (Shamir, 1979) (indepen-

dently) in 1979. This technology is well tested by

time. In particular, it was proposed to secure the

launching of nuclear missiles since the 1980s (Sim-

mons, 1990, p. 437).

When secret sharing is applied to email security,

we assume that the receiver has e-mail addresses with

different providers. An email message will be “split”

into several shares each to be sent over a different

provider. This way, the need for key management will

be eliminated, and hence the Public-Key Infrastruc-

ture (PKI) will not be required.

1.1 Related Works

Although the works by Shamir (Shamir, 1979) and

Blakley (Blakley, 1979) are very extensively cited,

they are quite rarely used in industrial applications

as stand-alone primitives. The only closely related

work, which the authors are aware of, is the report by

Oren and Wool (Oren and Wool, 2009) which used se-

cret sharing in a similar email security setting. Their

Chiapputo, N., Desmedt, Y. and Morozov, K.

Using Untrusted and Unreliable Cloud Providers to Obtain Private Email.

DOI: 10.5220/0012090700003555

In Proceedings of the 20th International Conference on Security and Cryptography (SECRYPT 2023), pages 171-182

ISBN: 978-989-758-666-8; ISSN: 2184-7711

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

171

work is different from ours in that they used only 2-

out-of-2 secret sharing and did not implement a ro-

bust scheme (hence not providing data integrity). At

the same time, they introduced a linguistic encod-

ing which makes both of the secret-shared messages

meaningful.

This lack of interest by the industry is quite re-

markable in the light of a straightforward applica-

tion to protection of cloud storage with unconditional

security—see, e.g., (Attasena and Harbi, 2017; ?) for

surveys of the literature on this topic.

1.2 Our Contribution

The proposed system is implemented as an add-on to

the Thunderbird email client, and it is made avail-

able via Github (git, 2022). The code is written

in Javascript using Mozilla’s Web Crypto API (web,

2021b) and Rempe’s secret.js library (Rempe, 2019).

The add-on uses a modular design, which allows a

ﬂexible setting of the number of supported e-mail

providers, the number of untrusted providers to be tol-

erated, as well as other security parameters. The add-

on has an option of automatic deletion of the mes-

sage copies (shares) on the email provider servers,

further lowering the chances for unauthorized access.

It is guaranteed that the email messages are protected

against access by an unauthorized set of the email

providers, with unconditional security.

Speciﬁcally, a current version of the add-on al-

lows users to distribute their e-mail messages to-

gether with attachments using one of the follow-

ing schemes: 2-out-of-2 additive scheme, k-out-of-n

threshold Shamir scheme (Shamir, 1979), and the Ra-

bin and Ben-Or robust scheme (Rabin and Ben-Or,

1989) (throughout this paper, we will refer to it as the

RB scheme, for short). Also, it allows an easy inte-

gration of different secret sharing schemes, including

those for arbitrary access structures.

1.3 Organization

This paper is organized as follows: our notation,

the software used, and the underlying cryptographic

primitives are described in Section 2. A high-level de-

scription of the proposed architecture is presented in

Section 3. Details of the implemented functionality

are discussed in Section 4. The cryptographic aspects

are discussed in Section 5. Section 6 presents and dis-

cusses the simulation results. Finally, conclusions and

future works are discussed in Section 7.

This useful feature adds to the user privacy in case of

the “Big Brother”-style surveillance.

2 PRELIMINARIES

2.1 Notation

A uniformly random selection of an element x from

its domain X is denoted as x ←

X. A bitwise XOR

is denoted by “⊕”.

Parties are called honest when they follow the de-

scribed protocol and do not attempt to eavesdrop a se-

cret. Adversaries could be passive (sometimes called

“semi-honest”), or active. Passive adversaries will

follow the described protocol, but will attempt to re-

cover a secret in an unauthorized way. Active adver-

saries do not have to follow the given protocol.

2.2 Thunderbird

Thunderbird is an open-source e-mail client devel-

oped by Mozilla. This client allows users to read any

of their e-mail accounts from separate domains into

one location. Since it is open-source, it is highly cus-

tomizable through user-made themes and add-ons to

add extra functionality to the software. The add-ons

are developed in JavaScript as a result of Thunderbird

being built on top of the Mozilla web platform that

is shared with Firefox. This allows the add-ons to be

cross-platform so they can be developed for any oper-

ating system or device that Thunderbird is developed

for.

We chose Thunderbird to host the add-on both be-

cause of the cross-platform ability, and because it is

able to connect with multiple e-mail servers and to

get direct access to a user’s full e-mail history. This

allows the add-on to easily search through the e-mails

and ﬁnd matching shares for reconstruction. The

browser extensions do not normally have this ability,

so that Thunderbird being an email client is the obvi-

ous choice.

Thunderbird recently underwent an overhaul of its

add-on environment, moving from legacy extensions

to a more uniﬁed WebExtension API (web, 2021a).

Thunderbird has several advantages, which are be-

yond the scope of this paper, such as an active on-

line community for add-on developers supported by

Thunderbird (top, 2021).

Because Thunderbird incorporates the majority of

Firefox’s features, Thunderbird add-ons have access

to Mozilla’s WebCrypto API (web, 2021b). This API

is developed by Mozilla to allow access to crypto-

graphic primitives. Using this API, the add-on can

generate cryptographically-strong random values us-

ing a Crypto object with the getRandomValues()

method.

The add-on also has access to the TextEncoder

SECRYPT 2023 - 20th International Conference on Security and Cryptography

172

and TextDecoder APIs developed by Mozilla. These

APIs allow encoding and decoding to and from strings

and Uint8Arrays (arrays of eight-bit unsigned inte-

gers representing the character codes of the string).

They are used in this add-on to more easily com-

pute XOR calculations using bytes instead of char-

acters by converting strings into byte streams (of type

Uint8Array) and vice versa as well as decoding the

information in the attachment ﬁles generated during

the share generation phase.

2.3 Secret Sharing and Access

Structures

Secret sharing is a cryptographic protocol which al-

lows one to split sensitive data (a secret) into pieces

(called shares) which individually

provide no infor-

mation about the secret.

More generally, one deﬁnes a certain number k,

called a threshold such that less than k shares provide

no information about the secret. At the same time, k

shares (or more) allow an efﬁcient reconstruction of

the secret. Clearly, k cannot exceed the total number

of parties n (email providers, in our case).

The access structure is a collection of sets (of par-

ties) who can reconstruct the secret. The access struc-

ture just described is called a threshold access struc-

ture and the schemes which realize it are the threshold

schemes. In particular, the Shamir scheme (Shamir,

1979) used in our implementation is of this type. For

the k-out-of-n threshold structures and schemes de-

scribed in the previous paragraph, we will use the no-

tation (k, n), e.g., a (k,n)-threshold scheme.

The general access structures support arbitrary

collections of access sets. These may reﬂect differ-

ent levels of trust which the data owner may assign to

different providers. For example, different thresholds

may be assigned to different groups of providers. It

is easy to extend our implementation to support such

access structures.

2.3.1 2-out-of-2 Additive Secret Sharing

A secret value is shared between two parties in such

a way that each individual share gives no information

about the secret, while reconstruction is possible from

both shares.

An easy way to implement it, assuming that the

secret is a binary string s ∈ {0,1}

, is to use a (binary)

one-time pad scheme, where the key represents the

ﬁrst share s

←

{0,1}

and the ciphertext represents

In special cases, it is possible that some individual

shares may allow recovery of the secret, but this is just an

academic possibility, which typically is not used.

the second share s

= s ⊕ s

. The reconstruction is

s = s

⊕ s

Note that the above is a special case of a thresh-

old scheme with both the threshold and the number of

parties equal to 2, hence we will be referring to it as

(2,2)-additive scheme.

Finally, we remark that the (2,2)-additive scheme

was proposed during the US Clinton administration

for key escrow (dep, 1994; Cli, 1993).

2.3.2 Shamir Threshold Secret Sharing Scheme

The (2,2) scheme suffers from two potential security

problems. First, two of the servers may collaborate

to recover the secret. To increase the security, the

aforementioned scheme can easily be adapted to an

(n,n) scheme. Secondly, any (n, n) scheme does not

provide a backup in case some of the serves is down.

The scheme we now discuss allows to deal with these

problems, provided we choose the parameters care-

fully.

System parameters (Shamir, 1979): A ﬁeld F

, a

number of shares n, a threshold k, where k ≤ n, and a

set (α

,. ..,α

) of distinct and public elements of F

which serve as id’s of the parties. To share a secret

s ∈ F

for some prime p > n, k − 1, the coefﬁcients

,· ·· ,a

k−1

∈ F

are chosen uniformly at random to

form the polynomial f (x) = s +a

+·· ·+a

k−1

The value f (α

) is the share s

that is given to party

. Any set of at most k − 1 shares provide no extra

information on the secret.

To reconstruct the secret, at least k honest par-

ties must submit their share s

. For every k distinct

,· ·· ,α

and s

,· ·· ,s

values, there exists a unique

polynomial q(x) of degree at most k − 1 such that

q(α

) = s

for 1 ≤ i ≤ k. Hence, the reconstruction

algorithm uses Lagrange interpolation to compute the

secret as s = q(0).

2.3.3 Rabin and Ben-Or Robust Secret Sharing

Scheme and its Variant

While Shamir secret sharing protect against acci-

dental or unauthorized deletion (or unavailability) of

shares by less than n − k parties, it does not give any

protection against active adversaries. It was observed

by Tompa and Woll (Tompa and Woll, 1987) that in-

correct shares submitted at the reconstruction in the

Shamir scheme will result in incorrect secret.

A goal of the so called robust secret scheme is

to ensure reconstruction of a correct secret. Rabin

and Ben-Or (Rabin and Ben-Or, 1989) proposed to

use the so-called check vectors for this purpose. In

the context of unconditional message authentication

codes (MAC), their schemes can be interpreted as fol-

Using Untrusted and Unreliable Cloud Providers to Obtain Private Email

173

lows: the share generation algorithm produces shares

(according to some secret sharing scheme), as well as

the MAC keys/tags for each pair of parties. This way,

each party obtains their share, the tags which authen-

ticate it for each respective party, and the keys which

authenticate shares of all other parties.

At the reconstruction, one accepts only the shares

supported by majority of the parties. By “supported”,

we refer to the fact that the corresponding tag veriﬁes

correctly for the corresponding key. It is implicitly

assumed that parties always support themselves (al-

though no tag is generated for this case)—this is just

counted as “plus one” vote for each share.

Finally, note that when using the RB scheme

(which provides data integrity), the probability ε for

dishonest e-mail providers to successfully modify

messages (without being noticed) cannot be zero. The

reason is that the RB scheme relies on MAC, which

can only guarantee a positive ε. By increasing the

length of the MAC, ε can be made sufﬁciently small.

Note that the non-zero ε is what makes our approach

different from the original work on Private and Se-

cure Message Transmission (PSMT) (Dolev et al.,

1993). We observe the later variants of PSMT, e.g.,

(Franklin and Wright, 2000), incorporate a non-zero

ε as a relaxed reliability requirement. Further details

on PSMT is beyond the scope of this paper.

2.3.4 Universal Hash Functions

Universal hash functions were introduced by Carter

and Wegman (Carter and Wegman, 1979) and

their use for authenticating messages by Wegman-

Carter (Wegman and Carter, 1981). In one of their

algorithms, a message m

m is a vector over a ﬁeld F

and a key k is a single element of F. Speciﬁcally, in

Carter and Wegman’s original algorithm, for the mes-

sage m

m ∈ F

n+1

and key k ∈ F, the function is com-

puted as y =

∑

i=0

n−i

, where m

∈ F are the ele-

ments of m

m for i = 0, .. ., n.

A lot of fast Universal Hash Functions were de-

veloped; see, e.g., (Bierbrauer et al., 1994; Johans-

son et al., 1994; Afanassiev et al., 1997). For our

implementation, we selected PolyQ32 (Krovetz and

Rogaway, 2001), which is designed to hash strings in

32-bit blocks.

Note that since the collision bounds for the

Krovetz-Rogaway approach are linear in the message

size n, it is important to implement a method of con-

trolling the collision probability to improve security.

The collision bound is also linear in the inverse of the

size of the key space |K

|. By choosing the key as

multiple elements from this set, the collision proba-

bility can be decreased to (1/|K

with respect to

the number of elements m chosen.

3 HIGH-LEVEL DESCRIPTION

OF THE PROPOSED

FUNCTIONALITY

The secret sharing Thunderbird add-on currently

implements the (2, 2)-additive scheme, the (k,n)-

threshold Shamir scheme, and the RB robust secret

sharing scheme (using Shamir shares and MAC based

on universal hashing). The parties (share holders) of

the secret sharing schemes are the email providers.

Hence, when using a (k,n)-threshold scheme, n is

the number of e-mail providers with which the recip-

ient has an e-mail account (or, e.g., the employer of

the sender does).

3.1 Sending a Message

With the add-on, Thunderbird provides an easily-

accessible button on the compose message window

that allows the user to secret share a message, in-

cluding attachments, in the compose window. When

secret-sharing a message, the add-on has a feature to

automatically ﬁll out the to: ﬁelds of the different

share messages. Each e-mail sent contains a unique

128-character hex string identiﬁer (UID).

The add-on is also integrated with Thunderbird’s

address book system. The user is required to store

their contact’s information in a preferred address book

that is selected using the popup preferences window.

The email addresses associated with secret sharing

communication are stored in a comma-delimited list

in the “Notes” section of the contact information. The

user then adds the contact’s main email address as the

receiver in the original message. Then, when the user

secret-shares the message, the add-on will ﬁnd the as-

sociated emails and auto-ﬁll the ﬁelds when generat-

ing the new messages with the secret shares.

Since the purpose of the add-on is to prevent

enough information to reconstruct the message being

on any one e-mail server, the user is expected to send

each message (or at least a number of the messages

less than the threshold) from a different e-mail ac-

count (e.g., a Gmail, Yahoo, ProtonMail, or Outlook

account). The recipient addresses should not include

more than a threshold amount from any one provider.

3.2 Receiving a Message

When a user opens any one of the secret shared e-

mails, they are provided with a custom button as

part of the add-on. Clicking on this button initiates

the reconstruction process. Users can view the re-

constructed message and download any attachments

SECRYPT 2023 - 20th International Conference on Security and Cryptography

174

through a custom window opened after the recon-

struction.

When reconstructing the email, the add-on is able

to automatically detect the scheme and parameters

used to share the message based on the body con-

tents of the received message. To retrieve shares

other than the one the user is viewing, the add-on

searches through other email inboxes on the system to

match with the aforementioned unique 128-character

(64 byte) hex UID in the subject line. The add-on

then takes the shares and, if applicable, the keys and

tags from each of these ﬁles. If reconstruction is pos-

sible, the add-on is able to separate the subject, body

text, and any attachments and display them in a cus-

tom window. The user can then select the attachments

and download them to their local system exactly as

they would with a regular, unsecured email commu-

nication.

3.3 Further details

The add-on implementation is centered around a

background script and a pop-up window. Both of

these, along with all the necessary permissions, im-

age icons, and add-on information, are deﬁned in the

manifest ﬁle (manifest.json) included in the open

source repository (git, 2022). The pop-up window al-

lows the user to adjust the system parameters includ-

ing the scheme, number of shares, and threshold for

reconstruction. This pop-up window (popup.html)

is written in HTML with custom CSS to improve the

interface.

4 FUNCTIONALITY DETAILS

Let us describe the details of our implementation and

justify some of its features.

4.1 Sending a Message

When the user clicks on the compose window button,

the script ﬁrst removes the subject line on the email.

The body text of the email is prepended with “SUB-

JECT: ” followed by the original subject line and fol-

lowed by an empty line. The subject line is then re-

placed with a randomly generated 128-character (64-

byte) hex string. This will be used to identify the

shares on the receiving end during the reconstruction

process.

Next, the add-on checks if any attachments have

been added to the compose window. A header string

is created with information about the attachments

to allow the reconstruction to correctly parse the e-

mail content and the attachments. The ﬁrst line of

the header contains the number of attachments be-

ing shared in the format count=<n> where <n> is the

number of attachments.

Following this, there is a line for each attachment

that contains the name, MIME type, and size in bytes

of the respective attachment with each piece of in-

formation delimited by a comma. This information

is prepended to the contents of the currently written

message (subject line and body text) to create the cur-

rent secret value.

To differentiate between the end of the e-mail con-

tents and the beginning of the attachment contents, a

single null character delimiter is appended to the end

of the current secret value. For each attachment, the

ﬁle object is taken and its contents are appended to

the end of the secret. There are no delimiters neces-

sary between the ﬁle contents as the size of each of the

ﬁles is stored in the header information. This allows

us to avoid any issues caused by setting delimiters that

users may put into their e-mails (e.g., random strings

of characters, new line characters, lengths of equal

signs, etc.).

This data is then converted into byte data by con-

verting the string contents into a Uint8Array using

the TextEncoder API where each index in the ar-

ray is a single byte. The body text is then changed

to a message that tells the recipient the name of the

scheme, the number of shares created, and the thresh-

old for reconstruction.

If the user wishes to attempt to automatically ﬁnd

the addresses of where to send the secret shared ma-

terial, the add-on requires the user to ﬁll in the to:

ﬁeld of the original compose email with an email ad-

dress of a contact added in the user-selected address

book (as selected from the preferences popup win-

dow). To retrieve the email addresses the user has

saved (if any) to use when secret sharing with the se-

lected recipient, the add-on ﬁrst retrieves the selected

address book. When the user selected a preferred ad-

dress book in the settings menu on the popup window,

the add-on stored the internal address book ID value

to the addressBook local storage value.

The add-on then uses the WebExtension folders

API to search for this address book. If the search

fails, an error will return. The add-on listens for this

error and, if none is found, the list of contacts is re-

turned back to the main thread. However, if the ad-

dress book is not found, this likely means that it has

been deleted. This is because the add-on internally

stores the ID value instead of the name of the address

book, as the name can be changed but the ID can not.

In the event that the selected address book has

Using Untrusted and Unreliable Cloud Providers to Obtain Private Email

175

been deleted, the add-on will recognize this issue and

search through the current available address books for

the “Personal Address Book.” This is the default ad-

dress book in Thunderbird and can not be deleted, so

it is guaranteed to exist. The local storage value for

the address book preference is then overwritten with

the ID of the default address book. It is important to

note that this check for the existence of the selected

address book is also performed when the add-on loads

and when the preferences popup window is opened to

ensure the preference option remains current. Then,

the contacts of the selected address book are returned

back to the main thread.

Once the main thread receives back the list of

contacts, it will ﬁrst parse the original to: ﬁeld for

the display name and email address of the receiver.

Thunderbird formats this string as DisplayName

<email@address> where the angle brackets surround

the contact’s email address. This can be easily parsed

to retrieve the display name and email address. With

this information, we can then iterate through the ad-

dress book (there is no search API with the given in-

formation) to look for a contact with a matching dis-

play name and email address.

Once the contact is found, the add-on will ac-

cess the content of the “Notes” section of the contact.

This content is assumed to be a comma-delimited

list of email addresses and is returned as a string.

The string is split on each comma and the substrings

at each index are trimmed of leading and trailing

whitespace to clean the data. For user readability,

the display name parsed earlier is appended in front

of each email address and the address is surrounded

by angled brackets to create the format DisplayName

<email@address> that Thunderbird prefers for the

to: ﬁeld.

After this step, the add-on will take the combined

data from the header text, subject line, body text, and

attachment data and send the combined string through

the selected secret sharing algorithm (either (2,2) Ad-

ditive, Shamir, or Robust) along with the number of

shares, the threshold, and the original compose details

(to preserve the hex subject identiﬁer and informative

body text). After the secret sharing algorithm is com-

plete and the necessary number of shares are gener-

ated, the add-on will open one compose window for

each share.

In each window, each of the pieces of the respec-

tive share (share, keys, and tags as applicable to the

current scheme) are added as attachments to the new

e-mail. The subject line for each e-mail contains a

common 64 byte hex string. This string is used as an

identiﬁer during reconstruction to allow the add-on to

ﬁnd which e-mails contain shares to be used in the

same instance of reconstruction process.

4.2 Receiving a Message

To reconstruct the messages, the user opens any one

of the messages that contains a share and clicks on

the customized button in the message display view.

Since some e-mail providers append to the subject

line (e.g., “[EXT] ” in Outlook, or “Fwd: ” for for-

warded e-mails), the add-on uses the regular expres-

sion /[0-9a-f]{128}/ to eliminate all but a 128

character long hex string from the current subject

line. This result is then used as a query to search

for messages with matching subject lines. This query

searches for any e-mails with matching subject lines

under any account from any incoming folder.

Thunderbird helpfully provides attributes for each

folder in each account and assigns them a type value

that can take the value, among other less important

values, “sent”. In the event that a user sends these

protected e-mails to themselves, the e-mails will ap-

pear in both an outbound and inbound folder. When

querying for messages given a unique subject line,

messages sent from the user to their own e-mail ad-

dress, or addresses, will appear twice. This will result

in an error during share generation as the implemen-

tation will ﬁnd twice as many messages as it needs

and will not know which ones are duplicates without

parsing the attachments.

To ﬁx this, we can change the message query to

only look for folders of type “inbox”. However, many

users wish to use custom folders to sort their e-mails.

These custom folders commonly have an undeﬁned

type. It is then easier to remove all query results from

“sent”-type folders to ensure that there are no dupli-

cate messages.

The messages found from non-sent-type folders

are parsed for attachments with titles matching the

format of the shares, keys, or tags to ﬁnd the rele-

vant reconstruction information. Since there is no API

for parsing the individual attachments, the raw attach-

ment data must be retrieved and parsed to ﬁnd the

individual pieces of information and then converted

from Base64 format.

To facilitate parsing the raw message data

for the attachments, the raw data is sent to the

getAttachmentData() function. The raw data is

then split at every instance of the string “Content-

Disposition: attachment;”. While the raw data ﬁle

does actually deﬁne a speciﬁc boundary string in the

beginning of the ﬁle, it is easier to simply split on

sections where we know there are attachments rather

than look through each section between two bound-

aries and ﬁgure out if it is an attachment.

SECRYPT 2023 - 20th International Conference on Security and Cryptography

176

Splitting the raw data on the content disposition

string results in n + 1 strings for a message with n

attachments where the remaining string is the header

information followed by the email contents and other

information related to the delivery of the email. The

format of each string resulting from the split is such

that the ﬁrst and third lines are blank. The second

line provides the name of the ﬁle using the format

filename="<f>" where <f> is the name of the ﬁle.

To then get the name of the ﬁle, we ﬁrst split the cur-

rent string into another array of strings based on the

newline delimiter. Then, we can simply take the sub-

string from the eleventh character to the third to last

character, inclusively. We omit the ﬁnal two charac-

ters as these are the closing quotation mark and a new-

line character.

Before iterating through the attachments to

store the content data, we must ﬁrst verify that this

is a share, tag, or key ﬁle sent from the add-on

since it is possible that a user may have attached

a separate ﬁle to the secret share message (this

is not suggested, but is possible for users to do).

This is done through a simple regular expression

that checks if the ﬁlename is “share”; “tag-” fol-

lowed by one or more digits, then a “-”, and one

or more digits; or “k-” (for key) followed by one

or more digits, then a “-”, and one or more dig-

its. In the regular expression format, this is written

/(share|tag-[0-9]+-[0-9]+|k-[0-9]+-[0-9]+)/.

If the ﬁlename matches this regular expression,

then the add-on iterates through the array of strings

split from the current section of the raw message data

starting from the fourth line as the ﬁrst three were

two empty lines and the ﬁlename. At each line, we

ﬁrst check if the string starts with 14 hyphens. This

is because the ending delimiter for the attachment

data section is formatted such that it starts with 14

hyphens followed by 24 hex characters (A through

F). While we could again use a regular expression,

it has actually been shown that using the JavaScript

String.startsWith() function is much faster, es-

pecially on small strings. If this returns true, then we

break out of the loop. If the ending barrier has not

been reached, then we simply append the current line

to the data from the previous lines.

Once we reach the end of the attachment data,

the ﬁnal newline is removed from the data as this

has the possibility of corrupting the attachment data.

The attachment content data is then pushed to an ar-

ray where each index contains the contents of an at-

tachment with the corresponding ﬁlename pushed to

a separate array. After each attachment has been

parsed, these two arrays are returned back to the call-

ing function.

Input: Secret data s

Output: Randomness r

r ← ∅

n ← s.length / 65,536

for i ← 1 .. .n do r ← r ∩ getRandomValues(

65,536 )

r ← r ∩ getRandomValues( s.length mod

65,536 )

Figure 1: Key generation algorithm for the (2,2)-additive

scheme to work around the 65,536 byte limitation of

getRandomValues().

The body of the current message is then parsed

to ﬁnd which secret sharing scheme was used to gen-

erate the shares. The detected scheme is then used to

reconstruct the message using the parsed shares, keys,

and tags as appropriate.

After reconstruction, the attachments and e-mail

contents need to be separated. The attachment header

information is used to get information on the attach-

ments in the message. The e-mail content is found

by looking for the ﬁrst occurrence of the null charac-

ter. The remaining attachment data is parsed using the

size attributes stored in the header information.

After the attachment parsing, a custom window

is opened with a message area that displays the re-

constructed message along with an area for attach-

ment ﬁles to be downloaded from. If there was an

error somewhere along the reconstruction, the area

will instead be populated with the error message (e.g.,

“Missing tag”, etc.).

5 CRYPTO DETAILS

We now explain how the different secret sharing

schemes explained in Section 2.3 have been imple-

mented and other details about the cryptography be-

ing used for these schemes.

Note that when sending a message, we ﬁrst follow

the steps outlined in Section 4.1. Similarly, we follow

the steps in Section 4.2 when receiving a message.

5.1 (2, 2) Additive Secret Sharing

To ﬁrst test the ability of the Thunderbird ecosystem

to handle secret sharing schemes, we implemented

a simple (2, 2)-additive secret sharing scheme as de-

scribed in Sec. 2.3.1.

Note that a (2,2) scheme is the same as the one-

time pad (Vernam, 1926) encryption scheme in which

one share is the key and the other the ciphertext. Since

the one-time pad scheme is well known, we use this

terminology.

Using Untrusted and Unreliable Cloud Providers to Obtain Private Email

177

While the XOR operation is quite simple, the

complexity of this implementation lies in the gener-

ation of the key with which to XOR the secret. To do

this, an empty byte array is created of the same length

as the secret byte data. To generate the random values

for the key, the Crypto API’s getRandomValues()

function is called. However, this function will return

a DOMException (quota exceeded error) if more than

65,536 bytes are asked to be generated at once. To

work around this issue, we generate n sets of 65,536

bytes where n = l/65,536 is the result of the inte-

ger division of the length of the secret content l in

bytes and the maximum number of bytes we can gen-

erate per function call. After those n sets, we gen-

erate the ﬁnal remaining number of bytes equal to

l mod 65,536. This solution can be seen in Fig. 1.

Since the secret content is passed to the func-

tion as an array of bytes and the key is also of the

same dataset, we can easily iterate through each byte

and use the built-in XOR operation in JavaScript to

compute the ciphertext. Once the ciphertext is com-

puted, two ﬁles are created: one with the ciphertext

byte data and one with the key byte data. Two com-

pose windows are also created. If available, the secret

email addresses from the user-selected address book

are added as the recipients of these two messages. Ad-

ditionally, the hex ID is saved to the subject line and

the informative body text is added. Finally, the ci-

phertext and key byte ﬁles are added as attachments

with one to each new compose window. These win-

dows then display for the user to ﬁnalize and send off

to the recipient.

The reconstruction for this scheme is straightfor-

ward. Once the user clicks the reconstruction but-

ton in the message view window, the add-on will

search for another message in the user’s inboxes with

a matching hex subject identiﬁer. If no other message

is found, then the reconstruction halts. If the other

message is found, then the attachments for the two

messages are parsed from the raw message data. The

add-on then takes the byte data from the two ﬁles and

XOR’s them together to produce the original secret

message. This information if then parsed to check the

header information for any initial attachments. If at-

tachments are found, then they are saved in local stor-

age. The reconstructed message view page will then

open. If there were any attachments with the original

message, then they will be available on this page for

download alongside the original message content.

5.2 Shamir’s Secret Sharing

The implementation of Shamir secret sharing scheme

takes the e-mail content and creates n shares as deter-

mined by the scheme parameters selected by the user.

The development time of this scheme is signiﬁcantly

improved through the use of the “secrets.js” library

(Rempe, 2019) that is used to construct the shares and

reconstruct the secret. To construct the shares, the se-

cret is ﬁrst required to be converted to a hex string.

While it does come with a string to hex conversion al-

gorithm, it was quite slow. Instead, a new algorithm

was written that experimentally showed to be about

1.5 times faster and is also easier to follow.

The ﬁrst stage of the construction follows the ad-

ditive scheme. The user ﬁrst clicks secret sharing but-

ton in the compose window and the e-mail content

is combined into a byte string. The Shamir secret

sharing algorithm is then given as input the content,

the updated compose window details with the hex ID

subject line and informative body text, the number of

shares, and the threshold for reconstruction. The e-

mail content is then converted from a byte string to a

hex string. This hex string secret is passed to the “se-

crets.js” library along with the number of shares and

reconstruction threshold to generate the shares.

The library ﬁrst converts the hex string into a bi-

nary string that is prepended with a 1 as a marker to

preserve the length of the message and then padded

to a multiple of 128 bits. The default implementation

of this padding appends a pre-generated 1,024-length

string of zeros to the string and then uses the slice()

method of the String object to reduce the length back

to the desired padding. This method can be somewhat

slow, so it is replaced by a single line command using

the function padStart(), also from the String object.

This resulted in a time improvement of up to 25% and

is more noticeable with larger secret sizes.

The binary string is then read starting with the

least signiﬁcant bit, converting every byte into an in-

teger and populating an array with the data. For each

integer in the array, the library generates a polynomial

of degree k − 1 and then evaluates the polynomial at

n locations using Horner’s method. This results in n

Shamir shares for each integer in the integer array.

The n shares for each integer are referred to as

subshares. Each subshare is converted from a number

to a binary string and padded to a multiple of eight

bits. The i

subshare is then prepended to the i

share. At the conclusion of the share generation, each

share is composed of n subshares in binary string for-

mat.

Since the library is designed to be conﬁgurable to

different data representations, the constructed shares

have two pieces of extra data prepended to them.

First, the number of bits per integer is converted to

a base 36 value. For this implementation, eight bits

is always used so this will be a constant. This value

SECRYPT 2023 - 20th International Conference on Security and Cryptography

178

also limits the maximum number of shares to 2

. The

second piece of data is an identifying value. This is

simply the index of the share over the range [1, n].

This value is converted to a two-character hex string

as the maximum value would then be 255, covering

the range of the maximum number of shares. The

ﬁrst three characters of the n shares are given by

801,802, ·· · , 8xx where xx is the hex representation

of n. The remainder of the share is the hex string

conversion of the binary string share calculated pre-

viously.

The n shares are then returned to the main imple-

mentation. The hex strings are converted into byte

arrays that are used to create a ﬁle for each share.

The shares are then added as attachments to new com-

pose windows. The original compose window is then

closed and the user is able to send the shares to their

selected intermediaries.

The reconstruction also begins much the same as

the additive scheme. The user opens an e-mail and

selects the reconstruction button. E-mails in any in-

coming folder with matching subject identiﬁers are

collected. The same attachment parsing method as

described in the additive scheme is then used to ﬁnd

the share data from the attachments. The resulting hex

string shares are then passed as an array to the Shamir

reconstruction algorithm.

The reconstruction algorithm calls the reconstruc-

tion function from the secrets.js library. The library

ﬁrst extracts the two pieces of extra information at the

front of each of the shares in order to know how to

convert the string into an integer array. The set of in-

teger arrays are then placed in a matrix with each ar-

ray representing a row. The matrix is then transposed

such that the number of columns is equal to n and the

number of rows is equal to the length of the integer

arrays.

The Lagrange interpolation is then evaluated us-

ing each row of integers. Each result is then converted

to a binary string, padded to a multiple of eight bits,

and prepended to a string holding the results of all of

the evaluations. The ﬁnal binary string result is con-

verted back into a hex string and returned to the main

implementation. This hex string is converted into an

ASCII string as the return value for the Shamir recon-

struction algorithm.

5.3 Robust Secret Sharing

The robust secret sharing (RSS) implementation

builds on top of the Shamir Secret Sharing scheme.

When the user selects the option to construct the

shares, the system generates the Shamir shares as

in the previous scheme. Then, keys (k

i j

) and tags

(tag

i j

) are generated for each pair of parties i, j ∈ [n]

where i ̸= j using the fast universal hashing algo-

rithm PolyQ32 as described in (Krovetz and Rog-

away, 2001). Fortunately, the algorithm as deﬁned in

the paper can be mapped directly into JavaScript, so

there are no translation or syntactical issues to work

around. After the keys and tags and generated, the

share for party i after the construction consists of s

n − 1 keys k

i j

∀i ̸= j, and n − 1 tags tag

i j

∀i ̸= j for a

total of 2n − 1 attachments.

The fast universal hashing function from (Krovetz

and Rogaway, 2001) allows the system to use a small

key size of 32-bits with a message in 32-bit blocks.

This plays well with the Shamir implementation that

generates shares whose lengths are multiples of 128

(this is customizable in the Shamir implementation,

but is not changed for the purpose of this add-on).

This allows the system to generate the keys using the

getRandomValues() function and send the key and

share directly to the PolyQ32 function.

The function as described in (Krovetz and Ro-

gaway, 2001) is directly implementable in the

JavaScript implementation. Because the share is in

binary format, the only addition to the function is con-

verting 32-bit blocks of the share into integers to per-

form the calculations. The arithmetic of the function

is computing modulo 2

− 5, the largest prime num-

ber under 2

. Since JavaScript can represent integers

up to 2

− 1 without needing other objects, these 32-

bit calculations will not overﬂow and lose any accu-

racy.

The construction of PolyQ32 is such that the colli-

sion probability increases with the length of the mes-

sage. To improve the collision bounds, multiple keys

in Z

are used to generate multiple tags for each

share. These tags are then concatenated before send-

ing to generate a longer tag. In the key and tag attach-

ment ﬁles, they are delimited by a newline to allow

the reconstructor to parse them. For the reconstruc-

tion, each of the key-tag pairs must match for tag

i j

be accepted. If a majority of the tags for one share are

accepted (at least

− 1 are veriﬁed), then the share is

accepted into the reconstruction. Otherwise, the share

is not included in the reconstruction.

As with the other schemes, the reconstruction be-

gins when the user opens an e-mail. The add-on ﬁrst

searches for any messages with a matching subject ID

in any incoming folder. It then parses the attachments

for all of the ﬁles. Since RSS requires multiple attach-

ments (share, keys, and tags), the attachment parsing

had to be reconﬁgured for this scheme to allow both

the contents and the titles of the attachments to be re-

trieved. This allows the system to then parse the at-

tachments with the knowledge that the attachment is

Using Untrusted and Unreliable Cloud Providers to Obtain Private Email

179

Table 1: Average share generation time in milliseconds over

500 iterations for each implemented scheme with secret

sizes of 1 KB, 10 KB, 100 KB, and 500 KB.

Scheme

Secret Size

100 B 1 KB 10 KB 100 KB 500 KB

(2, 2) Additive 4.58 4.70 5.82 14.07 53.15

Shamir 6.68 13.74 83.23 728.24 3,527.35

Robust 8.00 17.09 114.58 1,113.62 6,025.45

Table 2: Average reconstruction time in milliseconds over

500 iterations for each implemented scheme with secret

sizes of 1 KB, 10 KB, 100 KB, and 500 KB.

Scheme

Secret Size

100 B 1 KB 10 KB 100 KB 500 KB

(2, 2) Additive 52.67 54.78 56.68 74.86 179.41

Shamir 55.57 64.03 145.61 913.43 2,797.70

Robust 58.09 74.62 234.25 1,529.21 5,143.46

a share, tag, or key. The tags and keys are parsed into

matrices where each index represents the list of keys

and tags used to verify the shares. The tags for each

key and share are then calculated and compared to the

tags received from the e-mail attachments. If a ma-

jority of the tags match, then the share is added to the

list of accepted shares.

Once all the accepted shares are found, they are

sent to the Shamir decryption implementation as a

part of the library in (Rempe, 2019) as described pre-

viously. The results are then sent back to the main

program and stored in local storage. The reconstruc-

tion is also printed in the developer console to allow

for debugging.

6 SIMULATION RESULTS

In this section, we present experimental results on the

execution time of the add-on relative to the selected

scheme and the size of the secret. We compare each

of the three implemented schemes with secret sizes of

1 KB, 10 KB, 100 KB, and 1 MB. To remove some of

the overhead caused by Thunderbird and focus more

on the implementation, we remove output logging and

new windows are not opened at the end of both the

sharing and reconstruction phase. Each experiment is

tested 500 times. During the experimentation, it was

noted that around the 75th iteration during testing, the

execution time would consistently slow down signiﬁ-

cantly. In an attempt to negate this behavior, the 500

experiments are split into 10 sets of 50 iterations. The

simulations are executed using Thunderbird version

81.0b2.

The results in Table 1 shows the experimental re-

sults for generating shares using the three schemes for

Table 3: Average time spent only on share generation (ex-

cluding attachment parsing) in milliseconds over 500 itera-

tions for each implemented scheme.

Scheme

Secret Size

100 B 1 KB 10 KB 100 KB 500 KB

(2, 2) Additive 0.03 0.10 0.74 6.18 30.38

Shamir 0.80 5.99 69.36 710.44 3,465.80

Robust 1.35 9.57 100.67 1,109.91 5,972

Table 4: Average time spent only on reconstruction (exclud-

ing content parsing, message querying, and attachment sav-

ing) in milliseconds over 500 iterations after removing mes-

sage and attachment parsing and message querying.

Scheme

Secret Size

100 B 1 KB 10 KB 100 KB 500 KB

(2, 2) Additive 0.07 0.23 1.68 13.08 63.50

Shamir 0.45 3.09 27.43 338.82 2,072.65

Robust 0.87 5.97 57.29 714.61 4,881.69

secret sizes of 100 B up to 500 KB. Table 2 shows

the same results for reconstructing the shares gener-

ated from Table 1. These results show that the im-

plementation has decent performance for lower secret

sizes. Based on the percentage increase in the exe-

cution time compared to the percent increase in the

secret sizes, it can be surmised that a large portion of

the execution time for small secret sizes is composed

of overhead caused by Thunderbird or the test sys-

tem. Since Thunderbird is a single-threaded process,

it is likely that other operations introduce delay into

the secret sharing processing.

In addition, the execution times for larger secret

sizes (in particular 100 KB and 500 KB) had sig-

niﬁcant variation between individual reconstructions.

For the 500 KB test set, the individual execution

times ranged from 4,400 milliseconds to 5,600 mil-

liseconds. This can likely be explained as the result

of Thunderbird frequently attempting to save drafted

messages and query for new messages, causing some

inconsistent overhead. The results for lower secret

sizes also varied with a similar percentage of the over-

all time. It is important to note that this implementa-

tion has not been thoroughly optimized, so there is

likely still some signiﬁcant room for improvement in

these execution times by improving the iteration and

conversion operations.

In an attempt to isolate the reasons for the longer

execution times for larger secrets, we also recorded

the time for just the share generation and reconstruc-

tion without Thunderbird-related operations such as

querying for matching messages, parsing the raw

message contents, parsing the message body for the

scheme information, and saving the ﬁles to local stor-

age. This removes overhead that can not be improved

SECRYPT 2023 - 20th International Conference on Security and Cryptography

180

(a)

(b)

Figure 1: (a) The percentage of time spent on only share

generation. (b) The percentage of time spent only on recon-

struction. Both ignore message parsing, Thunderbird APIs,

and attachment data saving in order to examine the over-

head cost.

much given the current Thunderbird API and instead

focuses on just the secret sharing implementations.

The share generation execution time results for this

experiment are recorded in Table 3 and the recon-

struction execution time results are recorded in Ta-

ble 4. These results are illustrated as a percentage

of the total execution time in Fig. 1 for the three

schemes.

These results show that, for small secret sizes

around 1 KB and below, the Shamir and robust

scheme reconstructions take less than 10% of the

overall time. The remaining time is spent querying

and parsing the messages and saving the attachments

to local storage. At a secret size of 10 KB and above,

the Shamir and robust scheme reconstructions take

the majority of the time and reach 90% and greater

around 500 KB.

Since the reconstruction has signiﬁcantly less

message parsing and ﬁle saving, the share generation

has noticeably less overhead. The Shamir and robust

scheme share generation accounts for around 50% of

the total execution time with a 100 KB secret size.

This value only decreases to around 10% for a 100 B

secret.

7 CONCLUSIONS AND FUTURE

WORK

The proposed private email communication system is

implemented in the form of the Thunderbird add-on

which currently supports 2-out-of-2 additive scheme,

Shamir’s scheme, as well as the Rabin and Ben-OR

robust scheme (based on Shamir’s sharing and fast

universal hashing by Krovetz and Rogaway). The

shares (and also keys, and tags in the robust scheme)

are sent as attachments in multiple e-mails via email

providers (that represent different parties in a secret

sharing scheme). Each e-mail contains a unique 128-

character hex string identiﬁer (UID) to link them to-

gether during the reconstruction process.

This implementation has a distinct advantage over

other forms of email security apps. Indeed, our Thun-

derbird add-on keeps the contents secret not only from

the communication channel eavesdroppers, but also

from the email hosts and servers who facilitate the de-

livery and receipt of the email. To guarantee this, the

user needs to chooses not to send a threshold number

of the shares through untrusted providers.

Another advantage of our add-on is that in current

existing email security apps, such as PGP, the secu-

rity relies on computational security, which remains

unproven. This entails the need to perpetually eval-

uate the security of the cryptographic primitives and

their security parameters (such as key length). The

use of unconditional security by our implementation

eliminates these concerns (provided the random gen-

erator provides true uniformly random independent of

anything).

It is worth noting that our proposal can also be

combined with the existing (computationally secure)

application to enhance their security. For example, an

email message can be both encrypted using PGP and

then secret-shared using our implementation. Then,

the adversary will have no information about the mes-

sage unless (s)he is able to access the threshold num-

ber of shares. After that, (s)he would have to break

the encryption scheme to ﬁnally access the message.

A proper combination of unconditionally and compu-

tationally secure cryptographic primitives for the pur-

poses of email security may be worth a further study.

The add-on is available via Github (git, 2022).

Future work could focus on speeding up the add-

on, and on evaluating how good the random gener-

Using Untrusted and Unreliable Cloud Providers to Obtain Private Email

181

ation is. We now discuss the speeding up in more

details.

One topic is focusing on optimizing the Shamir

library to reduce the execution time. In addition,

the message parsing needs to be optimized as cur-

rently it is required for the system to parse the en-

tire raw message contents to get attachments on in-

coming messages. In the future, this may be made

more simple through expanded WebExtension APIs.

Currently, due to the recent major version change and

add-on overhaul, the Thunder WebExtension APIs do

not have any direct access to message attachments.

Another potential route for optimization is selecting

another secret sharing scheme that may be more op-

timized for a JavaScript implementation and for ﬁle

sizes of up to a few megabytes. Finally, alternative

universal hashing functions should be considered.

REFERENCES

(1993). A proposed federal information processing standard

for an escrowed encryption standard (ees). Federal

(1994). Department of justice brieﬁng re escrowed encryp-

tion standard. Department of Commerce, Washington

D.C.

(2021). “add-on developers.” topicbox.com. [online]. https:

//thunderbird.topicbox.com/groups/addons.

(2021a). Thunderbird webextension apis - thun-

derbird webextensions latest documentation.

readthedocs.io. [Online]. Available at https://

thunderbird-webextensions.readthedocs.io/en/latest/.

(2021b). Web crypto api. Mozilla Developer Network [On-

line]. Available: https://developer.mozilla.org/en-US/

docs/Web/API/Web Crypto API.

(2022). Proposed thunderbird add-on. [On-

line]. Available: https://github.com/NTSAS/

Thunderbird-Secret-Sharing.

Afanassiev, V., Gehrmann, C., and Smeets, B. (1997).

Fast message authentication using efﬁcient polyno-

mial evaluation. In Biham, E., editor, Fast Soft-

ware Encryption, pages 190–204, Berlin, Heidelberg.

Springer Berlin Heidelberg.

Attasena, V., D. J. and Harbi, N. (2017). Secret sharing

for cloud data security: a survey. The VLDB Journal,

26:657—-681.

Bierbrauer, J., Johansson, T., Kabatianskii, G., and Smeets,

B. (1994). On families of hash functions via geometric

codes and concatenation. In Stinson, D. R., editor,

Advances in Cryptology — CRYPTO’ 93, pages 331–

342, Berlin, Heidelberg. Springer Berlin Heidelberg.

Blakley, G. R. (1979). Safeguarding cryptographic keys. In

1979 International Workshop on Managing Require-

ments Knowledge (MARK), pages 313–318.

Carter, J. and Wegman, M. N. (1979). Universal classes

of hash functions. Journal of Computer and System

Sciences, 18(2):143–154.

Dolev, D., Dwork, C., Waarts, O., and Yung, M. (1993).

Perfectly secure message transmission. J. ACM,

40(1):17–47.

Franklin, M. K. and Wright, R. N. (2000). Secure commu-

nication in minimal connectivity models. Journal of

Cryptology, 13:9–30.

Johansson, T., Kabatianskii, G., and Smeets, B. (1994). On

the relation between a-codes and codes correcting in-

dependent errors. In Helleseth, T., editor, Advances in

Cryptology — EUROCRYPT ’93, pages 1–11, Berlin,

Heidelberg. Springer Berlin Heidelberg.

Krovetz, T. and Rogaway, P. (2001). Fast universal hash-

ing with small keys and no preprocessing: The polyr

construction. In Won, D., editor, Information Security

and Cryptology — ICISC 2000, pages 73–89, Berlin,

Heidelberg. Springer Berlin Heidelberg.

Liu, C. L. (1968). Introduction to Combinatorial Mathe-

matics. Computer science series. McGraw-Hill.

Oren, Y. and Wool, A. (2009). Perfect privacy

for webmail with secret sharing. Techni-

cal Report, Tel-Aviv University, Available at

https://85c6e2e3-099c-4499-b7e5-046bb17abf53.

ﬁlesusr.com/ugd/5dd4a3

318130cb05614ab58e275c1d5994247f.pdf.

Rabin, T. and Ben-Or, M. (1989). Veriﬁable secret sharing

and multiparty protocols with honest majority. In Pro-

ceedings of the Twenty-First Annual ACM Symposium

on Theory of Computing, STOC ’89, page 73–85, New

York, NY, USA. Association for Computing Machin-

ery.

Rempe, G. (2019). Secret sharing for javascript.

github.com. [Online] Available at https://github.com/

grempe/secrets.js.

Shamir, A. (1979). How to share a secret. Commun. ACM,

22(11):612–613.

Simmons, G. J. (1990). Prepositioned shared secret and/or

shared control schemes. In Quisquater, J.-J. and Van-

dewalle, J., editors, Advances in Cryptology — EU-

ROCRYPT ’89, pages 436–467, Berlin, Heidelberg.

Springer Berlin Heidelberg.

Tompa, M. and Woll, H. (1987). How to share a se-

cret with cheaters. In Proceedings on Advances

in Cryptology—CRYPTO ’86, page 261–265, Berlin,

Heidelberg. Springer-Verlag.

Vernam, G. S. (1926). Cipher printing telegraph systems

for secret wire and radio telegraphic communications.

Transactions of the American Institute of Electrical

Engineers, XLV:295–301.

Wegman, M. N. and Carter, J. (1981). New hash functions

and their use in authentication and set equality. Jour-

nal of Computer and System Sciences, 22(3):265–279.

ık, P., Ploszek, R., and Zajac, P. (2022). Practical use of

secret sharing for enhancing privacy in clouds. Elec-

tronics, 11(17).

SECRYPT 2023 - 20th International Conference on Security and Cryptography

182
