Compilation of Distributed Programs to Services Using Multiple

Programming Languages

Thomas M. Prinz

Course Evaluation Service, Friedrich Schiller University Jena, Jena, Germany

Keywords:

Service, Compiler, Distributed Programming, Programming Language, Engineering.

Abstract:

Service-orientation recommends dividing software into separate independent services, with each service being

implemented in the programming language that best ﬁts into the service’s problem space. However, data must

be shared between the distributed services, so common data models and interfaces must be deﬁned in each

programming language used. This leads to a higher development effort and dependencies, while neglecting

the beneﬁts. This paper explains a new idea that arranges a distributed program as if it is a single one, even

though it consists of different parts using possibly different programming languages. For this purpose, the

idea of meta network programming languages is introduced. They are based on network machines and hide

the complexity arising during development of distributed software. A compiler translates and distributes these

programs by splitting them into several parts. As a result, this should reduce the overhead of developing

distributed general purpose software. The intention of this position paper is to give new ideas to implement

distributed programs in the future. An implementation of the idea does not exist yet.

1 INTRODUCTION

The development and implementation of software

is a complex process. To deal with this complex-

ity, researchers and practitioners have deﬁned dif-

ferent strategies. One strategy is to divide the soft-

ware into different modules, whereby each module

can be developed separately from the others. To

reduce functional implementation effort, each mod-

ule should be implemented in the programming lan-

guage and tool stack that best ﬁts its problem space.

Emerging technologies like service-oriented architec-

tures (SOA) make this possible. If services are very

closed (atomic) in their functionality, they are called

microservices. A microservice communicates over a

network, is deployed independently from other ser-

vices, and uses the programming language and tool

stack that best ﬁts its needs (Newman, 2015). For ex-

ample, if someone needs to develop a software, which

deals with objects, but also with machine learning,

parts can be implemented in Java, a typical object-

oriented language, and in Python, known for its data

science packages.

When software is divided into different subsys-

tems, the subsystems must communicate with each

https://orcid.org/0000-0001-9602-3482

other to achieve the overall goal of the software.

Therefore, they need communication interfaces. In

software development with one programming lan-

guage, these interfaces are realized with function

(method) declarations. When using multiple pro-

gramming languages, however, not all functions are

located in the same execution environment; they

could be anywhere in the network or on the machine

and are called via network or other approaches.

The big difference between calls within a pro-

gramming language or outside via services is mainly

in their support (De Paoli, 2018). In monolingual

programming, most of the program code is known at

compile time, so most of the code is known during

development; integrated development environments

(IDEs) can use these information and, therefore, can

fully support the development. Modern IDEs iden-

tify, among other things, calls to undeﬁned methods,

access violations, and incorrectly placed method pa-

rameters. In those cases, the IDE provides immediate

feedback during coding and, usually, some error han-

dling. Furthermore, since the software is developed

in a single language, compilers can translate it into

(virtual) machine code and — in most cases and by

deﬁning the execution environment — they are imme-

diately executable. On the contrary, in the context of

service-based and distributed software architectures,

Prinz, T.

Compilation of Distributed Programs to Services Using Multiple Programming Languages.

DOI: 10.5220/0012151500003584

In Proceedings of the 19th International Conference on Web Information Systems and Technologies (WEBIST 2023), pages 191-198

ISBN: 978-989-758-672-9; ISSN: 2184-3252

191

Developers

Services

Configurations

Compilers/

Deployment

Network of

(virtual) machines

Developers

Services

(Network program)

(Network)

Compiler

Network of

(virtual) machines

(Network)

Machine

Current approach New approach

Figure 1: The current approach to develop distributed and service-oriented software (left) and our new approach (right).

such IDE support is weak. The reason is that the IDE

only knows one service and not the overall software

architecture. Developers need to control each service

and verify that they meet predeﬁned speciﬁcations.

Without this quality check, services will not be called

properly — even if they are implemented correctly.

Besides the described disadvantages in IDE sup-

port, the current practice has further disadvantages

resulting in a high development effort. The shared

data models between services must be implemented

in all programming languages used, which leads to

a high and unnecessary programming overhead. In

addition, objects shared between services need serial-

izers and deserializers and Application Programming

Interfaces (APIs) must be implemented for services

as well as for calls to them. (Apel et al., 2019) have

shown in a real project that the ratio of implementa-

tion overhead is sometimes less than or equal to 1 : 3

between functional and additional code, i. e., for 100

lines of functional code 300 lines of organizational

code are required. In general, the current approach

leads to a high workload during programming, devel-

opment, speciﬁcation, and maintenance and, there-

fore, to high costs and time expenditure. Especially,

for small development teams, these cost and time fac-

tors become crucial.

Figure 1 (left) visualizes the current approach of

distributed software development. Developers deﬁne,

implement, and deploy services separately, which

eventually run on different virtual machines and re-

alize the software.

Figure 1 (right) illustrates our new idea using

a compiler for distributed and service-oriented soft-

ware. At ﬁrst, we reduce common properties of dis-

tributed, multiprocessor, and service-oriented systems

to a single, abstract base which we call a network ma-

chine. A network machine hides the complexity of the

network of (virtual) machines to simplify imagination

of the execution environment during development. In

addition, it organizes sharing of data, message ex-

change, and calls of distributed functionality (e. g.,

service calls). Thus, developers can imagine, their

program runs on a single machine, where researchers

claim that it is easier to think about and improves

code quality (Kozlovics, 2019). In ease, network ma-

chines describe runtime environments. These envi-

ronments execute so-called network programs. Net-

work programs describe the combination of all dis-

tributed parts of a distributed software but hiding its

complexity by ordinary method and function calls.

The advantage of a network program is the ability to

implement different functions of the software in dif-

ferent programming languages. It is the task of a net-

work compiler to split the program into separate mod-

ules and translate each module into a different lan-

guage with its own (shared) execution environment.

Advantages of our idea would be that IDEs

can support developers across service and language

boundaries and, when good algorithms are found to

split programs automatically in such a way that it

has the best performance neglecting communication

overhead, the overall program performance can be

improved. Furthermore, programming, development,

and speciﬁcation would become easier and faster as

with conventional approaches, and, by the way, de-

velopment becomes also easier when using different

programming languages in a non-distributed context.

This paper introduces the idea and basic concepts

while there is no concrete implementation yet.

This paper is structured as follows: Section 2 con-

siders related work in distributed systems and their

implementation. Section 3 starts to generalize the

approach and deﬁnes network machines running net-

work programs deﬁned in Section 4. Subsequently,

Section 5 describes a compiler architecture for net-

work programs. Section 6 concludes and brieﬂy dis-

cusses the idea.

WEBIST 2023 - 19th International Conference on Web Information Systems and Technologies

192

2 RELATED WORK

The idea of implementing software in a uniﬁed lan-

guage is not new and came up early in research

and industry. For this reason, many approaches for

languages for data models and functionality have

evolved in the past. For example, the Uniﬁed Mod-

eling Language (UML) (Object Management Group,

2017b) is such a uniﬁed language, in which the soft-

ware development community and industry use vari-

ous diagrams that are widely used as modeling lan-

guage standard (Oquendo et al., 2016) (especially,

class, use case, and sequence diagrams (Dobing and

Parsons, 2006)). The Action Language for Foun-

dational UML (Alf) (Object Management Group,

2017a) and the Semantics of a Foundational Subset

for Executable UML Models (fUML) (Object Man-

agement Group, 2018) are standards for describing

complete systems in UML down to the behavior of

individual functions, but their application is not triv-

ial and requires scientiﬁc knowledge (Ciccozzi et al.,

2019). In contrary, our idea would be similar to usual

software development and should be easier to learn.

Interoperability of different systems, program-

ming languages, and platforms is the goal of the Com-

mon Object Request Broker Architecture (CORBA)

(Object Management Group, 2021). CORBA fol-

lows a strong object-oriented approach and consid-

ers each functionality to be bounded in (remote) ob-

jects as methods. Developers describe the signature

of such methods in an Interface Deﬁnition Language

(IDL), compile them into programming language spe-

ciﬁc interface stubs, and add their functionality. An

Object Request Broker (ORB) handles requests to the

methods and delegate them to speciﬁc implementa-

tions regardless where they are and how they are im-

plemented. Although CORBA has similarities with

our approach, it also differs. CORBA focuses on

interacting objects; our approach, however, handles

objects just as complex data structures and provide

functions/methods as (micro)services. Furthermore,

CORBA deﬁnes function signatures separately in the

IDL, compiles them into stubs, and force to imple-

ment them subsequently; however, our approach al-

lows to integrate both the implementation and the

“cross-language” signature. Finally and importantly,

CORBA is expensive for companies as ORBs are

complex and, therefore, usually are licensed from

commercial vendors; our approach, however, should

result in a less complex environment and, therefore,

should be more attractive for small companies.

Alternative approaches try to minimize the effort

between design and implementation. For example,

Swagger (Swagger, 2023a) allows the speciﬁcation

of REST APIs in an OpenAPI speciﬁcation (Swag-

ger, 2023b) and the generation of client and server

code skeletons. JHipster (Raible, 2018) generates

complete applications within a predeﬁned technol-

ogy stack. Both Swagger and JHipster are limited

by ignoring the system behavior. The framework

Flutter (Google, 2023) describes applications in Dart

and compiles them into native cross-platform applica-

tions, but does not translate parts of the program into

individual target machines and languages. Some web

template and behavioral languages, e. g., pug (pug,

2023), Haml (Catlin, 2023), and GWT (Tacy et al.,

2013), allow software descriptions and compile them

into web applications. They are powerful but limited

to web applications, JavaScript, and Java.

Although limited to C++, C, and Fortran,

OpenMP (OpenMP Architecture Review Board,

2018) has similarities to our ideas and has become

a standard for programming shared memory systems

in High Performance Computing (HPC). Rather than

focusing on multiprocessors on the same machine as

OpenCL (Khronos OpenCL Working Group, 2023),

it enables high-level parallel programming and porta-

bility (Yu et al., 2020) over a network. Programs are

translated into heterogeneous multiprocessor systems,

but this complexity is hidden from the programmer.

After compilation, the OpenMP environment auto-

matically moves different machine code to the proces-

sors and handles data exchange between them. Our

idea is similar by hiding details about the infrastruc-

ture. However, our focus is not on HPC, but on pro-

gramming for general purpose.

The game development engine Unity (Unity Tech-

nologies, 2023) follows a similar idea like ours. It al-

lows to describe games in a subset of C# running on

Mono (Mono Project, 2023), an open-source .NET

framework. Mono is based on the Common Lan-

guage Infrastructure (CLI) standard (Ecma Interna-

tional, 2012), which allows programs to run on dif-

ferent operating systems. The use of C# as a de-facto

meta programming language follows our idea to de-

ﬁne data models and services independently of pro-

gramming languages. However, instead of translat-

ing the models and services into a single language

and runtime environment, our approach is to dis-

tribute them across different languages and environ-

ments. Another example in game development is

the GameEngine of (Apel, 2018) for the deﬁnition

of massively multiplayer online games (MMOG). The

novelty of his approach was the automatic generation

of code for communication, controllers, etc. as well as

their compilation at runtime. This made games leaner

in terms of shortened implementation times and lines

of code. However, its focus on MMOGs makes it dif-

Compilation of Distributed Programs to Services Using Multiple Programming Languages

193

ﬁcult for use in general development.

Instead of simplifying the development of soft-

ware with a speciﬁc execution environment as intro-

duced in the previous examples, the web computer

hides the complexity during the development and ex-

ecution with an own operating system (Kozlovics,

2019). It addresses similar problems in software de-

velopment as we do, focusing on the assumption that

the software should be implemented for a single com-

puter, a single user, and as single executed program.

Its main approach is to hide all network and mem-

ory sharing speciﬁc issues from the developer by dis-

tributing memory changes across all physical devices

and automatically creating network communications.

The approach seems promising, but it is still unclear

how web computer applications are developed and

compiled. It is also limited to web applications.

There are only a few papers that try to compile

complete service systems, examples are Singer et al.

(Singer, 2016; Geisriegler et al., 2017) and Prinz et

al. (Prinz et al., 2014; Prinz et al., 2015). However,

both research groups have a background in business

process management and focus on business processes.

However, current process modeling languages are not

able to describe the full functionality of general pur-

pose software.

3 NETWORK MACHINES

Business processes, HPC, distributed, and service-

oriented software have their differences in imple-

mentation and execution. However, they also have

strong similarities: They are implemented to run on

a network of possibly different (virtual) machines,

which may have their own supported programming

languages and tool stacks. From an abstract perspec-

tive, in multiprocessor systems such as those used

in HPC, each multiprocessor can perform a different

function that can be executed on one machine with a

different instruction set than on the other machines. In

SOA, services are the interfaces of functions, where

the service could be implemented in different pro-

gramming languages, run on different machines, and

have its own or a shared and distributed memory. Be-

cause of the strong similarities between them, our idea

is to combine them into a common ground of dis-

tributed software that we call a network machine.

A network machine is a lightweight runtime en-

vironment for distributed software. From the devel-

oper’s point of view, a network machine executes a

network program that is deﬁned in detail in the next

section. The ﬁnal compiled ﬁles of a network pro-

gram are containers, which contain various services,

Network Machine

Container Container ContainerContainer

Loc. Mem.

Network

Loc. Mem.

Computer

Instruction

Set

Loc. Mem.

Service 4Service 3Service 2Service 1

Java

JVM

Interpreter

CPython

python

Loc. Mem.

Machine

Address register

Service 1: 192.1.2.3/service1

Service 2: 128.3.42.12/service2

...

Service 1

Persistence

Interface

Container

Loader

Common

Interface

Common

Interface

Common

Interface

Common

Interface

Common

Interface

Figure 2: A network machine with containers that deﬁne

services, (virtual) machines (devices), used programming

languages, and execution environments with local and dis-

tributed memories. In addition, the network machine pro-

vides a container loader, a persistence interface, a common

interface for services, and an address register where it stores

the network addresses of the services.

but all services within a container are compiled from

the same programming language, e. g., there could be

containers for Java, R, C, and Python services. Basi-

cally, one technology that can be used and imagined

for containers is Docker (Docker Inc., 2023) and Ku-

bernetes (Burns et al., 2019). The network machine

loads these containers and makes them available. At

this moment, the software is running and accessible.

Since the network machine knows all services, if one

service calls another, the machine can redirect the call

to the right service. Figure 2 illustrates the conceptual

idea of network machines.

From a technical point of view, a network machine

hides the complexity of a set of different, possibly vir-

tual, computing machines (devices) connected to each

other over a network (as shown in Figure 2). The net-

work serves as bus for the exchange of data and mes-

sages between the devices. Each device hosts a con-

tainer and, therefore, provides all the container’s ser-

vices. Since the network machine knows the network,

it can assign speciﬁc addresses to each service (like

memory addresses on normal machines) and store

them in an address register. All services can be ac-

cessed via a common interface, which processes data

input and output. This is comparable to the handling

of functions in machine languages: The common in-

terface deserializes each input parameter and puts the

result into the service context so that the service can

access it. Then the interface calls the service func-

tionality. The results of the service call are serialized

by the interface and sent back to the caller.

WEBIST 2023 - 19th International Conference on Web Information Systems and Technologies

194

The service functionality is executed in a sepa-

rate (possibly virtual) environment. These are ac-

tual runtime environments for the programming lan-

guages used in the services, e. g., Java Virtual Ma-

chines (JVM) (Lindholm et al., 2014) or Python and

R runtime environments. Since a network machine

is also a runtime environment, behind a service can

again be an own network machine. In addition, each

service has its own local memory and shares data only

via the interfaces. Global data should be used with

caution, as with any distributed software. Network

machines provide global data via a persistence inter-

face for all data structures deﬁned in the network pro-

gram and shared by the services. This persistence in-

terface allows easy and continuous storage of data,

its access, modiﬁcation, and deletion. Since services

could run in parallel when asynchronous service calls

are used, this interface solves the race condition be-

tween parallel accesses, e. g., by locking mechanisms.

4 NETWORK PROGRAMS

Programming distributed software is a challenge be-

cause the developer cannot simply call another func-

tion in a distributed part of the program, but must call

an external service using the right parameters, for-

mat, etc. It is helpful during development to imag-

ine that all functions of a program are located in the

same environment, regardless of where they are ac-

tually located (Kozlovics, 2019). The idea of net-

work programs creates this situation. Network pro-

grams are executed on the previously deﬁned network

machines and are written in a so-called network pro-

gramming language that mainly deﬁnes data models

and the software structure as services. The advan-

tages of such network programs are: (1) they deﬁne

the interfaces of all services, (2) service calls are more

similar to function/method calls, and (3) they describe

shared data models only once.

Figure 3 shows an example of a small network

program. It is written in a Java-like language only

as an example. At the beginning, the program de-

ﬁnes the data model (class) Pair with two ﬁelds

a and b and a constructor. It also deﬁnes a class

Computation, which contains two methods. The

method handlePairs is written in Java and transfers

a nested integer array of pairs into a list of objects of

type Pair. At the end, the method returns the sum of

the list of pairs by calling the computeSums method,

which is written in R. The method computeSums re-

quires an array (or list) of pairs deﬁned by the class

Pair. It then calculates the sum of the two ﬁelds a

and b of each Pair object and returns it as an array.

1 c las s Pai r {

2 pub li c i nt a , b ;

3 Pa ir ( int a , i nt b ) {

4 th is . a = a ; t hi s . b = b ;

5 }

6 }

1 c las s C o mp u tat i on {

2 @J ava

3 pub li c i nt [] han d leP a ir s ( int [] [] p ai rs ) {

4 Pa ir [] p ai r Li s t = n ew Pa ir [ p ai rs . l eng th ];

5 fo r ( i nt i = 0; i < p ai rs . l eng th ; i + +) {

6 in t a = p air s [ i ][0] , b = pa irs [i ][1 ];

7 p ai r Lis t [ i ] = ne w P ai r (a , b );

8 }

9 ret urn th is . c o mp u teS u ms ( p a irL ist );

10 }

11 @R

12 pub li c i nt [] com p ute S um s ( Pai r [] pa irs ) {

13 sap ply ( pa irs , fun cti o n ( p air ) {

14 pa ir$a + pair $b

15 })

16 }

17 }

Figure 3: An example of a network program.

The implementation of the program with the cur-

rent state-of-the-art is not a challenge but time con-

suming. First the data structure Pair must be im-

plemented in Java and in R. Then, the Java part of

the program must be implemented and made avail-

able as a service, e. g., with REST. In addition, de-

velopers must implement the R part of the program

and also make it available as a service. Since data

is transferred, a protocol must be deﬁned or an exist-

ing one like JSON (Ecma International, 2017) must

be used for the exchange. Furthermore, the data must

be mapped to the correct parameters.

The implementation overhead can cause develop-

ers to implement the program/software in a single

language instead of multiple ones. However, some

problems can be solved, computed, and implemented

much more efﬁcient in other programming languages.

This advantage is then missing and, therefore, leads to

increasing implementation costs (Apel et al., 2019).

Network programs should improve this situation since

developers avoid the previous described steps.

5 COMPILER ARCHITECTURE

FOR NETWORK PROGRAMS

Network programs are transferred to a runnable soft-

ware with the help of a compiler. Basically, the archi-

tecture of such a compiler can follow a similar struc-

ture as classical compilers (e. g., (Cooper and Torc-

Compilation of Distributed Programs to Services Using Multiple Programming Languages

195

Code Service Call

Extender

Target 1

Code Generator

Target n

Code Generator

...

Target 1

Exec. Environment

Generator

Target n

Compiler

Target 1

Compiler

Target n

Exec. Environment

Generator

Code Splitting

Docu.

Generator

Target 1

Files

Target n

Files

Target 1

Environment files

Target n

Environment files

Scanner

Parser

Optimizations

Semantic Analyzer

Transformer

Source Code

Documentation

files

Target 1

Optimizer

Target n

Optimizer

Target 1

Container

Target n

Container

Front end

Splitting

Back end

Figure 4: The compiler architecture for network programs.

zon, 2011)). It consists of a front end, which pro-

cesses the source program (the input) and translates

it into an internal intermediate representation (IR),

and a back end that translates it into the output lan-

guage. Although so-called cross compilers are capa-

ble of generating code for different output languages,

they produce code for the entire program in one lan-

guage. Our idea of a compiler architecture overcomes

this limitation and allows to split the source program

into parts and compile each part into a different pro-

gramming language. Furthermore, it generates addi-

tional code that allows the parts to communicate with

each other (i. e., method/function calls). The splitting

itself is part of the optimizations of the compiler.

Figure 4 shows the phases of the compiler archi-

tecture we propose for network programs. The front

end of the compiler has the same structure as in the

classical compiler architecture. First, the scanner pro-

duces a stream of tokens from the source program,

which is used in the parser to check the grammar

of the programs and build the Abstract Syntax Tree

(AST). The semantic analyzer executes various algo-

rithms to ﬁnd errors in the program as early as pos-

sible, e. g., (static) type violations, access violations,

undeﬁned variables, and so on. The compiler trans-

lates the conﬁrmed AST into a an internal represen-

tation — the IR — in the transformer to make some

optimizations easier to apply to it. All optimizations

are independent with respect to the target code(s).

At this point, it is important to mention that the

front end should mainly process those parts of a net-

work program that are written in a network program-

ming language. Code which is already written in

the target languages is not checked in the front end.

For them, it uses the language-speciﬁc compilers and

provides the whole context (e. g., data models and

method schemes with arguments) in the back end.

After the front end, the compiler architecture has a

splitting section, comparable to an optimization. The

compiler tries to split the IR into a distributed IR,

where each distributed part of the IR can be translated

into a different target language and machine. The

compiler takes the code that is already available in all

target languages and adds translations of data models

to them if necessary. For example, the network pro-

gram in Figure 3 abstractly describes the class Pair.

Since this class is needed in the Java and R sections

of the program, this class should be available in both

Java and R. For this reason, the compiler translates

the abstract deﬁnitions of the classes into program-

ming language speciﬁc deﬁnitions in both languages.

Since splitting the code into different parts leads

to a more complex software architecture, the result-

ing architecture should be well documented. The

compiler should provide a Documentation Generator

phase, which generates both an architectural descrip-

tion and information about deﬁned data models, e. g.,

in the form of class diagrams.

After code splitting and assignment of target pro-

gramming languages, the compiler extends the differ-

ent parts with additional code in the IR. The Code

Service Call Extender wraps each part with a service.

In other words, they can be called by other program

parts with the common interface explained for the net-

work machines. Therefore, the extender also has to

add code for serialization and deserialization of data.

For example, most modern programming languages

have libraries allowing to deﬁne RESTful service in-

terfaces (Fielding and Taylor, 2002) and to import and

export complex data models as JSON (Ecma Interna-

tional, 2017) or CSV (Shafranovich, 2005). These

implementations can be used.

Following the code extender compiler phase, the

back end translates the program parts step by step in

the target programming language. Since this transla-

tion is language dependent, the compiler can perform

some optimizations in additional Optimizer phases.

For the optimized partial code, a language depen-

dent Code Generator produces high-level code in the

target programming language. Compiling the partial

program itself is outside the compiler’s scope — for

WEBIST 2023 - 19th International Conference on Web Information Systems and Technologies

196

most programming languages there are compilers that

generate executable ﬁles.

Many modern programming languages, such as

Java, R, Python, and JavaScript, require special en-

vironments to be executable. Fortunately, there are

tools to create such environments (e. g., (Docker Inc.,

2023) and (Burns et al., 2019)). One goal of the com-

piler is to generate containers for each partial pro-

gram describing their execution environments and the

services. This is done in the Execution Environment

Generator and bundled in containers. As a result, the

compiler generates a complete distributable and exe-

cutable network program.

6 CONCLUSION / DISCUSSION

This paper presented a new idea for developing dis-

tributed programs. An implementation would allow

to arrange each distributed program as if it is an undis-

tributed one, although it consists of different parts,

no matter which programming language they use. A

compiler distributes the program by splitting it into

several parts in different programming languages. To

achieve this, the program must be deﬁned in a so-

called network programming language. A network

program deﬁnes data models and services, where the

service functionality is described in an individually

available programming language chosen by the de-

veloper. That language that best solves the function-

ality can be used. The overall concept is based on

principles of network machines, which generalize ar-

chitectures of distributed and multiprocessor systems

and are a runtime environment for network programs.

In this paper only the idea of network programs and

a conceptual compiler architecture are described. It

shall give a new view on developing distributed sys-

tems and state-of-the-art approaches. Therefore, an

implementation does not exist yet.

Of course, the proposed approach does not have

only advantages. If development teams do not imple-

ment services separately, the resulting services (and

their interfaces) might be less reusable and more cou-

pled. This problem depends more on architecture and

design decisions than on implementation decisions,

which are the focus of our approach. Furthermore,

our approach leads to new middleware (the network

machine) that must be installed and maintained by en-

terprises, although the goal is to keep this to a mini-

mum. Finally, some developers specialize in a small

number of programming languages. For this reason,

such developers might have problems writing, read-

ing, and understanding network programs.

The implementation effort of our approach de-

pends on the number and types of programming lan-

guages initially supported. The network program-

ming language itself should be less complex, as

should its compiler. One difﬁculty will be recognizing

calls to distributed functions in the target program-

ming languages. The use of a (language-dependent)

library could be a solution for a ﬁrst prototype. The

network machine should be the most complex part, as

it provides several runtime components. A ﬁrst pro-

totype should reuse an existing technology stack to

keep the implementation simple and feasible. How-

ever, compared to other approaches, such as CORBA,

the implementation effort and the hurdle to use our

approach should be lower.

Future work includes the deﬁnition of a ﬁrst gram-

mar of a network programming language, which al-

lows to include existing languages in the description

of functionality. The next step deﬁnes a parser of this

language and the phase of code extensions for service

calls in the compiler. Fortunately, the back end of the

compiler is lightweight, since it can reuse all existing

compilers for the programming languages used in the

program. All this future work contains challenges, but

could be feasible in a few years.

REFERENCES

Apel, S. (2018). Reducing Development Overheads with

a Generic and Model-Centric Architecture for On-

line Games. In IEEE International Conference on

Software Architecture, ICSA 2018, Seattle, WA, USA,

April 30 - May 4, 2018, pages 21–28. IEEE Computer

Society.

Apel, S., Hertrampf, F., and Sp

athe, S. (2019). Towards

a Metrics-Based Software Quality Rating for a Mi-

croservice Architecture - Case Study for a Measure-

ment and Processing Infrastructure. In L

uke, K., Eich-

ler, G., Erfurth, C., and Fahrnberger, G., editors, Inno-

vations for Community Services - 19th International

Conference, I4CS 2019, Wolfsburg, Germany, June

24-26, 2019, Proceedings, volume 1041 of Communi-

cations in Computer and Information Science, pages

205–220. Springer.

Burns, B., Beda, J., and Hightower, K. (2019). Kubernetes:

Up and Running — Dive into the Future of Infrastruc-

ture. O’Reilly, California, USA, 2 edition.

Catlin, H. (2023). Haml. http://haml.info/. Last visit in

September 2023.

Ciccozzi, F., Malavolta, I., and Selic, B. (2019). Execution

of UML models: a systematic review of research and

practice. Software & Systems Modeling, 18(3):2313–

2360.

Cooper, K. D. and Torczon, L. (2011). Engineering a Com-

piler. Morgan Kaufmann, USA, 2nd edition.

De Paoli, F. (2018). Challanges in services research: A

software architecture perspective. In Lazovik, A. and

Compilation of Distributed Programs to Services Using Multiple Programming Languages

197

Schulte, S., editors, Advances in Service-Oriented and

Cloud Computing, pages 219–227, Cham. Springer

International Publishing.

Dobing, B. and Parsons, J. (2006). How UML is used. Com-

munications of the ACM, 49(5):109–113.

Docker Inc. (2023). Empowering App Development for De-

velopers — Docker. https://www.docker.com/. Last

visit in September 2023.

Ecma International (2012). Standard ECMA-335: Common

Language Infrastructure (CLI) — 6th edition (June

2012). http://www.ecma-international.org/publica

tions/ﬁles/ECMA-ST/ECMA-335.pdf.

Ecma International (2017). Standard ECMA-404: The

JSON Data Interchange Syntax — 2nd edition (De-

cember 2017). http://www.ecma-international.org/p

ublications/ﬁles/ECMA-ST/ECMA-404.pdf.

Fielding, R. T. and Taylor, R. N. (2002). Principled design

of the modern Web architecture. ACM Trans. Internet

Techn., 2(2):115–150.

Geisriegler, M., Kolodiy, M., Stani, S., and Singer, R.

(2017). Actor based business process modeling and

execution: A reference implementation based on on-

tology models and microservices. In 43rd Euromicro

Conference on Software Engineering and Advanced

Applications, SEAA 2017, Vienna, Austria, August 30

- Sept. 1, 2017, pages 359–362. IEEE Computer Soci-

ety.

Google (2023). Flutter - Beautiful native apps in record

time. https://ﬂutter.dev/. Last visit in September 2023.

Khronos OpenCL Working Group (2023). The OpenCL

Speciﬁcation. https://registry.khronos.org/OpenCL/

specs/3.0-uniﬁed/html/OpenCL\ API.html.

Kozlovics, S. (2019). The web computer and its operat-

ing system: A new approach for creating web applica-

tions. In Bozzon, A., Mayo, F. J. D., and Filipe, J., edi-

tors, Proceedings of the 15th International Conference

on Web Information Systems and Technologies, WE-

BIST 2019, Vienna, Austria, September 18-20, 2019,

pages 46–57. ScitePress.

Lindholm, T., Yellin, F., Bracha, G., and Buckley, A.

(2014). The Java Virtual Machine Speciﬁcation, Java

SE 8 Edition. Addison-Wesley Professional, Califor-

nia, USA, 8 edition.

Mono Project (2023). Mono — Cross platform, open source

.NET framework. https://www.mono-project.com/.

Last visit in September 2023.

Newman, S. (2015). Building Microservices: Designing

Fine-Grained Systems. O’Reilly, California, USA, 1

edition.

Object Management Group (2017a). Action Lan-

guage for Foundational UML (Alf). Concrete Syn-

tax for a UML Action Language, Version 1.1.

https://www.omg.org/spec/ALF/1.1.

Object Management Group (2017b). OMG Uni-

ﬁed Modeling Language — version 2.5.1.

https://www.omg.org/spec/UML/2.5.1.

Object Management Group (2018). Semantics of a Founda-

tional Subset for Executable UML Models (fUML),

Version 1.4. https://www.omg.org/spec/ALF/1.1.

Object Management Group (2021). Common Object Re-

quest Broker Architecture Speciﬁcation, Version 3.4.

https://www.omg.org/spec/CORBA/3.4.

OpenMP Architecture Review Board (2018).

OpenMP Application Programming Interface

— version 5.0. https://www.openmp.org/wp-

content/uploads/OpenMP-API-Speciﬁcation-5.0.pdf.

Oquendo, F., Leite, J., and Batista, T. (2016). Execut-

ing Software Architecture Descriptions with SysADL.

In Tekinerdogan, B., Zdun, U., and Babar, A., ed-

itors, Software Architecture, pages 129–137, Cham.

Springer International Publishing.

Prinz, T. M., Heinze, T. S., Amme, W., Kretzschmar, J., and

Beckstein, C. (2015). Towards a Compiler for Busi-

ness Processes - A Research Agenda. In de Barros,

M. and R

uckemann, C.-P., editors, SERVICE COM-

PUTATION 2015: The Seventh International Confer-

ences on Advanced Service Computing, Nice, France,

March 22–27, 2015. Proceedings, pages 49–54.

Prinz, T. M., Spieß, N., and Amme, W. (2014). A ﬁrst

step towards a compiler for business processes. In

Cohen, A., editor, Compiler Construction - 23rd In-

ternational Conference, CC 2014, Held as Part of the

European Joint Conferences on Theory and Practice

of Software, ETAPS 2014, Grenoble, France, April 5-

13, 2014. Proceedings, volume 8409 of Lecture Notes

in Computer Science, pages 238–243. Springer.

pug (2023). Getting Started - Pug. https://pugjs.org/. Last

visit in September 2023.

Raible, M. (2018). The JHipster mini-book. C4Media,

USA, 5.0.1 edition.

Shafranovich, Y. (2005). RFC 4180: Common Format

and MIME Type for Comma-Separated Values (CSV)

Files. https://datatracker.ietf.org/doc/html/rfc4180.

Singer, R. (2016). Business process modeling and execu-

tion - A compiler for distributed microservices. CoRR,

abs/1601.05976.

Swagger (2023a). The Best APIs are Built with Swagger

Tools. https://www.swagger.io/. Last visit in Septem-

ber 2023.

Swagger (2023b). OpenAPI Speciﬁcation. https://swagger.

io/speciﬁcation/. Last visit in September 2023.

Tacy, A., Hanson, R., Essington, J., and Tokke, A. (2013).

GWT in Action. Manning Publications Co., Green-

wich, CT, USA, 2nd edition.

Unity Technologies (2023). Unity — Game Engine.

https://unity.com/. Last visit in September 2023.

Yu, C., Royuela, S., and Qui

nones, E. (2020). OpenMP

to CUDA graphs: a compiler-based transformation to

enhance the programmability of NVIDIA devices. In

Stuijk, S. and Corporaal, H., editors, SCOPES ’20:

23rd International Workshop on Software and Com-

pilers for Embedded Systems, St. Goar, Germany, May

25-26, 2020, pages 42–47. ACM.

WEBIST 2023 - 19th International Conference on Web Information Systems and Technologies

198
