A Knowledge Distillation Approach with Time Series Prediction and

Predictive Elastic Telescopic Algorithm in Computing Force Network

Shizhan Lan

1,2

, Zhenyu Wang

, Siyuan Song

and Yuxuan Long

2,*

China Mobile Guxangxi Branch Co., Ltd, Nanning, China

South China University of Technology, Guangzhou, China

Keywords: Computing Force Network, Elastic Scaling, Knowledge Distillation.

Abstract: Computing Force Network (CFN) is a new type of information infrastructure that allocates computing,

storage and network resources on demand and flexibly schedules computing, storage and network resources

among cloud, edge and terminal according to service requirements. Accurate matching between user

resource demand and computing resource is a key problem in CFN. Elastic resource scaling enables elastic

scheduling of computing resources based on service requirements to meet real-time service requirements

and improve computing utilization. Resource elastic scaling based on prediction is a common scaling

strategy. We first proposed a new knowledge distillation method, and then used the relatively advanced time

series prediction algorithm Informer as the basic model to propose a time series prediction model KD-

Informer based on knowledge distillation. Finally, we proposed a predictive elastic telescopic algorithm (P-

HPA). We verified through experiments that our proposed knowledge distillation method improved by

about 10% compared with the existing knowledge distillation algorithm, KD-Informer prediction model

improved the prediction accuracy and reduced the model memory occupation compared with the existing

model, and P-HPA improved the QoS compared with the default HPA.

1 INTRODUCTION

In recent years, the traditional network architecture

has evolved from large-scale cloud data centers to

distributed multi-access edge computing (MEC)

servers scattered across different locations and

mobile intelligent devices, forming a three-layers

network architecture consisting of cloud, edge, and

end (Kong, 2022)-(Garg, 2021). Therefore, how to

integrate ubiquitous and heterogeneous computing

resources with the network to achieve accurate

matching of user needs and computing resources has

become an important research direction for the

future development of networks. In the opportunity

of the integration of computing power and network

development, European Telecommunication

Standards Institute (ETSI) have proposed the

concept of Computing Force Network (CFN).

CFN is a new type of information infrastructure

that flexibly allocates and schedules computing,

storage and network resources according to business

needs among cloud, edge, and end (Zhou, 2023).

there are many business scenarios with high

elasticity demands for resources. Although advanced

resource scheduling strategies and mature

microservice architectures can be used to achieve the

matching of resource demand and supply, existing

static resource scheduling mechanisms and

microservice scheduling mechanisms cannot meet

the dynamic and precise matching of business needs

and resource supply for performance burst scenarios.

Resource elasticity scaling is a technology that

flexibly and dynamically adjusts resource supply

based on real-time resource demands of users(Toka

L, 2020), which can dynamically adapt to user

demand. When user resource demand decreases,

resource allocation is reduced to lower enterprise

costs and increase cluster resource utilization.

According to the type of elasticity scaling, elasticity

scaling can be mainly divided into vertical scaling

and horizontal scaling. Vertical scaling is mostly

used for small-scale applications, which do not

require any modifications to user applications and

directly change the resource quota of the server

where the user application is located. Horizontal

scaling is a more common scaling method, which

mainly involves increasing the number of servers

rather than changing the resource quota of a single

server when the business peak increases. The

management and scheduling of resources in the

Lan, S., Wang, Z., Song, S. and Long, Y.

A Knowledge Distillation Approach with Time Series Prediction and Predictive Elastic Telescopic Algorithm in Computing Force Network.

DOI: 10.5220/0012273200003807

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 2nd International Seminar on Artiﬁcial Intelligence, Networking and Information Technology (ANIT 2023), pages 26-33

ISBN: 978-989-758-677-4

computing network mainly rely on the Kubernetes

resource orchestration platform. The open-source

version of Kubernetes provides HPA and VPA

policies. Among them, HPA adopts a polling

mechanism to obtain the CPU utilization rate of each

Pod from the metrics server, then calculates the

average resource utilization rate of the cluster,

compares it with the user-defined CPU resource

utilization threshold during the decision-making

phase, and finally calculates the expected number of

Pod replicas. To some extent, HPA solves some

elasticity requirements in the computing network.

However, the open-source version of HPA is a

reactive scaling strategy, which passively adjusts

resource allocation based on changes in application

load, resulting in a certain degree of lag and

increasing the SLAs violation rate (Shin S H, 2023)-

(Paulo Pereira, 2019).

The challenges of CFN is presented as follows.

1) Scaling decisions are typically based solely on the

observations from the current scaling period,

primarily focusing on average CPU usage. However,

considering a broader historical perspective could

provide a more accurate understanding of what lies

ahead.2) The default capacity expansion mechanism

is lagging behind. When user resource requirements

change rapidly, the default capacity expansion

mechanism reduces user QoS. 3) The existing

prediction algorithms have some problems, such as

insufficient prediction accuracy and large memory

consumption. Moreover, we propose a predictive

HPA mechanism, on the one hand to monitor the

traffic, on the other hand to achieve early expansion

before load burst. The contributions of this paper are

summarized as follows.

 We proposed a new knowledge distillation

method and it is experimentally verified that

the proposed knowledge distillation method

improves the model accuracy compared to

existing knowledge distillation methods.

 Based on the knowledge distillation method

and the existing time series prediction model

Informer, a new time series prediction model

KD-Informer is proposed in this article. It is

experimentally verified that the proposed

model improves the prediction accuracy

compared to Informer, Reformer, and other

time series models.

 We propose P-HPA based on the above time

series prediction model. Experiment results

show that the P-HPA improves the scaling

accuracy and reduces the SLAs violation rate

compared to the default HPA.

2 RELATED WORK

Elastic resource scaling is not a unique concept to

the computing power network, which has always

been a key factor to consider in cloud computing.

We have conducted research and summarized the

current state of research on resource elasticity

scaling, and Classified it as follows.

Threshold-Based: (Yahya Al-Dhuraibi, 2017)

and (Gourav Rattihalli, 2019) improved vertical

elasticity in lightweight virtualization technology

cloud systems using threshold-based scaling rules.

(Hamzeh Khazaei, 2017) proposed Elastic Docker,

an autonomous solution based on IBM's MAPE-K

principle, which enables autonomous vertical

elasticity for Docker containers. In (Zhicheng Cai,

2022), the authors introduced an automatic scaling

system based on resource utilization, enhancing

Kubernetes' VPA and dynamically adjusting

container allocation in Kubernetes clusters. Both

papers explore container migration and investigate

vertical scaling possibilities, while our proposed

solution focuses on enhancing horizontal

autoscalers. (Toka, 2020) demonstrated the

architecture and initial implementation of Elascale,

which provides automatic scalability and monitoring

as a service for any cloud software system. Elascale

makes scaling decisions based on a tunable linear

combination of CPU, memory, and network

utilization.

Forecast-Based: Short-term demand forecasting

has been extensively studied in various domains

(Kader, 2022)-(Punia, 2020). In the energy sector,

accurate prediction of electricity generation from

wind turbines is crucial. Li et al. (H. Arabnejad,

2017) proposed a four-input neural network that

outperformed traditional single-parameter methods.

For predicting electricity market prices, Catalao et

al. introduced a three-layer feedforward neural

network approach, which proved to be superior to

the previously proposed autoregressive integrated

moving average (ARIMA) methods in terms of time

efficiency and ease of implementation. Inspired by

Tan's work (Horovitz, 2018), who designed a

predictive HPA using the AdaBoost-LSTM

algorithm with improved QoS, we adopt a

prediction-based approach in our system. We aim to

select the most suitable scaling method by

leveraging prediction techniques.

Reinforcement Learning-Based: Arabnejad et

al. (Sherstinsky, 2020) proposed a resource

allocation approach for virtual machines (VMs) by

combining Q-learning and the SARSA algorithm

with an adaptive fuzzy logic controller. They

A Knowledge Distillation Approach with Time Series Prediction and Predictive Elastic Telescopic Algorithm in Computing Force Network

focused on dynamic resource allocation. Similarly,

Horovitz et al. (Vaswani A,2017) introduced a

threshold-based horizontal container autoscaling

solution that utilized Q-learning to adjust scaling

thresholds.

3 SOLUTIONS

In this section, we propose new load prediction

algorithm and prediction HPA algorithm (P-HPA).

We will select a basic model from several time

series prediction models, and a new knowledge

distillation method is used to improve the above

model.

3.1 Time Series Prediction Model

LSTM: LSTM(Forecasting, 2021) is a common

time series prediction model. There are three kinds

of LSTM gates: forget gate, input gate, and output

gate. A gate is a structure that enables information to

pass through selectively. LSTM selects to update or

delete information using the gate structure, and

transmits useful information to the latest decision

unit through cell state for reference. Although this

design method of LSTM solves the problem that

RNN is easy to forget long-term historical

information, LSTM can only solve sequences of 100

orders of magnitude, and the performance of LSTM

is not good for sequences of longer orders of

magnitude. Moreover, since each unit of LSTM has

four fully connected layers, LSTM can be very time

consuming if the network is very deep and the

sequence length is very long.

Transformer: Transformer (Zhao, 2022) is a

deep learning model based on self-attention.

Compared with LSTM model, Transformer can pay

more attention to historical information and improve

the prediction accuracy. However, for long time

series, the calculation time and memory

consumption are huge. When the original

Transformer model deals with the sequence length

of N time series, Both time and space complexity are

O(N

Informer: Informer(Kang, 2022) is an improved

model based on Transformer model, mainly to solve

the problem of long time sequence prediction.

Informer uses ProbSparse self-attention mechanism

and distillation mechanism to shorten the training

time of Transformer model and improve the

predictive performance. In this paper, the Informer

model will be used as the basic model, and we used

knowledge distillation method to improve the

prediction performance of the model. And we call

the final model KD-Informer. Next we will

introduce the process of knowledge distillation.

3.2 Knowledge Distillation

Knowledge distillation refers to the process of

"distilling" the knowledge learned by a complex and

powerful large model and transferring it to a smaller

model with a relatively simpler structure. In

knowledge distillation, the large model with high

complexity and strong learning ability is called the

teacher model, while the smaller model generated by

the large model with a simple structure and fewer

parameters is called the student model. The most

common application of knowledge distillation is to

enable the student model with fewer parameters and

a smaller structure to learn the knowledge of the

teacher model with a more complex structure and

higher accuracy, and deploy the student model on

devices with limited computing power instead of the

teacher model.

Since the proposal of knowledge distillation,

there have been many research achievements in the

field of classification. Zhao et al.(Takamoto, 2020)

reconstructed the classic KD loss into two parts,

namely Target Class Knowledge Distillation

(TCKD) and Non-Target Class Knowledge

Distillation (NCKD), and then proposed

Disentangled Knowledge Distillation (DKD), which

enables TCKD and NCKD to play their roles more

effectively and flexibly, and ultimately demonstrated

the effectiveness of the method in image

classification and object detection tasks. Kang et

al.(Xu, 2022) proposed a new deep neural network-

based class incremental learning method, which

effectively solves the problem of catastrophic

forgetting. These algorithms aim to solve

classification problems. Regression problems are

different from classification problems. Regression

problems are unbounded, which means that the

predicted values of the teacher model may deviate

significantly from the true labels, causing negative

effects on the student model. For regression

problems, Makoto Takamoto et al.(Chen, 2017)

proposed a new method for knowledge distillation

for regression problems, which first defines a new

loss function, and uses the predicted values of the

teacher model to detect abnormal labels in the

original data, thus increasing the robustness of the

student model. Xu et al.(Kitaev, 2020) proposed a

Contrastive Adversarial Knowledge Distillation

(CAKD) for time series regression tasks where the

student and teacher use different architectures. The

ANIT 2023 - The International Seminar on Artiﬁcial Intelligence, Networking and Information Technology

core idea is to use a novel contrastive loss to achieve

instance alignment between the student and teacher.

It can be seen that in regression problems, the

current research mainly designs new loss functions

to make the student model imitate the output of the

teacher model, thus achieving the goal of knowledge

distillation. In this article, a new method is proposed,

which does not adjust the loss value of the student

model, but uses the weighted sum of the predicted

values of the teacher model and the true labels as the

real labels for training the student model based on

the predicted accuracy of the teacher model. The

purpose of this approach is to enable the student

model to imitate the output of the teacher model and

learn the generalization ability of the teacher model

on the one hand, and on the other hand, to reduce the

impact of abnormal values in the true labels on the

student model and improve the prediction accuracy

of the model.

Due to the unbounded nature of time series

prediction, the predicted values from the teacher

model can be arbitrary. In the process of knowledge

distillation, we hope that the student model can take

into account both the true label and the predicted

value provided by the teacher model. When the

predicted value from the teacher model is close to

the true label, the student model should avoid

completely fitting the true label and learn the

generalization ability of the teacher model. When

the predicted value from the teacher model deviates

significantly from the true label, the student model

should try to discard the erroneous knowledge

provided by the teacher model. Most existing

knowledge distillation methods for regression

problems add distillation losses to the student model

based on the difference between the predicted value

from the teacher model and the true label, so as to

make the student model's predicted value closer to

the teacher model's predicted value. In this paper,

based on the above idea, we propose to dynamically

adjust the target of the student model based on the

prediction error of the teacher model, instead of

adding additional losses to the student model.

Formula(1) reflects the relationship between the

predicted value from the teacher model, the true

label, and the label used for training the student

model.

𝑦

𝜆𝑦







1 −𝜆



𝑦





𝑦



represents the predicted output of the teacher

model, y represents the true label, and y^ represents

the actual label used during the training of the

student model. λ is a weight coefficient between 0

and 1, where a lower value of λ indicates that the

student model is less influenced by the teacher

model, and vice versa. The formula for calculating

the weight coefficient λ is as follows:

𝜆1 −



│𝑦



−𝑦│





Formula(2) reflects the relationship between the

predicted output of the teacher model and the true

label, where both 𝑦



and y are values normalized to

the range [-1,1], and the absolute difference between

𝑦



and y can take any value within the range [0,2],

reflecting the error between the predicted output and

the true label. When the error between these two

values is larger, the value of λ becomes smaller. The

process of knowledge distillation algorithm is as

follows.

Algorithm 1: Knowledge distillation algorithm.

1. Training teacher model with big dataset.

2. Initialize the student model S

3. While there are samples that haven’t been

trained do

4. sample←𝒙, 𝒚

5. 𝒚

𝒕

←𝑷𝒓𝒆𝒅𝒊𝒄𝒕𝑻, 𝒙

6. 𝝀←𝑭 𝒚

𝒕

, 𝒚

7. 𝒚

←𝑷 𝝀, 𝒚

𝒕

, 𝒚

8. Train(S,x, 𝒚

)

9. end While

10. return S

3.3 P-HPA

In order to meet the elastic demands of the

computing network, We proposed P-HPA to solve

this problem, which architecture diagram of P-HPA

is presented as follows.

Figure 1: P-HPA architecture diagram.

The monitoring module is the foundation of the

prediction and scaling modules in the elastic scaling

system. The monitoring module collects various

real-time computing network data through

Prometheus and stores it in a persistent database.

A Knowledge Distillation Approach with Time Series Prediction and Predictive Elastic Telescopic Algorithm in Computing Force Network

The prediction module obtains historical data

collected by the monitoring module and stored in the

database for training the prediction model. After the

prediction model is trained based on this historical

data, it is not directly deployed and predicted.

Instead, the knowledge distillation method is used to

compress the pre-trained large model into a small

model, which is then deployed and provides

prediction results for the scaling module. After the

scaling module obtains the prediction results from

the prediction module, the P-HPA calculates the

expected number of replicas, and the deployment

performs the scaling operation.

To ensure the normal operation of the predictive

HPA, two parts of work need to be done: deploying

monitoring components to obtain target metric

values, and using load prediction algorithms for

prediction. In this system, the target metric is QPS

(Query Per Second), specifically the number of http

requests per second. QPS is a custom metric that

cannot be obtained by existing monitoring

components in the cluster, and the metrics server can

only provide core metrics such as CPU and memory

information. To solve the problem of obtaining

custom metrics, a set of Prometheus Custom Metrics

monitoring system needs to be deployed.

Firstly, node-exporter and Prometheus are

deployed, where node-exporter acts as a client to

collect monitoring data from various nodes in the

cluster, and Prometheus acts as a server to store the

collected data in a time-series format. However, the

data collected by Prometheus is incompatible with

the data actually used in Kubernetes. Therefore, the

kube-state-metrics component needs to be deployed,

which converts the monitoring data in Prometheus

into a format that can be used in Kubernetes. At this

point, the monitoring system can monitor the core

metrics in Kubernetes, but to obtain custom metrics

such as QPS, the Prometheus-adapter component

needs to be deployed, which provides an API for

obtaining custom metrics. In order to observe the

cluster status information clearly, the Grafana

visualization component is also deployed.

At this point, the cluster already has the ability to

obtain custom metrics. However, the predictive HPA

still cannot function properly because it does not

know what custom metrics it needs to obtain.

Therefore, the Config Map file of Prometheus-

adapter needs to be modified to include the rules for

obtaining the QPS metric.

4 EXPERIMENT

In this section, we first introduce the dataset used in

this article and the data processing process. Then we

provide the experimental results of KD-Informer and

P-HPA on the dataset.

4.1 Dataset

The dataset is the access volume dataset of the UK

academic backbone network, which can well

represent web applications with seasonal features.

The dataset contains two dimensions, timestamp and

access volume, with a time span of more than two

months and a sampling time of 5 minutes. The

original dataset was divided into three parts: training

set, validation set, and test set, with a ratio of 8:1:1.

There are only 20,000 pieces of data in this data set,

and it is difficult for the model to get better

performance when the amount of data is small.

Therefore, we propose to expand the data set by data

enhancement. The specific methods are as follows.

Algorithm 2: Data enhancement algorithm.

1. Divide the original data set into m child data

sets

. Randomly selected from all child data set data

set 𝑆𝑎𝑚𝑝𝑙𝑒



3. 𝑆𝑎𝑚𝑝𝑙𝑒



weight for 𝛼, others weight for β,

β = (1 − α)/(m − 1)

. for s in S except 𝑆𝑎𝑚𝑝𝑙𝑒



5. 𝑆*+= 𝛽 ∗ s

6. end for

7. 𝑆𝑎𝑚𝑝𝑙𝑒



= S ∗/m

8. Adding gaussian noise

9. return 𝑆𝑎𝑚

𝑝

𝑙𝑒







We used the above data enhancement algorithm to

extend the original data from 20,000 to 64,172.

Before the start of the experiments, we took the

consecutive 20,000 data as the incremental dataset.

The complete extended dataset was used to train the

Informer ensemble model as the teacher model, the

baseline model trained on the incremental dataset

was used for comparison, as well as the KD-

Informer trained on the incremental dataset with the

teacher model.

The evaluation metrics used in this chapter are

mean squared error (MSE), mean absolute error

(MAE), and model memory usage. We first

compares the proposed knowledge distillation

method with the knowledge distillation methods

proposed in references (Chen,2017) and (Lai, 2018).

The teacher models of the three algorithms are

all ensemble Informer models, and the training sets

ANIT 2023 - The International Seminar on Artiﬁcial Intelligence, Networking and Information Technology

all use the incremental dataset. The student models

have the same parameters and structure. Table I

shows the experiment results. From the experimental

results, we can see that the knowledge distillation

methods proposed in this paper and in (Chen, 2017)

have significantly improved the prediction accuracy

of the student model. The former reduced the MSE

loss by 10.8% and the MAE loss by 11.8%

compared to the latter. This result demonstrates the

effectiveness of the proposed knowledge distillation

method.

Table 1: Knowledge distillation experiment.

Metrics KD-Informer (Lai, 2018). (Chen, 2017) none

MSE 0.0222(±0.002) 0.0260(±0.002) 0.0249(±0.002) 0.0266(±0.003)

MAE 0.1069(±0.006) 0.1238(±0.06) 0.1212(±0.006) 0.1245(±0.01)

We compare the performance of KD-Informer

with Informer, Reformer, LSTNet, MTGNN under

different prediction horizons of 36, 72, and 144. We

set the encoder and decoder of KD-Informer to 2 and

1, and the encoder and decoder of informer and

Reformer to 3 and 2, The results are obtained from

the experiments conducted in this study. Table II

shows the experiment results. The experimental

results show that KD-Informer outperforms the

baseline Informer model in terms of both prediction

accuracy and model memory consumption under

different prediction horizons. Specifically, for

prediction horizons of 36, 72, and 144, KD-Informer

achieves MSE reductions of 16.5%, 15.0%, and

13.6%, and MAE reductions of 12.0%, 13.3%, and

30.2%. Based on these experimental results, we can

conclude that KD-Informer can learn the

generalization ability of the teacher model and

improve the prediction accuracy, and achieve similar

results to the teacher model using a small amount of

data and smaller memory.

Table 2: Prediction Model Experiment.

Model Metrics 36 72 144

Informer

MAE 0.1245(±0.01) 0.1601(±0.02) 0.1768(±0.03)

MSE 0.0266(±0.004) 0.0412(±0.008) 0.0580(±0.01)

MEMORY 93.7

Reformer

MAE 0.1583(±0.02) 0.2080(±0.03) 0.2162(±0.04)

MSE 0.0493(±0.003) 0.0683(±0.004) 0.0713(±0.01)

LSTNet

MAE 0.1175(±0.02) 0.1726(±0.04) 0.2308(±0.06)

MSE 0.0437(±0.008) 0.0999(±0.010) 0.1524(±0.015)

MTGNN

MAE 0.1103(±0.04) 0.1652(±0.04) 0.2219(±0.08)

MSE 0.0283(±0.004) 0.0660(±0.005) 0.1172(±0.01)

KD- MAE 0.1096(±0.006) 0.1388(±0.008) 0.1528(±0.01)

Model Metrics 36 72 144

Informer

MAE 0.1245(±0.01) 0.1601(±0.02) 0.1768(±0.03)

MSE 0.0266(±0.004) 0.0412(±0.008) 0.0580(±0.01)

MEMORY 93.7

Informer

MSE 0.0222(±0.002) 0.0350(±0.004) 0.0405(±0.005)

MEMORY 62.7

We compare the experimental results of the Informer

model without knowledge distillation and the model

with knowledge distillation to verify the

effectiveness of knowledge distillation. Table III

shows the experiment results. The experimental

results are shown as follows. From the experimental

results, we can see that the addition of knowledge

distillation greatly improves the predictive

performance of the model compared with the default

Informer.

According to the experimental results in Fig. 2,

we can see that compared with default HPA, P-HPA

can realize the capacity expansion in advance when

the traffic surges. Therefore, in the computing

network, P-HPA proposed in this paper can

effectively avoid the situation of QoS reduction

caused by insufficient resource supply. As shown in

Fig.3, we can also see that P-HPA based on KD-

Informer and the P-HPA based on Informer can

basically achieve capacity expansion before load

burst, but the expansion ratio of the former is more

accurate than that of the latter. At the same time, it

also proves that KD-Informer has improved the

prediction accuracy compared with Informer

algorithm. From the above experimental results and

analysis, we can draw the following conclusions:

Compared with the default HPA mechanism, the P-

HPA can realize capacity expansion before load

changes, effectively ensure the QoS of user

applications, and provide a solution to the resource

elastic scaling problem under the computing

network.

(a) sequence 1

1000

2000

3000

4000

5000

6000

7000

1000

2000

3000

4000

5000

6000

7000

1 11213141516171

capcity

traffic

time/t

true traffic

our

default

A Knowledge Distillation Approach with Time Series Prediction and Predictive Elastic Telescopic Algorithm in Computing Force Network

(b) sequence 2

Figure 2: Comparison between P-HPA and default HPA.

(a) sequence 1

(b) sequence 2

Figure 3: Comparison between P-HPA and based on

KD-Informer and Informer.

5 CONCLUSION

In this paper, we proposed a new knowledge

distillation method, a advanced time series

prediction model and a predictive HPA. A new

knowledge distillation method is proposed to solve

the problem that the prediction model occupies a

large memory and requires a large number of

training samples. In order to achieve advance

expansion, we proposed a time series prediction

model and predictive HPA mechanism, and our

method achieves advance accurate scaling compared

with the existing methods. The experiment results

have shown that our methods are better the state of

arts.

In future work, we plan to apply our P-HPA in a

real cloud container cluster and try to improve the

accuracy of P-HPA. In addition, we can also try to

design more advanced knowledge distillation

algorithm to address the challenges in CFN.

REFERENCES

Kong X, Wu Y, Wang H, et al. Edge Computing for

Internet of Everything: A Survey[J]. IEEE Internet of

Things Journal, 2022, 9(23): 23472-23485.

https://doi.org/10.1109/JIOT.2022.3200431

Garg S, Kaur K, Kaddoum G, et al. Security in IoT-driven

mobile edge computing: New paradigms, challenges,

and opportunities[J]. IEEE Network, 2021, 35(5): 298-

305. https://doi.org/10.1109/MNET.211.2000526

Zhou Z, Zhang C, Ma L et al. AHPA : Adaptive

Horizontal Pod Autoscaling Systems on Alibaba Cloud

Container Service for Kubernetes[J]. arXiv preprint

arXiv, 2023. https://arxiv.org/abs/2303.03640

Toka L, Dobreff G, Fodor B et al. Adaptive AI-based

auto-scaling for Kubernetes[J]. 2020 20th IEEE/ACM

International Symposium on Cluster, Cloud and

Internet Computing, 2020: 599–608.

https://doi.org/10.1109/CCGrid49817.2020.00-33

Shin S H, Kim D, Kim T et al. High Concurrency

Response Strategy based on Kubernetes Horizontal

Pod Autoscaler[J]. Journal of Physics: Conference

Series, 2023, 2451(1): 012001.

https://doi.org/10.1088/1742-6596/2451/1/012001

MK Mohan Murthy, HA Sanjay J A. Threshold based auto

scaling of virtual machines in cloud environment[A].

IFIP International Conference on Network and

Parallel Computing[C]. 2014: 247–256.

https://doi.org/10.1007/978-3-662-44917-2_21

Paulo Pereira, Jean Araujo, Paulo Maciel et al. A Hybrid

Mechanism of Horizontal Auto-scaling Based on

Thresholds and Time Series[C]. 2019 IEEE

International Conference on Systems, Man and

Cybernetics (SMC). 2019: 2065–2070.

https://doi.org/10.1109/SMC.2019.8914522

Yahya Al-Dhuraibi, Fawaz Paraiso F P. Autonomic

Vertical Elasticity of Docker Containers with

ELASTICDOCKER[C]. 2017 IEEE 10th International

Conference on Cloud Computing (CLOUD). 2017: 25–

30. https://doi.org/10.1109/CLOUD.2017.67

Gourav Rattihalli, Madhusudhan Govindaraju, Hui Lu et

al. Exploring potential for non-disruptive vertical auto

scaling and resource estimation in kubernetes[C]. 2019

IEEE 12th International Conference on Cloud

1000

2000

3000

4000

5000

6000

7000

1000

2000

3000

4000

5000

6000

7000

1 11213141516171

capcity

traffic

time/t

1000

2000

3000

4000

5000

6000

7000

1000

2000

3000

4000

5000

6000

7000

1 11213141516171

capcity

traffic

time/t

true traffic

our

Informer

1000

2000

3000

4000

5000

6000

7000

1000

2000

3000

4000

5000

6000

7000

1 11213141516171

capcity

traffic

time/t

ANIT 2023 - The International Seminar on Artiﬁcial Intelligence, Networking and Information Technology

Computing (CLOUD). 2019: 08–13. https://doi.org

/10.1109/CLOUD.2019.00018

Hamzeh Khazaei et al. Elascale: Autoscaling and

Monitoring as a Service[J]. arXiv preprint arXiv, 2017.

https://arxiv.org/abs/1711.03204

Zhicheng Cai et al. Inverse Queuing Model-Based

Feedback Control for Elastic Container Provisioning of

Web Systems in Kubernetes[J]. IEEE Transactions on

Computers, 2022, 71(2): 337–348. https://doi.org/10

.1109/TC. 2021.3049598

Toka L, Dobreff G, Fodor B, et al. Adaptive AI-based

auto-scaling for Kubernetes[C]//2020 20th IEEE/ACM

International Symposium on Cluster, Cloud and

Internet Computing (CCGRID). IEEE, 2020: 599-608.

https://doi.org/10.1109/CCGrid49817.2020.00-33

Kader N I A, Yusof U K, Khalid M N A, et al. A review

of long short-term memory approach for time series

analysis and forecasting[C]//International Conference

on Emerging Technologies and Intelligent Systems.

Cham: Springer International Publishing, 2022: 12-21.

https://doi.org/10.1007/978-3-031-20429-6_2

Li S, Wunsch D C, O’Hair E A et al. Using neural

networks to estimate wind turbine power generation[J].

IEEE Transactions on Energy Conversion, 2001,

16(3): 276–282. https://doi.org/10.1109/60.937208

Punia S, Nikolopoulos K, Singh S P, et al. Deep learning

with long short-term memory networks and random

forests for demand forecasting in multi-channel

retail[J]. International journal of production research,

2020, 58(16): 4964-4979.

H. Arabnejad, C. Pahl, P. Jamshidi and G. Estrada. A

Comparison of Reinforcement Learning Techniques

for Fuzzy Cloud Auto-Scaling[C]. 2017 17th

IEEE/ACM International Symposium on Cluster,

Cloud and Grid Computing (CCGRID). 2017: 64–73.

https://doi.org/10.1109/CCGRID.2017.15

Horovitz S. Horovitz et al. Efficient Cloud Auto-Scaling

with SLA Objective Using Q-Learning[C]. 2018 IEEE

6th International Conference on Future Internet of

Things and Cloud. 2018: 06–08.

https://doi.org/10.1109/FiCloud.2018.00020

Sherstinsky A. Fundamentals of Recurrent Neural

Network (RNN) and Long Short-Term Memory

(LSTM) network[J]. Physica D: Nonlinear

Phenomena, 2020, 404: 132306.

Vaswani A, Shazeer N, Parmar N et al. Attention Is All

You Need[J]. Advances in neural information

processing systems, 2017, 30. https://doi.org/10

.1016/j.physd.2019.132306

Forecasting T, Zhou H, Zhang S et al. Informer: Beyond

Efficient Transformer for Long Sequence Time-Series

Forecasting[C]. Proceedings of the AAAI conf. on

Artificial Intelligence. 2021: 11106–11115.

https://doi.org/10.1609/aaai.v35i12.17325

Zhao B, Song R, Qiu Y. Decoupled Knowledge

Distillation[J]. Proceedings of the IEEE/CVF Conf. on

Computer Vision and Pattern Recognition, 2022:

11953–11962. https://arxiv.org/ abs/2203.08679

Kang M, Park J. Class-Incremental Learning by

Knowledge Distillation with Adaptive Feature

Consolidation[J]. Proceedings of the IEEE/CVF Conf.

on Computer Vision and Pattern Recognition, 2022:

16071–16080. https://arxiv.org/abs/ 2204.00895

Takamoto M, Morishita Y. An Efficient Method of

Training Small Models for Regression Problems with

Knowledge Distillation[C]. 2020 IEEE Conf. on

Multimedia Information Processing and Retrieval

(MIPR), 2020: 67–72. https://doi.org/10.1109/

MIPR49039. 2020.00021

Xu Q, Chen Z, Ragab M et al. Neurocomputing Contrastive

adversarial knowledge distillation for deep model

compression in time-series regression tasks[J].

Neurocomputing, Elsevier B.V., 2022, 485: 242–251.

https://doi.org/10.1016/j.neucom.2021.04.139

Chen G, Choi W, Yu X, et al. Learning efficient object

detection models with knowledge distillation[C]

Proceedings of the 31st International Conference on

Neural Information Processing Systems. 2017: 742-

751. https://dl.acm.org/doi/abs/10.5555/3294771.3294

842

Kitaev N, Kaiser Ł, Levskaya A. Reformer: The Efficient

Transformer[J]. arXiv preprint arXiv, 2020: 1–12.

https://arxiv.org/abs/2001.04451

Lai G, Chang W, Yang Y et al. Modeling long-and short-

term temporal patterns with deep neural networks[C].

The 41st international ACM SIGIR conference on

research & development in information retrieval.

2018: 95–104. https://doi.org/10.1145/3209978.32

10006

Wu Z, Pan S, Long G et al. Connecting the dots:

Multivariate time series forecasting with graph neural

networks[C]. Proceedings of the 26th ACM SIGKDD

International Conference on Knowledge Discovery &

Data Mining. 2020: 753–763. https://doi.org/

10.1145/3394486.3403118

A Knowledge Distillation Approach with Time Series Prediction and Predictive Elastic Telescopic Algorithm in Computing Force Network
