OPTIMAL ANALYSIS OF A HYBRID AUTHENTICATION
SYSTEM: WEB SECURITY VERSUS SYSTEM PERFORMANCE
Ben Soh, Aaron Joy
Applied Computing Research Institute
Department of Computer Science & Computer Engineering
La Trobe University
Bundoora, VIC, Australia 3083
Keywords: Authentication, Web Security
Abstract: A web authentication system uses a number of functions to provide integrity of messages sent between the
client and the web server. These include hash functions, public key encryption, and nonce length. In this
paper, we present an optimal analysis of investigating the effects of some different parameters on the web
security and performance of the authentication system. Our main aim is to devise a technique to achieve the
best of both worlds: optimal web security and system performance. To the best of our knowledge, such
approach is the first attempt to combine the two dependability attributes in a quantitative study.
1 INTRODUCTION
Figure 1 shows the web server framework that we
have developed at La Trobe University (A Joy et al.,
2002). A secure channel established between a client
and the web server is used to combat interception
and modification attacks. However, to protect the
client and web server against fabrication attacks (C.
Kaufman et al., 1995), we need to incorporate into
the secure web server framework two forms of
authentication: (i) user-level authentication and (ii)
machine-level authentication. User-level
authentication is provided by one-time passwords
(OTP) (A. Jones, 1981)(N.Haller et al., 1998), while
machine-level authentication is provided by a hybrid
authentication system, which is the subject of this
paper.
Figure 1: Full web server framework
The hybrid authentication system uses a number of
functions to provide integrity of messages sent
between the client and the web server. These include
hash functions, public key encryption, and nonces
(see Section 2). In this paper, we present a
quantitative analysis of investigating the effects of
various parameters on the security and performance
of the hybrid authentication system. Our main aim is
to devise a technique to achieve the best of both
worlds: optimal web security and optimal system
performance. To the best of our knowledge, this type
of quantitative analysis in terms of the two
dependability attributes is still lacking in the
research community.
2 THE HYBRID
AUTHENTICATION SYSTEM:
BRIEF DESCRIPTION
Authentication
Encrypted Channel
Connection-Oriented
Logging and
Intrustion Detection
User
Machine
The following is a semantic representation of the
hybrid authentication system based on X.509 (C.
I’Anson et al., 1990), where A is a client and B is an
web server. Firstly, A generates a non-repeating
number, r
A
, which is used to detect replay attacks
and to prevent forgery. A then sends the following
message to B:
A Æ B: B {r
A
, Ap, sgnData} ,
where
281
Soh B. and Joy A. (2004).
OPTIMAL ANALYSIS OF A HYBRID AUTHENTICATION SYSTEM: WEB SECURITY VERSUS SYSTEM PERFORMANCE.
In Proceedings of the First International Conference on E-Business and Telecommunication Networks, pages 281-286
DOI: 10.5220/0001383502810286
Copyright
c
SciTePress
B {} = the encryption of {} using B’s public key
r
A
= non-repeating number
Ap = A’s public key
SgnData = Digital signature.
The sgnData is for data origin authentication and is
provided by a digital signature that involves the hash
value of the data and is then encrypted using the
user’s private key. This provides verification that A
and B are in possession of their appropriate private
key. Once B receives the message it carries out the
following actions:
Obtains Ap
Verifies the signature, and thus the integrity
of the information.
Checks that B itself is the intended recipient.
Checks if r
A
has not been replayed.
Once the above verification process is
completed, B generates r
B,
a non-repeating number
similar to r
A
. B then sends the following message to
A :
BÆA: A{r
B
, Bp, r
A,
sgnData}.
B can also provide data origin authentication by
using sgnData which is included in the message.
Once receiving the message, A will:
Verify the signature, and thus the integrity
of the information.
Check that B itself is the intended recipient.
Check if rB has not been replayed.
Check that rA is the same rA it has sent.
If all the above criteria are satisfied, A sends B
the final message
AÆB: B{r
B
,Bp}
On receiving this message, B checks that the same r
B
was sent back and the message is meant for B. The
final message is crucial for preventing a man-in-the-
middle attack on the web server, by enabling the
client and the web server to authenticate each other
without the use of a timeserver.
3 PERFORMANCE AND
SECURITY EVALUATION
PARAMETERS OF THE HYBRID
AUTHENTICATION SYSTEM
The dependability, in terms of system performance
and security of our hybrid authentication system,
depends on four main parameters: the type of hash
function, the nonce length, the length of the random
seed, and the number of random seeds used. These
four parameters are discussed in the following
subsections.
3.1 Hash Functions
A hash function is a “computationally efficient
function mapping binary strings of arbitrary length
to binary strings of some fixed length, called hash
values” (A. Menezes et al.,1996). For a hash
function to be of cryptographically secure, (i) the
hash function h must be chosen so that it is
computationally infeasible to find two distinct inputs
which will hash to a common value, and (ii) given a
specific hash-value say y it is computationally
infeasible to find an input x such that h(x)=y.
The hash function is used in the hybrid
authentication system to provide data integrity for
the messages sent by the web server and the client.
The information in the message is hashed and the
resultant hash value is encrypted with the public key
of the recipient. Our hybrid authentication system
can accept any of the three types of hash functions:
MD5 (R.Rivest,1992), RIPEMD-160 (B. Preneel et.,
1997), and SHA-1 (SECURE HASH STANDARD,
1995). Each of these hash functions has its own
specifications but the same underlying principles.
They can all provide the hash value for the creation
of a digital signature in the hybrid authentication
system.
3.2 Nonce Length
A nonce is a set length of random bytes that the
client and server send to each other. It contains a
value used no more than once as an identifier to
prevent (undetectable) replay attacks (A. Menezes et
al.,1996). The nonce is a major part of the hybrid
authentication system, by enabling the system to
carry out its authentication function without the use
of timeservers. To achieve this, the clients include a
nonce in an outgoing message sent to the web
server. Thus, any recipient of these messages
requires the knowledge of this nonce. This enables
the client and the web server to achieve a fixed point
as their reference time during the message
exchanges. This is analogous to a shared clock. The
maximum time permitted for a message exchange is
constrained by the timeout period, which somewhat
enforces the use of local, independent clocks (A.
Menezes et al.,1996). The three nonce sizes used in
our hybrid authentication system are 100, 50, and 20
(bytes), thus giving sample spaces of 6.668 x 10
240
,
2.582 x 10
120
, and 1.461 x 10
48
, respectively.
ICETE 2004 - SECURITY AND RELIABILITY IN INFORMATION SYSTEMS AND NETWORKS
282
3.3 Random-Seed Length
The random-seed length is the size of the random
data that will be placed into the array in the function
RAND_pseudo_bytes() of the hybrid authentication
system. This random data is then used by another
function RAND_seed() to carry out the public-key
data encryption. The three sample spaces used are
1000, 500, and 100 (bytes).
3.4 The Number of Random Seeds
Used
The number of times the public–key encryption is
seeded is given by the number of random seeds
generated by the following code segment :
for(int j=0; j < NUMBER_OF_TIMES_SEEDED;
j++)
{
RAND_pseudo_bytes(rand_seed,
KEYGEN_NUMBER_RAND_SEED);
RAND_seed(rand_seed, sizeof rand_seed);
}
It is noteworthy that the code uses the for() loop so
that the function RAND_pseudo_bytes() and
RAND_seed() can be run more than once.
4 PERFORMANCE EVALUATION:
EXPERIMENTAL SETUP AND
RESULTS
The performance evaluation of the hybrid
authentication system is based on the speed at which
the client and server authenticate each other with the
variation of the four parameters discussed in the
previous section. The simulations were run on a
Pentium (200MMX with 64mb of EDO ram) using
Redhat Linux 7.0. The UNIX time command was
used to obtain the time required for the hybrid
authentication system to complete the full
authentication task. The evaluation was based on the
end-to-end authentication in that messages were
passed from the server functions to the client
functions without going through the
communicational channel. This was done so that the
results would not be affected by the channel delays
between the client and the server.
Tables 1-4 are snapshots of the results obtained and
respectively show the effects on the system
performance of the hybrid authentication system
caused by:
hash functions
the nonce length
the random-seed length
the number of random seeds used.
Table 1: Performance wrt hash functions
Nonce
length
(bytes)
Seed
length
(bytes)
Average Performance Time
(s) wrt hash functions
No
of
seed
s
used
SHA-1 RIPEN
D-160
MD5
100 1000 .3973 .3823 .3863
50 500 .2999 .3010 .2980
20 100 .2677 .2720 .2683
100 100 .2707 .2637 .2647
50 500 .2870 .2843 .2837
20 1000 .3123 .3220 .3127
100 500 .2737 .2750 .2727
50 1000 .2883 .2847 .2850
20 100 .2627 .2690 .2653
Table 2: Performance wrt the nonce length
Average Performance
Time (s) wrt nonce
length
No o
f
Hash
Function seeds
used
Seed
length
(bytes)
100 50 20
SHA-1 1000 .3973 .3317 .3323
RIPEND-160 500 .3127 .3010 .2987
MD5 100 .2690 .2713 .2683
SHA-1 100 .2707 .2667 .2657
RIPEND-160 500 .2857 .2843 .2860
MD5 1000 .3083 .3083 .3127
SHA-1 500 .2737 .2790 .2730
RIPEND-160 1000 .2850 .2847 .2983
MD5 100 .2627 .2677 .2653
Table 3: Performance wrt the seed length
Average Performance
Time (s) wrt seed length
No
of
seeds
used
Nonce
length
(bytes)
Hash function
1000 500 100
100 SHA-1 .3973 .2970 .2687
50 RIPEND-160 .3473 .3010 .2677
20 MD5 .3330 .2970 .2683
100 SHA-1 .3110 .2840 .2707
50 RIPEND-160 .3127 .2843 .2700
20 MD5 .3127 .2853 .2727
100 SHA-1 .2877 .2737 .2707
50 RIPEND-160 .2847 .2777 .2627
20 MD5 .2843 .2777 .2653
OPTIMAL ANALYSIS OF A HYBRID AUTHENTICATION SYSTEM: WEB SECURITY VERSUS SYSTEM
PERFORMANCE
283
Table 4: Performance wrt the number of seeds
Average Performance
Time (s) wrt the
number of seeds
Hash
functions
Nonce
length
(bytes)
Seed
length
(bytes)
3 2 1
SHA-1
100 1000 .3973 .3110 .2877
RIPEND-160
50 500 .3010 .2843 .2777
MD5
20 100 .2683 .2727 .2653
SHA-1
100 100 .2687 .2707 .2707
RIPEND-160
50 1000 .3473 .3127 .2847
MD5
20 500 .2970 .2a853 .2777
SHA-1
100 500 .2970 .2840 .2737
MD5
50 1000 .3323 .3083 .2850
RIPEND-160
20 100 .2720 .2713 .2690
Based on the results of the performance evaluation,
we define for our hybrid authentication system a
measure called Performance Index (PI) as the
inverse of the average performance time. For
example, for the hybrid authentication system using
SHA-1 as the hash function, the nonce length of 100
bytes, the seed length of 1000 bytes and 3 random
seeds, the PI is 1/0.3573 = 2.7988.
5 WEB SECURITY EVALUATION
As a matter of fact, quantitative measures for web
security evaluation are yet to be agreed upon in the
research community. Consequently we need some
mechanisms to calibrate our hybrid authentication
system from the security point of view. To this end,
we utilize the industrial data and standards, expert
knowledge and research outcomes in the field,
within the sample space of the four parameters
described in Section 3. In the sample space of the
parameter concerned, a parameter value deemed to
offer the maximum security will be given a weight
of 1; the weight is otherwise less than 1 (which we
will discuss below). For our hybrid authentication
system, we define a measure called Security Index
(SI) as the average weight of the 4 parameters:
SI = (hash_function_weight +
nonce_length_weight + seed_length_weight +
number_of_seeds_weight) / 4
where hash_function_weight etc are self-
explanatory. This calibration would not lead to an
absolute measure for security evaluation but would
be useful as a tool for comparative and sensitivity
studies by varying the values of those parameters of
the hybrid authentication system.
For our hybrid authentication system, the sample
space of the hash function parameter is {MD5,
RIPEND-160, SHA-1}. Since the collision method
found by Paul Oorschot and Michael Wiener (R. M.
Needham, 1993), MD5 and RIPEMD-160 have been
found to contain weaknesses. In particular, the
CryptoBytes newsletter (B. Preneel et., 1997) best
described MD5’s situation: “The presented attack
does not yet threaten practical applications using
MD5, but it comes rather close”. Also, Paul Van
Oorschot and Mike Wiener (C. Kaufman et al.,
1995) showed that a brute-force job on MD5 can be
done in less than a month…” To date, SHA-1 has
been found to be the most secure hash function
among the three. Based on the expert knowledge,
we consider within the sample space that SHA-1 has
a hash_funciton_weight of 1. Using the 30/70 rule
for a comparative study, we assign 0.43 to the
hash_function_weight of RIPEND-160 and 0.18 to
MD5, which is deemed the weakest among the three.
The nonce is an important factor for authentication
in that the larger the nonce the less chance will the
nonce be predicted and compromised by an attacker.
Our nonce_length space is {100, 50, 20}. On this
basis, 100 bytes of nonce is given a weight of 1.
Using the rule of proportionality for a comparative
study, 50 bytes of nonce is given a weight of 0.5,
and 20 bytes of nonce a weight of 0.2.
For the random-seed length, the sample space used
is {1000, 500, 100}. From a security point of view,
the larger the random data seeded the more random
is the public-key encryption. This implies that it will
be harder for an attacker to find a pattern (National
Institute Of Standards and Technology, 2001).
Hence, 1000 bytes of seed length has a weight of 1,
500 bytes a weight of 0.5, and 100 bytes a weight of
0.1 (by proportioning).
The sample space for the number of random seeds
used is {3, 2, 1}. The number of seeds determines
the number of times the public-key encryption is
seeded. If data are seeded more frequently, they will
tend to be more random, which would be harder for
an attacker to compromise. Thus, a weight of 1 is
given if the number of seeds used is 3. By
proportioning, a weight of 0.67 and 0.33 is given if
the number of seeds used is 2 and 1, respectively.
ICETE 2004 - SECURITY AND RELIABILITY IN INFORMATION SYSTEMS AND NETWORKS
284
6 OPTIMAL WEB SECURITY-
AND-PERFORMANCE INDEX
FOR THE HYBRID
AUTHENTICATION SYSTEM
From the above discussions, it is obvious that
performance and security are two opposing
dependability attributes. For example, if the random
seed length is excessive (which is good for security
reasons), system performance will be reduced
tremendously, as mentioned in (D. Eastlake et al.,).
This points to the need for a compromise between
performance and security for our hybrid
authentication system. To this end, using
Performance Index (PI) and Security Index (SI)
defined in Sections 4 and 5 respectively, we propose
a composite index called Authentication System
Index (ASI), which is defined as follows:
ASI = PI x SI.
Using the ASI, we are able to find an optimal set of
the parameters used in our hybrid authentication
system, in terms of both security and system
performance. Table 5 gives a snapshot of the results
involving ASI. By analysing all the data (not
included here because of space constraints), we are
able to list down the following observations for our
hybrid authentication system:
1. The random-seed size of 1000 bytes is too large,
which reduces the ASI value. A seed size of 500
(or 100) bytes may give optimal ASI.
2. The nonce size of 20 bytes is too small. A size of
100 (or 50) bytes may produce optimal ASI.
3. For optimal ASI, the number of random seeds
used can be just one.
7 CONCLUSION
In this paper, we have presented a quantitative
analysis on the web security and system
performance evaluation of an actual hybrid
authentication system. We have proposed a
composite index called Authentication System Index
(ASI), which can be used to evaluate at the same
time both the security and performance of our hybrid
authentication system.
From the results obtained, we have found that: (i) a
nonce size of either 50 or 100 bytes is fine for
optimal security and system performance; this
concurs with the findings presented in (D. Eastlake
et al.,); (ii) it is claimed in (D. Eastlake et al.,) that
1000 bytes for the size of the seeds used seem too
large, and our study in this paper proves this point;
our results show 100 (or 500) bytes is a good seed
size to be used for our authentication system, and
(iii) the number of seeds used (i.e. frequency of
seeding the public-key encryption) can be just once,
which would give sufficient randomness.
REFERENCES
A Joy and B Soh, “A proposed secure TCP connection-
oriented model for e-commerce systems,” Proceedings
of International Conference on Internet and
Multimedia Systems and Applications, Hawaii, Aug
12-14, pp 68-73, 2002.
C. Kaufman, R. Perlman, and M. Speciner. Network
Security Private Communications in a Public World,
Prentice Hall 1995.
A. Jones, “Password authentication with insecure
communication,” ACM Communications, vol. 24,
number 11, 1981, pp 12-21.
N.Haller, C. Metz, P. Nesser, and M. Straw . “A One-
Time Password System,RFC2289, February 1998,
http://www.ietf.org.
C. I’Anson and C. Mitchell. “Security defects in CCITT
recommendation X.509 – The directory authentication
framework,” Computer Communications Review, pp
45-53, April 1990.
A. Menezes, P. van Oorschot and S. Vanstone, Handbook
of Applied Cryptography, CRC Press, 1996.
R.Rivest, “The MD5 Message-Digest Algorithm”, Internet
RFC 1321, April 1992.
B. Preneel, and A. Bosselaers, “The Cryptographic Hash
Function RIPEMD-160”, CryptoBytes, vol 3, no 2,
Autumn 1997.
National Institute of Standards and Technology, SECURE
HASH STANDARD, FIPS PUB 180-1, 1995. February
13 2001
http://www.itl.nist.gov/fipspubs/fip180-1.htm.
R. M. Needham , “Denial Of Service,” Proceedings of the
1st ACM conference on Computer and
Communications Security
, pp 151-153, November 3-5,
1993, Fairfax, VA USA.
National Institute Of Standards and Technology, FIPS 112
Password Usage. 1995. September 2001,
http://www.itl.nist.gov/fipspubs/fip112.htm.
D. Eastlake, S Crocker, and J Schiller, “Randomness
Recommendations for Security”, rfc1750,
http://www.i
OPTIMAL ANALYSIS OF A HYBRID AUTHENTICATION SYSTEM: WEB SECURITY VERSUS SYSTEM
PERFORMANCE
285
APPENDIX
Table 5: Performance versus Security
No of seeds
used
Nonce
length
(bytes)
Seed
length
(bytes)
Hash
functn
PI SI ASI
3 100 1000 SHA-1 2.51701.00002.5170
3 50 500 SHA-1 3.33440.75002.5008
3 20 100 SHA-1 3.73550.57502.1479
2 100 100 SHA-1 3.69410.69252.5582
2 50 500 SHA-1 3.48430.66752.3258
2 20 1000 SHA-1 3.20200.71752.2974
1 100 500 SHA-1 3.65360.70752.5849
1 50 1000 SHA-1 3.46860.70752.4469
1 20 100 SHA-1 3.80660.40751.5512
3 100 1000 RIPEND-
160
2.61570.85752.2430
3 50 500 RIPEND-
160
3.32230.60752.0183
3 20 100 RIPEND-
160
3.67650.43251.5901
2 100 100 RIPEND-
160
3.79220.55002.0857
2 50 500 RIPEND-
160
3.51740.52501.8467
2 20 1000 RIPEND-
160
3.10560.57501.7857
1 100 500 RIPEND-
160
3.63630.56502.0545
1 50 1000 RIPEND-
160
3.51250.56501.9846
1 20 100 RIPEND-
160
3.71750.26500.9851
3 100 1000 MD5 2.58870.79502.0580
3 50 500 MD5 3.35570.54501.8289
3 20 100 MD5 3.72720.37001.3791
2 100 100 MD5 3.77790.48751.8417
2 50 500 MD5 3.52490.46251.6302
2 20 1000 MD5 3.19800.51251.6390
1 100 500 MD5 3.66700.50251.8427
1 50 1000 MD5 3.50880.50251.7631
1 20 100 MD5 3.76930.20250.7632
ICETE 2004 - SECURITY AND RELIABILITY IN INFORMATION SYSTEMS AND NETWORKS
286
