Towards a Flexible Access Control Mechanism for

E-Transactions

Vishwas Patil and R.K. Shyamasundar

School of Technology and Computer Science

Tata Institute of Fundamental Research

Homi Bhabha Road, Colaba, Mumbai - 400005, India

Abstract. Security over the Internet depends on a clear distinction between au-

thorized and un-authorized principals. Discriminating between the two involves:

identiﬁcation (user identiﬁes himself/herself), authentication (the system vali-

dates the user’s identity) and authorization (speciﬁc rights granted). Thus, it is

important to develop speciﬁcations for access control that realize the above prop-

erties with ease. Public Key Infrastructures (PKIs) provide a basis for specifying

access-control to the users in a secure and non-reputable fashion. Some of the

general deﬁciencies of PKIs are: (i) they are rigid and cannot scale across dif-

ferent PKI frameworks, (ii) due to efﬁciency reasons, PKIs are constrained to be

just static data-structures shipped across domains and hence cannot carry any dy-

namic or state-based information, and (iii) for reasons of (ii) the recipients are not

explicitly deﬁned. In this paper, we shall argue that a judicious mix of digital cer-

tiﬁcates and authentication mechanisms would lead to a ﬂexible security policy

speciﬁcation having both static and dynamic capabilities and lead to user-friendly

mechanisms to achieve availability of secure services in e-commerce.

1 Introduction

Web has become an important medium for disseminating information, doing commerce

and business. Organizations are making their whole work-ﬂow system e-enabled, shar-

ing their resources with clients, collaborators, out-stationed employees etc. It has be-

come necessary to deploy mechanisms that would restrict access of such networked

resources only to the authorized users. The main security threats are:

– Conﬁdentiality: gets violated when unauthorized users get protected information,

– Integrity: gets violated when unauthorized user modiﬁes protected information,

– Availability: gets violated when the system is prevented from doing its intended

function.

Cryptographic frameworks like PKI [1] have become de facto standards for realizing

such requirements since it provides authentication, authorization of users, data integrity,

conﬁdentiality, and non-repudiation of transactions.

Access control mechanisms based on digital certiﬁcates solely, help in authenticat-

ing and determining user’s authorizations. However, it needs an extensive infrastruc-

ture, which is costly and as certiﬁcates are not modiﬁable once issued, the dynamic or

context-based authorization policies cannot be embedded into them.

Patil V. and K. Shyamasundar R. (2004).

Towards a Flexible Access Control Mechanism for E-Transactions.

In Proceedings of the 1st International Workshop on Electronic Government and Commerce: Design, Modeling, Analysis and Security, pages 66-81

DOI: 10.5220/0001403700660081

 SciTePress

There are access control mechanisms that are based on the capability models, tradi-

tionally used in operating systems, in which each process originating from an authorized

user inherits same power and this power has to be trimmed down or ampliﬁed based on

the context/state of the system, as the case in capability based operating systems. This

is not possible in a PKI based access control mechanisms because of the static nature of

certiﬁcates that carry only authorization information. However, the rationale of a PKI

cannot be achieved in capability models. Some of the recent work in capability based

systems [2] tries to take the power of capability model to the applications in distributed

environment. In this approach, users transfer their capabilities over resources/users to

other using references, unlike authorization certiﬁcates in PKI based models. A user

can execute a permission over a resource if it has a reference inherited from someone

who already posses such authorization over the resource. Revocation of authority in

such models is immediate since it is an on-line system. Being an on-line system (that

are generally costly), it may hamper the access control decisions in case the underlying

communication system fails.

Several other models exist that try to capture the requirements of an access control

mechanism; PolicyMaker [3], KeyNote [4], RBAC [5]. Access control mechanisms for

a small number of users with limited set of permissions under a single administrative

domain are fairly straight forward. For example, an access control matrix in which each

entry deﬁnes a speciﬁc set of permissions for a user; removing the entry will revoke

user’s authorizations. As the number of users grow, this approach becomes tedious in

terms of management and performance due to the size of the access control matrix.

RBAC etc. abstracts user permissions into roles, and the roles are assigned to users

using digital certiﬁcates that can be used as a proof against the role authorizations.

In this paper, we show that a mix of an off-line framework such as SPKI/SDSI [6],

with an a priori deﬁned heterogeneous authentication mechanisms (on-line/off-line), on

the resource controller’s side to perform additional policy compliance checking, leads

to an expressive policy speciﬁcation framework. A large part of our framework has

been the establishment of the need of such a mixed approach. Towards the end, we

shall illustrate how the above concepts are being embedded in our effort on the design

of ﬂexi-ACL [7].

The rest of the paper is organized as follows: An overview of SPKI/SDSI is given in

section 2. In sections 3 – 4, we will argue requirements of an access control framework

in distributed environments and highlight the shortcomings of existing approaches. We

brieﬂy sketch our access control framework formalism in section 5 followed by discus-

sions in section 6.

2 Background: SPKI/SDSI

In this section, we give an overview of underlying PKI framework, SPKI/SDSI, used

in our framework. SPKI and SDSI [6, 8] were two separate efforts initiated to over-

come the complexity, privacy and trust related issues faced by the highly centralized

traditional PKIs [9] that have now been integrated under the name SPKI/SDSI or just

SPKI.

SPKI emphasizes naming, groups, ease-of-use, and ﬂexible authorizations. To ac-

cess a protected resource, a client must present proof that it is authorized to the server;

this proof takes the form of a “certiﬁcate chain” proving that the client’s public key is in

one of the groups on the resource’s ACL. In SPKI, the onus of identiﬁcation and proof

of authority to do something is left on the user. Every principal can issue/deﬁne the key

bindings locally using an identiﬁer which is valid only locally but the underlying raw

public key is valid globally. So, the SPKI principals can issue certiﬁcates binding other

principal’s keys or names (called extended names) at discretion. An authorization grant

is made only locally. If a principal needs to grant authorization to someone beyond her

locality, then she may (must) delegate that grant through a chain of local relationships.

Formally SPKI certiﬁcates are deﬁned below:

– A name certiﬁcate C is a signed four-tuple (K, A, S, V ):

• The issuer K is a public key; the certiﬁcate is signed by K.

• The identif ier A (together with the issuer) determines the local name “KA”

that is being deﬁned; the name belongs to the local name space of key K.

• The subject S is a key or a local name deﬁned in the other key’s name space

to which issuer of this certiﬁcate binds its local name.

• The validity specification V provides additional information allowing one

to ascertain if the certiﬁcate is currently valid, beyond the obvious veriﬁcation

of the certiﬁcate signature.

– An authorization certiﬁcate C is a signed ﬁve-tuple (K, S, D, T, V ): where,

• delegation bit D, if true, grants the subject permission to further delegate to

others the authorization it is receiving via this certiﬁcate.

• authorization specification or authorization tag , T , that speciﬁes per-

missions being granted.

A brief functional outline of the authorization computation using rewrite rules is illus-

trated with the following scenario: Let principal K serve a resource denoted by RE-

SOURCE and specify the ACL for its access. K authorizes principals K

, K

to act

as retailers for its service. A principal K

subscribes for the RES OURCE service via one

of the retailers. Let us see how the subscriber K

comes up with an authorization proof

to access RESOU RCE, and how the resource owner K makes use of group certiﬁcates

and extended names to efﬁciently specify and manage the access to the resource. Design

for such a policy is given below, using short-hand denotations for the sake of simplicity;

– K retailers → {K

, K

} is a “retailers” group deﬁned by principal K and

it can enforce a common policy on all the three subject principals by just narrating

the policy over the name deﬁnition retailers.

– K customers → {K

, K

customers} is another local group deﬁnition by

principal K, where it has included another group i.e. K

’s customers apart from

and K

, where K

customers → {K

, K

– Principal K consolidates its groups by issuing

K subscribers → {K retailers, K customers} and empowers its members to

access the RESOU RCE by making an authorization deﬁnition,

KRESOURCE → K subscribers ¤. The live delegation ﬂag allows members of group

subscribers to further delegate the authority.

The sequel of messages, between the veriﬁer (K) and the prover (K

) is given below:

1. K

sends an access request for RES OURCE. Controller K demands K

to satisfy

the access control policy enforced by the following rule:

KRESOURCE → K subscribers ¤.

2. K

requests for the deﬁnition of K’s subscribers. (K

should prove its member-

ship to subscribers group, deﬁned by principal K)

3. K provides the deﬁnitions of its groups subscribers, retailers, and customers.

In K’s customers deﬁnition, K

ﬁnds the missing authorization link.

KRESOURCE → K subscribers ¤

KRESOURCE → K customers ¤ ; since

K subscribers

→ {K retailers, K customers}

KRESOURCE → K

customers ¤ ; since

K customers → {K

, K

customers} and

customers → {K

, K

}

∴ KRESOURCE → K

Fig. 1. K

’s Certiﬁcate Chain Discovery Composition

Fig. 1 is K

’s authorization proof inference (“certiﬁcate chain discovery”). In this man-

ner, K

proves its access credentials over RESOURCE and is capable of delegating the

authority further. A dead delegation ﬂag in the access control deﬁnition of RESOU RCE

will restrict K

from further delegation. For complete certiﬁcate chain discovery al-

gorithm (including extensions for threshold authorizations), readers are encouraged to

refer [10, 6].

Such a distributed security infrastructure facilitates designing and efﬁciently manag-

ing complex security models. Its ability to allow users to locally deﬁne their own name

and authorization binding helps achieving natural decentralized trust models, which are

not rigidly dependent on global root CAs. Also, the separation of authorization from

naming prevents unnecessary revelation of user’s authorizations which are not required

while executing a particular authority. Furthermore, provision of threshold certiﬁcates

and group certiﬁcates allow a resource administrator to write the access control policies

in a relatively manageable and editable fashion.

3 Modeling Security Requirement Speciﬁcations

In this section, we shall illustrate how security requirements for a wide range of applica-

tions cannot be met merely either by a PKI framework or an OS-based mechanism; but

needs a mix of static and dynamic (e.g. on-line authentication) schemes. In the follow-

ing section, we provide a number of examples, where we start from a simple scenario

and gradually reﬁne the requirements – formulating solutions in our envisaged frame-

work, and the solutions possible in existing frameworks. The presentations are kept

informal for want of space.

User0

Certificate

Server

Resource

Web

Fig. 2. Access Control with X.509

Scenario 0: Consider a Certiﬁcate server that can issue certiﬁcates and rights for ser-

vices on a Web Resource, as shown in Fig. 2. Users of this setup should be able to

securely authenticate themselves to the Web Resource and perform authorizations as

speciﬁed inside the certiﬁcate. The dashed lines indicate off-line communication links.

Solution: A simple solution using certiﬁcates is: Users obtain digital certiﬁcate from

the Certiﬁcate Server for accessing the Web Resource. Users provide the credentials

acquired from Certiﬁcate Server as a signed access request to the Web Resource, which

simply veriﬁes Certiﬁcate Server’s digital signature over the requester’s credentials and

its absence in the CRL (Certiﬁcate Revocation List) provided by the Certiﬁcate Server.

A centralized PKI framework with a single certiﬁcate for name and authorization

bindings introduces issues in scalability, hierarchical trust, and privacy. These issues

are brought out in the examples below where we gradually add constraints or demand

ﬂexibility.

3.1 Scenario 1: Is it possible to delegate authorizations and restrict the number?

User0

Certificate

Server

Resource

Web

Fig. 3. Access Control with SPKI

The facility of delegation is a natural requirement in any distributed decision making

framework. Fig. 3, shows the modiﬁed access control setup using SPKI (delegation is

supported), where principal U

is acting as an authorization proxy for the Certiﬁcate

Server. The authorization has been further delegated to U

, U

, . . . without any limit,

unlike U

(hence shown in shade). In SPKI, the source authority cannot control the dis-

tribution of authority once it issues an authorization certiﬁcate with delegation facility

to a subject. Thus, without a central database

: authorized principal

without delegation

facility

Trust Value

Delegation Depth (d)

d=1

d=2

d=3

d >= 4

theta = 3

Legend:

Principal U3 has no control over the

# of principals present at this level

Server / Source

of Authority

Certificate

Fig. 4. Authorization Flow under SPKI

it is not possible to enforce limits on the number of authorized users in the system.

Plausible Solution: One can restrict the number of delegations in a setup through the

use of an on-line central repository which must be updated upon each new assertion

made by any authorized agent of the system. But such an approach will transform the

setup into on-line mode and the role of sub-authority will be reduced to a proxy to the

central authority. Obviously, such model is not appropriate for distributed environment

like Internet, since communication failures are intrinsic to it.

3.2 Scenario 2: Is it possible to restrict the depth of authorization delegation?

Strictly speaking, it is not possible to restrict the depth of authorization delegation with

the help of digital certiﬁcates alone (discussed below).

A principal (requester) can form an authorization ﬂow graph (analogous to the one

shown in Fig. 4) from the set of certiﬁcates it possesses, in which each vertex is a princi-

pal (either issuer and/or subject) and each directed edge between two vertices represents

an authorization ﬂow from the issuer to the subject vertex. By performing depth-ﬁrst-

search on such a graph [10], a principal can discover several paths originating in source

authority vertex and terminating in the vertex represented by the principal itself. One of

these paths can be presented as proof of that principal’s authorization over the resource

under consideration. And each vertex present in the proof path essentially represents

one depth of authority delegation. Thus, the veriﬁer of the authorization proof can keep

a tab on the maximum depth permissible in the construction of the proof.

3.3 Scenario 3: Can each user have different accessing rights on the web resource?

An authorization certiﬁcate speaks for user’s access rights. One has to revoke the autho-

rization certiﬁcate even if a single right among the set of user’s rights has to be revoked.

Thus, on the basis of PKIs such provision becomes cumbersome and unmanageable

over a period of time. But it is possible to provide different access rights to the user if

the resource controller makes use of certiﬁcates only to perform correct user authenti-

cation and maintains a separate database (access control matrix) for each user. Such a

scheme is not scalable if there are large number of users with frequent proﬁle updates.

Solution 1: A practical approach is to categorize users into different roles and autho-

rizing them against the rights honored against respective roles. This way the resource

controller has to maintain less information in a manageable way (as done in work-ﬂow

management systems, RBAC [5]).

Solution 2: Another approach could be to explicitly specify the rights of each user into

the user’s certiﬁcate itself. This is suitable for a setup where users exercise rights from

a well-deﬁned ﬁxed set of rights. Since inclusion of all rights information into a cer-

tiﬁcate will limit the scope of certiﬁcates to particular domain. Furthermore if one uses

X.509 [1] to enlist user’s authorizations into the certiﬁcate itself; revocation decision

on a single user right will require re-issuance of the certiﬁcate apart from the privacy

aspects involved in such an approach. SPKI uses separate certiﬁcates for each authoriza-

tion and hence, reduces the impact of revocation to that particular authority. Further, it

uses separate certiﬁcates for naming purpose, they are shielded from any authorization

revocation decisions and their scope is not limited to a particular application.

3.4 Scenario 4: Is it possible to restrict an authorized user from acting as a service

proxy for others?

In the access control setup, a user requires a signed statement from the Certiﬁcate

Server to access the protected resource. The type of certiﬁcation scheme used in the

underlying PKI framework has direct effect on the setup. Adding too little informa-

tion about the recipient of the authorization in the authorization statements boils down

to a scheme where: whoever produces a signed authorization request, will get an ac-

cess. Such a setup can only distinguish between authorized and un-authorized access

requests. Whereas, adding too much of user information will invade user’s privacy. So,

the underlying scheme should be able to provide a trade-off between above two options

suitable to users and the system so that the system can identify authorized users. Also,

it should provide effective means of authorization communication among the users so

that they can authorize other users for certain task.

– Case 1: Authorizing users to act as an authorization/service proxy: Sometimes it

is required to allow the authorized users to act as proxy, as is the case of auction

robots bidding on behalf of the user. The underlying PKI framework should be able

to provide authorization delegation facility to its users, unlike hierarchical PKIs

where it is only given to CAs/sub-CAs.

– Case 2: Use of authorization certiﬁcates containing no additional information

other than the issuer and subject public keys: Under such setups, users enjoy full

anonymity and can run laundry service [11] for others.

– Case 3: Use of authorization certiﬁcates containing additional information e.g.

user’s name, address of delivery etc.: Specifying service access point details inside

the users’ authorization certiﬁcate can be a solution for the scenario mentioned in

Case 1. Inclusion of such details either reduces the scope of the underlying certi-

ﬁcation scheme or poses privacy threats. Hence, such an approach is not feasible.

But such a setup will certainly differentiate between authorized and un-authorized

users. In communications that are not face-to-face, remote lending cannot be pre-

vented, regardless of whether privacy-protecting certiﬁcates or fully traceable iden-

tity certiﬁcates are used. Indeed, the “lender” might as well perform the entire

showing protocol execution and simply relay the provided service or goods to the

“borrower” [12]. In user’s negative spirit, it is difﬁcult to stop such behavior.

Further, in a centralized authorization setup (Fig. 2), as the number of users grows the

load on Certiﬁcate Server increases. It will be of great assistance, if it could designate

few other agents as a proxy for its’ authorization issuance service.

An important observation is that certiﬁcates are static data-structures with crypto-

graphic properties to convey the assertions in provable and off-line manner. To increase

their scope across different applications that use them, one cannot put application-

speciﬁc information in them. Also, we have seen that such an effort acts against user’s

privacy. The inability of these static data-structures to convey the dynamic state changes

of applications that use them demands non-certiﬁcate based methods in the access con-

trol framework to express context-aware access policies. In the sequel, we will discuss

solutions to the above discussed scenarios and some new scenarios that explicitly de-

mand book keeping of state change.

4 Modeling Static and Dynamic Security Requirements

In the earlier sections, we have argued that the existing frameworks do not support the

following features:

1. Constraints and ﬂexibilities required for specifying proxies by users,

2. Variable access rights for the users,

3. Emergency access requirements, and

4. Robustness/Fault-tolerance and immediate revocation of authority.

As highlighted already, to cater to the above needs, we should have a judicious mix of

certiﬁcates and on-line schemes such as authentications. Conceptually, our approach or

solution addresses these through the following abstractions:

1. Abstract out the core access control across scenarios as a global policy speciﬁcation

that can and will be handled through certiﬁcates,

2. Specify reﬁnements that may require on-line schemes as local policies, and

3. The overall policy is then is then obtained through a merger (e.g., intersection is an

example of such merging operation) ) of the global and local policies.

Employing the underlying PKI framework for secure authentication of users to the sys-

tem and thereafter to establish identity, through a challenge-response based negotiation

allows to ﬁlter out the efforts of authorized users to run laundry service for others. The

inherent feature of delegation comes handy for proxy authorization when required. Fur-

thermore, to derive ﬁne-grained access control decisions, the requester negotiates with

the resource controller for a list of local policies that needs to be adhered to. The re-

source controller may also specify policies for auxiliary rights for users based on the

state information associated with that speciﬁc user/process. Integration of capability

based mechanisms at this level of implementation helps us modeling capability systems

for distributed applications.

Server/Resource

Controller

Vat

Resource

Reference

Server/Resource

Controller

Resource

Authorization

(a) Capability Model

(b) PKI Model

Certificate

Capability

Certificate

Fig. 5. Granovetter Diagrams for Capability, PKI Models

A comparative distinction between access control system under capability model

and PKI model is depicted in Fig. 5. Access control system based totally on capability

model is an on-line system as opposed to the off-line feature of PKI model that can turn

on-line during user’s negotiation phase with the resource controller for ﬁne-grained

access controller decisions. Thus, it is important to ﬁnd a ﬁne trade-off between off-line

and on-line mechanisms in the design of a scalable, fault-tolerant access control system.

It is also important to see that a skillful execution of user rights in a particular se-

quence should not land up the system in unsafe or inconsistent state. By isolating unsafe

execution of sequences of access rights from users and encapsulating a desired sequence

of rights under a newly deﬁned policy, the system can maintain safe protection state.

The encapsulation of rights is achieved by restricting the communication interface of

these access right mechanisms to the domain of encapsulation. A user can only inter-

act with the interface provided by this newly deﬁned access rights mechanism by the

system. A meta-level sequencing is possible using cryptographic tokens/cookies as a

communication parameter between the sequenced chain of access rights.

Immediate revocation of authority, provisions for alternative authorization in emer-

gency, robustness, and fault-tolerance are other important aspects required in an access

control mechanism. Due to lack of space, we shall not describe formal notations of

ﬂexi-acl to handle these aspects. A brief informal description is given in the next sec-

tion using S-expression like notations.

5 Towards an Integrated Formalism Specifying Static and

Dynamic Security Requirements

(subject (name

(hash sha1 |tY8plW2ry0yQdtgk3l9oQtR=|)

(acl

my−group))

(delegate)

(tag (ftp://mil.gov (read write))))

Fig. 6. ACL For Resource ftp://mil.gov

In general, the access control frameworks abstract the users of the system into groups

or roles for the sake of brevity while expressing the access control policies. In doing

so they lose the ability to address the user-speciﬁc policies, which is essential in the

long term because Resource Administrator should have methods to immediately revoke

only the non-conforming users from the system, instead of revoking the whole group to

which the non-conforming user belongs. We have elaborated few such scenarios below.

Before that let us give the templates, on which our description is based, describing the

access control policy for resource ftp://mil.gov and an authorization certiﬁcate that

allows its recipient to access this resource.

(not−before "2004−04−01_00:00:00")

(not−after "2005−05−01_00:00:00"))

(cert

(hash sha1 |isEf64Sf5JpqasB4DCsR6Bn=|))

(hash sha1 |tY8plW2ry0yQdtgk3l9oQtR=|)

(issuer (name

(subject

my−group))

Fig. 7. Name/Group Certiﬁcate For Resource ftp://mil.gov

Fig. 6 is the access control policy for ftp://mil.gov with two distinct permissions

(read, write). The requester for this resource must prove that it belongs to my-group,

a group deﬁned by the subject principal, listed inside the ACL. Many such local or

extended name deﬁnitions may be listed in the ACL.

Fig. 7 shows a membership certiﬁcate empowering its subject to ftp://mil.gov with

full permissions automatically. Inheritance of these permissions allow the members of

my-group to delegate the authorizations to others due to presence of (delegate) ﬂag in

the ACL of resource. Partial delegation of authorization is shown in Fig. 8 (only read

permission is delegated to the subject). Authorization certiﬁcate is used to transfer au-

thorizations (permission set) and as authorizations are delegated further, the permission

set can only reduce.

(not−before "2004−04−01_00:00:00")

(not−after "2005−05−01_00:00:00"))

(cert

(issuer

(hash sha1 |isEf64Sf5JpqasB4DCsR6Bn=|))

(delegate) (tag (ftp://mil.gov (read)))

(subject

(hash sha1 |ZdtyR5TuOr2sXgtyuoqGbET=|)

Fig. 8. Authorization Certiﬁcate For Resource ftp://mil.gov With read Permission

From this setup, it should be clear that users belonging to the group deﬁnition

my-group can access the resource with full permissions (both read and write); however,

the user authorized by the certiﬁcate shown in Fig. 8 can access the resource only with

read permission. The Resource Administrator is free to update the ACL as the policy

changes over the period of time. Therefore, the actual permissions available to a re-

quester has to be computed accordingly, which is done by taking the intersection of

permissions listed inside (tag) ﬁelds of authorization certiﬁcates present in the “certiﬁ-

cate chain”. The subject principal listed in Fig. 8 deduces its authorization proof with

the help of certiﬁcates shown in Fig. 6, 7, and 8 accessed in the same order. The actual

set of permissions available to this principal are computed as described below using

AIntersect (t1, t2) function, where t1 and t2 are (tag) ﬁelds from authorization cer-

tiﬁcates. Therefore,

AIntersect ( (tag (ftp://mil.gov (read write)))), (tag (ftp://mil.gov (read))) ) =

(tag (ftp://mil.gov (read)))

Intersection of tag sets:

– basic: if t1 == t2, then the result is t1

– basic: if t1 != t2 and neither has a *-form, then the result is “null”.

– (tag (*)): if t1 == (tag (*)), then the result is t2.

If t2 == (tag (*)), then the result is t1.

– (* set ...): if some (tag) S-expression contains a (* set ) construct, then one

expands the set and does the intersection of the resulting simpler S-expression.

– (* prefix ...): if some (tag) ﬁeld compares a (* prefix ) to a byte string, then the

result is the explicit string if the test string is a preﬁx of it and otherwise “null”.

Let us study the behavior of Resource Administrator as different policy requirements

gradually arise in the setup.

– Scenario 1: Stop the service to members of my-group deﬁned by public-key

(hash sha1 |tY8plW2ry0yQdtgk3l9oQtR=|).

Solution: The Resource Administrator removes the rule that authorizes members of

my-group, from the ACL.

– Scenario 2: Resource ftp://mil.gov not in a position to provide write permission.

Solution: The Resource Administrator updates the tag ﬁeld of corresponding ACL

entry to (tag (ftp://mil.gov (read)))

– Scenario 3: Introduce a new permission foo over the resource ftp://mil.gov.

Solution: The Resource Administrator modiﬁes the (tag) ﬁeld of corresponding

ACL entry to (tag (read write foo)); provided that the (tag) ﬁeld of user’s autho-

rization certiﬁcate is (tag (*)) so that upon taking intersection the effective set of

permissions include foo.

– Scenario 4: Restrict the resource service only to the members of my-group.

Solution: The Resource Administrator removes the delegation ﬂag (delegate) from

the ACL rule for group my-group.

In the above scenarios, the actions of Resource Administrator are enforced on a set of

users in a generalized fashion. Such an approach falls short of expectations when the

change in policy is directed towards a subset of a well-deﬁned group or an individual.

The main reason behind this shortcoming is the inability of the underlying framework to

efﬁciently capture the system’s state information through just certiﬁcates. One solution

is to issue new certiﬁcates as and when the state constraint changes. However, this is

too costly and does not serve the rationale of PKIs and further, one need to handle the

problem of revocations.

In our approach towards a ﬂexible access control framework, we integrate a pri-

ori deﬁned heterogeneous e-authentication mechanisms to attain the goals of capturing

state information, instant revocation of authority, ﬁne-grained access control, and pro-

vision for alternate methods of authorization. We also pursue a new approach in cer-

tiﬁcation mechanism; the authorization certiﬁcates under our framework include more

general (and relatively static) permissions inside the (tag) ﬁeld followed by (*), i.e.

(tag (resource (foo1 bar1)(*))). Whereas the (tag) structure of ACL contains a (*)

followed by the set of frequently up-datable permissions over the resource, i.e. (tag

(resource (*)(foo2 bar2))). This approach segregates the more general access policies

(global policy) imbibed into the authorization certiﬁcates of the users and access per-

missions that are subject to change depending upon state of the system or context (local

policy) are expressed inside the ACL entries. The effective policy for resource access is

a combination of general policy, speciﬁed inside the requester’s credentials, and local

policy speciﬁed at the resource in conjunction with the e-authentication mechanisms for

conditional decision making. Another tool in our integrated approach for ﬂexible access

control framework is the tokenization of user credentials. Such an abstraction of user’s

credentials makes the framework modular and efﬁcient, if the trust among the differ-

ent veriﬁers in the setup is high. Also, the abstraction induces a level of indirection in

user’s authorization proof; thus providing the much needed property for e-transactions

– privacy.

5.1 Access Control Policy Using e-authentication Mechanisms

The communication between the resource requester and the resource is an interactive

process during which the resource controller challenges the requester with access con-

trol rules for the resource. Fig. 9 shows a typical access control policy designed using

(quorum 1

(acl−block B1

(rule X1) AND (rule X2) AND (rule X3))

(acl−block B2

(rule Y3) OR (rule Y4) AND (rule Y6))))

(flexiacl

Fig. 9. ﬂexi-ACL: Typical Structure

heterogeneous e-authentication mechanisms (like pamd, RSA SecurID, biometric,

TCP/IP wrapper etc.) as basic access control rules

. The heterogeneous authenti-

cation mechanisms are glued together using the boolean AND, OR operators.

Table 1. AND, OR Operators

Expression Description

(rule X1) AND (rule X2) returns 1; when evaluate (rule X1) = 1

and evaluate (rule X2) = 1, else returns 0

(rule Y3) OR (rule Y4) returns 0; when evaluate (rule Y3) = 0

and evaluate (rule Y4) = 0, else returns 1

The heterogeneous primitive access control rules can be aggregated into an acl-block.

Such blocks can be placed under another construct called quorum to achieve a very ﬂex-

ible access control policy expression. Such an unique, modular method of expressing

access control policies allows the Resource Administrator to establish a comfortable

trust or credibility level before making access control decisions. Hence, for the policy

speciﬁed in Fig. 9, the requester has to conform to any of the two acl-blocks to get

resource access, since the quorum is set to 1.

In the following, we show features like instant authority revocation, state-based access

decisions, rights ampliﬁcation, and ﬁne-grained access control that can be effectively

and elegantly addressed in our approach; note that these features cannot be handled in

the existing access control frameworks.

– Scenario 5: Stop providing service to non-conforming users.

Solution: The Resource Administrator simply revokes non-conforming users from

the authentication mechanism. Since the resource has been conditionally integrated

with a priori deﬁned e-authentication mechanism, a non-conforming user can pro-

duce certiﬁcate based authorization proof but could not authenticate itself against

the authentication mechanism.

– Scenario 6: A particular user U should not access the resource more than n times.

Solution: For such scenarios, the Resource Administrator may integrate the re-

source with an e-authentication mechanism like “one-time password” and issue n

passwords to the user.

The complete details of ﬂexi-ACL speciﬁcations are available in [7]

– Scenario 7: Provide more permissions to the users who can satisfy the additional

policy requirements. (rights ampliﬁcation)

Solution: The Resource Administrator can put the additional policy requirements

in conjunction with the necessary e-authentication mechanism as a conformance

check.

– Scenario 8: Introduce a new permission foo over the resource only to certain users.

Solution: The Resource Administrator will create a new rule inside the

(acl-block) in which permission foo is introduced as a new permission under lo-

cal policy but availed to the users who can authenticate themselves against the

e-authentication mechanism integrated with that rule using AND operator.

More complex and ﬂexible policies can be envisaged using our approach. For lack of

space, we will informally describe additional properties like sequential access and al-

ternative/emergency access provisions using an abstract comprehensive scenario in the

next subsection.

5.2 A Comprehensive Scenario

The subscript s denotes

the policy of the resource

requires a policy confor-

mance speciﬁed elsewhere

12s

44s

33s

d=1

32s

23s

34s

d=3

d=2

- j

resource at

and d = i

hierarchy level of R

d - delegation depth or

hierarchy level i

U - Users of the system

Fig. 10. Layered Security Infrastructure

In an environment where the resources are widely distributed and have varying levels

of sensitivity towards unauthorized resource access, a common access control policy

cannot be envisaged due to various reasons. Let us explain a scenario using which we

will demonstrate our framework.

Consider an organization that has installed its resources (R

, R

33s

, R

etc.)

in hierarchical layers closely resembling the descending organization hierarchy. The

ﬁrst subscript of a resource R denotes its placement in hierarchy level, second subscript

denotes its identity number and the third optional subscript indicates sequential access

constraints over the resource (i.e. access request to such a resource should be made after

complying to the policies speciﬁed at the resource prior/lower to it in the hierarchy).

Members of the organization are authorized to access the resources lying in their

hierarchical level; conditional access to resources at higher hierarchical levels can be

granted. Also, it should not be possible for a member to lend out its credentials to

others. Access to certain resources must start at the lowest level of hierarchy and should

proceed further in strict sequence. The internal network of the organization is assumed

to be a trusted and resource access requests originating from outside the network will

not be honored with full authorization capability. Also, the resources should have the

facility to implement context-based access control policies.

Let the head of the organization be the source of authority. It empowers the subordi-

nates in the immediate hierarchy for accessing the resources and allows further delega-

tion of the authorization. This way the authorization ﬂows from top level of hierarchy

to lower levels. Now let us analyze the constraints and options available to principal U

for accessing the resource R

12s

. As mentioned earlier, the resource subscript s denotes

that it can only be accessed in a particular sequence. The directed paths shown in Fig.

10 are such sequences. Therefore, in the process of accessing resource R

12s

– principal U

has to ﬁrst comply with policy deﬁned at resource R

, which is in-

stalled at third level. R

issues a token for policy conformance to U

– The signed tokens issued by R

are acceptable as part of authorization proof at

resource R

32s

and R

34s

– Similarly, tokens issued by R

32s

and R

34s

are accepted at R

23s

– And resource R

12s

accepts only the tokens issued by R

23s

In this fashion, one can deploy a layered access control policies over a large setup. The

concept of tokenization should work across the administrative domains, based upon the

level of trust between the tokenizer and the acceptor of such tokens.

6 Conclusion

In this paper, we have argued the need for a hybrid of digital certiﬁcates and other

state based schemes to arrive at ﬂexible distributed access control speciﬁcations. We

have designed and experimenting the notations for ﬂexible access control mechanism,

called ﬂexi-ACL [7], to achieve the above mentioned dynamic access control decisions

in distributed systems.

Our access control model allows to make a judicious mix of on-line decision mak-

ing protocols with the underlying off-line framework to capture the dynamics of modern

access control requirements. Inclusion of external authentication mechanisms into the

PKI framework empowers the resource controller to provide ﬁne grained access con-

trol. The ability of resource controller to enforce local access control policies helps the

resource owner in granting discretionary auxiliary rights to users. Such provisions also

allow the resource controller to do rights ampliﬁcation after a user achieves credibility

by following the respective local policies. This scheme can easily express the com-

plex access control requirements of applications like e-government, work-ﬂow etc. in a

manageable way.

We also observe that in the ﬁnancial transactions, technical requirements form only

a part of the overall requirements for security. Non-technical aspects include the rep-

utation of the parties involved, liability for misuse, (legal action and stiff penalties for

wrong doing), etc.

Acknowledgments

We are grateful to the Ministry of Information Technology, Government of India, for

the support.

References

1. Warwick Ford and Michael S. Baum. Secure Electronic Commerce: Building the Infrastruc-

ture for Digital Signatures and Encryption, Second Ed. Prentice Hall, 2002.

2. Mark Miller and Jonathan Shapiro. Paradigm Regained: Abstraction Mechanisms for Ac-

cess Control. Advances in Computing Science, ASIAN 2003 Programming Languages and

Distributed Computation, LNCS 2896:224–242, 2003.

3. Matt Blaze, Joan Feigenbaum, and Martin Strauss. Compliance Checking in the PolicyMaker

Trust Management System. Financial Cryptography, FC 1998, LNCS 1465:254–274, 1998.

4. Matt Blaze, Joan Feigenbaum, John Ioannidis, and Angelos Keromytis. The KeyNote Trust-

Management System Version 2. RFC 2704, Internet Engineering Task Force, 1999.

5. David F. Ferraiolo, Ravi Sandhu, Serban Gavrila, D. Richard Kuhn, and R. Chandramouli.

A Proposed Standard for Role-Based Access Control. Technical report, NIST, Dec 2000.

6. Carl Ellison, Bill Frantz, Butler Lampson, Ronald Rivest, Brian Thomas, and Tatu Ylonen.

SPKI Certiﬁcate Theory. RFC 2693, Internet Engineering Task Force, Sep. 1999.

7. Vishwas Patil and R.K. Shyamasundar. Notations for Flexible Access Control System: ﬂexi-

ACL. Technical report, Tata Institute of Fundamental Research, 2003.

8. Ronald Rivest and Butler Lampson. SDSI – A Simple Distributed Security Infrastructure.

Presented at CRYPTO’96 Rumpsession, 1996.

9. Carl Ellison. SPKI/SDSI Certiﬁcate Documentation, 2002.

http://world.std.com/˜cme/html/spki.html.

10. Dwaine Clarke, Jean-Emile Elien, Carl Ellison, Matt Fredette, Alexander Morcos, and

Ronald Rivest. Certiﬁcate Chain Discovery in SPKI/SDSI. Journal of Computer Security,

9(4):285–322, 2001.

11. Mark Miller, Chip Morningstar, and Bill Frantz. Capability-Based Financial Instruments.

Financial Cryptography, FC 2000, LNCS 1962:349–378, 2001.

12. Stefan Brands. Rethinking Public Key Infrastructures and Digital Certiﬁcates; Building in

Privacy. MIT Press, 2000. ISBN 0-262-02491-8.

This document is a draft of the work undergoing on Notations for Flexible Access Control

System: ﬂexi-ACL
