RESOURCE SHARING AND LOAD BALANCING BASED ON

AGENT MOBILITY

Gilles Klein

LAMSADE - University of Paris IX

Place du Mar

echal de Lattre de Tassigny, 75016, Paris

Alexandru Suna, Amal El Fallah-Seghrouchni

LIP6 - University of Paris VI

8, Rue du Capitaine Scott, 75015, Paris

Keywords:

Mobile Agents, Agents for Internet Computing, Load Balancing and Sharing, Agent-Oriented Programming.

Abstract:

From the recent improvements in network and peer-to-peer technologies and the ever-growing needs for com-

puter might, new ways of sharing resources between users have emerged. These methods are very diverse,

from SETI@HOME which is a way to share the load of analysing the data from space in order to ﬁnd traces

of extraterrestrial life, to NAPSTER and its successors, and to Real-time video-games. However, these tech-

nologies allow only centralised calculus-sharing, even if they already offer ”peer-to-peer” sharing of data. We

present in this paper a method based on Multiagent systems which allow load-sharing between distant users.

1 INTRODUCTION

As the power of computer processors keeps growing,

it appears that whatever the power of the computers

is, it is never enough, as computer software is al-

ways more demanding. Even if it is now common

to own a computer, the most powerful ones are still

out of reach of most of the users. As distributed ap-

plications become very common (multiplayer games,

for example), network-based sharing technologies are

still limited to very speciﬁc applications (like peer-

to-peer sharing systems). Even the great societies

could vastly proﬁt from it, simply because the com-

puter resources of multinational groups are always

underused. As a matter of fact, as these resources

are distributed all around the world, at every single

moment, there are computers unused, simply because

their user is not working at that time. These comput-

ers could be used to lower the load of the ones placed

at ”the antipodes”. These points are what drives re-

search into the domains associated with grid program-

ming (Foster and Kesselman, 1999) and peer-to-peer

systems, from SETI@HOME (Seti) to Napster but

also to works like (Vercouter, 2002) on open systems

working without middleware agents.

To permit sharing of resources (not only between em-

ployees of a single group, but also between anony-

mous users), certain problems must be overcome.

To be efﬁcient, a resource sharing application must

allow users to execute code on the shared comput-

ers. It induces a clear problem: The code that will

be executed must be present on the shared computer;

it makes real sharing very difﬁcult as it is difﬁcult to

know a priori what application will be shared and so

these applications cannot be installed on every shared

computer beforehand.

The sharing system must be ﬂexible as it must nei-

ther disturb the users nor be hindered if a computer is

turned off.

The system will not be used if it is needed of everyone

to reboot their distributed applications every time one

of the shared computers suffers a problem (an event

which can happen relatively often if the computers are

personal systems). It becomes all truer if the sharing

system is distributed on a large scale (e.g. Internet).

It must also be considered that as the system would

be then very wide, it would not be possible to make

the hypothesis that the communications are timeless,

so local information of a site concerning another site

will always be obsolete (even if only by few seconds).

In fact, trying to renew the local information often

might be so costly in terms of communications, that

the whole system would be diminished. So the load

sharing must be done based on obsolete information.

The system must also guaranty the safety of the users.

In fact, this kind of systems implies that foreign code

will run on the shared computers, which can be a risk

for every user.

Finally, for the sharing to be efﬁcient, it is necessary

that the applications which are going to be distributed

350

Klein G., Suna A. and El Fallah-Seghrouchni A. (2004).

RESOURCE SHARING AND LOAD BALANCING BASED ON AGENT MOBILITY.

In Proceedings of the Sixth International Conference on Enterprise Information Systems, pages 350-355

DOI: 10.5220/0002601303500355

 SciTePress

on it will use it correctly.

It is not reasonable to believe that it might be pos-

sible to distribute very heavy applications efﬁciently

while all the distribution is managed by a ”super-OS”.

Highly distributed systems are different from shared-

memory multiprocessors computers because the com-

munications between the computers can be very ex-

pensive when compared to the internal communica-

tions of a computer. But the system itself has no way

to determine the cost of the communications, if the

application is not built speciﬁcally so that it includes

a description of its processes’ communications.

2 RELATED WORK

The resource sharing between different computers is

a goal of several distributed computing approaches,

from Grid-Computing to Cluster-computing or peer-

to-peer sharing systems. Our model has common ele-

ments with each one of these.

In many aspects, we follow the same basic principles

as the ones of the peer-to-peer systems of the last gen-

erations (Kazaa, Overnet (Bhagwan, et al., 2003) or

Chord (Stoica, et al., 2001)). Those systems follow

certain hypotheses that should be followed in the case

of all resource sharing systems:

- Since the problems of Napster, every one of these

systems must be fully distributed, so that no central

server could be attacked (physically or legally).

- They must be generic; every kind of ﬁle can be

shared using these systems. It was not the case for

Napster, which offered only MP3s sharing, but since

Gnutella, the sharing systems are not restrained by the

type of the shared ﬁles.

- They are anonymous. In fact, they are not anony-

mous, the requests are anonymous but the answers

are not (it is so to let two computers communicate

directly). However, the principle is very good, as

anonymity offers the greatest protection against spec-

iﬁed attacks.

- The mass of communication is minimized. To re-

duce the communication load, several methods are ap-

plied, from ”super-nodes” architectures (e.g. Kazaa)

to indexing methods (e.g. Overnet).

However, there are evident differences; ﬁrst, it is far

easier to share ﬁles than generic computer resources.

File sharing does not ask for neither load-balancing

system nor redundancy and other safety systems. It is

why, while in principle, sharing computer resources

within the characteristic hypotheses of the peer-to-

peer ﬁle sharing systems, we should also consider

the works in grid computing and cluster computing

as they both treat the problem of distribution compu-

tational load on several computers.

The research in the clusters domain encountered a

serious problem while treating the case of hetero-

geneous computers. Several system exist that ac-

cept heterogeneous computers, for example PVM

(Geist, et al., 1994), P4 (Dongarra, et al., 1993) or

LINDA (Carriero and Gelernter, 1989). One of the

most interesting solutions concerning cluster comput-

ing has been the introduction of distributed shared

memory like in LINDA. The functionalities of the

clustered systems have also been applied to larger

scale systems (e.g. using Globus (Foster and Kessel-

man)). However, distributing a shared application

(e.g. SETI@Home project (Seti)) is easier than shar-

ing computational power for applications unknown.

The only solution to really share resources is to use

mobile code, to have the processes migrate from a site

to another until they ﬁnd a good one.

Most of the grid programming systems (Globus, Le-

gion (White), MPICH (MPICH-G2)) offer the func-

tionalities necessary to implement every kind of dis-

tributed application. However, these systems are

rather platform for building distributed application

than sharing platform. Most do not implement mo-

bility facilities and so cannot be used in the frame of

our hypotheses.

3 MOTIVATING OUR CHOICES

3.1 An architecture for mobility ...

Multiagent systems appeared as the most pertinent ba-

sis to build our sharing system as it helps to solve

many of the problems cited before. They offer a

great ﬂexibility to the whole system and are naturally

adapted to distributed environments. Nevertheless,

as we showed in (Klein et al., 2002), in order to be

plainly able to proﬁt from the diverse advantages of

distributed systems, they must be conceived so that

they take into account these distribution problems.

Using mobile agents gives us a solution to most of

the problems described before; indeed, mobile code

offers the lone alternative to the presence of a copy

of every single distributed program on every shared

computer and the agents are not only very adapted

to the distributed systems, but they also carry a very

high level of encapsulation of the code which can help

to improve the security of the system and a certain

autonomy of the processes distributed across the net-

work which can let the system be very adaptive to the

evolution of the situation.

3.2 ... and resource sharing

As we showed before, it would be interesting to be

able to share resources from different users’ comput-

ers even if they are distant. To be able to do that,

RESOURCE SHARING AND LOAD BALANCING BASED ON AGENT MOBILITY

351

we have to build a sharing ”platform”. Three differ-

ent points must be taken into account: the security

and the managing of every single computer partici-

pating to the sharing network, the building of every

of the tasks distributed on the different computers and

ﬁnally, the state of the system as a whole.

As sites can be owned by different people and as the

users can have divergent goals and as the number of

shared sites is not limited, it is not realistic to be-

lieve that we can build a sharing system following a

real hierarchic architecture. There can be neither cen-

tralized management nor even domain-based manage-

ment. So we considered an agent-based architecture

composed of three types of agents.

The Task agents encapsulate the distributed processes

of the users. They verify if the site where they run is

satisfying enough, and if it is not, they look for a bet-

ter one following the pieces of information they pos-

sess and the information the Manager of the site can

give them. Then they migrate to a better site.

The Manager agents manage their sites and they are

not mobile. They guaranty that the local running

Tasks agents follow the rules, that the security and

the stability of their site are good enough and that the

local information about the system as a whole is not

too obsolete.

The Sniffer agents travel across the network, migrat-

ing between shared sites to ﬁnd good sites for the ap-

plications of their owners. They also try to renew the

information of every site they go through by making

propositions of changes about the local knowledge to

the manager of the site. So they make the system as

a whole efﬁcient as these pieces of information are

used by every Task agent. Finally, their contents can

be analyzed when they come back to their home site.

4 HOW CAN AGENTS CLASSIFY

THE SITES

One of the ﬁrst problems we met while conceiving a

sharing system where agents choose their destinations

by themselves can be found in the fact that it is nec-

essary to give the agents a tool to make that choice.

So both a computable representation of the comput-

ers and a method of classiﬁcation fast enough to not

consume too much resources (the agents must spend

as few resources as possible or the distribution will

not carry any gain).

4.1 How agents represent the sites

One of the ﬁrst characteristics of our system of rep-

resentation is that it must let agents take into account

the temporality of the information. Indeed, in order to

not overload the communications, we must consider

that the knowledge of a site about another one will

not be refreshed very often (the Sniffers will refresh

them only if they can in their present state). It is also

necessary that this knowledge is simple enough to be

computed in a reasonable time, still complete enough

to offer good results.

We must separate the data about the sites in two cat-

egories, the dynamic and the static information. The

static data is characteristic to the computer (like its

microprocessor or OS) and it can evolve but very

rarely; on the other hand, the dynamic information

represent the temporal state of the computer at a pre-

cise time. The dynamic information will be the one

that should be refreshed from time to time.

4.1.1 Static Data

The static characteristics that we are taking into ac-

count in our application are: the computation power,

memory’s and disks’ characteristics, allowances of

the hosted Task agents, network connection character-

istics. For our tests, we obtained the ﬁrst two points

with PerformanceTest edited by PassMark Software,

which gave us numerical marks for each one of these

points on PCs with Windows operating system (OS).

It is possible to obtain similar things with the system

tools when running Linux, but to simplify this paper

we will only consider Windows-based sites. The per-

missions are ﬁxed by the user and represented in a

binary table, same as the connection nature. The av-

erage distance is a numerical measure (of time) and

the quality of the connection is a distribution curve.

4.1.2 Dynamic Data

The dynamic data are divers curves describing the

evolution of the system that are refreshed locally, like

the load of the processor, of the memory, the instant

distance to a reference site, and the instant quality of

the local connection. There are other kinds of data

that are not taken into account yet, like the speciﬁc

services accessible on this site.

For our simulation, we used a simpliﬁed version of

the description of the sites; it only includes the basic

characteristics of the computer.

4.2 Classifying the sites

To classify the computers is a necessity. Indeed, the

agents must not only represent the sites but also use

these representations to make decisions about where

to and when migrate. They must be able to select a

site and decide that the services of their present site

are not sufﬁcient. So they must be able to compare

and classify the sites, satisfying the following rules:

classifying a computer must use little resources; the

classifying functions must be simple and light; the

ICEIS 2004 - SOFTWARE AGENTS AND INTERNET COMPUTING

352

classiﬁcation obtained must be systematic and there

must be no ambiguity.

To obtain all these characteristics, we choose Galois’s

lattices (Ore, 1944) to represent the preferences as

they can be applied even to abstract data (e.g. curves,

histograms, fuzzy sets) (Diday and Emilion, 2003).

The Galois lattices can be deﬁned as follows: be two

lattices (E, ≥, ∪, ∩) and (F, ≥, ∪, ∩) where ≥, ∪ and

∩ are respectively the order relationship, the supre-

mum and the inﬁmum, a Galois correspondence is a

couple (f, g) so that:

f : E → F and g : F → E are decreasing mappings

h = f ◦ g : E → E and k = g ◦ f : F → F are

both extensive (i.e. so that ∀x ∈ E, h(x) ≥ x , resp.

∀y ∈ F, k(y) ≥ y ).

In our situation, F is the description lattice (which can

be seen as a partial classiﬁcation of the abstract sites

and that is presented in the ﬁgure 1) and E is the sets

lattice, sets that contains the real sites associated to

the descriptions. We combine these descriptions with

values representing our preferences.

The lattices are sets of sets of computers (with in-

Figure 1: Galois Lattice

clude an order relationship), associated with their de-

scriptions. So, the user deﬁnes the preferences of his

agents through the use of the lattices of descriptions of

computers. We can guaranty that a machine can ﬁnd

its unique place in the lattice after at most n compar-

isons (with n being the length of the longest branch

of the lattice). It will always be possible to classify

a new site and to compare it to older ones. Yet, we

must recall that a lattice is a partial order, so certain

computers will not be comparable. For this reason,

we also ask the user to give qualities to each of the

categories deﬁned by the descriptions.

Inside a category, it will choose a computer from the

most restrictive node possible. This solution guar-

anties that the best solution will be selected, but it let

some ﬂexibility to the whole; the agents will, for ex-

ample, be able to choose their destination by taking

into account the moves of their ”site mates” and go

to a second choice if everyone goes to the ﬁrst one.

As the representation and the classifying tool are rel-

atively light, they will be easy to carry during the

migrations. Finally, this system is simple enough to

open the potentiality of creating new lattices for new

applications.

5 THE TEST PLATFORM

5.1 CLAIM and SYMPA

For our implementation, we used the CLAIM lan-

guage and the SyMPA platform (El Fallah and Suna,

2003) because they provide every mechanism for the

design of intelligent, mobile agents, and for the visu-

alization of agents’ execution and migration.

CLAIM (Computational Language for Autonomous,

Intelligent and Mobile agents) is a declarative lan-

guage that combines elements from the agent oriented

programming languages for representing agents’ in-

telligence and communication with elements from

the concurrent languages (e.g. the ambient calcu-

lus (Cardelli and Gordon, 1998)) for representing

agents’ mobility. An agent in CLAIM is an au-

tonomous, intelligent and mobile entity that has a list

of local processes concurrently executed and a list of

sub-agents. In addition, an agent has mental com-

ponents such as knowledge, capabilities and goals,

that allow a forward (reactive behavior) or a back-

ward reasoning (goal driven behavior). An agent can

create new agents, can call methods implemented in

other programming languages (e.g. Java methods, in

this version of CLAIM), can communicate with other

agents (one can deﬁne using the language’s primitives

a unicast, a multicast or a broadcast communication)

and can migrate using the mobility primitives inspired

from the ambient calculus.

SyMPA (French: Syst

eme Multi-Plateforme

Figure 2: SyMPA’s Architecture

d’Agents) is a MASIF (Milojicic, et al., 1998) com-

pliant platform, implemented in Java (Java), consist-

ing in a set of connected computers, that supports

CLAIM agents and offers all the mechanisms needed

for the design and the secure execution of a distributed

RESOURCE SHARING AND LOAD BALANCING BASED ON AGENT MOBILITY

353

MAS. SyMPA’s architecture (ﬁgure 2) presents three

levels:

The Central System provides services for agents’

and agents systems’ management and localization.

An Agent System is deployed on each connected

computer at the SyMPA platform. It provides high

level mechanisms, such as a graphical interface for

deﬁning CLAIM agents and classes, an interpret for

verifying the deﬁnitions’ syntax and interfaces for the

running agents, low level mechanisms, for agents’

deployment, communication, migration and manage-

ment, fault tolerance and security mechanisms.

An agent in SyMPA is a entity deﬁned using CLAIM.

It is uniquely identiﬁed. Each agent has an interface

for visualizing the behavior, communication and mo-

bility and is concurrently executing the reactive and

pro-active behavior.

In order to assure the efﬁciency and the security of

the system, communication protocols were proposed,

doubled by cryptographic mechanisms and resources

access policies.

5.2 The classes of agents

Two very important characteristics of CLAIM are the

generality and the expressiveness. One can repre-

sent agents’ reasoning, communication and mobility.

A Web information research example (El Fallah and

Suna, 2003) and an electronic commerce example (El

Fallah and Suna, 2003) were already successfully pro-

grammed in CLAIM. So we choose CLAIM for our

load balancing application.

As we’ve seen in the application’s description, there

are three classes of agents.

The Manager agents are static agents situated on

each of the computers involved in the application.

They have a representation of the characteristics of

the other sites under the form of Galois lattices. They

have capabilities for creating Sniffers, for answer-

ing at the Sniffer and Task agents’ requests concern-

ing the other computers’ characteristics, for updating

their knowledge when a Sniffer gives them new infor-

mation. In plus, when a Manager observes the over-

charge of the local resources, it can demand the de-

parture of the local Task agents.

The Sniffer agents are created by the Managers and

they migrate to the other computers where they update

their knowledge about the local computer character-

istics, and the knowledge of the local Manager about

the other computers.

The Task agents are executing several tasks. In

order to do this, a Task agent migrates to the best

computer known in its Galois lattice, received from

the Manager, and starts to execute the task. When it

detects that the local resources aren’t sufﬁcient any-

more, or when it receives a departure demand from

the local Manager, it migrates to the new best com-

puter and resumes its task. At the end, it returns to the

initial computer and terminates the execution.

5.3 The Practical Tests

It wasn’t possible to test our model in a real situa-

tion, on the internet, mainly because of the security

restrictions concerning the mobile agents. So we were

forced to perform the tests at a reduced scale. We

used a simpliﬁed version of our programs and we in-

stalled and deployed them on three different comput-

ers from the computational power point of view, con-

nected on a local network (of the LIP6, University of

Paris 6), with the following characteristics: a Pentium

III-1 GHz, with 1 GBytes RAM and Windows Server

2002 OS, a Pentium IV-2,6 GHz, 512 MBytes RAM,

Windows XP and a Pentium III 1,5 GHz, 256 MBytes

RAM, Windows XP.

The results aren’t entirely representative because they

were obtained in a simpliﬁed environment. Mean-

while, they give an approximation of the different

characteristics, if the system would have been imple-

mented in a real situation.

5.4 Results

The tests were performed in several steps. First, we

started four Task agents on each machine, in a static

manner (by forbidding the migration). The four Task

ﬁnish after 20 minutes on the slowest computer, com-

paring with 10 minutes on the two faster ones. Next,

we performed the same test, without started any task

on the second computer and allowing the migration.

In this way, 2/5 of the system total computational

Figure 3: Experimental results

power wasn’t utilized. All the agents from the third

machine migrated to the ﬁrst machine (the best one,

that was free at the last passage of the Sniffers) which

become overcharged, but some of the agents (that

overcharged the maximum number of agents for a op-

timal run) migrated to the second computer, that was

free. A centralized distribution of charge would have

avoided this useless migration from 3 to 1, but in our

ICEIS 2004 - SOFTWARE AGENTS AND INTERNET COMPUTING

354

case we couldn’t hope for a better execution, because

the agents worked with obsolete data. This useless

migration took between 20 and 40 seconds for the

three involved agents. In spite of this, the earning of

time was important (see Figure 3).

We have to note that during the tests, all the agents

having the same preference description Galois lattice

migrate to the same destination. It is very probable

that the situation would be the same if they would

have lattices with little differences. This ”rabble” mi-

gration is not very efﬁcient and the destination com-

puter will be rapidly overcharged. It would be prefer-

able in the future to have a co-operation between the

agents in order not to migrate to the same site, because

this behaviour affect all the agents in the system. In

plus, we’ll consider in the future the introduction of

authorisation and reservation mechanisms that could

avoid the useless migrations of the agents.

6 CONCLUSION AND FUTURE

WORK

The performed tests cannot be considered complete

for several reasons. First, using SyMPA, the agents’

execution is necessarily slowed down in order to al-

low the users to follow the agents’ behavior, com-

munication and migration. Another limit of these

tests is their reduced scale and the fact that they don’t

take into account all the computers selection criteri-

ons from our list. It would be necessary to replace the

system in a real situation for a complete validation.

The system itself leaves some points in suspense. The

Galois lattices should be built entirely in a dynamic

and automatic manner. It would be also useful to have

standard lattices for some types of applications.

Nevertheless, the interest of this work consist in the

real experimentation of the agents’ distribution, that

allowed us to show the viability of the mobility for the

load balancing. The computers’ classiﬁcation based

on the Galois lattices also seems pertinent. It allows

to reasonably choose a computer based on completely

dynamic descriptions. Finally, we could prove that

the platform efﬁciently manage the migration and the

communication.

There are a lot of things to do in the future concern-

ing this work. In the ﬁrst phase, we would like to

implement our system in an environment closer to its

real destination, i.e. on several computers physically

distant. We should also propose a coordination mech-

anism between the Task agents in order to avoid the

mass migration to the same destination and a reserva-

tion mechanism for allowing a continuous utilization.

Using the properties of the Galois lattices, it should

be possible to a Task agent to clone a part of itself and

to give it the sub-lattice adapted to its needs. It should

be also possible to create new lattices in function of

the last experiences (maybe using genetic algorithms)

and to ﬁnd a pertinent way to use the data gathered by

the Sniffers.

REFERENCES

Bhagwan R., Savage S., Voelke G. M. (2003). Overnet:

Understanding Availability. In Proceedings of the 2nd

International Workshop on P2P Systems.

Cardelli L., Gordon A. (1998). Mobile Ambients. In

Foundations of Software Science and Computational

Structures, Maurice Nivat (Ed.), LNCS, Vol. 1378,

Springer, pages 140-155.

Carriero N., Gelernter D. (1989). How to write parallel pro-

grams: a guide to the perplexed. In ACM Computing

Surveys, Vol. 21(3), pages 323-357.

Diday E., Emilion R. (2003). Maximal and Stochastic Ga-

lois Lattices. In Discrete Applied Mathematics, Vol.

127(2), pages 271-284.

Dongarra J., et al. (1993). Integrated PVM Framework Sup-

ports Heterogeneous Network Computing. In Com-

puters in physics, Vol. 7(2), pages 166-174.

El Fallah-Seghrouchni A., Suna A. (2003). An Uniﬁed

Framework for Programming Autonomous, Intelli-

gent and Mobile Agents. In the proceedings of

CEEMAS’03, LNAI, Vol. 2691, pages 353-362.

El Fallah-Seghrouchni A., Suna A. (2003). CLAIM: A

Computational Language for Autonomous, Intelligent

and Mobile Agents. In Proceedings of ProMAS’03,

workshop of AAMAS, Melbourne, Astralia.

Foster I., Kesselman C. (1999). The Grid: Blueprint for a

Future Computing Infrastructure. Morgan, Kaufmann.

Foster I., Kesselman C. The Globus Project: a statuts report,

on-line at: http://www.globus.org

Geist A., et al. (1994). PVM: Parallel Virtual Machine: A

Users Guide and Tutorial for Network Parallel Com-

puting. In MIT Press.

Java on-line at http://java.sun.com

Klein G., El Fallah-Seghrouchni A., Taillibert P. (2002).

HAMAC: An Agent Based Programming Method. In

Proceedings of AAMAS’02, pages 47-48.

MPICH-G2: A Globus-enabled MPI, on-line at:

http://www3.niu.edu/mpi/

Milojicic D., et al. (1998). MASIF, The OMG Mobile Agent

System Interoperability Facility. In Proceedings of

Mobile Agents, LNAI, Vol. 1477, pages 50-67.

Ore O. (1944). Galois Connections. In Trans. Amer. Math.

Soc., Vol. 55, pages 494-513.

Seti on-line at http://www.setiathome.ssl.berkeley.edu/index.html

Stoica I., et al. (2001). Chord: A Scalable Peer-To-Peer

Lookup Service for Internet Applications. In Proceed-

ings of the ACM SIGCOMM ’01, pages 149-160.

Vercouter L. (2002). A fault-tolerant open MAS. In Pro-

ceedings of AAMAS 2002, ACM, pages 670-671

White B. S., et al. LegionFS: A Secure and Scalable File

System Supporting Cross-Domain High-Performance

Applications. On-line at: http://legion.virginia.edu/

RESOURCE SHARING AND LOAD BALANCING BASED ON AGENT MOBILITY

355
