ACQUIRING AND INTEGRATING EXTERNAL DATA INTO

DATA WAREHOUSES

Are You Familiar With the Most Common Process?

Mattias Strand, Benkt Wangler, Carl-Fredrik Lauren

Department of Computer Science, University of Skövde, Box 408, Sweden

Keywords: Data Warehouse, Data In

tegration, Data Acquisition

Abstract: Data warehouses (DWs) has beco

me one of the major IT-investments during the last decades and in order to

fully exploit the potential of data warehouses, more and more organizations are acquiring and integrating

external data into their star-schemas. However, the literature covering external data acquisition and

integration is limited. Therefore, in this paper the results of an interview study conducted among banking

organizations are presented. The study aimed at identifying different approaches for acquiring and

integrating external data into DWs. The results show that there are many different approaches for the

acquisition and integration, depending on the purpose and structure of the data being acquired. In addition,

the most common external data acquisition and integration process is presented and discussed.

1 INTRODUCTION

The concept of data warehouse (DW) has evolved

out of two needs: the business requirement of a

company-wide view of information and the need

from IT departments to be able to manage company

data in a better way. Current database technologies

make it possible to effectively store large amounts of

internal data in a well-organised way (Connolly and

Begg, 2002).

However, to be able to better plan for future

ccess of the corporation, more than just the

internal data is needed (Devlin, 1997). Furthermore,

Inmon (1999) argues for the importance of

integrating internal and external data, as it creates an

enhanced foundation for decision-support, i.e. it

allows the decision-maker to contrast and verify

internal information from an external perspective.

On the contrary, Inmon (1999) also claims that the

integration of external data with the internal data is

the most difficult problem of external data

incorporation.

Still, the literature covering this issue is limited

and fra

gmented. Therefore, in this paper, we present

the results of an explorative interview study partly

aimed at outlining and describing different issues on

external data acquisition and integration. In addition,

a major purpose of the paper is to outline specific

problems that make the integration so problematic.

This will be done by concrete examples and

explanations as to their relation to the integration

efforts.

The rest of the paper is outlined as follows.

Firstly, related

work is presented in Section 2. In that

description we also define external data and give a

résumé of existing literature on external data

acquisition and integration. Section 3 describes the

interview study conducted. In Section 4, analysis

and results are given. The paper is concluded

(Section 5) with a discussion on the future for

external data incorporation and ideas for future

work.

2 RELATED WORKS

In this section external data will be defined and

introduced. In addition, although the literature

coverage of external data acquisition and integration

is limited some ideas from related literature will be

presented and discussed.

According to Singh (1998), one of the main

reason

s for a DW is to set free the information that is

locked up in the internal operational databases and

508

Strand M., Wangler B. and Lauren C. (2004).

ACQUIRING AND INTEGRATING EXTERNAL DATA INTO DATA WAREHOUSES - Are You Familiar With the Most Common Process?.

In Proceedings of the Sixth International Conference on Enterprise Information Systems, pages 508-513

DOI: 10.5220/0002601905080513

 SciTePress

to mix it with information from other external

sources. Singh (1998) further advocates that

organizations should increase their acquisition of

data originating from outside their own systems

boundaries. Inmon (1996) is even more outspoken

concerning the contribution of external data in a

DW. He claims that even though external data do

not say anything directly about particular companies,

they may still give a lot of valuable information

about the environment that the company must work

and compete in.

Defining external data is not trivial, since the

externality may be considered in different ways.

From a DW perspective, several notions are to be

found related to the acquiring external data from

outside the organization (e.g. Kimball, 1996; Kelly,

1996; Damato, 1999; Oglesby, 1999) However, for

this work, the following definition was adopted

(Devlin, 1997, p. 135):

“Business data (and its associated metadata)

originating from one business that may be used as

part of either the operational or the informational

processes of another business.”

The generality of the definition was considered

as important, since the aim of the work was to

outline, from a broad, explorative perspective,

current approaches for acquiring and integrating

external data.

External data has, in a comparison with internal

data, some different key characteristics, especially

from an acquisition and integration perspective. First

and foremost, the acquiring organization has less of

the structure of the data. Even worse, the conceptual

meaning of the data may also be difficult to

interpret. Inmon et al. (2001) also emphasize the

transformation problems of external data, as

important metadata may be missing, making

transformations almost impossible. Still,

organizations tend to reduce the impact of these

potential problems, by acquiring external data from

specialized data suppliers (Strand et al., 2003).

Kimball (1996) refers to these as syndicate data

supplier.

3 THE INTERVIEW STUDY

Data for the study were primarily collected through

interviews. The following steps were used to guide

the preparation and accomplishment of the

interviews:

1) Selecting the respondents. For this study, it

was considered as important to interview

organizations that were long-gone in there DW

initiatives. Therefore, the financial sector was

considered suitable, with a specific focus on banks.

The respondents were selected by contacting all

companies labelled bank on the yellow-pages. A

total amount of 24 companies were contacted.

However, since the scope of the study was rather

narrow (the companies should have a DW and

incorporate external data into it), only 10 banks

remained. 8 out of these 10 companies agree on

participating, making the final “interview rate” 80%.

2) Constructing the interview questions. The set

of interview questions was split into four main

groups, besides the usual introductory and

concluding questions. The questions were arranged

according to the four main activities of the external

data integration process, i.e. identification,

acquisition, integration, and usage (Strand, 2003). In

this paper, results related to acquisition and

integration will be accounted for.

3) Initiating the interviews. The interview

questions were sent to the respondent in advance so

as to let them read through the questions and reflect

upon them before the actual interview. A

personalized cover letter accompanied the interview

questions, the aim of which was to explain the

purpose of the study and to guarantee the

confidentiality of the collected data, and to explain

how the material was to be compiled and validated.

4) Conducting the interviews. Every interview

lasted for approximately 60 minutes. After the

interviews, the answers were transcribed and sent

back to the respondent for reviewing and

authorization. In this way, we avoided errors in the

material and misinterpretations were corrected.

4 ANALYSIS AND RESULTS

In the following section, the analysis of the

interview study is presented, along with the results

of the analysis.

4.1 Issues on External Data

Acquisition

In this section, issues related to external data

acquisition will be described and discussed.

Integration approaches are given account for in the

next section (Section 4.2).

Firstly, there seems to be two main approaches

of the frequency of which the consuming

organizations are acquiring the external data from

syndicate data suppliers. The most common out of

these two was to use a subscriber service approach.

Subscriber service means that the consumer receives

external data on a regular basis, i.e. as any other

subscription, according to the established contract

ACQUIRING AND INTEGRATING EXTERNAL DATA INTO DATA WAREHOUSES: Are you familiar with the most

common precess?

509

between the two parties. This approach was used by

five out of eight corporations (63 %). The second

most common approach for acquiring external data

is the on-demand approach. Corporations using the

on-demand approach contact their suppliers when

they need external data. This approach was used by

three out of eight corporations (37%). The most

common motivation for acquiring the data On-

demand Approach was solely base on monetary

issues. Organizations that had no need for external

data on regular basis did not want to pay in vain for

the rather expensive data.

One of the respondents claimed that they were

only randomly acquiring data from external sources

and represents thereby a third, minor approach, i.e.

randomly. This approach differs from the on-

demand approach since it is not based upon an

existing supplier-consumer relationship. Instead a

contract is established when needs arise. Moreover,

one of the respondents stated that they used both

subscription and on-demand for acquiring external

data, and that explains the fact that 8 respondents

were applying the first two approaches. The reason

given for applying both approaches was that the

supplier which the organization was subscribing

from could not supply with all external data needed.

Occasionally, the organization needed other data and

therefore they acquired it from another data supplier.

The next issue focused upon was related to how

the external data was distributed to the consuming

organization. The results of the interview study

shows that the external data could be distributed

from the suppliers in several different ways. The

corporations receive external data from the suppliers

by; 1) File Transfer Protocol (FTP) technology, 2)

have a DVD-ROM or CD-ROM sent to them, 3)

have the external data attached in an E-mail or 4) by

accessing a Web-hotel. The FTP technology was the

most common approach applied. Seven out of eight

(88%) corporations used FTP to receive the external

data. The reason for using FTP was that the

organizations already had the necessary, underlying

technology and that it gives an opportunity to

automatically integrate the data, without any manual

activities needed. The data was simply pumped into

the data transformation tools in the same manner as

the internal data. The second most used approach

was to receive external data sent on a CD-ROM.

This approach was never used stand-alone, but as a

complement to FTP transfer.

The other two approaches, i.e. the external data

attached in an e-mail or by accessing a Web-hotel

were not given too much attention. However, the e-

mail approach was considered as convenient when

only small amounts of data was needed and when it

was needed instantly. In such cases, the external data

was attached to the mail and sent to the

administrator of the DW. This approach was also

used as a complement to FTP. The final approach

mentioned in the interviews was the access a Web-

hotel. In this case, no other approaches were used.

When new external data is available, the corporation

receives a message from their supplier and may then

access the Web-hotel and download the external

data.

The third issue concerned the tools used for

extracting, transforming, and loading (ETL) the

external data into the data warehouse. In addition,

the interviews also brought some interesting

viewpoints on whether the ETL operations are

automatically performed by these tools or whether

there are operations that are performed manually.

These tools discussed in this section will for now on

be referred to as ETL-tools.

According to the results of the interviews, five

out of eight (63%) organizations applied commercial

ETL-tools when integrating the external data. The

reasons given for this by the organizations are well

aligned with the advantages mentioned by Gleason

(1997), i.e. the built-in support for metadata

generation and the avoidance of the sometimes

costly and not always successful, products of in-

house development. Especially the generation of

metadata was considered as important and this is

also emphasized by e.g. Devlin (1997), Inmon et al.

(2001), and Marco (2000).

On the contrary, the rest of the respondents were

applying in-house developed ETL-tools. Their

strongest argument for not investing in commercial

tools was the large monetary investment related to

such procurement. Another argument given was that

by developing an own, in-house solution, the

organization preserves the control over what data

enters the DW. The respondent claimed that

commercial ETL-tools were functioning in a black-

box matter, giving that raw external data was

entering the tools and resulted in external data mixed

in the DW without actually any control of the quality

of the data.

ICEIS 2004 - DATABASES AND INFORMATION SYSTEMS INTEGRATION

510

The drawback of such solution was that it is

difficult to develop such commercial look-alike tools

and therefore, for being able to achieve the overall

same functionality, the organization had to invest in

additional programs. Occasionally, this also resulted

in manual activities, where it was difficult to

integrate the different components.

4.2 Characterizing External Data

Integration Approaches

After the data has been acquired and transformed

according to given rules, it will, in some way or

another, be integrated into the DW environment. The

integration approach chosen depend on the purpose

of the external data. Therefore, in this section,

different integration approaches will be described

and exemplified.

As a result of the interview study and related

literature, the following four integration approaches

has been identified (Figure 1):

• Star-schema dimension integration

• Dimension attribute integration

• Attribute value integration

• Spread-sheet integration

The first approach is to integrate the external

data into a separate dimension in the DW. By

integrating external data into separate dimensions

the external data is not mixed with the internal data.

This may be contributory as external data is

sometimes of poor quality. For example, an

organization may want to add a business partner’s

customer data to a star-schema designated towards

sales (Figure 1A). However, if the organizations do

not want to mix its internal customer data with the

business partner’s data, that data is then stored in a

separate dimension. This approach was applied by

two out of eight corporations.

The second approach relates to separate

attributes containing the external data, presented and

store in dimension which is mostly based on internal

data. As an example, one of the respondents

mentioned customer ratings. The respondent

explained that his organization bought customer

ratings from a syndicate data supplier and used that

data to segment customers in different types of

marketing campaigns. An example of attribute

integration is presented in Figure 1B. This approach

was used by three out of eight corporations.

The third approach was to consider the external

data integrated on a attribute value level, i.e. mixing

the data store under one attribute, from both internal

and external sources. In this way, the external data is

ACQUIRING AND INTEGRATING EXTERNAL DATA INTO DATA WAREHOUSES: Are you familiar with the most

common precess?

511

strongly integrated with the external data, making it

transparent to the user whether the data is

originating from the internal systems or if it is

integrated directly from an external source. The

most common example given in the interviews was

customer address refreshments, in which customer

addresses acquired from the internal systems are

refreshed with external data. In this sense, the DW

becomes the washing machine, the internal data is

the dirty laundry, and the external data becomes the

soap (Figure 1C). When the customer address data

are to be updated, fresh addresses is purchased from

a data supplier and the old value is updated and

replaced with the new one as the DW is refreshed.

An example of this is shown in Figure 1C. This

approach was used by four out of eight corporations.

The fourth and last approach was to store the

external data in a reference table (Figure 1D). In this

sense, the external data is not integrated into the

DW. Instead, it is integrated in a spread-sheet

manner (concept adopted from Devlin, 1997), where

the querying tool uses external data, collected from a

reference table outside the DW, to plot the external

data into a referential line, allowing for comparison

with the internal data result. This approach was only

vaguely expressed during the interviews. Still, it was

considered as relevant, since Devlin (1997) mentions

reference tables as a possible way to handle external

data that is somewhat “integration-awkward”.

To conclude this section, it was clearly shown

that external data may be acquired and integrated in

many different ways. Probably, if this study was

conducted in a few years time, there would probably

be more than one organization that applied more

than one integration approach. However, currently

one may claim that the most common process of

acquiring and integrating external data would be

outline as follows; the data is acquired via a

subscription service and distributed to the

organization by FTP technology. Thereafter, it is

scrubbed and cleaned in a commercial ETL-tool and

integrated with the internal data as attribute values.

4.3 Common problems

The interviews gave the following problems as most

common for hindering organization to integrate

external data:

• Data structure problems

• Poor data quality

• Expensive ETL-tools

The most common problem regarding integration

of external data into DWs is the difference in the

data structure of external data compared to the

structure of the internal data already stored in the

DWs. This problem is also described in the literature

by Devlin (1998) and Inmon et al. (2001). The data

must be transformed to fit the data structure of the

DW and this is a very time consuming and costly

process. This problem could be solved if the data

suppliers adjust the external data in the way that the

corporations request. However, this requires that the

data actually is integrated from external data

suppliers. This is the most common approach, but

far from the only (Strand et al., 2003).

The problem with poor data quality is a well

known problem and mentioned in literature by e.g.

Adelman (1997), Inmon et al. (2001), and Strand

and Olsson (2003). The information gathered from

the interviews presents three main problems

regarding data quality. 1) The age/staleness of

external data. Data acquired from external sources

could be old and when old external data is integrated

and then used in a DW, the result is not accurate.

Internal data is according to Inmon et al. (2001),

time-stamped before it is integrated into a DW.

External data must also be time-stamped, but as the

source of the external data sometimes is unknown, it

may only be time-stamped from an integration

perspective and not from a factual age perspective.

You may never know for how long the data has been

stored at its source, before it was acquired. From the

authors’ point of view, this problem is usually

related to data received from other sources than data

suppliers, as data suppliers generally deliver data

that is time-stamped. 2) The origin of the external

data may be unknown, making it difficult to rely on.

Also in this case, it was shown that organizations

tend to trust well-known data suppliers and thereby

make the origin of the data known. 3) The most

obvious problem related to data quality is incorrect

data, which may result in important decisions made

on incorrect numbers or facts. This is an issue that is

difficult to solve, since it depends on how suspicious

you are as a decision-maker and on how many

sources you base your decisions on. If you solely use

the DW data as a baseline for decision-making, you

may become very sensitive. However, if you

complement the warehouse facts with data and

information from other sources, the sensitivity is

dramatically decreased.

Finally, advantages and disadvantages of

expensive, commercial ETL-tools have already been

discussed in detail in Section 4.1 and will not be

given more attention.

5 DISCUSSIONS

Based on the experiences and results of the

interview study, it is interesting to discuss the

ICEIS 2004 - DATABASES AND INFORMATION SYSTEMS INTEGRATION

512

duality of the future of external data integration. In

alignment with the results of the interview study

presented in Strand and Olsson (2003), indicating

that the integration of external data will drastically

increase in the future, the result of this study shows

that the increased usage of external data may take

two different faces. The respondents of this study

became divided into two equally big groups, in

which one group claimed that the integration of new

external data will increase, whereas the other group

claimed that it is no necessity that new data will be

integrated. Instead, organizations must become

much better on fully exploiting the external data that

they already integrate. Mostly, economical reasons

underlined the second viewpoint, since most

organizations claimed that external data (acquired

from syndicate data suppliers) is very expensive and

therefore, to be able to achieve return on

investments, it must be much more exploited.

However, other reasons were also presented and

security issues and regulating laws were indicated as

barriers for increased external data incorporation.

Obviously, when acquiring and distributing data

from external sources, holes are opened up in the

system and these holes must be kept to a minimum.

The respondents aiming for an increased

integration of new external data, advocated as their

strongest reason that the DW becomes more and

more integrated with other systems and this

generates new needs for different types of data.

Nowadays, it is common that business intelligence

initiatives are focused around a technical solution,

with a DW in its core. This idea is well supported in

literature related to DWs solutions, e.g. Tiwana

(2000) and Salmeron (2001).

REFERENCES

Adleman, S., 1997. Data Quality, Data Warehouse:

practical advice from the experts, (Bischoff, Joyce and

Ted Alexander, eds.), New Jersey: Prentice Hall, 122-

134.

Connolly, T. and Begg, C., 2002. Database Systems: a

practical approach to design, implementation and

management). Harlow: Addison Wesley Longman, 3

edition.

Damato, G. M., 1999. Strategic information from external

sources – a broader picture of business reality for the

data warehouse, acquired from

http://www.dwway.com, printed 2003.03.20.

Devlin, B., 1997. Data warehouse: from architecture to

implementation. Harlow: Addison Wesley Longman.

Gleason, D., 1997. Data transformation, Data warehouse:

practical advice from the experts, (Bischoff, Joyce and

Ted Alexander, eds.) (p.). New Jersey: Prentice Hall,

160-173.

Inmon, W. H., 1996. Buliding the data warehouse, New

York: John Wiley and sons, 2

edition.

Inmon, W. H., 1999. Integrating internal and external

data, The Bill Inmon.com library LLC, acquired from

http://www.billinmon.com/library/articles/intext.asp.,

printed 2003.02.23.

Inmon, W. H., Imhoff, C. and Sousa, R., 2001.

Information corporation factory, New York: John

Wiley & sons, 2

edition.

Kelly, S., 1996. Data Warehousing the route to

customization – updated and expanded, New York:

John Wiley & Sons.

Kimball, R., 1998. The data warehouse lifecycle toolkit:

expert methods for designing, developing, and

deploying data warehouses, New York: John Wiley &

sons.

Marco, D., 2000. Building and managing the meat data

repository: a full lifecycle guide, New York: Johan

Wiley & sons.

Oglesby, W. E., 1999. Using external data sources and

warehouses to enhance your direct marketing effort,

acquired from http://www.dmreview.com., printed

2003.02.22.

Salmeron, J. L., 2001. EIS data: findings from an

evolutionary study. Journal of systems and software,

Vol.64, Issue 2, 87-172.

Singh, H., 1998. Data Warehousing: Concepts,

Technologies, Implementations, and Management,

New Jersey: Prentice Hall.

Strand, M., 2003. Incorporating external data into data

data warehouses. In proceedings of the knowledge in

organization (KIO) doctorial consortium, part 2, 5-6

February, Västerås, Sweden.

Strand, M. and Olsson, M. (2003) “The Hamlet dilemma

on external data in data warehouses” in Proceedings

of the 5th International Conference on Enterprise

Information Systems (ICEIS) - Part 1, Olivier Camp,

Joaquim Filipe, Slimane Hammoudi and Mario

Piattini. (Ed.), April 23-26, Angers, France, pp.570-

573.

Strand, M. Wangler, B. and Olsson, M.,

2003. Incorporating External Data into Data

Warehouses: Characterizing and Categorizing

Suppliers and Types of External Data". In AMCIS’03,

Americas Conference on Information Systems. 2460-

2468, (CD-ROM).

Tiwana, A., 2000. The Knowledge Management Toolkit:

practical techniques for building a knowledge

management system, New Jersey: Prentice Hall.

ACQUIRING AND INTEGRATING EXTERNAL DATA INTO DATA WAREHOUSES: Are you familiar with the most

common precess?

513
