DIFFICULT ISSUES IN DESIGNING ADAPTIVE OBJECT MODEL

SYSTEMS

Yun Mai and Jinmiao Li and Greg Butler

Computer Science Department, Concordia University

Montreal, Canada

Keywords:

Adaptive Object Model, Reﬂection, Software Architecture, Repository-based Software Design.

Abstract:

The adaptive object model enables a system to change its behavior at run-time without re-programming. It

provides an extremely extensible architecture solution for large software systems. As a particular kind of

reﬂective architecture, the core of the adaptive object model encapsulates changeable system properties and

behaviors as meta-information. Changing the meta-information reﬂects changes in the domain. However, this

approach leads to a more complex design compared to a traditional object-oriented design and thus its im-

plementation is difﬁcult for developers. This paper provides a general design model that compiles techniques

proposed by existing adaptive systems and models. The core of the design model is based on a layered archi-

tecture. The paper starts from a high level view of the architecture. It then zooms in different components.

Major issues in designing various components are fully discussed. General design solutions are elicited as a

result of the discussions.

1 INTRODUCTION

Evolution of a software system is hard. To design a

system with future changes in mind becomes an art of

software design. If a system is designed in a ﬂexible

way then it is still possible to minimize changes that

might undermine the original system architecture. A

powerful solution to make a system extremely ﬂexi-

ble and adaptive is to use the adaptive object model

(Foote and Yoder, 1998a; Foote and Yoder, 1998b;

Foote and Yoder, 2001; Revault and Yoder, 2001).

The model allows an application system to be easily

extended and changed at run-time without changing

the existing program.

Normally, a system designed with an adaptive

object model is hard to understand and develop.

Many papers reinforce the concepts on adaptive ob-

ject model from different perspectives with examples

(Johnson, 1997; Manolescu and Johnson, 1999; Mar-

tin et al., 1998; Riehle et al., 2000). But since the

adaptive object model is most suitable to be used in

large systems (otherwise, the system can be easily dis-

carded and re-built from scratch) and it is very expen-

sive to build one, there are not many industry practices

that can best demonstrate how systems are built with

adaptive object model. One of the well-known suc-

cessful practices on adaptive object model is the Argo

framework (Devos and Tilman, 1998). The system is

very large and ﬂexible, but its design is very complex

compared to a traditional object-oriented design ap-

proach.

Designing an adaptive object model system is com-

plex and difﬁcult. It is therefore necessary to provide

a design paradigm for implementing such a system.

This paper unfolds the difﬁcult issues in adaptive soft-

ware system design. By compiling techniques pro-

posed by existing adaptive object model systems, the

paper captures and highlights major design issues and

provides generic design solutions. The rest of the pa-

per is organized as follows: Section 2 is the state of

art of the adaptive object model. Section 3 provides

the software architecture and its key features. Sec-

tion 4 discusses various design issues in the software

architecture. Section 5 concludes this paper.

2 RELATED WORK

In recent years, many works have been devoted to the

adaptive object model (AOM). The Reﬂection pat-

tern (Buschmann et al., 1996), Accountability pat-

tern (Fowler, 1997), and Type Object pattern (Mar-

295

Mai Y., Li J. and Butler G. (2004).

DIFFICULT ISSUES IN DESIGNING ADAPTIVE OBJECT MODEL SYSTEMS.

In Proceedings of the Sixth International Conference on Enterprise Information Systems, pages 295-302

DOI: 10.5220/0002614202950302

 SciTePress

tin et al., 1998) are fundamental technologies of the

adaptive object model. The Dynamic Object Model

pattern (Riehle et al., 2000) captures the basic logical

architecture for the adaptive object model. Detailed

logical architecture designs are presented in (Yoder

et al., 2001a; Yoder et al., 2001b; Yoder and Johnson,

2002).

To allow a software application to change its

behavior on the ﬂy, a well-known solution is to

build the system as a so-called “reﬂective architec-

ture” (Buschmann et al., 1996; Forman and Danforth,

1998; Fowler, 1997). A reﬂective architecture deﬁnes

a self-descriptive adaptive software system by logi-

cally splitting the system into two parts: a base level

and a meta level. The base level deﬁnes the domain

application logic, while the meta level encapsulates

and represents system structure and behavior informa-

tion by deﬁning metaobjects. Changes to metaobjects

kept in the meta level affect subsequent base level be-

havior (Buschmann et al., 1996). In addition to split-

ting a system into two levels, an interface, called the

Metaobject Protocol (MOP), has to be deﬁned to al-

low clients to specify and manipulate changes to the

system. Figure 1 shows the general structure of a re-

ﬂective architecture.

Component

MetaObject MetaobjectProtocol(MOP)

MetaLevel

BaseLevel

Figure 1: Reﬂective Architecture

The adaptive object model is a particular kind of re-

ﬂective architecture. The core of the adaptive object

model is the Type Object pattern (Martin et al., 1998).

Type Objects explicitly represent type information as

instances of a class, namely type class or meta class.

Therefore, the type information can be created and

modiﬁed dynamically at run-time, just like any ma-

nipulation of objects in a traditional object-oriented

system. All type information are encapsulated in the

meta level so that changes to the meta information

reﬂect changes to the system behavior. In addition,

attributes, relationships, and behavior of a class are

normally represented separately from the class itself.

These approaches can be achieved by applying some

patterns such as the Property pattern (Riehle, 1997)

and Strategy pattern (Gamma et al., 1995). The Type

Object pattern, Property pattern, Strategy pattern, and

Value Holder pattern (Foote and Yoder, 1998a; Woolf,

1994) together form a Type Square (Balaguer and Yo-

der, 2001; Yoder et al., 2001a), which is the core

architecture of the adaptive object model (Johnson,

1997; Yoder et al., 2001a; Yoder et al., 2001b; Yo-

der and Johnson, 2002). Figure 2 shows the core ar-

chitecture of the adaptive object model. In addition

to the software patterns presented above, other pat-

terns may also be used to build a real adaptive sys-

tem. They are speciﬁc to system requirements and

design implementation. Examples of such patterns

include Organization Hierarchy (Fowler, 1997), His-

tory (Johnson and Oakes, 1998) (also Historic Map-

ping (Fowler, 1997)), Rule Object (Arsanjani, 1998;

Arsanjani, 2000; Arsanjani, 2001), Serializer (Riehle

and et al., 1998)etc.

Entity

EntityType

Property

PropertyTypeBehavior

Value

Figure 2: Core Architecture of the Adaptive Object Model

There are some successful industry experiences in

using the adaptive object model including the well-

known Argo framework and Objectiva framework.

Argo is a framework that is used to develop appli-

cations for a semi-government organization manag-

ing several hundred public schools. The framework

behavior is driven by a repository. New applications

can be developed through modeling and conﬁguration

rather than through coding (Devos and Tilman, 1998).

Objectiva is a framework that is used to develop ap-

plications for telecommunication billing. It aims to

develop a single billing system to handle any kind of

telecommunication service (Anderson and Johnson,

1998).

3 SOFTWARE ARCHITECTURE

There are two key architecture features in a system

designed with the adaptive object model: metadata

driven and layered architecture.

3.1 Metadata Driven

An adaptive system is a system that could adapt itself

to requirement changes and system changes on the ﬂy.

Such a system is self-describable. It maintains infor-

mation about system itself and uses this information

to remain changeable and extensible. The foundation

of the adaptive object model is the Type Object pat-

tern (Martin et al., 1998). As described in Section 2,

object types are represented as objects (named type

ICEIS 2004 - INFORMATION SYSTEMS ANALYSIS AND SPECIFICATION

296

objects) and processed like any objects. By chang-

ing the type objects at run-time, system behaviors and

states are changed accordingly.

An adaptive object model system is an open meta-

data driven software system. The system contains

a repository for different information (Devos and

Tilman, 1998; Forman and Danforth, 1998):

• Domain objects

These objects are about the knowledge of an ap-

plication domain. For example, in a university

management system, domain objects can be ob-

jects representing students, professors, administra-

tion, faculties, etc.

• Meta-information

These are information about the object model that

describes the domain object types and their rela-

tionships. They can be information about the ap-

plication structures, business models, user views,

etc.

The repository contains all information about an

application domain, the domain model, and the model

description itself. The repository is accessible at run-

time so by changing the meta-information, the system

becomes adaptive.

3.2 Layered Architecture

Layering is a common design technique to break

down a complex system. It reﬂects the “divide and

conquer” principle and helps to minimize subsystem

dependencies. A lower layer provides services to the

layer above it. A layered system can be easily under-

stood in isolation and be substituted easily. An adap-

tive object model system can be broken down into

three layers: Front Room, Presentation Server, and

Back Room. Figure 3 shows its layered architecture.

• Front Room is a subsystem that provides services

to the end user. It includes a set of presentation

tools such as data access tools, query management,

end-user applications, tools for conﬁguration and

administration, etc.

• Presentation Server is a subsystem that maintains

a repository for object model and domain ob-

jects. It contains some managers that handle ob-

ject caching, query, transaction and lock. Presenta-

tion Server interacts with Back Room subsystem to

read/write data from/to different data stores.

• Back Room is a subsystem interacting with data

sources. There are two abstraction layers in this

subsystem. Data Mapping Engine maps the in-

memory data (such as in-memory objects) into

an abstract representation (logical data represen-

tation). Persistency Engine then maps the logical

data representation to its physical storage (physi-

cal data representation). Data Mapping Engine has

no knowledge of any physical data storage detail,

while Persistency Engine has no knowledge of the

in-memory data format.

Front Room

Presentation Tools

Presentation Server

Back Room

Data Mapping Engine

Persistency Engine

Data Source

Systems

Figure 3: Layered Architecture for AOM

4 MAJOR DESIGN ISSUES OF

THE AOM ARCHITECTURE

In this section, we follow the software architecture

structure presented above and further discuss major

issues that may be encountered in each part of the lay-

ered architecture design.

4.1 Front Room

Front Room refers to some tools and applications that

provide interactive interfaces to end users. First of

all, there are end-user applications that provide main

functions to the end user for daily processing. In addi-

tion, administration and conﬁguration tools have to be

provided to allow the authorized high-level end user

to monitor and change objects (including meta ob-

jects) in the repository. There are some issues related

to the object manipulation in the Front Room.

Issue 1: User Authorization Issue

Since a change of an object in the repository can cause

an end-user application to change its behavior, it must

be careful to provide authentication rule for only au-

thorized users to do so. Roughly, we divide end users

into two groups: operator only runs and uses the end-

user applications, while administrator not only is able

to run end-user applications but also can use conﬁgu-

ration and administration tools to browse objects, add

new objects, and change existing objects. Figure 4

shows the use case diagram.

DIFFICULT ISSUES IN DESIGNING ADAPTIVE OBJECT MODEL SYSTEMS

297

End-user Applications

Configuration and

Administration

Operator

Administrator

Figure 4: Use Case Diagram for the AOM System

Issue 2: Object Conﬁguration Issue

A typical object conﬁguration scenario in an adaptive

object model system is: the user creates some crite-

ria to search for an object, upon receival of a set of

matched objects, the user picks one and displays its

properties for browsing or conﬁguration. The more

adaptive a system is, the more objects have to be

stored for conﬁguration. We want to store as much

information as possible for conﬁguration. But to pro-

vide customized forms for every object to be browsed

and conﬁgured is a daunting task.

To minimize the workload in creating object brows-

ing and conﬁguration forms, factoring out common

objects and common properties is very important. It is

generally a good practice to provide a common object

query window and a common object browsing win-

dow, and for each object, a separate window can be

created to show object properties. Creation of object

property windows should take advantage of the Type

Object pattern so that all object properties can be re-

trieved and displayed via object introspection. In ad-

dition, rules and constraints should be deﬁned to en-

sure object integrity. Some adaptive systems such as

Argo (Devos and Tilman, 1998) and Objectiva (An-

derson and Johnson, 1998) provide good examples in

designing conﬁguration and administration tools.

Issue 3: End-User Programming

The adaptive object model differs from traditional ob-

ject model in that the system behavior can be changed

at run-time. This is achieved by providing a simple

domain-speciﬁc language (such as scripts), so sophis-

ticated users can modify existing object behavior or

add simple behavior for newly created types without

re-deployment. The domain-speciﬁc language can be

used to specify process rules, class behavior, and var-

ious constraints. A specialized compiler should be

provided to parse the scripts into an abstract syntax

tree or rule objects (Arsanjani, 2000), which will be

stored and interpreted for run-time execution.

4.2 Presentation Server

Presentation Server is the middle tier in the adap-

tive object model software architecture. It bridges

the Front Room and the Back Room. Presentation

Server provides a data repository that manages the in-

memory information. As a data container, there are

some important design issues about its capacity, oper-

ation performance, data load and update, etc.

Issue 1: Performance Issue

As stated before, Presentation Server is essentially an

in-memory repository that contains domain objects

that describe the application domain and the meta-

objects that specify the meta-information. On one

hand, all information about the application domain

and the system itself need to be stored as objects in

the repository. On the other hand, the repository is

an in-memory data container and will have a limited

capacity. It is impossible to store all objects in mem-

ory in most cases. Therefore, some objects have to

be loaded on demand. If the user issues an operation

and most related objects are not in memory, the sys-

tem has to load the meta-objects, and then the domain

objects. It is inevitable that the user will perceive a

signiﬁcant delay.

To solve this problem, we need a Cache Manager.

The Cache Manager will implement a certain num-

ber of caching strategies. So at run-time, depending

on the operation context, a caching strategy is chosen

and objects are loaded implicitly on demand under

unawareness of the end user. When an object is re-

quested, the cache (in-memory repository) is checked

ﬁrst, if the object exists it is returned to the appli-

cation; otherwise, the Cache Manager is responsible

for loading it from the persistent storage (by send-

ing requests to the Back Room). The Cache Manager

decides what objects to be pre-stored in the reposi-

tory according to a caching strategy or a combina-

tion of multiple caching strategies. With ﬁne tuned

caching strategies, the performance for data access in

the adaptive system is improved.

Another performance issue is when to create ob-

jects in the in-memory repository. If objects are be

created/loaded on demand, we will face the same per-

formance problem since creating/loading a large num-

ber of objects will be expensive. A solution is to bulk

load objects into the repository initially. A caching

strategy will determine which objects to be loaded at

boot and a bootstrapping process will interact with the

Cache Manager to bulk load objects when the Presen-

tation Server is up.

ICEIS 2004 - INFORMATION SYSTEMS ANALYSIS AND SPECIFICATION

298

Issue 2: Concurrence Access Issue

Since objects are cached in the in-memory repository

(and stored in some persistent storages too), it is risky

that multiple concurrent updates could be made to the

same properties of some objects in a distributed envi-

ronment. So the issue is, how can we control accesses

to the objects so that they will not be left in inconsis-

tent states if multiple manipulations occur?

One straightforward and commonly used solution

is to use transactions and locks. All data operations

must be performed within the context of a reposi-

tory transaction that keeps track of local changes to

one or more objects. Once committed, a transaction

is translated into underlying database operations and

transactions (Devos and Tilman, 1998). Furthermore,

to avoid any accidental corruption of data integrity, a

locking mechanism is necessary. The Locking Man-

ager is responsible for ensuring that object properties

are correctly locked in a transaction.

Issue 3: Data Consistency Issue

Another problem with object manipulation is object

inconsistency. When an object conﬁguration changes,

all objects depending on this object may need to be

changed accordingly. Some data structures such as

Direct Acyclic Graph (DAG) (Shaffer, 1997) can be

used to manage the object dependency relationships.

Should all dependent objects (both in the in-memory

repository and in physical data stores) change imme-

diately, or in-memory objects change ﬁrst while the

others change only when they are loaded? When an

object is not referenced any more, should it be de-

stroyed and when? There are many small issues re-

lating to data consistency. The solution somewhat de-

pends on the system requirements (e.g. performance

requirements and organization policies). A compo-

nent named Consistency Manager can be designed to

encapsulate the solution for these issues.

Issue 4: Version Control Issue

Object manipulation also brings up an interesting

topic on object history management. When an object

conﬁguration changes, should we maintain its his-

tory? This can be up to a system requirement. But,

a good practice is to keep the versions of the object

because they are always useful and desirable. For ex-

ample, if an organization changes one of its statistics

forms to a new format since May 1, 2003, should all

forms (with data) before this date be changed to adapt

to the new form format? Normally, people would like

to display the old data with the old form, while dis-

play the new data with the new form. In such case,

it is important to keep both the new and old form

formats in order to interpret different data. A Ver-

sion Control Manager component is used to control

object versioning. It is responsible for associating

meta-data version information with the corresponding

base-level versioned data, and choosing an appropri-

ate meta-data version to correctly interpret the associ-

ated versioned data.

Repository

Transaction

Manager

Query

Manager

Presentation Tools

Presentation Server

Data Mapping Engine

Bootstrap

Manager

Version

Control

Manager

Consistency

Manager

Lock

Manager

Cache

Manager

Figure 5: Presentation Server Architecture

Design Discussion

Figure 5 shows the high-level design of the Presen-

tation Server subsystem. The core of this subsystem

is the Repository package. It handles any access to

the in-memory repository. The data contained in the

repository are partitioned into type objects and nor-

mal objects constructed according to Figure 2. There

are some other auxiliary packages such as Transac-

tion, Query, Caching, Locking, Bootstrapping, Ver-

sion Control, and Data Consistency, that interact with

the Repository to help control access to and populate

the repository. Each auxiliary package can deﬁne a

manager that provides the main functionality for that

package. The behaviors are illustrated in Figure 6 for

executing a query and Figure 7 for executing a con-

ﬁguration command.

: QueryMgr: FrontRoom::Tool : RepositoryMgr : BackRoom::Mapper

query()

load()

: CacheMgr

load()

check()

VersionMgr

checkVersion()

Figure 6: Sequence Diagram for User Query

DIFFICULT ISSUES IN DESIGNING ADAPTIVE OBJECT MODEL SYSTEMS

299

: TransactionMgr

: FrontRoom::Tool

: RepositoryMgr

: BackRoom::Mapper

update()

: LockMgr

update()

getLock()

VersionMgr

ConsistencyMgr

updateVersion()

updateDependences()

update()

Figure 7: Sequence Diagram for User Conﬁguration

4.3 Back Room

An adaptive object model system is a kind of

repository-based system, that is, the application’s be-

havior is driven by the repository. Therefore, we need

a persistency mechanism to protect the repository in-

formation from loss. Back Room is such a subsystem

to handle data persistency in the AOM architecture.

Issue 1: Model Persistency Issue

A traditional system only stores application data (do-

main information) into persistency. In an AOM sys-

tem, only store domain information are not enough.

To avoid any loss of the meta-information, we also

need to store them to a persistency media. In other

words, we not only store application information (do-

main objects) as persistency, but also store meta-

objects as persistency.

Issue 2: Data Storage Issue

As discussed above, application information such as

objects, code-based rules or constraints, different for-

mats of domain information, should be stored in the

persistent storage. Different information may re-

quire different data storage carriers. Typical data

stores include object-oriented database systems, re-

lational database systems, XML (Extensible Markup

Language) documents, ﬂat ﬁles, and so forth. For

an object-oriented software system, object-oriented

database is a straightforward solution for object stor-

age. XML ﬁle format is an alternative solution be-

cause there exist many ready-to-use XML tools (e.g.

SAX and DOM parser) that simplify data process

and speed up system development. But for rela-

tional database, an object-relational mapping mech-

anism should be provided to handle the data trans-

formation between in-memory objects and relational

data. The following will give a more detailed discus-

sion on the object-relational mapping.

Issue 3: Persistency Access Issue

Since there are different data storage formats, ac-

cess to persistent storage varies greatly. The problem

is, if such chunk of connectivity code has to be re-

peated wherever a persistency connection is required,

it tightly couples the application and the data sources

so that migration from one type of data source to an-

other is difﬁcult.

DAO

RelDbDAO OODbDAO

XMLDAO

+load()

+update()

+insert()

+remove()

Mapper

RelDbMapper

OODbMapper

XMLMapper

Data Access

Figure 8: Persistency Access with Data Access Object

(DAO) Pattern

Data Access Object (DAO) (Sun Microsystems

Inc., 2003) aims to solve persistency access problem.

A DAO encapsulates all accesses to a data source. In

an AOM system, we can create a DAO class and sub-

class it with concrete DAOs that handle different data

storage types. One concrete DAO is responsible for

handling any access to objects stored in that corre-

sponding media type. Figure 8 (grey area) shows an

example.

Issue 4: Persistency Mapping Issue

If objects are stored to the same persistency media,

they will share the same DAO. But, how can the DAO

tell the differences of the objects it is going to handle?

A DAO cannot tell the differences of the objects.

All objects must be processed before they are for-

warded to a DAO. A mapping mechanism must be

provided in order for a DAO to correctly process the

objects. Figure 9 shows an example of a mapping en-

gine.

+load()

+update()

+insert()

+remove()

Mapper

RelDBMapper

OODBMapper

XMLMapper

Metadata Mapping

-dataClass : Class

-tableName : String

-columnMaps : List

TableMap

-columnName : String

-fieldName : String

-field : Field

-dataMap : TableMap

ColumnMap

Figure 9: Persistency Mapping with MetaMapping Pattern

Our goal is to map objects in storage to objects

in memory. As shown in Figure 9, by applying the

ICEIS 2004 - INFORMATION SYSTEMS ANALYSIS AND SPECIFICATION

300

MetaData Mapping pattern (Fowler, 2002), relational

database mapper deﬁnes a Table Map class which

maps each data class to its table name, and a Col-

umn Map class to maps data class ﬁeld types to table

column names. By using the information provided

by Table Map and Column Map, the application is

easy to ﬂatten an object and store it into relational

database or assembly it when retrieve it from rela-

tional database. Figure 10 shows a scenario that how

an object is loaded from relational database system.

: RelDbMapper : TableMap : ColumnMap : RelDbDAO

: PresentationServer

:: CacheMgr

load()

getTableInfo()

getColumnInfo()

load()

Figure 10: Sequence Diagram for Data Load from Rela-

tional Database

Design Discussion

Figure 11 shows a common high-level design of the

Back Room subsystem. Back Room contains two lev-

els of data abstraction. The top level, Data Mapping

Engine, is the one for logical data mapping. The bot-

tom level, Persistency Engine, is for physical data ac-

cess. Data Mapping Engine is responsible for map-

ping in-memory information to logical data represen-

tation. The repository not only contains objects, it

also contains documents, images, videos, etc. Ac-

cording to the information stored in the repository,

different data mapping engines should be provided.

In general, we can deﬁne two kinds of data mapping

engines to handle two major data catalogs.

Object Mapping

Engine

Persistency

Engine

Data Source Systems

Presentation Server

Back Room

Document-

based

Mapping Engine

Figure 11: Back Room Architecture

Firstly, an Object Mapping Engine can be deﬁned

to map in-memory objects and their properties to their

logical data abstraction. These in-memory objects

may includes user-deﬁned domain objects, objects in

the object model and meta model, rule objects repre-

senting process rules, class behavior, and various con-

straints, as well as system utility objects.

Secondly, for documents processing, a separate

mapping engine can be deﬁned to handle document

speciﬁc mapping. Document processing can be seen

in many workﬂow systems, we will not further dis-

cuss them in this paper.

Finally, since a physical data access process is

data storage type speciﬁc, we can deﬁne different

media-dependent components in the Persistency En-

gine. Persistency Engine consists of a hierarchy of

DAO objects which handle data storage type speciﬁc

data load and data store.

5 CONCLUSION

To change a system is hard. The adaptive object

model makes it easy to adapt a system to new changes.

Although people complain it is hard to understand

the adaptive object model and to develop a system

with it, we still consider it worthwhile to regard it

as a potential architecture and to invest in it, because

the payback in terms of ﬂexibility and ease of evo-

lution has great value. In an adaptive object model

system, everything is an object including the system

aspects that describe the business model and that de-

scribe the model itself. Since objects can be created

and modiﬁed at run-time, it is easy to change the sys-

tem behavior and extend a system using a common

object browser and conﬁguration tool platform. Thus,

no programming practice is required to make such

changes. The drawback of using the adaptive object

model is that it is hard to debug the system behavior

since object interaction is implicit due to the reason

that the interaction is encapsulated into object conﬁg-

uration. Still, such a system can be hard to maintain

if the model is not clear or the components of the sys-

tems design are not clear. Hence, the need for a soft-

ware architecture and design guidelines is imperative.

The main contribution of this paper is that it ad-

dresses the complexity and difﬁculty of developing an

adaptive software system. By compiling techniques

proposed by existing adaptive object model systems,

the paper captures and highlights major design issues

and provides generic design solutions. One differ-

ence between the solution proposed in the paper and

other papers is that we deﬁne a layered architecture

for the adaptive system. Layering de-couples interac-

tions between subsystems so that it is easy to plug in

or to replace a subsystem. The architecture is com-

pletely metadata-driven. We discussed various com-

ponents in the system and difﬁcult issues that have

to be considered when designing a system with the

adaptive object model. The paper unfolds difﬁcult

design issues towards an implementation of an adap-

DIFFICULT ISSUES IN DESIGNING ADAPTIVE OBJECT MODEL SYSTEMS

301

tive software system with the adaptive object model.

The guidelines suggested in this paper will help soft-

ware designers to address major design problems in-

herent in the adaptive system design. Using adap-

tive object model may introduce certain performance

penalty. We will consider various means to improve

it in our future work.

REFERENCES

Anderson, F. and Johnson, R. (1998). Objectiva Architec-

ture. UIUC’98 MetaData Pattern Mining Workshop,

Urbana, IL.

Arsanjani, A. (1998). Meta-Modeling and Grammar-

oriented Object Design. OOPSLA 98 Workshop on

Metadata and Active Object Model.

Arsanjani, A. (2000). Rule object: A Pattern language

for Adaptive and Scalable Rusiness Rule Construction

(Part 1: Rule Object). Proceeding of PLoP 2000.

Arsanjani, A. (2001). using Grammar-oriented ob-

ject Design to Seamlessly Map Business Models to

Component-based Software Architectures. Proceed-

ing of the International Association of Science and

Technology for Development. Pittsburgh, PA, USA.

Balaguer, F. and Yoder, J. W. (2001). Adaptive

Object-Model Architecture. OOPSLA 2001 Adap-

tive Object-Model Tutorial. Available on the web at

http://www.adaptiveobjectmodel.com/.

Buschmann, F., Meunier, R., Rohnert, H., Sommerlad, P.,

and Stal, M. (1996). Pattern-Oriented Software Ar-

chitecture: A System of Patterns. John Wiley & Sons.

Devos, M. and Tilman, M. (1998). A repository-based

framework for evolutionary software development

(Argo Belgium School System). UIUC’98 MetaData

Pattern Mining Workshop.

Foote, B. and Yoder, J. W. (1998a). Metadata and Active

Object-Models. Fifth Conference on Patterns Lan-

guages of Programs (PLoP ’98) Monticello, Illinois.

Foote, B. and Yoder, J. W. (1998b). Metadata and Active

Object-Models. Workshop Position Paper; OOPSLA

’98.

Foote, B. and Yoder, J. W. (2001). Adaptive Object-Models.

Smalltalk Solutions 2001 AOM Workshop Presenta-

tion, Rosemont, IL, USA.

Forman, I. R. and Danforth, S. H. (1998). Putting Meta-

classes to Work: A New Dimension in Object-Oriented

Programming. Addison-Wesley.

Fowler, M. (1997). Analysis Pattern: Reusable Object Mod-

els. Addison-Wesley.

Fowler, M. (2002). Patterns of Enterprise Application Ar-

chitecture. OOPSLA 2002.

Gamma, E., Helm, R., Johnson, R., and Vlissides, J.

(1995). Design Patterns: Elements of Reusable

Object-Oriented Software. Addison-Wesley.

Johnson, R. (1997). Dynamic Object Model. OOPSLA ’97.

Johnson, R. and Oakes, J. (1998). User-Deﬁned Prod-

uct Framework. UIUC’98 MetaData Pattern Mining

Workshop.

Manolescu, D. and Johnson, R. (1999). Dynamic Object

Model and Adaptive Workﬂow. OOPSLA’99 Meta-

data and Active Object-Model Pattern Mining Work-

shop, Denver, Colorado.

Martin, R. C., Riehle, D., Buschmann, F., and Vlissides,

J. (1998). Pattern Languages of Program Design, 3.

Addison-Wesley.

Revault, N. and Yoder, J. W. (2001). Adaptive Object-

Models and Metamodeling Techniques. Workshop Re-

sults; ECOOP 2001 Budapest, Hungary.

Riehle, D. (1997). A Role-Based Design Pattern Catalog

of Atomic and Composite Patterns Structured by Pat-

tern Purpose. Ubilab Technical Report 97-1-1. Zurich,

Switzerlang: Union Bank of Switzerland.

Riehle, D. and et al., W. S. (1998). Serializer. Pattern lan-

guages of Program Design 3. Addison-Wesley, Chap-

ter17, pages 293–312.

Riehle, D., Tilman, M., and Johnson, R. (2000). Dynamic

Object Model. PLoP 2000.

Shaffer, C. A. (1997). A Practical Introduction to Data

Structures and Algorithm Analysis. Prentice Hall.

Sun Microsystems Inc. (2003). Core J2EE Pattern.

http://java.sun.com/blueprints/corej2eepatterns/.

Woolf, B. (1994). Understanding and Using

ValueModels. Available on the web at

http://www.ksccary.com/article6.htm.

Yoder, J. W., Balaguer, F., and Johnson, R. (2001a). Adap-

tive Object Models for Implementing Business Rules.

Position Paper for Third Workshop on Best-Practices

for Business Rules Design and Implementation, OOP-

SLA.

Yoder, J. W., Balaguer, F., and Johnson, R. (2001b). Ar-

chitecture and Design of Adaptive Object Models. In-

triguing Technology Presentation at the 2001 Confer-

ence on Object-Oriented Programming Systems, Lan-

guages, and Applications (OOPSLA ’01), ACM SIG-

PLAN Notices, ACM Press.

Yoder, J. W. and Johnson, R. (2002). The Adaptive Ob-

ject Model Architectural Style. The Proceeding of The

Working IEEE/IFIP Conference on Software Architec-

ture 2002 (WICSA3 ’02).

ICEIS 2004 - INFORMATION SYSTEMS ANALYSIS AND SPECIFICATION

302
