A SEMI-AUTOMATIC BAYESIAN ALGORITHM FOR

ONTOLOGY LEARNING

Francesco Colace, Massimo De Santo, Mario Vento

Dipartimento di Ingegneria dell’Informazione ed Ingegneria Elettrica, Università degli Studi di Salerno, Via Ponte Don

Melillo 1, 84084, Fisciano (Salerno), Italia

Pasquale Foggia

Dipartimento di Informatica e Sistemistica, Università di Napoli “Federico II”, Via Claudio, 21, 80125 Napoli, Italia

Keywords: Bayesian Networks, Ontology, E-Learning

Abstract: The dynamism of the new society forces the professional man to be abreast of technical progress. It is

essential to introduce new didactic methodologies based on continuous long-life learning. A good solution

can be E-learning. Although distance education environments are able to provide trainees and instructors

with cooperative learning atmosphere, where students can share their experiences and teachers guide them

in their learning, some problems must be still solved. One of the most important problem to solve is the

correct definition of the domain of knowledge (i.e. ontology) related to the various courses. Often teachers

are not able to easily formalize in correct way the reference ontology. On the other hand if we want realize

some intelligent tutoring system that can help students and teachers during the learning process starting

point is the ontology. In addition, the choice of best contents and information for students is closely connect

to the ontology. In this paper, we propose a method for learning ontologies used to model a domain in

the field of intelligent e-learning systems. This method is based on the use of the formalism of

Bayesian networks for representing ontologies, as well as on the use of a learning algorithm that

obtains the corresponding probabilistic model starting from the results of the evaluation tests

associated with the didactic contents under examination. Finally, we will present an experimental

evaluation of the method using data coming from real courses.

1 INTRODUCTION

On-line educational systems represent a rapidly

growing research field. Currently, one of the greatest

challenges in scientific research is the development

of advanced educational systems that are adaptable

and intelligent. Methodologies linked to knowledge

representation are among the key elements to

building intelligent and advanced training systems.

In fact, an ensemble of well-structured concepts is

able to significantly improve interoperability and

information sharing between systems. It can also be

efficiently used in intelligent system-supported

learning. In literature, such a set of concepts and

their relationships describing a knowledge domain is

called ontology (Gruber, 1993). It is clear that

defining ontologies means formalizing the ways of

organizing knowledge, monitoring its transfer

procedures and persistence over time, obviously

keeping in mind that knowledge mobility will

impose continuous changes to the formalized

structures. In such a context, ontologies are among

the most efficient tools for formalizing knowledge

that should then be shared by groups of people

(Studer, 1998). Furthermore, it is necessary to

identify which items belong to the domain under

examination, in order to establish their significance

and determine the way in which they relate to the

real needs of users. Ontologies have a consolidated

reputation as tools capable of satisfying these

requests (Swartout, 1997) and, therefore, lend

themselves very well for coordinating knowledge

organization and distribution in training courses in

191

Colace F., De Santo M., Vento M. and Foggia P. (2004).

A SEMI-AUTOMATIC BAYESIAN ALGORITHM FOR ONTOLOGY LEARNING.

In Proceedings of the Sixth International Conference on Enterprise Information Systems, pages 191-196

DOI: 10.5220/0002625201910196

 SciTePress

the field of e-learning. Another important and

typical aspect of on-line education systems, to which

ontologies may surely contribute, is the ability to

retrieve the most useful and suitable information to

be proposed to students, with the aim of adapting

training paths and module sequences to different

user needs. The ontology construction process,

based on the definition of a graph representing the

knowledge domain (the nodes represent the subjects

and the arcs represent the pedagogical links), is

neither trivial nor easy. Teachers who have to

describe the links among the subjects constituting a

course often provide a very detailed representation

giving birth to ontologies characterized by a large

number of states, which could not be easily

interpreted and used. A further problem, to which it

is difficult to give an unambiguous answer, is related

to the evaluation of the links among the different

states. As previously said, although direct

construction of ontologies is difficult, a source of

indirect evidence exists that can be profitably

employed for reconstructing “a posteriori” ontology

used during a course or a series of lessons: end-of-

course evaluation tests. Besides evaluating the

students’ comprehension of subjects, tests proposed

by teachers at the end of a course or a cycle of

lessons represent, considering both subject

sequencing and propaedeuticity, the ontology really

used within the course. The teacher planning the

end-of-course evaluation test not only assesses

students’ level of preparation for the most significant

subjects proposed during the lessons, but also tends

to describe the ontology outlining the propaedeutic

aspects that relate subjects to one another. It may be

useful to extract the ontology from these tests, and

then evaluate it and refine the propaedeutic

relationships among the subjects forming it through

the analysis of the answers given by students on

such tests. Bayesian networks represent a technique

useful for this purpose. Bayesian networks are

graph-based probability models where nodes are a

set of random variables X={X

i,....,

}and arcs

represent the causal dependences between variables.

In recent years, such networks have been more and

more often used for encoding knowledge domains

provided by experts with a grade of uncertainty

(Heckerman, 2000) and they have proved to be

particularly effective for solving data-modelling

problems (Conati, 1997). The aim of this paper is to

introduce a technique that allow a supervised

construction of ontology in order to allow a more

easy management of the contents, related to every

subject belonging to ontology, by teachers or

intelligent tutoring system. In this paper, we firstly

define ontologies and the advantages coming from

their use in knowledge-based systems. Secondly, we

discuss Bayesian networks and how they can easily

represent ontology. Finally, we present some results

obtained from using Bayesian networks for creating

an ontology starting from the answers given by

students on tests proposed to them.

2 ONTOLOGIES

Ontologies represent a vast topic that cannot be

easily defined, given the disagreements coming from

the several methods adopted to build and use them,

as well as from the different roles they may play. In

1991, Neches stated that an ontology defines the

basic terms and relations comprising the vocabulary

of a topic area, as well as the rules for combining

terms and relations to define extensions to the

vocabulary (Neches, 1991). Later on, Gruber, in the

context of knowledge sharing, used the term to refer

to an explicit specification of a conceptualization

(Gruber,1993). In the field of computer science,

ontology represents a tool useful to the learning

processes that are typical of artificial intelligence. In

fact, the use of ontologies is rapidly growing thanks

to the significant functions they are carrying out in

information systems, semantic web and knowledge-

based systems. The current attention to ontologies

paid by the AI community also arises from its recent

interest in content theories, an interest that is greater

than the one in mechanism theories. In this regard,

Chandrasekaran makes a clear distinction between

these theories by asserting that, though mechanisms

are important since they are proposed as the secret of

making intelligent machines, they cannot do much

without a good content theory of the domain on

which they have to work. Besides, once a good

content theory is available, many different

mechanisms can be used to implement effective

systems, all using essentially the same content.

Following this point of view, ontologies are content

theories, since their principal contribution consists in

identifying specific classes of objects and relations

existing in some knowledge domains

(Chandrasekaran99). Ontological analysis, therefore,

clarifies knowledge structures: given a domain, its

ontology represents the heart of any knowledge

representation system for that domain. Another

reason for creating and developing ontology is the

possibility of sharing and reusing knowledge domain

among people or software agents. It is clear that

ontologies are important because they explicate all

the possible relations among the concepts belonging

to a domain. Once these relations are explained, it

will be possible to easily modify them, if our

knowledge about that domain changes. These

explicit specifications provided by ontologies can

also help new users to understand what specific

ICEIS 2004 - ARTIFICIAL INTELLIGENCE AND DECISION SUPPORT SYSTEMS

192

terms in a domain mean (Uschold, 1992).

Furthermore, by offering a unifying structure,

ontologies are able to reduce terminological and

conceptual ambiguity.

3 BAYESIAN NETWORKS

Bayesian networks have been successfully used to

model knowledge under conditions of uncertainty

within expert systems, and methods have been

developed from data combination and expert system

knowledge in order to learn them (Conati,

1997)(Heckerman,1997)(DeCampos,2000). The

learning process through Bayesian networks has two

important advantages: it is easy to encode

knowledge of an expert in a Bayesian network, and

such knowledge can be used to improve learning

efficiency and accuracy and nodes and arcs of the

learnt Bayesian network often correspond to

recognizable links and causal relationships.

Consequently, it is possible to comprehend and to

exploit more easily the knowledge encoded in the

representation. A Bayesian network is a graph-based

model encoding the joint probability distribution of a

set of random variables X={X

i,....,

}. It consists of

a directed acyclic graph S (called structure) where

each node is associated with one random variable

and each arc represents the conditional

dependence among the nodes that it joints and a

set P of local probability distributions, each of

which is associated with a random variable X

and

conditioned by the variables corresponding to the

source nodes of the arcs entering the node with

which X

is associated. The lack of an arc between

two nodes implies conditional independence. On

the contrary, the presence of an arc drawn from

the node X

to the node X

represents the fact that

is considered a direct cause of X

. Given a

structure S and the local probability distributions

of each node p(X

|Pa

) where Pa

represents the set

of parent nodes of X

, the joint probability

distribution p(X) is obtained from:

(

)(|

)

xpXPa

∏

and it is evident that the couple (S, P) encodes p(X)

unequivocally (Jensen, 1998). In order to construct a

Bayesian network for a given set of variables, it is

necessary to define some arcs from the causal state

to the states that represent their direct effects

obtaining a network that accurately describes the

conditional independence relations among the

variables. Causal semantics of the Bayesian

networks has much responsibility for determining

their success as knowledge representations in expert

systems. Once the network is constructed (through a

priori knowledge, or data or a combination of both

of them), it is necessary to determine the various

probabilities of interest from the model. Such

probabilities are not directly stored in the model, it is

therefore necessary to calculate them. In general,

given a model, the calculation of a probability of

interest is known as probabilistic inference

(Jensen, 1998).

4 OUR PROPOSAL AND

OBTAINED RESULTS

This proposal aims to present a technique able to

semi-automatically infer propaedeutic relationships

among the different subjects forming a university

course. In other words, we intend to define the

ontology on which the teacher founds his/her

lessons. As previously said, the teacher can have

considerable difficulties in delineating relationships

among the subjects and their propaedeutic

connections. A source of indirect evidence that can

be employed for reconstructing a posteriori an

ontology used during a course, as well as the

propaedeutic connection among the single subjects,

is represented by the end-of-course evaluation tests.

The teacher planning the end-of-course evaluation

tests not only assesses students’ level of preparation

for the most significant subjects proposed during the

lessons, but also tends to describe the ontology on

which his/her course was based outlining the

propaedeutic aspects that relate subjects to one

another. It may be useful to extract the ontology

from these tests, and then evaluate it and refine the

propaedeutic relationships among the subjects

forming it through the analysis of the answers given

by students on such tests. In fact, supposing that

questions on subjects A and B are posed, and A is

considered by the teacher to be a propaedeutic

subject to the comprehension of B, it is clear that, in

case such a propaedeutic constraint is real, the

probability that the student will provide wrong

answers to questions relating to B is high if the

student gives wrong answers to questions associated

with A. On the basis of these considerations,

teachers has planned the final test of the first-level

course on Computer Science at the Electronical

Engineering Faculty of the University of Salerno and

the final test of the first-level course on Introduction

to Computer Science at the Language Faculty of the

University of Salerno. These courses provide first-

year students with the foundations of computer

science in the first case and introduces to Computer

A SEMI-AUTOMATIC BAYESIAN ALGORITHM FOR ONTOLOGY LEARNING

193

Science in the second case. At the courses beginning

teachers delineated the subjects forming the courses

and, then, provide a hypothesis relating to the

strength of their relationships. In the case of the

second ontology the teacher divided it in two sub-

ontology: hardware and software. The result of this

process is shown in figure 1 (see appendix). On the

basis of the presented ontology, some

questionnaires, composed by multiple choice

questions, to be filled in by students have been

realized. The previously described graph represents

the ontologies, but can also be used as a Bayesian

network for the inference process. Each node of the

networks has two states ‘Yes’ for complete

knowledge of the subject or ‘Not’ for total ignorance

on the subject and represents the probability that a

generic learner knows the subject associated with the

same node. The student’s level of knowledge is

evaluated on the basis of the answers given to the

questions. The presence of missing values, in other

words the state of some variable can not be

observable, has not been foreseen. This hypothesis

can be obtained imposing that the student must

answer to all the questions and thinking wrong a

missing answer. Through a Bayesian inference

conducted on the previously described networks

using a Bayesian inference tool designed and

implemented by us, the candidate ontologies

networks have learned from data. The inference

algorithm used in our tool is the one called

“junction-tree” introduced by Finn V. Jensen in

(Jensen, 1998). For the inferential process we have

used data coming from about five hundred

questionnaires for the first ontology and three

hundred questionnaires for the second and third

ones. At this point we have to estimate the strength

of propaedeutic relationship between two arguments

after the learning of the network. The presence, in

fact, of an arc between two nodes in the bayesian

nets can be interpreted like a causality relationship

between the variables associated to the same nodes

so it is important to define a function that is able to

evaluate this strength. For the nodes that belong to a

bayesian network a good dependence indicator is the

cross-entropy function and so defined:

∑

bPaP

baP

baPBAEC

)()(

),(

log),(),.(.

where A and B are nodes of the bayesian network

and a and b are the states of each node. So according

to cross entropy definition we can say that A and B

are independent if and only if C.E.(A, B) is equal to

0. However often we have not the real probability

distribution of the full network but only an

empirical evaluation of it coming from data analysis.

So it is incorrect to consider as condition of

independence C.E.(A,B) = 0 and we can suppose A

independent from B when C.E.(A,B)<e, where e>0

is an arbitrary threshold near to zero. The cross

entropy function can also quantify the dependency

weight between the nodes. In fact an high value of

C.E.(A,B) means a very high preparatory link

between the two nodes. In order to suppose that at

least the father-child nodes sorting proposed by the

teacher is correct we have submitted the data coming

from the questionnaires to statistical tests, typical of

bayesian network structural learning algorithms, that

are able to establish from them the correct father-

child nodes arrangement. This tests results have

confirmed in the case of the under experimentation

ontologies that the arrangement proposed by

teachers is correct. So at this point we have set in

input to the bayesian network the data coming from

the questionnaires in order to obtain the probability

values associated to the various states of the nodes.

With these values we calculated the cross entropy

values among all the single states of the net.

Particularly the cross entropy has been calculated

both for the arcs proposed by the teacher and for

those among brother nodes not signalled. Figure 2,

in the appendix, shows the obtained results. On the

left side of every figure we can see the cross entropy

values for the correct arcs, that represent

propaedeutical connection between two topics,

while on the rigth side (after the blank column) we

can see the cross entropy values for the incorrect

arcs. In general we can say the teacher’s expected

arcs have a greater cross entropy values than other

arcs confirming the teacher ontology design. In the

case of ontology #1 we have an arc P(8|6) having a

cross entropy value in the range of correct arcs. This

is not a surprise: in fact in the ontology designing

phase teacher had some doubts about this arc. In fact

he believed that preparatory links between the nodes

8 and 6 exist but with a low cross entropy value.

Instead data show a substantial cross entropy value

between these nodes and teacher, according this

model, have to refine his ontology proposal.

5 CONCLUSION

In this paper, we have presented a method for

learning in a semi-automatical way ontologies

representing the didactic contents of an Intelligent

Tutoring System and the propaedeutic

relationships existing among these contents. In

particular, our approach to the problem is based

on the use of Bayesian networks. Thanks to their

characteristics, these networks can be used to

model and evaluate the conditional dependencies

ICEIS 2004 - ARTIFICIAL INTELLIGENCE AND DECISION SUPPORT SYSTEMS

194

among the nodes of ontology on the basis of the

data obtained from student tests. An experimental

evaluation of the proposed method has been

performed using real student data. The

experimentation has demonstrated that the

relationships inferred by the system are very

similar to the ones that a human expert would

have defined, thus confirming the effectiveness of

the proposed method. In the future, we aim to

integrate the proposed method into a distance

learning platform, in order to exploit the inferred

ontologies for an adaptive selection of contents. In

particular, we intend to use the system to help the

teacher in the representation of course reference

ontology and in the formulation of tests that

provide a better coverage of the course contents,

as well as for define per student tests that are

automatically adapted to the student training

objectives and to his/her level of preparation. This

technique can also be applied to the presentation

of training contents, thus providing the system

with the ability to choose, on the basis of

periodical feedback tests, the contents that are

most appropriate for each student.

REFERENCES

Gruber T. R., 1993. A translation Approach to Portable

Ontology Specifications. In Knowledge Acquisition,

5(2): 199-220

Neches R., Fikes R. E., Finin T., Gruber T. R., Senator

T., Swartout W. R., 1991. Enabling Technology for

Knowledge Sharing. In AI Magazine, 12(3):36-56

Chandrasekaran B., Josephson J. R., Benjamins R.,

1999. What are ontologies, and why do we need

them?. In IEEE Intelligent Systems, Volume: 14

Uschold M., Gruninger M., 1992. Ontologies:

Principles, Methods and Applications. In

Knowledge Engineering Review, volume 11,

number 2

Heckerman, Geiger, Chickering, 2000. Learning

Bayesian Networks: The combination of knowledge

and statistical data. In Machine Learning, vol.4

Conati, Gertner, VanLehn, Drudzel, 1997. On-Line

Student Modeling for Coached Problem Solving

Using Bayesian Networks. In User Modeling:

proceedings of the sixth international conference,

UM97

Jensen, F., 1998. An Introduction to Bayesian

Networks. Springer – Verlag, New York.

Heckerman, 1997. Bayesian Networks for Data Mining.

In Data Mining and Knowledge Discovery 1

Luis M. de Campos, Juan M. Fernández-Luna, Juan F.

Huete, 2000. Building Bayesian Network-Based

Information Retrieval Systems. In proceedings of

DEXA Workshop 2000

Studer R., Benjamins V. R., Fensel D., 1998.

Knowledge Engineering: Principles and Methods.

In DKE 25(1-2)

Swartout B., Patil R., Knight K. and Russ T., 1997.

Towards Distributed Use of Large-Scale

Ontologies. In Spring Symposium Series on

Ontological Engineering. Stanford University, CA

A SEMI-AUTOMATIC BAYESIAN ALGORITHM FOR ONTOLOGY LEARNING

195

APPENDIX

Ontology #2

Ontology #1

Ontology #3

Figure 1: Proposed ontology for the first-level course on Computer Science (Ontology #1) and Introduction to

Computer Science (Ontology #2 and Ontology #3)

Ontology #1

Ontology #2

Ontology #3

Figure 2: Obtained Results on reference set ontologies

ICEIS 2004 - ARTIFICIAL INTELLIGENCE AND DECISION SUPPORT SYSTEMS

196
