SEMI-STRUCTURED INFORMATION WAREHOUSES

Requirements and Definition

Juan Manuel Pérez, Rafael Berlanga and María José Aramburu

Jaume I University, Castellón, Spain

Keywords: XML applications, semi-structured data analysis, document warehouses.

Abstract: During the last decade, data warehouse and OLAP techniques have helped companies to gather, organize

and an

alyze the structured data they produce. Simultaneously, digital libraries have applied Information

Retrieval mechanisms to query their repositories of unstructured documents. In this context, the emergence

of XML means the convergence of these two approaches, making possible the development of warehouses

for semi-structured information. Although there exist several extensions of traditional data warehouse

technology to manage semi-structured information, none of them are based on an underlying document

model able to exploit this kind of information. Along this paper we expose our vision of what a semi-

structured information warehouse should be, by identifying a set of requirements throughout an example

scenario.

1 INTRODUCTION

During the last decade, data warehouse (Kimball,

2002) and OLAP (Codd et al, 1993) techniques have

helped companies to gather, organize and analyze

their structured data (usually stored in their own

enterprise’s databases) to support decisions at

various levels. These organizations also produce

huge amounts of unstructured documents such as

emails, spread sheets or word processing documents.

At the same time, the Web has become the largest

source of companies external information.

Unfortunately, although all these documents contain

highly valuable information, current data warehouse

technology cannot be applied to them.

The ever increasing amount of information

blished on the Internet has provided us with new

services like digital libraries. All these applications

require of novel techniques to store and manage

huge amounts of unstructured information. Most

solutions to query these repositories are based on

Information Retrieval (IR) (Baeza-Yates and

Ribeiro-Neto, 1999) techniques. More recently, the

efforts are focused on the definition of architectures

for the integration of distributed and heterogeneous

documents sources.

From our point of view, XML is a means of

conve

rgence for the warehouse and document

retrieval research areas, and opens a novel and

interesting range of possibilities to exploit semi-

structured information.

The acceptance of XML as the standard for

sem

i-structured data exchange over the Web, points

out to a close future when information on the

Internet will be published as XML documents, and

exportation tools from most proprietary systems to

XML-like formats will be available. Furthermore,

the current demand of new architectures for the

integration of distributed information, together with

the already proven qualities of the data warehouse

and OLAP techniques for the analysis and

exploitation of large data repositories, make very

attractive the idea of extending data warehouses with

more flexible data models, able to incorporate XML

documents: semi-structured information

warehouses.

In the recent literature some proposals start

alyzing the problem of extending current data

warehouse technology to manage semi-structured

information. Section 2 presents some works done in

the field of semi-structured data models and XML

warehouses. However, to date none of these

approaches entirely exploit all the properties of these

documents. At this work we present our particular

interpretation of what a warehouse for semi-

structured information should be. In Section 3 we

present an example scenario for the development of

semi-structured information warehouses and identify

a set of new requirements for this novel technology.

Finally, we expose conclusions and future research

at Section 4.

579

Manuel Pérez J., Berlanga R. and José Aramburu M. (2004).

SEMI-STRUCTURED INFORMATION WAREHOUSES - Requirements and Deﬁnition.

In Proceedings of the Sixth International Conference on Enterprise Information Systems, pages 579-582

DOI: 10.5220/0002633705790582

 SciTePress

2 RELATED WORK

Several models have been proposed to store and

retrieve XML documents, like (Navarro and Baeza-

Yates, 1997) and (Xyleme, 2001). These approaches

combine IR techniques with mechanisms for the

evaluation of conditions over the structure of the

documents. In the same line, TOODOR (Aramburu

and Berlanga, 2001) is a storage and retrieval model

for structured documents which additionally

considers their temporal dimensions.

More recently, in the scope of data warehouses,

some works which start managing semi-structured

information have been presented. They can be

classified as follows.

A first group of works (Binh et al, 2001)

(Mangisengi et al, 2001) are oriented towards the

integration of data warehouses. These systems use

XML languages to represent metadata over the data

sources, or as canonical languages when transferring

data between their components.

A second group of works (Xyleme, 2001)

(Ishikawa et al, 1999) are focused on the definition

of architectures for document or semi-structured

data warehouses. Although, these proposals specify

techniques for the collection and massive storage of

semi-structured data, they do not include any high

level analysis tools able to exploit this information.

Finally, a quite different approach is (Pedersen et

al, 2002). There, a new query language based on

SQL and XPath allows the execution of OLAP

operations that involve data contained in external

XML documents. In this case, the semantics of

aggregation operations is meticulously revised, but

the highly structured philosophy of the traditional

data warehouses remains in the model. That is,

OLAP operations include data coming from semi-

structured documents, but this information is

managed as structured data once inside the

warehouse.

Summarizing, there exist different proposals to

enrich current data warehouse technology with XML

information. However, in our opinion, to date none

of these systems is able to entirely exploit the semi-

structured nature of these kind of documents. In next

section we expose our interpretation of semi-

structured information warehouses, by pointing out a

set of requirements throughout an example scenario.

3 AN EXAMPLE SCENARIO

In this section an example scenario and a set of

analysis queries is used to explain the special

requirements of a warehouse for semi-structured

information. The language used at the example

queries is an extension of TDRL (Aramburu and

Berlanga, 2001) with XPath expressions and the

OLAP operators of SQL-99.

We will consider that our warehouse stores a

collection of XML digital news extracted from

various Internet sources. Figure 1 presents a

document of this repository with a news item about

the disasters caused by a storm. The objective of our

analysis is to study the weather conditions that

caused the natural disasters described at the relevant

documents.

Traditional data warehouses operate over a set of

highly structured facts. These tuples contain

attributes with the measures of study and the

dimensions to analyze. However, in a warehouse for

semi-structured information the facts are not so

highly structured as they take part of the textual

contents of XML documents. Thus, traditional data

warehouse techniques cannot be directly applied to

them.

Figure 1: A piece of a document of the warehouse.

As shown in Figure 1, the labels

LOCATION,

DATE, RAINFALL and TEMPERATURE contain values

that can be considered as either measures of

analysis, or values of the corresponding dimensions.

<NEWSPAPER NAME=”El País” PUBLICATION_DATE=”Tuesday, 2nd July 2002”> ...

<LOCAL_SECTION>

<NEWS_ITEM> <AUTHOR>Carlos García</AUTHOR>

<TITLE>

<LOCATION XW:VALUE=”/Europe/Spain/Valencia”>Valencia</LOCATION> suffers the biggest storm of July of the last

41 years

</TITLE>

Two bathers die drowned at the beaches of <LOCATION XW:VALUE=”/Europe/Spain/Menorca”>Menorca</LOCATION> and

<LOCATION XW:VALUE=”/Europe/Spain/Formentera”>Formentera</LOCATION>

</SUBTITLE>

The biggest storm of July of the last 41 years fell<DATE XW:VALUE=”/2002/07/01”>yesterday</DATE> night over

the city of <LOCATION XW:VALUE=”/Europe/Spain/Valencia/Valencia”> Valencia</LOCATION>. The

<RAINFALL XW:VALUE=”128” XW:UNIT=”l/m2”>128 liters per square meter</RAINFALL> rained in only 24 hours made

firemen had to go on rescue more than 100 times. At <LOCATION XW:VALUE=”/Europe/Spain/Valencia/Burjassot”>

Burjassot</LOCATION> fell <RAINFALL XW:VALUE=”132” XW:UNIT=”l/m2”> 132 liters per square meter</RAINFALL>

throwing down a building. The strong rain on the East of Iberian Peninsula caused disasters in the regions of

<LOCATION XV:VALUE=”/Europe/Spain/Murcia”>Murcia</LOCATION> and <LOCATION XW:VALUE=”/Europe/Spain/Baleares”>

Baleares</LOCATION>.

</PARAGRAPH> ...

</NEWS_ITEM> ...

</LOCAL_SECTION> ...

ICEIS 2004 - DATABASES AND INFORMATION SYSTEMS INTEGRATION

580

These labels could appear in the original documents

or, alternatively, they can be inserted by applying

information extraction or shallow parsing

techniques.

3.1 Documents structure and

conceptual analysis schema

As XML documents are self-describing, part of the

conceptual analysis schema (dimensions and

measure values) is implicitly represented in their

own structure (or in their associated XML Schemas).

Notice how the elements in bold of the example

document of Figure 1 can be used as a dimension or

as a measure. In this way, when managing semi-

structured information, path expressions are a

natural way of specifying the dimensions and

measures involved in analysis queries. Thus, it could

be possible to design warehouse architectures where

the analysis schema would only define the

dimension hierarchies, and where the measures and

dimensions to study could be directly specified in

the analysis queries.

The example query below shows how XPath

expressions can be used to indicate the dimension

and measures under analysis:

SELECT Avg(Paragraph/Rainfall)

FROM //Local_Section//News_Item

GROUP BY CUBE (Paragraph/Location)

3.2 Fact relevance

The previous query computes the average of the

values of the measure

Rainfall for the dimension

value

Location, that is, it returns the average of the

amount of water collected per location. The facts

considered by this query are those contained in the

paragraphs of the news items stored in the

warehouse. Notice that in the document of Figure 1

there exist paragraphs which describe more than one

fact. Conversely, there could also occur different

paragraphs of the same news item describing the

same

Rainfall-Location fact. The reason for

these repetitions is the high relevance of the fact

with respect to the news main subject.

Like in IR systems, where query results are

ranked with a relevance index, a measure of fact

relevance must be introduced in semi-structured

information warehouse models. In this way, the most

relevant facts of news items could receive more

consideration in the evaluation process than the

other less relevant facts. Notice that the levels of a

dimension hierarchy will affect to the relevance of

the facts for a given news item. For example,

considering the levels of the

Location dimension,

facts that are different at lower levels of the

hierarchy could became the same fact at higher

levels.

It is concluded that the semantics of the

aggregation operations in semi-structured

information warehouses must be carefully revised,

not only to manage the facts relevance, but also to

consider those facts that appear without some of

their measures or dimensions.

3.3 The structure as an implicit

dimension

In this section we explain how the document

structure can be considered as an implicit dimension

when analyzing semi-structured information. For

example, next query builds a cube for the average of

temperature values but without selecting any

dimension.

SELECT Avg(//Temperature)

FROM //Local_section//News_Item

GROUP BY CUBE

Like in the example of Figure 1, each

News_Item element in the warehouse describes a

set of facts. Thus, this query would return a

temperature average for each news item of the

Local_section elements stored in the warehouse.

By going up a level in the document structure

hierarchy we would obtain the same measure for

each local section. This process could be repeated

several times until considering complete documents.

Consequently, by using the structure of

documents as an implicit dimension, it is possible to

construct OLAP cubes to analyze the facts at

different levels of detail. Notice that the elements at

higher levels of the structure use to group more

occurrences of the same fact, implying that the

relevance of the facts is also affected by the structure

dimension.

3.4 OLAP queries with IR conditions

In order to complete our analysis of the general

requirements of a warehouse for semi-structured

information, in this section we explain the

importance of specifying IR conditions in OLAP

queries. Notice that although our objective is to

study the weather conditions that caused the natural

disasters, previous example queries involved all the

news items stored in the warehouse.

The next query shows how to restrict our

analysis to those news items that in their title contain

SEMI-STRUCTURED INFORMATION WAREHOUSES: Requirements and Definition

581

the term “storm” with a relevance index greater than

50%. When evaluating an aggregation, the degree of

contribution of the facts described in a news item

must be proportional to the relevance of this news

item for the studied topic.

SELECT Avg(Paragraph/Rainfall)

FROM //Local_Section//News_Item

WHERE Title contains ‘storm’ > 0.5

GROUP BY CUBE (Paragraph/Location)

3.5 IR terms as a dimension

Finally, next query shows how the terms specified at

IR expressions can be used as an additional analysis

dimension. In this context, thesaurus and ontologies

would allow defining classification hierarchies over

this new dimension. In this way, the query below

provides a new dimension to study the aggregation

of those news that contain the term “tidal wave”, or

the aggregation for the term “flood”. Note that these

two aggregations can be joined at higher levels of

the term hierarchy (e.g. “natural disaster”).

SELECT Avg(Paragraph/Rainfall)

FROM //Local_Section//News_Item

WHERE Title contains

‘tidal wave| flood’ > 0.5

GROUP BY CUBE

(‘tidal wave| flood’,

Paragraph/Location)

4 CONCLUSIONS

In this paper we have explained how the data

warehouses and digital libraries communities, each

from its particular point of view (structured vs.

unstructured information, respectively), can

mutually take advantage from semi-structured

information. Recently, some proposals start

extending the traditional data warehouse technology

towards semi-structured information. However, to

date none of these approaches entirely exploit all the

properties of these documents. Along this work we

have identified a set of requirements for this novel

technology, the semi-structured information

warehouses technology.

In our opinion, the development of such systems

must be based on an underlying document model

able to exploit the nature of this kind of information.

We are currently working on a semi-structured

model which combines IR and evaluation of

structural conditions techniques to query an XML

documents collection, and where the facts described

at the selected documents are ranked by relevance.

For the future, we plan to design a semi-

structured warehouse model built over this

document model. In order to involve the facts

relevance in the warehouse model, the semantics of

the aggregation operations will have to be revised. In

this context, we find interesting some works which

study the management of imprecise information

(Pedersen et al, 1999) (Rundensteiner et al, 1992).

REFERENCES

Kimball, R., 2002. The Data Warehouse toolkit. John

Wiley & Sons.

Codd, E. F.; Codd, S. B. and Salley, C.T., 1993. Providing

OLAP to user-analysts: An IT mandate. Technical

Report, E.F. Codd & Associates.

Baeza-Yates, R. and Ribeiro-Neto, B., 1999. Modern

Information Retrieval. Addison-Wesley.

Navarro, G. and Baeza-Yates, R., 1997. Proximal Nodes:

A Model to Query Document Databases by Contents

and Structure. ACM Trans. on Information Systems.

Xyleme, L., 2001. A dynamic warehouse for XML data of

the Web. IEEE Data Engineering Bulletin 24(2).

Aramburu, M. J. and Berlanga, R., 2001. A Temporal

Object-Oriented Model for Digital Libraries of

Documents. Concurrency: Practice and Experience 13

(11), John Wiley.

Binh, N. T.; Tjoa, A. M. and Mangisengi, O., 2001. Meta

Cube-X: An XML Metadata Foundation for

Interoperability Search among Web Warehouses.

Proc. Intl. Workshop on Design and Management of

Data Warehouses.

Mangisengi, O.; Huber, J.; Hawel, C. and Essmayr, W.,

2001. A Framework for Supporting Interoperability of

Data Warehouse Islands Using XML. Proc. of the 3rd

Intl. Conference on Data Warehousing and

Knowledge Discovery. LNCS 2114.

Ishikawa, H. et al, 1999. Document Warehousing Based

on a Multimedia Database System. Proc. IEEE 15th

Intl. Conference on Data Engineering, pp. 168-173.

Pedersen, D.; Riis, K. and Pedersen, T. B., 2002. XML-

Extended OLAP Querying. Technical Report,

Department of Conputer Science, Aalborg University.

Pedersen, T. B.; Jensen, C. S. and Dyreson, C. E., 1999.

Supporting Imprecision in Multidimensional

Databases Using Granularities. Proc. of the Eleventh

International Conference on Scientific and Statistical

Database Management, pp. 90–101.

Rundensteiner, E. and Bic., L., 1992 Evaluating

Aggregates in Possibilistic Relational Databases.

DKE, 7(3):239–267.

ICEIS 2004 - DATABASES AND INFORMATION SYSTEMS INTEGRATION

582
