EXPLICIT CONCEPTUALIZATIONS FOR KNOWLEDGE

MAPPING

Willem-Olaf Huijsen

Telematica Instituut, P.O. Box 589, NL-7500 AN, Enschede, The Netherlands

Samuël J. Driessen

Océ Technologies, P.O. Box 101, NL-5900 MA, Venlo, The Netherlands

Jan W.M. Jacobs

Océ Technologies, P.O. Box 101, NL-5900 MA, Venlo, The Netherlands

Keywords: information classification, con

ceptualizations, knowledge mapping, ontologies, semantic networks, thesauri.

Abstract: Knowledge mapping supports members of an organization in finding knowledge available within the

organization, and in developing insights into corporate expertise. An essential prerequisite is an explicit

conceptualization of the subject domain to enable the classification of knowledge resources. Many tools

exist to create explicit conceptualizations. This paper establishes a set of requirements for conceptualization

tools from the perspective of knowledge mapping. Next, a number of tools are reviewed – thesauri,

ontologies, and semantic networks – using the following criteria: the complexity, the effort required, and the

degree to which it is possible to integrate it into the overall knowledge mapping system.

1 INTRODUCTION

Knowledge mapping is about making the knowledge

that is available within an organization transparent,

and is about providing insights into its qualities.

Generally, when employees look for knowledge,

they draw from three sources: other employees,

documents of various types, and information

systems. First, other employees typically include

close colleagues and other colleagues one knows to

have relevant expertise. The search is typically

limited to only a few people. Still, there may be

others with high-quality knowledge one misses

because one does not know them or does not know

all of the expertise one’s colleagues have. Second,

documents often come in large numbers, and with a

poor structure to them, making a quick and effective

search very difficult. Third, information systems

tend to be numerous too, and each system has a

different interface and internal structure, so that

finding knowledge and piecing together information

from across a number of systems is a lot to ask. The

distributed nature of organizational knowledge

makes it very hard to get a clear, complete overview,

and to draw conclusions.

Knowledge-mapping systems (KMSs) provide

pport for addressing these issues, collecting data

on the corporate knowledge from various

information systems.

The knowledge-mapping process can be said to

nsist of the following steps. First, raw data is

acquired from one or more sources. This typically

involves some basic processing such as filtering or

keyword extraction. The resulting first-order data is

stored in the knowledge-mapping database

(KMDB). In order to obtain more meaningful

information, it may be further analyzed, aggregated,

and contextualized, resulting in higher-order data.

By visualizing the first-order and higher-order data

in specific ways, and taking into account user

preferences, knowledge maps can be produced that

provide insights into corporate knowledge.

2 CONCEPTUALIZATIONS

To talk about a domain of knowledge, one needs a

way to label pieces of knowledge and the

relationships between them. This is done by using

conceptualizations. To establish a common frame of

reference, we review some basic notions. A concept

can be defined as any unit of thought, any idea that

forms in our mind [Gertner, 1978]. Often, nouns are

used to refer to concepts [Roche 2002]. Relations

231

Huijsen W., J. Driessen S. and W.M. Jacobs J. (2004).

EXPLICIT CONCEPTUALIZATIONS FOR KNOWLEDGE MAPPING.

In Proceedings of the Sixth International Conference on Enterprise Information Systems, pages 231-236

DOI: 10.5220/0002634202310236

 SciTePress

form a special class of concepts [Sowa, 1984]: they

describe connections between other concepts.

Modifiers (or attributes) may be attached to concepts

and relations to restrict or clarify their scope. One of

the most important relations between concepts is the

hierarchical relation (subsumption), in which one

concept (superconcept) is more general than another

concept (subconcept). Instances are concrete objects

that may be examples of the more abstract concepts.

A conceptualization is “the objects, concepts, and

other entities that are assumed to exist in some area

of interest and the relationships that hold among

them” [Genesereth & Nilsson, 1987]. A

conceptualization can be divided into a conceptual

model and an instance model. The conceptual model

includes all concepts of interest and the relations

between them. The instance model includes all

instances of interest and the relations that link these

instances to each other and to the concepts.

The conceptual model states that the individuals of

interest to the organization are its employees and the

external contacts. In terms of the knowledge-

mapping process the instance model data is derived

from the external information systems such as

document management systems and organizational

databases. This data is stored in the KMDB. The

conceptual model typically is not available in any

information system, and must be developed as part

of the KMS. The KMDB invariably requires a large

number of specific relations corresponding to the

information presented by the various knowledge

maps. Since a thesaurus can only accommodate 3–5

relations, it is not an option to integrate the KMDB

and the thesaurus (Fig. 1a). However, in the case of

ontologies and semantic networks, any number of

specific relations can be incorporated.

3 CRITERIA

A knowledge-mapping tool uses the conceptualiza-

tion in several situations: the indexing of knowledge

sources, concept naming for user interaction,

browsing the concept space, and relevance ranking.

Indexing determines for a given knowledge source

which concepts it is concerned with. Essentially,

indexing consists of examining the document and

establishing its subject content; identifying the

principle concepts present in the subject; and

expressing these concepts in the indexing language

[ISO 1985]. Therefore, indexing requires the

conceptualization to include, for each concept of

interest, all terms that describe it: synonyms and

spelling variants. If a term is ambiguous, then

hyperonyms and hyponyms, and other related

concepts may be used for disambiguation.

The conceptualization is also used to name relevant

concepts for communication with the user. The

following must be addressed: technical terms may

have any number of synonyms and spelling variants,

and they may be ambiguous. Generally, this is dealt

with by selecting, for every concept, from the set of

synonyms and spelling variants, a single,

unambiguous term as the preferred term, while the

others are the non-preferred terms. This also ensures

consistent naming.

An important feature of a knowledge-mapping tool

is browsing the system’s conceptual space. This

means that the system must contain descriptions of

the relations between the concepts. The number of

relations depends in part on the application’s

requirements and on the number of instances of the

relations. We find that the minimum is two: the

subsumption relation and the association relation.

The intended application may require certain

distinctions between types of relations. A practical

consideration is that if there are too few relation

types, then a concept may have very many relation

instances with the same name. Then it may be too

difficult to find the information one is looking for.

Given a query, a knowledge-mapping tool will try

and find relevant knowledge items. In presenting the

knowledge items, the results are ranked according to

their relevance to the query. A knowledge item may

also refer to the concept in question using synonyms

Conceptual

model

(= thesaurus)

Instance

model

(= KMDB)

Conceptual

model

instance

model

Conceptualization

(Thesaurus Type)

Conceptualization

(Ontology/

Semantic network

Type)

(a)

Aircraft

Passenger

Aircraft

Military

Aircraft

Freight

Aircraft

Civil

Aircraft

Payload User type

Passenger

Aircraft

Military

Aircraft

Freight

Aircraft

Civil

Aircraft

(b)

Figure 1: (a) Two conceptualization types, (b) Facets

ICEIS 2004 - INFORMATION SYSTEMS ANALYSIS AND SPECIFICATION

232

and other related terms. Thus, relevance ranking can

also benefit from knowledge about relations between

terms.

Conceptualizations consist of a set of concepts on

the one hand and a set of relations between those

concepts on the other. From the perspective of the

above-mentioned applications, we observe that

having terms for the set of concepts is sufficient for

indexing and concept naming. In addition,

information on the relations can improve the

indexing process. However, for concept browsing,

both the set of concepts and the relations between

them is necessary. Thus, a term set provides a

minimal basis for knowledge mapping, but

additional information on the relations between

concepts is necessary for concept browsing.

We now summarize the requirements on a

knowledge classification system. First, it must

include, for every concept, all terms that describe the

concept: synonyms and spelling variants, and related

concepts (hyperonyms, hyponyms, etc.). Second, it

must include a set of different relation types. At least

subsumption and association are required. More

relations are needed if the application requires so, or

if the number of relation instances with the same

name becomes impractical.

4 TOOLS

For knowledge mapping we consider the following

three conceptualization types: thesauri, ontologies,

and semantic networks. Other, simpler structures

such as keyword lists and taxonomies are not taken

into account as they fail to meet basic requirements.

After reviewing these tools, section 5 evaluates them

with respect to the criteria established above.

4.1 Thesauri

Thesauri are classification systems that combine a

set of technical terms with a few basic relations. Our

discussion is inspired by the ISO and ANSI/NISO

standards [ISO 1986, NISO 1993, cf. Wielenga

2001]. The latter defines a thesaurus as “a controlled

vocabulary arranged in a known order and structured

so that equivalence, homographic, hierarchical, and

associative relations among terms are displayed

clearly and identified by standardized relationship

indicators that are employed reciprocally”.

Thesauri divide the technical terms into sets of

synonyms. From each set, one preferred term is

chosen to represent the underlying concept; the

others are non-preferred terms. The included

relation types are synonymy, subsumption, and

association.

A clear advantage of thesauri is their simplicity,

which allows for an easier implementation. The

downside is that since only three basic relations are

distinguished one may feel that many different

relations get mixed up.

Of course, depending on one’s application, one may

vary the number and nature of the basic relations

used in the thesaurus. As the hierarchical relation is

the primary structuring principle, we focus on two

variations that improve the clarity of the hierarchy.

An important and generally applicable variation

explicitly distinguishes different types of

hierarchical relations: the generic relation, the

whole-part relation, and the instance relation. With

only one hierarchical relation, in browsing concepts,

these different types of subordinate concepts will not

be readily distinguishable. Alternatively, using three

relations, the presentation for concept browsing can

be made much clearer.

A second variation is based on the subdivision of

concepts. One can use different characteristics of a

concept as the criterion for subdividing it (facets)

(Fig. 1b).

4.2 Ontologies

Generally, an ontology is an explicit specification of

a shared conceptualization. An ontology consists of

concepts, terms, and relations between the concepts

and terms [Huijsen & Driessen 2003].

An important observation about the ontology is that

it defines terms in the domain and relationships

between these terms in a formal way, but it does not

specify the meaning of the terms. Therefore, the

definition of an ontology can be focused to a formal

specification of a part of a conceptualization. The

names of the concepts and the description of the

ontology in natural language are therefore important

for the ability to understand and use an ontology.

In practical terms, developing an ontology includes

defining concepts in the ontology, arranging the

concepts in a subsumption hierarchy, defining facets

and describing allowed values for these facets, and

filling in the values for facets for instances [Noy &

McGuinnes 2001]. In contrast to thesauri, an explicit

difference is made between concepts and instances.

Furthermore, while subsumption is the main relation

in ontologies, there is no limit to the number of

relation types that can be used in ontologies.

4.3 Semantic Networks

A semantic network is a graph of the structure of

meaning. A semantic network represents knowledge

as a graph. An idea, event, situation or object

invariably has a composite structure; this is

EXPLICIT CONCEPTUALIZATIONS FOR KNOWLEDGE MAPPING

233

represented in a semantic network by a

corresponding structure of nodes representing

conceptual units, and directed links representing

relations between units. It becomes semantic when

you assign a meaning to each node and link

[Lehmann 1992]. Each concept is defined by its

links to other concepts [Sowa 1984]. Concept

meaning is extended by tracing outward from a

particular concept to all the concepts associated with

that particular concept. Semantic networks aim to

represent any kind of knowledge which can be

described in natural language. A semantic network

system includes not only the explicitly stored net

structure but also methods for automatically deriving

a much larger body of implied knowledge. The

essential idea of semantic networks is that the graph-

theoretic structure of relations and abstractions can

be used for inference as well as understanding

[Lehmann 1992].

Semantic networks do not distinguish between

concepts and instances, as ontologies do. As with

ontologies, there is no limit to the number of relation

types used in ontologies. The relations between the

concepts/instances are bidirectional.

In an ontology the subsumption relation is the basic

structure, and there typically is a strict distinction

between concepts and instances. By contrast, in a

semantic network, all concepts, instances and all

relations have an equal status. The subsumption

relation is just one of the relations, and no

distinction is made between concepts and instances.

This is an advantage because this makes abstraction

and inference over the concepts easier. The number

of relations in thesauri is fixed. In ontologies this

relation is not as strict by distinguishing between

concepts and instances. Semantic networks have rich

relations between the concepts. This means that

there are many more relations between the concepts

(than in ontologies), the (semantic) distance between

the concepts can be given, and finding related terms

is not limited by the hierarchy (as in thesauri and

ontologies).

A conceptualization in a knowledge-mapping tool is

used to describe the content of knowledge sources.

The results of the indexing of knowledge sources

and other information are stored in the KMDB. Note

that there is a commonality between the

conceptualization and the KMDB: both define

relations between concepts. If one allows for a large

enough number of concepts and relations in the

conceptualization, then these systems can be

integrated. This reduces complexity and improves

performance. Such a combination has a number of

implications. First, since a database typically

includes many relations, the conceptualization must

allow for a large number of relations. Second, the

conceptualization must also include the concepts of

the database, such as the knowledge sources

themselves.

5 EVALUATION

From the viewpoint of conceptualizations, what are

the fundamental differences between the models of

thesauri, ontologies, and semantic networks.

Thesauri focus primarily on the textual appearance

of concepts, namely technical terms. They only

indirectly recognize the existence of concepts by

grouping terms into synonym sets that each have one

preferred term to represent the corresponding

concept. Thesaurus standards limit the power to

express relations between concepts in that they

define only a handful of relations.

In contrast, the ontology model focuses on the

notions underlying the terms: concepts and

instances. The technical terms themselves are of

Country

The

Netherlands

Continent

consists of/part of

America

associates with

part of/consists of

Population

consists of/part of

State

consists of/part of

(a)

Country

The

Netherlands

Province

State

is a/instance of

America

part of/consists of

associates with

part of/consists of

Holland

also called

not the same as

(b)

Figure 2: (a) Sample ontology (b) Sample semantic network

ICEIS 2004 - INFORMATION SYSTEMS ANALYSIS AND SPECIFICATION

234

lesser importance. Issues like synonymy are not

central, and can be dealt with in terms of the

multifunctional attributes of concepts and instances.

In terms of relations, the ontology model still places

a focus on the hierarchical subsumption relation, but

allows for arbitrarily many other relations. The

ontology model thus takes a more appropriate focus

and enhances expressive power by not limiting the

number of relations, while still being able to deal

with the issues central to the thesaurus model.

Finally, semantic networks subscribe to the more

generic view that concepts and instances have so

much in common that it warrants having only one

type of object, also termed “concept”. The

distinction between the concepts and instances of the

ontology model can still be made using attributes.

The semantic network model also liberalizes the role

of the relations. Relations are all given equal status:

there is no a priori focus on the subsumption

relation. Like the ontology model, the semantic

network model does not limit the number of

relations. In comparison to the ontology model, the

semantic network model therefore is more generic: it

retains the expressive power, and makes it much

easier to handle concepts and instances as the same

type of object where appropriate.

In summary, moving from the thesaurus model via

the ontology model to the semantic network model,

we see that each step corresponds to important

additional insights, and each successive model is

more capable to appropriately serve as a model for

conceptualizations. The expressive power of each

previous model is retained, not by extending the

previous model, but by replacing the modeling

primitives with more generic ones. As a conse-

quence, necessary features must be softcoded in

terms of the modeling primitives instead of being

hardcoded as modeling primitives themselves. This

means that in addition to the model itself it must be

specified how to use modeling primitives such as

attributes to implement the required features.

The structure of conceptualizations helps build the

conceptualization. As we have seen the thesaurus is

simple to build, while the ontology and semantic

network call for more effort. Furthermore the

structure of the conceptualization also limits or

extends its inference capabilities. As for the

thesaurus and the ontology, we saw that they were

limited by the top-down tree structure. The semantic

network is not limited by its structure.

The number of relations in a thesaurus is limited.

This results in a simple conceptualization that can be

built more easily. The relations in an ontology and

semantic network are not limited. This implies a

complex structure, especially for a semantic

network. Being able to use lots of relations results in

powerful inference capabilities.

Thesauri do not distinguish between concepts and

instances. They use preferred terms to represent the

concept. Ontologies do distinguish between concepts

and instances, while semantic networks do not. The

distinction between preferred terms and other terms

is simple and straightforward. Distinguishing

between concepts and instances, as in ontologies, is

a more complex approach. In semantic networks no

distinction is made between concepts and instances.

This results in a complex network, but also in the

advantage of being able to abstract from a concept

more easily.

Higher-order processing for knowledge mapping

involves some reasoning. In the thesaurus

configuration, inference is hardcoded into the

software and is limited by the structure of the

conceptualization. Alternatively, in the ontology and

semantic network configurations, we are not limited

by the structure of the network. Inference typically

makes use of the specific relations in the KMDB.

Thus, inference capabilities of the

conceptualizations only make sense if the KMDB is

integrated with the conceptualization, because this

enables the explicit coding of the inference rules.

Now we will judge the conceptualization based on

the criteria listed in section 3. All conceptualizations

can include all terms that describe the concept, e.g.

synonyms and spelling variants. Thesauri do both

explicitly. In ontologies and semantic networks the

spelling variants are treated as synonyms. Thesauri

define a preferred term, ontologies and semantic

networks do not. The conceptualizations all define

other relations. Thesauri usually consist of three or a

limited number of relations. Ontologies and

semantic networks usually also have a predefined

number of relations, but theoretically can account

for an unlimited number of relations.

In our view there are two viable conceptualizations

for knowledge mapping: the thesaurus and the

semantic network. The thesaurus variant is geared

towards simplicity, ease of implementation, and

reduction of work. The semantic network variant is

geared towards maximum expressiveness. It has a

more complex structure, which makes it harder to

implement. It also allows for integration with the

KMDB.

Table 1: Comparison of conceptualization Tools

Thesaurus Ontology Semantic

Net

Complexity low medium medium

Labour

intensity

medium high high

Integrated – + +

EXPLICIT CONCEPTUALIZATIONS FOR KNOWLEDGE MAPPING

235

6 CONCLUSION

Which conceptualizations should be recommended

to extend a knowledge mapping system?

Conclusions can be drawn from the evaluation of the

conceptualizations themselves and in the light of the

knowledge mapping criteria. From a technical point

of view – does the conceptualization account for

fully integrated conceptualization? Ontologies and

semantic network satisfy these criteria, while

thesauri do not. From a user perspective – how

easily can a conceptualization be built? – the

thesauri is the simplest and most straight-forward to

build (and maintain). Ontologies and semantic

networks require much more effort. However, the

complexity of the semantic network is higher than

that of the ontology due to the fact that no

distinction is made between concepts and instances,

and the possible relations are endless.

Thus, when we have to make a choice between these

conceptualizations we advise to choose between the

simple approach by using the thesaurus for the

knowledge mapping systems or the complex

approach, by choosing for the semantic network.

When you want to have more complex capabilities

than thesauri have, building an ontology is useless.

We advise to use the semantic network approach

because of the extra advantages the structure of a

semantic network has and the fact that semantic

networks do not differentiate between concepts and

instances, which makes abstracting easier.

REFERENCES

Genesereth, M.R. and Nilsson, N.J., 1987. Logical

Foundations of Artificial Intelligence, San Mateo, CA:

Morgan Kaufmann Publishers.

Gertner, D., 1978. “On Relational Meaning: The

Acquisition of Verb Meaning”. Child Dev.ment, 49,

pp.988-998.

Huijsen, W., and Driessen, S., 2003. “How to Build

Ontologies for the Metis Pilots”, Telematica Instituut,

internal technical report.

ISO 5963, 1985. “Documentation – Methods for Examing

Documents, Determining Their Subjects, and

Selecting Indexing Terms”, 1st edition, ISO.

ISO 2788, 1986. “Documentation – Guidelines for the

Establishment and Development of Monolingual

Thesauri”, 2nd edition, ISO.

Lehmann, F., 1992. “Semantic Networks”. In Computers

& Mathematics with Applications, vol. 23, nr. 2-5.

NISO. “Guidelines for the Construction, Format, and

Management of Monolingual Thesauri”, NISO Press,

Betheseda, MD.

Noy, N.F. and McGuinness, D.L., 2001. “Ontology

Development 101: A Guide to Creating Your First

Ontology”, Stanford Knowledge Systems Laboratory

Technical Report KSL-01-05.

Roche, C., 2002. “Form Information Society to

Knowledge Society: the Ontology Issue”. In:

Computing Anticipatory Systems: CASYS 2001 – Fifth

Int. Conf., ed. D.M. Dubois.

Sowa, J.F., 1984. Conceptual Structures: Information

Processing in Mind and Machine, Menlo Park, CA:

Addison-Wesley.

Wielenga, B.J., Schreiber, A.Th., Wielemaker, J., and

Sandberg, J.A.C., 2001. “From Thesaurus to

Ontology”,. In First Int. Conf. on Knowledge Capture

(K-CAP 2001), Victoria, British Columbia, Canada.

ICEIS 2004 - INFORMATION SYSTEMS ANALYSIS AND SPECIFICATION

236
