Risk Analysis of Biometric Systems

Christos K. Dimitriadis

, Prof. Despina Polemi

Expertnet SA, 244 Kifisias Av., 15231 Athens, Greece

University of Piraeus, 80 A. Dimitriou, 18534 Piraeus, Greece

Abstract: This paper, presents a risk analysis knowledgebase, which aims to

enhance existing risk analysis methodologies and tools, by adding the capabil-

ity of analyzing the risk of the biometric component of an information system.

The knowledgebase was created by applying the Multi-Criteria Analysis meth-

odology to the results of research in the security aspect of biometric technolo-

gies. The result is a set of vulnerabilities, risk factors and countermeasures for

biometric systems.

1 Introduction

A main security weakness of password and token-based authentication mechanisms,

is the fact that knowledge, as well as the possession of an item, does not distinguish a

person uniquely. Modern biometric technologies provide enhanced security levels by

introducing a new dimension in the authentication process called “proof by property”.

However, the design and deployment of a security architecture incorporating biomet-

ric technologies hides many pitfalls, which when underestimated can lead to major

security weaknesses. International security standards, such as ISO/IEC 17799, “IT –

Code of practice for information security management” and COBIT: “Control Objec-

tives for Information and related Technology”, provide the general guidelines and

principles for correctly deploying a security architecture, both indicating as a very

important aspect, the conduct of risk analysis. Regardless of the risk analysis method-

ology deployed, it is a common practice to utilize a database of common risks and

countermeasures (called knowledgebase) for assuring the effectiveness of the process

[4]. Such knowledgebases, are sources of expertise regarding security issues for the

various components of information systems, assuring that no risks will be missed and

adequate countermeasures will be proposed during the process. Despite the existence

of biometric-specific standards and best practices, such as ANSI X9.84 “Biometric

Information Management and Security” and Best Practices in Testing and Reporting

Performance of Biometric Devices [1], there are no detailed knowledgebases for

assisting the risk analysis process, as far as biometrics are concerned.

This paper, presents a risk analysis knowledgebase, which aims to enhance exist-

ing risk analysis methodologies and tools, by adding the capability of analyzing the

risk of the biometric component of the system. Part of this work is the author’s con-

tribution to the EC project BIOSEC [20]. The authors would like to thank the EC for

K. Dimitriadis C. and Polemi D. (2004).

Risk Analysis of Biometric Systems.

In Proceedings of the 2nd International Workshop on Security in Information Systems, pages 23-32

DOI: 10.5220/0002650100230032

 SciTePress

funding BIOSEC, as well as the BIOSEC partners. The remainder of the paper is

organized in the following main sections:

• Methodology (general approach and multi-criteria analysis): Describing the meth-

odology followed for building the knowledgebase.

• Biometric risk analysis Knowledgebase (BK): Containing the knowledgebase of

vulnerabilities and risk factors of biometric systems, as well as the countermea-

sures for risk reduction.

2 Methodology: General Approach

In order to ensure applicability and easy integration of BK, to the widest possible risk

analysis methodologies and tools, a general risk analysis model [2][3], which is im-

plemented by most of the standard methodologies, was studied. This model is com-

prised of the following steps:

1. Asset identification,

2. Threat identification (defining as threat, an event that can potentially cause unde-

sirable effects),

3. Vulnerability identification (defining as vulnerability, a security weakness of the

system),

4. Risk identification (defining as risk, the probability that a particular threat will

exploit a particular vulnerability),

5. Identification of countermeasures for risk reduction.

The first two steps (asset and threat identification) are covered sufficiently by stan-

dard risk analysis methodologies without the need of a specialized BK.

The third step (vulnerability identification) revealed the emerging need for the de-

velopment of a catalogue of vulnerabilities for biometric systems. The catalogue

acted as a foundation stone of BK and was populated by conducting:

• Extensive desk research on known or possible attacks against various biometric

technologies

• Penetration tests on biometric systems in a dedicated lab

• Interviews with experts in the field

The forth step (risk identification), depends on the risk analysis methodology.

Most standard risk analysis methodologies rely on the combination of existing

knowledge with information extracted from questionnaires and interviews [5][6].

Other methodologies and tools [7] utilize predetermined risk scores for each identi-

fied vulnerability, based on the estimation of experts who studied the likelihood of

occurrence of vulnerability exploits. For the creation of BK, a quantitative approach

was chosen, calculating a risk factor for each vulnerability. The risk factor is an indi-

cator of the importance of the vulnerability and the sum of all risk factors provides

the total risk factor of the biometric component of the information system under re-

view. In order to calculate the risk factor and provide an objective evaluation of each

vulnerability a standard methodology called Multi-Criteria Analysis (MCA) was

deployed.

The last step (identification of countermeasures for risk reduction), indicated the

need for identifying countermeasures for reducing the risk. The countermeasures

were identified as an extension of the research conducted for identifying vulnerabili-

ties and was also based on the conduct of tests, desk research and interaction with

experts in the field of security and biometrics.

The final form of BK, is a set of vulnerabilities followed by the corresponding risk

factors and countermeasures. In the case of vulnerabilities, which are applicable to all

biometric technologies, common risk factors were calculated. In the opposite case of

technology-specific vulnerabilities, individual risk factors were calculated for finger-

print, iris, face and voice biometrics.

3 Methodology: Application of Multi-criteria Analysis (MCA)

Multi-Criteria Analysis (MCA) [8][18] is a method to evaluate different alternatives

(currently biometric vulnerabilities) and to determine an order of ranking of these

alternatives. MCA takes into account that some specific criteria should be more influ-

ential in the determination of the ranking between alternatives. This is accomplished

by the attachment of weighing factors to the different criteria. The following MCA

steps were followed for evaluating biometric vulnerabilities:

1. Criteria selection: a number of criteria were selected, which were considered as the

most important for evaluating vulnerabilities and which influence their probability

of occurrence. These are:

• C1: Difficulty to exploit in terms of technical expertise required and complexity.

• C2: Effectiveness (in terms of level of exposure to threats - binding the vulnerabil-

ity with the threat).

• C3: Cost in terms of special equipment required.

2. Input of the scores: For each vulnerability a score was calculated per criterion. The

score was calculated after processing results from the desk research, biometric lab

tests and interviews. The scores were based on a common quantitative scale (from

1-10). In more detail:

• C1: The highest score (10) represents the lowest difficulty.

• C2: The highest score (10) represents the highest effectiveness.

• C3: The highest score (10) represents the lowest cost.

3. Attachment of the weighing factors: The next step in the MCA process involved

the prioritization of the criteria by the assignment of different rankings or weights.

A weighing factor was attached to each criterion, after studying security incidents

and attack profiles. The first three steps of MCA are presented in figure 1:

Fig. 1. The first three steps of MCA: criteria C1, C2, C3, scores and attached weighing factors

Vulnerabilit

Score A on C1

Score A on C2

Score A on C3

W1*Score A on C1

W2*Score A on C2

W3*Score A on C3

4. Ranking of the vulnerabilities: a simple method was deployed - the injunction

MCA method. This method multiplies the scores of the criteria with the correspon-

dent weighing factors and calculates for every vulnerability the sum of these prod-

ucts, as shown in the following figure.

Fig. 2. Ranking of vulnerabilities. Calculations according to the injunction MCA method

The result is the total score per vulnerability and correspondent ranking. The vul-

nerability with the highest total score is the highest in ranking and most danger-

ous.

4 Biometric Risk Analysis Knowledgebase

This section is comprised of two sub-sections. The first one presents the identified

vulnerabilities and countermeasures, while the second one presents a comprehensive

form of BK, including vulnerabilities, risk factors and countermeasures.

4.1 Description of Vulnerabilities

This sub-section provides a short description of the identified catalogue of vulner-

abilities of biometric systems, followed by proposed countermeasures for risk reduc-

tion.

• Spoofing – Mimicry – Artefacts: Poor biometric implementations are vulnerable to

spoofing and mimicry attacks. An artificial finger made of commercially available

Vulnerability A

W1*Score A on C1

W2*Score A on C2

W3*Score A on C3

Total Score of A

Vulnerability B

W1*Score B on C1

W2*Score B on C2

W3*Score B on C3

Total Score of B

Total Ranking

silicon or gelatin, can deceive a fingerprint biometric sensor [9][10]. The proce-

dure for materializing this attack is consisted of three steps. The first step is captur-

ing a fingerprint (e.g. from a glass, a door handle or with the user’s consent). The

second step is creating the artefact, which is a procedure that lasts from a few

hours, to a few days maximum. The final step is using the artefact to access the

system. The use of pictures, masks, voice recordings or speech synthesis tools is

possible to deceive iris, face, and voice recognition systems. As a countermeasure,

it must ensured that vitality detection features, which conduct an extra measure-

ment of one or more attributes, such as the relative dielectric constant, the conduc-

tivity, the heartbeat, the temperature, the blood pressure, the detection of vitality

under the epidermis, or the spontaneous dilation and constriction of the pupil or

eye movement, are integrated in the biometric device.

If these features are not pre-

sent, compensating controls must be applied, such as the deployment of multimo-

dal biometrics (e.g. combination of face and lips movement recognition), or the

implementation of interactive techniques (e.g. the request for the user to say a spe-

cific phrase, or place 3 fingers in a certain order on the sensor).

• Server side - Fake templates: Server based architectures, where the biometric tem-

plates are stored centrally, inherit the vulnerabilities of such systems [14]. A possi-

ble attack can be realized when the impostor inserts his template in the system un-

der someone else’s name. Distributed architectures (e.g. template storage in a

smart card) should be preferred. In that case, the template is stored in a tamper re-

sistant memory module that is write-once and erased or destroyed if its content is

altered, resisting to this type of attack. When this scenario is not an option, strong

security controls must protect the server, including encryption of the templates,

system and network security controls (firewalls, intrusion detection and prevention

mechanisms) and a strong security policy followed by detailed procedures based

on international standards.

• Communication links: Data could be captured from the communication channel,

between the various components of a biometric system [14], such as: the sensor

and the feature extractor, the feature extractor and the matching algorithm or the

matching algorithm and the application, in order to be replayed at another time for

gaining access. This is also called electronic impersonation. An effective counter-

measure is the integration of the various parts of the system into a hardware secu-

rity module, or generally the elimination of the transmission of the biometric tem-

plate. An example of such a module is the biometric smart card, that has a finger-

print sensor and the matching mechanism embedded in it, confining the template to

a secure environment. Similar security levels are addressed in integrated terminal

devices, such as PDAs or mobile phones. If this is not an option, challenge and re-

sponse is another approach for addressing this vulnerability. An additional control

is the introduction of a rule to discard a signal when it is identical to the stored

template or to the last measurement that was conducted.

• Cross system: The utilization of the template in two or more applications with

different security levels (i.e. convenience applications and security applications)

tends to equalize these security levels, by decreasing the higher security level to

the lower one - if a template is compromised in one application, it can be used for

gaining access to the other. A countermeasure, depending on the criticality of the

application, is the deployment of custom encoding algorithms in order to ensure

the creation of custom templates per user. Another option is the combination of ex-

isting biometric encoding algorithms with one-way hash functions for ensuring

that the templates produced for a specific user in the specific system, are unique. In

that case, special care should be given to the calibration of the system, because

very strong non-invertible functions lower the system’s accuracy, due to the fact

that the matcher, must deal with the measurement variations, in the transformed

space [11]. This feature, also provides the ability of revocation to the system in the

case that an impostor compromises a template.

• Component alteration: A possible attack can be realized with a Trojan Horse on

the feature extractor, the matching algorithm or the decision algorithm of the sys-

tem, acting as a manipulator of each component’s output. Security controls should

be defined, such as write-once memory units that host the feature extraction pro-

gram and the matching algorithm, as well as the integration of the system to a

hardware security module. Additional controls include the development of a strong

security policy controlling the operation of the system, in order to protect it from

exposure to manipulating attempts.

• Enrolment, administration and system use: Poor enrolment, system administration

and system use procedures, expose the biometric system. During the enrolment

phase, raw biometric data and biometric templates can be compromised and data-

bases can be altered or filled with imprecise user data. Poor system administration

procedures, in addition to the above, might lead to altered system configuration

files, with decreased FAR, making false acceptance easier, thus security weaker.

Similarly, a user might exceed his/her authority, threatening the system. Detailed

procedures for user enrolment, system administration and use should be defined,

based on international standards and best practices. Controls should be defined, as

extensions of the system’s security policy, forcing for example segregation of du-

ties, job rotation procedures, logging facilities, alteration or anomaly detection

mechanisms.

• Noise and power loss: Off-limit power fluctuation or flooding of a biometric sen-

sor with noise data - for example flashing light on an optical sensor, changing the

temperature or humidity of the fingerprint sensor, spraying materials on the surface

of a sensor or vibrating the sensor outside its limits - might cause the biometric de-

vice to fail. The design of the security policy, should include those security con-

trols that will make the system environment as controlled as possible. These con-

trols depend on the nature of the application.

• Power and timing analysis: Capturing the power consumption of a chip can reveal

the software code running on the chip, even the actual command [12][13]. Simple

Power Analysis and Differential Power Analysis techniques are deployed for such

purposes and are capable for breaking cryptographic algorithms such as DES, by

using statistical software.

The same strategy can be followed, for breaking the

matching mechanism of the biometric system or revealing the biometric template.

The secret key or biometric template will appear as the peaks of a diagram project-

ing the result of applying the appropriate software to the power consumption meas-

urement. Timing attacks are similar and measure the processing time instead of the

power consumption. As countermeasure, it should be ensured that all necessary

technology controls are in place. These include the use of micro controllers with

lower power consumption and noise generators for power blurring. Regarding tim-

ing attacks, the algorithm and program code have to be designed as time-neutral.

These technological countermeasures must be included in the biometric system ei-

ther it is a smart card based architecture or not.

• Residual characteristic: The residual biometric characteristic of a user on the sen-

sor may be sufficient to allow access to an impostor (e.g. a fingerprint the sensor).

The attack is realized on a fingerprint sensor with a residual fingerprint from the

previous measurement, by pressing a thin plastic bag of warm water on the sensor,

by breathing on the sensor or by using dust with graphite, attaching a tape to the

dust and pressing the sensor [14]. The last technique is the most effective one.

Even when a specific rule in the login algorithm is in place, for declining the exact

same measurement, repositioning the tape to provide a slightly different input

would deceive the system. A technology assessment should be conducted. Non-

optical types of fingerprint sensors are resistant to this vulnerability. In general,

deploying interactive authentication in an adequate control for this type of risk.

• Similar template - Similar characteristics: A user having a similar template or a

similar characteristic with a legitimate one, might deceive the system, especially in

identification applications, where one to many template comparisons are con-

ducted. The maturity of the encoding algorithm, in terms of producing unique out-

puts from different inputs, as well the FAR of the biometric device should be stud-

ied. For security applications the biometric system should be calibrated in order to

have reduced FAR (indicative value FAR<0,001%). The maturity of the algorithm

can be assured by the deployment of certified products or independently tested

products based on [1].

• Brute force: This type of attack is based on trial and error practices [16][17]. The

impostor is attempting continuously to enter the system, by sending incrementally

increased matching data to the matching function until a successful score is ac-

complished. This method is most effective in systems that implement identification

rather than verification, since the biometric measurement is compared to a great

number of templates, making the system weaker (as the number of users in-

creases), due to the increased probability of the existence of similar templates or

characteristics among the population. Biometrics however are more resistant to this

attack, than traditional systems, since the impostor has to find a way to insert the

trial data to the system, thus combine this vulnerability with one of those described

above. As a countermeasure, it should be ensured that traditional controls are in

place, such as the automatic locking of the user’s account after a specific number

of attempts, as well as the application of verification instead of identification if

possible.

4.2 Comprehensive Form of BK

MCA, was applied step by step for each identified vulnerability. Criteria C1 (diffi-

culty to exploit) and C3 (cost) were assigned with higher weighing factors (equal to 3

) than C2 (effectiveness - weighing factor equal to 1), reflecting the most common

attack profiles and following the observation that attackers test vulnerability exploits

when they are easy to exploit and inexpensive, considering effectiveness at a latter

stage [19].

The results of MCA were transformed to percentages (risk factors). Each risk fac-

tor indicates the increase of the risk level, in the case that the vulnerability is applica-

ble to the system under review and no countermeasure is taken to address it. The sum

of all risk factors provides the total risk factor of the biometric component of the

information system under review. The risk factors were individually produced in the

cases of vulnerabilities that were specific for each biometric technology. Null scores

are translated to non-applicability of the vulnerability to a specific biometric technol-

ogy. The vulnerabilities, risk factors and countermeasures comprise the comprehen-

sive form of BK(fingerprint: Fi, iris: Ir, face: Fa, voice: V).

Table 1. : Comprehensive form of BK. Vulnerabilities, risk factors and countermeasures

Vulnerability Risk Factor (%) CM No.

Fi Ir Fa V

1. Spoofing – mimicry - artefacts 11 10 12 14 i, ii, iii

2. Server side - Fake templates 16 iv, v

3. Communication links 11 Vi

4. Cross system 9 vii

5. Component alteration 11 iv, vi

6. Enrolment, administration and system use 19 iv

7. Noise and power loss 4 4 4 6 iv

8. Power and timing analysis 4 viii

9. Residual characteristic 7 0 0 0 iii, ix

10. Similar template - Similar characteristics 2 2 6 6 ix, x

11. Brute force (verification applications) 4 xi

Countermeasures

i. Vitality detection.

ii. Multimodal architecture.

iii. Interactive authentication.

iv. Well-implemented security policy according to standards.

v. Storage of the template in a secure medium.

vi. System integration into a hardware security module.

vii. Custom biometric encoding algorithms – hash functions.

viii. Noise generators, low power consumption chips and specific software de-

sign.

ix. Technology assessment.

x. Calibration review.

xi. Traditional controls - account lock after a number of attempts.

In order to clarify the figures presented in the table, the calculation of the risk fac-

tor for the power and timing analysis vulnerability is presented below as an example:

1. Desk research, tests and interviews, defined timing analysis attacks, as difficult to

implement (special expertise is required - score on C1=1), effective (score on

C2=8) and expensive also (specific equipment is required - score on C3=1).

2. The scores were multiplied with the weighing factor of each criterion, providing a

total score of 14.

3. After calculating the total score for each vulnerability, the maximum total score of

all vulnerabilities was calculated - it belonged to the case of voice biometrics.

4. All scores were transformed to percentages of the maximum total score of all vul-

nerabilities. This action was performed, in order to achieve a maximum of 100%

when all vulnerabilities are present and at the same time preserve a common de-

nominator for all vulnerabilities. This resulted the risk factor of the power and tim-

ing analysis vulnerability to be 4%.

The role of BK during risk analysis depends on the methodology deployed. The

main functions are the identification of those vulnerabilities that are applicable to the

system under review, after consulting the vulnerability description sub-section, the

calculation of the total risk factor, by adding the percentages of each identified vul-

nerability, utilizing the comprehensive form of BK and the proposal – implementation

of countermeasures for risk reduction.

5 Conclusions

The main conclusions of the research conducted, are the following: Special care

should be given to user enrolment, system administration and use, implementing as a

mandatory control, concrete security policies and procedures based on international

standards. Server-based architectures, where templates are stored centrally, heavily

increase the risk level of the system, uncovering the demanding need for encryption

and strong intrusion prevention, detection and response countermeasures. Vitality

detection was also identified as a demanding need, which can be relatively compen-

sated by interactive authentication techniques or multi-modal biometrics. The restric-

tion of the biometric template to a hardware security module and the elimination of

the template submission over communication links and networks, addresses a great

number of vulnerabilities and reduces the total risk factor significantly. Horizontal

results between the four different biometric technologies were also derived and made

visible in the comprehensive form of BK, including the high distinctiveness of fin-

gerprint and iris characteristics, reducing the similar characteristic vulnerability.

These results however, are strictly related with security, under the specified criteria

and should not be confused with results on biometric system performance, or applica-

bility testing. The conduct of risk analysis is a significant step towards the creation of

security architectures, which promote the advantages of biometric systems in a risk-

proof manner.

References

1. Wayman, J.L., Mansfield, A.J.: Best practices of testing and reporting performance of bio-

metric devices. http://www.cesg.gov.uk/site/ast/biometrics/media/BestPractice.pdf. (2002)

2. Certified Information Systems Auditor Manual. Information Systems Audit and Control

Association (2003)

3. Peltier, T.R.: Information Security Risk Analysis. CRC press LLC USA (2001)

4. King, M., Dalton, C., Osmanoglu, T.: Security Architecture. RSA press USA (2001)

5. Operationally Critical Threat, Asset, and Vulnerability Evaluation method (OCTAVE).

http://www.cert.org/octave

6. CCTA Risk Analysis and Management Method (CRAMM). http://www.cramm.com.

7. Consultative, Objective and Bi-functional Risk Analysis (COBRA). http://www.security-

risk-analysis.com/introcob.htm

8. Multi-Criteria Analysis manual. http://www.odpm.gov.uk

9. Matsumoto, T., Matsumoto, H., Yamada, K., Hoshino, S.: Impact of artificial fingers on

fingerprint systems. Proceedings of SPIE, Vol. 4677. Yokohama (2002)

10. Van der Putte, T., Keuning, J.: Biometrical fingerprint recognition – don’t get your fingers

burned. IFIP TC8/WG8.8 Fourth Working Conference on Smart Card Research and Ad-

vanced Applications. Kluwer Academic Publishers. (2000) 289-303

11. Sudan, M., Jules, A.:A fuzzy Vault Scheme. IEEE Internation Symposium on Information

Theory. IEEE Press Lausanne Switzerland (2002) 408

12. Gandolfi, K., Mourtel, C., Olivier, F.: Electromagnetic Analysis: Concrete Results. Lecture

Notes in Computer Science, Vol. 2162. Springer-Verlag (2001) 251-261

13. Kocher, P., Jaffe, J., Jun, B.: Introduction to Differential Power Analysis and Related At-

tacks. http://www.cryptography.com/technology/dpa/DPATechnicalInfo.PDF. (1998)

14. IST-1999-20078 Business environment of biometrics involved in e-commerce.

http://expertnet.net.gr/bee (2002)

15. Prabhakar, S., Pankanti, S., Jain, A.: Biometric Recognition Security and Privacy Concerns.

IEEE Security and Privacy, March /April (2003) 33-42

16. Bolle, R.M., Connell, J.H., Ratha, N.K.: Biometric perils and patches. Pattern Recognition,

Vol. 35, no. 12 (2002) 2727-2738

17. Smith, R.: The biometric Dilemma. Secure Computing (2002)

18. Pardalos, P., Siskos, Y., Zopounidis, C.: Advances in Multicriteria Analysis. Kluwer Aca-

demic Publishers Dordrecht Hardbound (1995)

19. Know your enemy series. The Honeynet project. http://www.honeynet.org

20. IST-2002-001766 Biometrics and Security – BIOSEC. http://biosec.tid.es
