INFORMATION SYSTEM FOR SUPPORTING THE INCLUSION

OF JOB SEEKERS TO THE LABOUR MARKET.

Paraskeuas P. Chatzidiakos

Department of Electronics, Technological Educational Institute of Athens, Athens, Greece

Christos Skourlas

Department of Informatics, Technological Educational Institute of Athens, Athens, Greece

Theodoros Alevizos

Dept. of Industrial Informatics, Technological – Educational Institute of Kavala, Kavala, GREECE

Keywords: System Integration, System Interconnection, Data Mart, Cross Lingual Information Retrieval.

Abstract: In this paper, the interconnection and integration problem of disparate Inform

ation sources including

multilingual information related to the Unemployed and Business is analyzed. A possible solution based on

the use of the European curriculum vitae and the creation of Data Marts is briefly described. The approach

is also influenced by well-known Cross-Lingual Information Retrieval (CLIR) techniques. We also focus on

the creation of a pilot Information System for the Institute of Labour (INE) of the Greek General

Confederation of Labour (GSEE). Eventually, our experience and a first evaluation of the system are

discussed.

1 INTRODUCTION

There are various organisations (e.g. EURES –The

European Employment Services for the Job

Mobility, Information Offices for the Unemployed

and Businesses, National Employers' Organisations,

National Trade Unions) that are interested in

vocational training and employment. The

interconnection / integration of operational,

disparate Information sources, which have been

established to cover the needs of such organisations

is a difficult problem, in general.

The technical framework for solving the

problem

today, is related to traditional methods and

techniques of system analysis and, also, new

concepts (e.g., data warehouse, data mining),

techniques (e.g. Information / Text Retrieval

techniques), tools (e.g. OLAP, Document

Management tools) and standards (e.g. Z39.50).

1.1 Standardised individuals’ data.

The basis of an Information System for supporting

the inclusion of unemployed individuals to the

labour market is a comprehensive standardised

overview of education attainments and work

experience of the individuals.

It is, also, impossible to improve the

nagement and support decisions that are related to

the problem of the unemployment without having a

common pool of "unified" data.

1.2 Cedefop

Cedefop (Centre Europeen pour le Developpement

de la Formation Professionnelle) is the European

agency that helps policy-makers and practitioners of

the European Commission, the Member States and

social partner organisations across Europe make

informed choices about vocational training policy. It

617

P. Chatzidiakos P., Skourlas C. and Alevizos T. (2004).

INFORMATION SYSTEM FOR SUPPORTING THE INCLUSION OF JOB SEEKERS TO THE LABOUR MARKET.

In Proceedings of the Sixth International Conference on Enterprise Information Systems, pages 617-624

DOI: 10.5220/0002657206170624

 SciTePress

was established as a non-profit making body,

independent of the Commission, to help rethink the

direction and requirements of vocational training

and assist the Commission in promoting the

development of vocational training.

1.3 The European Curriculum Vitae

The European Curriculum vitae (CV) (Cedefop) is

recommended by CEDEFOP to provide information

on: language competences, work experience,

education and training background, additional skills

and competences acquired outside formal training of

the individual. The CV format is available in 13

languages and can be download in various formats

(MS Word, rtf, pdf). Download examples of filled in

CVs are also available.

1.4 The Case of the Greek Institute of

Labour

The Greek General Confederation of Labour

(GSEE), the leading employees' organization, was

founded in 1918. Members of the GSEE are the

second level trade union organisations (union

federations and Labour Centres). The Institute of

Labour (INE) of the GSEE was established in

December 1990. INE GSEE is a non profit making

company and is organised also at the regional level

(based on 13 administrative regions) and at the

branch level (based on 22 branches of economy

activity. It aims at the scientifically supported

intervention of the trade union movement in the

following areas of action:

• Research, studies and data gathering.

• Planning, implementation and development of

appropriate schemes for vocational training.

• Development of systems related to trade union

education and training.

The Information Office for the Unemployed and

Businesses was also established in 2000 by GSEE

with the aim to provide information about labour

relations, insurance legislation, immigration policy,

employment, education and training.

A pilot Information System was established to

study the current situation, gain experience, provide

information about employment, education and

training and facilitate one’s inclusion to the

labour/job market.

In this paper the problem of integration of

information collected / gathered “in house” and

information, partially extracted, from other

(external) information systems for the Unemployed

and Businesses is presented and discussed. In the

following section 2 the problem’s solution is

formulated following various directions

(perspectives): Data Warehouse / Data Mart,

information extraction based on the European CV

and Document / Text Retrieval. In section 3 we

present a first solution of the problem in the case of

the INE. Eventually, in section 4 we discuss our first

estimations. Conclusions and future activities are

presented in section 5.

2 PROBLEM SOLUTION

There are many aspects of the problem related to the

various requirements not only of an information

office but also of the entire parent organisation.

2.1 The Perspective of the Data Mart

National organisations usually have invested money

in "legacy" systems and disparate databases. Thus, if

new needs must be covered they often build some

structure on top of the existing systems, a data

warehouse, where information of many databases is

copied to a central database. If there are also

information needs for an updateable new system

usually for a specific topic we prefer to design and

operate Data Mart.

Data warehousing and Data Marts arose for two

main reasons: First, the need to provide single,

clean, consistent source of data for decision support

purposes; second, the need to do so without

impacting operational systems.

There are potential users that prefer to use office

automation software for writing documents (e.g.

CVs of individuals out of employment, companies’

profiles). We have to collect and organise all these

kinds of information. In some cases there is also a

need to handle images, drawings etc. Text and

Document retrieval and text mining can offer the

appropriate techniques.

An emphasis must be given to the fact that the

design, construction, and implementation of the data

warehouse / data mart is an important and

challenging consideration that should not be

underestimated (e.g. (Karanikolas, 2003)).

Lechtenborger and Vossen (Lechtenborger,

2003) stress that the warehouse design is a non-

trivial problem. They present a sequence of

multidimensional normal forms and discuss how

these forms allow reasoning about the quality of

conceptual data warehouse schemata. Lu and

ICEIS 2004 - DATABASES AND INFORMATION SYSTEMS INTEGRATION

618

Lowenthal (Lu, 2003) examine strategic

arrangements of fact data in a Data Warehouse in

order to answer analytical queries, efficiently, and

improve query performance.

2.2 Using Z39.50 protocol

There are various Standards operating in the domain

under consideration to provide the framework for the

access, exchange, management and integration of

data that support information needs and the

management, delivery and evaluation of related

services. One promising specification adopted by the

ISO (ISO 23950) is the NISO Z39.50 protocol, the

international standard for information retrieval. This

protocol could also be seen as an interoperability

standard enabling disparate applications to access

and exchange a wide array of information resources

and databases.

The typical scenario for Z39.50 applications,

today, has much impact on libraries and information

retrieval communities. ZING (Z39.50 International:

Next Generation) is the umbrella name used to

describe several experiments that focus on making

the protocol more amenable to and usable by the

Web-based community (Needleman, 2002).

The protocol could support such functions as

security checks, participants’ identification,

availability checks, exchange mechanism

negotiations and, most importantly, data exchange

structuring. As an example, in the GAIA project, in

Electronic Brokerage, customers are provided with a

uniform way of accessing heterogeneous suppliers

without changes in the supplier software and Z39.50

is used for discovery of a resource or product etc

(RFC 2525), (Hands, 2002).

Finally, the Standard is mature and stable, has

been widely implemented (mainly in the library

world) and there are available not only commercial

products but also freely available code packages that

can be used to build applications (Needleman,

2002).

Analysing this situation we have to study the

related standard that seems to offer a key structural

basis for solving the access and interconnection

problem.

2.3 Document storage and retrieval

The similarity of a document against a submitted

query has been the field of continuing research for

many years. In the popular vector space model a

data set of n unique terms is specified, called the

index terms of the document collection, and every

document can be represented by a vector (T1, T2,

…, Tn), where Ti=1, if the index term i is present in

the document, and 0 otherwise.

We can distinguish two types of index terms (or

key phrases): Keywords, Uncontrolled terms. The

difference between Keywords and Uncontrolled

terms is that keywords are phrases that belong to a

specific authority list e.g. a specific Classification

Coding scheme (or a thesaurus). Uncontrolled terms

are usually given by individuals (e.g. authors) or

extracted using specific Information extraction

techniques. Hence, we can form a list of UTs and

eventually using various methods and experts (e.g.

information officers) to form an authority list of

keywords in the future.

A query is a document and can be represented in

the same manner. The document and query vectors

can be envisioned as an n-dimensional vector space.

A vector matching operation, based on the cosine

correlation used to measure the cosine of the angle

between vectors can be used to compute the

similarity. Hence, the following equation (e.g.

(Karanikolas, 2000)) gives us a well-known method

to measure the similarity of document Di against

query Q:

SD Q

jij

(,)=

⋅

−=

∑

∑∑

∑

where n is the number of index terms used in the

collection, tij is the weight of term j in document Di

and qj is the weight of term j in the query.

The following two equations can be used to

measure the terms tij and qj:

=+⋅05 05..

max

DOCFREQ

⎛

⎝

⎜

⎞

⎠

⎟

log

where Fij is the frequency of term j in document Di,

maxFi is the maximum frequency of the terms in

document Di, N is the number of documents in the

collection and DOCFREQj is the number of

documents that include the index term j.

INFORMATION SYSTEM FOR SUPPORTING THE INCLUSION OF JOB SEEKERS TO THE LABOUR MARKET.

619

2.4 Phrase extraction.

Phrase extraction is the subject of interesting

research accompanied by various experimental (and

not only) tools. As examples we can mention KEA

system which implements in Java simple algorithms

for extracting phrases from English text (Witten,

2000) (Witten, 1977).

It is worth mentioning here that such research

works and tools are usually oriented towards the

extraction of information from Web applications

Especially in the case of some languages (e.g.

the Greek language) there is a rich inflectional

(grammatical) system that implies further difficulties

in the extraction process. Prerequisites for a serious

work in handling Cross Lingual text are the use of a

list of stop-words, some morphological analysis,

stemming, etc. It is also interesting to see the

research works attacking the problem of extracting

phrases from texts written in languages with rich

inflectional system (e.g. (Ahonen, 1977) (Alevizos,

1989)).

We must also stress the importance of n-grams

for extracting keywords and the free-text searching

process.

Using these extracted phrases human experts can

form a list of Uncontrolled Terms (phrases), which

is some kind of controlled vocabulary, and can be

used as terms characterising the document.

Then, we can use such terms for classifying (or

indexing of) the document.

3 INFORMATION EXTRACTION

BASED ON EUROPEAN CV

European CVs (Cedefop) share a common structure

(form). They include information organised in text

mode having the following fields (and sub-fields):

• Personal Information: Name, Address,

Telephone, E-mail, Nationality, Date of birth

• Work Experience: Dates, Name and address of

employer, Occupation or position held, Main

activities and responsibilities.

• Education and training: Dates, Name and type

of organisation providing education and

training, Title of qualification awarded,

Principal subjects / occupational skills covered,

Thesis Title and short comments.

• Personal skills and competence: Mother

Tongue, Other Languages (Reading skills,

Writing skills, Verbal skills)

• Social skills and competence: Team work,

Mediating skills, Intercultural skills

• Organisational skills and competence

• Technical skills and competence

• Additional Information Publications

• Personal Interests

All CVs form a potential source for extracting

information e.g. the classification codes related with

the employment.

Figure 1 shows a portion of the Entity

Relationship model that illustrates the implemented

database. The information is well structured, in

general, but there are also fields (or sub-fields)

written in plain text. To clarify things let us consider

the Work Experience field that is a key text field for

our study. Examples of values of such a field could

be the following (Cedefop):

• Dates: March – July 2002

• Name and address of employer: Youth Unit,

DG Education and Culture, European Commission

200, Rue de la Loi, B-1049 Brussels

• Occupation or position held: Independent

consultant

• Main activities and responsibilities:

1. Evaluating youth training programmes and the

Partnership between the Council of Europe and

European Commission

2. Organizing and running a 2 day workshop on non-

formal education for Action 5 large scale projects

focusing on quality, assessment and recognition.

Some portions, as Occupation and Employers’

sub-fields could be structured and some coding

scheme could also be used. Unfortunately, Main

activities and responsibilities are usually written as a

plain text. Such a text could only be retrieved using

free text searching techniques and keywords or

uncontrolled terms summarizing the previous work

experience of the individual and the current

occupation.

The Education and Training field is another key

text field for our study. Examples of the values of

such a field could be the following (Cedefop):

• Dates: 1997-2001

• Name and type of organization: Brunel

University, London, UK, Funded by an Economic

and Social Research Council Award

• Title of qualification awarded: Ph.D.

• Principal subjects/occupational skills covered:

Thesis Title: 'Young people in the Construction

of the Virtual University’, Empirical research that,

directly, contributes to debates on E-learning.

• Dates: 1993- 1997

• Name and type of organization: Brunel

University, London, UK.

ICEIS 2004 - DATABASES AND INFORMATION SYSTEMS INTEGRATION

620

• Title of qualification awarded: Bachelor of

Science in Sociology and Psychology.

• Principal subjects/occupational skills covered:

Sociology of Risk, Sociology of Scientific

Knowledge / Information Society, E-learning and

Psychology, Research Methods.

The name and the type of organizations and the

title of qualification have to be imported from

external Information Systems or standardized using

coding schemes, in house. Subjects and occupational

skills have to be handled using two complementary

approaches: Subject Headings (or Thesaurus) and

Uncontrolled phrases. The Uncontrolled phrases

(index terms) must be given by the applicants while

the controllable terms are assigned by experienced

information officers.

Dissertation titles and the related short abstracts

form some kind of bibliographic data and can be

handled using standard procedures. However, this

approach (these handling procedures) makes sense

only in the case of a system oriented towards the

support of scientific CVs.

Skills and competence are also potential sources

of critical information but, in general, is difficult to

be handled using (even semi) automated methods.

A possible solution for the retrieval of CVs

seems to be classification based on training sets.

Hence, intuitively, we propose the use of a

document collection (collection of portions extracted

from specific CVs that is the “training” set) as a

basis. Each new document (portion of the CV) could

be seen as a query submitted for extracting “similar”

documents from the collection. The document

collection is also characterized by a number of Index

Terms (Uncontrolled Terms). For each document in

the collection the existing Index terms in the

document can have weight, frequency etc. This

approach has an advantage because such text

retrieval techniques are well known and have been

tested for many years.

Reviewing the process we can select new

documents classified and improve the document

collection (the “training” set).

Hence, for each new document we can extract

the key-phrases for possible future utilization in the

list and identify the UTs that exist in the text. Then

the vector for the document is constructed and the

similarity of the document with the documents of the

training set is calculated using the above measure.

Then a discretization table (with ranges) could

be used to propose possible Classification Codes

(CC) for the indexing of the document.

4 DISCUSSION

Main target of this paper is to discuss techniques that

could offer to the information officers the

opportunity to extract CVs and companies’ profiles

from various sources, store them in a Data Mart

system and automatically or semi-automatically

match (retrieve) the appropriate information in the

future. Hence, such cross lingual documents could

be classified by using codes contained in a Standard

Classification Scheme – SCS. The STEP list

(EKEPIS), a statistical classification list of jobs, was

used in our system. Eventually, the information

officer can focus on an information extraction

process, from various sources and documents, which

is based on phrases from a loosely controlled

vocabulary and codes from a specific SCS.

The proposed method is based on the following

process:

1) A set of documents is formed by extracting

(and storing) documents from various sources. These

documents play the role of a “training” set for the

whole Corpus of the documents in the future.

2) The traditional IR process is applied as a first

step to automatically or semi - automatically focus

on some information extraction; in other words to

extract potential terms describing documents.

3) The creation of an authority list follows. All

the extracted UTs are submitted to the information

officer(s) to select the appropriate ones to

characterize the documents.

4) A Study of the distribution of UTs in the

corpus of the documents can be conducted to form

the "training set".

5) A vector is created for each document of the

training set. Each item (of the vector) has two

possible values (true, false) representing the

existence or not of the corresponding UT in the

document. The last item of each vector has the

classification code (e.g. the STEP code) that

characterizes the document (the class of document).

Hence, there are some critical points for the

method:

• Extract key-phrases. As an example, we can

adapt a method (e.g. Naïve Bayes technique)

used in (Witten, 1977) for selecting key-phrases

from a new document.

• Using the extracted phrases from the text the

experts can form a list of Uncontrolled Terms.

• The STEP list could be used for the indexing of

documents.

• A Knowledge Discovery “mapping” between

UTs and classification codes must be supported.

INFORMATION SYSTEM FOR SUPPORTING THE INCLUSION OF JOB SEEKERS TO THE LABOUR MARKET.

621

4.1 Training set and documents’

representation

We introduce an ordered set (a sequence) of

Uncontrolled terms (UTs):

ℜ

UTs

= ⎨UT

, UT

, …, UT

⎬

and the ordered set (sequence) of the Classification

Codes (CC):

ℑ

CCs

= ⎨CC

, CC

, …, CC

⎬

For each document (e.g. CV, company’s profile) we

have to itemize all the appropriate terms.

Such a representation, as the above one, could be

implemented using various techniques. True

indicates the existence of the related UT in the

document and False means the nonexistence.

Alternative representations could also be

implemented and easily expand to include

frequencies etc. Further refinement is possible in

various directions and depth e.g. some weights could

be added for each term existing in the document.

The vector representations could be used as vehicle

for extracting a variant of association rules useful for

classifying documents.

4.2 Classification Rules - A Data

Mining approach

The training set could be defined as a relation

(matrix) of the form:

CC UT

… UT

T)rue F)alse T)rue

e.t.c.

Figure 2

Classification rules of the following form are

easily produced (Karanikolas, 2002):

(Α

λ1

=ν

λ1

)^(Α

λ2

=ν

λ2

)^. . .^(Α

λj

=ν

λj

) ⊃ (A

m+1

=B) where

1 ≤ λ

< λ

< . . . < λ

≤ m for each attribute Α, m is

the number of UTs in the authority list, ν

∈ {true,

false} and B ∈ {b | b is any valid classification

code}

5 CONCLUSION

The integration of existing, separately operated

Information Systems, which have been established

to cover the needs of the same enterprise, is a

complex and difficult problem to be solved. The

problem is even harder if a new system has to be

based on information extracted from in-house and

external information systems. Another complex

requirement is the need for supporting cross-lingual

information within the framework of the new

system.

As a first conclusion, from a technical point of view,

the interconnection of existing systems in GSEE etc

is possible. The proposed solution of using the

Z39.50 protocol for the interconnection problem is

technically valid and reliable.

There is a need for extracting and classifying

information, (semi) automatically. As an example

companies’ profiles form a potential source of

information for extracting classification codes

related with their activities. Data / Text mining can

offer the appropriate techniques (Deal, 2001). Fuzzy

sets can also be used for the mining of useful

information (Hong, 2003).

We have suggested methods for (semi) automatic

classification of CVs based on information retrieval

and knowledge discovery in databases.

Apart from the above mentioned and discussed

general structure of a CV there are also some other

fields of such a document that are case dependent

(e.g. training’ certification, organizational skills and

related fields). We shall focus on results related to

this analysis in the near future. There is also a plan

to extent the existing IS to “reflect” the new

understanding of information.

Legal aspects will also be examined in the future.

Acknowledgements: Mr Harry Papanikos has

developed a first prototype of the system

REFERENCES

Cedefop - Centre Europeen pour le Developpement de la

Formation Professionnelle

www.cedefop.eu.int/transparency/CV.asp

GSEE - Greek General Confederation of Labour:

www.gsee.gr

Karanikolas, N., Skourlas, C., 2003, Shifting from legacy

systems to a data mart and computer assisted

information resources navigation framework, In

ICEIS’03, 5th International Conference on Enterprise

Information Systems, ICEIS Press

Lechtenborger, J., Vossen, G., 2003, Multidimensional

normal forms for data warehouse design, Information

systems, No 28, pp 415-434.

Lu, X., Lowenthal, F., 2003, Arranging fact table records

in a data warehouse to improve query performance,

Computers and Operations Research.

ICEIS 2004 - DATABASES AND INFORMATION SYSTEMS INTEGRATION

622

Needleman, M.., 2002, ZING Z39.50: Next Generation,

Serials Review, pp 248-250

RFC 2525, 1999, Architecture for the information

brokerage in the ACTS project GAIA, Blinov,

Bessonov, Clissmann

Hands et. al., 2002, An exclusive and extensible

architecture for electronic brokerage, Decision

Support Systems, vol. 29, pp 305-321

Karanikolas, N., Skourlas, C., 2000, Computed Assisted

Information Resources Navigation, Medical

Informatics and the Internet in Medicine, vol.25, No 2.

Witten, I., Frank E., 2000, Data Mining: Practical

Machine Learning tools and techniques with Java

Implementations, Morgan Kaufmann

Ahonen et. al., 1977, Mining in the phrasal frontier, In

Principles of knowledge discovery in Databases

conference, Springer - Verlag.

Alevizos et. al., 1989, Information Retrieval and Greek-

Latin text, 12th International ONLINE Information

EKEPIS - National Accreditation Centre of Vocational

Training Structures and Accompanying Support

Services: www.ekepis.gr/frame.html

Karanikolas, N., Skourlas C., 2002, Automatic Diagnosis

Classification of patient discharge letters. In MIE

2002, XVIIth International Congress of the European

Federation for Medical Informatics.

Deal, DC, 2001, Techniques of Document Management:

A review of Text Retrieval and related technologies.

Journal of Documentation 57, pp 192-217.

Hong, Tzung-Pei et. al., 2003, Fuzzy data mining for

interesting generalized association rules, Fuzzy sets

and systems.

Witten et. al., 1999, KEA: Practical automatic key

phrases extraction, Proceedings of the fourth ACM

conference on Digital Libraries.

INFORMATION SYSTEM FOR SUPPORTING THE INCLUSION OF JOB SEEKERS TO THE LABOUR MARKET.

623

APPLICANT

COMPANY

looks for

has

EXPERIENCE

CP_Street

CP_Number

CP_Name

Emp_Phone

Bike_Licence

Car_Licence

NameSex

Birth

Password

Username

App_No

knows

ISO_LANGUAGE

SEMINAR

Inst_Name

Sem_Skills

Duration

Start_Date

Ser_No

R_Skills

Lang_Title

W_Skills

V_Skills

Street

City

Phone

CP_Town

CP_Post_Code

CP_Region

CP_Fax

Street_No

Post_Code

Mobile

Fax

E_Mail

MName

LName

FName

Ser_No

Start_Date

End_Date

Emp_Name

Emp_street

Emp_Number

Emp_City

Emp_Fax

Emp_Mail

Emp_Site

Position

Activities

has attended

Language

Language_Code

CP_Job

CP_Phone

CP_Mail

ISO_COUNTRY

has nationality

VAT_No

Comp_Name

Comp_Site

resides at

Country

Country_Code

has maternal

language

reside at

gained working

EDU_TRAINING

is provided with

Ser_No

Start_Date

Gradu_Date

Edu_Name

Edu_Title

Edu_Skills

Edu_Level

EMPLOYER_TYPE

having horked in

the sector of

Emp_Type

Emp_Type_Code

INSTITUTE_TYPE

Edu_Type

Edu_Type_Code

belongs to the

rung

is activated in

the sector

CP_LName

CP_FName

CONTACT_INFO

CONTACT_PERS

has

represents

Acc_No

ure 1: Portion of the Entit

-Relationshi

model

ICEIS 2004 - DATABASES AND INFORMATION SYSTEMS INTEGRATION

624
