An Efficient Off-Line Reputation Scheme
Using Articulated Certificates
Roslan Ismail
1
, Colin Boyd
1
, Audun Josang
2
, and Selwyn Russell
1
1
ISRC, Queensland University of Technology, Brisbane, Australia
2
DSTC, University of Queensland, St Lucia, Australia
Abstract. A common feature practical reputation schemes is that they
are on-line which results in restrictions to both availability and scala-
bility. In order to overcome these two problems we propose an off-line
reputation scheme based on public key certificates. We introduce the
idea of articulated certificates which use proxy signatures to increase the
efficiency of reputation verification. As well as being well-suited to our
problem such linked certificates may be of independent interest.
1 Introduction
Reputation schemes are systems developed to collect, analyse and propagate
users’ reputation [12]. They can be used for many purposes, but in the last few
years have emerged as a promising means for enabling electronic transactions
in e-commerce. Studies have shown that use of reputation schemes has positive
effects on the efficiency and honesty of markets [1], and that the reputation of a
particular agent can have positive effects on the agent’s gain [13].
Most current reputation schemes, especially the practical ones, are specif-
ically designed for on-line use, eBay being a prime example (www.ebay.com).
This situation is not surprising as a reputation scheme must provide real time
responses so that users’ past behaviours can be obtained immediately. Although
an on-line reputation scheme is currently preferred, it suffers two main difficul-
ties: availability and scalability. For example, in a case of denial of service it
may not be p ossible to access the central server and so reputation values cannot
be found. If the central server is distributed to overcome such problems, then
synchronisation and consistency of data will become difficult.
These problems of distributed reputation systems have much in common
with the problems of distribution of public keys. In both cases there is a need for
access to authenticated values distributed in a timely fashion. Public keys are
usually propagated through certificates formed by an off-line trusted third party.
It seems a natural idea to use reputation certificates formed in an analogous way
by a trusted third party. One of the main aims of this paper is to explore how
this may best be achieved.
Reputation certificates may be controlled by users themselves. The certified
reputation value calculated from processed feedback is communicated to the rep-
utation owner after completion of transactions with its counterparts. Reputation
Ismail R., Boyd C., Josang A. and Russell S. (2004).
An Efficient Off-Line Reputation Scheme Using Articulated Certificates.
In Proceedings of the 2nd International Workshop on Security in Information Systems, pages 53-62
DOI: 10.5220/0002660200530062
Copyright
c
SciTePress
Table 1. The participants and their symbols
F T A feedback target is the entity who is being evaluated and gains the reputation
rating based on the feedback given by a feedback provider.
RP A relying party is the entity who relies on the feedback target’s reputation
rating to make a decision whether to proceed in a transaction or not.
C A The certificate authority is responsible for the registration of the feedback tar-
gets as well as to issue certificates to them.
CC/RA
The collection centre/reputation authority collects legitimate feedbacks and
uses them to calculate reputation rating and update the feedback target’s rep-
utation certificate.
AA
The attribute authority is resp onsible for issuing and signing the attributes.
certificates can be obtained from reputation owners without the need to contact
a central authority. There seem to be two natural ways to realize this proposal.
1. Employ existing identity certificate technologies, for example, X.509 [5] and
PGP [15] to incorporate reputation values.
2.
Employ a separate certificate specifically for the reputation value.
In the former option a reputation rating is regarded as one of the attributes
in the identity certificate. As a result the implementation does not require any
significant modification to the existing infrastructure. The latter, on the other
hand, requires a special authority to manage the reputation rating scheme. We
will compare the relative advantages of these different options later.
This paper prop oses an off-line reputation scheme based on public key certifi-
cates. The solution is flexible enough to accommodate most formats of reputation
rating. Different options are considered for how to bind the reputation informa-
tion with the identity of the subject. Our proposal, which we call articulated
certificates, can be applied in other situations when it is desired to augment or
update certificate information without re-issuing the identity certificate.
Organisation of the paper
Section 2 discusses the background of reputation
schemes. Section 3 discusses three basic solutions to implement binding between
identity certificates and reputation information. Section 4 describes our proposed
solution, its properties and the required protocols. Section 5 discusses the relative
merits with other options. Table 1 presents the notations and the symbols used
throughout the paper.
2 Reputation Systems
There has been considerable interest in reputation systems in recent years and
an extensive literature has developed [12]. Reputation systems may be roughly
classified into two activities.
54
Reputation calculation is the task of obtaining reputation values from a set
of feedback information. There are various properties that may be desirable
for calculation engines and reputation values may take different formats. In
this paper we are not concerned with how reputation values are calculated,
as long as they can be represented efficiently in a bit string.
Reputation propagation is concerned with how to distribute reputation val-
ues to parties that require to use them. This is the area addressed in this
paper. There are different properties that may be important, including high
availability of values and reliability. A feature that has often been neglected
is privacy of reputation values; we address this partially in this paper by
allowing owners of reputation certificates to control their distribution.
Off-line reputation propagation has been proposed by some recent authors
[4, 3]. These schemes addressed the integrity of the submitted feedbacks against
manipulation but are not suited to centralised reputation calculation. A recent
proposal of Liau et al. [7] (the LZBT scheme) demonstrated the possibility of
using certificates to represent a user’s reputation in the off-line environment. The
LZBT scheme seems promising for P2P systems because no central authority is
required to operate the scheme. However, its major limitation is that the relying
party has to contact one or more of the preceding feedback provider to verify
the validity of reputation certificates. This creates an extra burden to the service
consumers to verify the certificate.
3 Reputation certificates
Identity certificates bind the identities of users with their public keys. The cer-
tificate is issued and signed by a trusted certificate authority CA. Identity certifi-
cates are typically long term and contain several attributes such as subject name,
public key, expiry date, issuer name, and certificate holder’s name. These certifi-
cates are mainly used for authentication purposes. Attribute certificates [9], on
the other hand, are mainly used to provide access controls and role permissions
of an entity with regard to accessing resources. Therefore, these certificates are
often employed within organizational boundaries. Attribute certificates typically
do not contain the identity of an entity; instead they may contain attributes such
as role, access control, expiry date, the issuer name and the issuer signature.
A reputation rating can be considered as an attribute bound to an iden-
tity. Reputation certificates therefore need to be used in conjunction with an
identity certificate. There are various ways that this may be achieved. Park
and Sandhu [11] discussed three techniques to bind two certificates (the iden-
tity and the attribute certificate): monolithic, autonomic and chained signatures.
In the monolithic signature technique the identity and attribute certificate are
combined to become a single certificate which is signed by an authority. The
autonomic signature technique implements separate signatures: the identity cer-
tificate and the attribute certificate are signed by different authorities. To bind
the two certificates certain attributes in the identity certificate are linked to the
attribute certificate. Finally in the chained signature technique the signature of
55
authority on the identity certificate is used as a connection link between the
identity and the attribute certificates. In the next subsections we will consider
solutions which correspond roughly to this classification.
3.1 Combined Certificates
In this solution the identity certificate and reputation certificate are the same
object, and the reputation value is simply an additional attribute in the cer-
tificate. This corresponds to the monolithic certificate of Park and Sandhu [11].
Figure 1 depicts the abstract view of the solution. In this solution, the feedback
target and the feedback provider are required to register with the authority. A
reputation certificate is issued and signed by the reputation certificate authority.
The reputation certificate should be verified by the relying party.
FT
Reputation
Authority
RP
Issue & Update
Reputation
Certificate
Show
Reputation
Certificate
Fig. 1. Abstract view of Combined Reputation Certificate
The combined certificate offers several advantages; it requires no new infras-
tructure, is straightforward to implement and requires only one operation to
verify the authority’s signature. However, it has some drawbacks.
1. The reputation authority is required to issue and manage the certificates
besides its routine task to calculate the reputation of the participants.
2.
The reputation attribute b ecomes available to any party who has access
to the identity certificate. Users may prefer to hold their reputation values
privately except when needed for transactions.
3.
Reputation certificates need to be updated frequently so the identity certifi-
cate also needs to be issued each time the reputation is up dated.
A different way to form a combined certificate was the smart certificate pro-
posed by Park and Sandhu [10]. The scheme uses the structure of the X.509
certificate as its basis and the extension fields in the original certificate are used
to incorporate additional attributes. Each attribute in the certificate is managed
by different authorities. Although the smart certificate has several desirable prop-
erties, a major limitation highlighted by Chadwick and Otenko [2] is that it is
automatically invalid once any attribute is changed. We expect the reputation
rating to change frequently and the certificate needs to be re-issued each time.
3.2 Separate Certificates
The separate certificate corresponds to the autonomic certificate of Park and
Sandhu [11]. Figure 2 is a graphical representation of the solution showing the
56
two types of certificates used. The identity certificate is issued by the certificate
authority, while the reputation certificate will be issued by the reputation au-
thority. The certificates are linked due to shared information, in particular the
unique name (or X.509 distinguished name) from the identity certificate may be
included in the attribute certificate.
FT
CA
RA
RP
Identity Certificate
Show Identity Certificate
Show Reputation
Certificate
Reputation Certificate
Fig. 2. Abstract view of Separate Certificate
Because there are two authorities, separation of duties can be conducted
which can reduce the problem of overloading the reputation authority. The rep-
utation authority is only responsible for the calculation of the reputation, while
the certificate authority is responsible for the registration of the feedback targets.
The identity certificate is used as an identity mechanism for the feedback target.
Like the combined certificate solution, this solution also has its limitations.
1. It is costly to match the identity certificate and the reputation certificate
especially to the relying party RP who has to do three steps of verifica-
tion: first to check the validity of the identity certificate; second to check
the validity of the reputation certificate; third to match between these two
certificates.
2.
RP cannot determine whether RA is authorized to provide reputation for
F T s. This means that relying parties have to independently check the policy
and practice statements for any issuers of attribute certificates.
3.3 Related Certificates
The idea of related certificates is to ensure that the attribute certificate has a
functional link to the identity certificate, beyond simply referring to the same
identity. This corresponds to the chained certificates of Park and Sandhu [11].
The difference from the separate certificate option is that now the binding infor-
mation in the attribute certificate depends on the C A signature on the identity
57
certificate. In other words, the attribute certificate is bound to a specific instance
of the identity certificate.
Using an attribute certificate related to the identity certificate as the reputa-
tion certificate is a reasonable option. However, the drawbacks already mentioned
for separate certificates still apply. Independent signature checking increases the
computational burden. The issue of authorization of the RA also applies here,
but with a different twist. The issuer of attribute certificate is free to act inde-
pendently of the C Aof the identity certificate. However, C As may object to use
of their certificates by third parties for purposes without their consent and may
put in place legal obstacles to prevent this.
4 Articulated Certificates
From the discussion in section 3 we see that each of the previous proposals
for binding identity and attribute certificates has some drawbacks when used
for reputation certificates, although separate certificates or related certificates
could be reasonable choices. In this section we proposed a new scheme for linking
reputation and identity certificates. We called this an articulated certificate.
User Public Key
Expiry Date
Serial Number
CA ID
RA
1
ID
RA
2
ID
RA
n
ID
CA signature
Basic Certificate
User ID
Reputation Rating
RA
1
ID
RA
1
signature
User ID
Reputation Rating
RA
2 
ID
RA
2
signature
User ID
Reputation Rating
RA
n 
ID
RA
n
signature
Reputation
Certificate
Fig. 3. Abstract View of Articulated Certificate
Figure 3 illustrates the view of the proposed scheme. The properties of ar-
ticulated certificates are different from all the options considered in section 3.
Articulated certificates can only be issued by entities that have been autho-
rised to do so by the identity C A. Moreover, the authority to issue may be
restricted for a specific purpose or particular time interval.
The articulated certificate can be verified using the C Apublic key alone
no separate certificate is required for the reputation authority.
The identity certificate may be used either with or without the attribute
certificate.
58
A major feature of our proposed solution is to use the concept of delegation
to allow the certification authority to give power to the reputation authority
to link to the original certificate. Delegation enables RA to update reputation
rating in the certificate without invalidating the certificate. The C A delegates
his signing capability to RA using the proxy signature scheme. Figure 4 shows
the abstract view of the proposed architecture.
FT
CA
RA
RP
Delegate
Signature
Issue Certificate
Show
Certificate
Update Certificate
Fig. 4. Proposed Architecture
4.1 Proxy Signatures
Proxy signature schemes allow an original signer to delegate signing capability to
another entity, the proxy signer. The first proxy signature scheme was introduced
by Mambo et al. [8]. Subsequently a number of schemes have been proposed in
the literature [14, 6]. For our purpose the scheme of Mambo et al. (MUO scheme
hereafter) will be employed. However, other proxy signature schemes can also be
used in our proposal. A brief review of MUO scheme follows.
System Settings: Global system parameters consist of a large prime p, a
prime factor q of p 1, and an element g Z
p
of order q. Computations take
place in Z
p
unless indicated otherwise. Entity A denotes the original signer and
B denotes the proxy signer. Assume that x
A
is a private key for A and the
corresponding public key y
A
= g
x
A
and m
w
is a statement about delegation
which typically contains some particulars including the proxy signer identifica-
tion. A one way hash function H() is used. The scheme can be divided into four
phases; generation of a proxy key, verification of the proxy key, signing using the
proxy key and verifying the proxy signature. A small modification is made to
the original of MUO scheme to include the hash of m
w
.
Generation of a proxy key.
A chooses a random number, k
R
Z
q
and com-
putes r = g
k
. He proceeds to compute s
P
= x
A
H(m
w
) + kr mod q and then
sends (s
P
, r) to B securely.
Verification of the proxy key.
Upon receiving (s
P
, r), B verifies g
s
P
?
= y
H(m
w
)
A
r
r
.
If this equation holds B accepts it is a valid proxy key.
59
Signing using the proxy key. B signs message m using the proxy key s
P
.
The signed message is S(m), r where S() is any discrete log signature gen-
eration algorithm.
Verifying of the proxy signature. A verifier first calculates y
P
= y
H(m
w
)
A
r
r
and checks the validity of the proxy signature V ( y
P
, message)
?
= true where
V () is a the signature verification algorithm.
Since MUO scheme is employed, the properties of the scheme of MUO are
automatically inherited into our proposal.
1.
Unforgeablity Besides C A, only RA can create a valid proxy signature.
The third parties who are not designated as a proxy signer cannot create a
valid proxy key.
2. Verifiability RP can be convinced of the original signer agreement on the
signed message.
3. Identifiability Anyone can determine the identity of the proxy signer from
a proxy signature.
4. Undeniability Once the proxy signer creates a valid proxy signature he
cannot repudiate it.
4.2 Protocol of the Scheme
The protocol consists of six phases as follows. Execution of the phases is not
necessarily in sequential order, except that the delegation and registration phases
have to be executed prior to the other phases. Some phases may need to be
executed more than once, such as updating certificate, showing certificate and
validating certificate.
Delegation C A delegates signing capability to RA so that RA can update
the certificate of F T with a new reputation rating. It is assumed that both
parties C A and RA have already agreed upon the terms and conditions of
delegation beforehand which are encoded in m
w
. To delegate, C A executes
the generation phase of the MUO scheme by choosing a random number k
and computes r
RA
= g
k
. This is followed by computing s
RA
= x
CA
H(m
w
)+
kr
RA
mod q and sends (s
RA
, r
RA
) to RA securely. On receiving this pair RA
verifies g
s
RA
?
= y
CA
H(m
w
)r
r
RA
RA
. If this holds RA accepts it is a valid proxy
key.
Registration F T creates a public key y
F T
and the corresponding private
key x
F T
. y
F T
and ID
F T
are securely sent to C A for registration. A typical
certificate format of the basic certificate may be as follows:
Sig
CA
F T
y
F T
Exp
CA
RA
where Sig
CA
denotes the CA’s signature and Exp denotes expiry date of
the certificate, On receiving F T ’s particulars, C A verifies their validity. The
certificate is signed by C A using his private key x
CA
and is sent to F T .
60
Notice that it is not essential to include the identity of the reputation au-
thorities with the identity certificate, as shown above. Instead, the RA may
be identified separately to the relying party by the certificate owner.
Sending Identity Certificate F T is required to send his identity certifi-
cate to RA for the initial contact. It can then be recorded in a database
maintained by RA until a new identity certificate is issued.
Updating Reputation Certificate
To prevent unnecessary updating, statistics of activity of the feedback target
may be used to determine when the reputation rating should be updated.
An active user may be given a short expiry date while an inactive user has a
longer one. To issue a new reputation certificate RA signs it using the proxy
private key s
RA
. The certificate is sent to F T . A typical certificate format
of the articulated certificate may be as follows.
Sig
RA
ExpR
F T
RA
F T Rating
where Sig
RA
is the signature of RA and ExpR denotes the expiry date of
the reputation rating,
Showing Certificate Before any engagement with the intended RP , F T
may be required to show his reputation certificate to RP so that his repu-
tation can be evaluated.
Validating Reputation Rating Prior to accepting the rating in the rep-
utation certificate, RP calculates y
RA
and verifies the certificate validity
based on signature to the conditions in m
w
. If so RP accepts the reputation
rating as a valid reputation rating.
5 Discussion
There are several advantages held by our scheme compared to other schemes.
Only one operation is required to verify the reputation certificate, as only the
RA’s signature needs to be checked by the relying party while the validity of
the identity certificate is verified by RA. This advantage is also shared by the
basic certificate. Separate certificates and related certificates, on the other
hand, require three computations to verify the validity of both certificates.
There is a separation of duties between the identity CA and reputation
authority. This is generally a good security practice, and ensures that neither
is overloaded with management tasks.
Our scheme implements tightly-coupled binding between the identity and
reputation certificates because a single identity certificate may be mapped
to multiple reputation certificates. This advantage is shared by the combined
certificate while the separate certificate implements loosely-coupled solution.
Our proposal has high reusability because changes to the reputation certifi-
cate or the identity certificate cannot invalidate the reputation certificate.
This is shared by the separate certificate while the basic reputation and the
related certificates have low reusability because any changes invalidate them.
61
References
1. G. Bolton, E. Katok, and A. Ockenfels. How Effective are Online Reputation
Mechanisms? Discussion Papers on Strategic Interaction 25-2002, Max-Planxk-
Institut, 2002.
2.
D. W. Chadwick and A. Otenko. The permis X.509 role based privilege manage-
ment infrastructure. Future Generation Computer Systems, 19(2):277–289, Febru-
ary 2003.
3.
D. Fahrenholtz and W. Lamersdorf. Transactional security for a distributed repu-
tation management system. In Proceedings of the 3rd International Conference on
Electronic Commerce and Web Technologies, volume 2455 of LNCS, pages 214–223.
Springer-Verlag, 2002.
4. M. Gupta, P. Judge, and M. Ammar. A reputation system for peer-to-peer net-
works. In ACM 13th International Workshop on Network and Operating Sys-
tems Support for Digital Audio and Video (NOSSDAV 2003), pages 144–152. ACM
Press, June 1-3 2003.
5.
ITU-T. Recommendation X.509 Information technology - Open systems Intercon-
nection - The Directory : Authentication framework, 1997.
6. B. Lee, H. Kim, and K. Kim. Strong proxy signature and its applications. In
SCIS’2001, pages 603–608, Jan 23-26 2001.
7.
C. Y. Liau, X. Zhou, S. Bressan, and K.-L. Tan. Efficient distributed
reputation scheme for peer-to-peer systems. In The 2nd International Hu-
man.Society@Internet Conference, volume LNCS 2713, pages 54–63. Springer-
Verlag, 2003.
8. M. Mambo, K. Usuda, and E. Okamoto. Proxy signatures for delegating signing
op eration. In Proceedings of the 3rd ACM conference on Computer and communi-
cations security, pages 48–57. ACM Press, 1996.
9.
R. Oppliger, G. Pernul, and C. Strauss. Using attribute certificates to implement
role-based authorization and access controls. In Proceedings of the 4. Fachtagung
Sicherheit in Informationssystemen (SIS 2000), Z¨urich (Switzerland), pages 169–
184, October 5-6, 2000.
10. J. S. Park and R. Sandhu. Smart certificates: Extending X.509 for secure attribute
service on the web. In Proceedings, 22nd National Information Systems Security
Conference, pages 337–348, October 18-21 1999.
11.
J. S. Park and R. Sandhu. Binding identities and attributes using digitally signed
certificates. In 16th Annual Computer Security Applications Conference (ACSAC),
pages 120–127, December 11-15 2000.
12.
P. Resnick, R. Zechauser, E. Friedman, and K. Kuwabara. Reputation systems.
Communication of the ACM, 43(12):45–48, December 2000.
13. P. Resnick, R. Zeckhauser, J. Swanson, and K. Lockwood. The value of reputa-
tion on eBay: A controlled experiment. In Working paper presented at the ESA
conference, June 2002.
14.
S. P. S. Kim and D. Won. Proxy signatures, revisited. In Proc. of ICICS’97,
International Conference on Information and Communications Security, volume
LNCS 1334, pages 223–232. Springer, 1997.
15.
P. R. Zimmermann. The Official PGP User’s Guide. MIT Press, Cam-
bridge, MA, USA, 1995. Available at http://www-mitpress.mit.edu/mitp/recent-
b ooks/comp/pgp-user.html.
62
