New S/Key System against Dictionary Attack :

A Case Study in Casper and CSP/FDR

Il-Gon Kim and Jin-Young Choi

Department of Computer Science and Engineering,

Korea University

SEOUL, 136-701 KOREA

Abstract. S/Key(One-Time Password) system has vulnerabilities such

as dictionary attack. In this paper, we propose a corrected S/Key system

mixed with EKE to solve the man-in-the-middle attack. In addition, we

specify a new S/Key system with Casper, verify its secrecy and authen-

tication properties using CSP/FDR.

Keywords: Casper, CSP, FDR, S/Key, EKE, Dictionary Attack

1 Introduction

S/Key system has the vulnerability, which an intruder can guess a passphrase

used in generating an one-time password, comparing the resulting 128 bit hash

with variation lists to the dictionary ﬁles[2]. For the secure key exchange of

passphrase, we compose EKE[7] protocol with S/Key system[6]. Second, for the

robustness of passphrase, the new S/key system uses a large random passphrase.

In this paper, we specify a new S/Key with Casper, translate its high level

description into CSP[4] code, and ﬁnally verify its secrecy and authentication

properties with FDR[3]. Finally we check a random passphrase’s robustness using

password cracking tool. In section 2, we give an overview of a new S/Key model.

In section 3, we talk about analyzing and verifying a corrected S/Key system

using Casper[5] and CSP/FDR. We sum up in section 4.

2 A new S/Key System

In this paper, we focus on the new S/Key system against the oﬄine attack. As

mentioned before, to prevent passphrase from dictionary attack, passphrase must

be secret between client and server. In order to satisfy the secrecy requirements,

we modify S/Key system with a secure EKE. Secondly, passphrase must be ran-

domized, not guessable. We combine EKE with challenge & response protocol in

S/Key, exception with applying other variants to it because other variants are

Kim I. and Choi J. (2004).

New S/Key System against Dictionary Attack : A Case Study in Casper and CSP/FDR.

In Proceedings of the 2nd International Workshop on Veriﬁcation and Validation of Enterprise Information Systems, pages 75-77

DOI: 10.5220/0002677500750077

 SciTePress

2 Il-Gon Kim et al.

more complex, less eﬀective in the tradeoﬀ between security and traﬃc perfor-

mance. Therefore, ﬁrstly we ﬁnd the vulnerabilities of EKE protocol based on

[1], then modify it. Example 1 shows a new S/Key authentication mechanism

against dictionary attack.

Example 1. New S/key System

Message 1: A → B:A,{PK(a)}K

Message 2: B → A:{B, Challenge}PK(a)

Message 3: A → B:{Na}K

Message 4: B → A:{B,N

, P assphrase

Message 5: A → B : Response

PK(a) is a public key of host A, K

is a secret password between A and

B, Challenge is a random number including seed and sequence number, N

a random number generated by host A. The Response is a hash function of

one-time password generated by host A. P assphrase

is a random session key

to generate one-time password used in authenticating a correct user. The most

important characteristics in a new S/Key system, diﬀerently from that of the

previous one, are the encryption of B identity with PK(a) and P assphrase

with K

. Therefore, the intruder can’t be disguised as a legitimate agent and

get hold of the plaintext passphrase.

3 Analysis and Veriﬁcation of new S/Key system

Based on message sequences shown in section 2, we write the new S/Key system

in Casper script. A corrected S/Key system is as belows.

#Protocol description

0. -> a : b

1. a -> b : a, {ServerKey(a)}{passwd}

2. b -> a : {b, challenge}{ServerKey(a)}

3. a -> b : {na}{passwd}

4. b -> a : {b,passphrase}{passwd}

5. a -> b : F(otp)

The Speciﬁcation section is used to specify the requirements of the proto-

col. In order words, Speciﬁcation section deﬁnes the speciﬁcation model that

describes secrecy and authentication properties. We assume that the intruder

is a user of the computer network, and so can take part in normal runs of the

protocol, and other agents may initiate runs of the protocol with him.

#Specification

Secret(a, na, [b])

Secret(b, challenge, [a])

Agreement(a, b, [na, challenge, otp])

Agreement(b, a, [na, challenge, otp])

Title Suppressed Due to Excessive Length 3

The lines starting Secret specify secrecy property.InCSP,asecrecy property

can be formalized as signal.Claim

Secret.a.b.s event. This may be understood

to mean; ‘The secret value s used in the run between a and b, which was initi-

ated by a should be secret for the entire protocol run’. If the secrecy property is

satisﬁed in the model, then the intruder should not be able to obtain access to

the secret value, s. Secret(a, na, [b]) may be paraphrased as: ‘a thinks na is a

secret that can be known to only a and b’. In like manner, Secret(b, challenge,

[a]) represents that ‘a thinks challenge is a secret that can be known only b

and a’. The lines starting with Agreement deﬁne that authentication property.

In CSP model, an authentication property can be observed from two viewpoints;

one is the authentication of the initiator by the responder,while the other is the

authentication of the responder by the initiator. The Agreement(a, b, [na, chal-

lenge, otp]) means that ‘a is authenticated to b based on the agreement with na,

challenge, otp values between two hosts. Also the Agreement(b, a, [na, challenge,

otp]) implies that ‘b is authenticated to a based on the agreement with na, chal-

lenge, otp values between two hosts. After running FDR tool, we conﬁrm that

new S/Key system satisﬁes security properties of secrecy and authentication.

4 Conclusion

S/Key is a very famous authentication system that uses a one-time password

scheme to protect a malicious attacker from replay attack. But with the great

development of PC’s computation power, we unfortunately are confronted by

a various threat factors. Moreover, vulnerabilities of S/Key were reported by

many researchers. Among them, one of the most eﬀective attacks is to sniﬀ a

seed and sequence number from client, then guess passphrase using dictionary

attack tool. In this paper, we point out the weakness of an original EKE protocol

and modify it. We combine a corrected EKE with S/Key and propose a new

S/Key system against dictionary attack. And we specify and verify its secrecy

and authentication properties using Casper and CSP/FDR.

References

1. J. Clark and J. Jacob, A survey of authentication protocol literature: Version 1.0,

Available via http://www.win.tue.nl/˜ecss/downloads/clarkjacob.pdf, 1997.

2. L.Chen and C.J.Mitchell, Comments on the S/KEY user authentication scheme,

ACM SIGOPS Operating Systems Review, Volume 30, Issue 4.,1996.

3. Formal Systems(Europe) Ltd, Failure Divergence Reﬁnement-FDR2 User Manual,

Aug. 1999.

4. C.A.R. Hoare, Communicating Sequential Processes. Prentice-Hall, 1985.

5. G. Lowe, Casper: A compiler for the analysis of security protocols, 10th IEEE

Computer Security Foundations Workshop, 1997.

6. N. Haller, “The S/Key one-time password system,” RFC 1760, 1995.

7. S. M. Bellovin, M. Merritt, Encrypted Key Exchange: Password-Based Protocols

Secure Against Dictionary Attacks, AT&T Bell Laboratories. Proceedings of the

1992 IEEE Computer Society Conference on Research in Security and Privacy,

May 1992.
