Towards a Services Platform for Mobile Context-
Aware Applications
Patrícia Dockhorn Costa
1
, Luís Ferreira Pires
1
, Marten van Sinderen
1
and José Gonçalves Pereira Filho
2
1
Centre for Telematics and Information Technology, University of Twente,
PO Box 217, 7500 AE Enschede, the Netherlands
2
Universidade Federal do Espírito Santo, Dept. de Informática,
Av. Fernando Ferrari s/n, CEP 29060-900 Vitória (ES), Brazil
Abstract. Context-aware services platforms aim at supporting the handling of
contextual information in order to provide better user-tailored services. This
paper proposes a novel services platform architecture to support mobile
context-aware applications, giving emphasis to the configurability of the
platform’s generic functionality. The paper introduces concepts and a language
to cope with configurability aspects. The paper also reports on the
implementation of this architecture in the WASP
a
platform, which is a Web
services-based context-aware services platform that runs on top of 3G
networks.
1 Introduction
Context-awareness has emerged as an important and desirable feature in distributed
mobile applications. This feature deals with the ability of applications to utilize
information about the user’s environment (context) in order to dynamically select and
execute relevant services that better match the user needs [2]. In a ubiquitous
environment, with many services available at any time, context information is
especially important to help determining which services are relevant for the user [4].
Building context-aware systems involves the consideration of several new
challenges mainly related to the gathering/sensing, modelling, storing, distributing
and monitoring of contextual information. These challenges motivate the need for
proper architectural support.
There have been many initiatives towards architectural support for context-aware
applications. In particular, considerable effort has been spent on the development of
infrastructure software to support the development and/or operation of context-aware
applications. Infrastructure software comprises code libraries or runtime
environments that provide high-level abstractions to shield application developers
from the interactions with (lower-level) data repositories, hardware devices and
a
The WASP (Web Architectures for Service platforms) project is funded by the Freeband
Knowledge Impulse joint initiative of the Dutch government, knowledge institutes and industry.
Dockhorn Costa P., Ferreira Pires L., van Sinderen M. and Gonçalves Pereira Filho J. (2004).
Towards a Services Platform for Mobile Context-Aware Applications.
In Proceedings of the 1st International Workshop on Ubiquitous Computing, pages 48-61
DOI: 10.5220/0002680300480061
Copyright
c
SciTePress
software constructs [4]. Among these infrastructures, we have seen the emergence of
context-aware services platforms, which aim at providing support for application
designers to conceive their applications by using services, mechanisms and interfaces
that shield them from the complexity of handling contextual information [3].
Currently available platforms, however, offer a limited level of configurability.
Ideally, a platform for context-aware applications should facilitate the creation and
the dynamic deployment of a large range of context-aware applications that are
unanticipated during the design of the platform. In this paper, we define a services
platform architecture for context-aware applications, giving emphasis to the
configurability and extensibility of the platform’s generic functionality. We present a
descriptive language, coined WSL (WASP Subscription Language), which enables
applications to dynamically configure the platform to fulfil their needs.
The remainder of this paper is structured as follows: Section 2 gives an overview
of our proposed context-aware services platform, Section 3 defines the concepts
applied in the platform development, Section 4 describes WSL, Section 5 introduces
the platform components, Section 6 presents the prototype and an application
example, and Section 7 gives final remarks and identifies topics for further study.
2 Overview of the Services Platform
The services platform forms the system environment for context-aware mobile
applications. It supports the scenario in which context information is gathered from
Context Providers (sensors or third-party information providers) and services are
implemented by third-party service providers.
The services platform aims at delivering the most adequate services based on both
application requirements and contextual facts (see Fig. 1). Applications describe their
requirements by defining the desired services and the contextual conditions in which
the services should be provided. The platform should autonomously react to reaction
rules, which are defined in terms of conditions to be checked against contextual facts.
Services
Platform
service capabilities
(service
descri
p
tion
)
contextual facts
(context information)
Context
Providers
Mobile C
A
Applications
Third Party
Services
a.o. mobile network
services providers
application requirements
(user needs)
Fig. 1. Overview of the services platform
In [3] we have identified the essential requirements to be satisfied by the services
platform, which include:
49
Context handling: the platform should provide efficient mechanisms to gather,
store, distribute and monitor contextual information;
Reactive behaviour: the platform should allow the specification of reaction rules.
Moreover, it should be able to react according to the specified rules;
Configurability: the platform should be able to support context-aware applications
that are unanticipated during platform design. For that, mechanisms of
configurability and the use of generic components need to be considered.
We have addressed all these requirements when designing the platform architecture,
but most of our efforts have been spent on developing an architecture with a high
level of configurability. The proposed solution includes the definition of a
subscription language, which allows applications to dynamically expose their needs to
the platform.
Fig. 2 depicts the proposed services platform architecture, which contains three
main components: Monitor, Registry and Context Interpreter.
SERVICES PLATFORM
Registry
Monitor
Parser
Subscription
Manager
EntityType
Registry
FunctionType
Registry
ContextDB
Re
g
istr
y
Context Interpreter
ActionType
Registry
Entity
Re
g
istr
y
User Profile
Re
g
istr
y
C
A
A
P
P
L
I
C
A
T
I
O
N
S
S
E
R
V
I
C
E
P
R
O
V
I
D
E
R
S
CONTEXT PROVIDERS
Fig. 2. Services platform architecture
The Context Interpreter gathers contextual information from Context Providers
(sensors or third-party providers), manipulates contextual information and makes it
uniformly available to the rest of the platform. The Registry maintains information
necessary to support the interpretation of application requirements and the execution
of services. The Monitor is the core of the platform, since it is responsible for
receiving and interpreting application requests and making them active within the
platform.
50
In our approach, applicationļplatform interactions are dynamically configured
through the definition of application subscriptions. In a subscription, an application is
capable of dynamically exposing its requirements to the platform, which composes at
runtime new tailored services from the set of available services.
The services platform architecture proposed in this paper has been designed and
implemented in the WASP (Web Architectures for Services platforms) project. The
prototype implementation is referred to as the WASP Platform. The WASP project is
concerned with the definition and validation of a services platform to facilitate the
development and deployment of mobile context-aware applications, called WASP
applications, on top of 3G networks [7], using Web Services technologies [12]. The
3G networks provide the telecommunication infrastructure for mobile terminals. In
addition, a 3G network can play the role of a Context Provider, since it is able to
provide the current location of its users. 3G network functions are accessed using the
Parlay X [8], a Web services interface. Web Services technologies are used to support
applicationļplatform and platformļservice provider interactions.
3 Concepts
In order to effectively and consistently manipulate the contextual knowledge of the
platform, we need to organize, represent, and describe it in a model. For this purpose
we have introduced a context model. Whenever such a model is available, it can be
used as basis for common understanding between platform and applications
developers, and service providers.
3.1 The Platform Context Model
The services platform manipulates data entities, which represent objects of the real
world (users, restaurants, museums, roads, vehicles, etc.). Attributes (age, area,
address, etc.) and Context (time, location, activity, etc.) are associated with data
entities.
The UML class diagram depicted in Fig. 3 shows a possible configuration of the
context model proposed for the platform. This diagram shows only an example
configuration, with entities restaurant and user, and their relationship with the
location context. The model can be extended if required by the applications, by
(dynamically) adding new entity types, such as, e.g., museum and supermarket and
context types, such as, e.g., time and activity.
The model presents three instantiation levels, namely a metamodel, a model and an
object level. The metamodel level is embedded in the platform and is defined during
the platform design-time, but remains unchanged during runtime. The model and the
object levels can be dynamically changed during runtime. They represent instances of
the metamodel and the model levels, respectively. The context model is discussed in
more detail in [2].
51
Entity Type Context Type
Use
r
Location
«instance»
«instance»
Restaurant
Model
Restaurant:Location
**
Model
User:Location
**
«instance»
AccessModelType
**
«instance»
«instance»
Metamodel
Model
LosPonchos 123, 3425 John
«instance»
«instance» «instance»
Pinochio
«instance»
A
lice
«instance»
Objects
Fig. 3. Context Model
Fig. 3 shows a model configuration in which entities types Restaurant and User
(model) are instances of Entity Type (metamodel). Moreover, the context Location
(model) is instance of Context Type (metamodel). Similarly, Pinochio and
LosPonchos (object) are instances of entity Restaurant (model) and Alice and John
(object) are instances of entity User (model).
(Hierarchical) relations between entity types can also be defined, varying from
simple categorizations of entity types to complex ontologies [9]. A common
representation of this knowledge is essential for the interoperability of the platform
and its environment.
3.2 Services
We have defined two types of service units to be used as building blocks for services
in the platform: (i) service units that reason about contextual circumstances, which we
call functions and (ii) service units that are triggered and react to some determined
contextual fact, which we call actions.
A function is a service unit that performs a computation with no side-effects, i.e.,
the computation does not change the current status of the platform. An example of
function is the isInside operation, with parameters of type container and person.
This functions returns true if the given person instance is inside the given container
instance, and false otherwise.
An action is a service unit that performs a computation with side-effects for one or
more parties involved in the system. An example of action is the sendAmbulance
52
operation, which sends an ambulance to a physical place. The invocation of functions
and actions follows the request-response pattern.
Functions and actions are composed together by the platform to form new services.
The service compositions are described by the applications, by means of applications
subscriptions written in WSL.
4 The WASP Subscription Language (WSL)
WSL is a descriptive language that we have developed in order to be able to specify
application subscriptions. Initially, we identified two essential requirements with
respect to the elements of this language: (i) a way to specify the reactions of the
platform to stimuli from the environment and (ii) a way to correlate events that
eventually trigger the specified reactions.
Subscriptions can be either parameterized or not. Parameterization is necessary
when the rule (subscription) applies to a collection of entities, since it would be
cumbersome to write a subscription for each target entity. Sometimes it is also
necessary to select entities of a collection for which a certain condition holds.
We illustrate the WSL clauses in the sequel by means of examples that use the
functions count and IsInside, and the action sendSms. Count returns the
number of elements in a collection; IsInside returns true if an entity is inside a
given container, and false otherwise; and sendSms sends a message to a set of users.
The WSL (abstract) syntax has been completely specified in [2], using both EBNF
and UML class diagrams.
4.1 The SELECT clause
The SELECT clause returns a collection of entities for which a given filtering
expression holds true. This clause allows the selection of a subset of a collection that
respects a filtering condition defined as a logical combination of contextual facts
and/or attributes. Its abstract syntax is as follows:
SELECT (<collection-of-entities>; <var>;
<filtering-expression-involving-var>)
A select clause that returns a collection of users currently located in the city of
Enschede can be defined as:
SELECT (entity.user.*; u; u.location.city ==
"Enschede")
where entity.user.* represents the collection of all users in the system, u is the
variable to designate the elements of the collection and u.location.city ==
"Enschede" is the logical expression that filters the designated collection of users
by selecting the ones that are in Enschede.
53
4.2 The ACTION-GUARD clause
The ACTION-GUARD clause defines that one or more actions should be triggered as
a consequence of a correlation of events. This clause allows one to represent actions
that are performed by the platform as a reaction to stimuli defined in a logical
expression. Its abstract syntax is as follows:
ACTION <action> [GUARD <correlation-of-events>]
An action to send an SMS message to a user if he is inside a movie theatre can be
defined as:
ACTION SendSms (entity.user.John,
"Hey John, Cola and movie, a perfect combination!");
GUARD
(count (SELECT (entity.cinema.*; c;
( isInside(entity.user.John, c) AND
(c.location.city == "Enschede") ) )
) > 0 )
The statement above defines that a message should be sent to John if John is inside a
movie theatre and this movie theatre is located in Enschede. The SELECT clause is
used to select a collection of movie theatres in Enschede where user John currently is.
The selected collection has 0 or 1 element (either the user is in one or in zero movie
theatres). If the user is inside a movie theatre, an advertisement is sent; otherwise the
action is not triggered.
An ACTION-GUARD clause can be used to define an application subscription,
since it tells the platform which correlation of events has to be monitored, and which
actions should be triggered.
4.3 The SCOPE clause
The SCOPE clause defines a collection of target entities for which the subscription
defined in a nested ACTION-GUARD clause should be applied. The SCOPE clause
has been introduced to support subscription parameterization. Its abstract syntax is as
follows:
SCOPE (<collection-of-entities>; var){
ACTION <action-involving-var>
[GUARD <correlation-of-events>]}
The SCOPE clause can be used to define the scenario "Send an advertisement to every
user inside the movie theatres in Enschede" in the following way:
SCOPE ((SELECT (entity.user.*; u2; u2.location.city ==
"Enschede")); u)
{
ACTION SendSms (u,
"Cola and movie, a perfect combination!");
GUARD
( count (SELECT (entity.cinema.*; c;
(isInside(u,c) AND
54
(c.location.city == "Enschede") ) )
) >0 )
}
The SELECT clause returns a collection of users located in Enschede in that given
moment. The nested ACTION-GUARD clause applies to each of the selected users,
which are named u in the SCOPE clause.
5 Platform Components
The three main components of the services platform architecture are the Context
Interpreter, the Registry and the Monitor.
5.1 Context Interpreter
The Context Interpreter gathers contextual information from Context Providers
(sensors or third-party providers) and makes it uniformly available to the rest of the
platform. The interpreter may also perform:
Context aggregation: the context interpreter provides contextual information about
a certain entity by gathering and aggregating context from a set of context
providers, if necessary;
Context inference: the context interpreter infers context from other contexts.
Inference rules may be used to perform this activity.
5.2 Registry
The Registry component consists of a collection of registries that contain and
maintain the information represented in the data entity model (see Fig. 3). These
registries provide essential information to support the deployment of applications in
the platform. We have defined six registries:
Entity Type Registry: stores entity types, and their correspondent attributes and
context types. Examples of entity types are person, cinema, restaurant and
museum; examples of attributes are age and address; examples of context types are
location, velocity and activity. Some types of contexts apply only to specific entity
types. For example, velocity may be applied to a person but not to a movie theatre.
The Entity Type registry manages all possible combinations of context types and
entity types, being the actual representation of the Model level of the context
model;
Entity Registry: stores instances of entity types. For example, it might store the
instances Alice and John of the entity type person, and Pizza Hut of entity type
restaurant;
Function and Action Type Registries: store, match and retrieve functions and
actions profiles, respectively. Actions and functions are published and
implemented by third-parties service providers;
55
User Profile Registry: manages user profiles. Significant facts can be collected
directly from the user profiles, like, e.g., as gender, date of birth, name,
preferences, etc. These facts can be considered as contextual information, in the
sense that they describe the environment in which a user operates;
ContextDB Registry: preserves contextual information over time (history). Keeping
context history is essential to allow context inference based on past occurrences.
5.3 Monitor
The core of the platform architecture is the Monitor module, which is responsible for
interpreting and managing the application subscriptions. In order to perform its
operations, the Monitor makes use of the data available in the Registry and the
contextual information provided by the Context Interpreter.
Applicationļplatform interactions are dynamically configured through the
definition of application subscriptions written in WSL, as discussed in Section 4.
Using WSL one can refer to entities (their context and attributes) and the combination
of actions and functions in order to express the desired service in terms of a
subscription. Furthermore, new entities, context, attributes, actions and functions can
be added to the platform on demand. This implies that different forms of possibly
complex services can be composed and deployed at runtime by the platform, making
it highly configurable.
The Monitor contains a Parser and a Subscription Manager component.
Parser. The Parser component is responsible for verifying whether the subscriptions
are syntactically and semantically correct, having as reference the syntax of WSL [2].
The parsing result is a tree containing WSL primitive elements. There are two levels
of semantic checking:
1. A model checking level using the platform entity metamodel (Fig. 3). At this level,
the Parser verifies the existence of the entity types and whether the combinations
of context type and entity type are meaningful. Furthermore, the Parser needs to
verify the semantics of functions and actions;
2. An instance checking level using the instance repositories to check the existence of
the entities (final instances).
Subscription Manager (SM). The SM provides an interface for applications to add,
remove or update subscriptions. Furthermore, applications should provide a
notification interface for possible callbacks from the platform. Fig. 4 depicts the
internal structure of the Subscription Manager.
Applications subscribe to the platform by dynamically adding application
subscriptions. Moreover, existing application subscriptions can be updated or
removed. An added or updated subscription is parsed and verified for syntax and
semantic integrity. If no errors are found, the subscription is forwarded to the event
handler, which constantly checks the condition in the GUARD clause. The frequency
in which checks are performed depends on how often contextual information is
56
provided by the Context Interpreter. In general, the GUARD clause is checked
whenever notifications of context changes are received from the Context Interpreter.
Subcription Manager (SM)
a
b
c
e
NotifyApp
Event-driven
subscription
Non-parsed
subscription
OK/
Error
Action (user)
GUARD
clause is true
Add,
remove,
update
subscription
NotifyApp
a
d
Metamodel
and model
information
Context
Context
a) Applications interface
b) Parser interface
c) Context Interpreter interface
d) Repositories interfaces
e) Parlay Web Services Interface
Event
Handler
P
R
O
X
Y
Action
Executor
Fig. 4. Subscription manager
When a condition in the GUARD clause becomes true, the corresponding action is
triggered, which could be a simple callback to the application or a more complex task
on the users’ device. Fig. 5 shows the interactions that take place in the Subscription
Manager in order to handle a subscription.
A
pplication Proxy Parse
Events
Verifie
r
Action
Executo
r
User
req(service:Service)
add(subs:Subscription)
send(event_subs:Subscription)
send(subs:Subscription)
send(ok:bool)
send(ok:bool)
send(event_subs:Subscription)
sendSMS(msg:String)
Fig. 5. Interactions necessary for handling a subscription
In Fig. 5 the user requests a service to the application, which consists of sending
him a message in case one of his colleagues is close to him. The application describes
57
the service composition by means of a subscription and adds it to the platform. The
Proxy gets the subscription and asks the Parser to check it. Once the subscription is
checked, it is forwarded to the EventVerifier. The EventVerifier checks whether there
is a colleague of the user close by him. In case this condition becomes true, the
ActionExecutor triggers the sendSMS action.
6 Validation Scenario
The main goal of the services platform prototype built in the WASP project has been
to demonstrate and validate the concepts and the main architectural elements. In this
prototype we have focused on the applicationļplatform interactions.
6.1 Prototype
We have prototyped the Monitor (Subscription Manager and the Parser), some of the
Registries and a simplified Context Interpreter. The applicationļplatform and
platformļcontext provider interactions have been implemented. The prototype does
not include the implementation of the platformļservice providers interactions.
Essential actions and functions have been hard-coded in the platform with which our
scenarios have been performed (mainly location-aware scenarios). Future
implementations of the prototype will consider these interactions, by implementing
the action type registry and function type registry. Service discovery can also be
implemented, e.g., by using UDDI [13].
We have defined an XML Schema that represents the WSL syntax [2], so that
application subscriptions can be written as XML documents and validated using this
WSL XML Schema. The WSL parser reads application subscriptions in XML format
and maps them into Java classes, which are automatically compiled and executed
during runtime.
We have used Web Services technologies and Java language for implementing the
prototype. The WASP platform interface is offered as a web service end-point,
allowing the operations to be remotely called by the platform applications.
Furthermore, we also have implemented the users’ terminals as a web service end-
point to allow callbacks from the platform. We have used JAX-RPC [10] to
automatically generate the WSDL file from Java interfaces and the W3C’s Document
Object Model (DOM) [11] to develop our XML-based WSL parser.
6.2 Example: Taxicab Application
We illustrate the use of the platform with a context-aware taxicab application. Users
request a taxicab directly at the taxicab company’s web site with no need to inform
their current location. Furthermore, users get a message when the requested taxicab
approaches their location. Fig. 6 depicts the sequence diagram of this scenario.
58
(1)
(2)
(3)
(3)
(3)
(3)
(4)
(5)
(6)
.
.
.
(7)
John:
User
TaxiCab:
App
Platform
Context
Provider
Fig. 6. Sequence diagram for the taxicab scenario
Table 1 gives the messages that correspond to the numbering in Fig. 6.
Table 1. Exchanged messages in the taxicab scenario
Message
Number
Message Contents
(1) “I need a cab”
(2)
ACTION
NotifyApp( bookTaxicab
(SELECT (entity.taxicab.*; tc;
(CloseBy (tc, entity.user.John,
3000)) AND
(tc.company = "ABC"))));
(3) John’s location and taxicabs’ locations
(4) The booked taxicab identification and the approximate taxicab
arrival time
(5) “The taxicab will arrive in approximately 5 minutes”
(6)
ACTION
SendSMS(entity.user.John,
"Your taxicab has arrived.");
GUARD
CloseBy(entity.user.John,
entity.taxicab.cab1234, 50)
(7) SMS with the text “your taxi has arrived”
In Table 1, message (1) represents the user request for a taxicab. Message (2) is the
application subscription in WSL for a service composed using actions NotifyApp
and bookTaxicab, and function closeby as building blocks. Action
NotifyApp causes a callback from the platform to the application, in which the
results of action bookTaxicab are informed. These results are the identification of
the taxicab and an approximate arrival time. Besides returning this information,
59
bookTaxicab is a third-party service that books a taxicab from a given collection.
We assume in this scenario that the context provider is able of providing the current
locations of taxicabs and users (message (3)).
An extra service offered by this context-aware taxicab application is that the user
gets a message when the taxicab approaches the current location of the user. Message
(6) is the application subscription used to define this extra service.
7 Final Remarks
Most of the current approaches for building context-aware services platforms ignore
the dynamic (runtime) deployment of mobile context-aware applications on top of
these platforms. The architecture presented in [6] focuses on the handling of different
types of adaptation mechanisms for device-oriented services, and addresses resource
availability and adaptability. A language for coordination of events intended for the
enterprise domain has been reported in [5]. An infrastructure based on a distributed
database and a dynamic decentralized resource discovery service for wearable
computing has been described in [1].
Our approach supports the configuration of applicationsļplatform interactions at
runtime. Furthermore, our platform can be extended with additional functions, actions
and data entities, making it appropriate for a large range of (unanticipated) context-
aware applications.
In order to allow dynamic configuration of interactions we have introduced WSL,
which is a descriptive language developed especially for this purpose. We have
decided to develop our own relatively simple language in order to be able to start
experimenting with our configuration approach right away. By using XML-based
techniques, the development of language manipulation support (parsers and
interpreters) has been facilitated. In future we will investigate how WSL can be
replaced by standard languages.
We have used Web Services technology to support the interactions of the platform
with its environment. As a consequence, third-party applications can access the
services offered by the platform through widely-used Internet protocols. In addition,
Web Services technology facilitates the extension of the platform by third-party
service providers, which can provide additional functions and actions as web services.
Defining a comprehensive architecture for a context-aware services platform is a
non-trivial task. It involves several issues and domains, such as ubiquitous computing,
artificial intelligence, human-computer interaction, and other crosscutting issues such
as security and privacy, scalability and performance. Another effort within the WASP
project has aimed at designing a privacy architecture for the WASP platform [14],
providing the users of the platform with privacy control while being unobtrusive.
In the WASP project we have also investigated the applicability and usefulness of
Semantic Web technologies for the representation of contextual information, leading
to the development of context ontologies and the use of reasoners to detect context
conditions [9]. Further work in the WASP project will consider the integration of the
different results, such as the overall architecture and the privacy support, giving
special attention to the use of Semantic Web technologies. We believe that the use of
60
ontologies and reasoners are promising techniques to enhance the reusability,
flexibility and intelligence of context-aware services platforms and applications.
References
1. DeVaul, R. et al.: The Ektara Architecture. MIT Technical Report (2000)
2. Dockhorn Costa, P.: Towards a Services Platform for Context-Aware Applications. Master
Thesis. University of Twente, the Netherlands (2003)
3. Dockhorn Costa, P., Pereira Filho, J.G., van Sinderen, M.: Architectural Requirements for
Building Context-Aware Services Platforms. In: E. Halasz et al (eds.): Proceedings of 9th
Open European Summer School and IFIP Workshop on Next Generation Networks
(EUNICE 2003). Hungary (2003)
4. Edwards, W.K., Bellotti, V., Dey, A.K., Newman, M.W.: Stuck in the Middle: The
Challenges of User-Centered Design and Evaluation for Infrastructure. In: Proceedings of
the Conference on Human Factors in Computing Systems (CHI 2003). Fort Lauderdale,
Florida, USA (2003)
5. Efstratiou, C. Cheverst, K., Davies, N., Friday, A.: An Architecture for the Effective
Support of Adaptive Context-Aware Applications. In: Tan, K-L., Franklin, M.J., Lui, J.C.S.
(eds.): Mobile Data Management: Second International Conference (MDM 2001). Lecture
Notes in Computer Science, Vol. 1987. Springer-Verlag (2001) 15-26
6. Indulska, J., Loke, S.W., Rakotonirainy, A., Witana, V., Zaslavsky, A.B.: An Open
Architecture for Pervasive System. In: Zielinski, K., Geihs, K., Laurentowski, A. (eds.):
Proceedings of the 3rd International Working Conference on Distributed Applications and
Interoperable Systems (DAIS 2001). Kluwer (2001) 175-188
7. Laar, V.: Requirements for the 3G Platform. WASP Deliverable D1.1 (2003)
8. Parlay Group: Parlay X Web Services White Paper (2002)
[http://www.parlay.org/ about/parlay_x/ParlayX-WhitePaper-1.0.pdf]
9. Rios D., Dockhorn Costa, P., Guizzardi, G., Ferreira Pires, L., Pereira Filho, J.G., van
Sinderen M.: Using Ontologies for Modeling Context-Aware Services Platforms. In:
Workshop on Ontologies to Complement Software Architectures (OOPSLA 2003).
Anaheim, CA, USA (2003)
10. Sun Microsystems: Java API for XML-Based RPC (JAX-RPC) Specification 1.0, JSR-101.
[http://java.sun.com/xml/downloads/jaxrpc.html#jaxrpcspec1]
11. World Wide Web Consortium. Document Object Model (DOM) Level 1 Specification
(1998)
[http://www.w3.org/TR/REC-DOM-Level-1/]
12. World Wide Web Consortium: Web Services Architecture (2003)
[http://www.w3.org/TR/ws-arch/]
13. Universal Description, Discovery and Integration (UDDI) project: UDDI: Specifications.
[http://www.uddi.org/specification.html]
14. Zuidweg, M., Pereira Filho, J.G., van Sinderen M.: Using P3P in a Web Services-Based
Context-Aware Application Platform. In: E. Halasz et al (eds.): Proceedings of 9th Open
European Summer School and IFIP Workshop on Next Generation Networks (EUNICE
2003). Hungary (2003)
61
