Risk Based Security Analysis of Permissions in RBAC
Nimal Nissanke and Etienne J. Khayat
Centre for Applied Formal Methods, London South Bank University
103 Borough Road, London SE1 0AA, UK
Abstract. Because of its vulnerability to errors and, hence, unauthorised access,
assignment of access rights is a critically important aspect of
RBAC. Despite ma-
jor advances in addressing this clearly using formal models, there is still a need
for a more robust formulation, especially incorporating strict guidelines on as-
signment of access rights and how to perform such tasks as delegation of access
rights. In this respect, this paper proposes a precise mathematical framework, ca-
pable of considering important factors such as the relative security risks posed by
different access operations when performed by different users. This is based on a
novel concept of a security risk ordering relation on such tasks, to be established
by a detailed independent risk assessment process. In the case of lack of informa-
tion on security risks, the approach makes conservative assumptions, thus forcing
the security analyst to re-assess such situations if he disagrees with this default
interpretation. The risk ordering relation is central to a security-orientated defini-
tion of role hierarchies and a security-risk minimising strategy to role delegation.
1 Introduction
Role Based Access Control (RBAC) is a widely used access control mechanism whereby
access rights to users (subjects) are granted on the basis of their roles in an institution
rather than as individuals. Allocation of access rights, whether it takes place as a result
of system administrator’s duties, such as permission assignment to roles, or discre-
tionary actions exercised by subjects higher up in role hierarchy, such as delegation, is
a process vulnerable to errors and existence of unforeseen loopholes that could com-
promise the system security.
The growing interest in
RBAC is evident from the large number of works devoted to
it. Notable among them are the works [5,6,9,10] characterising a hierarchy of
RBAC
models with increasing sophistication, dealing with role hierarchies, potential conflict
of interests between roles, etc. A major outcome of these developments is the recogni-
tion by the research community of the need for a standard [1] aimed at a unified model
for
RBAC. Related is also our own work [7], providing a formal state-based model for
the core
RBAC [1]. Important issues related to delegation are elaborated in a number of
works; with [2] dealing with a basic but sufficiently detailed model of delegation, [8,11,
12] showing a practical scenario of the implementation of delegation and [13] giving
detailed mathematical models for various types of delegation.
Despite the above advances, there seems to be little definitive rules or guidelines
that govern the assignment of access rights in
RBAC and clarify the means by which
Nissanke N. and J. Khayat E. (2004).
Risk Based Security Analysis of Permissions in RBAC.
In Proceedings of the 2nd International Workshop on Security in Information Systems, pages 331-340
DOI: 10.5220/0002687403310340
Copyright
c
SciTePress
the goals of the security mechanisms are to be achieved. System invariants for access
rights allocation that should always be respected are not sufficiently well defined in
the literature, including those cited above. Allocation of access rights is often based
on informal rules based on past experience or inherited institutional practices. In order
to overcome the above deficiencies, this paper introduces a novel approach ensuring a
consistent and systematic interpretation of security requirements and a compatible and
effective way to enforce the security arrangements.
Our approach is based on the concept of a risk ordering relation [4] expressing the
relative risk posed by a subject of a particular role performing a particular task, com-
pared to the same posed by a similar subject-task combination. It is a mathematical
concept designed both to introduce rigor into security modelling and to eliminate am-
biguities, omissions and inconsistencies in the risk assessment process. Risk ordering
itself is established through an appropriate independent security risk analysis of the
organisation. From the perspective of security risk analysis, the approach offers two
major benefits: firstly, it makes explicit the form of the information required from such
an analysis and, secondly, it prompts the security expert to question his security assess-
ment, thereby improving the quality and comprehensiveness of the process, as well as
the end–product of the security risk assessment. Questioning of the security assessment
is achieved by a default conservative interpretation of risks levels whenever there is a
lack of information on security risks. According to this, any task with a possible inad-
equate consideration of risk is placed conservatively in a lower security risk band by
default, alerting the security analyst to reconsider its risk nature if such an interpretation
is undesirable. Turning to the modelling of
RBAC, our work proposes certain security
principles for permission assignment to roles and for subject-invoked role delegation.
The paper has the following structure. Section 2 introduces the required basic con-
cepts of
RBAC and the relevant mathematical definitions used later. Section 3 presents
the concept of security risk ordering relation, expressing the risks posed by different
combinations of roles and tasks (permissions) relative to one another. Section 4 states
the proposed principles of allocation of access rights in
RBAC in a precise manner.
Section 5 presents a case study drawn from the domain of health care illustrating the
application of the latter principles. Section 6 concludes the paper with a summary of
achievements.
2 Basic Concepts and Mathematical Preliminaries
The purpose of RBAC is to determine at run–time whether to allow, or deny, a user (sub-
ject) accessing a required resource (object) based on access rights granted to the roles
that subjects perform in the organisation. This section introduces the basic
RBAC con-
cepts relevant to these issues and an appropriate notation for the discussion; see also [7].
Our formulation is based on the following basic types of entities: SUBJECT denoting
the set of all possible users (subjects) of the computer system (including any non-human
agents), OBJECT the entities (objects) being accessed by the subjects, ROLE the roles
in the capacity of which the subjects derive the access rights to the objects concerned,
and OPERATION the set of operations that may be performed on the objects. Disre-
garding here the applicability of operations to specific objects, the set of all possible
333
tasks are denoted by TASK, defined as
TASK = OPERATION × OBJECT (1)
Associated with the above are the following functions [Note: P denotes the power set
of its operand set (on the right)]:
SubjectRoles : SUBJECT P ROLE (2)
SubjectRoles(s) giving the set of roles associated with each subject s, and
Permissions : ROLE P TASK (3)
Permissions(r) giving the set of tasks authorised for each role r. When dealing with
individual permissions, it is convenient to have the elements of the following set
PERM ROLE × TASK (4)
the elements of which denote roles and the applicable tasks.
In relation to delegation of access rights or tasks in hierarchical
RBAC, we introduce
two types of delegation: lateral delegation (a role delegating its duties to another role
lying at the same level of the hierarchy) and downward delegation (a role delegating its
duties to a junior role). A record of such delegated roles to each particular role may be
maintained by the following functions:
lat
del roles, down del roles, delegated roles : ROLE P ROLE (5)
lat
del roles(r), down del roles(r) and delegated roles(r) giving, respectively, the
roles delegated to role r laterally, downward and in total. Note that for each of the
above, r cannot be delegated to itself. Together the above satisfy
r ROLE delegated
roles(r)=lat del roles(r) down del roles(r) (6)
Turning attention to conflicts of interests (COI), there are two kinds of separation of du-
ties that need to be taken into account in determining the permitted delegations of roles
and tasks, namely: a) Static Separation of Duty (SSD), which concerns the prevention
of any conflict of interests arising from the mere assignment of such roles to the same
subject, and, b) Dynamic Separation of Duty (DSD), which concerns the concurrent
exercise of such roles by any subject at the same time and not whether they can be as-
signed to the same subject. With the above in mind, let us introduce three symmetric and
irreflexive binary relations SSD, COI and COI on ROLE, such that COI = SSD DSD.
3 Security Risk Ordering
In general, risk expresses a combined measure of the likelihood of a hazardous, or a
harmful, event occurring and the ensuing consequences should it ever take place. In
computer security, such events include intrusion, tampering with data, eavesdropping,
etc., violating system security properties such as confidentiality, integrity and availabil-
ity. Security threats not intensifying, the risk of such events taking place usually reduces
334
with increasing protection. Risk assessment is an exercise in its own right and is beyond
the scope of this paper. What is important here is, however, the outcome of the risk as-
sessment process and, in particular, the relative risks posed by various security threats
relative to one another.
Risk ordering relation, introduced here, relies on a comparison of risks arrived at
by an appropriate independent risk assessment process. It is denoted by and has the
form
: PERM PERM (7)
Its meaning is such that, given two permissions p
1
and p
2
, where p
1
, p
2
PERM,
p
1
p
2
signifies that p
2
is more, or equally, secure compared to p
1
or, alternatively, p
1
carries a higher, or an equal, security risk compared to p
2
. is reflexive and transitive,
but not necessarily symmetric or antisymmetric. We decompose into two relations:
: a partial order relation over the elements of PERM, which orders their risk levels.
If p
1
p
2
, then p
1
carries a higher security risk than p
2
, unless p
1
and p
2
denote
the same permission.
: an equivalence relation between the elements of PERM.Ifp
1
p
2
, then p
1
and
p
2
are identical in terms of security risk.
As a consequence of this decomposition, is the union of and . In other words,
for permissions p
1
and p
2
, p
1
p
2
if and only if p
1
p
2
or p
1
p
2
.
The relation is best depicted in the form of a graph, as in Figure 1(a), showing
the ordering of the permissions. Since the risk analysis is performed by human security
analysts, the relation may contain gaps, inaccuracies and inconsistencies. Therefore,
following [4], we use the concept of risk band to alert the risk analyst to such defi-
ciencies. The idea is to interpret any lack of information conservatively in favour of
greater provision of security. In effect, risk bands extend the graph of with numeri-
cally indexed risk bands such that permissions carrying relatively greater security risks
are placed in higher risk bands, while the more secure permissions in lower risk bands;
see Figure 1(b). In the event of insufficient information as to where a particular per-
mission is to be placed, it is interpreted as an indication that the permission concerned
is to be placed in the highest possible risk band, subject to any constraints imposed by
other pairs in the relation . Any disagreement with this default interpretation obliges
the security risk analyst to clarify the relative risk levels of the permissions concerned
more accurately, thus helping to refine the risk ordering relation and, thereby, making
it more complete, accurate and consistent with the required security requirements. The
graph of the relation , extended with risk bands, is referred to as the risk graph; see
Figure 1(b). The arcs in the graph are assumed to run upward and the reflexivity of
the permissions in the relation are not shown in the graph to reduce clutter. The risk
bands are numbered from 1 to some n, higher indices signifying greater risk. Risk graph,
corresponding to a specific relation , is to be determined according to the following
rules:
Permissions with the highest security risk, or the least secure ones, (i.e. those in the
nth risk band) are exactly:
a) The permissions that are lowest in the partial order relation , but not related
by to any other permission in .
335
b) Any other permissions related by to the ones just mentioned in (a) above.
If there exist two distinct permissions p
1
and p
2
such that a) p
1
p
2
,b)p
1
is the
only immediate predecessor so related to p
2
, and c) p
1
is in risk band i, then p
2
is in
risk band (i 1).Ifp
2
has several immediate predecessor permissions, then its risk
band index would be one less than the lowest risk band index of those predecessor
permissions.
If there exist two permissions p
1
and p
2
such that p
1
p
2
, then p
1
and p
2
are in
the same risk band.
Low Security Risk
H
G
F
E
C
D
I
B
A
J
H
G
F
E
C
D
I
B
A
J
G
F
E
D
A
C I
B
J
Risk Band 4
Risk Band 6
Risk Band 3
Risk Band 2
H
Risk Band 5
Risk Band 1
(b) (a)
High Security Risk
Fig.1. (a) Risk ordering relation (b) Risk graph.
Associated with the risk graph is a risk distance between two permissions of the
form: RD(p
1
, p
2
)=RB(p
1
) RB(p
2
), where RB(p) gives the risk band index of a
given permission p PERM, taking the sign into consideration. From the security risk
perspective, two permissions p
1
and p
2
are said to be risk-comparable if and only if they
are equivalent through p
1
p
2
or are in different risk bands (i.e., RB(p
1
) = RB(p
2
)).
If they are in the same risk bands (i.e., RB(p
1
)=RB(p
2
)), but are not equivalent (i.e.,
p
1
≈ p
2
), then they are said to be risk-non-comparable.
4 Principles of Allocation and Delegation of Permissions
This section formulates several principles to be followed when allocating access rights.
These concern the cases of permission assignment to roles and delegation of access
rights.
4.1 Relations on Roles
The hierarchical model of
RBAC [1], also known as RBAC
1
[10], places the roles in a
hierarchy in accordance with the functional requirements of the organisation and other
considerations such as the skills, the competence, the past experience, etc., required as
part of the job descriptions. However, this is based mathematically on a simple set–
theoretic characterisation of roles as a partial order , namely, for any two roles r
1
and
r
2
as
r
1
r
2
Permissions(r
1
) Permissions(r
2
) (8)
336
It is important to note that (8) characterises only a hierarchical relationship between
roles with inheritance of permissions of juniors by seniors. In our view, however, there
are other notions of seniority relations of relevance to security. Of particular interest
here is a relation that characterises roles performing different kinds of activities but
being equivalent. This is because, for example, being equivalent in status would allow
the delegation of roles that deal with authorisations, etc. With this in mind, this work
uses three relations on roles, two of them being
A partial order relation, , as defined in (8), dealing with hierarchical inheritance
of permissions of junior roles by their seniors.
An equivalence relation, , dealing with equivalence of roles belonging to differ-
ent categories of roles in terms of their status.
leaving the third relation for Section 4.2. In relation to and , as an example, con-
sider the members of a hospital in two different role categories: medical and nurs-
ing. According to , roles in the medical category may be ordered hierarchically as:
resident surgeon consultant, whereas those in the nursing category as nurse se-
nior
nurse chief nurse. Furthermore, using the equivalence relation , it is possible
to relate the chief nurse and the surgeon as chief
nurse surgeon in order to convey
that they have the same seniority status and, therefore, they are eligible to delegate, for
instance, certain authorisation tasks between them.
4.2 Principle I: Permission Assignment to Roles
As noted above, roles in
RBAC are assigned permissions by associating them with the
tasks that they are authorised to perform. In most cases, this association is based solely
on the functional requirements of the organisation. Prior to such assignment of permis-
sions to roles, however, a security risk assessment needs to be performed in order to
verify if the functional requirements would induce any unintended security threat to
the organisation’s assets. This is where the security risk ordering relation, introduced in
Section 3, proves to be useful. With further implications in terms of risk bands, the risk
graph of represents a detailed ordering of security risks posed by different permitted
role–task combinations.
The third hierarchical relation on roles, introduced in this work, takes into account
the risks described above. It is a hierarchical partial order and is denoted by .It
extends the relation in (8) by incorporating and, following [4], is defined as
r
1
r
2
(r
1
< r
2
) ( t TASK t / Permissions(r
1
)
t Permissions(r
2
) (r
1
, t) (r
2
, t))
(9)
According to this principle, role r
2
is senior to r
1
, i.e., r
1
r
2
, if and only if the role
r
2
is senior to the r
1
in the sense of in (8), i.e., r
1
< r
2
, and all permissions, which
are not included in the junior role r
1
but are in r
2
, are handled more securely by r
2
than
by r
1
with respect to the relevant risk graph. The intention is to ensure that senior roles,
while inheriting permissions of the respective junior roles, are entrusted with certain
permissions requiring greater degree of security. This is a justification for a security–
orientated notion of a hierarchical seniority. However, this does not necessarily mean
337
that the senior role can handle all its permissions more securely than the junior role. In
fact, it may be the case that the junior role is intended to handle its own tasks, perhaps
with the exception of its own inherited ones, more securely than the senior role because
of, for example, the specialist expertise required by the tasks concerned.
4.3 Principle II: Delegation of Tasks
Our approach to delegation of access rights is based on certain rules that take security
risks into consideration. The lack of such explicitly stated rules in other works may
be due to the informality of the way delegation is handled normally or the excessive
number of possibilities in delegation encountered in practical situations. Note that del-
egation applies only to level 1 delegation [3], that is, to roles initially assigned by the
system administrator and not to those gained by previous delegations from other roles.
Principle II(a): Lateral Delegation of Tasks. The lateral delegation here concerns
the delegation of roles at the same level of seniority as understood by the relation ,
introduced in Section 4.1. This may be expressed as
r
1
, r
2
ROLE r
1
= r
2
r
2
lat del roles(r
1
) r
1
r
2
(10)
Principle II(b): Downward Delegation of Tasks. This principle deals with the dele-
gation of its access rights by one role to another in a strictly lower level in the hierarchy
; see Section 4.2. Let us deal here only with the total delegation, i.e., the delega-
tion of all access rights of the delegator role [3]. In order for such a delegation to be
permitted, the two conditions (11) and (13) are to be satisfied.
Firstly, the delegating and delegatee roles must be hierarchically related, as in
r
1
, r
2
ROLE r
1
= r
2
r
2
down del roles(r
1
) r
1
r
2
(11)
Secondly, security risk considerations need to be taken into account. To minimise secu-
rity risks, the access rights are better be delegated to the role(s) that would present the
least risk when they perform the delegated tasks. This can be established using the risk
graph, introduced in Section 3. Considering each of the tasks to be delegated under the
delegating role, it is possible to calculate the worst (lowest, taking the sign into account)
risk distance from the delegating role to each candidate delegatee role. Thus, for each
potential pair of delegating-delegatee roles there is to be a lowest risk distance. The del-
egatee role giving the largest of these risk distances (taking the sign into account) would
be the one to be favoured for delegation. With this in mind, let us first define the worst
risk distance between the permissions of one role r
1
relative to the same permissions
under another role r
2
r
1
, r
2
r
2
r
1
worst risk dist(r
1
, r
2
)=
min{RD((r
1
, t), (r
2
, t)) | t permissions(r
1
) t / permissions(r
2
)}
(12)
where min S gives the minimum value in the set S (of integers). The role(s), which is
the least risky for delegating r
1
s permissions, is a role r
2
having the largest among the
worst risk distances calculated as described above. In other words, for delegating r
1
the
least risky delegatee role is r
2
, provided that
r
3
r
3
r
1
worst risk dist(r
1
, r
2
) worst risk dist(r
1
, r
3
)
(13)
338
Principle II(c): Avoidance of Conflicts of Interest. Furthermore, neither of the above
forms of delegation should result in any static conflict of interest with other delegated
roles and the target (delegatee) role (r below) itself. That is, delegation must respect the
static separation of duty. This principle may be expressed as
r ROLE
roles P ROLE roles = delegated roles(r) ∪{r}⇒
roles × roles SSD =
(14)
5 Case Study: A Health Care Information System
This section illustrates the proposed approach using a hypothetical, but realistic, simple
access control system applicable to a hospital environment, but in relation to: a) the
construction of a role hierarchy (Principle I), and b) downward delegation (Principle
IIb), both based on security considerations. A description of the functional requirements
of the access control system are summarised, along with the notation, in Table 1.
Table 1. The tasks defined in the hospital’s information system
Task Name Representation Brief Description Authorised Roles
t
1
(lead,op) leading an operation consultant (c)
t
2
(asst,op) assist in performing an operation consultant (c)
surgeon (s)
t
3
(prep,pat) pre-operation care for a patient nurse (n)
t
4
(mont,pat) post operation monitoring of patient nurse (n)
t
5
(adm-med,pat) administering medication to patient nurse (n)
t
6
(adm-aneas,pat) administering anaesthetics to patient anaesthetist (a).
Note: Shown in brackets is the notation to be used later.
n,t
6
n,t
1
1
c,t
c,t
5
c,t
6
6
s,t
43
s,t
5
s,t
2
s,t
s,t s,t
1
4
a,t
5
a,t
6
a,t
3
a,t
a,t
2
1
a,t
n,t
3
n,t
4
n,t
n,t
2
5
RB=2
RB=5
RB=4
Low Security Risk
RB=1
RB=3
RB=6
H
igh Security Risk
2
c,t
3
c,t
4
c,t
Nurse ConsultantSurgeon
Anaesthetist
Fig.2. Risk graph of the permissions in the hospital’s information system.
A security risk assessment, involving the permissions and the roles concerned, has re-
sulted in a security risk ordering relation shown in Figure 2. Though its primary purpose
is to present relative security risk levels between various pairs of permissions, belong-
ing also to different roles, it also indicates the risk graphs of individual roles. Arcs on
the graphs, assumed to run upwards, show the risk–comparability between permissions.
Let us first consider three possible role hierarchies in relation to both the Princi-
ple I and the functional requirements. These are shown in Figure 3 along with the
339
permissions associated with each role. The three role hierarchies can be checked for
conformity with (9) against the security risk graph shown in Figure 2. By the man-
ner of their construction, all three hierarchies satisfy the relation in (8) the first
conjunct of (9). Hierarchy 1 satisfies also the second conjunct. In this case, note that
Permissions(s) Permissions(c), t
1
Permissions(c) but t
1
/ Permissions(s) and,
according to the risk graph, (s, t
1
) (c, t
1
). Analogous arguments apply to pairs of
roles s and n, and a and n. It may be noted that Hierarchy 1 also satisfies the functional
requirements. Following a similar analysis, we note that Hierarchy 3 conforms with
Principle I, but violates the functional requirements. In Hierarchy 2, however, in rela-
tion to the pair n s (by transitivity of ), t
6
Permissions(s) and t
6
/ Permissions(n)
but (s, t
6
) (n, t
6
), which violates Principle I. Thus, we conclude that only Hierarchy
1 satisfies both the functional requirements and the security considerations expressed in
Principle I, thus justifying its applicability to
RBAC as proposed here.
Hierarchy 1
5
} {t
1
, t
6
, t
3
, t
2
, t
4
{t
3
, t
5
, t
4
}
{t
3
, t
5
, t
4
, t
6
}
, t
6
}
, t
4
, t
3
, t
5 2
{t
, t
5
} {t
1
, t
6
, t
3
, t
2
, t
4
{t
3
, t
4
}
{t
3
, t
5
, t
4
}
, t
4
, t
3
{t
2
, t
5
} {t
1
, t
6
, t
3
, t
2
, t
4
Nurse(n)
{t
3
, t
5
, t
4
, t
6
}
{t
3
, t
5
, t
4
}
{t
2
, t
4
, t
5
}
, t
3
Surgeon (s)
Consultant (c)
Anaesthetist (a)
Nurse(n)
Consultant (c)
Surgeon (s)
Nurse(n
)
Anaesthetist (a)
}
Consultant (c)
Anaesthetist (a)Surgeon (s)
Hierarchy 2 Hierarchy 3
, t
Fig.3. Three possible role hierarchies
Turning attention to delegation, let us consider a situation where a subject exercising
the role consultant wishes to delegate his role (i.e. the totality of the tasks) to a junior
role in Hierarchy 1. In determining the most secure role(s) to whom the delegation
should take place, the risk distances between the permissions of consultant and the
same performed by the other roles need to be calculated. Note, however, that some
of consultants tasks are shared also by the junior roles. Therefore, risk distances are
needed only in relation to the non–shared tasks. The tasks concerned are: t
1
and t
6
in the case of delegation to surgeon; t
1
and t
2
, in the case of anaesthetist; and t
1
, t
2
and t
6
in the case of nurse. Therefore, according to (12), the worst risk distances are,
respectively, -4, -4 and -5, leading to the least risky roles anaesthetist and surgeon for
delegating consultants role.
6 Conclusion
This paper presents a rigorous formal approach for dealing with some of the key issues
in
RBAC, in particular, delegation and allocation of access rights. Assignment of access
rights is a critical and an error-prone process. Therefore, precise, clear and well-studied
guidelines are essential for combating security breaches resulting from unauthorised
access rights. An important contribution of the proposed approach, in this respect, is
the formulation of several principles for defining role hierarchies and handling role
340
delegation based on a novel idea of a security risk ordering relation. The approach also
incorporates precise ways to consider other factors, such as functional requirements and
conflicts of interest, etc., essential for assuring the system integrity. The risk ordering
relation relies on a detailed assessment of the risks faced by the system. In the event
of lack of sufficient information, the approach enforces certain default interpretations
of risk in a conservative manner, so that any disagreement leads to a refinement of
the security risk analysis. A case study drawn from health care domain illustrates the
approach and demonstrates its effectiveness.
References
1. American National Standard for Information Technology. Role Based Access Control. Draft
BSR INCITS 359, April 2003.
2. Barka E. and Sandhu R. A Role-Based Delegation Model and Some Extensions. Proceedings
of the 23rd NIST-NCSC National Information Systems Security Conference, pp: 101–114,
Baltimore, USA, October, 2000.
3. Barka E. and Sandhu R. Framework for Role-Based Delegation Models. Proceedings of the
16th IEEE Annual Computer Security Applications Conference, pp: 168–175, New Orleans,
Louisiana, USA, December, 2000.
4. Dammag H. and Nissanke N. A Mathematical Framework for Safecharts. Proceedings of
the 5th International Conference of Formal Engineering Methods, pp: 620–640, Singapore,
Singapore, November, 2003.
5. Ferraiolo D. Cugini J., and Kuhn R. Role-Based Access Control (RBAC): Features and Mo-
tivations. Proceedings of the 11th Annual Computer Security Applications Conference, pp:
241–248, New Orleans, LA, USA, December, 1995.
6. Ferraiolo D., Sandhu R., Gavrila S., Kuhn R. and Chandramouli R. “Proposed NIST Standard
for Role-Based Access Control”. ACM Transactions on Information and System Security
(TISSEC), Vol. 4, No. 3, August 2001, pp: 224–474.
7. Khayat E. and Abdallah A. A Formal Model for Flat Role-Based Access Control. Proceedings
of the ACS/IEEE Conference on Computer Systems Applications, Tunis, Tunisia, July, 2003.
8. Na S. and Cheon S. Role Delegation in Role-Based Access Control. Proceedings of the 5th
ACM workshop on Role-Based Access Control, pp: 39–44, Berlin, Germany, June, 2000.
9. Sandhu R., Coyne E., Feinstein H. and Youman C. “Role-Based Access Control Models”.
IEEE Computer, Vol. 29, No. 2, November 1996, pp: 38–47.
10. Sandhu R., Ferraiolo D. and Kuhn R. The NIST Model for Role-Based Access Control:
Towards A Unified Standard. Proceedings of 5th ACM Workshop on Role-Based Access
Control, pp: 47–64, Berlin, Germany, July, 2000.
11. Zhang L., Ahn. G.J. and Chu B.T. “A Rule-Based Framework for Role-Based Delegation and
Revocation”. ACM Transactions on Information and System Security, Vol. 6, No. 3, August
2003, pp: 404–441.
12. Zhang L., Ahn. G.J. and Chu B.T. A Role-Based Delegation Framework for Healthcare
Information Systems. Proceedings of the 7th ACM symposium on Access Control Models
and Technologies, pp: 125–134, Monterey, California, USA, June, 2003.
13. Zhang X., Oh S. and Sandhu R. PBDM: A Flexible Delegation Model in RBAC. Proceed-
ings of the 8th ACM symposium on Access Control Models and Technologies, pp: 149–157,
Como, Italy, June, 2003.
341
