Towards a Classiﬁcation of Security Metrics

Carlos Villarrubia, Eduardo Fern

andez-Medina, and Mario Piattini

Universidad de Castilla - La Mancha, Alarcos Research Group

Paseo de la Universidad, 4, 13071, Ciudad Real(Spain),

Abstract. For the generation of trust in the use of information and communica-

tions technologies it is necessary to demonstrate security in the use of these tech-

nologies. Security metrics or assurance metrics are the most appropriate method

to generate that trust. In this article we propose a series of features for classi-

fying security metrics. We present the main conclusions obtained through this

classiﬁcation together with the list of metrics analyzed.

1 INTRODUCTION

The information and support processes, systems and networks are important assets to

any organization. These assets suffer risks and insecurities continually coming from a

wide variety of sources, including threats based in malicious code, programming errors,

carelessness of people, sabotages or ﬁres.

According to [1], the loss due to malicious code alone exceeded $13 billion in 2001,

and security expenditures are projected at more than $3 billion in 2004.

This concern has prompted many organizations and investigators to propose differ-

ent metrics to evaluate the security of their information system. In general, there exists a

consensus in afﬁrming that the election of the metric depends on those concrete security

necessities of each organization. Most of the analyzed proposals propose methodologies

for the election of these metrics [2–7]. Even in some cases the necessity is suggested of

developing speciﬁc methodologies for each organization [8].

In any one of these proposals the necessity is to quantify the different relative as-

pects of security to be able to understand, to control and to improve the trust in the

information system.

If an organization doesn’t use security metrics to make decisions, the choices will

be motivated by purely subjective aspects, external pressures or even purely commercial

motivations.

This research is part of the CALIPO project, supported by the Direcci

on General de Inves-

tigaci

on of the Ministerio de Ciencia y Tecnolog

ıa (TIC2003-07804-C05-03), and the MES-

SENGER project, supported by the Consejer

ıa de Ciencia y Tecnolog

ıa of the Junta de Comu-

nidades de Castilla-La Mancha (PCC-03-003-1).

Villarrubia C., Fernández-Medina E. and Piattini M. (2004).

Towards a Classiﬁcation of Security Metrics.

In Proceedings of the 2nd International Workshop on Security in Information Systems, pages 341-350

DOI: 10.5220/0002688203410350

 SciTePress

2 SECURITY METRICS

2.1 Metrics Classiﬁcation

To analyze the different metric proposals it is necessary to use certain approaches to

classify them and to be able to obtain conclusions.

The selection of these classiﬁcation approaches is based on the different previous

proposals [9, 3, 4, 7], keeping in mind that they cover the different necessities of the

security of an organization, eliminating the repetitions of proposed approaches and se-

lecting those approaches with greater generality.

The approaches selected to classify the security metrics correspond to the differ-

ent objectives of security pursued, to the control area used to get those objectives, the

moment that those controls are applied and to the audience directed with that metric.

1. Security Objective (SO). The security of a system is characterized by information

like the persecution of the following objectives:

– Conﬁdentiality, assuring that only those who are authorized can access the in-

formation.

– Integrity, assuring against the unauthorized modiﬁcation of the information.

– Availability, assuring that the authorized users have access to the information

and their assets associates when they require it.

– Authentication, assuring that the identity of a subject or resource is the one

claimed.

In our study, we have included a general objective to characterize those metrics that

pursue two or more objectives of security.

2. Control Area (CA). The previous objectives are achieved using different controls

in the information system. According to [9], those different types of controls to get

the objectives of security can be classiﬁed as:

– Management. Security controls that can be characterized as managerial. In gen-

eral, they focus on the management of the computer security program and the

management of the risk within the organization.

– Operational. Security controls implemented and executed by people (as op-

posed to systems).

– Technical. Security controls that the computer system executes.

3. Temporal Dimension (TD). From the point of view of the risks management, the

used controls can be applied in different instants:

– Preventive. Designed to lower the amount and impact of threat.

– Detective. Used to detect threat once it has occurred.

– Corrective. Implemented to help mitigate the impact of a loss event.

– Recovery. They allow the recovery of the system to the state previous to the

attack.

4. Intended Audience (IA). The security metrics are the fundamental mission to in-

form on the different aspects of security. [7] classiﬁes a metric depending on the

following intended audience:

– Technical. Technical personnel of the company or institution.

– Decision Makers. Different people responsible for the company.

– External Authorities. Any external entity to the company that should inform on

the situation of the security of the company.

343

2.2 Metrics features

The information of the previous paragraph can be even more valuable to the stake-

holders if it comes accompanied by additional information on the metrics themselves,

which may help discriminate between metrics with the same functionality and purpose.

Based on the proposal of [10], we will distinguish six features for a given metric. The

ﬁrst group identiﬁes three of the basic (intrinsic) properties of any metric. The three

remaining features determine whether the metric has been validated or not, the kind of

validation used (theoretical or empirical), and whether the metric has a tool that auto-

mates its measurement process or not.

1. Objectivity/Subjectivity (O/S). A metric is objective if its values are calculated by

an algorithm or a mathematical formula. On the contrary, a metric is subjective if

its measurements are (totally or partially) provided by a human being. In case of

subjective metrics, it is very important to record the person or expert that performs

the evaluation and provides the values.

2. Direct/Indirect (D/I). According to ISO 9126, a direct measure is a measure of an

attribute that does not depend upon a measure of any other attribute. An indirect

measure is a measure of an attribute that is derived from measures of one or more

other attributes.

3. Run-time/Static (R/S). This characteristic classiﬁes a metric depending on the mo-

ment in which it can be measured. Run-time metrics can only be measured during

system operation, acting on instances of the component or system being evaluated.

Static measures can be evaluated based on the component properties only. Exam-

ples of run-time measured metrics are percentage of used media sanitized before

reuse or disposal and number of intrusion attempts reported. Static measured met-

rics include percentage of systems that have a contingency plan or percentage of

laptops with encryption capability for sensitive ﬁles.

4. Theoretical Validation (TV). The main goal of theoretical validation is to prove that

a metric actually measures what it is supposed to measure [11]. Theoretical valida-

tion can also help us know when and how to apply the metric. This feature indicates

whether the metric has been theoretically validated or not, and how. Even though

several methods and principles have been proposed for metric theoretical valida-

tion (mainly in the context of software engineering), there is no widely accepted

proposal yet. The two major approaches currently proposed are the following:

– Measurement-theory based approaches such as those proposed by [12], [13],

and [14].

– Property-based approaches (also called axiomatic approaches), such as those

proposed by [15] and [16, 17].

5. Empirical Validation (EV). Empirical validation tries to demonstrate with real ev-

idence that the metrics meet their objective, and that they are useful in practice.

There are three major types of empirical research strategy:

– Experiments. Experiments are formal, rigorous and controlled investigations.

They are launched when we want control over the situation and want to ma-

nipulate behavior directly, precisely and systematically. Hence, the objective

is to manipulate one or more variables and control all other variables at ﬁxed

344

levels. An experiment can be carried out in an off-line situation, for example

in a laboratory under controlled conditions, where the events are organized to

simulate their appearance in the real world. Experiments may alternatively be

carried out on-line, which means that the research is executed in the ﬁeld under

normal conditions [18, 19].

– Case Studies. A case study is an observational study, i.e., it is carried out by the

observation of an on-going project or activity. The case study is normally aimed

at tracking a speciﬁc attribute or establishing relationships between different

attributes. The level of control is lower in a case study than in an experiment

[20].

– Surveys. A survey is often an investigation performed in retrospect, when, for

example, a tool or technique has been in use for a while. The primary means

of gathering qualitative or quantitative data are interviews or questionnaires.

These are completed by taking samples which are representative of the pop-

ulation to be studied. The results from the survey are then analyzed to derive

descriptive or explanatory conclusions. Surveys provide no control over the ex-

ecution or the measurement, though it is possible to compare them to similar

ones [21].

6. Automation (A). This feature indicates whether the metric has speciﬁc tool sup-

port or not. Not only methodological, but also technological support is deﬁnitely

required for the effective use of metrics in industrial settings [22].

3 ANALYSIS OF EXISTING SECURITY METRICS

As mentioned in the introduction, we are currently witnessing a proliferation of met-

rics for security. For the present study, we surveyed the existing literature on these

topics, looking for metrics that could provide interesting information for description,

comparison or prediction of any aspect related to the security of an information sys-

tem. Interestingly, we had to discard some of the metrics because they didn’t have a

sufﬁcient description to be able to determine the values of those characteristics used

to classify these metrics. Examples of these metrics include those used as examples

in those articles that describe methodologies for the construction of these metrics. We

also discarded repeated metrics, i.e., those metrics proposed by more than one author.

We included one instance of such metrics only. Finally, 57 metrics from 85 different

proposals were selected, which are listed in the Appendix of this paper.

Regarding the speciﬁc classiﬁcation approaches to security, the results have been

the following:

– Security Objective: 74% of the metrics were general, while 9% of the metrics were

to do with availability and authentication.

7% were conﬁdentiality metrics and only one was speciﬁc to the integrity.

– Control Area: 44% of the metrics were operational, 30% were relative of technical,

and the rest were management.

– Temporal Dimension: 84% of the metrics were preventive metrics, 9% were detec-

tive metrics, and 2% were corrective metrics and recovery metrics respectively.

345

– Intended Audience: 44% of the metrics were for decision makers, 39% were for

technical people and the rest for external authorities.

After evaluating the features of the metrics, the following list shows a summary of

the results obtained.

– Objectivity or Subjectivity: 96% of the metrics were objective, the rest subjective.

– Direct or Indirect: 61% of the metrics were indirect, the rest were direct.

– Static or Run-time: 63% of the metrics were static metrics, the rest were run-time.

– Theoretical validation: None of the surveyed metrics had been theoretically vali-

dated.

– Empirical validation: Only one of the metrics had been empirically validated- even

worse, and none of the rest of the proposals mentioned empirical validation as

something they were planning to achieve as part of their future work.

– Automation: Only one of the metrics had some kind of supporting tool.

These results provide a global picture the proﬁle of the surveyed metrics:

– As expected, most of the metrics deﬁned are general metrics and this type of metric

only measures general actions relative to the security and in an indirect way they

have the preservation of the conﬁdentiality, integrity and availability as objectives.

– Most of the metrics are of a preventive character showing the importance granted

to avoidance of problems of security.

– Regarding the area of the used controls and intended audience they have there exists

a reasonable balance indicating that the metric proposals form correct aspects.

– Most of the metrics are objective. This is good, since this kind of metrics are more

reliable and easier to automate.

– Most of the metrics are direct metrics. Although these metrics are very important,

they are only a ﬁrst step towards the ﬁnal goal of satisfying the information needs

of a user. Hence, indirect metrics, which usually provide more information than

direct metrics, and indicators based on them should also be deﬁned

– The lack of validation and automation of the metrics is common to all the disci-

plines in which the application of metrics is still immature, and clearly shows an

area of research that needs to be addressed in order to be able to rely on real engi-

neering methods and tools.

4 CONCLUSIONS AND FUTURE WORK

In this paper we have presented the results of a survey we have conducted on the most

representative existing security metrics.

The results obtained show the distribution of the metrics and, more importantly, the

areas with lack of metrics which therefore require the deﬁnition of new metrics, speciﬁc

for these areas.

There are several possible extensions to our work. In the ﬁrst place, we need to con-

tinue classifying forthcoming metrics, in order to conﬁrm and validate the conclusions

346

extracted from this ﬁrst classiﬁcation, and to further analyze the tendencies in the time

for the proposition of new metrics.

We also want to start analyzing the relative importance among those metrics for the

attainment of the objectives of security. In this way, additional approaches will be used

to prioritize the use of metrics. We also want to analyze the difﬁculty in the obtaining of

the metric ones or in their use to guide in the modiﬁcation of those metrics to be more

useful.

The characterization of security metrics proposed is not complete because some

metrics are the same values for all features. A future work is to reﬁne this characteriza-

tion so that each metric is different in the classiﬁcation.

Finally, indicators should be deﬁned in function of the size of the organization and

sector (for example, public sector and private sector) because it is not realistic to have

a good group of metrics which are useful for all the organizations.

References

1. Mercuri, R.T.: Analyzing security costs. Communications of the ACM 46 (2003) 15–18

2. Swanson, M., Bartol, N., Sabato, J., Hash, .J., Graffo, L.: Security metrics guide for infor-

mation technology systems. Technical Report NIST 800-55, National Institute of Standards

and Technology (2003)

3. Vaughn, Jr., R.B., Henning, R., Siraj, A.: Information assurance measures and metrics -

state of practice and proposed taxonomy. In: Proceedings of the 36th Hawaii International

Conference on Systems Sciences. (2003)

4. Bouvier, P., Longeon, R.: Le tableau de bord de la s

ecurit

e du syst

eme d’information.

ecurit

e Informatique (2003)

5. Nielsen, F.: Approaches of security metrics. Technical report, NIST-CSSPAB (2000)

6. Payne, S.C.: A guide to security metrics. Technical report, SANS Institute (2001)

7. ACSA, ed.: Proceedings of the Workshop on Information Security System Scoring and

Ranking, Williamsburg, Virginia (2001)

8. Colado, C., Franco, A.: M

etricas de seguridad: una visi

on actualizada. SIC. Seguridad en

Inform

atica y Comunicaciones 57 (2003) 64–66

9. Swanson, M.: Security self-assessment guide for information technology systems. Technical

Report NIST 800-26, National Institute of Standards and Technology (2001)

10. Calero, C., Mart

ın-Albo, J., Piattini, M., Vallecillo, M.B..A., Cechich, A.: A survey on

software component metrics. Submitted to ACM Computing Surveys (2003)

11. Fenton, N., Pﬂeeger, S.: Software Metrics: A Rigorous Approach. 2nd edn. Chapman Hall,

London (1997)

12. Whitmire, S.: Object Oriented Design Measurement. Wiley, New York (1997)

13. Zuse, H.: A Framework of Software Measurement. Walter de Gruyter, Berlin (1998)

14. Poels, G., Dedene, G.: Distance-based software measurement: Necessary and sufﬁcient prop-

erties for software measures. Information and Software Technology 42 (2000) 35–46

15. Weyuker, E.J.: Evaluating software complexity measures. IEEE Transactions on Software

Engineering 14 (1988) 1357–1365

16. Briand, L.C., Morasca, S., Basili, V.R.: Property-based software engineering measurement.

IEEE Transactions on Software Engineering 22 (1996) 68–86

17. Briand, L.C., Morasca, S., Basili, V.R.: Property-based software engineering measurement:

Reﬁning the additivity properties. IEEE Transactions on Software Engineering 23 (1997)

196–197

347

18. Juristo, N., Moreno, A.: Basics of Software Engineering Experimentation. Kluwer Academic

Publishers (2001)

19. Wohlin, C., Runeson, P., Ohlsson, M., Regnell, B., Wesslen, .A.: Experimentation in Soft-

ware Engineering: An Introduction. Kluwer Academic Publishers (2000)

20. Yin, R.: Case Study Research: Design and Methods. 2nd edn. Applied Social Research

Methods Series, vol 5 Sage Publications Inc, Thousand Oaks, CA (1994)

21. Pﬂeeger, S., Kitchenham, B.: Principles of survey research. Software Engineering Notes 26

(2001) 16–18

22. Lavazza, L.: Providing automated support for the gqm measurement process. IEEE Software

17 (2000) 56–62

23. Departament of the Air Force: AFI33-205. Information Protection Metrics and Measure-

ments Program. (1997)

24. Calero, C., Piattini, M., Genero, M.: Empirical validation of referential integrity metrics.

Information and Software Technology 43 (2001) 949–957

25. ISO: ISO 7498-2. Open Systems Interconnection - Basic Reference Model - Part 2: Security

Architecture. (1989)

26. ISO/IEC: ISO/IEC TR 13335-1. Guidelines for the Management of IT Security. Part I:

Concepts and Models of IT Security. (1996)

27. ISO/IEC: ISO/IEC 15408. Evaluation Criteria for IT Security. (1999)

28. ISO/IEC: ISO/IEC 17799. Code of Practice for Information Security Management. (2000)

29. King, G.: Best security practices: An overview. In: Proceedings of the 23rd National Infor-

mation Systems Security Conference, Baltimore, Maryland, NIST (2000)

30. Marcelo, J.M.: Identiﬁcaci

on y Evaluaci

on de Entidades en un M

etodo AGR. In: Seguridad

de las Tecnolog

ıas de la Informaci

on. AENOR (2003) 69–103

31. McKnight, W.L.: What is information assurance? CrossTalk. The Journal of Defense Soft-

ware Engineering (2002) 4–6

32. Schuedel, G., Wood, B.: Adversary work factor as a metric for information assurance. In:

Procedings of the New Security Paradigm Workshop, Ballycotton, Ireland (2000) 23–30

33. Carnegie Mellon University Pittsburgh, Pennsylvania: SSE-CMM Model Description Doc-

ument. 3.0 edn. (2003)

34. Vaughn, Jr., R.B., Siraj, A., Dampier, D.A.: Information security system rating and ranking.

CrossTalk. The Journal of Defense Software Engineering (2002) 30–32

APPENDIX

This appendix presents, in tabular form, the metrics that we have surveyed for our anal-

ysis, and the dimensions and features assigned to each of them.

Metric information is displayed in columns. Column one is a sequence counter (1

to 57). Column two show the metric name and description, together with the reference

to the article in which the metric was originally deﬁned. Columns three to six show the

dimensions assigned to the metric. Finally, columns seven to twelve display the values

assigned to the metric features.

The values assigned to the cells of the columns three at six they have the following

meaning:

– Column SO (Security Objective): C (Conﬁdentiality), I (Integrity), A (Availability),

AU (Authentication) and G (General).

– Column CA (Control Area): M (Management), O (Operational) and T (Technical).

348

– Column TD (Temporal Dimension): P (Preventive), D (Detective), C (Corrective)

and R (Recovery).

– Column IA (Intended Audience): T (Technical Experts), D (Decision makers) and

E (External authorities).

The values assigned to the cells in the last two columns (Empirical validation and

Automation) require some special explanations:

– Column ”EV” shows whether the metric has gone through any kind of empirical

validation. Cells in this column may be either empty, or have the following values:

”1E” (validated by one experiment); or ”FW” (mentioned as future work by the

metric authors).

– Column ”A” shows the kind of automated support for the metric. Cells of this

column may be either empty, or have the value ”CT”, indicating that there is a tool

that supports the metric. A description of such tool can be found in the paper cited

for the metric.

349

Metric Description

O/S

D/I

R/S

Percentage of critical data ﬁles and operations with an established backup frequency [2]

Percentage of systems that have a contingency plan [2]

Percentage of systems for which contingency plans have been tested in the past year [2]

Number of uses of the backups [4]

Annual down time for a system [3]

Percentage of systems that perform password policy veriﬁcation [2]

Percentage of users with special access to systems who have undergone background evaluations [2]

Number of failed login attempts [3]

Percentage of systems without active vendor-supplied passwords [2]

Percentage of unique user [2]

Percentage of websites with a posted privacy policy [2]

Percentage of used media sanitized before reuse or disposal [2]

Number of clock cycles per byte encrypted [3]

Percentage of laptops with encryption capability for sensitive ﬁles [2]

Frequency of the audits [4]

Number of rules for security’s politics [4]

Level of maturity in developers’ process [33]

Percentage allocated for security program [3]

Percentage of systems that have had risk levels reviewed by management [2]

Percentage of systems recertiﬁed if security controls are added/modiﬁed after the system was developed [2]

Percentage of systems that are operating under an Interim Authority to Operate (IATO) [2]

Percentage of systems with approved system security plans [2]

Risk assessment [30]

Percentage of systems that had formal risk assessments performed and documented [2]

Percentage of total systems for which security controls have been tested and evaluated in the past year [2]

Percentage of systems that have the costs of their security controls integrated into the life cycle [2]

Percentage of total systems that have authorized for processing following certiﬁcation and accreditation [2]

Percentage of current security plans [2]

Assessment of the execution of the recovery plans [4]

Percentage of information systems libraries that log the deposits and withdrawals of tapes [2]

Percentage of data transmission facilities in the organization that have restricted access to authorized users [2]

Percentage of software changes documented and approved through change request forms [2]

Percentage of in-house applications with documentation on ﬁle [2]

Percentage of users with access to security software that are not security administrators [2]

Number of hours employed in formation [4]

Percentage of formed people [4]

Percentage of systems compliant with the separation of duties requirement [2]

Percentage of systems that impose restrictions on system maintenance personnel [2]

Percentage of systems with documented risk assessment reports [2]

Number of incidents reported to FedCIRC, NIPC, and local law enforcement [2]

Percentage of employees with signiﬁcant security responsibilities who have received specialized training [2]

Percentage of agency components with incident handling and response capability [2]

The average time elapsed between vulnerability discovery and implementation of corrective action [2]

Percentage of security-related user issues resolved immediately following the initial call [2]

Number of detected attacks [4]

Number of invalid packets rejected for a ﬁrewall [3]

Number of elements dedicated to network security [4]

Number of components with audit trail [4]

Evaluation Assurance Level according Common Criteria for a system [27]

Percentage of systems with the latest approved patches installed [2]

Percentage of systems with automatic virus deﬁnition updates and automatic virus scanning [2]

Percentage of systems running restricted protocols [2]

Percentage of systems on which audit trails provide a trace of user actions [2]

Adversary work factor [32]

Number of intrusion attempts reported [23]

Number of reported successful intrusions with limited access or total access [23]

Number of systems with functions of integrity in ﬁles [4]

350
