A FAST TABU SEARCH ALGORITHM FOR FLOW SHOP

PROBLEM WITH BLOCKING

Jozef Grabowski, Jaroslaw Pempera

Wroclaw University of Technology, Institute of Engineering Cybernetics

Janiszewskiego 11-17, 50-372 Wroclaw, Poland

Keywords:

Flow-shop scheduling; Blocking; Makespan; Local search; Tabu Search.

Abstract:

This paper develops a fast tabu search algorithm to minimize makespan in a ﬂow shop problem with blocking.

We present a fast heuristic algorithm based on tabu search approach. In the algorithm the multimoves are used

that consist in performing several moves simultaneously in a single iteration of algorithm and guide the search

process to more promising areas of the solutions space, where good solutions can be found. It allow us to

accelerate the convergence of the algorithm. Besides, in the algorithm a dynamic tabu list is used that assists

additionally to avoid being trapped at a local optimum. The proposed algorithm is empirically evaluated and

found to be relatively more effective in ﬁnding better solutions in a much shorter time.

1 INTRODUCTION

This paper considers the blocking ﬂow shop problem

to minimize makespan. The classical ﬂow shop prob-

lem disregards the behavior of the jobs between two

consecutive operations, i.e. it is assumed that inter-

mediate buffers have inﬁnite capacity and that a job

can be stored for unlimited amount of time.

In a ﬂow shop problem with blocking, there are

no buffers between the machines and a job, having

completed processing on a machine, remains on this

machine and blocks it, until the next machine down-

stream becomes available for processing.

The ﬂow shop problem with blocking has been

studied by many researchers including (Abadi et al.,

2000), (Caraffa et al., 2001), (Grabowski and Pem-

pera, 2000), (Hall and Sriskandarajah, 1996), (Leis-

tein, 1990), (McCormick et al., 1989), (Nowicki,

1999), (Peng et al., 2004), (Reddi and Ramamoor-

thy, 1972), (Ronconi, 2004), (Ronconi and Armen-

tano, 2001), (Smutnicki, 1983).

In this paper, we propose a new heuristic algorithm

based on tabu search technique. The paper is orga-

nized as follows. In Section 2, the problem is deﬁned

and formulated. Section 3 presents the description

of algorithm, moves, neighbourhood structure, search

process and dynamic tabu list. Computational results

are shown in Section 4 and compared with those taken

from the literature.

2 PROBLEM DESCRIPTION AND

PRELIMINARIES

The ﬂow-shop problem with blocking can be formu-

lated as follows.

PROBLEM: Each of n jobs from the set J =

{1, 2, . . . , n} has to be processed on m machines

1, 2, . . . , m in that order, having no intermediate

buffers. Job j ∈ J, consists of a sequence of m

operations O

j1

, O

j2

, . . . , O

jm

; operation O

jk

corre-

sponds to the processing of job j on machine k during

an uninterrupted processing time p

jk

. Since the ﬂow

shop has no intermediate buffers, a job j, having com-

pleted processing of the operation O

jk

, can not leave

the machine k, until the next machine k + 1 is free,

k = 1, 2, . . . , m−1, j ∈ J. If the machine k+1 is not

free, then job j is blocked on the machine k. We want

to ﬁnd a schedule such that the processing order of

jobs is the same on each machine and the maximum

completion time is minimal.

Each schedule of jobs can be represented by per-

mutation π = (π(1), . . . , π(n)) on set J. Let Π de-

note the set of all such permutations. We wish to ﬁnd

such permutation π

∗

∈ Π, that

C

max

(π

∗

) = min

π ∈Π

C

max

(π),

where C

max

(π) is the time required to complete all

jobs on the machines in the processing order given

71

Grabowski J. and Pempera J. (2005).

A FAST TABU SEARCH ALGORITHM FOR FLOW SHOP PROBLEM WITH BLOCKING.

In Proceedings of the Second International Conference on Informatics in Control, Automation and Robotics, pages 71-76

DOI: 10.5220/0001160900710076

Copyright

c

SciTePress

by π. It is known from literature (Ronconi, 2004)

that C

max

(π) = D

π ( n)m

, where the departure time

D

π ( j)k

of job π(j) on machine k can be found using

the following recursive expressions:

D

π (1)0

= 0, k = 1, . . . , m − 1,

D

π (1) k

=

P

k

l=1

p

π (1) l

, k = 1, . . . , m − 1,

D

π ( j)0

= D

π ( j−1), 1

, j = 2, . . . , n,

D

π ( j)k

= max{D

π ( j)k−1

+ p

π ( j)k

, D

π ( j−1), k+1

},

j = 2, . . . , n, k = 1, . . . , m − 1,

D

π ( j)m

= D

π ( j),m −1

+ p

π ( j)m

, j = 1, . . . , n.

The two-machine ﬂow shop problem with block-

ing can be solved in O(nlogn) time (Reddi and Ra-

mamoorthy, 1972) using an improved implementation

by (Gilmore et al., 1985) of the algorithm of (Gilmore

and Gomory, 1964). For m > 2, the problem is un-

fortunately NP-hard.

It is useful to present the considered problem by

using a graph (Grabowski and Pempera, 2000). For

the given processing order π, we create the graph

G(π) = (N, R ∪ F

0

(π) ∪ F

−

(π)) with a set of nodes

N and a set of arcs R ∪ F

0

(π) ∪ F

−

(π), where:

• N = {1, ..., n}×{1, ..., m}, where node (j, k) rep-

resents the k-th operation of job π(j). The weight

of node (j, k) ∈ N is given by the processing time

p

π ( j)k

.

• R =

n

S

j=1

m−1

S

k=1

{((j, k), (j, k + 1))}. Thus, R con-

tains arcs connecting consecutive operations of the

same job.

• F

0

(π) =

n−1

S

j=1

m

S

k=1

{((π(j), k), (π(j+1), k))}. Arcs

from F

0

(π) connect jobs to be processed on the

machines in the processing order given by π. Each

arc of F

0

(π) has weight zero.

• F

−

(π) =

n−1

S

j=1

m−1

S

k=1

{((π(j), k + 1), (π(j + 1), k)}.

Each arc ((π(j), k+1), (π(j+1), k)) ∈ F

−

(π) has

weight minus p

π ( j),k+1

and ensures the blocking

of job π(j + 1) (i.e. operation O

π ( j+1) ,k

) on the

machine k, if the machine k + 1 is not free.

The makespan C

max

(π) of the ﬂow-shop problem

with blocking is equal to the length of the longest

(critical) path from node (1, 1) to (n, m) in G(π).

Each path from (1, 1) to (n, m) can be repre-

sented by a sequence of nodes, and let denote a crit-

ical path in G(π) by u = (u

1

, u

2

, . . . , u

w

), where

u

i

= (j

i

, k

i

) ∈ N, 1 ≤ i ≤ w and w is the num-

ber of nodes in this path. Obviously, it has to be

u

1

= (j

1

, k

1

) = (1, 1), and u

w

= (j

w

, k

w

) = (n, m).

The critical path can naturally be decomposed into

several speciﬁc subpaths and each of them contains

the nodes linked by the same type of arcs, i.e. all arcs

of the subpath belong either to F

0

(π) or to F

−

(π).

The ﬁrst type of subpaths is determined by a maxi-

mal sequence (u

g

, ..., u

h

) = ((j

g

, k

g

), . . . , (j

h

, k

h

)))

of u such that k

g

= k

g + 1

= . . . = k

h

and

((j

i

, k

i

), (j

i+1

, k

i+1

)) ∈ F

0

(π) for all i = g, . . . , h−

1, g < h. Each such subpath determines the sequence

of jobs

B

g h

= (j

g

, j

g + 1

, . . . , j

h−1

, j

h

),

which is called the block of jobs in π. Jobs j

g

and

j

h

in B

g h

are the ﬁrst and last ones, respectively. A

block corresponds to a sequence of jobs (operations)

processed on machine k

g

without inserted idle time.

Next, we deﬁne the internal block of B

g h

as the

subsequence

B

∗

g h

= B

g h

− {j

g

, j

h

}.

The second type of subpaths is deﬁned by a max-

imal sequence (u

s

, ..., u

t

) = ((j

s

, k

s

), . . . , (j

t

, k

t

)))

of u such that ((j

i

, k

i

), (j

i+1

, k

i+1

)) ∈ F

−

(π) for all

i = s, . . . , t−1, s < t. Each such subpath determines

the sequence of jobs

A

st

= (j

s

, j

s+1

, . . . , j

t−1

, j

t

),

which is called the antiblock of jobs in π. Similarly

to in B

g h

, jobs j

s

and j

t

in A

st

are the ﬁrst and

last ones, respectively. An antiblock corresponds to

blocked jobs. Note that operation O

π ( j

i

)k

i

of jobj

π ( j

i)

is processed on machine k

i

with k

i

> k

i+1

= k

i

− 1,

i = s, . . . , t − 1. Similarly to in B

g h

, now we deﬁne

the internal antiblock of A

st

as the subsequence

A

∗

st

= A

st

− {j

s

, j

t

}.

The critical path u can contain many different blocks

and antiblocks, and let l

B

and l

A

denote, respectively,

the numbers of blocks and antiblocks in u . Each of

blocks (or antiblocks) can be characterized by the pair

(g

i

, h

i

), i = 1, . . . , l

B

(or (s

i

, t

i

), i = 1, . . . , l

A

), and

let GH = {(g

i

, h

i

) | i = 1, . . . , l

B

} (or ST =

{(s

i

, t

i

) | i = 1, . . . , l

A

}) be the set of the pairs de-

noting all blocks (or antiblocks) in u.

Property 1 (Grabowski and Pempera, 2000).

For any block B

g h

(or antiblock A

st

) in π, let α be

a processing order obtained from π by an interchange

of jobs from the internal block B

∗

g h

(or A

∗

st

). Then we

have C

max

(α) ≥ C

max

(π).

Immediately from Property 1, it results the follow-

ing Theorem

Theorem 1 .

Let π ∈ Π be any permutation with blocks B

g h

and antiblocks A

st

. If the permutation β has been

obtained from π by an interchange of jobs that

C

max

(β) < C

max

(π), then in β

ICINCO 2005 - INTELLIGENT CONTROL SYSTEMS AND OPTIMIZATION

72

(i) at least one job j ∈ B

g h

(or j ∈ A

st

) precedes job

j

g

(or j

s

), for some (g, h) ∈ GH (or (s, t) ∈ ST ),

or

(ii) at least one job j ∈ B

g h

(or j ∈ A

st

) succeeds job

j

h

(or j

t

) , for some (g, h) ∈ GH (or (s, t) ∈ ST ).

Note that Theorem 1 provides the necessary con-

dition to obtain a permutation β from π such that

C

max

(β) < C

max

(π).

3 ALGORITHM TABU SEARCH

WITH MULTIMOVE (TS+M)

Currently, tabu search (TS) approach, see (Glover,

1989) and (Glover, 1990), is one of the most effective

methods using local search techniques to ﬁnd near-

optimal solutions of many combinatorial intractable

optimization problems, such as the vast majority of

scheduling problems. This technique aims to guide

the search by exploring the solution space of a prob-

lem beyond local optimality. Since TS has not been

applied to our problem, we propose a TS approach.

The main idea of this method involves starting from

an initial basic job permutation and searching through

its neighbourhood, a set of permutations generated

by the moves, for a permutation with the lowest

makespan. The search then is repeated starting from

the best permutation, as a new basic permutation, and

the process is continued. One of the main ideas of

TS is the use of a tabu list to avoid cycling, overcom-

ing local optimum, and to guide the search process

to the solutions regions which have not been exam-

ined. The tabu list records the performed moves that,

for a chosen span of time, have tabu status and cannot

be applied currently (they are forbidden); that is they

determine forbidden permutations in the currently an-

alyzed neighbourhood. Usually, the algorithm TS ter-

minates when it has performed a given number of iter-

ations (Maxiter), time has run out, the neighbourhood

is empty, a permutation with a satisfying makespan

has been found, etc.

3.1 Moves and neighbourhood

One of the main components of a local search algo-

rithm is the deﬁnition of the move set that creates a

neighbourhood. A move changes the location of some

jobs in a given permutation. The intuition following

from Theorem 1 suggests that the ”insert” type move

should be the most proper one for the problem con-

sidered. Let v = (π(x), π(y)) be a pair of jobs in a

permutation π, x, y ∈ {1, 2, ..., n}, x 6= y. The pair

v = (π(x), π(y)) deﬁnes a move in π. This move

consists in removing job π(x) from its original posi-

tion x, and next inserting it in the position immedi-

ately after job π(y) (or before π(y)) in π if x < y (or

x > y).

The neighbourhood of π consists of permutations

π

v

obtained by moves from a given set M , and de-

noted as N (M, π) = {π

v

| v ∈ M }. The proper

selection of M is very important to construct an ef-

fective algorithm.

For each job j we consider at most one move to the

right and at most one to the left. Moves are associ-

ated with blocks and antibloks. Let us take the block

B

g h

= (j

g

, j

g + 1

, . . . , j

h−1

, j

h

)) in π. Now we deﬁne

the sets of candidates

E

a

g h

= {j

g

, j

g + 1

, . . . , j

h−1

} = B

g h

− {j

h

},

E

b

g h

= {j

g + 1

, . . . , j

h−1

, J

h

)} = B

g h

− {j

g

}.

Each set E

a

g h

(or E

b

g h

) contains the jobs in block B

g h

of π that are candidates for being moved to a position

after (or before) all other jobs in this block.

For any block B

g h

in π, we deﬁne the following set

of moves to the right

RB

g h

= {(j, j

h

) | j ∈ E

a

g h

},

and the set to the left

LB

g h

= {(j, j

g

) | j ∈ E

b

g h

}.

Set RB

g h

contains all moves of jobs of E

a

g h

to the

right after the last job j

h

of block B

g h

. By anal-

ogy, set LB

g h

contains all moves of jobs of E

b

g h

to the left before the ﬁrst job j

g

of block B

g h

. It

should be found that for each move v ∈ RB

g h

(or

v ∈ LB

g h

) , the necessary condition of Theorem 1 is

satisﬁed to obtain a permutation π

v

from π such that

C

max

(π

v

) < C

max

(π). As a consequence, in algo-

rithm, we will employ the set of moves

MB =

[

(g , h)∈ GH

[RB

g h

∪ LB

g h

],

The similar considerations can be provided for the

antiblocks A

st

, and we then obtain the set of moves

MA =

[

(s,t)∈ST

[RA

st

∪ LA

st

].

Finally, in our TS+M, we propose the following set of

moves

M = MB ∪ M A,

which creates neighbourhood N (M, π).

In order to accelerate the convergence of the algo-

rithms to good solutions, we propose to use the mul-

timoves. A multimove consists of several moves that

are performed simultaneously in a single iteration of

algorithm. The performances of the multimoves al-

low us to generate permutations that differ in various

signiﬁcant ways from those obtained by performing a

single move and to carry the search process to hitherto

A FAST TABU SEARCH ALGORITHM FOR FLOW SHOP PROBLEM WITH BLOCKING

73

non-visited regions of the solution space. Further-

more, in our algorithm, the multimoves have the pur-

pose of guiding the search to visit the more promising

areas, where ”good solutions” can be found. In lo-

cal search algorithms, the use of multimoves can be

viewed as a way to apply a mixture of intensiﬁcation

and diversiﬁcation strategies in the search process.

In the following we present a method that will be

used in our TS algorithm to provide the multimoves.

For the blocks B

g h

, we consider the following sets

of moves

RB

∗

g h

= {(j, j

h

) | j ∈ B

∗

g h

},

LB

∗

g h

= {(j, j

g

) | j ∈ B

∗

g h

}.

Set RB

∗

g h

(or LB

∗

g h

) contains all moves that insert the

jobs from the internal block B

∗

g h

after the last job j

h

(or before the ﬁrst job j

g

) of this block (see Section

Moves and neighbourhood).

Next, for the block B

g h

, the ”best” move v

R(gh)

∈

RB

∗

g h

and v

L(g h)

∈ LB

∗

g h

are chosen (respectively):

C

max

(π

v

R(gh)

) = min

v ∈ RB

∗

gh

C

max

(π

v

),

C

max

(π

v

L(gh)

) = min

v ∈ LB

∗

gh

, v6=v

R(gh)

C

max

(π

v

),

and the following sets of moves are created

RB = {v

R(gh)

| (g, h) ∈ GH},

LB = {v

L(g h)

| (g, h) ∈ GH},

and

BB = RB ∪ LB = {v

1

, v

2

, ..., v

2l

B

}.

Let

BB

(−)

= {v ∈ BB | C

max

(π

v

) < C

max

(π)} =

= {v

1

, v

2

, ..., v

p

}, p ≤ 2l

B

.

be the set of the proﬁtable moves of blocks B

g h

per-

forming of which generates permutation π

v

”better”

than π.

The similar consideration can be provided for the

antiblocks A

st

, and we then obtain their the set of

proﬁtable moves

BA

(−)

= {v ∈ BA | C

max

(π

v

) < C

max

(π)} =

= {v

1

, v

2

, ..., v

q

}, q ≤ 2l

A

.

The main idea of a multimove is to consider a search

which allows us several moves to be made in a sin-

gle iteration and carry the search to the more promis-

ing areas of solution space, where ”good solutions”

can be found. In our algorithm, the set of promising

moves can be deﬁned as follows

BM

(−)

= BB

(−)

∪ BA

(−)

= {v

1

, v

2

, ..., v

z

},

z ≤ 2(l

B

+ l

A

).

From the deﬁnition of BM

(−)

it results that each

move v ∈ BM

(−)

produces permutation π

v

”bet-

ter” than π. Therefore, as a multimove, we took the

set BM

(−)

. The use of this multimove consists in

performing all the moves from BM

(−)

simultane-

ously, generating a permutation, denoted as π

v

, where

v = BM

(−)

. To simplify, in the further consider-

ations, multimove BM

(−)

will be denoted alterna-

tively by

v.

3.2 Search process

TS+M starts from an initial basic permutation π that

implies the neighbourhood N(M, π). This neigh-

bourhood is searched in the following manner.

First, the ”best” move v

∗

∈ M that gener-

ates the permutation π

v

∗

∈ N (M, π) with the

lowest makespan is chosen, i.e. C

max

(π

v

∗

) =

min

v ∈ M

C

max

(π

v

). If C

max

(π

v

∗

) < C

∗

(where C

∗

is the best makespan found so far), then the move v

∗

is selected for the search process. Otherwise, i.e. if

C

max

(π

v

∗

) ≥ C

∗

, then the set of unforbidden moves

(UF) that do not have the tabu status, is deﬁned

UM = {v ∈ M | move v is UF}.

Next, the ”best” move v

∗

∈ UM that generates

the permutation π

v

∗

∈ N(U M, π) with the lowest

makespan, i.e. C

max

(π

v

∗

) = min

v ∈ U M

C

max

(π

v

),

is chosen for the search.

If the move v

∗

is selected, then a pair of jobs cor-

responding to the move v

∗

is added to the tabu list

(see next section Tabu list and tabu status of move for

details) and the resulting permutation π

v

∗

is created.

Next, this permutation becomes the new basic one,

i.e. π := π

v

∗

and algorithm restarts to next iteration.

We develop our algorithm tabu search by using

the multimoves in some speciﬁc situations.If permu-

tation π

v

is obtained by performing a multimove

v,

then the next one is made when Piter of the con-

secutive non-improving iterations will pass in TS+M.

In other words, the multimove is used periodically,

where Piter is the number of the iterations between

the neighbouring ones.

If a multimove is performed, then a pair of jobs

corresponding to the move v

∗

∈

v with the smallest

value of C

max

(π

v

∗

) is added to tabu list T . The Piter

is a tuning parameter which is to be chosen experi-

mentally.

3.3 Tabu list and tabu status of move

In our algorithm we use the cyclic tabu list deﬁned

as a ﬁnite list (set) T with length LengthT contain-

ing ordered pairs of jobs. The list T is a realiza-

tion of the short-term search memory. If a multi-

move

v is performed on permutation π, then, for the

ICINCO 2005 - INTELLIGENT CONTROL SYSTEMS AND OPTIMIZATION

74

”best” move v

∗

= (π(x), π(y)) ∈ v, the pair of jobs

(π(x), π(x+1)) if x < y, or the pair (π(x−1), π(x)))

if x > y, representing a precedence constraint, is

added to T . Each time before adding a new ele-

ment to T , we must remove the oldest one. With re-

spect to a permutation π, a move (π(x), π(y)) ∈ M

is forbidden, i.e. it has tabu status, if A(π(x)) ∩

{π(x + 1), π(x + 2), ..., π(y)} 6= ∅ if x < y, and

B(π(x)) ∩ {π(y), π(y + 1), ..., π(x − 1)} 6= ∅ other-

wise, where

A(j) = {i ∈ J | (j, i) ∈ T },

B(j) = {i ∈ J | (i, j) ∈ T }.

Set A(j) (or set B(j)) indicates which jobs are to be

processed after (or before) job j with respect to the

current content of the tabu list T.

As mentioned above, our algorithm uses a tabu list

with dynamic length. This length is changed cycli-

cally, as the current iteration number iter of TS+M

increases, using the “pick“ in order to avoid be-

ing trapped at a local optimum (see (Grabowski and

Wodecki, 2004) for details). This kind of tabu list can

be viewed as a speciﬁc disturbance and was employed

on that very fast tabu search algorithm proposed by

Grabowski and Wodecki (Grabowski and Wodecki,

2004), where it was successfully applied to the classi-

cal ﬂow shop problem.

4 COMPUTATIONAL RESULTS

In this section we report the results of empirical tests

to evaluate the relative effectiveness of the proposed

tabu search algorithm. So far the best heuristic al-

gorithms for a permutation ﬂow-shop problem with

blocking were presented in papers by (Abadi et al.,

2000), (Caraffa et al., 2001), (Leistein, 1990), (Mc-

Cormick et al., 1989), (Nowicki, 1999), (Ronconi,

2004). It is showed that the best heuristic algorithm

is that proposed by Nowicki (Nowicki, 1999), de-

noted here as TSN. Therefore, we compare our al-

gorithm TS+M with TSN which is also based on the

tabu search approach.

Both algorithms TS+M and TSN were coded in

C++, run on a PC with Pentium IV 1000MHz proces-

sor and tested on the benchmark instances provided

by (Taillard, 1993) for the classic permutation ﬂow

shop, by considering all machines as the blocking

constraints are required. The benchmark set contains

120 particularly hard instances of 12 different sizes,

selected from a large number of randomly generated

problems. For each size (group) n × m: 20 × 5,

20 × 10, 20 × 20, 50 × 5, 50 × 10, 50 × 20, 100 × 5,

100 × 10, 100 × 20, 200 × 10, 200 × 20, 500 × 20, a

sample of 10 instances was provided.

The algorithms based on the tabu search method,

needs an initial permutation, which can found by any

Table 1: Computational results

TSN TS+M

M axiter 30000 1000 3000 30000

n × m APRI ACPU APRI ACPU APRI ACPU APRI ACPU

20 × 5 2.93 2.4 2.87 0.1 3.08 0.3 4.08 2.5

20 × 10 4.51 4.1 3.27 0.1 4.11 0.4 4.75 4.4

20 × 20 2.83 7.2 2.33 0.3 2.39 0.7 2.89 7.3

50 × 5 1.69 6.0 2.04 0.2 2.34 0.6 3.05 6.1

50 × 10 3.13 10.8 2.63 0.4 3.18 1.0 4.04 10.9

50 × 20 3.70 19.1 2.01 0.7 2.47 1.9 4.42 20.1

100 × 5 0.79 12.3 0.98 0.4 1.18 1.3 1.78 12.8

100 × 10 1.98 21.9 1.78 0.7 2.06 1.8 3.00 23.1

100 × 20 2.56 39.5 1.76 1.3 2.12 2.2 3.04 40.9

200 × 10 0.73 44.1 1.03 1.5 1.28 4.0 1.93 46.3

200 × 20 1.35 79.4 1.30 2.7 1.68 8.0 2.52 82.1

500 × 20 0.36 213 0.49 7.0 0.60 20.0 1.12 205

all 2.21 1.87 2.21 3.05

method. In our tests, we use algorithm NEH (Nawaz

et al., 1983) in its original version, which is consid-

ered to be the best one (champion) among simple

constructive heuristics for ﬂow-shop scheduling. In

our tests, for each instance, TS+M algorithm is ter-

minated after performing Maxiter = 1 000, 3 000 and

30 000 iterations, whereas TNS performed Maxiter =

30 000 iterations. The value of tuning parameter Piter

is drawn from (Grabowski and Wodecki, 2004) equal

to 3. The effectiveness of our algorithms was ana-

lyzed in both terms of CPU time and solution quality.

For each test instance, we collected the following

values:

• P RI = 100%(C

NEH

− C

A

)/C

NEH

– the

value of the percentage relative improvements of

the makespan C

A

obtained by algorithm A =

{T SN, T S + M} with respect to the makespan

C

NEH

obtained by algorithm NEH.

• CP U – the computer time (in seconds).

Then, for each size (group) n × m, the following

measures of the heuristic quality were calculated

• AP RI – the average (for 10 instances) percentage

relative improvements of the makespans.

• ACP U – the average (for 10 instances) computer

time.

The computational results presented in Table 1

show that, in terms of APRI values, our algorithm

TS+M, for M axiter =30 000 iterations, performs

signiﬁcantly better than TSN in comparable the CPU

times. The TS+M found makespans with the overall

average APRI equal to 3.05, whereas TSN found the

ones with 2.21. The superiority of TS+M over TSN

increases with the size of instances. And so, for the

largest instances with n × m = 500 × 20, the TS+M

found makespans with average APRI equal to 1.12,

A FAST TABU SEARCH ALGORITHM FOR FLOW SHOP PROBLEM WITH BLOCKING

75

whereas TSN found the ones with APRI = 0.36. For

the instances with n × m = 200 × 20, respective val-

ues are equal to 2.52 and 1.35.

Analysing the performance of our algorithm, we

have observed that TS+M converges to the good so-

lutions signiﬁcantly faster, on the average, than TSN.

The APRI values for all instances equal to 2.21 was

found by TSN in 30 000 iterations whereas for TS+M

the respective number is 3 000 iterations. Further-

more, about 85 % improvements obtained by TS+M

(i.e. APRI = 1,87 - for all instances) has been reached

in 1 000 iterations.

Generally speaking TS+M produces better results

than TSN in a signiﬁcantly shorter time.

ACKNOWLEDGEMENTS

This research has been supported by KBN Grant 4

T11A 016 24. The authors are due to anonymous ref-

erees for their useful comments and suggestions.

REFERENCES

Abadi, I. N. K., Hall, N., and Sriskandarayah, C. (2000).

Minimizing cycle time in a blocking ﬂowshop. Oper-

ations Research, 48:177–180.

Caraffa, V., Ianes, S., Bagchi, T., and Sriskandarayah, C.

(2001). Minimizing makespan in a blocking ﬂow-

shop using genetic algorithms. International Journal

of Production Economics, 70:101–115.

Gilmore, P. and Gomory, R. (1964). Sequencing a state-

variable machine: a solvable case of the traveling

salesman problem. Operations Research, 12:655–

679.

Gilmore, P., Lawler, E., and Shmoys, D. (1985). Well-

solved special cases. E.L. Lawler, J.K. Lenstra,

A.H.G. Rinnooy Kan, D.B. Shmoys (Eds), The Trav-

eling Salesman Problem: A Guided Tour of Combina-

torial Optimization. Wiley: Chichester, pages 87–143.

Glover, F. (1989). Tabu search. part i. ORSA Journal of

Computing, 1:190–206.

Glover, F. (1990). Tabu search. part ii. ORSA Journal of

Computing, 2:4–32.

Grabowski, J. and Pempera, J. (2000). Sequencing of jobs

in some production system. European Journal of Op-

erational Research, 125:535–550.

Grabowski, J. and Wodecki, M. (2004). A very fast

tabu search algorithm for the ﬂow shop problem with

makespan criterion. Computers and Operations Re-

search, 11:1891–1909.

Hall, N. and Sriskandarajah, C. (1996). A survey of ma-

chine scheduling problems with blocking and no-wait

in process. Operations Research, 44:510–525.

Leistein, R. (1990). Flowshop sequencing with limited

buffer storage. International Journal of Production

Research, 28:2085–2100.

McCormick, M., Pinedo, M., Shenker, S., and Wolf, B.

(1989). Sequencing in an assembly line with block-

ing to minimize cycle time. Operations Research,

37:925–935.

Nawaz, M., Enscore, E., and Ham, I. (1983). A heuristic al-

gorithm for the m-machine, n-job ﬂowshop sequenc-

ing problem. OMEGA The International Journal of

Management Science, 11:91–95.

Nowicki, E. (1999). The permutation ﬂow shop with

buffers: A tabu search approach. European Journal

of Operational Research, 116:205–219.

Peng, Y., Soong, B., and Wang, L. (2004). Electronics Let-

ters, 40:375–376.

Reddi, S. and Ramamoorthy, C. (1972). On ﬂowshop se-

quencing problems with no-wait in process. Opera-

tional Research Quarterly, 23:323–331.

Ronconi, D. (2004). A note on constructive heuristics for

the ﬂowshop problem with blocking. International

Journal of Production Economics, 87:39–48.

Ronconi, D. and Armentano, V. (2001). Lower

bounding schemes for ﬂowshops with blocking in-

process. Journal of the Operational Research Society,

52:1289–1297.

Smutnicki, C. (1983). Some properties of scheduling prob-

lem with storing constraints. Zeszyty Naukowe AGH:

Automatyka (in Polish), 34:223–232.

Taillard, E. (1993). Benchmarks for basic scheduling prob-

lems. European Journal of Operational Research,

64:278–285.

ICINCO 2005 - INTELLIGENT CONTROL SYSTEMS AND OPTIMIZATION

76
