Optimizing ICA Using Prior Information

Giancarlo Valente

1,2

, Giuseppe Filosa

1

, Federico De Martino

2

, Elia Formisano

2

,

Marco Balsi

1

1. Department of Electronic Engineering, University of Rome “La Sapienza”, Italy.

2. Department of Cognitive Neuroscience, University of Maastricht, The Netherlands.

Abstract. In this work we introduce a novel algorithm for Independent

Component Analysis (ICA) that takes available prior information on the sources

into account. This prior information is included in the form of a “weak”

constraint and is exploited simultaneously with independence in order to

separate the sources. Optimization is performed by means of Simulated

Annealing. We show how it outperforms classical ICA algorithms in the case of

low SNR. Moreover, additional prior information on the sources enforces the

ordering of the components according to their significance.

1 Introduction

Independent component analysis (ICA) is a technique that aims to separate

statistically independent signals from the observation of an (unknown) linear mixture

of these signals [1]. No a priori assumptions are usually made on the underlying

sources or on the mixing, except for the statistical independence of the original

signals.

Since its introduction ICA has been used successfully in several research fields.

Recently ICA has received great attention in various fields of functional

neuroimaging, including functional magnetic resonance imaging (fMRI) and electro-

and magneto-encephalography (EEG,MEG) [2],[3]. In all cases, observed data x are

modeled as a linear mixture of n statistically independent signals s: x=As where A is

the mixing matrix.

ICA algorithms attempt to recover the original sources by finding an estimate of

the unmixing matrix W such that the signals y=Wx are as much independent as

possible. However, due to the double indeterminacy in the mixing matrix and in the

original signals, it is not possible to define the variance of the sources univocally. For

the same reason, every permutation of the sources is still a solution, therefore no

intrinsic ordering of the sources is defined (unlike in principal component analysis,

where signals are extracted according to the amount of variance they explain). Several

algorithms have been proposed, using high order statistic (HOS) or second order

statistics (SOS), based on information theory criteria or on decorrelation principles.

For a review, see [4],[5].

Valente G., Filosa G., De Martino F., Formisano E. and Balsi M. (2005).

Optimizing ICA Using Prior Information.

In Proceedings of the 1st International Workshop on Biosignal Processing and Classiﬁcation, pages 27-34

DOI: 10.5220/0001195800270034

Copyright

c

SciTePress

While performances of conventional hypothesis-driven techniques highly depend

on the accuracy of a predefined model/template, the generality and the nature of the

assumptions underlying ICA make it a powerful and flexible tool. Some kind of

general knowledge of the sources, however, is often available [6]. In fMRI, for

instance, interesting sources of brain activity are expected to show regularities in

space and time. Similar considerations also apply to a broader range of ‘mixtures’ of

natural signals, in which interesting sources have some form of regularity. Such

information is completely ignored in classical ICA, as the structure of data does not

influence the cumulative statistics employed in the algorithm.

Prior information on a source together with gradient optimization has been used to

influence the order of extraction of the components ([7], [8], [9]) and to recover their

real variance (constrained ICA, [8]). In [9] the knowledge of reference functions of

different paradigms is incorporated into the extraction algorithm in order to perform a

semi-blind ICA. However, these approaches employ specific and rather strong

information on the sources and thus are affected by the same drawbacks as in the case

of hypothesis-driven methods,

In this paper, we propose an approach that allows including in ICA prior

knowledge of the spatial/temporal structure of the sources in a systematic and general

fashion. Such prior information can be quite general, so as to apply broadly to

potentially interesting signals, without requiring detailed knowledge of source

properties. The proposed solution also enforces the ordering of the extracted

components according to their significance. This is an advantage when only few of a

large number of components are actually interesting for the interpretation of the data.

2 ICA with Prior Information

The solution of an ICA problem can be obtained in two steps: defining a suitable

contrast function that measures independence, and optimizing it.

To avoid the direct computation of probability density functions, information-

theory-based contrast function are used. In particular robust estimates of mutual

information and negative entropy are employed to determine the degree of

independence between the estimated signals. Using the central limit theorem, it has

been shown that a linear transformation of the data that maximizes non-Gaussianity,

leads to independence as well [4].

FastICA recovers the sources by maximizing an estimate of negative entropy,

which is a measure of non-Gaussianity, by means of a fixed-point iteration algorithm.

In particular, negative entropy is approximated as follows:

()

(

)

(

)

{

}

[

]

2

ν

GyGyJ

G

−Ε=

(1)

where ν is a Gaussian distributed signal with the same mean and variance as y.

Maximization can be performed considering all the output signals together

(symmetric approach), or extracting one source at a time using a deflation approach.

Our approach is based on the maximization of a novel contrast function F:

28

HJF

λ

+

=

(2)

where J is again an estimate of negative entropy, and H accounts for the prior

information we have on sources. The parameter λ is used to weigh the two parts of the

contrast function. If λ is set to zero, maximization of F leads to pure independence.

As is usual with regularization problems, λ must be chosen appropriately to ensure

that both parts of the function are actually active. This problem is also related to the

fact that the magnitude of J and H must be appropriately limited and normalized. We

consider two basic approaches for the choice of H, according to the type of constraint

that should be enforced. H can be a nonlinear saturating function or a monotonic one.

A saturating H is only active in a limited domain, so that we obtain a constrained

optimization algorithm, in which independence is optimized freely within a bounded

class of functions. The second case, instead, requires joint optimization of the two

conditions, and is more sensitive to the choice of λ.

In order to keep the method as general as possible, it is preferable not to impose H

to be differentiable. Therefore we choose to maximize the contrast function using

Simulated Annealing (SA), a well known optimization procedure that has proved to

be a really powerful tool for optimization problems [11],[12].

The main advantage of SA is that it does not require use of derivatives to reach the

global optimum, even if it usually requires more time if compared with gradient

optimizations. Optimization is performed considering one component at a time, and

decorrelating the subsequent components at each iteration.

3 Methods

To test our algorithm we used a simulated fMRI dataset, consisting of three different

activation maps with related time courses (Fig. 1). The three maps were sparse, highly

localized and not overlapping; therefore all the assumptions of ICA model were met.

The three sources were mixed up, and FastICA managed to extract them exactly if

no noise was superimposed. As shown in [13], performance of classical ICA

algorithms tends to deteriorate as the SNR of the sources decreases.

In order to improve separation performances in case of superimposed noise we

performed new extractions including an additional term to account for prior

information on the spatial and temporal structure of the sources. We considered three

different contrast functions H that considered the spatial one-lag autocorrelation,

temporal one-lag autocorrelation and a linear combination of them. Such information

is meant to describe very loosely the regularity of natural signals. Let the two

dimensional index p refer to the image, then the spatial one-lag autocorrelation can be

expressed as:

()

]))(([#)()()(

2

ypNkypyyH

ppNk

sp

⋅⋅=

∑∑

∈

(3)

29

where N(p) is the 1-neighborhood of point p, and #N(p) is the cardinality of the

neighborhood.

The temporal one-lag autocorrelation of vector w can be calculated as:

()

(

)

2

1)( wtwtwwH

t

t

∑

+⋅=

(4)

In the first case we considered a purely spatial constraint, in the second a purely

temporal one, while in the third we considered a spatio-temporal constraint.

Sources that have spatial and temporal structure are expected to have higher values

of the contrast function so that their extraction is enhanced.

To test the algorithm we considered two different frameworks: in the first we

added Gaussian white noise to the mixed sources, and studied performances

according to the level of noise introduced, while in the second we superimposed the

artificial activations to a resting state experiment, modifying the amplitude of the time

courses of the injected activations.

In both case we evaluated the correlation between the original sources and the

recovered ones as a measure of the effectiveness of the extraction.

3.1 Test on Artificial Activations with Gaussian White Noise

We considered different levels of noise, and for each level the correlation between the

estimated source and the corresponding original one was computed. As expected,

FastICA performance deteriorates considerably and rather abruptly as the SNR of the

independent sources decreases. Instead, considering additional general prior

information such as high spatial and/or temporal autocorrelation makes the overall

extraction performances better.

In this case the additional contrast function H was weighted two orders of

magnitude more than pure independence, but considered until a threshold, so that we

looked for the maximization of negentropy within a subset of the original domain

such that H was above threshold.

In Figs. 2-4 the correlation of each spatial source with the corresponding separated

component vs. power of noise is depicted in the top panel, while in the bottom

correlation of corresponding time-courses is shown.

Correlation was calculated on thresholded maps, and each of the four algorithms

was executed 6 times, to give more significance to results.

The continuous line corresponds to FastICA extraction, the continuous-plus one to

the one-lag spatial autocorrelation additional cost function, the continuous-diamond to

one-lag temporal autocorrelation, while the dashdot line indicates the linear

combination of both cost functions. It is evident that spatial autocorrelation is more

effective in this setting.

As shown in Figs. 2-4, for high levels of noise the incorporation of prior

information helps recovering the sources more effectively, while classical

independence search fails to identify the sources. Performance decay of the

constrained algorithm is more regular with noise appearing almost linear.

30

0 10 20 30 40 50 60 70 80

0 10 20 30 40 50 60 70 80

0

10

20

30

40

50

60

70

80

Fig. 1. Simulated spatial independent sources with corresponding time courses (active voxels in

white).

0 0.2 0.4 0.6 0.8 1 1.2 1.4 1.6 1.8 2

0

0.5

1

First Source

Correlation

0 0.2 0.4 0.6 0.8 1 1.2 1.4 1.6 1.8 2

0

0.5

1

Variance of noise

Correlation

Fig. 2. Values of correlation between the first original source and the corresponding estimated

one.

0 0.2 0.4 0.6 0.8 1 1.2 1.4 1.6 1.8 2

0

1

2

Second Source

Correlation

0 0.2 0.4 0.6 0.8 1 1.2 1.4 1.6 1.8 2

0

0.5

1

Variance of noise

Correlation

Fig. 3. Values of correlation between the second original source and the corresponding

estimated one.

31

0 0.2 0.4 0.6 0.8 1 1.2 1.4 1.6 1.8 2

0

0.5

1

Third Source

Correlation

0 0.2 0.4 0.6 0.8 1 1.2 1.4 1.6 1.8 2

0

0.5

1

Variance of noise

Correlation

Fig. 4. Values of correlation between the third original source and the corresponding estimated

one.

3.2 Test on Artificial Activations Superimposed to Resting State fMRI

Experiment

We considered in this case a fMRI resting state experiment performed by a healthy

volunteer. The whole brain was acquired on a 3T Siemens Allegra (Repetition Time

1.5s, Interslice time 46 ms, 32 slices, matrix 64×64, slice thickness 3mm, 210

volumes). We skipped the first two volumes due to T2* saturation effects, and

performed a linear de-trending and high pass filtering with BrainvoyagerQX.

We therefore added the three simulated activities a single slice of the collected

dataset. In this case we modified the amplitude of the time courses of the simulated

activity at different Contrast to Noise Ratios (CNR), where CNR is the ratio of signal

enhancement and the standard deviation of the fMRI time series in those voxels that

are active. It is known in literature [13] that as the CNR decreases below 1, ICA

performances in fMRI signal extraction deteriorate significantly.

In this case we weighted the additional contrast function H an order of magnitude

less than negentropy (independence), because of the presence of other spatially and

temporally autocorrelated sources already present in the resting state dataset and

related to various causes (like movement artifacts, vessels), and that have higher

power than the simulated activations. As in the previous case, we considered the

correlation between sources and recovered signals as a benchmark for the separation.

In Figs. 5-7 correlations between the original sources and the recovered ones are

depicted for CNR ranging from 0.5 to 1. It has to be noted that also in this case the

new contrast function term helps recovering the sources even in the case when

FastICA fails to identify them.

Poor performances of temporal autocorrelation additive contrast function may be

due to the small number of time samples considered (100 points), while spatial

autocorrelation was computed over a whole slice (consisting of 4096 points).

32

0.5 0.6 0.7 0.8 0.9 1

0

0.5

1

First source

correlation

0.5 0.6 0.7 0.8 0.9 1

0

0.5

1

contrast to no i se rati o

correlation

Fig. 5. Values of correlation between the first original source and the corresponding estimated

one (top panel) and between time courses (bottom panel).

0.5 0.6 0.7 0.8 0.9 1

0

0.5

1

Seco nd so urce

correlation

0.5 0.6 0.7 0.8 0.9 1

0

0.5

1

contrast to no i se rati o

correlation

Fig. 6. Values of correlation between the second original source and the corresponding

estimated one (top panel) and between time courses (bottom panel)

0.5 0.6 0.7 0.8 0.9 1

0

0.5

1

Third source

correlation

0.5 0.6 0.7 0.8 0.9 1

0

0.5

1

contrast to noise ratio

correlation

Fig. 7. Values of correlation between the second original source and the corresponding

estimated one (top panel) and between time courses (bottom panel)

33

4 Conclusions

In this work we propose an approach to incorporate available prior information into

independent component analysis. This approach has the advantage of being very

general and flexible, as prior information is included in the form of an additional cost

function of any kind. The proposed method can be used for a wide area of problems

where there is some kind of prior knowledge on the sources, either considering

information as an additional contrast function, or considering it as a constraint. In

addition, we have shown that it is possible to enhance source extraction by using

general cost functions, like spatial one-lag autocorrelation and/or temporal one-lag

autocorrelation, without having detailed information on some of the sources, and

making the extraction more robust with respect to additive noise.

References

1. P. Comon: Independent component analysis—A new concept?, Signal Processing, (1994)

36(3), 287–314.

2. T.P. Jung, S. Makeig, MJ McKeown, A.J. Bell, T.W. Lee, T.J. Sejnowski: Imaging brain

dynamics using independent component analysis, Proceedings of the IEEE, (2001), 89(7)

1107-22.

3. M.J. McKeown, S. Makeig, G.G. Brown, T.P. Jung,S.S. Kindermann, A.J. Bell, T.J.

Sejnowski: Analysis of fMRI data by blind separation into spatial independent component

analysis. Human Brain Mapping (1998), 6, 160-188.

4. A. Hyvärinen, J. Karhunen, E. Oja: Independent Component Analysis, Wiley, 2001

5. A. Cichocki, S.I. Amari: Adaptive Blind Signal and Image Processing, Wiley, 2002

6. M.J. McKeown, T.J. Sejnowski: Independent component analysis of fMRI data: examining

the assumptions. Human Brain Mapping (1998), 6, 368-372

7. C. Papathanassiou, M. Petrou: Incorporating prior knowledge in ICA, Digital Signal

Processing 2002. IEEE 14th Int. Conf. On, (2002) 2, 761.64.

8. W. Lu, J. Rajapakse: Eliminating indeterminacy in ICA, Neurocomputing (2003), 50, 271-

290.

9. V.D. Calhoun, T. Adali, M.C. Stevens, K.A. Kiehl, J.J. Pekar: Semi-blind ICA of fMRI: a

method for utilizing hypothesis-derived time courses in spatial ICA analysis, Neuroimage,

(2005), 25(2), 527-538.

10. A. Hyvärinen: Fast and Robust Fixed-Point Algorithms for Independent Component

Analysis, IEEE Trans. on Neural Networks, (1999), 10(3), 626-634.

11. S. Kirkpatrick, C. D. Gelatt, Jr., M.P. Vecchi: Optimization by simulated annealing,

Science, (1983), n. 4598,.

12. Handbook on algorithms and theory of computation, M.J. Atallah editor, CRC Press,

(1998).

13. F. Esposito, E. Formisano, E. Seifritz, R. Goebel, R. Morrone, G. Tedeschi, F. Di Salle:

Spatial independent component analysis of functional MRI time-series: To what extent do

results depend on the algorithm used?, Human Brain Mapping, (2002) 16(3), 146-157.

34
