C# TEMPLATES FOR TIME-AWARE AGENTS

Merik Meriste, Tõnis Kelder, Jüri Helekivi

University of Tartu, 50090 Tartu, Estonia

Leo Motus

Tallinn Technical University, 19086 Tallinn, Estonia

Keywords: software agent, time-aware agent, multi-agent system, agent based programming, agent engineering

environment, construction

of time-aware agents

Abstract: Autonomous behaviour of components characterises today computer applications. This has introduced a

new generic architecture – multi-agent systems – where the interactions of autonomous proactive

components (agents) – are decisive in determining the behaviour of the system. Increasingly, agent-based

applications need time-awareness of agents and/or their interactions. Therefore the application architecture

is to be enhanced with sophisticated time model that enables the study of time-aware behaviour and

interactions of agents. The focus of the paper is on the inner structure of a time-aware agent, the enabling

infrastructure for agent’s time-sensitive communication, and the class templates for the construction of

time-aware multi-agents. The prototype development is carried out in C# since this platform is suitable for

controlling multiple simultaneous threads, and flexible to handle sophisticated time models.

1 INTRODUCTION

Autonomous behaviour of components characterise

today computer applications. This has introduced a

new generic architecture – multi-agent systems –

where the interactions of autonomous components

i.e. agents – are decisive in determining the

behaviour of the system. A typical multi-agent

system has a distinctive property that is usually not

present in non-agent systems – the complete list of

interacting agents and the structure of their

interactions cannot be fixed at the design stage. Two

interesting research areas can be outlined here. First,

development of appropriate techniques and tools for

programming agents as well as for agent based

programming. Second, for many practical

applications multi-agent architecture should be

enhanced with time in order to study time-sensitive

behaviour and interactions of agents. For example, a

real-time system can be considered as a loosely

coupled collection of autonomous agents with time-

critical constraints on agents’ behaviour.

Multi-agent systems rely essentially on

beha

oural features that cannot be specified in

conventional algorithmic computing, but are

inevitable in real-time, autonomous, and/or proactive

computing systems. Examples of such features are

persistency, interaction with an environment, time-

sensitivity, and emergent behaviour. Many aspects

of those features cannot be completely specified in

advance – their presence depends on the dynamic

operational situations where the components of a

multi-agent system and its environment interact.

Attempts to handle and analyse the above-mentioned

features within the paradigm of algorithmic

computing have led to theoretical difficulties (Blass,

2003; Wegner, 1998).

In principle, an autonomic object with full

cont

ol over its state forms a pragmatic basis for

agent’s implementation. An agent implementation

needs additional control threads to support its time-

sensitive proactive behaviour. The implementation

of multi-agents with complex interactions among its

members remains a serious problem in software

engineering practice. The more sophisticated a

community of agents and their time-sensitive

interactions are, the more research needs to be

involved for resolving the implementation problem.

247

Meriste M., Kelder T., Helekivi J. and Motus L. (2005).

C# TEMPLATES FOR TIME-AWARE AGENTS.

In Proceedings of the Seventh International Conference on Enterprise Information Systems, pages 247-250

DOI: 10.5220/0002508402470250

 SciTePress

A multi-agent system that operates in time-

sensitive environment has a major additional feature

as compared to conventional real-time systems – the

participating agents and their interaction patterns

may change dynamically during integration, testing,

and also during normal operation. This feature has

always been desirable in real-time systems, but has

deliberately been avoided to increase the

behavioural determinism. The component-based

design and steadily increasing pro-activeness of

components have raised the role of emergent

behaviour in real-time systems to the level that

assumes reconsidering the behavioural analysis and

finding new ways of achieving behavioural

determinism.

This paper describes the structure of an agent in

a prototype of agent engineering environment

KRATT that is being developed for engineering

time-aware agents (Motus, 2002). The focus of the

paper is on the inner structure of a time-aware agent,

the enabling infrastructure for agent’s time-sensitive

communication, and the class templates for the

construction of time-aware multi-agents.

The prototype development is carried out in C#

and .NET since this platform is the most suitable for

controlling multiple simultaneous threads, and is

flexible to handle sophisticated time models (Selic,

2003). C# classes for the composition of agents are

described in section 2.

2 C# CLASSES FOR AGENTS

Time-aware agents exist and interact in a computer

system that is distributed across a set of, not

necessarily homogeneous, networks. The agents can

exist completely in a virtual world – interacting only

with the other agents, or also interacting with non-

agent components of the system.

An application consists of administrative agents,

and application agents. All the agents are generated

from classes pre-specified in C# language. Classes

form as a namespace AgentComponents.

2.1 Namespace AgentComponents

An agent (see also figure 1) is an instance of a base

class Agent in the namespace AgentComponents.

The class determines functionalities and lists related

components that are to be applied to generate an

instance of a time-aware agent. As a rule, a multi-

agent system comprises several agents; each agent is

implemented as Windows application (WinA).

Basic components of class Agent are:

• Communicator, exchanging time-stamped

messages with the other agents;

• Manager, managing strategic and operative time-

sensitive control of agent’s functioning;

• Actor, performing the functional tasks;

• Monitor, monitoring specified aspects and time-

stamped events in the agent’s behaviour.

Each component is described by a class in the

namespace AgentComponents. In the most cases the

Communicator is standardised, whereas the other

components are different in different applications.

Definition of a class of agents starts from

defining, at least, four primitive classes.

1) Property.

Property is a specification of an

agent or its component and is used for introduction

of an agent to its partners. Public class Property

belongs to the Namespace AgentComponents.

2) Service.

Service defines public services that

an agent can offer to its partners, the list of services

is stored by the Agent Management System (AMS)

and is available to agents registered with this

particular AMS. Each service has a name, service

type, and a list of service properties. An agent may

provide several services, described as particular

instances of public class Service.

3) AgentMessage

is an object that Communicator

sends to Manager (or to other components) for

further processing. A message usually has a form

that is imposed by communication protocols

combined with actions of encryption and/or

decryption systems. A public class AgentMessage

specifies the object AgentMessage. An

AgentMessage comprises two parts – header of the

message and body of the message. The header is

Agent Application (WinA)

Main Window

main()

Run()

AGENT

Manager

Actor

Monitor

Report

Config_

file

.xml

Services

events

Network

traffic

Communication with

physical world

Figure 1: Generic description of an agent

ICEIS 2005 - SOFTWARE AGENTS AND INTERNET COMPUTING

248

processed by methods of the class AgentMessage,

within the class Communicator. The body of the

message is not processed by Communicator but is

forwarded to Manager (or to the other addressees

respectively).

4) AgentDescription

contains the agent’s name,

lists of properties and services (meant for public use)

of the agent. AgentDescription is an instantiation of

a public class AgentDescription. AgentDescription is

applied to configure agents and to register agents

with an AMS.

2.2 Application Agents

Majority of agents, instantiated from the classes in

the namespace AgentComponents, carry out their

autonomous and proactive tasks. Application agents

belong to the public class Agent: AgentDescription.

Class Agent, the basic class of the namespace, is

derived from the class AgentDescription and may

contain all components of an agent, as variables:

Communicator communicator;

Manager manager;

Actor actor;

Monitor monitor.

When specialising a class Agent it is necessary, as a

rule, to specialise its components Communicator,

Manager, Actor, and Monitor. In the same WinA are

constructed all components of the Agent. One has

also to rewrite the respective constructor in order to

substitute the construction of components with the

construction of specialised (inherited) objects.

Instantiation of a representative of the base class

Agent is carried out by method init that has to be

rewritten if one wants to specialise the particular

class of agents.

2.3 Agent’s components

An application agent is a complex that comprises

several components described as follows.

1) Communicator implements the inter-agent

communication and interaction with the other agents

in the system. Communicator’s functionality is

standardised, e.g. it may implement the layers of

Agent Communication Language, FIPA. In principle

it could be an agent on its own. In its present

implementation it is an object instantiated from

public class Communicator.

Method Communicator.init invokes a thread that

waits for information from network, addressed to

port Port. This thread is simultaneous with the other

threads invoked within this agent. When a message

from the network is received, a method

Communicator.client is invoked – the thread waiting

for new network messages remains active. Thus, the

Communicator can process several network

messages concurrently. Specific synchronisation

services or appropriate time services support the

synchronisation of concurrent processing of

messages, whenever necessary. Those services and

primitives can be implemented as specific

application agents providing those services for other

agents of a particular multi-agent system.

Method Communicator.SendReply sends a

message to the partner agent and waits for response.

The response (possibly empty) is transformed to the

AgentMessage form and is the value of this method.

A method Communicator.shutdown terminates

the network message waiting thread of the

Communicator. Terminating of the Agent

automatically terminates the Communicator.

2) Manager is a public class whose instance

guides interaction between Communicator and

Actor, maintains the goal function(s) that define and

rule the proactive behaviour of the agent, and

controls learning and/or adaptability of the Actor.

The only method defined in the class is

Manager.Handle that is typically invoked by

Communicator. The method Manager.Handle

executes as an independent thread and must be re-

enterable. The other methods are to be defined

during the derivation from the class Manager.

3) The public class Actor implements direct

functional and non-functional requirements of an

agent. Hence its methods and attributes depend

heavily on a specific application, and very little can

be predefined. The modified constructor guarantees

communication with the other components of the

agent, and communication with the real world

objects (outside of the computer system) if

necessary.

4) Monitor is a component that monitors the

operation of the agent. Based on the monitoring

results it prepares periodic reports and forwards

those (upon request) to MonitorAgent that is

responsible for behaviour monitoring and self-

diagnosing of this particular multi-agent system.

Monitor records events and processes voluntarily

reported by the other components of an Agent. A

public class MonitoredEvent defines an abstract

event as an instantaneous phenomenon that has time

instant of occurrence, type of the phenomenon,

optional description of the phenomenon, and some

quantitative characteristics of the event. A public

class MonitoredProcess defines an abstract process

as an activity that has a starting time, termination

time, type of the activity, optional description of the

activity, and some quantitative characteristics of the

process.

C# TEMPLATES FOR TIME-AWARE AGENTS

249

Request for recording is done by a Monitor

method Record (MonitoredEvent event) or Record

(MonitoredProcess process). Monitor provides a

report in XML format; the report is based on

monitored events and processes, and includes self-

diagnosis results.

2.4 Administrative Agents

Administrative agents are specific in a sense that

they store and execute the rules, and provide

common services, required for expected normal

operation of application agents. Administrative

agents are also instances of classes of the namespace

AgentComponents.

1) Agent AMS for management of application agents

Instances of this class provide specific services, such

as authentication and registration of agents who plan

to operate within the domain of this particular AMS;

keeping a directory that lists the agents, their

location, their public resources and services, etc.

Agents of this class also keep track of the active

agents, agents who have temporarily suspended the

operation, and agents who have left the directory for

various reasons. Agents of this class also assign each

registered agent a port for messages from the other

agents provide search engine services for registered

agents who look for potential cooperating partners

can suspend, or terminate operation of any agent, if

necessary.

2) Agent ProxyAgent

Representative of this class may serve as a

switchboard for transferring messages to and from

the addressee whose address is not publicly available

– e.g. agents that reside behind a firewall. The

second area for using a ProxyAgent is debugging

and monitoring the traffic between application

agents. ProxyAgents of have to register themselves

with the corresponding agents from class AMS.

3) Agent MonitorAgent

Representatives of this class are agents that collect

and process activity reports from Monitor classes

within application agents. This information can be

used for analysing the properties of the application

system run-time, or during the post-mortem analysis.

Again, the designer may instantiate several agents of

this class with slightly different functions, if

necessary.

3 CONCLUSIONS

A clear rise of interest can be observed to applying

agents, and multi-agent systems in situations that

assume time-awareness, or even are essentially time-

critical. This could be caused by the successful

practice of building component-based systems,

combined with the fact that increasingly the

autonomous, and proactive components are being

used. The evolution of computer science is gradually

reaching the understanding that interactive systems

represent a new paradigm in computation (Wegner,

1998; Blass, 2003). The basis for this empirical

computer science research relies on two

contradictive concepts – inside-view to prescribe the

behaviour of an agent (i.e. programming), and

outside-view to design and analyse (i.e. modelling).

In this paper the agent specific structure

implemented for agent engineering environment

KRATT was considered. KRATT enables to develop

time-aware software agents. The focus of this paper

was on the inner structure of an agent that explicitly

enables to elaborate its time-awareness features, on

communication primitives of agents, and on the

classes of agents.KRATT is still under development.

ACKNOWLEDGMENTS

This research has been partially financed by

Estonian Science Foundation (ETF) grant no. 4860,

and by grants no. 014 2509s03 and no. 018 2565s03

from the Estonian Ministry of Education. This

support is gratefully acknowledged.

REFERENCES

Blass, A. and Gurevich, Y., 2003. Algorithms: A quest for

absolute definitions. Bulletin of European Association

for Theoretical Computer Science, no. 81, 30pp.

Motus, L., Meriste, M., Kelder, T., Helekivi, J., 2002. An

Architecture for a Multi-agent System Test-bed. Proc.

of the 15th IFAC World Congress, vol. L, Elsevier

Science Publ., 6p.

Selic, B. and Motus, L., 2003. Modeling of Real-time

Software with UML. IEEE Control Systems Magazine,

vol.23, no.3, 31-42.

Wegner, P., 1998. Interactive foundations of computing.

Theor.Computer Science, vol. 192, 315-351.

ICEIS 2005 - SOFTWARE AGENTS AND INTERNET COMPUTING

250
