SYNTHESISE WEB QUERIES

Search the Web by Examples

Vishv Malhotra, Sunanda Patro, David Johnson

School of Computing, Private Box 100, University of Tasmania, Hobart 7001 Australia

Keywords: Boolean expression, web search query, web search engine, World Wide Web, Recall and precision of query

Abstract: An algorithm to synthesise a web search query from example documents is described. A user searching for

information on the Web can use a rudimentar

y query to locate a set of potentially relevant documents. The

user classifies the retrieved documents as being relevant or irrelevant to his or her needs. A query can be

synthesised from these categorised documents to perform a definitive search with good recall and precision

characteristics.

1 INTRODUCTION

The primary contribution of the paper is an

algorithm that synthesises web search queries from

examples of text documents categorised as relevant

and irrelevant to the needs of a web searcher. The

synthesised query would locate web links to

resources relevant to the searcher as inferred from

the examples. The three primary objectives for the

algorithm are to ensure that the synthesised query

has good recall; good precision; and not the least, is

of a form and size acceptable to the intended search

engine (Sebastiani 2002, Brin and Page 1998).

The rest of this paper is organised as follows.

Sect

ion 2 gives an overview of the algorithm and

uses examples to explain and provide a context for

later sections. Sections 3, 4 and 5 describe the three

main building block of the query synthesiser. Some

of the issues arising from the algorithm and its

current implementation are discussed in the final

section.

2 PRELIMINARIES

A literal is an expression that is either a single term

or its negation. In this paper, Boolean operator NOT

(!) takes precedence over other Boolean operators.

A minterm is a sequence of literals combined by

Boolean operator AND (&). We would use Google

convention to use AND (&) as lowest precedence

and implied (not explicitly written) operator. A

sequence of minterms combined by Boolean OR (|)

operation is disjunctive normal form (DNF) of the

Boolean expression. A maxterm is a sequence of

literals combined by Boolean OR operations. A

Boolean expression is in conjunctive normal form

(CNF) if it is made of maxterms combined by

operator AND. For further information about the

Boolean expressions the reader may wish to see

(Aho and Ullman, 1992) as an excellent reference.

A se

arch query is suitably compacted

representation of a DNF Boolean expression with at

least one positive literal in each minterm. To help

presentation of the algorithms in the later sections,

we define a selection operation σ: For a set of

textual documents, D, and a search query, Q,

expression D σ Q will be used to denote a search

by query Q over set D. An operational interpretation

of expression D σ Q is as follows:

Case: Q is ter

m {doc | doc ∈ D and

term occurs in document

doc}

Case: Q is !te

rm {doc | doc ∈ D &

term does not occur in

document doc}

Case: Q is (R &

S) (D σ R)

σ S

Case: Q is (R |

S) (D σ R) ∪ (D σ S)

The current implementation of the query

syn

thesis algorithm requires the initial search query

for retrieving example relevant and irrelevant

documents to be a minterm comprising of positive

literals. In this paper, the terms in the initial query

minterm are deemed to occur in each document. A

real document may not have query terms because

search engines use, in addition to the text in the

291

Malhotra V., Patro S. and Johnson D. (2005).

SYNTHESISE WEB QUERIES - Search the Web by Examples.

In Proceedings of the Seventh International Conference on Enterprise Information Systems, pages 291-296

DOI: 10.5220/0002510202910296

 SciTePress

document, text near the links to the document in the

other documents to index the linked document.

For a set, S, |S| denotes its cardinality – the

number of elements in the set. For example, for a

Boolean expression BE and sets Relevant and

Irrelevant we define its precision as: precision(BE)

= |Relevant σ BE|/|Irrelevant σ BE|. The case where

denominator is 0 is handled by assigning a suitable

large value as precision.

The five main steps in the query synthesis

algorithm are:

i. Construct CNF (conjunctive normal form)

Boolean expression that selects every document

in set Relevant and rejects documents in set

Irrelevant. This expression is typically long

with many terms and Boolean operators to be

efficient and effective search queries. See

Section 3 for more details.

ii. Convert CNF Boolean expression into an

equivalent DNF Boolean expression. Remove

redundant minterms from the DNF expression.

These minterms will be called p-minterms. Step

5 would modify the p-minterms to aid

construction of an acceptable size search query.

This will be discussed further in Section 3.1.

iii. Synthesise a Boolean expression Query by

assembling a subset of minterms such that

Query selects every document in set Relevant.

Rewrite Query in a form suitable to the chosen

web search engine. Details are in Section 4.

iv. If Query is acceptable to the search engine, stop.

Boolean expression Query is the required search

query. Otherwise,

v. Derive a set of minterms from p-minterms that

supports synthesis of a better balanced search

query. Go back to step 3 to synthesise a new

candidate query. Section 5 deals with this issue.

2.1 Examples

To set a context and explain the steps in the

algorithms, some example queries are given in Table

1. These queries were run over Google search engine

to locate links to resources. A query with a single

term (naïve query) was initially generated to retrieve

documents for defining sets Relevant and Irrelevant.

Only text documents are included in these sets.

These sets are then used to synthesise a new query.

The case of query regarding rainbow needs some

further comments. In this case, the initial set

Relevant had very few (three) documents for an

effective synthesis of a query. The synthesised

query (rainbow sky) did not perform well.

However, the query synthesised from the documents

retrieved by this query proved to be a good search

query.

3 CONSTRUCT CNF BOOLEAN

EXPRESSION

The search query synthesis begins with construction

of a CNF Boolean expression that selects all relevant

documents and rejects irrelevant documents. The

Boolean expression can be constructed by repeatedly

constructing maxterms to cover all relevant

documents and reject many irrelevant documents.

Sanchez, Triantaphyllou, Chen and Liao (2002) have

reported an algorithm for maxterm construction by

endeavouring to reject the irrelevant documents that

have not been rejected by the previously constructed

maxterms. Thus, after each successive stage, the

conjunction of maxterms rejects more irrelevant

documents.

We make two important changes to the reported

algorithm to make it suitable for synthesising search

queries.

i. We construct maxterms containing only positive

literals. This conservative arrangement is

appropriate because sets Relevant and Irrelevant

do not characterise a closed world of

documents.

Table 1: Examples of queries accessed using Google search engine. Type indicates the source of the query: naïve

synthesised using the algorithm described in this paper, or a first attempt by a human.

Purpose

& Type

Search query Query

size

Relevant

accessed

Irrelevant

accessed

Information about radioactive element Radium.

Naive radium 1 19 41

Synthetic radium (((element | period) number) | ((element | metal) uranium)) 7 62 8

Human radium element radioactive 3 50 20

Information regarding rainbow that appear in sky after a rain.

Naive rainbow 1 3 52

Synthetic (rainbow sky) 2 16 48

Synthetic rainbow light (raindrop | higher | copyright | solar | (hand index dark)) 9 43 27

Human (rainbow rain color) 3 37 33

ICEIS 2005 - ARTIFICIAL INTELLIGENCE AND DECISION SUPPORT SYSTEMS

292

ii. Each term (word in the example documents) is

prioritised to reflect its potential as the next

candidate term in the maxterm under

construction.

Definition

The potential of a candidate term is defined by the

number of new relevant and irrelevant documents it

selects. The potential for term t during construction

of (i+1)

maxterm is computed as follows

(maxterm

is the partially constructed (i+1)

maxterm):

TR = Relevant – (Relevant σ maxterm

);

= TR σ t;

TIR = Irrelevant σ (maxterm

& …& maxterm

));

TIR

= TIR σ t;

Potential(t) =

((|TR

|)(|TIR|–|TIR

|))/((|TR|–|TR

|+1)(|TIR

|+1)).

□

An algorithm for constructing CNF Boolean

expression is shown in Figure 1. The algorithm

terminates successfully when a conjunction of

maxterms rejects every irrelevant document. The

changes made to the algorithm could, in some rare

cases, lead to a failed run of function

Build_Maxterm. If all terms in a relevant document

are also in an irrelevant document then it is not

possible to find a term for a maxterm that would

select the relevant document but would reject the

irrelevant document. It is practical to remove these

irrelevant documents from set Irrelevant. The price

for this action is a small reduction in the precision of

the synthesised query.

3.1 Eliminate Boolean Expression

Redundancies

The Boolean expressions constructed by algorithm

Build_CNF_BE frequently has too many terms for

an effective and efficient processing by the web

search engines. As an example of a constructed

Boolean query consider the case of search for

information about rainbow shown in Table 1.

Starting with query (rainbow sky) a set of 16

relevant and 48 irrelevant documents were

identified. The Boolean expression for this example

sunlight | american) (red | copyright | download |

index) (light) (water | green | board | dark).

Clearly, the query is not suitable for a Google

search.

To eliminate some redundancy the synthesised

CNF Boolean expression can be transformed into an

equivalent DNF expression using the distribution

property: A (B | C) ≡ (A B) | (A C). The application

Build_CNF_BE

Input: Relevant, Irrelevant, Original Query.

Output: BoolExp

Description: BoolExp selects all documents in set Relevant and rejects virtually all documents in set Irrelevant.

TIR := Irrelevant;

for (i := 1; TIR != {}; i++) {

Maxterm

:= Build_Maxterm(Relevant, TIR);

If (no Maxterm

possible) break;

TIR := Temp σ Maxterm

;

}

BoolExp := (Initial Query) & Maxterm

& Maxterm

& …;

Build_Maxterm

Input: Relevant, TIR

Output: maxterm

Description: maxterm selects every document in set Relevant and rejects some document in set TIR

TR := Relevant;

for (j := 1; TR != {}; j++) {

Candididate_terms_sorted := sort_candidates(set_of_terms_in(TR));

Term

:= Randomly_select_one_from_top_n(Candidate_terms_sorted);

TR := TR – (TR σ Term

);

}

maxterm := (Term

| Term

| …| Term

);

Figure 1: Algorithm to construct a Boolean expression that selects all relevant documents and reject irrelevant

documents.

SYNTHESISE WEB QUERIES: Search the Web by Examples

293

of this rule would generate 7x7x4x4=784 minterms,

each with 6 (or fewer) terms for the above example.

Equivalence of two forms of the Boolean expression

– the original CNF and the transformed DNF –

implies that each minterm would reject each

document in set Irrelevant. The set of minterms in

the DNF Boolean expression collectively select

every document in set Relevant. However, an

individual minterm may or may not select any

document in set Relevant. Minterms that do not

select any document in set Relevant are redundant

and can be removed. All but 241 minterms of the

original 748 minterms in DNF Boolean expression

for the rainbow query were removed through an

application of this rule.

We also remove those minterms from this set

that select a proper subset of relevant documents

selected by another minterm in the set. As a further

step in redundancy reduction, terms are removed

from minterms if their removal does not lead to

selection of an irrelevant document. The minterms

surviving these purges constitutes p-minterms (p

signifies precise, perfect or preferred).

4 SEARCH QUERY: MINIMUM

MINTERM COVER FOR SET

RELEVANT

A minimal set of minterms that selects each

document in set Relevant constitutes a search query.

The set of p-minterms collectively selects all

documents in set Relevant. At the same time, a

document may be selected by several minterms. For

example, the query concerning rainbow has 16

relevant documents, but has 241 p-minterms. No

more than 16 minterms are needed to select 16

documents. As the minimisation problem is in NP-

Complete, we use a heuristic to construct a minterm

cover for set Relevant.

A number of heuristics are possible to meet the

goal of keeping the size of the query small while

covering every document in set Relevant. The

Search query synthesis heuristic we use, builds

covering minterm set by selecting a minterm at a

time from the set of available minterms. A greedy

choice is made to select the minterm based on the

number of new relevant documents selected by the

minterm divided by the increase in the query size.

Apte, Damerau and Weiss (1994) have reported

a more sophisticated heuristic for a similar problem.

In their approach, an augmentation is either an

addition of a new minterm to the query or is a

substitution of a minterm in the query with another

minterm. In our heuristic, we derive similar benefits

by using a genetic algorithm approach. We construct

the query several times by starting with a randomly

selected first minterm. The query with the smallest

number of terms is affirmed as the search query.

Given a set of minterms comprising a query it is

useful to define function minimise to transform the

set into a query acceptable to Google (or some other)

search engine. We use the number of terms in this

minimised query as its size. An exact syntax of an

acceptable query for Google is not well defined.

Thus, we use a simplistic algorithm to minimise the

query representation. To construct a minimal query

from a given set of minterms the function identifies

a term that occurs most frequently in the query

minterms. The set of minterms can be partitioned

into two sets.

i. A set of minterms that do not contain the

identified term.

ii. The set of minterms that contains the term. The

term is factored out of these minterms by using

equivalence: (A B)|(A C) ≡ A (B | C).

The minimisation function is then applied

recursively to two sets to take advantage of other

terms that can be used to reduce the query size. As

an example consider the DNF expression: (radium

element number) | (radium period number) | (radium

element uranium) | (radium metal uranium). The

expression has 12 terms. The number of terms can

be reduced to 7 by the minimisation algorithm

leading the following query: radium (((element |

period) number) | ((element | metal) uranium)).

Deeply nested expressions may not be accepted by

some search engines. Consequently we would avoid

synthesising such queries.

In our experiments we noticed only a few cases

of queries with more than 10 terms when

synthesised from p-minterms. Typical query is well-

sized for the search engines. An oversize query for

the rainbow example is: rainbow ((raindrop light) |

(((higher red) | solar) water) | (bow copyright) |

(term red) | (hand index dark)).

5 FITTING QUERY TO SEARCH

ENGINE

If a synthesised query has too many terms it needs

modifications to help synthesise acceptable queries.

This issue will be discussed in this section.

Size of a query can be reduced to fit it to the

constraints of a search engine. However, it would

attract cost in terms of loss in its ability to select all

relevant documents or not being able to avoid all

irrelevant documents. If query size is reduced by

reducing its ability to select all relevant documents,

we need to perform supplementary searches to

ICEIS 2005 - ARTIFICIAL INTELLIGENCE AND DECISION SUPPORT SYSTEMS

294

ainbow

erm

rainbow solar water

rainbow higher red water

account for the documents that we might miss.

Human users tend to use this mode of search. If a

query fails to return a satisfying collection of

relevant links, the query is modified to seek other

links of interest. In contrast to human-controlled

interactive web session, the aim of a synthesised

query is to make each search comprehensive by

keeping the recall at its highest level and seek to

reduce query size by sacrificing precision. Thus, we

seek a query that meets the constraints of the search

engine and selects every document in set Relevant.

However, in addition it may select documents in set

Irrelevant. The goal is to minimise the number of

selected documents from the latter set.

For the oversized query for rainbow, the query

can be made smaller in size by removing terms (for

example) water, solar, higher or red. A term is

removed by replacing it by Boolean constant true.

The terms in the initial query are not available for

removal as such a change may alter the membership

of sets Relevant and Irrelevant. Each removal of

term from a query affects its size differently. For

example, the rainbow query will be one term smaller

if one of the terms, water, higher or red is removed

from it. It will be smaller by three terms if term

solar is removed.

A removal of a term from a minterm may cause

it to select a few irrelevant documents. Thus, there is

a lowering in minterm’s ability to reject irrelevant

documents. As an approximation, we measure the

precision of a query by the minimum precision of its

composing minterms. Consequently, query obtained

by removing term water has precision minimum

{precision(rainbow solar), precision(rainbow higher

red)}. On the other hand, if term solar is removed, it

will be precision(rainbow water). The irrelevant

documents are likely to have lower correlation

among distributions of query terms. These

observations lead us to a simple and effective

method for reducing the query size by lowering their

precision in a controlled way.

The method involves replacing two or more p-

minterms by a single minterm implied by each of the

p-minterms. The replacing minterm selects all

relevant documents selected by the replaced p-

minterms. It has fewer terms thus helping the

synthesised query to be smaller in size. However,

the query would have some lowering of its ability to

reject all irrelevant documents.

Alternately, one could attempt to create smaller

queries by defining minterms at lower precision

values by removing one or more terms from p-

minterms. However, such an approach may generate

a lot of minterms with only marginal advantage in

reducing the query size. The method suggested in

the previous paragraph is able to generate a well

spread lattice of minterms (see Figure 2) to

synthesise query near any required precision value.

A reduction in size of a synthesised but oversize

query by removal of some terms from its minterms

must compete against other queries that may be

synthesised through similar concessions. Thus, the

query synthesis is repeated whenever minterms have

been affected by a transformation that alters their

precisions.

The rest of this section contains a series of

definitions that provide an outline of a method for

constructing sets of minterms from p-minterms. The

basic idea will be to give a method for deriving

implied minterms from the given set of p-minterms.

Next we will define a set by selecting minterms

meeting a stipulated precision property. The set will

be called a set of good minterms. An important

property of p-minterms that the set preserves is the

ability to cover all relevant documents. Thus, using

minterms in the set, one can synthesise a query at a

precision value matching the precision of the

minterms in the set. If the query turns out to be too

ainbow

rainbow water

…

rainbow (Initial query)

Figure 2: A part of lattice spawned by p-minterms for rainbow query.

SYNTHESISE WEB QUERIES: Search the Web by Examples

295

large, the synthesis is repeated by constructing a new

set of good minterms at the next lower precision

level for which minterms can be found. The initial

query guarantees that the repetitions will eventually

terminate successfully; in the worst case we may

have the initial query as the best query for the

search.

Definition

Let R and S be two sets of minterms, coalesce(R, S)

is a set of minterms defined as follows:

coalesce(R,S) = {π(r,s) | r ∈R and s ∈S },

where π is defined as follows:

π(m

) = m, where m is a minterm such that

⇒ m, m

⇒ m, and for every minterm m’

⇒m’⇒m; m

⇒m’⇒m) ⇒ (m’≡m). □

Definition

Let M be a set of p-minterms. We derive set of all

useful minterms, U as follows: U = M

∪ M

…;

where M

= M and M

i+1

= coalesce (M

, M).

□

The finite size of set of terms makes it easy to

see that for some finite k, M

= M

k+1

. To each u ∈ U

we associate precision(u) = |Relevant σ u|/

|Irrelevant σ u|; where denominator is 0, a large

value is assigned as precision.

A set of minterms where each minterm meets a

stipulated constraint precision value is a set of good

minterms. These minterms can be used to synthesise

query at the matching precision level. Formally,

Definition

GoodMinterms(U, p) = {u∈U | precision(u)≥ p &

∀w∈U [(u ⇒ w) ⇒ ((precision(w) < p)|(u≡w))]}

□

The precision values in set U are discrete; by

progressively lowering the value one can derive a

query that meets the search engine constraints at the

best precision value possible.

6 CONCLUDING REMARKS

The paper has described a method for constructing

search query from a collection of relevant and

irrelevant text documents. The method constructs the

query by following a series of stages. Each stage is a

greed-driven heuristic to certain goals. In our

experiments, we found the greedy approach to be

adequate; there is little need to seek optimised and

perfect Boolean expressions as there are

uncertainties outside our controls. For example, the

small number of documents used to construct the

query can only define a very imprecise image of

documents and resources on the Web. Efforts spent

on matching this imperfect image would not deliver

proportionate rewards.

The method performs well when a reasonable

collection of relevant and irrelevant documents is

available. As the size of the collection increases, it

becomes better image of the resources on the Web!

Too small a size of the set does not help in synthesis

of a good quality search query. A very large

collection, on the other hand, requires additional

processing effort. Particularly, it will require more

human effort to classify the documents in the

collection. The goal of the exercise is to reduce

human effort. A set of about 10 relevant documents

with 10 to 20 irrelevant documents are generally

adequate.

The constructed queries include some unintuitive

terms. However, the queries retrieve fresh links and

are precise when used over the Web. An unintuitive

term is one that web searchers are not likely use in

queries. An unintuitive term is not a counter-

intuitive term.

The tests that we have conducted using the

algorithm to this stage have shown very good

improvements in the quality of links to resources in

comparison with the links retrieved using naïve

queries. Even in the areas well understood by a user,

the synthesised queries have performed better than

those constructed by humans. Some performance

results are available in Patro and Malhotra (2005).

REFERENCES

Aho, A.V. and Ullman, J.D., 1992. Foundations of

computer science, Computer Science Press, New

York.

Apte, C., Damerau, F.J., and Weiss, S.M., 1994.

Automated Learning of Decision Rules for Text

Categorisation, ACM Transactions on Information

Systems, 3(12). 233-251.

Brin, S. and Page, L., 1998. The anatomy of a large-scale

hypertextual web search engine, J. Computer

Networks and ISDN Systems, 30(1). 107-117.

Patro, S. and Malhotra V. 2005, Characteristics of the

Boolean web search query: Estimating success from

characteristics, http://eprints.comp.utas.edu.au:81/

Sanchez, S.N., Triantaphyllou, E., Chen, J. and Liao,

T.W., 2002. An Incremental Learning Algorithm for

Constructing Boolean Functions from Positive and

Negative Examples, Computers and Operations

Research 29(12). 1677–1700.

Sebastiani, F. 2002. Machine learning in automated text

categorization, ACM Computing Surveys, 34(1): 1-47.

ICEIS 2005 - ARTIFICIAL INTELLIGENCE AND DECISION SUPPORT SYSTEMS

296
