Appearance-based Face Recognition using
Aggregated 2D Gabor Features
King Hong Cheung
1
, Jane You
1,
* Qin Li
1
and Prabir Bhattacharya
2
1
Department of Computing
The Hong Kong Polytechnic University, Kowloon, Hong Kong
2
Concordia Institute for Information Systems Engineering,
Concordia University, Montreal, Quebec, H3G 1T7, Canada
Abstract. Current holist
ic appearance based face recognition methods require a
high dimensional feature space to attain fruitful performance. In this paper, we
have proposed a relatively low feature dimensional, template-matching scheme
to cope with the transformed appearance-based face recognition problem. We
use aggregated Gabor filter responses to represent face images. We investigated
the effect of “duplicate” images (images from different sessions) and the effect of
facial expressions. Our results indicate that the proposed method is more robust
in recognizing “duplicate” images with variations in facial expression than the
Principal Component Analysis method.
1 Introduction
Biometric recognition, or simply biometrics, is concerned with the automatic
recognition of individuals based on their biological/physiological or behavioral
characteristics. Although we do not expect that a single biometric to satisfy all
identification requirements, the use of such unique, reliable and stable personal features
has attracted considerable interest in the development of biometrics-based
identification systems for civilian, military, and forensic applications that has attained
certain level of maturity [8]. Among the many body characteristics that have been used,
face is one of the most commonly used characteristics and has been studied across a
number of research fields, e.g. computer vision, pattern recognition [6],[9],[17],[18].
Face recognition is a non-intrusive method that captures still images and/or video
sequences - from controlled, static environment to uncontrolled, cluttered environment;
we can perform recognition using 2D images and/or 3D models with approaches that
are holistic/global, or feature-based, or structural, or hybrid [19],[8]. Holistic/global
approach generally refers to those methods that take the whole face region as the input
to a face recognition system [19]. A well-known holistic/global approach to face
recognition is applying the principal component analysis (PCA) on preprocessed, or
even transformed, face training images. A subset of principal components forms the
global representation of face for recognition with a suitable (dis)similarity
measure.[15],[11],[5] Another common holistic/global approach is the introduction of
artificial neural networks as the classifier for face recognition [6].
Hong Cheung K., You J., Li Q. and Bhattacharya P. (2005).
Appearance-based Face Recognition using Aggregated 2D Gabor Features.
In Proceedings of the 5th International Workshop on Pattern Recognition in Information Systems, pages 3-11
DOI: 10.5220/0002566700030011
Copyright
c
SciTePress
In the feature-based structural approach, we first need to locate the feature points
and the regions of interest, such as eyes, noses and mouth; then one extracts the features
with the use of various operators or transforms based on their geometric or appearance
characteristics [19]. In [16], this approach is used to locate a set of fiducial points as
nodes of the elastic bunch graph. A small set of Gabor jets (i.e., filter responses) from
an individual is stored at the relevant nodes of the elastic bunch graph for face
recognition. Hybrid approach takes the global (whole face) and local features
consideration that is arguably to be potentially the best approach. This approach is also
used in [6] to allocate each local feature region a support vector machine (SVM)
detector to decompose the face into a set of facial components.
There are three key, interdependent subtasks need to be addressed in automatic face
recognition: (1) detection and rough normalization of faces, (2) feature extraction and
accurate normalization, and (3) identification and/or verification. That is to say, given a
still image or video sequence, the system can first localize face(s) within the image or
video sequence; features are extracted from potential face(s) for
identification/verification [19],[8].
In many commercial and civilian systems, since the environment is static and under
control, full elasticity of the automatic face recognition system may not be required, i.e.
with cooperative subjects, proper 2D frontal image can be obtained. In such a case, the
automatic face recognition problem can be simplified to the classical pattern
recognition/image retrieval problem, which deals mainly with feature extraction and
identification/verification. Texture analysis is one of the main streams in image
processing/analysis and retrieval, especially for monochromatic images. To perform
texture analysis, filtering is one of the popular techniques. 2D Gabor filters proposed by
Daugman [3] are one of the (multi-channel) filtering techniques adopted for texture
analysis because of spatial-frequency localization, tunable in orientations, radial
frequency bandwidths and center frequencies [2]. Characteristic textures contained in
an image can be used to distinguish it. Therefore, we employ texture information for the
retrieval of images containing identical and/or similar attributes.
2D Gabor filters (also known as 2D Gabor wavelets) are the key element in both
holistic/global approach and feature-based/structural approach to face recognition
[16],[17]. They were developed originally to model the receptive field profiles of
mammalian cortical simple cells. Because of biological relevance and computational
properties, they are used for image analysis, especially texture analysis [3],[4],[2],[9].
The holistic/global approach was adopted in Liu et al. [10] where an independent
Gabor features (IGFs) method for face recognition was developed by performing PCA
and then Independent Component Analysis (ICA) on downsampled Gabor filter
responses. In the testing of face databases, they used either manually detected face
images or no detection required and they concentrated on the feature extraction phase
and identification/verification phase. In the feature extraction phase, they first applied
Gabor filters (5 scales and 8 orientations) on the testing images in the frequency domain
and then the filter responses are down-sampled by a factor of 64. The dimensionality is
further reduced by performing PCA on down-sampled filter responses. IGFs are finally
deduced by means of ICA. In the identification/verification phase, the MAP Bayes’
rule is applied using the Probabilistic Reasoning Model (PRM) to perform
classification.
Wu et al. [17] used the feature-based/structural approach to extract Gabor features in
regions of interest such that computation complexity of Gabor features is reduced.
4
They detected the face first and then locate the feature points of interest within the face.
Afterwards, they applied Gabor filters around the eight feature points of interest to
generate filter responses as features for corresponding feature points of interest.
Features points of interest in the query image are matched against the analogous
regions in images registered in the database. The similarity measure between the query
image and registered images is defined as the average of, regular correlation of all
features of feature points of interest.
The feature dimension in [10] and [17] are both comparatively high. We, therefore,
suggested a holistic template-matching approach of relatively low feature dimension
that exploits aggregated Gabor filter responses and distance measures to deal with the
transformed appearance-based face recognition problem.
The organization of the paper is as follows. Section 2 will briefly review the theory
of 2D Gabor filters. Section 3 will outline the rationale of our suggested approach.
Section 4 will discuss the results of our experiments. Section 5 will give our
conclusion.
2 Background
2D Gabor filters proposed by Daugman [3],[4] extended from the original version
(generally referred to as the 1D version) proposed by D. Gabor in communication
engineering, has shown its capability in modeling the receptive-field profiles of simple
cells in mammalian visual cortex. Simple cells in mammalian visual cortex are
organized roughly in the polar Orientation-Frequency plane to form a receptive-field
such that with their specific 2D locations in visual space, preferred orientations and
spatial frequencies, localized 2D spectral information is captured [3]. A set of 2D
Gabor filters, which are of various spatial dimensions and, spatial frequency and
orientation bandwidths to imitate those empirical characteristics of receptive-field, can
be used to extract different kinds of information from images.
2D Gabor filters have been shown to be effective for texture analysis on
monochromatic images. They optimally achieve joint resolution in space and spatial
frequency; their orientations, radial frequency bandwidths and center frequencies are
all tunable. Thereby, it is adopted to perform texture analysis. [2],[4],[10]
2D Gabor filters, in general, are of the following functional form:
h(x, y) = g(x’, y’) exp[2
π
i(Ux + Vy)]
(1)
where (x’, y’) = (x cos
φ
+ y sin
φ
, -x sin
φ
+ y cos
φ
) and
+
=
2
22
2
2
)/(
exp
2
1
),(
σ
λ
πλσ
yx
yxg
(2)
with σ = σ
x
= σ
y
is the standard deviation of the Gaussian envelope
.
The corresponding Fourier transform is
H(u, v) = exp{–2
π
2
σ
2
[(u’U’)
2
λ
2
+ (v’V’)
2
]}
(3)
where (u’, v’) = (u cos
φ
+ v sin
φ
, -u sin
φ
+ v cos
φ
) and
(U’, V’) = (U cos
φ
+ V sin
φ
, -U sin
φ
+ V cos
φ
)
k(x, y) = k
c
(x, y) + ik
s
(x, y) (4)
where
k
c
(x, y) = Re{k(x, y)} = h
c
(x, y) * t(x, y), (5)
5
k
s
(x, y) = Im{k(x, y)} = h
s
(x, y) * t(x, y) (6)
The amplitude and phase (envelopes) of k(x, y) are, respectively,
m(x, y) = [k
c
2
(x, y) + k
s
2
(x, y)]
1/2
(7)
ψ
(x, y) = tan
-1
[k
s
(x, y)/k
c
(x, y)]
(8)
The expanded form of the family of Gabor filters used in our case study is
+
= )
2
exp()'iexp()''4(
8
exp
2
1
),,,(
2
22
22
κ
ω
κ
ω
πσ
θω
xyxyxh
(9)
for
+
=
12
12
2ln2
δ
δ
κ
and
σ
κ
ω
=
where i =
1
,
ω
is the sinusoidal wave frequency in spatial domain, θ is the
orientation of the filter and σ is the standard deviation of the Gaussian envelope [9].
3 Proposed Method
We use aggregated 2D Gabor features, as a relatively low dimensional (space)
representation of face because current appearance based face recognition techniques
require a high dimensional feature space. Liu et al. [10] reported that over 180 features
were needed for the recognition using the FERET data set [14] containing 600 images
(of 200 subjects) in order to attain similar performance of using 85 features with the
ORL dataset containing 400 images (of 40 subjects). In Wu et al. [17], there are 96
dimensions in total; under each dimension, however, it is a filter response of size 20
20. Therefore, the actual dimension used to calculate similarity is much higher. We
therefore proposed a holistic template-matching approach with lower feature
dimension to deal with the transformed appearance-based face recognition problem;
our proposed approach uses the mean and standard deviation of Gabor filters responses,
which is the result of the convolution of Gabor filters with grayscale face images, as
features. Since Gabor filters of three scales and six orientations are adopted for feature
extraction, for the mean and the standard deviation of filter responses, each is of
dimension thirty-six (eighteen each for real and imaginary part of filters’ responses);
that is there are totally seventy-two dimensions/features. Feature vector of a lower
dimensional space can reduce the computation complexity, i.e. increasing speed, as
well as the storage required for face recognition process. Moreover, our proposed
method is a template-matching approach that does not require any training/learning
beforehand.
Assuming the image is of size Y×X and based on Eqs. (5), (6) and (9), the mean (M)
of the real part and the imaginary part of filter responses are
YX
yxk
M
xy
c
c
=
),,,(
),(
θω
θω
(10)
Y
X
yxk
M
xy
s
s
=
),,,(
),(
θω
θω
(11)
Correspondingly, the standard deviation (SD) of the real part and the imaginary part
of filter responses are as follows.
6
1)(
)],(),,,([
),(
2
=
YX
Myxk
SD
c
xy
c
c
θωθω
θω
(12)
1)(
)],(),,,([
),(
2
=
∑∑
YX
Myxk
SD
s
xy
s
s
θωθω
θω
(13)
FV = [M
c
(ω
1
,θ
1
),…, M
c
(ω
3
,θ
6
),
M
s
(ω
1
,θ
1
),…, M
s
(ω
3
,θ
6
),
SD
c
(ω
1
,θ
1
),…, SD
c
(ω
3
,θ
6
),
SD
s
(ω
1
,θ
1
),…, SD
s
(ω
3
,θ
6
)]
(14)
L
1
- and L
2
-norm are adopted as the (dis)similarity measures to define how similar is
one image, in our testing databases, when it is compared to another. Based on the query
face image, the nearest neighbour rule with majority voting scheme helps to determine
the best matched individual within the database.
4 Experimental Results
We used the AR face database [12] from Purdue University in our experiment. After
careful examination of the database, we found that there are images from 135 subjects
(76 men and 59 women) instead of the stated 126, nonetheless. We also found that only
120 subjects (65 men and 55 women) out of the 135 subjects have been taken images in
the two sessions. Therefore, we used only those images from the 120 subjects who have
been taken photographs in two sessions (with 14 days apart between the two sessions).
As there are 13 images are taken in each session, the testing set we used contains 3,120
images (1,560 in each session); each of the 13 images is taken under various conditions:
different facial expressions, illumination settings and occlusions (sunglasses and scarf).
There is no limitation on the participant’s clothes, make-up, ornaments, hairstyles, etc.
[12],[10].
We have converted the color images in to gray scale images of size 192×144 as
images of our testing database. Since there is only one face per image and the face is
roughly located at the center of the image, no face detection is performed.
In our experiment, the images of 50 randomly chosen subjects were used consisting
of 25 males and 25 females. For the image set used, the facial features [11], such as the
center of eyes, in each of the image are first localized. Then each face is aligned upright
based on the center of eyes and the region containing the face is cropped to be of size
55×71; this is analogous to the planar transform suggested in [1]. They are finally
warped to a “standard” face [1]; the warping procedure, which is designed to normalize
the face and to align the facial features to approximately the same pixels, has been
shown to improve recognition results [11],[13]. Afterwards, an oval mask is applied to
remove the highly probable background area to extract only responses (for aggregated
2D Gabor Features) or pixels (for PCA) that are within the mask for feature extraction
[13].
We experimented with our method under four cases: Cases 1-4: ith session match
against jth session (s
i
vs. s
j
) for i =1, 2 and j =1, 2. For Cases 1 (S1 vs. S1) and 4 (S2 vs.
7
S2), images of either 1
st
session or 2
nd
session are used as registered/training and query
images, i.e. no unseen image is expected. For Cases 2 (S1 vs. S2) and 3 (S2 vs. S1),
however, either 1
st
or 2
nd
session is the registered set while the other one is the query set,
i.e. matching “duplicates” [13]. Another candidate under testing is the first 72 principle
components, which is associated with the largest variances, trained with all images
obtained in one session, i.e. either S1 or S2. Since we use PCA as a reference for
performance comparison, evaluation cases described above are tested such that images
in the training sets are from the same session. Moreover, we choose, for PCA, the same
feature dimension as that of aggregated 2D Gabor features because we can determine
the effectiveness of our proposed method directly from the system performance; we
only use one feature dimensionality for experiment as it already captures over 99.75%
of the total variability for either session of the two testing sets.
To study the effect of facial expressions, we conducted the experiment in two stages:
First, only the four images of the neutral expression (under various illumination
conditions) from both sessions, image sets S1n and S2n, are used in stage one; Second,
the seven images without occlusion, image sets S1 and S2 (i.e. S1n/S2n plus the three
with various facial expressions other than neutral, S1f/S2f), are used in stage two.
(a)
(b) (c) (d) (e)
(f)
(g)
(h)
(i) (j) (k)
(l)
(m)
(n)
Fig. 1. A set of warped images of one subject in our testing set; (a)-(g) are from 1
st
session while
(h)-(n) are from 2
nd
session.
A sample set of the fourteen preprocessed (warped) images used is shown in Figure
1. In Figure 1, the first row, i.e. (a)-(g), are images obtained in the first session (S1) and
the second row, i.e. (h)-(n), are those obtained in the second session (S2). In stage one
of experiment, image sets S1n and S2n, i.e. Figure 1 (a), (e)-(g) and (h), (l)-(n)
respectively (400 images in total) are used to test against our proposed method and
PCA similarly. In stage two of experiment, image sets S1 and S2, i.e. Figure 1 (a)-(g)
and (h)-(n) respectively (700 images in total) are used to test against the two methods.
In stage one of experiment, one test, Test I, is conducted using image sets S1n and
S2n to evaluate the performance of the two methods under the four evaluation cases; it
is mainly to determine the performance of the two methods on variations in
illumination.
In stage two of experiment, three tests, Tests II to IV, are conducted. Test II
introduces variations in facial expression in addition to those of Test I. In Test III,
8
image sets containing only the three with various facial expressions other than neutral,
S1f and S2f, are used to query against S1 and S2. Test III is mainly to show that the
high accuracy in recognition of PCA is due to the neutral expression images in query
sets. Further, in Test IV, we would like to know whether the two methods can withstand
facial variations without a priori knowledge by using S1f and S2f to query against S1n
and S2n. The average recognition rates for all tests and cases of the two methods are
plotted in Figure 2. The k nearest neighbours chosen are k = {5, 10, 20} but only k = 5
is shown as it always performs the best.
Test I
50
60
70
80
90
100
S1n vs. S1n S1n vs. S2n S2n vs. S1n S2n vs. S2n
Recognition Rate (%)
Ours L1-norm PCA L1-norm Ours L2-norm PCA L2-norm
Test II
50
60
70
80
90
100
S1 vs. S1 S1 vs. S2 S2 vs. S1 S2 vs. S2
Recognition Rate (%)
Ours L1-norm PCA L1-norm Ours L2-norm PCA L2-norm
Test III
0
20
40
60
80
100
S1f vs. S1 S1f vs. S2 S2f vs. S1 S2f vs. S2
Rcognition Rate (%)
Ours L1-norm
PCA L1-norm
Ours L2-norm
PCA L2-norm
Test IV
0
20
40
60
80
100
S1f vs. S1n S1f vs. S2n S2f vs. S1n S2f vs. S2n
Recognition Rate (%)
Ours L1-norm PCA L1-norm Ours L2-norm PCA L2-norm
Fig. 2. Results (the average recognition rates) of Tests I to VI in (a)-(f) respectively.
It is expected that PCA will outperform our proposed method in Test I. Since PCA is
sensitive to variations in pixels, the warping (that aligns the features), the oval mask
(that removes the noisy background) and the testing images, S1n and S2n (only the
neutral expression is used, i.e. no variation introduced by facial expression), are all in
greater favor to PCA. Both the methods, nevertheless, are expected to attain high
recognition rate, normally over 90 percent with a testing image set at this scale [11].
From Tests I and II, it is confirmed that our presumption about the performance of
our proposed method and PCA in Test I is correct; PCA outperforms our proposed
method in stage one of this experiment. Nonetheless, with the introduction of variations
in facial expression, Test II, a larger drop in performance of matching “duplicates”
using PCA is observed by comparing Test I with Test II while a relatively mild
degradation in performance is recorded for our proposed method. The overall
performance of PCA is better, which is mainly due to the composition of the query
image set. In the query image set, there are more than half (four out of seven) of the
images are of neutral facial expression. The high recognition rate of PCA for neutral
faces (see Tests I and II) dominates the performance evaluation. This can be confirmed
by Test III.
9
From Test III, It is seen that our proposed method is more robust than PCA against
variations in facial expression. We can further show that our proposed method is more
robust to variations in facial expression by Test IV using faces with facial expressions
other than neutral as query images to match against a database that contains only faces
with neutral facial expression. Since the database does not contain any faces with facial
expression other than neutral, they are unseen to PCA, i.e. not trained. Test IV shows
that PCA is ineffective to adapt variations in facial expression if no faces with varied
facial expression are presented in training whereas our proposed method can still
achieve a moderate accuracy, even matching the “duplicates”.
5 Conclusion
We have proposed a relatively low feature dimension scheme for face recognition for
frontal face images captured indoor. We derived an aggregated Gabor filter responses
representation for face images that is of lower feature dimension. A comparative study
on the effect of using different (dis)similarity measures, L
1
- and L
2
-norm, and the effect
of matching against “duplicates” is reported for our proposed method; a similar study is
done using PCA for performance comparison. A study of the influence of the facial
expressions has shown that PCA is not as effective as our proposed method in
recognizing face with varied facial expressions. The better performance of PCA is a
result of the uneven composition of images (of various facial expressions) in testing set
and its ability in matching neutral expression images. The performance for PCA is even
worse that if none of the images with variations in facial expression is included during
the training phase, PCA can hardly recognize a person correctly.
Acknowledgement
The authors would like to thank for the partial support of the research grants from Hong
Kong Government (UGC) and The Hong Kong Polytechnic University.
References
1. Beymer, D.: Vectorizing Face Images by Interleaving Shape and Texture Computations. AI
Memo No. 1537, AI Lab., Massachusetts Inst. of Technology (1995)
2. Bovik, A.C. Clark, M., Geisler, W.S.: Multi-channel texture analysis using localized spatial
filters. IEEE Trans. Pattern Anal. Machine Intell., Vol. 12 No. 1 (1990) 55-73
3. Daugman, J.G.: Uncertainty relation for resolution in space, spatial frequency, and
orientation optimized by two-dimensional visual cortical filters. Journal of the Optical
Society of America A., Vol. 2 No. 7 (1985) 1160-1169
4. Daugman, J.G.: Complete discrete 2-d Gabor transforms by neural networks for image
analysis and compression IEEE Trans. Acoust., Speech, Signal Processing, Vol. 36 No. 7
(1988) 1169-1179
5. Draper, B.A., Baek, K., Bartlett, M.S., Beveridge, J.R.: Recognizing faces with PCA and
ICA. Computer Vision and Image Understanding, Vol. 91 No.1-2 (2003) 115-137
6. Heisele, B., Ho, P., Wu, J., Poggio, T.: Face Recognition: component-based versus global
approaches. Computer Vision and Image Understanding, Vol. 91 No. 1-2 (2003) 6-21
10
7. Jain, A.K., Duin, R.P.W., Mao, J.: Statistical Pattern Recognition: A Review. IEEE Trans.
Pattern Anal. Machine Intell., Vol. 22 No. 1 (2000) 4-37
8. Jain, A.K., Ross, A., Prabhakar, S.: An Introduction to Biometric Recognition. IEEE Trans.
Circuits Syst. Video Technol., Vol. 14 No. 1 (2004) 4-20
9. Lee, T.S.: Image representation using 2D Gabor wavelet. IEEE Trans. Pattern Anal. Machine
Intell., Vol. 18 No. 10 (1996) 959-971
10. Liu, C., Wechsler, H.: Independent Component Analysis of Gabor Features for Face
Recognition. IEEE Trans. Neural Networks, Vol. 14 No. 4 (2003) 919-928
11. Martinez, A.M.: Recognizing Imprecisely Localized, Partially Occluded, and Expression
Variant Faces from a Single Sample per Class. IEEE Trans. Pattern Anal. Machine Intell.,
Vol. 24 No. 6 (2001) 748-763
12. Martinez, A.M., Benavente, R.: The AR face database. CVC Tech. Report #24,
Purdue Univ., Dept. of Electrical Eng. (1998); please see also:
http://rvl1.ecn.purdue.edu/~aleix/aleix_face_DB.html
13. Martinez, A.M. Kak, A.C.: PCA versus LDA. IEEE Trans. Pattern Anal. Machine Intell.,
Vol. 23 No. 2 (2001) 228-233
14. Phillips, P.J., Moon, H., Rauss, P.J., Rizvi, S.: The FERET Evaluation Methodology for Face
Recognition Algorithms. IEEE Trans. Pattern Anal. Machine Intell., Vol. 22 No. 10 (2000)
1090-1104
15. Turk, M., Pentland, A.: Eigenfaces for recognition. J. Cognitive Neuroscience, Vol. 3 No. 1
(1991) 71-86
16. Wiskott, L., Fellous, J.M., Kruger, N., von der Malsburg, C.: Face Recognition by Elastic
Bunch Graph Matching. IEEE Trans. Pattern Anal. Machine Intell., Vol. 19 No. 7 (1997)
775-779
17. Wu, H., Yoshida, Y., Shioyama, T.: Optimal Gabor Filters for High Speed Face
Identification. Proc. of 16th International Conference on Pattern Recognition, Quebec City,
Vol. 1 (2002) 107-110
18. Zhang, D., Peng, H., Zhou, J., Sankar, K.P.: A Novel Face Recognition System Using Hybrid
Neural and Dual Eigenspaces Methods. IEEE Trans. Syst. Man, Cybern. A, Vol. 32 No. 6
(2002) 787-793
19. Zhao, W., Chellappa, R., Phillips, P.J., Rosenfeld, A.: Face Recognition: A Literature Survey.
ACM Computing Surveys, Vol. 35 No. 4 (2003) 339-458
11
