ASPECTBOXES – CONTROLLING THE VISIBILITY OF ASPECTS

Alexandre Bergel

, Robert Hirschfeld

, Siobh

an Clarke

and Pascal Costanza

Distributed Systems Group

Trinity College Dublin, Ireland

Hasso-Plattner-Institut

Universit

at Potsdam, Germany

Programming Technology Lab

Vrije Universiteit Brussel, Belgium

Keywords:

Aspect-oriented programming, aspect composition, scoping change, aspects, classboxes, squeak.

Abstract:

Aspect composition is still a hot research topic where there is no consensus on how to express where and when

aspects have to be composed into a base system. In this paper we present a modular construct for aspects, called

aspectboxes, that enables aspects application to be limited to a well deﬁned scope. An aspectbox encapsulates

class and aspect deﬁnitions. Classes can be imported into an aspectbox deﬁning a base system to which

aspects may then be applied. Reﬁnements and instrumentation deﬁned by an aspect are visible only within

this particular aspectbox leaving other parts of the system unaffected.

1 INTRODUCTION

Aspect-oriented programming (AOP) promises to im-

prove the modularity of programs by providing a

modularity construct called aspect to clearly and con-

cisely capture the implementation of crosscutting be-

havior. An aspect instruments a base software system

by inserting pieces of code called advices at locations

An important focus of current research in AOP is

on aspect composition (Douence et al., 2004; Klaeren

et al., 2000; Nagy et al., 2005; Brichau et al., 2002).

Ordering and nesting are commonly used when com-

posing aspects and advices (Kiczales et al., 2001;

Tanter, 2006). Whereas most aspect languages pro-

vide means to compose aspects at a very ﬁne grained

level, experience has shown that ensuring a sound

combination of aspects is a challenging and difﬁ-

cult task (Lopez-Herrejon et al., 2006). First steps

are already taken by AspectJ (Kiczales et al., 2001)

by restricting pointcuts to a Java package or a class

through the use of dedicated pointcuts primitives such

as within and withincode primitive pointcuts.

If we regard an aspect as an extension to a base

system, multiple extensions are difﬁcult to manage

and control, even if they are not interacting with each

other. We believe that the reason for this is the lack of

a proper scoping mechanism.

In this paper we deﬁne a new modular construct

for an aspect language called an aspectbox. An as-

pectbox is a modular unit that may contain class and

aspect deﬁnitions. Classes can be imported into an as-

pectbox and the aspect is then applied to the imported

classes. Reﬁnements originated from such aspects are

visible only within the aspectbox that deﬁnes this as-

pect. Outside this aspectbox the base system behaves

as if there were no aspect. Other parts outside a par-

ticular aspectbox remain unaffected.

In Section 2 we provide an example illustrating the

issues when composing aspects. In Section 4 we de-

scribe the aspectboxes module system and its proper-

ties. In Section 5 we present our Squeak-based imple-

mentation of aspectboxes. Related work is discussed

in Section 6. We conclude by summarizing the pre-

sented work in Section 7.

2 MOTIVATION

To motivate the need for limiting the scope of aspects,

we use an example based on the design of a small

four-wheel electric car, and its implementation based

on a mainstream aspect language, AspectJ (Kiczales

et al., 2001).

The CyCab (Baille et al., 1999) is an electric four

wheel car designed to transport up to two people. The

Bergel A., Hirschfeld R., Clarke S. and Costanza P. (2006).

ASPECTBOXES – CONTROLLING THE VISIBILITY OF ASPECTS.

In Proceedings of the First International Conference on Software and Data Technologies, pages 29-35

DOI: 10.5220/0001316800290035

 SciTePress

Unit

Module

Dependancy

Driving Control

Position Control

Joystick

Position and

Velocity

Motion

Engine

Wheels

Safety Control

PowerOff,

Break

Figure 1: The three units and their modules that compose

the CyCab electrical car.

mechanics is taken from a small electrical golf car

frame. Functionalities implemented in a CyCab range

from an autonomous driving facility (like a coach in a

train) to ultrasonic sensors for collision avoidance. A

CyCab is composed of three different units (driving

control, position control and safety control). Each

unit is composed of one or more modules. Figure 1

illustrates the architecture of a CyCab.

Driving Control. A CyCab is steered with a joystick

emitting electrical pulses used by the motion engine

to activate the four motored wheels. This feature is

provided by three modules within the driving control

unit. The joystick module emits signals that are

captured by the motion engine module. This module

controls the wheels.

Position Control. The position control unit computes

the velocity and the location of the CyCab based on

the acceleration given by the motion engine to the

wheels and their angle between the car head.

Safety Control. The safety control unit veriﬁes the

interactions between the three modules of the driving

control unit. For example, it asserts that pulses emit-

ted by the joystick trigger the correct reaction in the

engine and the wheels reﬂect the heading dictated by

the joystick. In addition, in the event of failure the

power is shut down and communication between the

three modules is cut off.

3 EXAMPLE ANALYSIS

Behavior deﬁned by the safety control unit crosscuts

the whole driving control unit. For example, the im-

pact of a power shut-down is that the joystick, the mo-

tion engine and wheels are disconnected. This can

be easily captured in an aspect that adds behaviour to

check the power status into each affected module, as

implemented by the following AspectJ aspect:

aspect PowerOff {

private boolean hasPower = ...;

pointcut drivingControl():

target(Joystick) && call(public * *(..)) k

target(Engine) && call(public * *(..)) k

target(Wheels) && call(public * *(..));

void around(): drivingControl() {

if (hasPower == true)

proceed();

}

...

}

The PowerOffAndBreak aspect inserts a check be-

fore all public methods of the classes Joystick, Engine

and Wheels to proceed only if power is equal to true.

This aspect is applied to the driving control unit and

has to be composed with the PositionAndVelocity as-

pect deﬁned by the position control unit:

aspect PositionAndVelocity {

double speed;

pointcut speedUp() : call (* Engine.accelerate());

after(): speedUp() {

//... Speed calculation

}

...

}

PositionAndVelocity inserts a speed calculation

functionality after the execution of the accelerate

method. Deﬁning the position and velocity module

as an aspect has the beneﬁt to leave the driving con-

trol unit free from referring to the speed and position

computation. The two aspects PowerOffAndBreak and

PositionAndVelocity are woven into the base system,

the driving control unit, to form a deployable system.

With current aspect languages such as AspectJ, exten-

sions deﬁned by all aspects are automatically applied

to all the modules in the system (i.e., the physical dis-

play screen, the electronic control unit in charge of

the safety).

This facility is particularly dangerous regarding the

implicit sharing of the control ﬂow of the application.

A failure raised by the PositionAndVelocity aspect may

easily impact the PowerOffAndBreak aspect affecting

the electronic control unit in charge of the safety.

Whereas most of current aspect languages offer so-

phisticated pointcut primitives to express location of

join points, they do not provide a means to limit the

impact of an aspect into a well-deﬁned system area.

ICSOFT 2006 - INTERNATIONAL CONFERENCE ON SOFTWARE AND DATA TECHNOLOGIES

In the up coming section we deﬁne a module system

for an aspect-oriented programming environment in

which one or more aspect compositions are effective

only in the context of a well-deﬁned subset of the base

system.

4 SCOPING ASPECTS WITH

ASPECTBOXES

Most of today’s aspect languages do not provide a

way to limit the impact of an aspect within a delimited

scope. In this section, we describe a module system

for an aspect-oriented programming language that al-

lows for controlling the visibility of a set of aspects

relative to a well-deﬁned system area.

4.1 Aspectboxes in a Nutshell

Aspectboxes is a namespace mechanism for aspects.

An aspect lives in an aspectbox and the effects of this

aspect is limited to the aspectbox in which it is de-

ﬁned and to other aspectboxes that rely on the base

system extended by this aspect. An aspectbox can (i)

deﬁne classes, (ii) import classes from another aspect-

box and (iii) deﬁne aspects.

The import relationship is transitive: If an aspect-

box AB2 imports a class C from another aspectbox

AB1, then a third aspectbox AB3 can import C from

AB2. From the point of view of the importing as-

pectbox AB3, there is no difference if the class is de-

ﬁned or imported in the provider aspectbox AB2. Be-

cause aspects cannot be reused across multiple base

systems, aspects cannot be imported.

A pointcut deﬁnition contained in an aspect refers

only to classes that are imported (i.e., visible within

the aspectbox that deﬁnes this aspect). An aspect in

an aspectbox reﬁnes the behavior of the classes that

are imported or deﬁned, for instance by adding some

code before and after some methods. The classes aug-

mented with the aspect can also be imported from an-

other aspectbox. From the point of view of an import-

ing aspectbox, there is no distinction between classes

deﬁned within the aspectbox and those imported.

4.2 Namespace for Classes and

Aspects

An aspectbox deﬁnes a namespace for class deﬁni-

tions, aspect deﬁnitions and aspect compositions.

Aspectbox as namespace for classes. The class En-

gine contained in the aspectbox Dr ivingControlAB

We end the name of aspectboxes by AB to clearly make

a distinction between them and regular class names

illustrated in Figure 1 is deﬁned as the following

(Aspectbox named: #DrivingControlAB)

createClassNamed: #Engine

instanceVariableNames: ”

The class Engine does not have any instance vari-

ables and two methods accelerateWheels: anAcceler-

ation and setAnglewithHeading: anAngle are deﬁned

on it.

DrivingControlAB.Engine>>

accelerateWheels: anAcceleration

”accelerate the wheels with a given acceleration”

...

DrivingControlAB.Engine>>

setAnglewithHeading: anAngle

”set the heading of the car by setting

appropriately the wheel angle”

...

An aspectbox acts as a code packaging mechanism

and constrains aspect visibility. A class is visible

within an aspectbox if this class is deﬁned in or im-

ported to this aspectbox. Any class visible within an

aspectbox AB1 can be imported from AB1 by other as-

pectboxes. The aspectbox PositionControlAB imports

the class Engine from DrivingControlAB

(Aspectbox named: #PositionControlAB)

import: #Engine from: #DrivingControlAB

An instantiation of a class can occurs in any aspect-

box as long as this class is visible in the aspectbox that

contains the code performing the instantiation. Class

instances (i.e., objects) do not belong to an aspectbox.

Aspectbox as namespace for aspect deﬁnitions.

The module position and velocity is implemented by

the PositionAndVelocity aspect:

(Aspectbox named: #PositionControlAB)

createAspectNamed: #PositionAndVeloci ty

instanceVariableNames: ’heading velocity’

Because the aspect PositionAndVelocity has to

be applied to the class Engine, this class has to

be imported from the DrivingControlAB aspectbox.

This aspect also deﬁnes advices to be applied to

the methods accelerateWheels: anAcceleration and

setAnglewithHeading: anAngle that compute the

velocity and the heading, respectively, as illustrated

in Figure 2.

Aspectbox as namespace for aspect compositions.

An aspect, which is deﬁned in an aspectbox, is ap-

plied to classes that are visible in this aspectbox (i.e.,

classes that are imported or deﬁned). The effect of

this aspect is limited to the aspectbox in which this

Since our aspectboxes prototype is implemented in

Squeak, we therefore use the Squeak syntax to describe

them.

ASPECTBOXES – CONTROLLING THE VISIBILITY OF ASPECTS

PositionControlAB. PositionAndVelocity>> adviceComputeVelocity

ˆAfterAdvice

pointcut: (JoinPointDescriptor

targetClass: Engine targetSelector: #accelerateWheels:)

afterBlock: [:receiver :arguments :aspect |

”computation of the velocity according to the speed of the wheels”

velocity := ...]

PositionControlAB. PositionAndVelocity>> adviceComputeHeading

ˆAfterAdvice

pointcut: (JoinPointDescriptor

targetClass: Engine targetSelector: #setAnglewithHeading:)

afterBlock: [:receiver :arguments :aspect |

”computation of the heading according to the speed of the wheels”

heading := ...]

Figure 2: The velocity and the heading are computed by two advices adviceComputeVelocity and adviceComputeHead-

ing, respectively.

aspect is deﬁned. Outside this aspectbox, it is as if no

aspect would have been applied to the base system.

The aspectbox SafetyControlAB deﬁnes the aspect

PowerOff. This aspect has one advice, adviceDriving-

Control that proceed a method call if the hasPower is

true.

(Aspectbox named: #SafetyControlAB)

createAspectNamed: #PowerOff

instanceVariableNames: ’hasPower’.

SafetyControlAB.PowerOff>>

adviceDrivingControl

| joinpoints |

joinpoints := JointPointDescriptor

targetClasses: {Joystick . Engine . Wheels}.

ˆAroundAdvice

pointcut: joinpoints

aroundBlock: [:receiver :arguments :aspect |

hasPower ifTrue: [ aspect proceed ]

Aspects PowerOff and PositionAndVelocity de-

scribed above have a common pointcut: public

method of the class Engine. Because these

two aspects belongs to different aspectboxes

(SafetyControlAB and PositionControlAB, respec-

tively), they do not conﬂict with each other.

4.3 Executing Code in an Aspectbox

Triggering a program execution in an aspectbox is

achieved by the method eval:.

(Aspectbox named: #SafetyControlAB) eval: [

| app |

app := SafetyApplication new.

app run].

The code above instantiates the class SafetyAppli-

cation and invokes the method run. The code invoked

by this method run will beneﬁt from aspects deﬁned

in SafetyControlAB (i.e.,PowerOff). Similarly, an ap-

plication invoked in the aspectbox PositionControlAB

will beneﬁt from PositionAndVelocity without being

affected by SafetyControlAB.

4.4 Absolute Isolation of Aspects

It is widely accepted that encapsulating different

functionalities of a system in distinct modular units

aids their comprehensibility and maintainability (Par-

nas, 1972).

Figure 1 illustrates a modular architecture. Because

it is closely linked to the physical and external phys-

ical mechanic events, the driving control unit needs

special care and should not be altered by other units

that are not necessary for its execution. Also, for

safety reasons, the position control unit has to be built

on top of the motion engine without affecting its ex-

ecution. Different concerns composed into a system

have to be well modularized and isolated from the

base system.

The aspectboxes module system has the following

properties:

• Conﬂicts between aspects are avoided. By living in

different scopes, aspects are kept separated. Even

if aspects deﬁned in different aspectboxes have the

same join points, there is no need to deﬁne prece-

dence rules for composition ordering.

• Minimal extension of the aspect language. Com-

bining the aspectboxes module system with As-

pectS (Hirschfeld, 2003) did not require any mod-

iﬁcation of the aspect language syntax. Static ref-

erences contained in the deﬁnition of pointcuts are

resolved using the classes visible in the aspectbox

in which these pointcuts are deﬁned in.

ICSOFT 2006 - INTERNATIONAL CONFERENCE ON SOFTWARE AND DATA TECHNOLOGIES

Joystick Engine Wheels

Driving Control

PowerOff

Position

Velocity

Safety Control Position Control

Base system

Activation block

Aspect

Aspectbox

Pointcut

Figure 3: The PowerOff. and PositionAndVelocity aspects hooked into the driving control module.

5 IMPLEMENTATION

A prototype of aspectboxes is implemented in

Squeak. Figure 3 describes how the safety control

and the position control are hooked into the driving

control module.

AspectS. AspectS (Hirschfeld, 2003) is an approach

to general-purpose aspect-oriented programming in

the Squeak

Smalltalk environment (Ingalls et al.,

1997). It extends the Squeak metaobject protocol to

accommodate the aspect modularity mechanism. In

contrast to systems like AspectJ, weaving and un-

weaving in AspectS happens dynamically at runtime,

on-demand, employing metaobject composition.

Instead of introducing new language constructs,

AspectS utilizes Squeak itself as its pointcut lan-

guage. AspectS beneﬁts from the expressiveness and

uniformity of Squeak.

Activation blocks. AspectS uses Method Wrap-

pers (Brant et al., 1998) to instrument both message

sends and receptions. Such wrappers support exe-

cution of additional code before, after, around, or

instead of an existing method. The core of the aspect

activation mechanism is implemented in the isActive

method of the class MethodWrapper. All additional

code provided by a wrapper is to be activated only

if all activation blocks associated with it evaluate

to true. Activation blocks are treated as predicate

methods, returning either true or false as the outcome

of their execution.

Aspectboxes. The aspectboxes module system is

fully integrated in the Squeak environment. When

an aspect is woven, activation blocks are created and

placed at join points shadows. When the control ﬂow

of the application reaches a join point, the isActive

methods is executed in order to determine if this po-

tential join point is within the scope of an aspectbox

Squeak is an open-source Smalltalk available from

http://www.squeak.org

deﬁning this aspect to yield activation or not (i.e., if it

is associated with the current control ﬂow).

6 RELATED WORK

AspectJ. The pointcut language offered by AspectJ

provides a mechanism to restrict a pointcut deﬁnition

to a package or a class (i.e.,within and withincode

pointcut primitives). The purpose of these constructs

is to restrict the location of join points between a base

system and an aspect, however advices hooked at

those join points remain globally visible. Therefore,

the restricting pointcut primitives of AspectJ do not

help in scoping an aspect application.

CaesarJ. Aspects, packages and classes are uniﬁed

in CaesarJ (Aracic et al., 2006) under a single notion,

a cclass. Aspect deployment can either be global or

thread local.

Aspectboxes promotes a syntactic scoping of

aspects: an aspect is scoped to the aspectbox that

deﬁnes it. In CaesarJ, an aspect is scoped to the

thread it was installed in.

Classboxes. The Classbox module system allows a

class to be extended by means of class member addi-

tions and redeﬁnitions. These extensions are visible

in a locally and well-delimited scope. Several ver-

sions of a same class can coexist at the same time in

the same system. Each class version corresponds to a

particular view of this class (Bergel et al., 2005).

Classboxes and aspectboxes have a common root

which is the scoping mechanism for reﬁnement.

Whereas classboxes support structural reﬁnement

(i.e., class members addition and redeﬁnition), as-

pectboxes offer a scoping mechanism for behavioral

reﬁnement.

Context-aware aspects. Context awareness pro-

motes software program behaviour to depend on

“context”. Context-aware aspects (Tanter et al., 2006)

ASPECTBOXES – CONTROLLING THE VISIBILITY OF ASPECTS

offers language constructs to handle contexts. A con-

text is deﬁned by the programmer as a plain standard

object. The pointcut language is extended with primi-

tives such as inContext(c) and createdInContext(c) that

restrict a pointcut expression to a particular context c

and to objects that were created in a context c, respec-

tively.

Whereas context-aware aspects trigger the acti-

vation of aspects based on some arbitrary context

activation function, aspectboxes promote the con-

current applications of aspects by restricting them to

different scope.

Context-oriented programming. Con-

textL (Costanza and Hirschfeld, 2005), a CLOS-

based implementation for Context-Oriented Program-

ming, provides dedicated programming language

constructs to associate partial class and method

deﬁnitions with layers. Layers activation and deac-

tivation is driven by the control ﬂow of a running

program. When a layer is activated, the partial

deﬁnitions become part of the program until this

layer is deactivated.

Whereas scoping software system reﬁnement is the

common problem for context-oriented programming

and aspectboxes, the approaches are different. A

layer in ContextL encapsulate structural deﬁnitions,

whereas aspectboxes encapsulate behavioral deﬁni-

tions.

AWED. Aspects with Explicit Distribution

(AWED) (Navarro et al., 2006) is an approach

for deﬁning crosscutting behaviour on remote loca-

tions (i.e., distributed applications). AWED is an

aspect language supporting remote pointcuts, dis-

tributed advices and distributed aspects. A distributed

aspect allows for state sharing and aspect instance to

be distributed across multiple hosts.

7 CONCLUSION

Aspectboxes provide a new aspect modularity con-

struct limiting the scope of aspect composition with a

base software system. Modiﬁcations to the base sys-

tem are visible only in the aspectbox the aspect is de-

ﬁned in. This allows one to deploy multiple concur-

rent modiﬁcations in the same base system, avoiding

conﬂicting situations across aspectboxes.

In the work presented in this paper, an aspect can-

not be imported from an aspectbox. The reason for

this is that aspects are not generic (i.e., cannot be ap-

plied to other base systems). As future work, we plan

to reﬁne the notion of import to enable reuse of as-

pects within multiple aspectboxes.

Our prototypical implementation is based on As-

pectS. It integrates the composition mechanisms of

AspectS and Classboxes to achieve the desired com-

position and scoping behavior.

ACKNOWLEDGEMENTS

We gratefully acknowledge the ﬁnancial support of

the Science Foundation Ireland and Lero — the Irish

Software Engineering Research Centre. We also like

to thank Parinaz Davari and Daniel Rostrup for their

valuable comments.

REFERENCES

Aracic, I., Gasiunas, V., Mezini, M., and Ostermann, K.

(2006). An overview of caesarj. Transactions on

Aspect-Oriented Software Development, 3880:135 –

173.

Baille, G., Garnier, P., Mathieu, H., and Pissard-Gibollet,

R. (1999). Le cycab de l’inria rh

one-alpes. Technical

Report RT-0229, INRIA.

Bergel, A., Ducasse, S., and Nierstrasz, O. (2005). Class-

box/J: Controlling the scope of change in Java. In Pro-

ceedings of Object-Oriented Programming, Systems,

Languages, and Applications (OOPSLA’05), pages

177–189, New York, NY, USA. ACM Press.

Brant, J., Foote, B., Johnson, R., and Roberts, D. (1998).

Wrappers to the Rescue. In Proceedings ECOOP

’98, volume 1445 of LNCS, pages 396–417. Springer-

Verlag. method wrappers.

Brichau, J., Mens, K., and Volder, K. D. (2002). Build-

ing composable aspect-speciﬁc languages with logic

metaprogramming. In Proceedings of the 1st

ACM SIGPLAN/SIGSOFT Conference on Generative

Programming and Component Engineering (GPCE

2002), volume 2487 of LNCS. Springer-Verlag.

Costanza, P. and Hirschfeld, R. (2005). Language con-

structs for context-oriented programming. In Proceed-

ings of the Dynamic Languages Symposium 2005.

Douence, R., Fradet, P., and S

udholt, M. (2004). Composi-

tion, reuse and interaction analysis of stateful aspects.

In AOSD ’04: Proceedings of the 3rd international

conference on Aspect-oriented software development,

pages 141–150, New York, NY, USA. ACM Press.

Hirschfeld, R. (2003). AspectS – Aspect-Oriented Pro-

gramming with Squeak. In Aksit, M., Mezini, M.,

and Unland, R., editors, Objects, Components, Ar-

chitectures, Services, and Applications for a Net-

worked World, number 2591 in LNCS, pages 216–

232. Springer.

Ingalls, D., Kaehler, T., Maloney, J., Wallace, S., and Kay,

A. (1997). Back to the future: The story of Squeak, A

practical Smalltalk written in itself. In Proceedings

OOPSLA ’97, ACM SIGPLAN Notices, pages 318–

326. ACM Press.

ICSOFT 2006 - INTERNATIONAL CONFERENCE ON SOFTWARE AND DATA TECHNOLOGIES

Kiczales, G., Hilsdale, E., Hugunin, J., Kersten, M., Palm,

J., and Griswold, W. G. (2001). An overview of As-

pectJ. In Proceeding ECOOP 2001, number 2072 in

LNCS, pages 327–353. Springer Verlag.

Klaeren, H., Pulverm

uller, E., Raschid, A., and Speck, A.

(2000). Aspect composition applying the design by

contract principle. In Proceedings of the 2nd Inter-

national Symposium on Generative and Component-

Based Software Engineering (GCSE 2000), volume

2177 of LNCS, pages 57–69. Springer-Verlag.

Lopez-Herrejon, R., Batory, D., and Lengauer, C. (2006).

A disciplined approach to aspect composition. In

PEPM ’06: Proceedings of the 2006 ACM SIGPLAN

symposium on Partial evaluation and semantics-based

program manipulation, pages 68–77, New York, NY,

USA. ACM Press.

Nagy, I., Bergmans, L., and Aksit, M. (2005). Composing

aspects at shared join points. In Robert Hirschfeld,

Ryszard Kowalczyk, A. P. and Weske, M., editors,

Proceedings of International Conference NetObject-

Days, NODe2005, volume P-69 of Lecture Notes in

Informatics, Erfurt, Germany. Gesellschaft f

ur Infor-

matik (GI).

Navarro, L. D. B., S

udholt, M., Vanderperren, W., Fraine,

B. D., and Suv

ee, D. (2006). Explicitly distributed

AOP using AWED. In Proceedings of the 5th Int.

ACM Conf. on Aspect-Oriented Software Develop-

ment (AOSD’06). ACM Press.

Parnas, D. L. (1972). On the criteria to be used in decom-

posing systems into modules. CACM, 15(12):1053–

1058.

Tanter,

E. (2006). Aspects of composition in the reﬂex aop

kernel. In Proceedings of the 5th International Sym-

posium on Software Composition (SC 2006), LNCS,

pages 99–114, Vienna, Austria.

Tanter,

E., Gybels, K., Denker, M., and Bergel, A. (2006).

Context-aware aspects. In Proceedings of the 5th In-

ternational Symposium on Software Composition (SC

2006), LNCS, pages 229–244, Vienna, Austria.

ASPECTBOXES – CONTROLLING THE VISIBILITY OF ASPECTS
