A TELEPHONY APPLICATION FOR MANETS

Voice Over a MANET-extended JXTA Virtual Overlay Network

Luis Bernardo, Rodolfo Oliveira, Sérgio Gaspar, David Paulino and Paulo Pinto

Faculdade de Ciências e Tecnologia, Universidade Nova de Lisboa, P-2829-516 Caparica, Portugal

Keywords: Internet Telephony service, Mobile Ad-hoc Networks, Peer-to-Peer computing.

Abstract: This paper presents MANET-VoVON, a new Internet application for mobile ad-hoc networks (MANETs)

providing voice over virtual overlay networks. A MANET-enabled version of JXTA peer-to-peer modular

open platform (MANET-JXTA) is used to support user location and optionally, audio streaming over the

JXTA virtual overlay network. Using MANET-JXTA, a client can search asynchronously for a user, and

delay the call setup until a path is available to reach the user. The application uses a private signalling

protocol based on the exchange of XML messages over MANET-JXTA communication channels.

Nevertheless, it is fully interoperable with normal SIP clients through an embedded gateway function. This

paper describes a prototype implementation of the proposed application and of the MANET-JXTA, and

presents some performance measurements.

1 INTRODUCTION

Internet telephony services based on SIP (Session

Initiation Protocol) (Rosenberg, 02) were designed

for stable networks. The original IETF's approach

relied on a registration service to handle client's

mobility and availability. The call setup is forwarded

by a proxy server, which queries the registration

service for the current user location. Peer-to-peer

(p2p) services were proposed for replacing the

centralized registration service: Skype (Skype, 06)

(Baset, 04) uses Kazaa's p2p infrastructure for

storing the user's location, and P2P-SIP (Sing, 05)

uses a Chord p2p infrastructure for the same

purpose. However, both p2p approaches were

designed for the Internet and assume complete and

stable connectivity.

Unstable mobile ad-hoc networks (MANETs)

present a challenge for the existing applications

because they are composed by scattered islands of

nodes, with limited connectivity. Under these

conditions it is costly to create and maintain a Chord

distributed hash table (DHT) with a ring topology

that does not match the MANET topology. A Chord

link may connect two nodes that geographically are

several hops distant. It is also costly to create and

maintain a virtual overlay network (VON)

connecting Kazaa supernodes. (Oliveira, 05) shows

that for these conditions the p2p infrastructures

above collapse for high node's speeds. For a

MANET it is also not acceptable to base the

telephony call’s success upon the connectivity to a

centralized node. Instead, a new asynchronous

tolerant approach is needed. The "location service"

must be capable of storing the user's "call desires",

and opportunistically establish the call when the

network topology allows it. Therefore, the call

establishment is not immediate but can take some

time after the user gives the command.

We have implemented MANET-VoVON

(MANET Voice over VON), a partition tolerant

telephony service. The prototype is based on a new

p2p architecture (Oliveira, 05b) that was

implemented as an extension of the JXTA platform

version 2.3.2 (JXTA, 06) optimized for unstable

MANETs (we call it MANET-JXTA in this paper).

This service interoperates with external SIP clients

through a gateway, and within the MANET using

MANET-JXTA services. It can stream audio directly

end-to-end, or through the p2p VON. An evaluation

of the MANET-JXTA overhead is presented in this

paper.

The remainder of this paper is organized as

follows: Section two introduces MANET-JXTA

main characteristics. Section three presents the

proposed internet telephony architecture, and its

interoperation with SIP based services. Section four

gives an overview of the prototype software

implemented, and some performance measurements.

Finally, some conclusions are drawn in section five.

227

Bernardo L., Oliveira R., Gaspar S., Paulino D. and Pinto P. (2006).

A TELEPHONY APPLICATION FOR MANETS - Voice Over a MANET-extended JXTA Virtual Overlay Network.

In Proceedings of the International Conference on Wireless Information Networks and Systems, pages 227-233

 SciTePress

2 MANET-JXTA

MANET-JXTA defines an extended set of the JXTA

core p2p protocols and services (JXTA, 04), on top

of which applications can be implemented. These

protocols provide the basic functionality for peer and

resource discovery, communication and

organization.

2.1 JXTA

Applications run on a JXTA VON, which is a set of

peers grouped on peer groups created by exchanging

advertisements. All entities and resources (peers,

groups, pipes, endpoints, queries, services, etc.) in

JXTA are represented by advertisements.

Advertisements are XML documents having unique

IDs. JXTA core p2p services manipulate

advertisements caching them and using searching

procedures when caching fails.

JXTA defines a set of protocols adapted for

searching advertisements on the Internet (JXTA,

04). Basic query–reply message exchanges are

supported by the Resolver Service (RS), which

implements the Peer Resolver Protocol (PRP). RS is

then used to implement other application specific

resolution services. When no cache information is

available, PRP uses a search service to look for

advertisements. The most basic search service is the

Rendezvous service and besides PRP other higher

level search services also use it (e.g. Peer Discovery

service, Pipe Binding Protocol). Additionally, JXTA

supports a loosely-consistent DHT of advertisements

(Rendezvous peer view service) implemented by a

subset of Rendezvous peers. A Rendezvous (RV)

peer is the equivalent to the Kazza's supernode: it

acts as an advertisement concentrator supporting

searches for a subset of non-RV peers.

Inter-peer communication in JXTA is usually

implemented by exchanging XML messages over a

communication channel created by the pipe service.

The pipe service defines a one-to-one or one-to-

many non-reliable peer-to-peer channel that

transport messages through the VON connecting the

peer-nodes, crossing NAT routers and firewalls.

JXTA 2.0 defines two additional communication

layers that are not adapted to telephony applications:

endpoint service implements static connections;

JXTA sockets implement reliable communication.

Pipes use logical identifiers at system level that

are associated and resolved to physical addresses by

the Endpoint Routing Protocol (ERP) at run-time,

and when the connection is lost. Therefore, they

identify univocally an application and a peer,

independently of how many network interfaces the

peer's machine has, or if their IP addresses change.

However, pipes introduce an important message

overhead that results from all the JXTA headers

included by the JXTA core protocols and the

application protocols. The minimum set includes the

Endpoint Router header, which has the source and

destination endpoint addresses, and a tentative route

to the destination. (Antoniu, 05) evaluates the

JXTA's communication performance on a Fast

Ethernet, and shows that JXTA overhead can be

very high for small packet sizes. On the other side, a

minimum of five percent throughput degradation is

achievable on a Fast Ethernet for large packet sizes.

2.2 MANET-JXTA

MANET-JXTA handles queries preferentially using

searching, because cached information tends to be

outdated too fast on MANETs. It is also capable of

using the original JXTA mechanism to interoperate

with pure, non MANET-JXTA peers. MANET-

JXTA adds the MANET rendezvous protocol

(MANET-RVP) (Oliveira, 05b), a p2p protocol that

uses a cross-layering flooding approach for

propagating query messages through rendezvous

peers in real-time. Query messages are flooded

directly into the wireless LAN (WLAN) using IP

multicast. It does rely on any existing VON

topology. That might not be adapted to the physical

topology. Due to peer movement, several RV peers

may be located on the same network region. A

clustering protocol is used to reduce the flooding

overhead on these conditions. Each RV peer sends

beacons periodically. Using the beacon information,

RV peers are capable of selecting a subset of the RV

peers as broadcast group leaders, responsible for

broadcasting the query messages through all RV

peers. Beacons are also used to detect the

appearance of new neighbours. Notice that for a

MANET almost all the peers must be RV peers

because the topology may change continuously.

MANET-JXTA also modifies the Resolver

Service (RS), responsible for answering

advertisement queries. A TTL (Time-To-Live)

parameter was added to the query message, allowing

applications to specify time limited asynchronous

queries.

After the query message reaches a RV peer, it is

successively flooded using MANET-RVP protocol

until it reaches all connected RV peers, within the

specified maximum number of network hops. The

response message is sent back to the query

originator reversing the query message path. If the

path is broken (a peer in the path is out of range), the

route resolver protocol uses RS to search for another

path using the destination endpoint addresses.

Besides answering to the query with local

WINSYS 2006 - INTERNATIONAL CONFERENCE ON WIRELESS INFORMATION NETWORKS AND SYSTEMS

228

information, RV peers add the query message to a

finite length active query table. When a RV peer

previously out of range (peer 3 in figure 1) is

detected, the queries in the table are repropagated to

it, and to the RV peers in the island it belongs to,

eventually being stored by all RV peers that ever get

in touch with a covered peer island.

Figure 1: Query resolution after user 3 discovery.

For MANET-JXTA, the VON connecting the

peers is created on-demand after MANET-RVP is

used to answer a query. VON links are defined by

the path elements contained in the answer message

headers. Therefore, after a query resolution it

matches the physical MANET topology, with

minimum communication overhead. All neighbour

peers in the VON are within radio coverage. If peers

move from their original position, MANET routing

protocols can be used to maintain the VON links as

long as the application pipes are alive.

JXTA reference implementation (JXTA, 06) only

supported TCP and HTTP transport protocols.

MANET-JXTA added an UDP transport protocol

module. The use of UDP links eventually reduces

the end-to-end jitter on the application pipe's

communications over 802.11 error prone WLANs

(Zhang, 04). However, no quality of service

guarantees are provided by the existing 802.11 MAC

protocols on ad-hoc mode, and the implemented

UDP module does not support any traffic

differentiation mechanisms either.

3 MANET-VOVON APPLICATION

The MANET-Voice over VON (VoVON)

application implements a telephony application on a

MANET enabled version of JXTA service. Figure 2

shows the overall VoVON architecture.

Within MANET-JXTA enabled peers, VoVON

supports asynchronous telephony call setup to a

remote peer. VoVON application publishes a

VoVON ModuleSpecificAdvertisement, which

specifies the control receiving pipe advertisement.

Therefore, using MANET-JXTA resolver service,

other VoVON peers can search for VoVON

advertisements, and can establish a call using the

pipe advertisement.

If a MANET-JXTA RV peer exists

interconnecting the MANET to the Internet (forming

a meshed wireless network), the application supports

synchronous call setup using standard JXTA

protocols and services.

The model also includes a JXTA-SIP gateway

(figure 2), which allows standard SIP clients to make

calls to JXTA peers and to receive calls from JXTA

peers, without modifying the user agent. The

gateway associates a DNS domain name to the

VoVON's JXTA name space, and encapsulates the

RTP audio stream into XML messages, when

needed. It supports direct interaction with SIP users,

or indirect interaction, through SIP proxies.

Figure 2: MANET-VoVON architecture.

3.1 Signalling

The VoVON's signalling messages were defined as a

XML mapping of the SIP messages. In order to

handle JXTA pipe unreliability, all VoVON

messages are confirmed. A timer is used to

retransmit them if no acknowledge is received and

up to nine attempts are made. Table 1 presents a

subset of the messages supported by VoVON.

Call setup original three-way hand-shake was

mapped into a four-way VoVON message hand-

shake over a pipe channel. Call_Req message

includes the classical INVITE fields (e.g. Session

Description Protocol (SDP) field), but adds a TTL

field that defines for how long the call request is

valid. Call_Reply message acknowledges the

reception of Call_Req, and is equivalent to SIP's

"100 trying" message. Call_OK message implements

the "200 OK" SIP's message, with the corresponding

fields (including the SDP field), and the SIP codec

negotiation rules are followed. VoVON adds two

Call_Connect messages to initialize audio streaming

on each way, containing private pipe advertisements

(see figure 3).

A TELEPHONY APPLICATION FOR MANETS - Voice Over a MANET-extended JXTA Virtual Overlay Network

229

The SDP field was modified, to allow the

definition of either a RTP endpoint (RTP protocol,

IP address and the port number); or a JXTA pipe

(receptor pipe advertisement string). Through pipes

audio is transmitted over the VON links crossing

firewalls and NAT routers, reaching any peer within

JXTA VON. Pipes usage also minimizes the

network setup time on a MANET – no MANET

routing overhead exists. On the other hand, RTP

streams introduce an initial routing overhead – it is

necessary to discover the IP route between both

peers before sending the audio samples. Depending

on the MANET routing algorithm (Perkins, 01)

discovering an IP route for a remote peer several

hops away may mean: flooding the entire MANET

with a "route request" packet for on-demand

protocols (e.g. AODV, DSR, etc.); or continuously

updating a routing table for proactive protocols (e.g.

DSDV, OLSR). However, pipes may introduce a

huge bandwidth overhead (Antoniu, 05).

Table 1: MANET-VoVON signalling messages and their

mapping to SIP messages.

SIP MANET-VoVON

INVITE Call_Req / Call_Reply

200 OK (for INVITE) Call_OK

Call_Connect

ACK (for INVITE) Call_Status_Reply_OK

BYE / 200 OK Call_End / Call_End_ACK

VoVON call termination is implemented by a

two way message hand-shake. No REGISTER

message is included in VoVON signalling. Instead,

all peer associations are made using MANET-JXTA

RS (resolver service), more adapted to the unstable

nature of the MANETs.

3.2 SIP Interoperation

SIP interoperation with VoVON is supported by

JXTA-SIP gateways. A JXTA-SIP gateway

publishes a JXTA-SIP gateway advertisement

instead of a VoVON advertisement, which includes

additional gateway specific information. Therefore,

using the MANET-JXTA RS, other VoVON peers

can search for JXTA-SIP advertisements, and can

use them to establish a call to a SIP client.

A JXTA-SIP gateway is associated with a DNS

domain name and implements the SIP protocol stack

to communicate with SIP users and SIP proxies.

Each JXTA user is associated with a VOVON

uniform resource identifier (URI) within the JXTA

network. Thus URI can be associated with a SIP

URI identifying the domain when seen through a

JXTA-SIP gateway:

vovon:(name JXTA)

sip:(name JXTA) @ domain DNS

When a VoVON client requests a call setup to a

SIP URI, the VoVON application uses MANET-

JXTA RS to search for VoVON advertisements with

the URI's name component. If the search fails,

MANET-JXTA RS is then used to find JXTA-SIP

gateway advertisements. A bidirectional connection

is established to one of the JXTA-SIP gateways.

Figure 3 shows the messages exchanged through

the control pipes during a call setup from a

MANET-JXTA client to a SIP user agent connected

to a SIP proxy. JXTA-SIP gateway runs the VoVON

setup message hand-shake at the JXTA interface

with the VoVON user, and perform the translations

described above.

JXTA VOVON user

bob@jxtavoip.org

JXTA - SIP

Gateway

SIP Proxy

SIP user

Sip:Alice@fct.unl.pt

Call_Req

Call_Reply

INVITE

100 trying

INVITE

180 Ringing

RTP PayloadXML Payload

200 OK

Call_OK

Call_Status_Reply_OK

ACK

Call_End

Call_End_ACK

BYE

200 OK

Call_Connect

Figure 3: call setup from JXTA to SIP using a SIP proxy.

JXTA-SIP gateway maintains all audio encoding

specifications in the SDP audio fields it sends to the

SIP proxy or to the SIP user. Although, it swaps all

domain names with references to its domain name

(IP address) and to a dynamic UDP port, which is

allocated in response to a new VoVON client

request. Therefore, the JXTA-SIP gateway always

intermediates the audio streams from VoVON users

and SIP users, converting the encapsulation formats

and the addresses between the VoVON user (XML

message or RTP packets) and the SIP user (RTP

packets). In case of JXTA-SIP gateway failure, all

active connections are torn down, and VoVON

clients have to select a new MANET-JXTA gateway

and create new connections (possibly associated

with a different DNS domain).

WINSYS 2006 - INTERNATIONAL CONFERENCE ON WIRELESS INFORMATION NETWORKS AND SYSTEMS

230

Calls can be disconnected by any of the call

participants. When SIP's "BYE" or VoVON's

Call_End messages are received, JXTA-SIP end the

audio streaming, and completes the disconnection

signalling exchanges for each connection.

3.3 Interaction with SIP Proxy

JXTA-SIP gateway can be configured to register

itself on a SIP Proxy. However, the usual SIP

procedure of sending a REGISTER message for

each VoVON user cannot be used since the SIP-

Proxy does not know who is available in the

MANET.

Instead, JXTA-SIP gateway sends the SIP Proxy

a domain REGISTER message associating itself

with all names within a DNS domain name. A SIP

proxy handles an INVITE request by trying to match

a registered full URI. If none exists, it tries to match

a registered domain. In this case, it forwards the call

to the gateway and decrements the "Max-header"

field in the SIP header.

When a JXTA-SIP gateway receives a call to the

JXTA-SIP's DNS domain, it answers back with a

"100 trying" message and starts a MANET-JXTA

RS query looking for a VoVON user with the URI

name. This query carries a zero TTL value, meaning

that it only accepts calls when the VoVON user is

reachable at that instant. If the user is located, the

messages exchange follow a pattern similar to the

one presented in figure 3. Otherwise the call is

rejected.

4 APPLICATION

A VoVON prototype application is currently being

implemented over a prototype implementation of

MANET-JXTA. MANET-JXTA current prototype

extended a previous prototype presented in

(Oliveira, 05b) with the RS and the MANET-RVP

presented above.

4.1 VoVON Prototype

We implemented a MANET-JXTA application

which combines the VoVON user application and

the JXTA-SIP gateway application.

VoVON signalling is exchanged using two

control unidirectional pipes: one receiver pipe to

receive connection requests from remote client pipes

and other signalling messages; one client pipe for

connecting to remote control VoVON receiver pipes.

Audio can be transmitted using two JXTA pipes

(one for each direction), or using two RTP streams

over UDP.

Audio is handled using Java Media Framework

(JMF) version 2.1.1e (JMF, 06). The application

captures and formats audio into RTP format using

two JMF modules. VoVON application always tries

to select the GSM codec, due to its compression rate

(13 Kbit/s), but it is compatible with any format

supported by JMF.

Audio is transmitted over a JXTA pipe with the

RTP header, encapsulated in a XML message.

Therefore the JXTA pipe acts as a tunnel that

transparently sends audio samples through the JXTA

VON. JMF objects are connected to JXTA pipes

using a local UDP socket. JMF objects stream audio

to a local UDP socket, where the RTP packets are

received and sent through an audio JXTA pipe. RTP

packets are extracted from JXTA messages and sent

to the JMF objects using the same UDP socket.

Therefore, the architecture is not optimised for

sending audio over JXTA pipes because it

introduces additional jitter due to local socket

transmissions at the sender and at the receiver side.

The audio player is capable of compensating

some jitter, by storing the received audio samples on

a circular buffer and delaying their presentation.

However, if an audio sample is received after its

presentation time, it is discarded. By default, JMF

uses an audio buffer length of 250 ms, but it can be

configured to a maximum value of 1000 ms.

The graphical interface, presented in figure 4,

supports the application configuration and the call

initiation and termination. The user is allowed to

define its JXTA name (My Name), the JXTA group

it joins (Name), if it is a rendezvous peer (in

RendeVouz menu), and the gateway configuration

(RTP port and IP address, and the DNS domain

name, in the Gateway menu). The application

presents a list of known VoVON peers in a table, but

also allows the introduction of a SIP or VOVON

URI (by default is a SIP URI) to start a new call.

The Current MANET-JXTA implementation can

only use one of the transport protocols for all JXTA:

TCP or UDP. It cannot use both in parallel. When

the application is run for the first time, it opens a

MANET-JXTA configuration menu where the

transport module and the transport parameters are

chosen. The application stores the configuration in a

".jxta" directory for the next run.

4.2 Performance Measurements

VoVON application initial performance tests

focused on its overhead, compared to other Voice

over IP applications, and on its SIP interoperability.

A TELEPHONY APPLICATION FOR MANETS - Voice Over a MANET-extended JXTA Virtual Overlay Network

231

Figure 4: VoVON application user interface.

Audio can be sent using RTP packets over UDP

transport protocol, or using JXTA pipes over UDP

or TCP protocols. For GSM audio encoding, eighty

audio samples per second are sent. Using the

Ethereal protocol analyser (Ethereal, 06), we

measured the total number of bytes sent, represented

in table 2. JXTA pipes send two IP packet fragments

per sample, and TCP sends an acknowledge packet.

As expected, JXTA pipes introduce a huge overhead

that results from the presence of an Endpoint Router

and a VoVON headers, and from the XML encoding

overhead. This conclusion is consistent with

(Antoniu, 05), confirming that pipe encapsulation is

only valuable when bandwidth is not a problem, the

connection requires NAT or firewall crossing, or the

connection has a short life, dissuading any extra

MANET-route discovery delay.

Table 2: JXTA Pipes communication overhead for GSM

audio encoding.

Audio Encoding Sample size [Bytes]

RTP 153 Bytes/sample

JXTA Pipes over UDP 1799 Bytes/sample

JXTA Pipes over TCP 1818 Bytes/sample

Even with this large bandwidth overhead, it is

only possible to send audio over a JXTA pipe if the

end-to-end jitter introduced by the encoding and

decoding process is not significant, compared with

using RTP channels. Jitter is usually defined by

equation 1 (Schulzrinne, 03). Jitter is the mean

deviation (smoothed absolute value) of the

difference D between the arrival time and the sender

time tag. The smoothing factor of 1/16 is used to

reduce the effect of huge isolated deviation peaks,

common on 802.11b WLANs.

J(i)= J(i-1) + (|D(i-1,i)| - J(i-1))/16 (1)

Table 3 presents the average jitter value

measured at the receiver side for two SIP

Communicator user agents (SipCommunicator, 06)

using RTP streams over UDP, and for two VoVON

applications communicating on a network with only

two peers, using a TCP JXTA pipe. Jitter was

measured using Ethereal protocol analyser (which

uses equation 1), capturing the packets just before

they are received by the JMF object. The results

show that the use of JXTA TCP pipes introduces an

average jitter overhead of about 10 msec (52.8 %)

for one JXTA hop. This value can be compensated

using JMF buffering, and is clearly below the

maximum end-to-end delay defined by ITU-T for

telephony applications (150 msec).

Table 3: Average jitter for an unloaded Ethernet, measured

using Ethereal.

Audio encapsulation and network Jitter [ms]

RTP 19,23

RTP over JXTA TCP pipes 29,39

Table 4 presents the average jitter value

measured for an extensive set of experiments, with

two VoVON applications communicating on a

network with only two peers, for four different

setups. The jitter on the JXTA pipe was measured

when the XML audio messages are received from

the pipe (excluding the jitter introduced at the last

local socket retransmission), using a measuring

function included in the VoVON application. The

pipes' jitter measurements show that 802.11b

network is responsible for a 28% increase on the

average jitter for UDP pipes, and a 1% increase for

TCP pipes, comparing them to the Fast Ethernet

measurements. This behaviour difference is

probably due to a high overhead handling

fragmented 802.11b UDP packets on MS Windows

XP. Unfortunately, it was not possible to test

MANET-VoVON on Linux because the kernel does

not handle fragmented multicast UDP packets,

required for MANET-RVP. It also shows that TCP

congestion control effects are not noticeable

possibly because traffic bandwidth is very low.

VoVON JXTA-SIP gateway interoperability was

tested by connecting a VoVON client to a VoVON

JXTA-SIP gateway and to a SIP Communicator

(SipCommunicator, 06) user agent, using 802.11b

WLANs and Fast Ethernet. The system was also

tested with JAIN-SIP Proxy (NIST-SIP, 03). In all

WINSYS 2006 - INTERNATIONAL CONFERENCE ON WIRELESS INFORMATION NETWORKS AND SYSTEMS

232

cases, it was possible to start calls from the VoVON

clients and the SIP Communicator clients.

Table 4: Jitter measurements for unloaded networks using

VoVON and JXTA pipes.

Audio encapsulation and network Jitter [ms]

Pipes over UDP on Fast Ethernet 16,18

Pipes over TCP on Fast Ethernet 16,45

Pipes over UDP on 802.11b 20,75

Pipes over TCP on 802.11b 16,68

5 CONCLUSIONS AND FURTHER

WORK

This paper shows that MANET-JXTA peer-to-peer

open platform can be used to implement real-time

applications on a MANET or on meshed networks. It

shows that using MANET-RVP deferred search, it is

simple to have call setup triggered by connection

availability in a simple way. Other alternative

approaches, like using SIP events (Roach, 02),

would be complex. A centralized approach would

require a connection to a third party: the location

server. A decentralized approach would require

periodic flooding of searches or replies, controlled

by the application.

Internet Telephony based on p2p architectures

(i.e. Skype and P2P-SIP) has focused primarily on

the user's location tracking. This paper proposed and

analysed the possibility of also using the p2p

network for streaming audio, concluding that due to

the huge bandwidth overhead, its use should be

restricted to extreme situations: NAT and firewall

crossing, or short-lived connections. Results show

that the end-to-end jitter is acceptable when audio is

sent through a p2p VON.

Future work includes the continuation of the

design and implementation of MANET-JXTA and

MANET-VoVON. Quality of service can be

improved by introducing message differentiation

mechanisms in JXTA pipes, and by introducing

advanced flow control mechanisms based on

network state measurements. Further prototype

tuning is also necessary on the JXTA UDP transport

module and on the audio pipe communication. The

audio pipe's communication jitter can be reduced by

connecting the JMF classes directly to the JXTA

pipes using the JMF RTP socket interface. Finally,

comprehensive MANET multi-hop tests will be

done and reported on a future paper.

REFERENCES

Antoniu, G., Hatcher, P., Jan, M., Noblet, D., 2005.

Performance Evaluation of JXTA Communication

Layers. In GP2PC'2005, 5

International Workshop

on Global and Peer-to-Peer Computing, May 2005.

Baset, S., Schulzrinne, H., 2004. An Analysis of the Skype

Peer-to-Peer Internet Telephony Protocol. Technical

Report CUCS-039-04, Computer Science Department,

Columbia University, New York, USA, Sep 2004.

Ethereal, 2006. Ethereal: A Network Protocol Analyser.

Retrieved from http://www.ethereal.com/

NIST-SIP, 2003. A JAIN-SIP Proxy for the People!.

Retrieved from http://snad.ncsl.nist.gov/proj/iptel/

JMF, 2006. Java Media Framework API (JMF). Retrieved

from http://java.sun.com/products/java-media/jmf/

JXTA, 2004. Project JXTA: JXTA v2.0 Protocols

Specification. Retrieved from http://spec.jxta.org/

nonav/v1.0/docbook/JXTAProtocols.html

JXTA, 2006. JXTA: Get Connected. Retrieved from

http://www.jxta.org

Oliveira, R., Bernardo, L., Pinto, P., 2005. Flooding

Techniques for Resource Discovery on High Mobility

MANETs. In IWWAN'05, International Workshop on

Wireless Ad-Hoc Networks, May 2005.

Oliveira, R., Bernardo, L., Ruivo, N., Pinto, P., 2005b.

Searching for PI resources on MANETs using JXTA.

In AICT-SAPIR-ELETE'05, Advanced Industrial

Conference on Telecommunications/Service Assurance

with Partial and Intermittent Resources Conference/E-

Learning on Telecommunications Workshop, pp. 371-

376, IEEE Press, July 2005.

Perkins, C., 2001. Ad Hoc Networking, AddisonWesley.

Roach, A., June 2002. Session Initiation Protocol (SIP)-

Specific Event Notification. IETF RFC 3265, June

2002.

Rosenberg, J., Schulzrinne, H., Camarillo, G., Johnston,

A., Peterson, J., Sparks, R., Handley, M., Schooler, E.,

2002. SIP: Session Initiation Protocol. IETF RFC

3261, June 2002.

Schulzrinne, H., Casner, S., Frederick, R., Jacobson, V.,

2003. RTP: A Transport Protocol for Real-Time

Applications. IETF RFC 3550, July 2003.

Singh, K., Schulzrinne, H., 2005. Peer-to-Peer Internet

Telephony using SIP. In NOSSDAV'05, International

Workshop on Network and Operating Systems Support

for Digital Audio and Video, pp. 63-68. ACM Press.

SipCommunicator, 2006. SIP Communicator - the Java

VoIP and Instant Messaging client. Retrieved from

https://sip-communicator.dev.java.net/

Skype, 2006. Skype Explained. Retrieved from

http://www.skype.com/products/explained.html

Smith, J., 1998. The book, The publishing company.

London, 2

edition.

Zhang, X., Schulzrinne, H., 2004. Voice over TCP and

UDP. Technical Report CUCS-033-04, Computer

Science Department, Columbia University, New York,

USA, Sep 2004.

A TELEPHONY APPLICATION FOR MANETS - Voice Over a MANET-extended JXTA Virtual Overlay Network

233
