MULTIDIMENSIONAL SCHEMA EVOLUTION
Integrating New OLAP Requirements
Mohamed Neji, Ahlem Nabli, Jamel Feki, Faiez Gargouri
Laboratory MIRACL, ISIM Institute, BP 1030-3018, Sfax. Tunisie
Keywords: Data warehouse, Data mart, Schema evolution, OLAP requirement.
Abstract: Multidimensional databases are an effective support for OLAP processes. They improve the enterprise
decision-making. These databases evolve with the decision maker requirements evolution and, are sensitive
to data source changes. In this paper, we are interested in the evolution of the data mart schema due to the
raise of new OLAP needs. Our approach determines first, what functional data marts will be able to cover a
new requirement, if any, and secondly, decides on a strategy of integration. This leads either to the alteration
of an existing data mart schema or, to the creation of a new schema suitable for the new requirement.
1 INTRODUCTION
Decisional systems based on data warehouses
(DWs). In a previous work, we proposed a top down
DW design approach where requirements are
expressed as two-dimensional sheets. This approach
generates data mart (DM) schemes (Feki, 2004),
(Nabli and al., 2005) and (Soussi and al., 2004).
However, these requirements evolve and may
require additional data.
Recently, literature has brought forward the
problem of evolutions in the multidimensional
structures and, new models have been proposed. The
updating models (Blascka and al., 1999), focus on
mapping data into the most recent version of the
structure, whereas tracking history models (Bliujute
and al., 1998), (Chamoni and al., 1999), (Eder and
al., 2001), (Mendelzon and al., 2000) and (Pedersen,
2001) keep trace of the evolution of the system. The
approach in (Chamoni and al., 1999) develops a
multidimensional temporal model.
The model of (Eder and al, 2001) proposes mapping
functions that allow conversions between structure
versions. It provides a partial solution, which neither
takes schema evolution and time consistent
presentation into account, nor considers complex
dimension structures.
In (Pedersen and al., 2001), the authors propose
a conceptual model focusing on imprecision and
complex dimension structures. However, their model
does not provide the means to reporting data in any
other versions than the latest.
In this context of study, (Body and al., 2003) present
a model with validity periods and a multiversion
concept. They distinguished between schema
evolution and dimension instance evolution. This
work presents a list of operations for schema
changes and a set of operations for the instance
dimension changes. Similarly, we consider two
levels of evolution; the intention level (schema) and
the extension level (data).
In particular, we are interested with DM schema
evolution due to the emergence of new OLAP
requirements. To do so, we develop two main steps:
one comparison step, it is to identify which DM
schema may be altered, and one adaptation step to
make the necessary alterations on the DM schema.
In the remainder, section 2 will present the
multidimensional concepts, our notation and
describes the structure of OLAP requirements.
Section 3 describes our approach of MS evolution.
Section 4 outlines the proposed method and sets
future works.
2 MULTIDIMENSIONAL
CONCEPTS
Fact
Each fact reflects the information of the subject that
has to be analyzed.
Definition. A fact F is defined as (fname, Mf) where:
- fname is the name of a fact,
331
Neji M., Nabli A., Feki J. and Gargouri F. (2006).
MULTIDIMENSIONAL SCHEMA EVOLUTION - Integrating New OLAP Requirements.
In Proceedings of the Eighth International Conference on Enterprise Information Systems - DISI, pages 331-334
DOI: 10.5220/0002461303310334
Copyright
c
SciTePress
- Mf = {m
F
1
, m
F
2
…, m
F
n
} is a finite set of measures,
each measure m
F
i
is defined as m
F
i
= (NameM
F
i
,
FuncM
F
i
) where:
- NameM
F
i is the name of a measure,
-FuncM
F
i is an aggregate function.
Dimension
A dimension is the axis according to which a fact
will be analyzed. It is made up of a finite set of
attributes; some of them take part to define various
levels of detail (hierarchies), whereas others are less
significant but used, for instance, to label results.
The latter are said weak attributes.
Definition. A dimension d is defined as (d
N
, Att,
HIER) where:
- d
N
is the name of a dimension,
- Att is a set of all attributes of d (including weak
attributes),
- HIER = {h
1
d
, h
2
d
.., h
t
d
} is a set of hierarchies of d.
The attributes of a dimension d are organized in
hierarchies.
Definition. A hierarchy h
d
i
of a dimension d is an
acyclic path defined as (N
HMid
, ParamF, Att-F)
where:
- N
hid
is the name of a hierarchy,
- ParamF=<p1, p2…,pn > is an ordered list of
attributes used in h
d
i
,
- Att-F is a function which associates an attribute pi
to the set of its weak-attributes with i [1..n], Att-
F(pi)={ at
e
, ..,at
r
} and j [e..r], at
j
Att and at
j
ParamF.
Multidimensional Schema
A DM is characterized by its MS which can be
either a star schema analyzing a single fact
examined according to dimensions or, a
constellation schema gathering several facts with
shared dimensions. In our approach, each schema
belongs to one specific application domain.
Definition A multidimensional schema is defined as
a tuple (N
sch
, N
D-sch
, F
sch
, DIM, Funct) where:
- N
sch
is the name of a multidimensional schema,
- N
D-sch
is the name of the schema domain,
- F
sch
= {F
1
, F
2
,..,F
s
} is a finite set of facts,
- DIM = {d
1
, d
2
…, d
v
} is a finite set of dimensions,
- Funct is a function which associates a fact F
i
to the
list of its dimensions with i [1..s], Funct(f
i
) =
{d
i
…, d
p
} with j [i..p], d
j
DIM.
OLAP requirement structure
In our approach (Feki, 2004), which aims at
developing a computer aided design tool, we
propose to collect user requirements in a format
familiar to the decision makers, i.e., as structured
sheets (Figure 1). A sheet defines the fact to be
analyzed and its domain, its measures and
dimensions.
Italie
CLIENT
Dimension
Total
1999
2000
2001
year
France
Liban
Country
SALES
(qte, Amount)
Fact
Fact measures
TIME
Dimension
CLIENT
TIME
Italie
CLIENT
Dimension
Total
1999
2000
2001
year
France
Liban
Country
SALES
(qte, Amount)
Fact
Fact measures
TIME
Dimension
CLIENT
TIME
Figure1: Example of two-dimensional sheet.
Note that the structure of a sheet T can be seen as a
special star schema since it has a single fact.
3 DM SCHEMA EVOLUTION
DM schema evolve due to several causes, among
them : (i) changes in the source structure or (ii)
changes in the decisional user needs. In this work we
address the problem of DM schema evolution due to
changes in OLAP needs. These changes can affect:
subjects of analysis (fact and/or measures) or,
axes of analysis (dimensions and hierarchies).
To know whether a new requirement may be
covered by existing DMs or not, and how to realize
it, we propose a two-phase approach: a comparison
phase, it is to compare the OLAP requirement with
the functional DM schemes, and an adaptation
phase that is to adapt a DM schema according to
the new requirement. Only the first one is presented
in this paper.
The comparison phase compares the OLAP
requirement (sheet) with the existing DM schemes to
identify one of the following cases:
a)There is a schema that covers the requirement,
b)The requirement is partially satisfied, an alteration
of a schema is necessary,
c)The requirement is completely not satisfied, the
creation of a new MS is required.
The following algorithm Search_sch, identifies one
of the above situations.
Inputs:
-T is a sheet representing an OLAP requirement,
-S= {S
1
, S
2
…, S
n
}: a set of n stored MS belonging to
m domains of analysis (m n).
Output:
- A case is identified from a), b) or c) of above.
ICEIS 2006 - DATABASES AND INFORMATION SYSTEMS INTEGRATION
332
Algorithm SEARCH_SCH
BEGIN
For each Sch
i
in S do
Begin
1. If F Є Sch
i
then // integrate T in
Sch
i
1.1. If D
DIM then
If M
Sch
i
.F.mf
Then T is satisfied
else Add M
to Sch
i
.F.mf
1.2. else
Begin
1.2.1. determine the set D
add
of
dimensions to be added
1.2.2. for each d D
add
do
Add dimension d to DIM
1.2.3. determine the set D
alt
of
dimensions to be altered
1.2.4. for each d D
alt
do
1.2.4.1. to determine the
set H
add
of hierarchies to be
added
1.2.4.2 for each h H
add
do
add the hierarchie to d
1.2.4.3. determine the set
H
alt
of hierarchies to
be altered
1.2.4.4. For each h H
alt
do
begin
- to determine the strong
and weak attributes of h
to add to d
- to add the strong and
weak attributes to h
End
1.2.5 If M set of mesures F
then measures are satisfied
1.2.6 Else
add measures to sch
i
for the
fact F
End
End
2. else
begin // call IDENTIFY_SCH algorithm
Result := IDENTIFY_SCH (T,S)
If Result = {} then
Create new star schema
Else Add T to Result
End
END.
If the algorithm identifies case b) and the fact F
S
i
i [1..n] then it raises the problem of choosing
which DM schema has to be modified. This requires
the identification of the candidate MS and how to
choose one; i.e., the MS that has the maximum of
common elements with the new requirement. To
carry out this choice, we use the similarity factor
(Soussi and al., 2005) which is a metric measuring
the relevance of the integration.We define two
similarity metrics, one for measures and one for
dimensions.
Dimension Similarity Metric SimD (T, S
i
)
It measures the relevance of the integration of the
requirement in a MS, it is based on dimensions.
()
<=
=
otherwiseqp
mnorpnif
STSimD
i
/
75.0
,
- n: number of dimensions of T
- m: number of dimensions of S
i
- p : number of common dimensions between T and S
i
- q : number of different dimensions = n+m-p
Measures Similarity Metric SimM (T, S
i
)
It measures the relevance of the integration of the
requirement in a MS; it is based on measures.
()
<=
=
otherwiseqp
mnorpnif
STSimD
i
/
75.0
,
n, m, p and q are as above replacing dimensions by
measures.
To decide whether the fact F
in T leads to the
construction of a new MS or it will be integrated
into an existing one, we define two vectors:
1- A Dimension Similarity Vector DSV containing
all values of SimD (T,S
i
)
i
[1..n].
2- A Measure Similarity Vector MSV containing all
values of SimM (T,S
i
)
i
[1..n].
The integration of requirement T into an existing
DM can occur if and only if the maximum of at least
one vector is greater than 1/3.
The following algorithm IDENTIFY_SCH identifies
a schema, among several candidate MS, where the
requirement should be integreted. It uses DSV and
MSV vectors.
Algorithm IDENTIFY_SCH
- P
simil
: a threshold parameter indicating the minimal
value beyond which the integration of the
requirement can be carried out.
Max
d
:= Max (DSV)
Max
m
:= Max (MSV)
- VmaxD : a subset of S such as i [1..p] pn
VmaxD(i) = Max
d
.
- VmaxM : a subset of S such as i [1..q] qn
VmaxM(i) = Max
m
.
- Int_sch : a set of schemes common to VmaxD and
VmaxM
- nb : number of rows in HSM
Inputs:
- T: a sheet representing an OLAP requirement
analyse a fact according to n dimensions where F
T
S
i
i
[1..n]
- S ={S
1
,S
2
,……,S
n
}
: n stored MS belonging to m
domains
(m n).
MULTIDIMENSIONAL SCHEMA EVOLUTION - Integrating New OLAP Requirements
333
Output:
Sch_res: set of candidate schemes where T could be
integrated.
BEGIN
calculate DSV, MSV, VmaxD and VmaxM
1. If (Maxd Psimil) or (Maxm
Psimil) then
1.1. Int_sch = VmaxD VmaxM
1.2. If Int_sch = then
Begin
1.2.1 SmaxDM:=0
1.2.2 For each schema S in
VmaxD do
Begin
If SmaxDM < DSV(S) + MSV(S)
then
Begin
SmaxDM := DSV(S) + MSV(S)
Sch_res := Sch_res {S}
End
End
1.2.3 Return Sch_res
End
2. Else
2.1 If Int_sch = 1 then
Return Int_sch
2.2 Else
Begin
2.2.1 Calculate HSM for all
schemes in Int_sch
2.2.2 SH_max:=0
2.2.3 For each schema S in
Int_sch do
Begin
),(max_
1:
SjiHSMSHIf
nb
j
=
Begin
),(:max_
1:
SjiHSMSH
nb
j
=
=
Sch_res := Sj
end
End
2.2.4 Return Sch_res
End
END
4 CONCLUSION
In this paper, we present the evolution of the DM
schemes based on the OLAP requirements evolution.
These requirements expressed as dimensional fact
sheets are compared with the existing DM schemes
in order to be integrated. For that, we have proposed
two phases approach. The first phase compares the
new requirement with the MS to detect the new
requirement elements. The second phase, not
presented in this paper, adapts a MS and, is based on
a set of algebraic operators. We have introduced the
concept of similarity as a metric to identify the
candidate MS. This work is a part of an ongoing
project.
We are interested with the development of a
software tool. Especially, it is to visualize the MS
graphically and to highlight the evolution impacts on
the DW schema. Currently we are studying the
effect such alteration on the DM data.
REFERENCES
Blaschka M., Sapia C. and Höfling G., “On Schema
Evolution in Multidimensional Databases”,
Proceedings of DaWak’99 Conference, Florence,
Italy, 1999.
Bliujute R., Saltenis S., Slivinskas G., Jensen C.S.,
“Systematic Change Managment in Dimensional Data
Warehousing”, Proceedings of the 3rd International
Baltic Workshop on DB and IS, 1998.
Body M., Miquel M., Bedard Y., Tchounikine A.,
“Handling Evolutions in Multidimensional
Structures”, 19th International Conference on Data
Engineering Sponsored by the IEEE Computer
Society March 5 - March 8, 2003 Bangalore, India.
Chamoni P. and Stock S., “Temporal Structures in Data
warehousing”, In Proceedings of the DaWaK’99
Conference, Florence, Italy, 1999.
Eder J. and Koncilia C., “Evolution of Dimension Data in
Temporal Data Warehouses”, Proceedings of the
DaWaK’01 Conference, Munich, Germany, 2001.
Feki J., “Vers une conception automatisée des entrepôts de
données : Modélisation des besoins OLAP et
génération de schémas multidimensionnels“, 8th
MCSEAI, Tunisia, 2004.
Mendelzon A.O. and Vaisman A., “Temporal Queries in
OLAP” Proceedings of the 26th VLDB'00 Conference,
Cairo, Egypt, 2000.
Nabli A., Feki J. and Gargouri F.:" Automatic construction
of multidimensional schema from OLAP
requirements", AICCSA'05, 3-6 January, Cairo, Egypt.
Pedersen T.B., Jensen C.S. and Dyreson C.E., “A
foundation for capturing and querying complex
multidimensional data”, Information Systems Special
Issue: Data Warehousing, Vol 26, No 5, 2001.
Soussi A., Feki J., et Gargouri F., “Approche semi-
automatisée de conception de schémas
multidimensionnels valides“., EDA’05, 10 juin Lyon,
France, 2005.
ICEIS 2006 - DATABASES AND INFORMATION SYSTEMS INTEGRATION
334
