SECTET – An Extensible Framework for the Realization
of Secure Inter-Organizational Workflows
Michael Hafner
1
, Ruth Breu
1
, Berthold Agreiter
1
, Andrea Nowak
2
1
Universität Innsbruck, Institut für Informatik, Innsbruck, 6020, Österreich
2
Austrian Research Center Seibersdorf Research GmbH, Seibersdorf, 2444, Österreich
Abstract. S
ECTET is an extensible framework for the model-driven realization
of security-critical, inter-organizational workflows. The framework is based on
a methodology that focuses on the correct implementation of security-
requirements and consists of a suite of tools that facilitates the cost-efficient
realization and management of decentralized, security-critical workflows. After
giving a description of the framework, we show how it can be adapted to
incorporate advanced security patterns like the Qualified Signature, which
implements a legal requirement specific to e-government. It extends the concept
of digital signature by requiring that the signatory be a natural person.
1 Introduction
SECTET is a framework for the high-level development and management of security-
critical, inter-organizational workflows based on Web services. The framework
supports business partners during the design, the realization and the management of a
common Global Workflow - a decentralized collaboration between actors across
domain boundaries [1]. Realizing the paradigm of Model Driven Security [2], the
framework targets the correct technical implementation of business-level security-
patterns which are integrated at the abstract level into the specification of the Global
Workflow.
A Global Workflow specifies the message flow between partners in a distributed
environment with no central control, by means of UML 2.0 diagrams. The models of
this virtual process are translated into executable configuration files for Workflow
Management Systems (WFMS) and security components of target architectures
located at every partner’s node based on XML and Web services standards and
technologies [3]. A target architecture encapsulates a set of core Web services, which
may access back-end services, orchestrates them through a WFMS, and guards them
by imposing specified security policies to inbound and outbound service calls.
In this paper we present the core components of our framework and illustrate the
main concepts of our methodology for the systematic design and realization of
security-critical inter-organizational workflows with a portion of a workflow-scenario
drawn from e-government. We additionally show how the framework can be adapted
to incorporate advanced security patterns like the Qualified Signature, which extends
the concept of digital signature by requiring a natural person to sign [4].
Section 2 sketches the technical background of our framework and refers to related
Hafner M., Breu R., Agreiter B. and Nowak A. (2006).
SECTET – An Extensible Framework for the Realization of Secure Inter-Organizational Workflows.
In Proceedings of the 4th International Workshop on Security in Information Systems, pages 47-57
Copyright
c
SciTePress
work. Section 3 introduces a motivating scenario and shows how to realize a secure
inter-organizational workflow by applying the concepts of our framework to a
specific case. Section 4 shows how the framework can be extended according to
specific business requirements. For a comprehensive introduction to the S
ECTET
framework or a detailed presentation of single aspects, please refer to a series of
accompanying papers (e.g., [5], [6] and [7]).
2 Background
Workflow Standards. The Business Process Execution Language for Web Services
(WS-BPEL [8]) is an XML-based language to compose workflows on top of atomic
Web services. It provides mechanisms to define executable business processes and,
with limitations, abstract business protocols. Collaboration protocols like BPSS [9]
and WS-CDL [10] provide the means to formally specify collaborations in distributed
environments by offering a global view on collaborating services. BPML [11] and
ebXML [10] are alternative languages to specify executable processes. BPML is quite
similar to WS-BPEL as it supports Web services standards, but it is considered as
semantically weaker. ebXML comprises a powerful set of standards for the
specification of B2B protocols but it is not compatible to the Web services concept.
Since we strongly focus on Web services technologies, which is the most widespread
technology with strong vendor support, we consider WS-BPEL as the appropriate top-
layer standard to model local workflow processes in our context.
Web Services Security. Currently a comprehensive set of Web services security
standards is emerging. OASIS has proposed a security extension built on top of the
SOAP Protocol [12]. The extension uses the XML encryption and signature
mechanism to add security features to SOAP messages ([13], [14]). This way, security
mechanisms can be integrated into the header and the body of a SOAP message, and
be sent via any transport channel without compromising security. Beside transport
level security extensions, a variety of standards provides means to manage and
exchange security policies. XACML [15] is a standard to define access control for
resources in a system. Sun has proposed a specific profile for XACML – called Web
Services Policy Language - to define the reconcilement of access rights between
partners. SAML [16] is a standard for the exchange of security tokens. WS-Policy
[17] allows for the definition of protocol level security requirements.
Related Work. Many approaches deal with secure document exchange and
workflow management in centrally organized environments, e.g., the Author-X
system [18], Akenti [19] and the EU-financed project TrustCom [20]. A big
community is working on issues related to inter-organizational workflow management
systems [1], [21], [22], and [23]. We do not aim to contribute a novel approach to this
field. Instead, we rely on UML models for modeling workflow and security into
workflow management systems based on Web services technology. Security
extensions for workflow management systems are treated in [24], [25] and [26]
although at a quite technical level. A model driven approach that is close to the idea
of our framework is [2]. It introduces the concept of Model Driven Security for a
software development process that allows for the integration of security requirements
through system models and supports the generation of security infrastructures. But
48
this approach focuses exclusively on business logic, whereas we concentrate on inter-
organizational workflow management.
3 The SECTET - Framework
In this section we introduce the conceptual foundation (3.1), we then present the
components of the SECTET Framework (3.2) and finally show how the framework is
applied to a real-life case study, by modeling a Global Workflow that complies to
three basic security requirements of the concept Secure Document Flow (3.3).
3.1 Conceptual Framework
3.1.1 Global and Local Workflows
We define a Global Workflow as a network of partners cooperating in a controlled
way by calling services and exchanging documents. In order to guarantee loose
coupling and design autonomy at the local level without compromising
interoperability, we make the assumption that there is no central control of the inter-
organizational workflow. This means that there is no central Workflow Management
System (WfMS) or document repository.
The Global Workflow can be thought of as virtual process that emerges through
peer-to-peer interaction of executable Local Workflows, which traditionally are
located in different domains. Through their collaboration they exactly realize the
behavior as specified in the Global Workflow. This kind of decentralized application
is especially suited to scenarios where central management is not desirable, may it be
for social, political or competitive reasons (e.g., public procurement, e-government).
In contrast to the Global Workflow, a Local Workflow is executed on a WfMS.
This kind of process accesses back-end functionality by calling local services and
orchestrates these services according to some workflow logic. In our approach we
focus on the Global Workflow and assume that partners already have implemented
the application functionality they agreed to contribute to the Global Workflow.
3.1.2 Model Views
Our approach is based on two orthogonal views: the Interface View and the Workflow
View. The latter is further divided into the Global Workflow Model (GWfM)
specifying the message exchange between cooperating partners, and the Local
Workflow Model (LWfM) that describes the application and the workflow logic which
is local to each partner. The Interface View describes the interface of every partner
independently of the components’ usage scenario. The application of orthogonal
perspectives allows us to combine the components that provide the services, into
various global Workflows, each one realizing a particular usage scenario.
3.1.3 Interface View
The Interface View represents the contractual agreement between the parties to
provide a set of services. It specifies the minimum set of technical and domain level
constraints and thereby links the GWfM to the LWfM. It describes the interface of
49
every partner’s services independently of their usage scenario and consists of four
sub-models:
The Document Model is a UML class diagram that describes the data type view of
the partner. We talk of documents because we do not interpret this class diagram in
the usual object oriented setting but in the context of XML schema. The Interface
Model contains a set of abstract (UML-) operations representing services the
component offers to its clients. The types of the parameters are either basic types or
classes in the Document Model. Additionally, pre- and post-conditions (in OCL style)
may specify the behaviour of the abstract services. The Role Model describes the roles
having access to the services and finally the Access Model describes the conditions
under which a certain role has the permission to call a service. The permissions are
written in S
ECTET-PL [27] in a predicative style over the structures of the Document
Model. We provide an in-depth view on model dependencies in [5].
In most cases, when parties agree to realize a Global Workflow, the Interface View
or some of its sub-models already exist as parties may already make some of there
services accessible to the outside world. Very often the Document Model, which
corresponds to the information model and the Interface Model, consisting of method
signatures already exist.
3.1.4 Security in Global Workflows
The security requirements are modeled at the design level and integrated as security
patterns into the models of the Workflow and the Interface View. They are then
translated into executable security components or configuration artifacts for target
architectures. Our framework currently supports the following security patterns:
A. Secure Document Flow (Module S
ECTINO). This pattern allows the
specification of a secure document exchange satisfying “End-to-End Security”, which
means that the requirements are satisfied even in case of being routed via
intermediaries. Documents or parts can be qualified with the requirement of
confidentiality, which is implemented with the help of public key encryption,
Integrity, which means a kind of system signature or non-repudiation of sender or
receiver, which triggers signaling at the protocol layer through the exchange of signed
timestamps.
B. Context Dependent Access Constraints (Module S
ECTET-PL). We specify
conditions under which a specific role has the right to access services in the Access
Model with the help of an extended OCL-style predicate logic [27]. The right to call
an operation of a specific Web service may depend either on the caller’s role or on
parameters that may depend on the system’s environment (e.g., time, IP-Address etc.)
or that are sent together with the service call.
C. Application Domain Specific Security (Module S
ECTET-Extensions). Many
scenarios have to integrate complex security patterns that satisfy complex legal or
business-driven requirements. In most cases they are based on the basic requirements
of confidentiality, integrity or non-repudiation. The Qualified Signature is an e-
government specific requirement that extends the concept of the system signature,
which is used to guarantee integrity to a legal entity (e.g., a citizen). In public
procurement anonymity of bidders is guaranteed by a specific security protocol and in
most cases requires a trusted third party.
50
3.2 SECTET-Framework Components
3.2.1 Modelling Component
The modeling component comprises a set of tools that supports the collaborative
modeling of the Global Workflow and its security-requirements at the application
domain level in a platform independent context. According to OMG’s paradigm of
Model Driven Architectures (MDA) we specify three levels of abstraction (Fig. 1a):
The Platform Independent Model (PIM) captures the domain level knowledge
and abstracts from implementation details of the target architecture in two respects.
The global process is defined independently of platform technology at partner nodes
(J2EE, DotNet, Corba etc.) and independently of workflow standards like BPEL or
BPSS that may be used to implement local workflow logic. We model the Global
Workflow using UML 2.0 activity diagrams. Security requirements are integrated as
constraints associated to object nodes, which act as a logical container for documents
flowing from partner to partner. Documents and interface signatures are modeled as
class diagrams in the Document and the Interface Model respectively.
The Platform Specific Model (PSM) describes the system on its intended platform
(e.g. BPEL4WS) by integrating platform specific syntax and semantics. Parts of the
global workflow logic are translated into executable stubs in a specific workflow
standard for WfMS at partner nodes. The translation component (Sect. 4.2) generates
the interfaces of the Local Workflows that are accessed by the Global Workflow.
The Implementation Specific Model (ISM) represents the reference architecture
that acts as the runtime environment at local partner nodes. Currently our framework
targets a Web services based reference architecture.
Applying the MDA approach means the transformation of a PIM into a PSM and /
or an ISM. We extend the MDA approach towards Model Driven Security in the
sense that we integrate security requirements at the abstract level into the PIM. The
PIM and the PSM are mapped onto each other and finally translated into
configuration artefacts for the runtime environment.
(a) (b)
Fig. 1. Model Dependencies (a) and Reference Architecture (b).
1.
3. Optional: Conformance Validation through Standard
2´´
Global Workflow Model
UML 2.0
Interface Model
(UML 2.0)
Local Workflow Model
UML4BPEL UML 1.5 Profile
.
Orchestration Language
(BPEL)
Security Configurations
(XACML, WSPL, WS-Security, …)
Model Level
Runtime Level
PSM
PIM
ISM
Choreography Language
(WS-CDL, BPSS, …)
Security Domain Boundaries
External
Policy
Enforcement
Point
(Security
Gateway)
Token
Processing,
Decryption and
Signature
Validation
Message
Encryption and
Signature
Workflow
Engine
Web Service
Web Service
Web Service
Internal
policy
Enforcement
point
Elemental Services
Policy Decision Point
Policy Configuration
Engine
Authentication &
Role Mapping
Authentication Request
Security Compliance
Check
Authorization
Request
Policy
Repository
Internal
PDP
PKI Interface
to Security Token Service
Logging Unit Session Engine
5
3
2
1
2
4
6
7
8 9 10
2
11
12
Signature Component
11
51
3.2.2 Reference Architecture
The target architecture as depicted in Figure 1 represents the runtime environment for
the Local Workflow and its back-end services at the partner node. The architecture is
based on the data-flow model of XACML [15]. The components implement a set of
XML- and Web services Technologies and standards.
Workflow Component. A workflow engine (1), based on an XML-based
Workflow Language like BPEL orchestrates the sequence of local Web services (2)
calls as specified in the LWfM. The engine bundles the services to a composition that
may be offered to a service of its own. As described above, Global and Local
Workflows are modeled in the PIM and PSM as UML 2.0 diagrams and translated
into runtime artifacts (BPEL files for the Workflow Engine, WSDL-Files for Web
services description) for the target architectures.
Workflow Security. The workflow engine and the Web services in the back-end
are wrapped by security components. So-called Policy Enforcement Points (PEP) act
as security gateways. We differentiate between the external (3) and the internal PEP
(11). The external PEP is the single point of entry into the domain. He is in charge of
implementing requirements related to message integrity, confidentiality and non-
repudiation for all external communication. To this end, it checks the correct
signatures and decrypts incoming requests or response. Correspondingly, the gateway
signs outgoing requests or responses and encrypts them as specified in the global
workflow model. Both, the security gateway and the workflow engine implement the
requirements by configuration. The configuration data is generated from the
respective models views. After receiving a service request the PEP authenticates the
caller with support of the Authentication and Role Mapping Unit (6), checks the
compliance of the incoming message according to signed and encrypted elements (5)
and finally queries the Policy Decision Point (PDP) (4) for access rights. After
successful completion of these three steps, the PEP forwards the request to the
workflow engine (1) which then performs the service orchestration. Optionally, an
internal PEP, that merely acts as a role mapping unit may map the caller’s global role
to some internal role representation required by the back-end applications.
3.2.3 Model Transformation and Code Generation Component
This component has three tasks:
A. Mapping Global to Local Workflows. Those parts of the GWfM that
correspond to interfaces that local process nodes should implement are translated into
stubs of executable process code. In our case study the partners imported the stubs
into Oracle’s Process Manager [28] and added service calls to back end functionality.
B. Generation of Security Artefacts. The security requirements in the PIM are
translated into configuration artefacts for the target architectures. We made the
assumption that every partner wrapped his local node with the security components
specified in the reference architecture.
C. Import and Export of Global Workflows. A choreography which was
specified in a wide-spread standard like WS-CDL or BPSS can be imported into the
framework [29]. The intention is the representation of a global workflow with a
standard that is completely independent of the technical platform. WS-CDL is only
suited to representation of choreographies, that were designed to run on a Web
services based platform. The same can be said about BPSS and ebXML.
52
3.3 Scenario
The example captures an inter-organizational process in e-government. It is drawn
from a case that was elaborated within the project SECTINO [5]. The project's vision
was defined as the development of a framework supporting the systematic realization
of e-government related workflows.
The workflow “Municipal Tax Collection" describes a Web services based
interaction between three participants: a tax-payer (the Client), a business agent (the
Tax Advisor) and a public service provider (the Municipality). In Austria, wages paid
to employees of an enterprise are subject to the municipal tax. According to the
traditional process, corporations have to send an annual statement via their tax advisor
to the municipality. The latter is responsible for collecting the tax. It checks the
declaration of the annual statement calculates the tax duties and returns a tax
assessment notice to the tax advisor. In our case the stakeholders in this public
administration process agreed to implement a new online service, which enables
citizens and companies to submit their annual tax statements via internet. Due to legal
considerations, the process had to be realized in a peer-to-peer fashion and should
integrate security requirements like integrity, confidentiality and non-repudiation and
ultimately advanced security patterns like the Qualified Signature.
3.3.1 Modelling the Global Process
Table 1. Informal Description of Global Workflow and Security Requirements.
1. Client sends annual statement to Tax Advisor
2. Tax Advisor does internal processing on the document
3. The Tax Advisor forwards the processed annual
statement
4. Municipality calculates tax duties and
5. Municipality returns a notification to Tax Advisor
6. Tax Advisor processes notification
7. Tax Advisor sends tax information to Client
Internal Processing Steps Document flow Interaction Activity
A. Integrity: All exchanged documents have to be signed by
the sending party with a “System Signature” when leaving the
domain boundaries in order to guarantee message integrity.
B. Confidentiality: The annual income and the clientId of
the annual statement and the tax notification are
confidential, and should only be readable to the Municipality
C. Non-repudiation: Receipt of the annual statement and
the notification must not be deniable.
Modeling the global process requires two steps. In a first step the partners had to
agree on a global process scenario they wanted to implement. Table 1 informally
summarizes the Global Workflow. The partners identified three roles (Client, Tax
Advisor and Municipality), four interactions (steps 1, 3, 5 and 7) and four documents
flowing between the partners (annual statement, processed annual statement,
notification and information).
TaxAdvisor
receiveAnnualStatement
sen d P r oce sse d A S
sen d C on firma tion
Munici
p
alit
y
receiveProcessedAS
sen d N o ti fica ti o n
«sec urityR equirements»
context processedA S : ProcessedAS :
self.Confidentiality ={
(self.annualIncome ),
(self.clientID)
}
self.Integrity = { (s elf) }
self.NonR epudiation ={ (self) }
processedA S
notification
«se c urityR equ irem ents »
context notification : Notification:
self.Confidentiality ={
(self.annualIncome ),
(self.clientID )
}
self.Integrity = { (self) }
Client
Annual
Statem ent
Inform ation
Fig. 2. Global Workflow Model as UML 2.0 Activity Diagram.
53
Figure 2 shows the result of step 2: the Global Workflow is specified as a UML 2.0
activity diagram. It describes the collaboration of the three roles in terms of the
interactions in which the participating parties engage. Model information is confined
to "observable behaviour", corresponding to the message flow between the
participants, the interaction logic and the control flow between the elementary actions.
The graphical representation of the Global Workflow as a UML 2.0 activity diagram
allows formalizing the process description in a very intuitive way.
3.3.2 The Transformation Process
The first part of the translation process generates those parts of the Local Workflow
Model which represent the interfaces to the GWfM (e.g., the Interaction-Activities
receiveAnnualStatement and SendProcessedAS) for every partner-role (Fig. 3a).
Those partners who are assigned a specific role in the GWfM take the BPEL code
stubs, import them in the BPEL design tool of their choice (e.g., [28]) and
complement service calls to back-end application. The models can then be translated
into BPEL and WSDL files for the workflow engine with existing tools (e.g., [30]).
<process name="Sectino_TaxAdvisor_LWfM">
<partnerLinks>
<partnerLink name="MS_Provider" partnerLinkType="Municipality_LWfM"
partnerRole="Municipality_LWfM"/>
<partnerLink name="TS_Provider" partnerLinkType="TaxAdvisor_LWfM"
partnerRole="TaxAdvisor_LWfMRequester"
myRole="TaxAdvisor_LWfMProvider"/>
</partnerLinks>
<variables>
<variable name="input" messageType="AnnualStatement"/>
<variable name="output" messageType="Confirmation"/>
<variable name="input_MU" messageType="ProcessedAS"/>
<variable name="output_MU" messageType="Notification"/>
</variables>
<sequence name="main">
<receive name="receiveInput" partnerLink="TS_Provider"
portType="TaxAdvisor_LWfM"
operation="sendAnnualStatement" variable="input" createInstance="yes"/>
<invoke // !!! INSERT CALLS TO LOCAL SERVICES !!! //>
<invoke partnerLink="MS_Provider" portType="Municipality_LWfM"
operation="sendProcessedAS" inputVariable="input_MU"
outputVariable="output_MU" name="sendProcessedAS"/>
<invoke // !!! INSERT CALLS TO LOCAL SERVICES !!! //>
<invoke name="callbackClient" partnerLink="TS_Provider"
portType="TaxAdvisor_LWfMCallback"
operation="onResult" inputVariable="output"/>
</sequence>
</process>
PolicySet {(target=<AnnualStatement>)
PolicySet { target=<outbound>
PolicySet {(target=<processedAS>)
Policy (Aspect = “Confidentiality”) {
Rule {
Signature-Algorithm = “RSA-SHA1”,
Node1 = “/self/annualIncome”,
Node2 = “/self/clientID”,
Recipient = “Municipality”} }
Policy (Aspect = “Integrity”) {
Rule {
Signature-Algorithm = “RSA-SHA1”,
Node1 = “/self/”,
Recipient = “Municipality”}
}
PolicySet { target=<inbound>
PolicySet {(target=<processedAS>)
Policy (Aspect = “Qualified Sign”) {
Rule {
Signature-Algorithm = “RSA-SHA1”,
Node1 = “/self/”,
Source = “Municipality”
Signatories = 2}
}}}}
(a) (b)
Fig. 3. BPEL File (a) and Security File (b) for Role TaxAdvisor.
Security Components. The second part generates the configuration files for the
security components in the architecture (Fig. 3b). The security requirements in the
constraint box in GWfM (Fig. 2) are translated into an XACML file stored in the
Policy-Repository (7) and loaded into the PCE (5) at runtime in order to determine the
compliance of inbound messages and to identify security mechanisms to be applied to
outbound messages. Figure 4b) shows how the security requirements are translated
into a configuration file for the role
TaxAdvisor. Figure 4 shows the dependency
between the security requirements in the GWfM and the Document-Model of the
Interface View.
54
4.2 Platform Independent Model and Reference Architecture
Figure 6 shows how the security requirement – namely that the
Notification has to
be signed twice - is represented at PIM-level (once by the
LocalRole SeniorClerk
and once by a
ClericalAssistant). The requirement Qualified Signature in the
Document Model is translated into a corresponding entry into the XACML policy file
(Figure 3b) and is implemented through an additional component in the Reference
Architecture. In case of an appropriate requirement for an outbound message, the PEP
buffers the message, identifies, notifies authenticates the signatory and lets him sign
the message via an applet popping up in his work-place.
<<SecurityRequirement>>
context notification : Notification:
QualifiedSignature =
{
signatory.size() = 2,
Municipality.SeniorClerk,
Municipality.ClericalAssistant
}
«soapBody»
Notification
«dataType»
ResponseComment
1
1
«dataType»
ClerkID
1
1
«dataType»
ClientID
1
1
«documentType»
Notification
1
1
Fig. 6. Document Model “Notification” with Security Requirement.
4.3 Conclusion
S
ECTET implements a comprehensive approach for the model-driven realization and
management of inter-organizational workflows. Future work has to be done in several
directions. The set of supported security requirements has to be extended (e.g., rights
delegation). Additionally, we are currently implementing a testing environment and
working out requirements for efficient change management of inter-organizational
workflows. Positive results in pilot applications with industrial partners encourage us
to further steps.
References
1. W.M.P. van der Aalst.: Loosely Coupled Inter-organizational Workflows. In: Information
and Management 37 (2000) 2, pp. 67-75.
2. D. Basin, J. Doser, T. Lodderstedt: Model Driven Security for Process-Oriented Systems.
In 8th ACM Symposium on Access Control Models and Technologies. ACM Press, 2003.
3. IBM and Microsoft. 2002: Security in a Web Services World. A joint security whitepaper
from IBM Corporation and Microsoft Corporation. April 2002, Version 1.0.
4. Austrian Signature Act (Signaturgesetz - SigG), Art. 1 of the Act published in the Austrian
Federal Law Gazette, part I, Nr. 190/1999.
5. M. Hafner et al.: Model Driven Security for Inter-Org. Workflows in E-Gov. To Appear in:
A. Mitrakas et al. (Eds.) : Secure E-Government Web Services. Idea Group, Inc, 2006.
6. R. Breu et al. : Web Service Engineering - Advancing a New Software Engineering
Discipline. In: D. Lowe, M. Gaedke (Eds.): Web Engineering, ICWE 2005, Sydney,
Australia, July 2005, Proc. LNCS 3579 Springer 2005, ISBN 3-540-27996-2.
56
7. M. Hafner et al.: Modeling Inter-org. Workflow Security in a Peer-to-Peer Environment. In:
R. Bilof (Ed.): Proc. of the 2005 IEEE International Conference on Web Services, ICWS
2005, Orlando, USA, 2005, IEEE Conference Publishing Services, ISBN 0-7695-2409-5.
8. T. Andrews et al.: Business Process Execution Language for Web Services, Version 1.1. ,
BEA, IBM, Microsoft, SAP, Siebel (2003).
9. OASIS: ebXML Business Process Specification Schema Version 1.01. OASIS, 2001.
10. M. Bernauer et al., “Comparing WSDL-based and ebXML-based Approaches for B2B
Protocol Specification”. In: Proc. of the 1st Int. Conf. on Service-Oriented Computing
(ICSOC), Trento, 2003.
11. A. Arkin: Business Process Modeling Language - BPML1.0, Working Draft, 2002.
12. N. Mitra, N.: SOAP Version 1.2 Part 1: Messaging Framework. W3C Rec. 24/06/2003.
13. Eastlake, D. et al., (eds.): XML-Signature Syntax and Processing. W3C Rec. 14/02/2002
14. Eastlake, D. et al. (eds.): XML Encryption Syntax and Processing. W3C Rec. 10/12/2002.
15. T. Moses et al. (eds.): XACML Profile for Web-Services. XACML Working draft, v.
4/09/2003.
16. P. Mishra et al. (eds.): Conformance Requirements for the OASIS Security Assertion
Markup Language (SAML) V2.0. Committee Draft 02, 24/09/2004.
17. S. Bajaj, et al., :Web Services Policy Framework (WS-Policy). 09/2004.
18. E. Bertino, S. Castano, E. Ferrari: Securing XML Documents with Author X. In: IEEE
Internet Computing 5 (2001) 3, pp. 21-31.
19. D. W. Chadwick: RBAC Policies in XML for X.509 Based Privilege Management. In:
Proc. of the 17th Int. Conf. on Information Security: Visions and Perspectives 2002
20. http://www.eu-trustcom.com/
21. P. Grefen et al.: CrossFlow: Cross-org. Workflow Man. in Dynamic Virtual Enterprises. In:
Int. Journal of Computer Systems Science & Engineering 15 (2000) 5, pp. 277-290.
22. F. Casati and M. Shan: Event-based Interaction Management for Composite E-Services in
eFlow. In: Information Systems Frontiers 4 (2002) 1, pp. 19-31.
23. M. Dijkman, M. Dumas: Service-Oriented Design: A Multi-Viewpoint Approach. Int.
Journal of Cooperative Information Systems 13(4): 337-368 (2004).
24. E. Gudes, M. Olivier, R. van de Riet.: Modelling, Specifying and Implementing Workflow
Security in Cyberspace. In: Journal of Computer Security 7 (1999) 4, pp. 287-315.
25. W.K. Huang, V. Atluri: SecureFlow: A secure Web-enabled Workflow Management
System. In: ACM Workshop on Role-Based Access Control 1999, p. 83-94.
26. J. Wainer et al.: W-RBAC – A Workflow Security Model Incorporating Controlled
Overriding of Constraints. In: International Journal of Cooperative Information Systems. 12
(2003) 4, pp. 455-485.
27. M. Alam et al.: Model Driven Security for Web Services. In: Proc. of the 8th International
Multi-topic Conference (INMIC 2004), IEEE, Lahore, 2004.
28. http://www.oracle.com/technology/products/ias/bpel/index.html
29. J. Mendling, M. Hafner: From Inter-Organizational Workflows to Process Execution:
Generating BPEL from WS-CDL. In conf. and workshop proc. MIOS 2005 . R. Meersmann
et al. (Eds.): LNCS 3762, pp. 305-315, 2005.
30. K. Mantell: From UML to BPEL. IBM-developerWorks, 2003.
57
