Model Quality in the Context of
Model-Driven Development
Ida Solheim and Tor Neple
SINTEF ICT, P.O. Box 124 Blindern, N-0314 Oslo, Norway
Abstract. Model-Driven Development (MDD) poses new quality requirements
to models. This paper presents these requirements by specializing a generic
framework for model quality. Of particular interest are transformability and
maintainability, two main quality criteria for models to be used in MDD. These
two are decomposed into quality criteria that can be measured and evaluated.
Another pertinent discussion item is the positive implication of MDD-related
tools, both on the models in particular and on the success of the MDD process.
1 Introduction
1.1 Characteristics of Model-Driven Development
Model-driven development (MDD) has been around for some years, helping system
engineers to analyze and document the systems to be created and maintained, and to
generate parts of the program code automatically. In MDD, models are the prime
artefacts. That means, models are in use throughout the whole production chain, from
the early capture of user requirements to the production of executable code. Model
transformations are essential, and these should preferably be automated. Indeed, tool
support is by many considered a prerequisite for successful MDD (e.g. [1]).
Although MDD has been practiced for years, it did not gain ground until the Object
Management Group (OMG) launched its Model-Driven Architecture (MDA™)
initiative. Being “an approach to using models in software development” [2], MDA
has boosted the development of tools and thereby (semi)automation of program
development and maintenance. MDA motivates system development with the
following characteristics:
Many activities have models as input, or output, or both.
Several of these activities are model transformations (while others are model
analysis, model verification etc.).
A transformation takes one or several models as input and produces a model (or
models), or text, as output. During transformation, output models are supplied with
domain-related information not present in the input model. An example of such a
domain is the platform concept, often used for “implementation platform”.
Solheim I. and Neple T. (2006).
Model Quality in the Context of Model-Driven Development.
In Proceedings of the 2nd International Workshop on Model-Driven Enterprise Information Systems, pages 27-35
DOI: 10.5220/0002486100270035
1.2 Model Quality – A Less Mentioned Concern
The authors of this paper believe that successful adoption of MDD depends on high-
quality models, high-quality transformations, and high-quality transformation
languages and tools.
While other authors have contributed to the understanding of quality related to
transformations (e.g. [3]) and transformation languages (e.g. [4]), the quality of
models in MDD has so far been a less mentioned concern.
According to Selic [5], accuracy has been the greatest problem for successful
adoption of MDD. Lack of accuracy means imprecise models or modelling languages,
paired with unclear rules for mapping to underlying implementation technologies.
The authors of this paper agree that Selic has a good point. However, in [5] the
term accuracy is used for a collection of several undefined quality criteria. The
purpose of this paper is to define more precise quality criteria for models to be used in
MDD, and suggest how these criteria may be measured and evaluated.
1.3 The Structure of this Paper
The starting point for this work is a generic quality framework (chapter 2), which is
specialized to a quality framework for MDD models and their environments (chapter
3). The implications of tools are discussed in chapter 4, and a conclusive summary is
given in chapter 5.
2 A Generic Quality Framework
Krogstie and Sølvberg [6] presents a generic framework for discussing the quality of
models. This framework will be used as a reference frame for discussing model
quality in an MDD context, and will be refined for this purpose. Figure 1 depicts the
framework’s building blocks and their interrelationships, as described by Krogstie [7].
The explanation of the building blocks is rendered from [7] (mostly quoted):
G, the (normally organizationally motivated) goals of the modelling task
L, the language extension, i.e., the set of all statements that are possible to make
according to the graphemes, vocabulary, and syntax of the modelling languages
M, the externalized model, i.e., the set of all statements in someone’s model of part
of the perceived reality written in a language
Social actor
Goals of
Fig. 1. Krogstie’s generic framework for discussing the quality of models (rendered by courtesy
of the author).
D, the domain, i.e., the set of all statements which can be stated about the situation
at hand. Enterprise domains are socially constructed, and are more or less inter-
subjectively agreed. That the world is socially constructed does not make it any
less important to model that world.
, the relevant explicit knowledge of the set of stakeholders involved in modelling
, the relevant explicit knowledge of the set of stakeholders actively involved in
I, the social actor interpretation, i.e., the set of all statements which the audience
think that an externalized model consists of
T, the technical actor interpretation, i.e., the statements in the model as 'interpreted'
by different model activators (e.g., modelling tools, transformation tools)
The various qualities are expressed as relations between pairs of these building
blocks. The next chapter elaborates on model quality aspects related to MDD, refining
the above framework accordingly.
3 Quality Criteria for MDD Models and their Environments
3.1 Overview
A quality framework specialized with respect to MDD is depicted in Figure 2. The
authors of this paper want to emphasize transformability and maintainability as the
two main quality criteria for models to be used in MDD. Models must have the ability
to be transformed – to other models of greater detail (specialization), and at last to
executable pieces of code for selected technical platforms. Transformability may be
decomposed into:
completeness (semantic quality)
relevance (technical pragmatic quality)
precision (technical pragmatic quality)
well-formedness (syntactic quality)
Also, models for use in MDD need to be maintained during the system’s lifetime. One
of MDD’s strengths is rapid iterations of the development cycle analysis—design—
implementation—test, a feature that supports incremental development strategies.
Given this setting, it is of paramount importance that changes made to the
requirements are rendered correctly in the models and reflected in the code. A means
to keep track of changes is to trace them, from the requirements through the necessary
steps all the way to the code, and back. Therefore, maintainability of models may be
decomposed into:
traceability (technical pragmatic quality)
well-designedness (syntactic quality)
Out of the six quality criteria listed above, only one (completeness) is explicitly
mentioned in Krogstie and Sølvberg [6]. The remaining five may be considered
refinements of generic relations shown in Fig. 1. The transformability and
maintainability criteria are explained in the following subsections.
The environments of MDD models are here defined to be the change traces, the
tools, and the MDD process itself. The change traces and the tools belong to the
technical pragmatic quality.
Goals of
Goals of
Organizational quality:
Semantic quality:
Syntactic quality:
pragmatic quality:
Fig. 2. A specialized framework for model quality in MDD.
Concerning the MDD process as such, we may identify a primary goal of achieving
higher productivity in the development process. Hence,
productivity (organizational quality)
may be considered a quality criterion. In accordance with [6], this is in Fig. 2
expressed as a relation between the goals of modelling (G) and the externalized model
(M). However, for MDD, productivity should rather appear as a quality of M, L, T
and D in combination. Productivity is hard to measure, and results cannot easily be
generalized. The MODELWARE project [8] of the EU IST programme aims at
measuring the productivity of MDD in industrial trials, based on approaches
described in [9].
3.2 Transformability
Completeness is pointed out by Krogstie and Sølvberg [6] as an essential for the
semantic quality of models. Completeness assures that the model contains all
statements that are correct and relevant about the domain, and can be measured by a
percentage as prescribed in [6].
Whereas Krogstie and Sølvberg [op. cit.] consider relevance to be a property of
completeness, the authors of this paper would like to emphasize relevance as a
distinct quality criterion. However, the relevance of a model used in MDD depends on
both the model itself (M) and its transformation as specified by the technical actor
interpretation (T). High relevance means that no more statements are included in the
model than those which are going to be transformed. Relevance can be measured as
the percentage of model elements actually used in a particular transformation. Making
a larger model than necessary has a negative consequence in MDD; one has to drag
along unused model elements (or code), which may complicate documentation, blur
comprehension and hamper maintenance.
Precision reflects the level of detail and accuracy required for a model to be
transformed successfully. The result of the transformation may be another model,
which in case must be well-formed. Or, the result may be program code which can be
compiled without errors and which constitutes some meaningful result, e.g. a
component, a class structure or an interface. It may be possible to measure precision
on a scale (ordinal or interval). However, these authors prefer to evaluate model
precision as yes/no. This means, either the model is sufficiently precise for
transformation, or it is not.
Well-formedness is a syntactic quality of utmost importance to model
transformation. According to OMG [2], a transformation from one model to another is
dependent on a mapping between the two respective metamodels. Hence, any model
to be transformed must comply with its metamodel. For example, a model written in
UML must comply with UML’s metamodel. Also, there may exist sub-languages with
limitations on the vocabulary and/or grammar rules of the overall language. Examples
of such sub-languages are UML profiles. A well-formed model complies not only to
its metamodel, but also to its sub-language (profile) if appropriate. A measure of well-
formedness should yield 100 % before transformation is started.
3.3 Maintainability
3.3.1 Traceability
Traceability has been pointed out as an important aspect of MDD. One of the
purposes of maintaining traces between model elements is to check a model element’s
origin, e.g. in a requirement model, and to follow a model element through
transformations. In the latter case, the trace can also tell what kind of transformation
was used, and which transformation rule was applied. Albeit traceability doubtlessly
may involve more than one model, and indeed may involve artefacts other than
models, this section discusses traceability as a quality of a model. This means, to what
degree the model is usable in a scenario where traceability is needed.
Traceability may be vital for the management of large MDD projects, and for the
maintenance of systems built according to MDD. Tool-supported traceability may
range from “enterprise-wide” traceability solutions to simple traces maintained by the
modelling workbench. A model’s traceability depends on unique identifiers for the
different elements that constitute the model; otherwise no traces can be established.
Unique identifiers are supported by some modelling tools, but not all. In addition to
the identification of model elements, one will need a mechanism that logs and
documents all transitions undergone by each model element. Such a mechanism is
currently under development in the IST project MODELWARE [8].
A traceability metric for a model could be the model’s trace coverage, defined as a
percentage denoting the proportion of traceable model elements relative to the total
number of model elements.
3.3.2 Well-designedness
The maintainability of object-oriented systems has been studied by several authors,
e.g. Briand [10]. The main approach has been various combinations of measurements,
obtained by counting properties of object-oriented structures found in class diagrams.
Marinescu [11] introduced a quality model for object-oriented systems, applying well-
known metrics for the purpose of revealing particular design flaws. Among the design
flaws that can be revealed by his method, are flaws resulting from not using selected
design patterns described by Gamma et al. [12].
Well-designed models are understandable and tidy. In MDD, well-designedness
deserves much attention because the models are the prime artefacts. Maintenance
should preferably start with the models resulting from the last development cycle. If
changes are made directly to the generated code, they should be reflected in the
models as soon as possible to ensure the correspondence between the models and the
code. Bad model design may complicate the code, confuse the developers, ruin the
model-code correspondence and impede the use of MDD.
4 The Implications of Tools
In MDD, tools are used to create models, to transform one model into another, to
generate non-model software artefacts, to maintain traces, etc. In such a setting, the
human model-creation steps can be heavily guided by the tools. This means that
several quality parameters can be kept at sufficient levels through guides and
constraints in the tooling. It is also probable that the modeller will put most work into
those models that will be subject to usage further down the MDD transformation
A modelling tool will typically not allow a model to violate its metamodel. At
least, the model will be compliant with the tool’s interpretation of the metamodel.
This is a feature that has been observed in UML tools in the past, when tool vendors
have added capabilities not compliant to the UML metamodel as defined by the
standard. Such extensions may cause problems in an MDD tool chain if a common
non-standard metamodel, shared between the tools, is required.
A positive feature of some UML modelling tools is a mechanism allowing the user
to check whether a model is compliant with the applied profile. In MDD, this is
essential as most UML model transformations use stereotypes and extra properties in
the transformation process. While the profile provides explicit language constraints,
the tool enforces these constraints on the models. The quality of tool support for
profile adherence is thus shared between the profile itself (how explicit are the
constraints) and the tool (how well are these constraints enforced). In these cases, the
quality of the model at hand is therefore a combination of the quality of the model and
the quality of the applied profile.
Modelling tools can also help ensure that the structure (e.g. package organisation) of a
model is in accordance with the expectations of the down-chain tools. This is
typically done by the use of model templates or more formally defined constraints on
the model structure.
5 Conclusion
Models have been used for years without direct influence on system implementation.
However, the adoption of MDD forces system developers to spend more effort on
making high-quality models. This paper has presented a framework for reasoning
about model quality in the context of MDD. Since (automatic) model transformation
is a crucial activity in MDD, several quality measures depend on both the model and
the transformation (or transformation tool). Such dependency is indicated by the
association line between M and T in Fig. 2. Although measures may be obtained on
an ordinal or ratio scale, some quality criteria need to reach a sufficiently high level –
a threshold – in order for transformations to succeed. The table below gives a
summary of the quality criteria and suggestions of how to measure and evaluate them.
Type of
The model contains all statements that are correct and
relevant about the domain (from [6]). Suggested
measurement unit: percentage.
The model complies with its metamodel, and also with its
specified language profile, if appropriate. Suggested
measurement unit: percentage.
Suggested evaluation: yes/no.
The model is sufficiently accurate and detailed for a
particular automatic transformation.
Suggested evaluation: yes/no.
The model contains only the statements necessary for a
particular transformation. Suggested measurement unit:
The model’s elements can be traced backward to their
origin (requirements), and forward to their result (another
model or program code). Suggested metric: trace
coverage, the proportion of traceable model elements
relative to the total number of model elements.
The model has a tidy design, making it understandable by
humans and transformable to an understandable and tidy
result. Suggested metric: The quality model of Marinescu
[11], preferably extended with other diagrams than class
The use of tools in MDD serves several purposes. In addition to facilitating the
drawing, maintenance and transformation of models, tools also have some built-in
quality controls. It is desirable that the quality controls performed by tools are
extended to support as many as possible of the quality criteria listed above.
Future work will apply the presented quality framework to models used in MDD
projects within industry or public administration. Such trials are expected to give
valuable feedback to the appropriateness and further refinement of the framework.
This work has been conducted in the context of MODELWARE, a project co-funded
by the European Commission under the "Information Society Technologies" Sixth
Framework Programme (2002-2006). Information included in this document reflects
only the author’s views. The European Community is not liable for any use that may
be made of the information contained therein.
1. Alanen, M., et al.: Model Driven Engineering: A Position Paper. 1st International
Workshop on Model-Based Methodologies for Pervasive and Embedded Software,
MOMPES'04 (2004)
2. Object Management Group: MDA Guide. Ver. 1.0.1.
01.pdf (2003).
3. Bézivin, J., et al.: The ATL Transformation-based Model Management Framework. IRIN,
Université de Nantes (2003)
4. Grønmo, R., et al.: Evaluation of the Proposed QVTMerge Language for Model
Transformations. The First International Workshop on Model-Driven Enterprise
Information Systems (MDEIS-2005). Miami (2005)
5. Selic, B., The Pragmatics of Model-Driven Development. In: IEEE Software,
September/October 2003,
6. Krogstie, J. and Sølvberg, A.: Information systems engineering - Conceptual modeling in a
quality perspective. Kompendiumforlaget. Trondheim, Norway (2003)
7. Krogstie, J. (2003). Evaluating UML Using a Generic Quality Framework. In: Favre, L.
(ed.): UML and the Unified Process. IRM Press 1-22.
8. IST Project 511731 (2004-2006). MODELWARE. Modeling solution for software systems,
9. MODELWARE: MDD Business Metrics (in prep.). Sixth Framework programme (2006)
10. Briand, L., Daly, J., and Wüst, J.: A Unified Framework for Coupling Measurement in
Object-Oriented Systems. In: IEEE Transactions on Software Engineering, Vol. 25(1), No.
January/February, 1999
11. Marinescu, R.: Measurement and Quality in Object-Oriented Design. University of
Timisoara (2002)
12. Gamma, R., et al.: Design Patterns: Elements of Reusable Object-Oriented Software.
Addison-Wesley (1994)
