WEWORM: AN ETHICAL WORM GENERATION TOOLKIT

Mark Wallis and Frans A. Henskens

School of Electrical Engineering and Computer Science, University of Newcastle, Newcastle, N.S.W, Australia

Keywords: Worm, Virus, Ethical, Toolkit, Cleanup, Infection.

Abstract: One of the largest threats to network security in Internet-connected corporate networks is attack via worms.

Worms infiltrate the network and compromise security, consuming processor cycles and network bandwidth

that would otherwise be available for corporate use. This research analyses a particular strain of network

worm called the “Ethical worm”, which is targeted towards beneficial means rather than malicious. Also

presented is a design for an Ethical worm generation toolkit (named WEWorm) that will aid System

administrators in the cleanup of an infected network.

1 INTRODUCTION

One of the largest threats to network security in

Internet-connected corporate networks is attack via

viruses and worms. While viruses are a continuing

concern in the industry it is worms that are posing

the greatest threat. Worms infiltrate the network and

compromise security, consuming processing cycles

and network bandwidth that would otherwise be

available for corporate use. Additionally, they may

disable or alter the operation of resources from their

surrounding environment with the intent of

hampering administrative efforts to detect and

remove them. In a large corporate network that

spans many distinct physical sites it is normally left

to a single group of network administrators to detect

and resolve worm or virus outbreaks across the

corporation. One of the methods than can be used to

deal with worm outbreaks involves the use of patch

programs. When worms are flooding the

communications links and stealing CPU cycles,

administrators need a method by which such a patch

program can be effectively and automatically

distributed across the network - essentially

mimicking the way that worm traffic can spread

throughout the corporation. A patch program

deployed in this way is called an Ethical worm.

This paper presents WEWorm, the outcome of a

project that involved the design and development of

prototype tools that allow the security team of an

organisation to build and deploy Ethical worms.

Such worms are able to move from machine to

machine, curing any Malicious worm infections

before propagating to other hosts. WEWorms have

the ability to move between hosts using minimal

resources as well as the ability to disguise

themselves to avoid detection by sentient worms that

are designed to be self-preserving.

2 PROBLEM DESCRIPTION

In 2001 the CodeRed worm was analysed and found

to have infected more than 359,000 servers in less

than 14 hours, with a peak infection rate of 2,000

new hosts every minute (CAIDA 2006).

In 2003 the Sapphire/Slammer worm had managed

to spread itself worldwide in less than 10 minutes –

making it the fastest spreading worm to date

(CAIDA 2006).

In 2004 at the time of the W32/Mydoom.A worm

infection it is estimated that one in 12 emails on the

Internet were infected with the MyDoom virus

(SecurityStats undated).

The statistics above give an insight into one of the

largest security concerns that exists on the Internet

today. Malicious programmers are developing

worms and viruses that can spread and contaminate

at alarming rates. Security administrators do not

have the time and resources to be able to act upon

the results of existing detection and notification

systems before their network becomes compromised

with each latest viral outbreak.

Wallis M. and A. Henskens F. (2007).

WEWORM: AN ETHICAL WORM GENERATION TOOLKIT.

In Proceedings of the Third International Conference on Web Information Systems and Technologies - Internet Technology, pages 55-63

DOI: 10.5220/0001275500550063

 SciTePress

Much research is currently active in the area of

detection and automatic-response for computer virus

and worm infections (C.C Zou 2003; S. Sidiroglou

2003). Unfortunately the skills of the worm

developers are now at a level where the efforts of the

network administrators are focused more on

cleaning up network infections, than preventing

them. No longer can it be assumed that strong

network perimeter defences are enough to protect a

network from infection. Another important issue

involves the problems and restrictions placed on a

network when the administrator is tasked with

cleaning up an infected environment. For example,

the performance of an infected network may well

work against attempts to remove the infection. The

situation becomes even more difficult when the

infection involves malicious software that is actively

trying to ensure its own survival. Such Malicious

software may be capable of disabling local host

virus protection and other secondary systems that

remote administrators use to aid the cleanup process.

A growing number of corporate private networks

contain multiple geographically disparate sites

connected by wide area links. In such situations a

single group of network administrators may well be

tasked with the cleanup of nodes over the diverse

environment. Unfortunately many of the latest

generation of Malicious worms generate so much

network traffic in their attempt to spread that they

flood the communications links that administrators

use to remotely manage distant nodes. The wide area

communication links to distant nodes are of

necessity slower than local links and reduction in

their performance is particularly damaging.

The focus WEWorm is the cleanup of

environment-wide infections in private networks –

such as a network owned by a single corporation, or

a single educational institution.

2.1 Current Opinions

2.1.1 V. Bontchev - “Are ‘Good’ Computer

Viruses still a Bad Idea”

In (Bontchev 1999) the author details the particular

reasons why the greater security community sees

Ethical worms as harmful. Not all points are relevant

to all Ethical worm designs, but it is beneficial to

review them to provide a requirement from which to

build a design.

The reasons are summarised as follows:

1. Lack of control – once an Ethical worm is

released into the wild there is no control mechanism

by which an administrator can remotely choose to

halt its execution.

2. Recognition difficulty – if an Ethical worm

spreads via the same distribution mechanism as a

Malicious worm, existing anti-virus software may

not be able to tell them apart and act negatively

towards the Ethical worm.

3. Resource wasting – an Ethical worm may use

up computer and network resources just as a

Malicious worm can.

4. Compatibility problems – it is impossible to

test every combination of hardware and software in

hosts connected to the Internet – hence an Ethical

worm may hit compatibility problems trying to

execute on any non-standard hosts it infects.

5. Effectiveness – under certain circumstances it

can be found that a non self-replicating piece of

software would perform the same task as an Ethical

worm.

6. Unauthorised access – just like their malicious

counterparts, Ethical worms tend to execute on the

host system without authorisation from the host

owner.

7. Misuse – any sort of system designed for

deploying Ethical worms could also be used to then

also design and deliver Malicious worms

8. Trust – any worm, no matter its intention, is

capable of removing the user’s trust in their

computer system, because the user can no longer

guarantee that they are familiar with every piece of

software executing on their system.

9. Negative Common Meaning – due to the

media spin of the words “virus” and “worm” it is

very hard for normal users to understand the idea of

an Ethical worm whose aim is to do good.

2.1.2 B. Schneier – “Benevolent Worms”

In (Schneier 2003) Schneier claims that Ethical

worms are essentially patch-delivery mechanisms,

and as such should be designed to cover the

following four major characteristics of a good patch-

delivery system:

1. People can choose the patches they want,

2. Installation is adapted to the host it is

executing on,

3. It is easy to stop an installation in progress, or

uninstall the software,

4. It is easy to know what has been installed

where.

WEBIST 2007 - International Conference on Web Information Systems and Technologies

Historically, Ethical worms have addressed none

of the above items – and hence their effectiveness in

solving the worm problem has come under scrutiny.

3 WEWORM PROJECT

As can be seen from the above reviews, the Ethical

worm concept is not strongly supported. Initially it

was intended that WEWorm would be used to clean

up worms in Internets spanning multiple private

networks. In the light of current commentary, it was

decided, instead, to focus on a particular restriction

to the scope of this original intention. This allows

the design to address the majority of the issues

identified by previous research, and to develop a

scalable solution to the problem of the repair and

clean up of infected hosts.

To date all the reported Ethical worms have been

developed in a way that ensured they spread across

as many hosts and networks as possible – just like

the Malicious worm they were trying to remove. The

WEWorm design presented in this paper aims to

target small networks of hosts controlled as a single

group. This provides a solution for use by large

corporations and organizations for which a priority

is the removal of worms from their own internal

networks, rather than the removal of a worm from

all hosts on the Internet.

This restriction introduces new issues that need

to be addressed – namely how an administrator can

control a worm to guarantee it will not spread

outside of the network into which it was introduced

to protect.

3.1 Effect of Domain Restriction

This section reviews the criticisms raised in

(Bontchev 1999) and discusses the restriction of the

problem domain to private networks.

Lack of control

: Due to the restricted scope of

the problem domain described above, any control

mechanism will be much more effective. This is

because the Ethical worm no longer has to

communicate with active instances over the global

Internet. A control mechanism based on a modular

framework was developed. This framework provides

an effective mechanism for passing control

messages between the active Ethical worm

instances, and provides a level of active control over

the system.

Recognition difficulty

: Limiting the scope of

Ethical worms to a single network makes it possible

to create a unique propagation method for it. This

allows the worm to spread through the network

using a sanctioned propagation technique that is

unique to Ethical worms in this environment.

Combined with various encryption signatures

described later in the paper, this provides an

excellent method of distinguishing sanctioned

Ethical worms from Malicious worm infections.

Resource Wastage

: Problem domain restriction

negates the issue of resource wasting by Ethical

worms. If an Ethical worm is sanctioned and

deployed by a network administrator in a single

network entity then any resources used by that

Ethical worm will be well known and accepted

before deployment. It will be shown that the

WEWorm toolkit can be used to provide estimates

of resource usage to the Ethical worm designer to

help him/her understand the resources required to

deploy the self-propagating code on their network.

Compatibility Problems

: Deploying an Ethical

worm into a single well-defined network entity gives

the worm designer the ability to tailor the worm to

specific subsets of infected nodes. Compatibility

problems can be mitigated in networks where a

standard SOE (Standard Operating Environment)

deployment is used on all machines. The toolkit

design will show how an Ethical worm can be

designed and then test-deployed on a standard SOE

with a view to allowing network administrators to

complete a full test cycle before the work is released

into the network.

Effectiveness

: While the problem domain

restriction does not specifically address the issue of

effectiveness, a comparison will be made between

the restricted technique and other mainstream patch-

delivery systems that can be used to solve similar

problems.

Unauthorised access

: Using WEWorm, the only

person who will be able to deploy an Ethical worm

will be the system administrator responsible for the

network. Focusing on single-entity networks negates

the issue of ownership of the systems. If the single

entity network actually contains public clients (i.e. a

university network that contains student-owned

machines) then the users may be made aware of the

possible deployment of Ethical worms in the terms

and conditions of use of the network.

Misuse

: WEWorm addresses the issue of misuse

by ensuring that any worm developed using the

toolkit is designed in such a fashion that can only

propagate to nodes that trust the signature of the

worm’s author. This ensures that the design cannot

be directly reused for malicious intent without

further alteration to remove safeguards.

WEWORM: AN ETHICAL WORM GENERATION TOOLKIT

Trust: As with the issue of unauthorised access,

only Ethical worms designed by the network

administrator can propagate to nodes in the network

deploying the presented design. This ensures that the

end user’s trust in their workstation is maintained

and is not compromised any more than by other

automatic patch delivery mechanisms.

Negative Common Meaning

: By restricting the

problem to single-entity networks it can be ensured

that appropriate training and documentation can be

developed and circulated among users and staff. The

purpose is so they are aware that the Ethical worm

deployment is a trusted design by their

administrative staff, and should be trusted despite

the negative connotations of the name.

3.2 Design Goals

The following major design goals were identified for

the WEWorm project. These goals also include a

subset from (Schneier 2003), in which the author

describes a minimum set of requirements that any

patch deployment system has to exhibit to be trusted

and effective.

Identification of infection

: The system must be

designed in such a way that it can be further

integrated directly into a larger Intrusion Detection

system. This would allow IDS alerts to

automatically trigger Ethical worm actions and

deployment.

Responding to infection

: External intrusion

detection systems must be able to communicate with

the Ethical worm system to allow automatic

deployment of Ethical worms from an existing

library. The IDS would be able to store a link

between a certain signature and its related Ethical

worm to automatically combat infection.

System Security

: The Ethical worm system must

be secure from abuse by Malicious entities. This

security must protect the system from being reused

for the distribution and development of Malicious

worms while also providing security of the overall

environment.

Patch choice

: Users should be able to choose

which patches are deployed on their system. The

restricted implementation domain allows the

network administrator to decide which Ethical

worms will be deployed into the network. While the

end-user will continue to have no choice, in such

environments security is not their responsibility and

hence the trust and decision is placed on the network

administrator to choose the appropriate patches to be

deployed to each system.

Adaptive Installation

: Each patch should be

adaptive to the host on which it is being deployed. It

will be shown that the presented modular WEWorm

design allows the administrator to develop Ethical

worms that act differently depending on the host on

which they are executing. This will give added

power, allowing the Ethical worm to work across

multiple installations and architectures as required.

Installation Interruption

: A patch system must be

interruptible, even when it is halfway through a

patch installation. It will be shown that the control

methods in the WEWorm design allow the user to

control and stop the further propagation of an

Ethical worm in the network. Simulation and testing

demonstrate that the system does this effectively.

Installation Reporting

: The WEWorm system

implements a monitoring and reporting mechanism

that satisfies the requirement that any patch

management system must be able to report on what

patches have been installed, and where in the

network. Similarly to some of the historical Ethical

worms described previously, the design allows the

user to log the worm’s actions both on the host itself

and to a centralised database. These logs record

when a particular host executes an Ethical worm,

after the network administrators have deployed it.

3.3 Design of WeWorm

WEWorm implements an Ethical worm system

targeted at the cleanup of Malicious worm infections

in a single network entity. The above design

considerations were used to define the system

requirements, and the above criteria were used to

create a design that addresses the documented

concerns about the Ethical worm concept, while also

meeting all the specified design goals. The overall

design was based on a toolkit concept that allows a

network administrator to rapidly design, build and

deploy an Ethical worm into a network environment.

The developed Ethical worm is supported by a pre-

established runtime environment.

3.3.1 Toolkit Concept

The modular design of an Ethical worm is well

suited to the use of a component based architecture

that allows rapid, piece-by-piece building of a

solution. The toolkit is constructed using two groups

of components – common and targeted. Some

components form part of the worm itself and some

execute on the target hosts as part of the

environment that supports the Ethical worms. This

component architecture also allows corporations to

WEBIST 2007 - International Conference on Web Information Systems and Technologies

share components between each other to remove a

worm infection on a more global scale.

Components are classified as follows based on

their role in the Ethical worm system.

3.3.2 Common Components Groups

Common components are those that are shared

between, and required for, the operation of all

Ethical worms. These components comprise the core

of the payload and interact with the runtime

environment to provide end-to-end connectivity for

the system. Common components are of two kinds.

The first kind is packaged as part of each WEWorm

instance and is used when the worm is being

executed in the runtime environment. The second

kind is packaged as part of the environment itself as

is used in handling the processing of each new

WEWorm instance, as it is executed within the

environment.

The common components that are packaged with

WEWorm instances are the:

• Propagation Component

• Outgoing Security Component

• Outgoing Network Component

• Reporting Component

• Control Component

The common components that are packaged with

the runtime environment include:

• Incoming Security Component

• Incoming Network Component

WEWorm instances also include targeted

components that are tailored to deal with the

Malicious worm for which they are designed.

3.3.3 Targeted Components

Targeted components deal with specific Malicious

worm attacks and generally need to be modified or

created specifically for each Ethical worm that is

deployed. The main targeted component is the

Executable component.

3.3.4 System Walkthrough

The following section describes the process

followed to create and deploy an Ethical worm. It

demonstrates the steps that a Network Administrator

takes to use the WEWorm system to cleanse an

infection in a local network.

1. Network administrator receives an alert

from their IDS system that an infection has occurred.

2. Network administrator uses this IDS

information to ascertain the nature of the infection.

3. Network administrator designs the

requirements for the Ethical worm based on the IDS

information.

4. Network administrator builds the

WEWorm payload using the pluggable modules. If

required a targeted executable component is

developed to address a specific instance of

Malicious worm.

5. Network administrator manually loads the

payload into a host in the network and executes it.

6. Normal execution flow for the payload

begins:

6.1 The Incoming Network component in the

node’s environment receives the payload.

6.2 The Incoming Security component in the

node’s environment authenticates the

payload.

6.3 Control Component executes to ensure

there are no administrative commands

waiting to be actioned.

6.4 Executable component of the payload

executes a single command.

6.5 If more commands exist then repeat

through Control and Executable tasks

until all commands have been executed.

6.6 Reporting component executes.

6.7 Propagation component executes and if

further propagation is required then:

I. payload for propagation is created

II. outgoing Network component

delivers the payload to the next node.

3.4 Component Development

The targeted component development follows the

previously described toolkit methodology. The task

of cleaning up a Malicious worm infection can be

seen as a series of common steps with varying

parameters. Implementing a subset of these

commands allows for rapid development of the

actual Ethical payload as well as the surrounding

support infrastructure.

The following are examples of modular

commands that can be implemented using

WEWorm. They are a subset of the commands used

by real-world viral removal instructions.

• Kill process

• Remove registry parameter

• Delete file

• Reboot host

• Download file via TFTP

• Execute file

WEWORM: AN ETHICAL WORM GENERATION TOOLKIT

For example, to remove a Blaster infection the

following payload commands would be sequenced

together

• Download the Microsoft patch from a TFTP

server

• Execute the Microsoft patch

• Kill msblast.exe process

• Delete msblast.exe file from System32 folder

• Delete registry key HKLM\Software\

Microsoft\Windows\CurrentVersion\Run, value

windows auto update

3.5 Delivery Mechanism

Design of WEWorm included analysis into the best

network delivery mechanism that could be used for

propagating Ethical worm payloads between nodes

in a network environment. The delivery mechanism

has to satisfy specific requirements to be acceptable

for use in hostile and congested networks. These

requirements include

• High levels of efficiency,

• Small packet sizes, and

• Focus on local domains.

High levels of efficiency and small packet sizes

are requirements that specifically address the

problem if communication in a network that is

congested with Malicious worm traffic.

Taking these requirements into account the

following network protocol was specified to handle

inter-node communication:

IP Protocol: UDP

Source Port: dynamic

Destination Port: 55

Addressing Method: 1:m Broadcasting

Packet Payload: dynamic packet length

based on tuning parameters suited towards a

specific network outbreak.

UDP was chosen as the transport protocol due to

its lightweight implementation and ability to pass

data without the added network bandwidth

requirements of hand shaking. The initiating node

dynamically chooses the source port. The destination

port is deliberately chosen to be less than 1024, thus

ensuring that only privileged processes can bind to

that port. The addressing method chosen is a one-to-

many broadcast, which as described earlier allows a

single host to propagate to as many other hosts in the

same broadcast domain as possible. In a perfect

network, every host in the domain should receive a

one-to-many broadcast payload. However, in the

presence of malicious infections, it is possible that

this is not always the case, and hence multiple stages

of propagation are supported in a fashion that

models the spread of Malicious worms themselves.

The broadcast delivery mechanism also ensures that

the design is focused on local domains as per the

project scope definition (noting that IP only supports

intra-network broadcast).

The use of a broadcast delivery mechanism

introduces the constraint that an Ethical worm can

never propagate to a node outside of the current

broadcast domain. This acts as a safe guard, but also

introduces issues with large corporate networks that

span multiple broadcast domains. These issues are

solved using repeater nodes that essentially tunnel

the broadcast traffic between domains.

The use of a custom UDP packet design also

allows the user of WEWorm technology to choose

how to structure packets so they are able to traverse

a malicious network. A trade off may be required

between the size of packets and the number of

packets it can take to deliver a payload. The more

packets required to propagate a payload the more

CPU power is required on the end nodes to

authenticate and rebuild the final payload

deliverable. Increases in the number of packets also

means that each packet is smaller and more likely to

be able to move through congested networks than

large fragmented packets. This trade off is a

configurable option of the outgoing delivery

component.

3.6 Delivery Security

Security is paramount in the environment, thus

ensuring that only trusted sources are able to

disseminate Ethical worms. Special caution needs to

be taken to ensure the deployment environment

cannot be used for malicious means. The WEWorm

design relies on signing and encryption methods that

are optional components of deployed Ethical worms.

A trade-off is available to be made by the network

administrator for security versus efficiency.

A high security option is available that encrypts

each outgoing packet prior to processing by the

delivery component. This encryption ensures that

not only is the payload data protected from sniffing

attacks while in transit over the network, but also

that payloads encrypted with the trusted key are the

only ones that can be executed on each node. The

encryption is based on public/private key encryption

with each node in the system having a list of

acceptable public keys from which to accept

payloads.

IP Protocol: UDP

Source Port: dynamic

Destination Port: 55

Addressing Method: 1:m Broadcasting

Packet Payload: dynamic packet length

based on tuning parameters suited towards

a specific network outbreak.

WEBIST 2007 - International Conference on Web Information Systems and Technologies

The medium security option implements a

security component that does not encrypt, but signs

each packet prior to processing. This allows the

receiving node to validate that the payload has come

from a trusted source but will not protect the payload

itself from being viewed by malicious entities on the

network.

The low security option sends packets in raw

form, without any encryption or validation

mechanism.

4 WEWORM PROTOTYPE

A prototype of WEWorm has been implemented.

This prototype provides the key functionality

required to develop and deploy an Ethical worm that

is targeted at cleaning up a Malicious worm

infection. The following design choices were made

for this prototype.

Choice of Runtime

: A user-mode software

runtime solution was chosen due to the high levels

of rapid prototyping afforded by such an

environment. While a user-mode software solution is

not the most secure option due to its susceptibility to

local malicious code attacks, it does provide the

greatest flexibility when it comes to interacting with

the underlying operating system of the node in order

to remove an infection.

Choice of Language

: Java was chosen as the

development language for the prototype. This is

largely due to the fact that the Java Virtual Machine

(JVM) (T. Lindhalm) essentially mimics the user-

mode software runtime environment specified in the

initial design. Each node in the network executes a

JVM instance which provides the environment in

which the Ethical payload will execute.

Choice of Environment

: The prototype was

developed in a small-scale real network environment

consisting of three servers executing multiple virtual

machines. This created a virtual network of 15

infected hosts configurable in various network

deployments – including a large single broadcast

domain and two separate broadcast domains

separated by a router and VPN.

Runtime Environment Overview

: The runtime

environment was implemented as an application

running under a JVM on each node in the network.

This application executes code that listens for all

incoming packets on the specified UDP port. Once a

data packet is received the runtime environment uses

streamlined pipeline architecture to process the

Ethical worm payload. Each component in the

process is deployed as part of a library of features in

the runtime environment. If any of the components

required to execute a payload are not available then

the complete payload is rejected for execution.

Manual control of the runtime environment is

available using a subset of command line tools that

allow the administrator to perform tasks such as

manually executing a payload and reporting the

current environment’s status.

The JVM design was chosen to give a high level

of support for deploying WEWorm Ethical worms

into a heterogenous environment. Creation of a

specific Virtual Machine for WEWorm deployment

was outside the scope of a prototype, and

additionally was unnecessary due to the superset of

the required functionality that the JVM is able to

provide

4.1 Testing and Simulation

Testing of the prototype was broken into two main

categories – live testing and simulation.

Live testing was completed using real hardware

executing multiple virtual hosts to mimic a small

corporate network. A Cisco router was introduced to

allow testing of the prototype across multiple

broadcast domains. The tests involved infecting all

hosts in the network with a “captured” Malicious

worm and then deploying an Ethical worm, built

with the toolkit, to remove the infection. The Ethical

worms used for testing were built with reporting

components that allowed a central host to track the

Ethical worm in various network scenarios.

Scenarios were chosen to simulate differing levels of

network usage and domain structure.

The following live tests were completed:

1. Blaster infection across 15 hosts in a

single broadcast domain. Network usage levels

normal.

2. Blaster infection across 15 hosts in a

single broadcast domain. Network flooding

enabled to create high packet loss.

3. Blaster infection across 15 hosts in two

broadcast domains with a pair of repeater nodes

used to replicate the deployment. Network

usage levels normal.

4. Blaster infection across 15 hosts in two

broadcast domains with a pair of repeater nodes

used to replicate the deployment.

Network flooding, enabled between the

broadcast domains, was used to create high packet

loss.

After the live test results were gathered the data

was used to extrapolate results for larger networks

using a network simulation package. The ns-2

WEWORM: AN ETHICAL WORM GENERATION TOOLKIT

network simulator (ISI) package was used to create

large but basic scenarios in order to test propagation

between large numbers of nodes in single broadcast

domains.

The anti-Blaster Ethical worm developed for this

testing was created from the following components

• Propagation Component = broadcast run-once

with delay.

• Security Component = message signing, no

encryption.

• Network Component = 1:m broadcasting.

• Reporting Component = centralised HTTP

POST report.

• Control Component = centralised HTTP GET

control.

4.2 Test Results and Review

The following results were gathered on the test

scenarios described above. All tests were executed

using the standard packet strategy of large packet

size with no fragmentation. The resulting packet size

of the payload was 5.1 kb’s.

Table 1: Test results with large packet size.

Test

Type

Node

Domai

Packet

Loss

Total

time

Nodes

per

sec

Real 15 1 None 6 secs 2.5

Real 15 1 75%

secs

0.44

Real 15

(routed

)

None 8 secs 1.88

Real 15

(routed

)

75%

secs

0.24

Simu

lated

50 1 None

~ 25

secs

Simu

lated

100 1 None

~ 50

secs

Simu

lated

1000 1 None

~ 500

secs

The real prototype environment was rebalanced

to use smaller packets for payload delivery. The

packets were reduced to 1 kb so it took 6 packets in

total to deliver the WEWorm. The following results

were obtained:

Table 2: Test

results with small packet size.

Test

Type

Nod

Dom

ains

Packet

Loss

Overal

l Time

Nodes

per

Second

Real 15 1 None 14

secs

1.07

Real 15 1 75% 31

secs

0.48

Real 15 2

(route

None 19

secs

0.79

Real 15 2

(route

75% 54

secs

0.28

5 CONCLUSION

The community does not currently embrace the

concept of the Ethical worm. This research has

shown that, with appropriate domain restriction and

design, the concept has a place in modern network

security.

Testing results, both real and simulated, have

shown that Ethical worms provide the ability to

quickly clean up malicious infections, and that they

provide environmental scalability.

The design has met all of the major original

requirements set out in (Bontchev 1999). In review

• Lack of control – resolved using control

modules and direct interaction with the runtime

environment on the host

• Recognition difficulty – resolved by looking for

an authorised signature that verifies the worm

payload as authentic

• Resource wasting – resolved using a very light-

weight UDP based protocol and streamlined

execution pipeline

• Compatibility problems – resolved by domain

restriction

• Effectiveness – addressed by inherent worm

design that can handle largely unstable networks

• Unauthorised access – resolved by domain

restriction

• Misuse – resolved using payload signing and

encryption to ensure nodes only execute authentic

payload’s

• Trust – resolved by domain restriction

The initial design goals have also been met as

follows:

• Identification of infection – resolved by the

creation of an integration point for IDS systems to

design WEWorms.

WEBIST 2007 - International Conference on Web Information Systems and Technologies

• Responding to infection – resolved by the

creation of an integration point for IDS systems to

generate WEWorms.

• System security – resolved by the Security

modules that handle the encryption and network

delivery of WEWorms.

• Patch choice – resolved by allowing the

Network Administrator to use a 1:1 delivery

mechanism to control WEWorm propagation

• Adaptive Installation – resolved by allowing the

Network Administrator to use a 1:1 delivery

mechanism to target WEWorms towards subsets of

hosts.

• Installation Interruption – resolved by

continuous Control module polling during the

WEWorm execution cycle

• Installation Reporting – resolved by the

Reporting module of the WEWorm design.

There is scope for much more work in this field.

The design phase of WEWorm has shown that a

user-mode software solution, while being well suited

for prototyping, is not the most suitable for actual

deployment. Work in pushing the Ethical worm

support into kernel space, or even into a hardware

implementation would greatly improve the systems

resistance to attack.

5.1 Future Work

This research suggests that the following items

warrant further investigation and analysis.

Active Deployment

: Active deployment is a

topic that involves IDS systems automatically

generating and releasing Ethical worms to combat

infection in real time with no interaction required for

the System Administrator. Further development of

WEWorm to integrate deployment of Ethical worms

into existing IDS products would result in a

powerful end-to-end solution.

Provision of a GUI

: At this stage the Ethical

worm payload is described using an XML schema.

Writing of XML is notoriously error-prone, so

automation of generation is desirable. WEWorm has

been designed and implemented to support ultimate

provision of a Graphical User Interface. Such a GUI

would allow network administrators to easily drag-

and-drop components to build up this XML

representation, ready for compilation using the

existing utilities.

Runtime Development

: The current WEWorm

prototype was developed using the user-mode

software runtime concept. It is known that this

approach has security issues related to protection of

the runtime environment itself from malicious

attack. Further development leading to hardware that

implements this runtime environment would

increase security and reduce load on the node

processors. A preliminary design of such hardware

was been completed, as an additional module for

integration into standard network interface cards

(NICs).

REFERENCES

Bontchev, V. (1999). "Are ‘Good’ Computer Viruses Still

a Bad Idea ?" from http://vx.netlux.org/lib/avb02.html.

C.C Zou, L. G., et al. (2003). "Monitoring and Early

Warning for Internet Worms." from http://www-

unix.ecs.umass.edu/~gong/papers/monitoringEarlyWa

rning.pdf.

CAIDA. (2006). "Code-Red Security Analysis." from

http://www.caida.org/analysis/security/code-red/.

CAIDA. (2006). "Sapphire Security Analysis." from

http://www.caida.org/analysis/security/sapphire/.

ISI. "The Network Simulator - ns-2." from

http://www.isi.edu/nsnam/ns/.

S. Sidiroglou, A. K. (2003). "Countering Network Worms

through Automatic Patch Generation." from

http://www.cs.columbia.edu/techreports/cucs-029-

03.pdf.

Schneier, B. (2003). "Benevolent Worms " Crypto-Gram

Newsletter Retrieved Sep 03, from

http://www.schneier.com/crypto-gram-0309.html#8.

SecurityStats. (undated). "Virus Statistics." from

http://www.securitystats.com/virusstats.htm.

T. Lindhalm, F. Y. "The Java Virtual Machine

Specification." from

http://java.sun.com/docs/books/vmspec/2nd-

edition/html/VMSpecTOC.doc.html.

APPENDIX: XML DESCRIPTOR

An example of the XML descriptor used to build a

worm using this toolkit can be found at the link

below:

http://mark.serialmonkey.com/objects/sample_xml.txt

WEWORM: AN ETHICAL WORM GENERATION TOOLKIT
