TUNING SEARCH ENGINE TO FIT XML RETRIEVAL

SCENARIO

Gilles Hubert

IRIT/SIG-EVI, Université Paul Sabatier, 118 route de Narbonne F-31062 Toulouse cedex 9, France

Josiane Mothe

IRIT/SIG-EVI, Université Paul Sabatier, 118 route de Narbonne F-31062 Toulouse cedex 9, France

and ERT34, Institut Universitaire de Formation des Maîtres, 56 avenue de l’URSS, F-31078 Toulouse cedex, France

Kurt Englmeier

LemonLabs GmbH, Ickstattstrasse 16, 80469 Munich, Germany

Keywords: Information Retrieval, XML, configurable engine, retrieval scenarios.

Abstract: XML usage is growing to describe documents and consequently systems to search in XML collections are

necessary. Various proposals of systems intend to handle XML documents. This paper describes an XML

approach based on direct contribution of the components constituting an information need. The search

engine is largely configurable in order to be adapted to different context of search. Beyond being globally

adapted to a collection of documents an important objective is to define a search engine that can be adapted

to different retrieval scenarios and to identify how to adapt it. This paper presents first experiments on

INEX testbeds that show how the engine can be adapted to better respond to different retrieval scenarios.

1 INTRODUCTION

Documents particularly scientific publications are

more and more described using XML language

(Bray et al., 2004). Consequently, systems handling

documents tend to move to XML management.

Thus, in the information retrieval (IR) domain many

systems evolve to exploit the structure of documents

and combine textual search and structural search. IR

systems generally manage whole documents (i.e.

indexing units and retrieval units are whole

documents) even if works on passage retrieval (e.g.

paragraphs, phrases) have been undertaken.

With structured documents, new possibilities of

search are provided to users since different

granularities of elements can be managed. Users can

indicate structural constraints on the elements

constituting the response. These new possibilities

multiply the kinds of search and introduce numerous

retrieval scenarios. In addition to have systems

adapted to XML collections it would be interesting

to have systems adapted and even adaptable to

different retrieval scenarios. Moreover it would be

interesting to know how a system can be adapted to

respond as well as possible to a given retrieval

scenario. In this context, INEX (Fuhr et al., 2003) is

an initiative which aims at providing means for the

evaluation of XML retrieval systems. INEX defines

different retrieval scenarios.

This paper presents a configurable search engine

for XML retrieval that aims at being adapted to

various contexts of search notably different retrieval

scenarios. These possibilities of engine adaptation

have been experimented using INEX testbeds. The

paper is organized as follows. Section 2 summarizes

the principal approaches proposed in the domain of

XML retrieval and situates our search engine.

Section 3 describes the principles of the retrieval

engine. The engine adaptability is introduced in

section 4. Section 5 presents and discusses the

experiments realized within the INEX framework to

study the adaptation capabilities of our search

engine. Section 6 is the conclusions.

228

Hubert G., Mothe J. and Englmeier K. (2007).

TUNING SEARCH ENGINE TO FIT XML RETRIEVAL SCENARIO.

In Proceedings of the Third International Conference on Web Information Systems and Technologies - Internet Technology, pages 228-233

DOI: 10.5220/0001278802280233

 SciTePress

2 RELATED WORK

Many approaches related to XML IR are derived

from works on database query languages introducing

vague correspondence for predicates on content or

structure. For example, XIRQL (Fuhr and

Großjohann, 2004) introduce a ranking principle of

document result based on a probabilistic

computation from weighting of query indexing

terms and document indexing terms. XIRQL also

introduces data types to which can be associated

vague predicates and structural vagueness. Other

works propose structural relaxation of XPath (Clark

and DeRose, 1999) queries such as FlexPath (Amer-

Yahia et al., 2004). The underlying principle is to

built a set of queries where structural constraints are

enlarged and then to mix and reorder the results.

In the IR domain, the vector space model (Salton

et al., 1975) and similarity measures such as cosine

have inspired approaches for XML documents. For

example, (Carmel et al., 2003) propose query

decomposition into XML fragments. Pairs (term,

context) constitute indexing units. A context is an

XPath of an XML element. The cosine measure is

extended to combine context similarity and term

similarity. (Crouch et al., 2003) propose an approach

where a document vector is a set of sub-vectors for

different classes of information. The similarity

between document vectors is a linear combination of

similarities between corresponding sub-vectors.

Language modelling (Ponte and Croft, 1998) has

been also used for XML documents. For example,

(Sigurbjörnsson et al., 2005) propose a multinomial

language model with smoothing using document

indexes at different levels (article, element). A

length normalization of XML elements is proposed

to avoid the bias introduced by smoothing in the

results. A hierarchical language model is also

proposed by (Ogilvie and Callan, 2003) where XML

documents are represented by trees. Each XML node

(tag in the document) is estimated using a linear

interpolation of its content, its children models and

its parent model.

Otherwise, (Piwowarski et al., 2003) use

bayesian networks to describe documents. Scores are

computed recursively through the network from the

biggest root element of the network (corpus) to the

leaves (smallest XML components).

Few approaches deal with adaptation

possibilities. Few have studied their capacities to be

adapted to different search contexts. (Liu et al.,

2004) present an approach permitting a configurable

indexing and ranking for XML information retrieval.

This approach gave significant results with INEX

2003 testbed.

Our approach belongs to vector model

approaches. However, our underlying principle is

directly based on addition of individual

contributions of elements defining a query.

3 SEARCH ENGINE PRINCIPLES

Our objective is to propose a search engine

responding to information needs an end user can

express when handling XML documents.

Information need can be “traditional” regarding the

textual content such as looking for elements dealing

about a list of concepts. It can also be more precise

including XML structure such as looking for

sections dealing about concepts within articles

dealing about other concepts. Like commonly in the

IR domain, the objective is to define a search engine

which permits to respond as well as possible to the

information need expressed by a user without

necessarily satisfying all the indications defining this

need. Our approach is not based on a “usual”

similarity calculus. It is based on a combination of

contributions of query elements and mainly on the

contribution brought by every term constituting the

query. The elements getting the highest scores

constitute the result given to the user in response to

the query. Other works such as (Geva, 2005) arrived

to solutions based on similar guiding principles

however differing from heuristics used, score

propagation, and XML structure handling.

Moreover, the objective is to propose a search

engine that takes into account the elements defining

an information need in an incremental manner and

with a variable strength given to each element. The

search engine is largely configurable to try to

respond to various contexts of retrieval (e.g.

different kinds of collections, different retrieval

scenarios). For example, the engine has been used

for automatic categorization (Augé et al., 2003).

3.1 Scoring Principles

Document indexing is performed automatically at

the element level (i.e. leaf nodes of documents with

textual content) to provide the most possibilities for

scoring principles between documents and queries.

Documents are represented as sets of triplets (id,

term, occ) where id identifies an XML element

(including the document identifier and the XPath

locating the node containing the term in the

document) and occ is the number of occurrences of

the term in the textual content of the node. Term

extraction involves notably stop word removal and

TUNING SEARCH ENGINE TO FIT XML RETRIEVAL SCENARIO

229

optional processes such as stemming. A similar

extraction process is performed on queries.

To define our scoring method, we tried to determine

different characteristics which intervene in the

decision to consider an element as relevant. The

characteristics we identified are the following:

 the importance of a term in the element,

 the term importance to represent the

information need,

 the global query importance in the element.

These characteristics have been modelled and

combined via three factors to define the function that

estimates the relevance of an element as follows:

),(),(),(),( ETpTtgEtfETScore

⋅

⎟

⎠

⎞

⎜

⎝

⎛

⋅=

∑

(1)

Where T is the topic, t

is a term representing the

topic T, and E is an XML element.

Firstly, the function adds the contributions of the

query concepts. This principle allows giving

relevance to elements dealing about either only one

concept or several concepts. The sum promotes

elements containing several concepts. However,

depending on the different chosen functions, dealing

strongly about one concept can be evaluated higher

than dealing lightly about many concepts. Secondly,

the function estimates globally the relevance of an

element according to a query.

For previous works related to automatic

categorisation (Augé et al., 2003) functions f, g, h

were defined. For XML retrieval the functions f, g, h

have been adapted according to the context:

 The function f(t

,E) that measures the

importance of a term in an XML element is

based on the number of occurrences of the

term in the element.

 The function g(t

,E) that measures the

importance of a term in a topic representation

is based on the frequency of the term in the

topic. The frequency is moderated by the

number of XML elements containing the term.

 The function p(T,E) that measures the global

presence of a topic in an XML element is

based on the number of terms describing the

topic and that appear in the XML element.

The scoring function is then defined as follows:

nETScore

),(

⋅

⎟

⎠

⎞

⎜

⎝

⎛

⋅=

∑

f g p

(2)

Where

is the number of occurrences of the term t

in the

element E

i,T

is the frequency of the term t

in the query T

is the number of elements containing the term t

is a real (

> 0.0)

T,E

is the number of common terms between the

topic T and the element E

is the number of distinct terms in the topic T

When

is set to 1.0 the function p has no effect

on the final score. The influence of the function p on

the final score increases with the value of

. Using a

function power intends to clearly distinguish the

elements containing a lot of terms describing the

topic and the elements containing few query terms.

The scoring method is completed by principles

that handle term preferences (indications of term

interest or disinterest), coverage (representation

minimum of the query in the element to select it),

and structural preferences (preferences on content

localization and preferences on structure of target

elements). Since this paper does not focus on these

principles they are not detailed. Details can be found

in (Hubert, 2005).

3.2 Score Propagation

The XML hierarchical structure has to be treated.

The hypothesis on which is based our search engine

is that an element containing a component estimated

as relevant is also relevant. Our approach takes into

account this hypothesis propagating the score of an

element to the elements it composes. The score

propagated to the composed elements can be

decreased applying a reducing factor.

),(),(),(

),(

TEScoreTEScoreTEScore

EofancestorE

EEd

⋅+=

∀

Where

is a real coefficient (0.0≤

≤1.0)

E, E

, and E

are XML elements

d(E

,E) is the distance between E

and E in the path

associated to E (e.g. in the path /article/bdy/s/ss1/p,

d(bdy,p)=3)

d(E

,E) is the distance between the root E

and E in

the path associated to E

This process tends to consider a composed

element less relevant than the element it is

composed of. However, an element composed of

several relevant elements can obtain a score greater

than one of its components. The coefficient

allows

varying the score propagation of an element in its

ancestors from no propagation (

= 0.0) to total

propagation (

= 1.0).

WEBIST 2007 - International Conference on Web Information Systems and Technologies

230

4 ENGINE ADAPTABILITY

The proposed search engine is largely configurable.

In addition to changing the functions f, g, p (cf 3.2)

in the scoring function, the value of numerous

coefficients can be changed providing possibilities

to adapt the search engine. This paper focuses on the

query presence coefficient

(cf. 3.2), and the score

propagation coefficient α (cf. 3.3). These

coefficients can be related to different aspects of

XML retrieval. This tends to permit to adapt the

retrieval process to XML retrieval scenarios that can

be related to different criteria such as:

 Size of target elements: a user may be

interested firstly in short elements or on the

contrary he may prefer bigger elements. The

size of target elements can be influenced

varying the propagation coefficient.

 Query coverage: a user may prefer having few

elements in the results but dealing about a

major part of the query. On the contrary, he

may prefer having a longer list of resulting

elements even dealing about less concepts.

The query coverage is indirectly integrated in

the scoring method. The more concepts appear

in an element the greater is the score. This is

due to the sum of concept contributions and to

the query presence factor.

 Element focus: a user can be more interested

in elements focusing on one concept of the

query than elements dealing lightly about all

the concepts and inversely. The element focus

can vary modifying the propagation.

5 EXPERIMENTS

Participating to INEX in 2004 and 2005 led to a

configuration of our search engine adapted to the

INEX collection characteristics. Since this

configuration globally gave relatively good

evaluation results, it was chosen for additional

studies evaluating the influence of given parameters

on our engine. These additional experiments

intended to estimate the capacity of our search

engine to be adapted to different types of searches.

5.1 The INEX Framework

INEX provides testbeds (collection + topics +

assessments) and evaluation methods for XML

retrieval. The experiments presented are based on

the INEX 2005 testbed. INEX introduces two types

of queries on content only (CO) and mixing content

and structure (CAS). For each type of queries,

different tasks are defined (e.g CO.Thorough,

VVCAS) modelling different retrieval scenarios.

Relevance is defined according to two dimensions:

exhaustivity and specificity. Exhaustivity describes

the extent to which an element discusses the topic.

Specificity describes the extent to which an element

focuses on the topic. INEX 2005 defines different

evaluation metrics: normalized extended cumulative

gain (nxCG), effort-precision (ep), Q and R. Details

on these metrics can be found in (Kazai and Lalmas,

2005). The results presented in this paper are based

on the main overall indicator MAep (Mean Average

ep) of the official system-oriented evaluation based

on the ep measures. Two quantization functions are

defined to model different user preferences. The

strict quantization corresponds to searching only

fully specific and highly exhaustive elements while

the generalised quantization corresponds to having

interest in all relevant elements. Experiments were

done on CO.Thorough and VVCAS subtasks that are

similar tasks on different sets of topics.

5.2 Studied Parameters

The studied parameters in the experiments presented

in this paper are query presence factor and score

propagation. We tried to evaluate the influence of

these parameters regarding the different

quantizations and different tasks that is to say

different retrieval scenarios.

Runs are labelled in order to describe the

configuration of the experiments as follows:

 xpY indicates the value Y of the query

presence coefficient ϕ,

 pr0Z indicates the value 0.Z of the coefficient

α used for score propagation.

5.3 Influence of Propagation

Experiments were done to evaluate the possibility to

better respond to a given retrieval scenario when

varying score propagation. According to the

definition of the scoring principle as presented in

section 3.3, weak propagation supports leaf nodes of

XML documents or nodes near leaves. The first

hypothesis was that in the context of INEX this

corresponds to support highly specific nodes and

leads to obtain better evaluation results for strict

quantization. Increasing propagation includes higher

nodes in the hierarchical structures of XML

documents. The second hypothesis was thus that in

the context of INEX this corresponds to include in

results less specific nodes and leads to obtain worse

evaluation results for strict quantization but better

results for generalized quantization. However, it is

expected that a too strong propagation can

TUNING SEARCH ENGINE TO FIT XML RETRIEVAL SCENARIO

231

deteriorate results for both strict and generalized

quantizations since highly specific elements can

disappear from the results to the profit of less

specific elements. The experiments can show the

threshold from which this occurs.

Table 1: Influence of score propagation without query

presence factor for Thorough task.

Metric : ep/gr (MAep), Task: Thorough

Quantization

Run

strict generalized

pr01xp1

0,038

0,037

pr03xp1 0,031 0,052

pr05xp1 0,017

0,062

pr07xp1 0,011 0,056

pr09xp1 0,008 0,047

Table 2: Influence of score propagation with strong query

presence factor for Thorough task.

Metric : ep/gr (MAep), Task: Thorough

Quantization

Run

strict generalized

pr01xp1000

0,033

0,047

pr03xp1000 0,031 0,059

pr05xp1000 0,028 0,066

pr07xp1000 0,023

0,067

pr09xp1000 0,016 0,063

The results confirm that increasing score

propagation deteriorates the results for strict

quantization whatever the query presence factor. For

generalized quantization, increasing propagation

improves the results before to deteriorate them when

propagation becomes too strong. The best results

seem to be obtained for score propagation between

0.5 and 0.7. Applying significance test (paired t-test)

significant differences exist between runs except

between the runs pr05xp1000 and pr07xp1000 for

generalized quantization.

5.4 Influence of Query Presence

Experiments were also done to evaluate the

possibility to better respond to a given retrieval

scenario when varying query presence factor.

According to the definition of the scoring function

as presented in section 3.2, a high query presence

factor supports XML nodes containing several query

terms even if they appear frequently in the

collection. However, nodes containing the most

query terms (i.e. highly exhaustive) remain top

ranked. In the context of INEX this corresponds to

promote partially exhaustive nodes.

For generalized quantization results are expected

to be better with a query presence factor since more

exhaustive nodes are top ranked. However, a too

strong query presence factor can deteriorate results

since it can promote too many partially exhaustive

nodes. For strict quantization, a query presence

factor can compensate the elimination of specific

nodes caused by a too strong score propagation.

With weak score propagation a query presence

factor is not expected to improve evaluation results

since it can promote partially exhaustive nodes

instead of highly exhaustive ones.

Table 3: Influence of query presence factor with

intermediate score propagation for Thorough task.

Metric : ep/gr (MAep), Task: Thorough

Quantization

Run

strict generalized

pr06xp1 0,013 0,060

pr06xp50 0,020

0,069

pr06xp500 0,024 0,068

pr06xp1000 0,024 0,068

pr06xp3000

0,025

0,067

Table 4: Influence of query presence factor with weak

score propagation for Thorough task.

Metric : ep/gr (MAep), Task: Thorough

Quantization

Run

strict generalized

pr01xp1

0,038

0,037

pr01xp50 0,034 0,032

pr01xp500 0,033 0,036

pr01xp100 0,033 0,047

pr01xp3000 0,032

0,048

The results confirm that with score propagation

(Table 3) to increase the query presence factor leads

to better evaluation results for strict quantization.

For generalized quantization a slight query presence

factor leads to better results while continuing to

increase this factor seems to deteriorate the results.

With weak score propagation (Table 4) the

results are better for strict quantization without

query presence factor. On the contrary for

generalized quantization to increase the query

presence factor leads to better evaluation results.

Applying significance test (paired t-test) between

results shows significant differences between runs

except between the runs pr01xp50 and pr01xp500

and between pr06xp50, pr06xp500 and pr06xp1000.

For strict quantization, significance test shows

significant differences only for pr06 runs except

between pr06xp500, pr06xp1000 and pr06xp3000.

WEBIST 2007 - International Conference on Web Information Systems and Technologies

232

5.5 Synthesis

Regarding the results when varying the main

parameters and regarding the different quantizations

modelling different retrieval scenarios, we can

identify how to adapt the search engine to each case.

When searching only XML elements highly

exhaustive and fully specific (i.e. scenario: thorough,

strict) the adapted configuration of the search engine

is with weak score propagation (

= 0.1) and

without query presence factor (

= 1). When

searching all the relevant XML elements (i.e.

scenario: thorough, generalized) the adapted

configuration of the search engine is with

intermediate score propagation (

= 0.6) and with

weak query presence factor (

= 50).

Additional experiments were performed on CAS

topics defined in INEX 2005 according to VVCAS

evaluation. Regarding evaluation, the VVCAS task

criteria are similar to the CO.Thorough task. These

experiments confirm the search engine behaviour

according to the studied parameters. Regarding

quantizations same configurations that for

CO.Thorough task lead to the best results.

6 CONCLUSIONS

In this paper, we proposed a search engine for XML

retrieval. This engine is based on the addition of

contributions brought by each component of the

user’s information need. The search engine is largely

configurable intended to be adapted to different

contexts such as different retrieval scenarios.

Through experiments using the INEX framework we

have evaluated the influence of different parameters

on the effectiveness of the search engine. The

experiments confirm that the engine presented can

be adapted to better respond to different retrieval

scenarios and how to adapt it to a given scenario.

However, experiments have been analysed

globally using average precision. Like other

participants to INEX, our search engine has variable

effectiveness at query level. Additional studies have

to be carried out at the query level to define criteria

that permit to adapt the search engine per topic.

Some works (Sigurbjörnsson et al., 2005)(Pehcevski

et al., 2005) tried to define categories among the

INEX topics. It would be interesting to study our

search engine according to these categories. Fusion

of different results obtained with different

configurations of our search engine is also a

considered future work.

REFERENCES

Amer-Yahia S., Lakshmanan L., Pandit S., 2004.

FleXPath: Flexible Structure and Full-Text Querying

for XML, ACM SIGMOD, Paris, pp. 83-94.

Augé, J., Englmeier, K., Hubert, G., Mothe, J., 2003.

Catégorisation automatique de textes basée sur des

hiérarchies de concepts, BDA’03, 19

ièmes

Journées de

Bases de Données Avancées, Lyon, pp. 69-87.

Bray T., Paoli J., Sperberg-McQueen C. M., Maler E.,

Yergeau Y., 2004. Extensible, Markup Language

(XML) 1.0. (Third Edition), W3C Recommendation.

Carmel D., Maarek Y. S., Mandelbrod M., Mass Y., Soffer

A., 2003. Searching XML documents via XML

fragments, 26

international conference SIGIR,

Toronto, pp. 151-158.

Clark J., DeRose S., 1999. XML Path Language (XPath),

W3C Recommendation.

Crouch C. J., Apte S., Bapat H., 2003. An Approach to

Structured Retrieval Based on the Extended Vector

Model, 2

INEX Workshop, Dagstuhl, pp. 89-93.

Fuhr N., Großjohann K., 2004. XIRQL: An XML query

language based on information retrieval concepts,

ACM TOIS, vol. 22, Issue 2, pp. 313-356.

Fuhr N., Maalik S., Lalmas M., 2003. Overview of the

INitiative for the Evaluation of XML Retrieval

(INEX) 2003, 2

INEX Workshop, Dagstuhl, pp. 1-7.

Geva S., 2005. GPX – Gardens Point XML Information

Retrieval at INEX 2004, LNCS 3493, INEX’04, 3

International Workshop, Dagstuhl, p. 211-223.

Hubert G., 2005. A voting method for XML retrieval,

LNCS 3493, INEX’04, 3

International Workshop,

Dagstuhl, p. 183-196.

Kazaï G., Lalmas M., 2005. INEX 2005 Evaluation

Metrics, Pre Proceedings of the 4

INEX Workshop,

pp. 401-406.

Liu S., Zou O., Chu W. W., 2004. Configurable indexing

and ranking for XML information. 27

International

Conference SIGIR, Sheffield, pp. 88-95.

Ogilvie P., Callan J., 2003. Using Language Models for

Flat Text Queries in XML Retrieval, 2

INEX

Workshop, Dagstuhl, pp. 12-18.

Pehcevski J., Thom J. A., Tahaghoghi S. M. M., 2005.

Hybrid XML Retrieval Revisited, LNCS 3493,

INEX’04, 3

International Workshop, Dagstuhl, pp.

153-167.

Piwowarski B., Vu H.-T., Gallinari P., 2003. Bayesian

Networks and INEX'03, 2

INEX Workshop,

Dagstuhl, pp. 33-37.

Ponte J. M., Croft W. B., 1998. A Language Modeling

Approach to Information Retrieval, 21

International

Conference SIGIR, Melbourne, pp. 275-281.

Salton G., Wong A., Yang C. S., 1975. A vector space

model for automatic indexing, Communication of the

ACM, vol. 18, Issue 11, pp. 613-620.

Sigurbjörnsson B., Kamps J., de Rijke M., 2005. Mixture

Models, Overlap, and Structural Hints in XML

Element Retrieval, LNCS 3493, INEX’04, 3

International Workshop, Dagstuhl, pp. 196-210.

TUNING SEARCH ENGINE TO FIT XML RETRIEVAL SCENARIO

233
