EXPRESSIVE REASONING ABOUT CULTURAL HERITAGE

KNOWLEDGE USING WEB ONTOLOGIES

Dimitrios A. Koutsomitropoulos and Theodore S. Papatheodorou

High Performance Information Systems Laboratory, Computer Engineering and Informatics Dpt.

School of Engineering, University of Patras, 26500 Patras - Rio, Greece

Keywords: Ontologies, Reasoning, Cultural Heritage, Semantic Web.

Abstract: The cultural heritage knowledge domain is often characterized by complex semantic structures and a great

lot of legacy information, possibly scattered on the Web that is not always properly structured. Thus, to

achieve proper reasoning about this kind of knowledge one needs first a rather expressive model of

representation that would also accommodate for its web distributed nature; and secondly a set of techniques

that would allow for its intelligent and productive manipulation. The former can be served by the CIDOC-

CRM which we first transform to the Semantic Web standard language, OWL and then augment with more

expressive structures, possible only after this transformation. To show the latter we conduct a series of

experimental inferences based on this CRM augmented form, using our Knowledge Discovery Interface.

Our results clearly demonstrate the potential as well as the limitations of such an approach.

1 INTRODUCTION

The Semantic Web and its relating technologies

gradually appear to proceed from a research and

standardization experiment to a concrete and

productive effort. As such, their application space

has already started to span a wide range of domains,

mostly because of the alluring capabilities promised:

Web knowledge management, semantic resource

description and distributed knowledge discovery are

among the most important of them. Cultural heritage

is such a domain, traditionally benefiting from the

application of state of the art information

technologies that assist and automate its

documentation and information interchange needs.

On the other hand, there is often skepticism around

such efforts, grounded mostly on the fact that they

do not always succeed in producing satisfactory and

cost-effective results.

Recently, attention has been drawn to the

CIDOC Conceptual Reference Model (CRM),

currently under review by ISO. CIDOC-CRM

(Crofts et al. 2003, Doerr 2003) is a reference

ontology for the interchange and representation of

cultural heritage information. It is mostly intended

as a conceptual “template” for organizing,

structuring and representing cultural information,

rather than a concrete implementation of a

knowledge schema. Nevertheless, it is also available

in machine readable formats like XML and RDF.

Among the CRM applications, its use by the

Artequakt system appears to be the most relevant to

our work. Artequakt (Alani et al. 2003) tries to

alleviate the task of knowledge base maintenance by

following an automated knowledge extraction

approach. Artequakt applies natural language

processing on Web documents in order to extract

information about artists and the artistic world and

populate its knowledge base. Stored knowledge is

then used for the automatic production of

personalised biographies for artists. The CIDOC-

CRM is used as the “conceptual schema” for the

information that needs to be extracted from the

documents and stored in the knowledge base.

Nevertheless, it should be noted that no inference -

and thus knowledge discovery - takes place.

In this paper we examine the possibilities of

applying Semantic Web techniques and ideas in

order to enable reasoning on and discovery of

cultural heritage information over distributed

knowledge resources. Specifically, we show how to

use the CRM, appropriately modified and extended

for the Semantic Web environment, in order to

perform useful inferences on cultural knowledge

organized according to this model. First, we

276

A. Koutsomitropoulos D. and S. Papatheodorou T. (2007).

EXPRESSIVE REASONING ABOUT CULTURAL HERITAGE KNOWLEDGE USING WEB ONTOLOGIES.

In Proceedings of the Third International Conference on Web Information Systems and Technologies - Web Interfaces and Applications, pages 276-281

DOI: 10.5220/0001283502760281

 SciTePress

transform and encode CRM to the Semantic Web

standard language, OWL and present the lessons

learned in this process. We then augment the

model’s expressivity by adding more expressive

constructs made possible only after this

transformation. We further complement CRM by

adding some instances of CRM’s concepts and roles,

serving as a concrete modeling example. To be able

to conduct our inferences, we have developed a

prototype web based tool, the Knowledge Discovery

Interface (KDI) that employs a reasoning module

and aids the user to compose and submit intelligent

queries to OWL documents, stored locally or on the

Web. Using the KDI, we conduct a series of

experimental inferences based on the CRM

augmented form, which lead to the extraction of

new, useful knowledge, not previously expressed in

the ontology.

The rest of this paper is organized as follows: In

section 2 we discuss our process of transforming and

augmenting the CIDOC-CRM. Section 3 deals with

the methodology that is actually followed to infer

knowledge and introduces the KDI; then, section 4

shows the inferences conducted on the CRM and

their results. Finally, section 5 summarizes the

conclusions drawn from our approach.

2 UPGRADING CIDOC-CRM TO

OWL

CIDOC-CRM is currently at version 3.4.10 (aka

version 4). In our work we used the initial 3.4

version, because this is the most up-to-date CRM’s

version that maintains a machine readable

implementation. Later versions include small-scale

updates regarding mostly insertion, deletion and

renaming of concepts and roles in the model. Among

its implementations we chose RDF(S), as the

semantically richest and closest to OWL available

format.

As of Jan. 2005 there exists an OWL

transcription of the CRM’s RDF document.

However this version adds only role specific

constructs (inversion, transitivity etc) which,

semantically, do not exceed OWL Lite.

Version 3.4 includes about 84 concepts και 139

roles, not counting their inverses (that is, a total of

278 roles) (Figure 1). In terms of expressivity, the

CRM employs structures enabled by RDF(S), which

may be summarized as follows:

 Concepts as well as roles are organized in

hierarchies.

 For every role, concepts are defined that

form its domain and its range.

 For every role, its inverse is also defined, as

a separate role, because RDF(S) cannot implicitly

express inversion relation between two roles.

 There is no distinction between object and

datatype properties (roles) as in OWL; Rather,

roles that are equivalent to datatype properties

have

rdf:Literal as their range.

Changes and extensions made to the RDF(S)

CIDOC-CRM ontology, in order to upgrade to

OWL, were performed in a two-phase procedure:

First at syntactic and then at semantic level.

2.1 Transforming Syntax

In order to transform the ontology to OWL syntax,

we initially utilized the RACER system (Haarslev &

Möller 2003, Haarslev & Möller 2004). RACER has

the ability to load and process ontologies expressed

in various formats, including RDF(S) and OWL.

One can instruct RACER to load TBoxes expressed

in RDF(S) by using the

rdfs-read-tbox-file

command. Once loaded, the TBox can then be

exported to the appropriate format by using the

save-tbox command along with the: syntax

parameter.

Following these steps, we actually received a

formal OWL document representing correctly the

initial ontology. However, we discovered that

RACER included some unnecessary and redundant

statements, which, in many cases, were semantically

overlapping. For example:

 For every role and concept, RACER included tags

from the OILed namespace; in particular,

RACER added the tags

oiled:creationDate

and oiled:Creator, which were not required

nor included in the initial document.

 For every concept defined as domain or range,

RACER used the

owl: UnionOf operand, thus

expressing these restrictions as singleton concept

unions (including only the concept in particular).

 The definition of role domains and ranges, even

in OWL, comes from the RDF(S) namespace

(

rdfs:domain, rdfs:range). RACER, even

though it maintains these statements, it

duplicates them with equivalent expressions,

which relate to the DL-like style of expressing

this kind of restrictions. These equivalent

statements involve number and value restrictions

and can be represented in OWL.

This process resulted in transforming the initial

60KB file to a 478KB OWL document. We

therefore opted for the manual transcription of the

EXPRESSIVE REASONING ABOUT CULTURAL HERITAGE KNOWLEDGE USING WEB ONTOLOGIES

277

RDF(S) document, during which common

expressions between RDF(S) and OWL were

preserved (e.g.

rdfs:subClassOf and rdf:

resource), while we replaced some namespace

prefixes and updated the terminology used (e.g.

owl:Class instead of rdfs:Class and owl:

ObjectProperty or owl:DataTypeProperty

instead of

rdf:Property). In this manner the CRM

syntactical transformation phase was completed,

resulting in a 63ΚΒ document, named

cidoc_crm_v3.4.owl.

2.2 Augmenting Semantics

The second phase of CRM upgrading process

included its semantic augmentation with OWL-

specific structures up to the OWL DL level, as well

as its completion with some concrete instances.

Although these extensions could have been

integrated in the initial document, we chose to

include them in a new file. The reason for this is to

better show Semantic Web capabilities for ontology

integration and distributed knowledge discovery.

More specifically, we created a document named

mondrian.owl that includes CRM concept and role

instances which model facts from the life and work

of the Dutch painter Piet Mondrian. In this document

we also included axiom and fact declarations that

OWL allows to be expressed, as well as new roles

and concepts making use of this expressiveness. Ιn

detail:

 We modeled minimum and maximum

cardinality restrictions by using unqualified

number restrictions (

owl:minCardinality,

owl:maxCardinality).

 We modeled inverse roles, using the

owl:inverseOf operand.

 We included a symmetric role example, using

the

rdf:type= “&owl;Symmetric”

statement.

 We constructed concepts based on existential

and universal quantification, by using the

owl:hasValue, owl:someValuesFrom and

owl:allValuesFrom expressions, which

ultimately enable more complex inferences.

The aforementioned documents were made

available on the Internet through the Tomcat server.

Inclusion of cidoc_crm_v3.4.owl axioms was

possible simply by using the

<owl:imports>

directive in mondrian.owl. Therefore, loading

mondrian.owl also loads all the axioms from

cidoc_crm_v3.4.owl as well, as long as the latter is

available on the Internet. In order to resolve

potential ambiguities, different namespaces were

defined for each document. In order to refer to

statements from the imported ontology, the crm

prefix is used, whereas for the new statements the

default prefix (#) is used.

Figure 1: CIDOC-CRM taxonomy as shown by the KDI.

WEBIST 2007 - International Conference on Web Information Systems and Technologies

278

3 INFERENCE METHODOLOGY

Having expressed our ontology in OWL and created

some typical instances, we should identify the means

that would allow us to process this knowledge and

deduct new facts out of it. In other words, reasoning

support is explicitly needed to back the inference

process. As OWL does not natively support or

suggest a reasoning mechanism, we have to rely on

an underlying logical formalism and a corresponding

inference engine. In the following we discuss the use

of Description Logics as the bottom line of our

reasoning approach; then we introduce the KDI, the

web service we have created to actually perform our

inferences. This methodology is exhibited in more

detail elsewhere (Koutsomitropoulos et al. 2006a,

Koutsomitropoulos et al. 2006b).

3.1 Logical Formalism

Choosing an underlying logical formalism for

performing reasoning is crucial, as it will greatly

determine the expressiveness to be achieved.

Description Logics (DLs) form a well defined subset

of First Order Logic (FOL). OWL Lite and OWL

DL are in fact very expressive description logics,

using RDF syntax (Horrocks et al. 2003). Therefore,

the semantics of OWL, as well as the decidability

and complexity of basic inference problems in it, can

be determined by existing research on DL. OWL

Full is even more tightly connected to RDF, but its

typical attributes are less comprehensible, and the

basic inference problems are harder to compute

(because OWL Full is undecidable). Inevitably, only

the examination of the relation between OWL

Lite/DL with DLs may lead to useful conclusions.

On the other hand, even the limited versions of

OWL differ from DLs, in certain points, including

the use of namespaces and the ability to import other

ontologies.

Horrocks & Patel-Schneider (2003) have shown

how OWL DL can be reduced in polynomial time

into SHOIN(D), while there exists an incomplete

translation of SHOIN(D) to SHIN(D). This

translation can be used to develop a partial, though

powerful reasoning system for OWL DL. A similar

procedure is followed for the reduction of OWL Lite

to SHIF(D), which is completed in polynomial time

as well. In that manner, inference engines like FaCT

and RACER can be used to provide reasoning

services for OWL Lite/DL.

On the other hand, neither the currently available

Description Logic systems nor the algorithms they

implement, support the full expressiveness of OWL

DL. Even if such algorithms are implemented, their

efficiency will be doubtful, since the corresponding

problems are in NE

XP. Horrocks and Sattler (2005)

have introduced a decision procedure for the SHOIQ

Description Logic; this algorithm is claimed to

exhibit controllable efficiency and is currently under

implementation in two high-end inference engines.

Nevertheless, DLs seem to constitute the most

appropriate available formalism for ontologies

expressed in DAML+OIL or OWL. This fact also

derives from the designing process of these

languages. In fact, the largest decidable subset of

OWL, OWL DL, was explicitly intended to show

well studied computational characteristics and

feature inference capabilities similar to those of

DLs. Furthermore, existing DL inference engines

seem to be powerful enough to carry out the

inferences we need.

3.2 The Knowledge Discovery Interface

The KDI is a prototype web application, providing

intelligent query submission services on Web

ontology documents. We use the word Interface in

order to emphasize the fact that the user is offered a

simple and intuitive way to compose and submit

queries. In addition, the KDI interacts with RACER

to conduct inferences. RACER was chosen because

of its availability, its enhanced support for OWL DL

as well as its ability to reason about the ABox.

After connection to RACER has successfully

been established, the ontology is loaded and its

information is shown on the browser (see Figure 1).

The user may navigate through the concept

hierarchy, which is visualized in a tree form, and

select any of the available classes. Upon selection,

the page is reloaded, now containing in two drop

down menus all of the instances of the selected

class, as well as all of the roles whose domain is in

this class. The user is able to select an instance and a

role and then submit his query by pressing a button.

Note that an option is available to invert the selected

role, thus resulting in a different query.

We have identified such a declarative behavior to

be of crucial importance for the Semantic Web

knowledge discovery process; after all, the user

should be able to pose queries even to unknown

ontologies, encountered for the first time.

KDI helps the user compose a query by selecting

a concept, an instance and a role in a user friendly

manner. After the query is composed, it is

decomposed into several lower level functions that

are then submitted to RACER. This procedure is

transparent to the user, withholding the details of the

EXPRESSIVE REASONING ABOUT CULTURAL HERITAGE KNOWLEDGE USING WEB ONTOLOGIES

279

∃R.{i

}

∃R.I

∀R.D

knowledge base actual querying and making the

query composition process intuitive.

4 EXPERIMENTAL

INFERENCES

In the following we present the results from a series

of experimental inference actions conducted on the

CRM augmented OWL form using our KDI. For

every example we give the OWL fragment where

the inference is based on, and we graphically depict

the reasoning process in terms of the DL formalism.

To save space, instead of full namespaces we use the

prefix “&crm;” for entities originating from the

cidoc_crm_v3.4.owl document, as well as the

default prefix “#” for entities coming from the

mondrian.owl document (which includes the

former).

Top Concept: Τ

P94F.has_created: R

Painting_Event: C

Painting: D

Creation of Mondrian’s Composition: i

Mondrian’s Composition: i

Figure 2: Inference Example using Value Restriction.

The following code is a fragment from

mondrian.owl stating that a “Painting_Event” is in

fact a “Creation_Event” that “has_created”

“Painting” objects only:

<owl:Class rdf:ID="Painting_Event">

<rdfs:subClassOf rdf:resource=

"&crm;E65.Creation_Event"/>

<rdfs:subClassOf>

<owl:Restriction>

<owl:onProperty rdf:resource=

"&crm;P94F.has_created"/>

<owl:allValuesFrom

rdf:resource="#Painting"/>

</owl:Restriction>

</rdfs:subClassOf>

</owl:Class>

<Painting_Event rdf:ID=

"Creation of Mondrian's composition">

<crm:P94F.has_created rdf:resource=

"#Mondrian's composition"/>

</Painting_Event>

The above fragment is graphically depicted in

the left part of Figure 2.

“Creation of Mondrian’s Composition” (i

) is an

explicitly stated “Painting_Event” that

“has_created” (R) “Mondrian’s composition” (i

Now, asking the KDI to infer “what is a painting?” it

infers that i

is indeed a painting (right part of Figure

3), correctly interpreting the value restriction on role

Let’s now examine another example that

involves the use of nominals. The following

fragment from mondrian.owl states that a “Painting”

is a “Visual_ Item” that its “Type” is

“painting_composition”.

<owl:Class rdf:ID="Painting">

<owl:subClassOf rdf:resource=

"&crm;E36.Visual_Item"/>

<owl:equivalentClass>

<owl:Restriction>

<owl:onProperty rdf:resource=

"&crm;P2F.has_type"/>

<owl:hasValue rdf:resource=

"#painting_composition"/>

</owl:Restriction>

</owl:equivalentClass>

</owl:Class>

<crm:E55.Type rdf:ID=

"painting_composition"/>

<Painting rdf:ID=

"Mondrian's composition"/>

The above fragment is graphically depicted in the

left part of Figure 3.

Top Concept: Τ

P2F.has_type: R

Painting_Composition: i

Mondrian’s Composition: i

Figure 3: Inference Example using Existential

Quantification and Nominals.

“Mondrian’s Composition” (i

) is explicitly

declared as a “Painting” instance which in turn is

defined as a hasValue restriction on “has_type” (R).

WEBIST 2007 - International Conference on Web Information Systems and Technologies

280

“Painting_composition” (i

) is declared as a “Type”

object. While the fact that “Mondrian’s

Composition” “has_type” “Painting” is

straightforward, the KDI is unable to infer so and

returns null when asked “what is the type of

Mondrian’s composition?”

This example clearly demonstrates how difficult

is for RACER as well as for every other current DL

based system to reason about nominals. Given the

} nominal, RACER creates a new synonym

concept I

and makes i

an instance of I

. It then

actually replaces the hasValue restriction with an

existential quantifier on concept I

and thus is unable

to infer that R(i

) really holds.

5 CONCLUSIONS

In this paper we have shown how to take advantage

of the Semantic Web infrastructure in order to infer

knowledge over the cultural heritage domain. As

Semantic Web becomes a growing reality, domain

modelers and specialists need to be prepared in order

to adjust to this new environment and to rip the

benefits of novel opportunities presented.

The CIDOC-CRM is identified as a key starting

point for achieving cultural knowledge discovery.

Based on the CRM, we have designated a process

for representing cultural heritage information on the

Semantic Web, by encoding the model in OWL and

enriching it with more expressive semantic

structures.

Furthermore we succeeded in conducting a series

of inferences on web distributed cultural heritage

information. The method we provide is grounded on

a well-studied background and is based on decisions

crucial for the quality, expressiveness and value of

the inferences performed. In addition, the KDI

demonstrates proper evidence of how this approach

can be practically applied so as to be beneficial for a

number of applications.

Our results seem to justify such an approach; at

the same time they reveal that there are still

limitations on the extent to which current state-of-

the-art supports the full potential of the Semantic

Web, especially in terms of its inferring capabilities.

For example, the difficulty of current DL inferences

engines to deal with nominals greatly hampers the

expressiveness of our inferences.

Our results also suggest that augmenting the

CRM with the OWL DL specific constructors leads

to more powerful and semantically rich inferences.

Thus, the incorporation of such “post-RDF”

expressions in to the original model would probably

lead to its better utilization by knowledge-intensive

applications as well as to more accurate modelling

of the domain.

ACKNOWLEDGEMENTS

Dimitrios A. Koutsomitropoulos is partially

supported by a grant from the "Alexander S.

Onassis" Public Benefit Foundation.

REFERENCES

Alani, H., Kim, S., Millard, D. E.,Weal, M. J., Hall, W.,

Lewis, P. H., and Shadbolt, N. R., 2003. Automated

Ontology-Based Knowledge Extraction from Web

Documents. IEEE Intelligent Systems, 18(1): 14-21.

Crofts, N., Doerr, M., and Gill, T., 2003. The CIDOC

Conceptual Reference Model: A standard for

communicating cultural contents. Cultivate

Interactive, issue 9. http://www.cultivate-int.org/

/issue9/chios/

Doerr, M., 2003. The CIDOC conceptual reference model:

an ontological approach to semantic interoperability of

metadata. AI Magazine, 24(3): 75-92.

Haarslev V., and Möller R., 2003. Racer: A Core

Inference Engine for the Semantic Web. In Proc. of

the 2nd International Workshop on Evaluation of

Ontology-based Tools (EON2003), pp. 27-36.

Haarslev V., and Möller R., 2004. RACER User’s Guide

and Reference Manual Version 1.7.19.

http://www.sts.tu-harburg.de/~r.f.moeller/racer/ /racer-

manual-1-7-19.pdf

Horrocks, I., and Patel-Schneider, P. F., 2003. Reducing

OWL entailment to description logic satisfiability. In

D. Fensel, K. Sycara, and J. Mylopoulos (eds.): Proc.

of the 2003 International Semantic Web Conference

(ISWC 2003), number 2870 of LNCS, pp. 17-29,

Springer.

Horrocks, I., Patel-Schneider, P. F., and van Harmelen, F.,

2003. From SHIQ and RDF to OWL: The making of a

web ontology language. Journal of Web Semantics,

1(1):7-26.

Horrocks, I., and Sattler, U., 2005. A tableaux decision

procedure for SHOIQ. In Proc. of the 19th Int. Joint

Conf. on Artificial Intelligence (IJCAI 2005).

Koutsomitropoulos, D. A., Meidanis, D. P., Kandili A. N.,

and Papatheodorou, T. S., 2006. OWL-Based

Knowledge Discovery Using Description Logic

Reasoners. 2006 Int. Conf. on Enterprise Information

Systems (ICEIS 2006), SAIC track, pp.43-50.

Koutsomitropoulos, D. A., Fragakis, M. F., and

Papatheodorou, T. S., 2006. A Methodology for

Conducting Knowledge Discovery on the Semantic

Web. In S. Sirmakessis (Ed.) Adaptive and

Personalized Semantic Web, Studies In Computational

Intelligence (14), pp. 95-105, Springer.

EXPRESSIVE REASONING ABOUT CULTURAL HERITAGE KNOWLEDGE USING WEB ONTOLOGIES

281
