ACCELERATING XPATH AXES THROUGH STRUCTURAL

PARTITIONING

Olli Luoma

Department of Information Technology, 20014 University of Turku, Finland

Keywords:

XML, XPath, XML databases.

Abstract:

The query evaluation algorithms of practically all XML management systems are based on structural joins,

i.e., operations which determine all occurrences of parent/child, ancestor/descendant, preceding/following

etc. relationships between node sets. In this paper, we present a simple method for accelerating structural

joins which is very easy to implement on different platforms. Our idea is to split the nodes into disjoint

partitions and use this information to avoid unnecessary structural joins. Despite its simplicity, our proposal

can considerably accelerate XPath evaluation on different XML management systems. To exemplify this, we

describe two implementation options of our method - one built from the scratch and one based on a relational

database - and present the results of our experiments.

1 INTRODUCTION

In many modern applications areas, such as bioinfor-

matics and Web services, there is a need to efﬁciently

store and query large heterogeneous data sets marked

up using XML (W3C, 2006a), i.e., represented as a

partially ordered, labeled XML tree. This imposes a

great challenge on data management systems which

have traditionally been designed to cope with struc-

tured rather than semistructured data. In recent years,

a lot of work has thus been done to develop new meth-

ods for storing and querying XML data using XML

query languages, such as XPath (W3C, 2006b) and

XQuery (W3C, 2006c).

At the heart of the XPath query language, there are

12 axes, i.e., operators for tree traversal. In this paper,

we present a method for accelerating the evaluation

of the major axes, i.e., the ancestor, descendant,

preceding, and following axes, through partition-

ing. We make use of the observation that starting

from any node, the main axes partition the document

into four disjoint partitions. Our idea is to partition

the nodes more accurately, store the partition infor-

mation, and use this information to ﬁlter the nodes

that cannot be contained in the result before actually

performing the axis.

Since our method is based on simple geometric

properties of the preorder and postorder numbers of

the nodes, it is somewhat similar to the XML index-

ing approaches based on spatial structures, such as R-

trees (Grust, 2002) or UB-trees (Kr

atk

y et al., 2004).

The method described in this paper, however, is very

easy to implement even using B-trees, and thus it can

easily be used to accelerate XPath evaluation in XML

management systems built on relational databases,

such as XRel (Yoshikawa et al., 2001) and XPath ac-

celerator (Grust, 2002). Furthermore, our approach

can also be tailored to be used with other node identi-

ﬁcation schemes, such as the order/size scheme.

The rest of our paper is organized as follows. In

section 2, we take a short look at the related work and

in section 3, we present our own partitioning method.

In section 4, we discuss the implementation of our

method and in section 5, the results of our experimen-

tal evaluation. Section 6 concludes this article and

discusses our future work.

2 RELATED WORK

In the XML research literature, there are numerous

examples of different XML management systems.

Luoma O. (2007).

ACCELERATING XPATH AXES THROUGH STRUCTURAL PARTITIONING.

In Proceedings of the Third International Conference on Web Information Systems and Technologies - Internet Technology, pages 96-103

DOI: 10.5220/0001283800960103

 SciTePress

These systems can roughly be categorized into the fol-

lowing three categories:

• The ﬂat streams approach handles the documents

as byte streams (Peng & Chawathe, 2003) (Barton

et al., 2003). Obviously, accessing the structure

of the documents requires parsing and consumes

a lot of time, but this option might still be viable

in a setting where the documents to be stored and

queried are small.

• In the metamodeling approach, the XML doc-

uments are ﬁrst represented as trees which are

then stored into a database. With suitable in-

dexes this approach provides fast access to sub-

trees, and thus the metamodeling approach is by

far the most popular in the ﬁeld of XML man-

agement research. Unlike in the ﬂat streams ap-

proach, however, rebuilding large parts of origi-

nal documents from a large number of individual

nodes can be rather expensive. The partitioning

method discussed in this paper also falls into this

category.

• The mixed approach aims at combining the previ-

ous two approaches. In some systems, the data is

stored in two redundant repositories, one ﬂat and

one metamodeled, which allows the stored doc-

uments to be queried and the result documents

to be built efﬁciently, but obviously creates some

storage overhead. This problem could be tackled

by compression to which XML data is often very

amenable. There are also examples of a hybrid

approach in which coarser structures of the XML

documents are modeled as trees and ﬁner struc-

tures as ﬂat streams (Fiebig et al., 2003).

A lot of work has been carried out to accelerate

structural joins (Al-Khalifa et al, 2002), i.e., opera-

tions which determine all occurrences of parent/child,

ancestor/descendant, preceding/following etc. rela-

tionships between node sets. Some approaches are

based on indexes built on XML trees, whereas oth-

ers aim at designing more efﬁcient join algorithms.

The former category includes the so called proxy in-

dex (Luoma, 2005b) (Luoma, 2006) which effectively

partitions the nodes into overlapping partitions so that

the ancestors of any given node are contained within

the same partition. Thus, when the ancestors of a

given node are retrieved it is sufﬁcient to check the

partitions to which the node is assigned. Conversely,

descendants can also be found efﬁciently since there

is no need to check the partitions to which the node

is not assigned. However, this approach is suitable

for accelerating only ancestor/descendant operations.

The method discussed in this paper, on the contrary,

can also accelerate preceding/following operations.

The other group of methods include, for example,

the staircase join (Grust & van Keulen, 2003). The

idea of the staircase join is to prune the set of con-

text nodes, i.e., the initial nodes from which the axis

is performed. For instance, for any two context nodes

n and m such that m is a descendant of n, all descen-

dants m are also descendants of n, and thus m can be

pruned before evaluating the descendant axis. An-

other method based on preprocessing the nodes was

proposed in (Tang et al., 2005). In this approach

the nodes were partitioned somewhat similarly to the

method discussed in this paper. However, both of

these methods require a considerable amount of pro-

gramming effort since they work by preprocessing the

data rather than by building indexes. In the context of

relational databases, for example, this would mean ei-

ther reprogramming the DBMS internals or program-

ming a collection of external classes to implement

the join algorithms. Our method, on the contrary, re-

quires very little programming effort even when im-

plemented using a relational database, which we re-

gard as the main advantage of our approach.

3 XPATH BASICS

As mentioned earlier, XPath (W3C, 2006b) is based

on a tree representation of a well-formed XML docu-

ment, i.e., a document that conforms to the syntactic

rules of XML. A simple example of an XML tree cor-

responding to the XML document <b><c d="y"/><c

d="y"><e>kl </e></c><c><e>ez</e></c></b> is

presented in Figure 1. The nodes are identiﬁed using

their preorder and postorder numbers which encode a

lot of structural information

The tree traversals in XPath are based on 12 axes

which are presented in Table 1. In simple terms, an

XPath query can be thought of as a series of location

steps of the form /axis::nodetest[predicate]

which start from a context node - initially the root of

the tree - and select a set of related nodes speciﬁed by

the axis. A node test can be used to restrict the name

or the type of the selected nodes. An additional predi-

cate can be used to ﬁlter the resulting node set further.

The location step n/child::c[child::*], for ex-

ample, selects all children of the context node n which

are named ”c” and have one or more child nodes. As

a shorthand for axes child, descendant-or-self,

and attribute, one can use /, //, and /@, respec-

tively.

In preorder traversal, a node is visited before its sub-

trees are recursively traversed from left to right and in pos-

torder traversal, a node is visited after its subtrees have been

recursively traversed from left to right.

ACCELERATING XPATH AXES THROUGH STRUCTURAL PARTITIONING

4,6

8,9

9,8

6,5

5,3

@d=”y”

7,4

”kl”

0,7

”ez”

Element node

Attribute node

Text node

Figure 1: An XML tree.

Table 1: XPath axes and their semantics.

Axis Semantics of n/Axis

parent Parent of n.

child Children of n, no attribute nodes.

ancestor Transitive closure of parent.

descendant Transitive closure of child, no attribute nodes.

ancestor-or-self Like ancestor, plus n.

descendant-or-self Like descendant, plus n, no attribute nodes.

preceding Nodes preceding n, no ancestors or attribute nodes.

following Nodes following n, no descendants or attribute nodes.

preceding-sibling Preceding siblings of n, no attribute nodes.

following-sibling Following siblings of n, no attribute nodes.

attribute Attribute nodes of n.

self Node n.

Using XPath, it is also possible to set con-

ditions for the string values of the nodes. The

XPath query //record="John Scofield Groove

Elation Blue Note", for instance, selects all ele-

ment nodes with label ”record” for which the value

of all text node descendants concatenated in doc-

ument order matches ”John Scoﬁeld Groove Ela-

tion Blue Note”. Notice also that the result of

an XPath query is the concatenation of the parts

of the document corresponding to the result nodes.

In our example case, query //c//*, for exam-

ple, would result in no less than <c d="y"/><c

d="y"><e>kl</e></c><c><e>ez</e></c>

<e>kl </e><e>ez</e>.

4 PARTITIONING METHOD

As mentioned earlier, we rely on pre-/postorder en-

coding (Dietz, 1982), i.e., we assign both preorder

and postorder numbers for the nodes. This encoding

provides us with enough information to evaluate the

four major axes (Grust, 2002) as follows

Proposition 1. Let pre(n) and post(n) denote the pre-

order and postorder numbers of node n, respectively.

For any two nodes n and m, n ∈ m/ancestor::*

iff pre(n) < pre(m) and post(n) > post(m),

n ∈ m/descendant::* iff pre(n) > pre(m) and

post(n) < post(m), n ∈ m/preceding::* iff

pre(n) < pre(m) and post(n) < post(m), and

n ∈ m/following::* iff pre(n) > pre(m) and

post(n) > post(m).

This observation is exempliﬁed on the left side of

Figure 2 which shows the partitioning created by the

major axes using node (6,5) as the context node. The

ancestors of node (6,5) can be found in the upper-left

partition, the descendants in the lower-right partition,

This is actually a bit inaccurate since the attribute

nodes, for example, are not in the result of the descendant

axis. However, if all nodes are treated equally, the proposi-

tion holds.

WEBIST 2007 - International Conference on Web Information Systems and Technologies

0 2 4 6 8 10 12

Post

Pre

0 2 4 6 8 10 12

Post

Pre

Figure 2: Examples on the major axes (left) and partitioning using value 4 for p (right).

the predecessors in the lower-left partition, and the

followers in the upper-right partition. Based on the

previous observation, the following proposition is ob-

vious:

Proposition 2. For any two nodes n and m and

for any p > 0, bpre(n)/pc ≤ bpre(m)/pc and

bpost(n)/pc ≥ bpost(m)/pc if n ∈ m/ancestor::*,

bpre(n)/pc ≥ bpre(m)/pc and bpost(n)/pc ≤

bpost(m)/pc if n ∈ m/descendant::*,

bpre(n)/pc ≤ bpre(m)/pc and bpost(n)/pc ≤

bpost(m)/pc if n ∈ m/preceding::*, and

bpre(n)/pc ≥ bpre(m)/pc and bpost(n)/pc ≥

bpost(m)/pc if n ∈ m/following::*.

Proposition 2 provides us with simple means for

partitioning the nodes into disjoint subsets. The parti-

tioning is exempliﬁed in Figure 2 (right) which shows

the nodes of our example tree partitioned using value

4 for p. It should now be obvious that when searching,

for instance, the ancestors of node (6,5), it is sufﬁcient

to check the nodes in the shaded partitions since other

partitions cannot contain any ancestors. In what fol-

lows, values bpre(n)/pc and bpre(n)/pc where n is a

node residing in partition P are simply referred to as

the preorder and postorder number of P and denoted

by pre(P) and post(P), respectively.

Many minor axes can also beneﬁt from

partitioning. The ancestor-or-self and

descendant-or-self axes, for example, behave

similarly to ancestor and descendant axes, and

thus they can be accelerated using the same partition

information. The results of preceding-sibling

and following-sibling, on the other hand, are

subsets of preceding and following and the results

of parent and child subsets of ancestor and

descendant so they can also be accelerated using

the partitioning. However, other minor axes than

ancestor-or-self and descendant-or-self

are generally very easy to evaluate, and thus using

the partition information to evaluate them is often

just unnecessary overhead especially if we have an

index which can be used to locate the nodes with a

given parent node efﬁciently (Luoma, 2005a). One

should also notice that in practice, the nodes are

not distributed evenly and there are several empty

partitions. Thus, the number of non-empty partitions

is usually much smaller than p

5 IMPLEMENTATION OPTIONS

5.1 Relational Implementation

To test our idea, we designed a relational database

according to the principles described in the previous

section. As the basis of our implementation, we chose

the XPath accelerator (Grust, 2002). In order to store

the partition information, we employed relation Part,

and thus we ended up with the following relational

schema:

Node(Pre, Post, Par, Part, Type, Name, Value)

Part(Part, Pre, Post)

As in the original proposal, the database attributes

Pre, Post, Par, Type, Name, and Value of the Node

relation correspond to the pre- and postorder num-

bers, the preorder number of the parent, the type, the

name, and the string value of the node, respectively.

The database attributes Type, Name, and Value are

needed to support node tests and string value tests; the

axes can be evaluated using database attributes Pre,

ACCELERATING XPATH AXES THROUGH STRUCTURAL PARTITIONING

Post, and Par. The partition information is contained

in the Part table in which the database attributes Pre

and Post correspond to the preorder and postorder

number of the partition, respectively. The database

attribute Part in the Node relation is a foreign key

referencing to the primary key of the Part relation.

For the sake of brevity, we do not describe the

XPath-to-SQL query translation in detail; the de-

tails can be found in (Yoshikawa et al., 2001) and

(Grust, 2002). For our purposes, it is sufﬁcient to

say that in order to perform structural joins, these

systems issue SQL queries which involve nonequi-

joins, i.e., joins using < or > as the join condition,

which can easily lead to scalability problems (Luo-

ma, 2006). In XPath accelerator, the XPath query

/descendant::*, for instance, is transformed into

the following SQL query:

SELECT DISTINCT n

FROM Node n

, Node n

WHERE n

.Pre>n

.Pre AND n

.Post<n

.Post

ORDER BY n

.Pre;

Notice that tuple variables n

and n

are joined

completely using slow nonequijoins. However, we

can use the partition information stored into table

Part to replace some of the nonequijoins with much

faster equijoins, i.e., joins using = as the join condi-

tion. With the partition information, the same query

can be evaluated much more efﬁciently using the fol-

lowing piece of SQL:

SELECT DISTINCT n

FROM Node n

, Node n

, Part a

, Part b

WHERE a

.Part=n

.Part AND b

.Pre>=a

.Pre

AND b

.Post<=a

.Post AND n

.Part=b

.Part AND

.Pre>n

.Pre AND n

.Post<n

.Post

ORDER BY n

.Pre;

In simple terms, we use tuple variable a

for

the partition in which node corresponding to tu-

ple variable n

resides. Variable b

corresponds

to the partitions which can contain descendants of

; condition n

.Part=b

.Part restricts our search

into the nodes residing in those partitions. Fi-

nally, we simply use condition n

.Pre>n

.Pre AND

.Post<n

.Post to retrieve the actual descendants.

The nonequijoins on the Part table are seldom a

problem since the Part table is rather small provided

that p, i.e., the number of partitions, has been selected

carefully. Other major axes can obviously be acceler-

ated similarly.

5.2 Native Implementation

We also implemented a simple XPath processor

which parses an XML document and splits the nodes

corresponding to the document into partitions which

are maintained in the main memory. For each node,

our system maintains its preorder number, postorder

number, reference to its parent, type, name, and string

value. In other words, the representation of the nodes

is similar to the relational implementation discussed

earlier. The partitions are lexically sorted according to

their pre- and postorder numbers and the nodes within

the partitions are sorted in preorder. Thus, given

node n, set of partitions S, and axis axis, the follow-

ing join algorithm simply iterates the partitions and

checks only the partitions which can contain nodes in

n/axis::*. For the sake of brevity, we do not treat all

axes in algorithm join; operator + is used as a short-

hand for operation which adds an item to a set and

par(n) denotes the parent of node n.

join(n, S, axis, p)

in: Node n, partition set S, XPath axis axis, partitioning

factor p

out: Nodes in n/axis::* in S

if axis = preceding or axis = preceding-sibling

for each P ∈ S

if pre(P) ≤ bpre(n)/pc and post(P) ≤ bpre(n)/pc

result ← result + joinPart(n, P, axis)

...

return result

The structural joins within a partition, then, are

carried out using algorithm joinPart:

joinPart(n, P, axis)

in: Node n, partition P, XPath axis axis

out: Nodes in n/axis::* of p

if axis = preceding then

for each m ∈ M

if pre(m) < pre(n) and post(m) < post(n)

result ← result + m

if axis = preceding-sibling then

for each m ∈ M

if pre(m) < pre(n) and par(m) = par(n)

result ← result + m

...

return result

Again, our algorithm is heavily simpliﬁed. How-

ever, it is easy to extend the algorithm to support

node tests and string value tests by checking the type,

name, and string value attributes of the node. No-

tice also that we could dramatically lower the number

WEBIST 2007 - International Conference on Web Information Systems and Technologies

100

of structural joins by considering the fact that the all

nodes in partition P such that pre(P) < bpre(n)/pc

and post(P) < bpost(n)/pc are guaranteed to be in

n/preceding::*, and thus they could be added to the

result without performing the structural joins. We also

implemented this option but found out that is did not

lead to considerable gains in evaluation times. How-

ever, the beneﬁts obviously depend on the implemen-

tation and in some cases, this approach can further

accelerate the joins.

6 EXPERIMENTAL RESULTS

6.1 Relational Implementation

We implemented the relational option using Win-

dows XP and Microsoft SQL Server 2000 running

on 2.00 GHz Pentium PC Equipped with 512 MB

of RAM and standard IDE disks. The algorithms

needed to build the databases, as well as the algo-

rithms for query translation, were implemented using

Java. We built indexes on Node(Post), Node(Name),

Part(Pre), and Part(Post) and a clustered index

on Node(Part). As our test data sets, we used the

1998 baseball statistics (52707 nodes) and the col-

lection of Shakespeare’s plays (327129 nodes), both

available at http://www.ibiblio.org/examples.

The sizes of these documents were 640 kB and 7.47

MB, respectively; values 1, 2, 4, ..., 256 were used as

a partitioning factor p.

Figure 3 presents the query performance for the

major axes using a relatively large set of context

nodes; in these ﬁgures, the word ”Partitions” refers

to the value of p or the number of partitions per (pre-

order or postorder) dimension. In the case of base-

ball.xml, nodes with name ”PLAYER” (1226 nodes)

and in plays.xml, nodes with name ”SCENE” (750

nodes) served as the context nodes. One should no-

tice that our method can lead to considerable perfor-

mance gains in ancestor and descendant axes even

with a very small amount of partitions. In the case

baseball.xml and 16 partitions per dimension, for ex-

ample, there were only 55 partitions in total. Thus,

there were only 55 rows in the Part table, which is

certainly acceptable considering that there are no less

than 52707 nodes in the Node table. Even in the case

of 256 partitions per dimension, there were only 772

rows in the Part table for ”1998statistics.xml” and

859 rows for ”plays.xml”.

In the case of preceding and following axes,

however, no real acceleration could be observed.

These axes could be actually evaluated very efﬁ-

ciently even without the partitionin, which is due to

the very sophisticated join algorithms implemented

in SQL Server. Nevertheless, considering that the

ancestor and descendant axes were very time-

consuming to evaluate without the partition informa-

tion, we are still convinced that the small amount of

partition information can indeed pull its weight.

6.2 Native Implementation

The evaluation of our native implementation was car-

ried out using the same equipment and data sets which

were used in the relational case. Furthermore, the

same number of partitions per dimension were used

but in these tests, we randomly selected the context

nodes. Figures 4 and 5 present the results obtained

using the native implementation; all results are aver-

ages for 100 iterations. Overall, the ancestor and

descendant axes behaved similarly to the relational

case, i.e., they were considerably accelerated. How-

ever, the preceding and following axes were also

accelerated by roughly a factor of two. This is actu-

ally intuitively clear since an average node has much

more predecessors and followers than it has ances-

tors and descendants, and thus the preceding and

following axes usually result in much larger node

sets. In the case of ancestor axis, for example, the

partitioning can help us to ﬁlter out a massive amount

of nodes, i.e., the most of the descendants, predeces-

sors, and followers, whereas in the case of preceding

axis, a much smaller amount of nodes with respect to

the size of the result can be ﬁltered.

One should also notice that ordering the nodes

according to their preorder numbers favors the

preceding axis over the following axis. After the

preorder numbers have been checked in the case of

preceding axis, we still have to ﬁlter out the ances-

tors using the postorder numbers of the nodes. In

the case of following axis, on the contrary, the de-

scendants have to be ﬁltered, which is a harder task

since a node in an XML tree usually has more de-

scendants than it has ancestors. Conversely, sorting

the nodes according to their postorder numbers favors

the following axis.

7 CONCLUDING REMARKS

In this paper, we discussed a partitioning method

which can considerably accelerate the evaluation of

XPath axes in different XML management systems.

Our method is based on simple properties of the pre-

order and postorder numbers of the nodes in an XML

tree, which makes it very easy to implement. This

was exempliﬁed by presenting two different imple-

ACCELERATING XPATH AXES THROUGH STRUCTURAL PARTITIONING

101

5000

10000

15000

20000

25000

30000

1 10 100

Time (ms)

Partitions

ancestor

descendant

preceding

following

20000

40000

60000

80000

100000

120000

1 10 100

Time (ms)

Partitions

ancestor

descendant

preceding

following

Figure 3: Relational results 1998statistics.xml (left) and plays.xml (right).

20000

40000

60000

80000

100000

120000

1 10 100

Joins

Partitions

ancestor

descendant

preceding

following

100000

200000

300000

400000

500000

600000

700000

1 10 100

Joins

Partitions

ancestor

descendant

preceding

following

Figure 4: Number of joins for the major axes using random context nodes for 1998statistics.xml (left) and plays.xml (right);

native implementation.

100

150

200

250

300

1 10 100

Time (ms)

Partitions

ancestor

descendant

preceding

following

200

400

600

800

1000

1200

1400

1600

1800

2000

1 10 100

Time (ms)

Partitions

ancestor

descendant

preceding

following

Figure 5: Times for the major axes using random context nodes for 1998statistics.xml (left) and plays.xml (right); native

implementation.

WEBIST 2007 - International Conference on Web Information Systems and Technologies

102

mentations of our idea which both indicated that our

approach can lead to considerable performance gains.

REFERENCES

Al-Khalifa, S., Jagadish, H. V., Patel, J. M., Wu, Y., Koudas,

N., & Srivastava, D. (2002). In Proceedings of the

18th International Conference on Data Engineering,

(pp. 141-152).

Barton, C., Charles, P., Goyal, D., Raghavachari, M., Fon-

toura, M., & Josifovski, V. (2003). Streaming XPath

processing with forward and backward axes. In Pro-

ceedings of the 19th International Conference on Data

Engineering, (pp. 455-466).

Dietz, P. F. (1982). Maintaining order in a linked list. In

Proceedings of the 14th Annual Symposium on Theory

of Computing, (pp. 122-127).

Fiebig, T., Helmer, S., Kanne, C-C., Moerkotte, G., Neu-

mann, J., Schiele, R., & Westmann, T. (2003). Natix:

A technology overview. In Web, Web-Services, and

Database Systems, NODe 2002 Web and Database-

Related Workshops, (pp. 12-33).

Grust, T. (2002). Accelerating XPath location steps. In Pro-

ceedings of the 2002 ACM SIGMOD Conference on

Management of Data, (pp. 109-120).

Grust, T., & van Keulen, M. (2003). Tree awareness for re-

lational RDBMS kernels: Staircase join. In Intelligent

Search on XML Data, Applications, Languages, Mod-

els, Implementations, and Benchmarks, (pp. 231-245).

atk

y, M., Pokorn

y, J., & Sn

sel, V. (2004) Implementa-

tion of XPath axes in the multi-dimensional approach

to indexing XML data. In Proceedings of Current

Trends in Database Technology, (pp. 219-229).

Luoma, O. (2005). Modeling nested relationships in XML

documents using relational databases. In Proceedings

of the 31st Conference on Current Trends in Theory

and Practice of Computer Science, (pp. 259-268).

Luoma, O. (2005). Supporting XPath axes with relational

databases using a proxy index. In Proceedings of the

3rd International XML Database Symposium, (pp. 99-

113).

Luoma, O. (2006). Xeek: An efﬁcient method for support-

ing XPath evaluation with relational databases. In Lo-

cal Proceedings of the 10th East-European Confer-

ence on Advances in Databases and Information Sys-

tems, (pp. 30-45).

Peng, F., & Chawathe, S. S. (2003). XPath queries on

streaming data. In Proceedings of the 2003 ACM SIG-

MOD Conference on Management of Data, (pp. 431-

442).

Tang, N., Yu, J. X., Wong, K-F., L

u, K., & Li, J. (2005).

Accelerating XML structural join by partitioning. In

Proceedings of the 16th International Conference on

Database and Expert Systems Applications, (pp. 280-

289).

Yoshikawa, M., Amagasa, T., Shimura, T., & Uemura,

S. (2001) XRel: A path-based approach to stor-

age and retrieval of XML documents using relational

databases. ACM Transactions on Internet Technology,

1(1), 110-141.

W3C (World Wide Web Consortium). Ex-

tensible Markup Language (XML) 1.0.

http://www.w3c.org/TR/REC-xml/.

W3C (World Wide Web Consortium). XML path language

(XPath) 2.0. http://www.w3c.org/TR/xpath20/.

W3C (World Wide Web Consortium).

XQuery 1.0: An XML query language.

http://www.w3c.org/TR/xquery/.

ACCELERATING XPATH AXES THROUGH STRUCTURAL PARTITIONING

103
